Electrolux ERN2201FOW User Manual [en, de, es, fr]

ERN2201FOW
.................................................. ...............................................
EN REFRIGERATOR USER MANUAL 2 FR RÉFRIGÉRATEUR NOTICE D'UTILISATION 18 DE KÜHLSCHRANK BENUTZERINFORMATION 35 KK ТОҢАЗЫТҚЫШ ҚОЛДАНУ ТУРАЛЫ
НҰСҚАУЛАРЫ INSTRUCCIONES
53 70
www.electrolux.com
2
CONTENTS
SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
DAILY USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
HELPFUL HINTS AND TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
WHAT TO DO IF… . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
NOISES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
TECHNICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
ENVIRONMENT CONCERNS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com
Register your product for better service:
www.electrolux.com/productregistration
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
We recommend the use of original spare parts. When contacting Service, ensure that you have the following data available. The information can be found on the rating plate. Model, PNC, Serial Number.
Warning / Caution-Safety information General information and tips Environmental information
Subject to change without notice.
SAFETY INFORMATION
ENGLISH 3
In the interest of your safety and to ensure the correct use, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and acci­dents, it is important to ensure that all peo­ple using the appliance are thoroughly fa­miliar with its operation and safety features. Save these instructions and make sure that they remain with the appliance if it is moved or sold, so that everyone using it through its life will be properly informed on appli­ance use and safety. For the safety of life and property keep the precautions of these user's instructions as the manufacturer is not responsible for damages caused by omission.
CHILDREN AND VULNERABLE PEOPLE SAFETY
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the ap­pliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
• Keep all packaging well away from chil­dren. There is risk of suffocation.
• If you are discarding the appliance pull the plug out of the socket, cut the con­nection cable (as close to the appliance as you can) and remove the door to pre­vent playing children to suffer electric shock or to close themselves into it.
• If this appliance featuring magnetic door seals is to replace an older appliance having a spring lock (latch) on the door or lid, be sure to make that spring lock unusable before you discard the old ap­pliance. This will prevent it from becom­ing a death trap for a child.
GENERAL SAFETY
WARNING!
Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
• The appliance is intended for keeping foodstuff and/or beverages in a normal household as explained in this instruction booklet.
• Do not use a mechanical device or any artificial means to speed up the thawing process.
• Do not use other electrical appliances (such as ice cream makers) inside of re­frigerating appliances, unless they are approved for this purpose by the manu­facturer.
• Do not damage the refrigerant circuit.
• The refrigerant isobutane (R600a) is con­tained within the refrigerant circuit of the appliance, a natural gas with a high level of environmental compatibility, which is nevertheless flammable.
During transportation and installation of the appliance, be certain that none of the components of the refrigerant circuit be­come damaged.
If the refrigerant circuit should become damaged:
– avoid open flames and sources of igni-
tion
– thoroughly ventilate the room in which
the appliance is situated
• It is dangerous to alter the specifications or modify this product in any way. Any damage to the cord may cause a short­circuit, fire and/or electric shock.
WARNING!
Any electrical component (power cord, plug, compressor) must be replaced by a certified service agent or qualified service personnel to avoid hazard.
1.
Power cord must not be lengthened.
2.
Make sure that the power plug is not squashed or damaged by the back of the appliance. A squashed or damaged power plug may overheat and cause a fire.
3.
Make sure that you can come to the mains plug of the appliance.
4.
Do not pull the mains cable.
www.electrolux.com
4
• This appliance is heavy. Care should be
• Do not remove nor touch items from the
• Avoid prolonged exposure of the appli-
• Bulb lamps (if foreseen) used in this ap-
DAILY USE
• Do not put hot pot on the plastic parts in
• Do not store flammable gas and liquid in
• Do not place food products directly
• Frozen food must not be re-frozen once
• Store pre-packed frozen food in accord-
• Appliance's manufacturers storage rec-
• Do not place carbonated or fizzy drinks
• Ice lollies can cause frost burns if con-
CARE AND CLEANING
• Before maintenance, switch off the appli-
• Do not clean the appliance with metal
5.
If the power plug socket is loose, do not insert the power plug. There is a risk of electric shock or fire.
6.
You must not operate the appliance without the lamp cover (if foreseen) of interior lighting.
taken when moving it.
freezer compartment if your hands are damp/wet, as this could cause skin abrasions or frost/freezer burns.
ance to direct sunlight.
pliance are special purpose lamps selec­ted for household appliances use only. They are not suitable for household room illumination.
the appliance.
the appliance, because they may ex­plode.
against the air outlet on the rear wall. (If the appliance is Frost Free)
it has been thawed out.
ance with the frozen food manufacturer's instructions.
ommendations should be strictly ad­hered to. Refer to relevant instructions.
in the freezer compartment as it creates pressure on the container, which may cause it to explode, resulting in damage to the appliance.
sumed straight from the appliance.
ance and disconnect the mains plug from the mains socket.
objects.
• Do not use sharp objects to remove frost from the appliance. Use a plastic scra­per.
• Regularly examine the drain in the refrig­erator for defrosted water. If necessary, clean the drain. If the drain is blocked, water will collect in the bottom of the ap­pliance.
INSTALLATION
For electrical connection carefully follow the instructions given in spe­cific paragraphs.
• Unpack the appliance and check if there are damages on it. Do not connect the appliance if it is damaged. Report possi­ble damages immediately to the place you bought it. In that case retain pack­ing.
• It is advisable to wait at least four hours before connecting the appliance to allow the oil to flow back in the compressor.
• Adequate air circulation should be around the appliance, lacking this leads to overheating. To achieve sufficient ven­tilation follow the instructions relevant to installation.
• Wherever possible the back of the prod­uct should be against a wall to avoid touching or catching warm parts (com­pressor, condenser) to prevent possible burn.
• The appliance must not be located close to radiators or cookers.
• Make sure that the mains plug is acces­sible after the installation of the appli­ance.
• Connect to potable water supply only (If a water connection is foreseen).
SERVICE
• Any electrical work required to do the servicing of the appliance should be car­ried out by a qualified electrician or com­petent person.
• This product must be serviced by an au­thorized Service Centre, and only genu­ine spare parts must be used.
ENVIRONMENT PROTECTION
This appliance does not contain gasses which could damage the ozone layer, in either its refrigerant circuit or insulation materials. The appliance shall not be discarded together with the urban refuse and rubbish. The insulation foam con­tains flammable gases: the appli­ance shall be disposed according to the applicable regulations to ob­tain from your local authorities. Avoid damaging the cooling unit, especially at the rear near the heat exchanger. The materials used on this appliance marked by the sym-
are recyclable.
bol
ENGLISH 5
www.electrolux.com
6
OPERATION
SWITCHING ON
Insert the plug into the wall socket. Turn the Temperature regulator clockwise to a medium setting.
SWITCHING OFF
To turn off the appliance, turn the Temper­ature regulator to the "O" position.
TEMPERATURE REGULATION
The temperature is automatically regulated. To operate the appliance, proceed as fol­lows:
• turn the Temperature regulator toward lower settings to obtain the minimum coldness.
• turn the Temperature regulator toward higher settings to obtain the maximum coldness.
However, the exact setting should be chosen keeping in mind that the tempera­ture inside the appliance depends on:
• room temperature
• how often the door is opened
• the quantity of food stored
• the location of the appliance.
A medium setting is generally the most suitable.
If the ambient temperature is high or the appliance is fully loaded, and the appliance is set to the lowest temperatures, it may run continu­ously causing frost to form on the rear wall. In this case the dial must be set to a higher temperature to allow automatic defrosting and therefore reduced energy con­sumption.
DAILY USE
ENGLISH 7
CLEANING THE INTERIOR
Before using the appliance for the first time, wash the interior and all internal accesso­ries with lukewarm water and some neutral soap so as to remove the typical smell of a brand-new product, then dry thoroughly.
Do not use detergents or abrasive powders, as these will damage the finish.
FREEZING FRESH FOOD
The freezer compartment is suitable for freezing fresh food and storing frozen and deep-frozen food for a long time. To freeze fresh foods it is not necessary to change the medium setting. However, for a faster freezing operation, turn the temperature regulator toward high­er settings to obtain the maximum cold­ness.
In this condition, the refrigerator compartment temperature might drop below 0°C. If this occurs reset the temperature regulator to a warmer setting.
MOVABLE SHELVES
STORAGE OF FROZEN FOOD
When first starting-up or after a period out of use, before putting the products in the compartment let the appliance run at least 2 hours on the higher settings.
In the event of accidental defrost­ing, for example due to a power failure, if the power has been off for longer than the value shown in the technical characteristics chart un­der "rising time", the defrosted food must be consumed quickly or cooked immediately and then re­frozen (after cooling).
THAWING
Deep-frozen or frozen food, prior to being used, can be thawed in the refrigerator compartment or at room temperature, de­pending on the time available for this oper­ation. Small pieces may even be cooked still fro­zen, directly from the freezer: in this case, cooking will take longer.
The walls of the refrigerator are equipped with a series of runners so that the shelves can be positioned as desired.
www.electrolux.com
8
HUMIDITY CONTROL
POSITIONING THE DOOR SHELVES
The glass shelf incorporates a device with slits (adjustable by means of a sliding lever), which makes it possible to regulate the temperature in the vegetable drawer(s). When the ventilation slots are closed: the natural moisture content of the food in the fruit and vegetable compartments is preserved for longer. When the ventilation slots are opened: more air circulation results in a lower air moisture content in the fruit and vegetable compartments.
To permit storage of food packages of vari­ous sizes, the door shelves can be placed at different heights. To make these adjustments proceed as fol­lows: gradually pull the shelf in the direction of the arrows until it comes free, then reposi­tion as required.
1
2
HELPFUL HINTS AND TIPS
ENGLISH 9
HINTS FOR ENERGY SAVING
• Do not open the door frequently or leave it open longer than absolutely necessary.
• If the ambient temperature is high and the Temperature Regulator is set to low temperature and the appliance is fully loaded, the compressor may run contin­uously, causing frost or ice on the evap­orator. If this happens, set the Tempera­ture Regulator toward warmer settings to allow automatic defrosting and so a sav­ing in electricity consumption.
HINTS FOR FRESH FOOD REFRIGERATION
To obtain the best performance:
• do not store warm food or evaporating liquids in the refrigerator
• do cover or wrap the food, particularly if it has a strong flavour
• position food so that air can circulate freely around it
HINTS FOR REFRIGERATION
Useful hints: Meat (all types) : wrap in polythene bags and place on the glass shelf above the veg­etable drawer. For safety, store in this way only one or two days at the most. Cooked foods, cold dishes, etc..: these should be covered and may be placed on any shelf. Fruit and vegetables: these should be thor­oughly cleaned and placed in the special drawer(s) provided. Butter and cheese: these should be placed in special airtight containers or wrapped in aluminium foil or polythene bags to exclude as much air as possible. Milk bottles: these should have a cap and should be stored in the bottle rack on the door. Bananas, potatoes, onions and garlic, if not packed, must not be kept in the refrigera­tor.
• the maximum quantity of food which can be frozen in 24 hrs. is shown on the rat­ing plate;
• the freezing process takes 24 hours. No further food to be frozen should be add­ed during this period;
• only freeze top quality, fresh and thor­oughly cleaned, foodstuffs;
• prepare food in small portions to enable it to be rapidly and completely frozen and to make it possible subsequently to thaw only the quantity required;
• wrap up the food in aluminium foil or pol­ythene and make sure that the packages are airtight;
• do not allow fresh, unfrozen food to touch food which is already frozen, thus avoiding a rise in temperature of the lat­ter;
• lean foods store better and longer than fatty ones; salt reduces the storage life of food;
• water ices, if consumed immediately af­ter removal from the freezer compart­ment, can possibly cause the skin to be freeze burnt;
• it is advisable to show the freezing in date on each individual pack to enable you to keep tab of the storage time.
HINTS FOR STORAGE OF FROZEN FOOD
To obtain the best performance from this appliance, you should:
• make sure that the commercially frozen foodstuffs were adequately stored by the retailer;
• be sure that frozen foodstuffs are trans­ferred from the foodstore to the freezer in the shortest possible time;
• not open the door frequently or leave it open longer than absolutely necessary;
• once defrosted, food deteriorates rapidly and cannot be refrozen;
• do not exceed the storage period indica­ted by the food manufacturer.
HINTS FOR FREEZING
To help you make the most of the freezing process, here are some important hints:
www.electrolux.com
10
CARE AND CLEANING
CAUTION!
Unplug the appliance before carry­ing out any maintenance operation.
This appliance contains hydrocar­bons in its cooling unit; mainte­nance and recharging must there­fore only be carried out by author­ized technicians.
PERIODIC CLEANING
The equipment has to be cleaned regularly:
• clean the inside and accessories with lukewarm water and some neutral soap.
• regularly check the door seals and wipe clean to ensure they are clean and free from debris.
• rinse and dry thoroughly.
Do not pull, move or damage any pipes and/or cables inside the cab­inet. Never use detergents, abrasive powders, highly perfumed cleaning products or wax polishes to clean the interior as this will damage the surface and leave a strong odour.
Clean the condenser (black grill) and the compressor at the back of the appliance with a brush. This operation will improve the performance of the appliance and save electricity consumption.
Many proprietary kitchen surface cleaners contain chemicals that can attack/damage the plastics used in this appliance. For this reason it is recommended that the outer casing of this appliance is only cleaned with warm water with a little washing-up liquid added. After cleaning, reconnect the equipment to the mains supply.
DEFROSTING OF THE REFRIGERATOR
Take care of not to damage the cooling system.
DEFROSTING THE FREEZER
A certain amount of frost will al­ways form around the top com­partment.
Defrost the freezer when the frost layer reaches a thickness of about 3-5 mm.
Frost is automatically eliminated from the evaporator of the refrigerator compartment every time the motor compressor stops, during normal use. The defrost water drains out through a trough into a special contain­er at the back of the appliance, over the motor compressor, where it evaporates. Periodically clean the defrost water drain hole in the middle of the refrigerator com­partment channel to prevent the water overflowing and dripping onto the food in­side. Use the special cleaner provided, which you will find already inserted into the drain hole.
To remove the frost, do these steps:
1.
Switch off the appliance.
2.
Remove any stored food, wrap it in several layers of newspaper and put it in a cool place.
3.
Open the door.
4.
When defrosting is completed, dry the interior thoroughly.
5.
Switch on the appliance.
6.
Set the temperature regulator to obtain the maximum coldness and run the appliance for two or three hours using this setting.
7.
Reload the previously removed food in­to the compartment.
WARNING!
Never use sharp metal tools to scrape off frost from the evaporator as you could damage it. Do not use a mechanical device or any ar­tificial means to speed up the thawing process other than those recommended by the manufactur­er. A temperature rise of the frozen food packs, during defrosting, may shorten their safe storage life.
PERIODS OF NON-OPERATION
When the appliance is not in use for long periods, take the following precautions:
disconnect the appliance from elec-
tricity supply
• remove all food
• defrost (if foreseen) and clean the appli­ance and all accessories
• leave the door/doors ajar to prevent un­pleasant smells.
If the cabinet will be kept on, ask some­body to check it once in a while to prevent the food inside from spoiling in case of a power failure.
ENGLISH 11
www.electrolux.com
12
WHAT TO DO IF…
WARNING!
Before troubleshooting, disconnect the mains plug from the mains socket. Only a qualified electrician or com­petent person must do the trouble­shooting that is not in this manual.
There are some sounds during nor­mal use (compressor, refrigerant circulation).
Problem Possible cause Solution The appliance does
not operate. The
The appliance is switched off.
Switch on the appliance.
lamp does not oper­ate.
The mains plug is not con-
nected to the mains socket
Connect the mains plug to the mains socket correctly.
correctly.
The appliance has no pow-
er. There is no voltage in the mains socket.
Connect a different electrical appliance to the mains sock­et. Contact a qualified electri­cian.
The lamp does not
The lamp is in stand-by. Close and open the door.
work.
The lamp is defective. Refer to "Replacing the
lamp".
The compressor op­erates continually.
The door is not closed cor-
The temperature is not set correctly.
Set a higher temperature.
Refer to "Closing the door".
rectly.
The door has been opened
too frequently.
The product temperature is
too high.
Do not keep the door open longer than necessary.
Let the product temperature decrease to room tempera­ture before storage.
The room temperature is
too high.
Water flows on the rear plate of the re­frigerator.
Water flows into the
During the automatic de­frosting process, frost de­frosts on the rear plate.
The water outlet is clogged. Clean the water outlet.
Decrease the room temper­ature.
This is correct.
refrigerator.
Products prevent that wa-
ter flows into the water col-
Make sure that products do not touch the rear plate.
lector.
Problem Possible cause Solution Water flows on the
ground.
The melting water outlet does not flow in the evapo­rative tray above the com-
Attach the melting water outlet to the evaporative tray.
pressor.
The temperature in the appliance is too
The temperature regulator is not set correctly.
Set a higher temperature.
low. The temperature in
the appliance is too
The temperature regulator is not set correctly.
Set a lower temperature.
high.
The door is not closed cor-
Refer to "Closing the door".
rectly.
The product temperature is
too high.
Let the product temperature decrease to room tempera­ture before storage.
Many products are stored
at the same time.
There is no cold air circula-
tion in the appliance.
Store less products at the same time.
Make sure that there is cold air circulation in the appli­ance.
REPLACING THE LAMP
ENGLISH 13
CLOSING THE DOOR
1.
Clean the door gaskets.
2.
If necessary, adjust the door. Refer to "Installation".
3.
If necessary, replace the defective door gaskets. Contact the Service Center.
1.
Disconnect the mains plug from the mains socket.
2.
Remove the screw from the lamp cov­er.
3.
Remove the lamp cover (refer to the il­lustration).
4.
Replace the used lamp with a new lamp of the same power and specifi­cally designed for household applian­ces. (the maximum power is shown on the lamp cover).
5.
Install the lamp cover.
6.
Tighten the screw to the lamp cover.
7.
Connect the mains plug to the mains socket.
8.
Open the door. Make sure that the lamp comes on.
www.electrolux.com
14
INSTALLATION
WARNING!
Read the "Safety Information" care­fully for your safety and correct op­eration of the appliance before in­stalling the appliance.
POSITIONING
Install this appliance at a location where the ambient temperature corresponds to the climate class indicated on the rating plate of the appliance:
Cli­mate class
SN +10°C to + 32°C N +16°C to + 32°C ST +16°C to + 38°C T +16°C to + 43°C
ELECTRICAL CONNECTION
Before plugging in, ensure that the voltage and frequency shown on the rating plate correspond to your domestic power sup­ply. The appliance must be earthed. The power supply cable plug is provided with a con­tact for this purpose. If the domestic power supply socket is not earthed, connect the appliance to a separate earth in compli­ance with current regulations, consulting a qualified electrician. The manufacturer declines all responsibility if the above safety precautions are not ob­served. This appliance complies with the E.E.C. Di­rectives.
Ambient temperature
Refer to the assembly instructions for the installation.
NOISES
There are some sounds during normal run­ning (compressor, refrigerant circulation).
SSSRRR!
HISSS!
ENGLISH 15
CLICK!
BRRR!
OK
CLICK!
BRRR!
CRACK!
BLUBB!
CLICK!
BRRR!
BLUBB!
BLUBB!
www.electrolux.com
16
HISSS!
HISSS!
TECHNICAL DATA
Dimension of the recess Height 1225 mm Width 560 mm Depth 550 mm Rising Time 12 h Voltage 230-240 V Frequency 50 Hz
The technical information are situated in the rating plate on the internal left side of the appliance and in the energy label.
SSSRRR!
CRACK!
SSSRRR!
CRACK!
ENVIRONMENT CONCERNS
Recycle the materials with the symbol Put the packaging in applicable containers
to recycle it. Help protect the environment and human health and to recycle waste of electrical
and electronic appliances. Do not dispose
.
appliances marked with the symbol the household waste. Return the product
to your local recycling facility or contact your municipal office.
ENGLISH 17
with
www.electrolux.com
18
SOMMAIRE
CONSIGNES DE SÉCURITÉ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
FONCTIONNEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
UTILISATION QUOTIDIENNE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
CONSEILS UTILES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
ENTRETIEN ET NETTOYAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
EN CAS D'ANOMALIE DE FONCTIONNEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
BRUITS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
CARACTÉRISTIQUES TECHNIQUES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
EN MATIÈRE DE PROTECTION DE L'ENVIRONNEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
NOUS PENSONS À VOUS
Merci d'avoir choisi ce produit Electrolux. Avec ce produit, vous bénéficiez de dizaines d'années d'expérience professionnelle et d'innovation. Ingénieux et élégant, il a été conçu sur mesure pour vous. Grâce à cet appareil, vous savez que chaque utilisation vous apportera satisfaction.
Bienvenue chez Electrolux.
Visitez notre site Internet pour :
Obtenir des conseils d'utilisation, des brochures, de l'aide, des informations :
www.electrolux.com
Enregistrer votre produit pour obtenir un meilleur service :
www.electrolux.com/productregistration
Acheter des accessoires, consommables et pièces de rechange d'origine pour votre appareil :
www.electrolux.com/shop
SERVICE APRÈS-VENTE
N'utilisez que des pièces de rechange d'origine. Avant de contacter le service, assurez-vous de disposer des informations suivantes : Vous trouverez ces informations sur la plaque signalétique. Modèle, PNC, numéro de série.
Avertissement/Attention : consignes de sécurité. Informations générales et conseils Informations écologiques
Sous réserve de modifications.
CONSIGNES DE SÉCURITÉ
FRANÇAIS 19
Pour votre sécurité et garantir une utilisa­tion correcte de l'appareil, lisez attentive­ment cette notice, y compris les conseils et avertissements, avant d'installer et d'utiliser l'appareil pour la première fois. Pour éviter toute erreur ou accident, veillez à ce que toute personne qui utilise l'appareil con­naisse bien son fonctionnement et ses fonctions de sécurité. Conservez cette noti­ce avec l'appareil. Si l'appareil doit être vendu ou cédé à une autre personne, veil­lez à remettre cette notice au nouveau pro­priétaire, afin qu'il puisse se familiariser avec son fonctionnement et sa sécurité. Pour la sécurité des personnes et des biens, conservez et respectez les consi­gnes de sécurité figurant dans cette notice. Le fabricant décline toute responsabilité en cas de dommages dus au non-respect de ces instructions.
SÉCURITÉ DES ENFANTS ET DES PERSONNES VULNÉRABLES
• Cet appareil n'est pas destiné à être utili­sé par des enfants ou des personnes dont les capacités physiques, sensoriel­les ou mentales, ou le manque d'expé­rience et de connaissance les empê­chent d'utiliser l'appareil sans risque lorsqu'ils sont sans surveillance ou en l'absence d'instruction d'une personne responsable qui puisse leur assurer une utilisation de l'appareil sans danger.
Empêchez les enfants de jouer avec l'appareil.
• Ne laissez pas les différents emballages à portée des enfants. Ils pourraient s'as­phyxier.
• Si l'appareil doit être mis au rebut, veillez à couper le câble d'alimentation électri­que au ras de l'appareil pour éviter les risques d'électrocution. Démontez la porte pour éviter que des enfants ne res­tent enfermés à l'intérieur.
• Cet appareil est muni de fermetures ma­gnétiques. S'il remplace un appareil équipé d'une fermeture à ressort, nous vous conseillons de rendre celle-ci inutili­sable avant de vous en débarrasser. Ce­ci afin d'éviter aux enfants de s'enfermer
dans l'appareil et de mettre ainsi leur vie en danger.
CONSIGNES GÉNÉRALES DE SÉCURITÉ
AVERTISSEMENT
Veillez à ce que les orifices de ventilation, situés dans l'enceinte de l'appareil ou la structure intégrée, ne soient pas obstrués.
• Les appareils sont destinés uniquement à la conservation des aliments et/ou des boissons dans le cadre d’un usage do­mestique normal, tel que celui décrit dans la présente notice.
• N'utilisez pas d'appareils électriques, d'agents chimiques ou tout autre systè­me artificiel pour accélérer le processus de dégivrage.
• Ne faites pas fonctionner d'appareils électriques (comme des sorbetières électriques, ...) à l'intérieur des appareils de réfrigération à moins que cette utilisa­tion n'ait reçu l'agrément du fabricant.
• N'endommagez pas le circuit frigorifique.
• Le circuit frigorifique de l’appareil con­tient de l’isobutane (R600a), un gaz na­turel offrant un haut niveau de compatibi­lité avec l’environnement mais qui est néanmoins inflammable.
Pendant le transport et l'installation de votre appareil, assurez-vous qu'aucune partie du circuit frigorifique n'est endom­magée.
Si le circuit frigorifique est endommagé : – évitez les flammes vives et toute autre
source d'allumage
– aérez soigneusement la pièce où se
trouve l'appareil
• Ne modifiez pas les spécifications de l'appareil. Si le câble d'alimentation est endommagé, il peut causer un court cir­cuit, un incendie et/ou une électrocution.
www.electrolux.com
20
• Cet appareil est lourd. Faite attention lors
• Ne touchez pas avec les mains humides
• Évitez une exposition prolongée de l'ap-
• Les ampoules (si présentes) utilisées
UTILISATION QUOTIDIENNE
• Ne posez pas d'éléments chauds sur les
• Ne stockez pas de gaz ou de liquides in-
• Ne placez pas d'aliments directement
• Un produit décongelé ne doit jamais être
AVERTISSEMENT
Les éventuelles réparations ou in­terventions sur votre appareil, ainsi que le remplacement du câble d'alimentation, ne doivent être ef­fectuées que par un professionnel qualifié.
1.
Ne branchez pas le cordon d'ali­mentation à une rallonge.
2.
Assurez-vous que la prise n'est pas écrasée ou endommagée par l'arriè­re de l'appareil. Une prise de cou­rant écrasée ou endommagée peut s'échauffer et causer un incendie.
3.
Vérifiez que la prise murale de l'ap­pareil est accessible.
4.
Ne débranchez pas l'appareil en ti­rant sur le câble.
5.
Si la prise murale n'est pas bien fi­xée, n'introduisez pas de prise de­dans. Risque d'électrocution ou d'incendie.
6.
N'utilisez pas l'appareil sans le diffu­seur de l'ampoule (si présent) de l'éclairage intérieur.
de son déplacement.
les surfaces givrées et les produits con­gelés (risque de brûlure et d'arrachement de la peau).
pareil aux rayons solaires.
dans cet appareil sont des ampoules spécifiques uniquement destinées à être utilisées sur des appareils ménagers. Elles ne sont pas du tout adaptées à un éclairage quelconque d'une habitation.
parties en plastique de l'appareil.
flammables dans l'appareil (risque d'ex­plosion).
contre la sortie d'air sur la paroi arrière de l'appareil. (Si l'appareil est sans givre.)
recongelé.
• Conservez les aliments emballés confor­mément aux instructions de leur fabri­cant.
• Respectez scrupuleusement les conseils de conservation donnés par le fabricant de l'appareil. Consultez les instructions respectives.
• Ne mettez pas de bouteilles ni de boîtes de boissons gazeuses dans le comparti­ment congélateur, car la pression se for­mant à l'intérieur du contenant pourrait le faire éclater et endommager ainsi l'appa­reil.
• Ne consommez pas certains produits tels que les bâtonnets glacés dès leur sortie de l'appareil, car ils peuvent pro­voquer des brûlures.
ENTRETIEN ET NETTOYAGE
• Avant toute opération d'entretien, mettez l'appareil hors tension et débranchez-le de la prise de courant.
• N'utilisez pas d'objets métalliques pour nettoyer l'appareil.
• N'utilisez pas d'objet tranchant pour gratter la couche de givre. Utilisez une spatule en plastique.
• Contrôlez régulièrement l'orifice d'éva­cuation de l'eau de dégivrage dans le compartiment réfrigérateur. Nettoyez-le, si besoin. Si l'orifice est bouché, l'eau s'écoulera en bas de l'appareil.
INSTALLATION
Avant de procéder au branche­ment électrique, respectez scrupu­leusement les instructions fournies dans cette notice.
• Déballez l'appareil et vérifiez qu'il n'est pas endommagé. Ne branchez pas l'ap­pareil s'il est endommagé. Signalez im­médiatement au revendeur de l'appareil les dommages constatés. Dans ce cas, gardez l'emballage.
• Il est conseillé d'attendre au moins qua­tre heures avant de brancher l'appareil pour que le circuit frigorifique soit stabili­sé.
• Veillez à ce que l'air circule librement au­tour de l'appareil pour éviter qu'il ne sur­chauffe. Pour assurer une ventilation suf­fisante, respectez les instructions de la notice (chapitre Installation).
• Placez l'appareil dos au mur pour éviter tout contact avec le compresseur et le condenseur (risque de brûlure).
• Placez de préférence votre appareil loin d'une source de chaleur (chauffage, cuisson ou rayons solaires trop intenses).
• Assurez-vous que la prise murale reste accessible après l'installation de l'appa­reil.
• Branchez à l'alimentation en eau potable uniquement. (Si un branchement sur le réseau d'eau est prévu.)
MAINTENANCE
• Les branchements électriques nécessai­res à l'entretien de l'appareil doivent être réalisés par un électricien qualifié ou une personne compétente.
• Cet appareil ne doit être entretenu et ré­paré que par un Service après-vente au­torisé, exclusivement avec des pièces d'origine.
PROTECTION DE L'ENVIRONNEMENT
Le système frigorifique et l'isolation de votre appareil ne contiennent pas de C.F.C. contribuant ainsi à préserver l'environnement. L'appa­reil ne doit pas être mis au rebut avec les ordures ménagères et les déchets urbains. La mousse d'iso­lation contient des gaz inflamma­bles : l'appareil sera mis au rebut conformément aux règlements ap­plicables disponibles auprès des autorités locales. Veillez à ne pas détériorer les circuits frigorifiques, notamment au niveau du conden­seur. Les matériaux utilisés dans cet appareil identifiés par le symbo-
sont recyclables.
le
FRANÇAIS 21
www.electrolux.com
22
FONCTIONNEMENT
MISE EN FONCTIONNEMENT
Branchez l'appareil sur une prise murale. Tournez le bouton du thermostat dans le sens des aiguilles d'une montre sur une position moyenne.
MISE À L'ARRÊT
Pour mettre à l'arrêt l'appareil, tournez le bouton du thermostat sur la position "O".
RÉGLAGE DE LA TEMPÉRATURE
La température est réglée automatique­ment. Pour faire fonctionner l'appareil, procédez comme suit :
• tournez le bouton du thermostat vers le bas pour obtenir un réglage de froid mi­nimum.
• tournez le bouton du thermostat vers le haut pour obtenir un réglage de froid maximum.
Une position moyenne est la plus indiquée.
Toutefois, le réglage doit être choisi en te­nant compte du fait que la température à l'intérieur de l'appareil dépend de plusieurs facteurs :
• la température ambiante
• la fréquence d'ouverture de la porte
• la quantité de denrées stockées
• l'emplacement de l'appareil.
Si le thermostat est réglé sur la po­sition de froid maximum, lorsque la température ambiante est élevée et que l'appareil est plein, il est pos­sible que le compresseur fonction­ne en régime continu. Dans ce cas, il y a un risque de formation exces­sive de givre sur la paroi postérieu­re à l'intérieur de l'appareil. Pour éviter cet inconvénient, placez le thermostat sur une température plus élevée de façon à permettre un dégivrage automatique et, par conséquent, des économies de courant.
UTILISATION QUOTIDIENNE
FRANÇAIS 23
NETTOYAGE INTÉRIEUR
Avant d'utiliser l'appareil pour la première fois, nettoyez l'intérieur et tous les acces­soires internes avec de l'eau tiède savon­neuse pour supprimer l'odeur caractéristi­que du "neuf" puis séchez soigneusement.
N'utilisez pas de produits abrasifs, poudre à récurer, éponge métalli­que pour ne pas abîmer la finition.
CONGÉLATION D'ALIMENTS FRAIS
Le compartiment congélateur est idéal pour congeler des denrées fraîches et con­server les aliments surgelés ou congelés pendant longtemps. Pour congeler des aliments frais, il n'est pas nécessaire de modifier le réglage moyen. Toutefois, pour une congélation plus rapi­de, tournez le thermostat vers le haut pour obtenir plus de froid.
Dans ce cas, la température du compartiment réfrigérateur peut chuter au-dessous de 0°C. Si cela se produit, repositionnez le ther­mostat sur un réglage plus chaud.
Max pendant 2 heures environ, avant d'in­troduire les produits dans le compartiment.
En cas de dégivrage accidentel, dû par exemple à une panne de cou­rant, si la panne doit se prolonger plus longtemps qu'il n'est indiqué à la rubrique "temps d'augmentation" dans la section Caractéristiques techniques, consommez les ali­ments décongelés le plus rapide­ment possible ou recongelez-les après les avoir cuits (une fois refroi­dis).
LA DÉCONGÉLATION
Les aliments surgelés ou congelés peuvent être décongelés dans le compartiment ré­frigérateur ou à température ambiante, avant d'être utilisés, en fonction du temps disponible pour cette opération. Les petites pièces peuvent même être cui­tes sans décongélation préalable : dans ce cas, la cuisson est plus longue.
CONSERVATION DES ALIMENTS CONGELÉS
À la mise en service ou après un arrêt pro­longé, placez le thermostat sur la position
CLAYETTES AMOVIBLES
Plusieurs glissières ont été installées sur les parois du réfrigérateur pour vous permettre de placer les clayettes comme vous le sou­haitez.
www.electrolux.com
24
CONTRÔLE DE L'HUMIDITÉ
METTEZ EN PLACE LES BALCONNETS DE LA PORTE.
La clayette inférieure en verre est équipée d'un dispositif muni de fentes dont les ou­vertures sont réglables à l'aide d'un levier coulissant, afin de réguler la température du bac à légumes. Lorsque les fentes de ventilation sont fer­mées : le taux d'humidité naturel des aliments con­servés dans le bac à fruits et légumes est préservé plus longtemps. Lorsque les fentes de ventilation sont ou­vertes : le taux d'humidité est plus bas, car la circu­lation d'air est plus importante.
Selon la taille des emballages des aliments conservés, les balconnets de la porte peu­vent être positionnés à différentes hau­teurs. Pour les ajuster, procédez comme suit : tirez progressivement sur le balconnet dans le sens des flèches pour le dégager, puis repositionnez-le selon vos besoins.
1
2
CONSEILS UTILES
FRANÇAIS 25
CONSEILS POUR L'ÉCONOMIE D'ÉNERGIE
• N'ouvrez pas la porte trop souvent ou plus longtemps que nécessaire.
• Si la température ambiante est élevée, le dispositif de réglage de température est sur la position de froid maximum et l'ap­pareil est plein : il est possible que le compresseur fonctionne en régime con­tinu, d'où un risque de formation exces­sive de givre sur l'évaporateur. Pour évi­ter ceci, modifiez la position du dispositif de réglage de température de façon à obtenir des périodes d'arrêt du com­presseur et ainsi permettre un dégivrage automatique, d'où des économies d'énergie.
CONSEILS POUR LA RÉFRIGÉRATION DE DENRÉES FRAÎCHES
Pour obtenir les meilleures performances possibles :
• N'introduisez pas d'aliments encore chauds ou de liquides en évaporation dans le réfrigérateur.
• Couvrez ou enveloppez soigneusement les aliments, surtout s'ils sont aromati­ques.
• Placez les aliments pour que l'air puisse circuler librement autour.
CONSEILS POUR LA RÉFRIGÉRATION
Conseils utiles : Viande (tous les types) : enveloppez-la dans des sachets en plastique et placez-la sur la tablette en verre au-dessus du bac à légumes. La période de conservation est de 1 à 2 jours au maximum. Aliments cuits, plats froids, etc. : placez-les bien couverts sur une clayette. Fruits et légumes : placez-les une fois net­toyés dans le(s) bac(s) à légumes fourni(s). Beurre et fromage : placez-les dans des ré­cipients étanches spéciaux ou enveloppez­les soigneusement dans des feuilles d'alu­minium ou de polyéthylène, pour emmaga­siner le moins d'air possible.
Lait en bouteille : bouchez-le et placez-le dans le balconnet de la contreporte réservé aux bouteilles. Bananes, pommes de terre, oignons et ail ne se conservent pas au réfrigérateur, s'ils ne sont pas correctement emballés.
CONSEILS POUR LA CONGÉLATION
Pour obtenir les meilleurs résultats, voici quelques conseils importants :
• la quantité maximale de denrées que vous pouvez congeler par 24 heures est indiquée sur la plaque signalétique.
• le temps de congélation est de 24 heu­res. Aucune autre denrée à congeler ne doit être ajoutée pendant cette période.
• congelez seulement les denrées alimen­taires fraîches, de qualité supérieure (une fois nettoyées).
• préparez la nourriture en petits paquets pour une congélation rapide et uniforme, adaptés à l'importance de la consom­mation.
• enveloppez les aliments dans des feuilles d'aluminium ou de polyéthylène et assu­rez-vous que les emballages sont étan­ches ;
• ne laissez pas des aliments frais, non congelés, toucher des aliments déjà congelés pour éviter une remontée en température de ces derniers.
• les aliments maigres se conservent mieux et plus longtemps que les ali­ments gras ; le sel réduit la durée de conservation des aliments
• la température très basse à laquelle se trouvent les bâtonnets glacés, s'ils sont consommés dès leur sortie du comparti­ment congélateur, peut provoquer des brûlures.
• L'identification des emballages est im­portante : indiquez la date de congéla­tion du produit, et respectez la durée de conservation indiquée par le fabricant.
CONSEILS POUR LA CONSERVATION DES
www.electrolux.com
26
PRODUITS SURGELÉS ET CONGELÉS DU COMMERCE
Pour une bonne conservation des produits surgelés et congelés, vous devez :
• vous assurer qu'ils ont bien été conser-
• prévoir un temps réduit au minimum
• éviter d'ouvrir trop souvent la porte du
• une fois décongelés, les aliments se dé-
• respecter la durée de conservation indi-
vés au magasin ;
pour leur transport du magasin d'alimen­tation à votre domicile ;
congélateur et ne la laisser ouverte que le temps nécessaire.
tériorent rapidement et ne peuvent pas être recongelés.
quée par le fabricant.
ENTRETIEN ET NETTOYAGE
FRANÇAIS 27
ATTENTION
débrancher l'appareil avant toute opération d'entretien.
Cet appareil contient des hydrocar­bures dans son circuit réfrigérant : l'entretien et la recharge ne doivent donc être effectués que par du personnel autorisé.
NETTOYAGE PÉRIODIQUE
Cet appareil doit être nettoyé régulière­ment :
• Nettoyez l'intérieur et tous les accessoi­res avec de l'eau tiède savonneuse.
• Vérifiez régulièrement les joints de porte et nettoyez-les en les essuyant pour évi­ter toute accumulation de déchets.
• Rincez et séchez soigneusement.
Ne pas tirer, déplacer ou endom­mager les tuyaux et/ou câbles qui se trouvent à l'intérieur de l'appa­reil. Ne JAMAIS utiliser de produits abrasifs ou caustiques ni d'épon­ges avec grattoir pour nettoyer l'in­térieur de façon à ne pas l'abîmer et laisser de fortes odeurs.
Nettoyer le condenseur (grille noire) et le compresseur situés à l'arrière de l'appareil avec une brosse ou un aspirateur. Cette opération améliore les performances de l'appareil et permet des économies d'éner­gie.
Attention à ne pas endommager le système de réfrigération.
De nombreux détergents pour la cuisine re­commandés par les fabricants contiennent des produits chimiques qui peuvent atta­quer/endommager les pièces en plastique utilisées dans cet appareil. Il est par consé­quent recommandé d'utiliser seulement de l'eau chaude additionnée d'un peu de sa­von liquide pour nettoyer la carrosserie de l'appareil. Après le nettoyage, rebranchez l'appareil.
DÉGIVRAGE DU RÉFRIGÉRATEUR
En fonctionnement normal, le givre est au­tomatiquement éliminé de l'évaporateur du compartiment réfrigérateur à chaque fois que le compresseur s'arrête. L'eau de dé­givrage est collectée dans un récipient spé­cial situé à l'arrière de l'appareil, au-dessus du compresseur, d'où elle s'évapore. Nettoyez régulièrement l'orifice d'écoule­ment de la goulotte d'évacuation de l'eau de dégivrage située au milieu du comparti­ment réfrigérateur pour empêcher l'eau de déborder et de couler à l'intérieur de l'ap­pareil. Nettoyez l'orifice d'écoulement de l'eau de dégivrage avec le bâtonnet spécial se trouvant déjà dans l'orifice.
www.electrolux.com
28
DÉGIVRAGE DU COMPARTIMENT CONGÉLATEUR
Pour enlever le givre, suivez les instructions ci-dessous :
1.
2.
3.
4.
5.
6.
7.
Une certaine quantité de givre se forme toujours autour du comparti­ment supérieur.
Dégivrez le compartiment congéla­teur lorsque l'épaisseur de la cou­che de givre est d'environ 3-5 mm.
Mettez l'appareil à l'arrêt. Sortez les denrées congelées, enve-
loppez celles-ci dans plusieurs feuilles de papier journal et conservez-les dans un endroit frais.
Ouvrez la porte. Le dégivrage terminé, épongez et sé-
chez bien l'intérieur. Mettez l'appareil en fonctionnement. Réglez le thermostat pour obtenir plus
de froid et faites fonctionner l'appareil pendant deux ou trois heures en utili­sant ce réglage.
Replacez les produits surgelés ou con­gelés dans le compartiment.
AVERTISSEMENT
N'utilisez en aucun cas de couteau ou tout autre objet tranchant, d'ob­jet métallique pour gratter la cou­che de givre, vous risquez de dété­riorer irrémédiablement l'évapora­teur. N'utilisez aucun autre disposi­tif mécanique ou moyen artificiel que ceux qui sont recommandés par le fabricant pour accélérer le dégivrage de votre appareil. Une élévation de la température des denrées congelées, pendant la dé­congélation, peut réduire leur durée de conservation.
• laissez la porte/les portes entrouverte(s) pour prévenir la formation d'odeurs dés­agréables.
Si, toutefois, vous n'avez pas la possibilité de débrancher et vider l'appareiI, faites vé­rifier régulièrement son bon fonctionnement pour éviter la détérioration des aliments en cas de panne de courant.
EN CAS D'ABSENCE PROLONGÉE OU DE NON­UTILISATION
Prenez les précautions suivantes :
débranchez l'appareil
• retirez tous les aliments
• dégivrez si nécessaire et nettoyez l'ap­pareil ainsi que tous les accessoires
EN CAS D'ANOMALIE DE FONCTIONNEMENT
FRANÇAIS 29
AVERTISSEMENT
Avant de résoudre les problèmes, débranchez l'appareil. La résolution des problèmes, non mentionnés dans le présent ma­nuel, doit être exclusivement con­fiée à un électricien qualifié ou une personne compétente.
Certains bruits pendant le fonction­nement (compresseur, système ré­frigérant) sont normaux.
Anomalie Cause possible Remède L'appareil ne fonc-
tionne pas. L'ampou-
L'appareil est à l'arrêt. Mettez l'appareil en fonc-
tionnement.
le ne fonctionne pas.
La fiche n'est pas correcte-
ment branchée sur la prise
Branchez correctement la fi­che sur la prise de courant.
de courant.
Le courant n'arrive pas à
l'appareil. La prise de cou­rant n'est pas alimentée.
Branchez un autre appareil électrique sur la prise de courant. Faites appel à un électricien qualifié.
L'ampoule ne fonc­tionne pas.
L'ampoule est défectueu-
L'ampoule est en mode veille.
se.
Ouvrez et fermez la porte.
Consultez le paragraphe "Remplacement de l'ampou­le".
Le compresseur fonctionne en per-
La température n'est pas correctement réglée.
Sélectionnez une températu­re plus élevée.
manence.
La porte n'est pas correc-
tement fermée.
La porte a été ouverte trop
souvent.
Consultez le paragraphe "Fermeture de la porte".
Ne laissez pas la porte ou­verte plus longtemps que nécessaire.
La température du produit
est trop élevée.
Laissez le produit revenir à température ambiante avant de le ranger dans l'appareil.
La température ambiante
est trop élevée.
De l'eau s'écoule sur la plaque arrière du compartiment réfri-
Pendant le dégivrage auto­matique, le givre fond sur la plaque arrière.
Réduisez la température ambiante.
Ce phénomène est normal.
gérateur. De l'eau s'écoule
dans le comparti­ment réfrigérateur.
La gouttière d'évacuation de l'eau de dégivrage est obstruée.
Nettoyez la gouttière d'éva­cuation.
www.electrolux.com
30
Anomalie Cause possible Remède
Des produits empêchent
De l'eau coule sur le sol.
La température à l'intérieur de l'appa­reil est trop basse.
La température à l'intérieur de l'appa­reil est trop élevée.
La porte n'est pas correc-
La température du produit
Trop de produits ont été in-
L'air froid ne circule pas
l'eau de s'écouler dans le réservoir d'eau.
L'eau de dégivrage ne s'écoule pas dans le pla­teau d'évaporation situé au-dessus du compres­seur.
La température n'est pas correctement réglée.
La température n'est pas correctement réglée.
tement fermée.
est trop élevée.
troduits simultanément.
dans l'appareil.
Assurez-vous que les pro­duits ne touchent pas la pla­que arrière.
Fixez la gouttière d'évacua­tion de l'eau au plateau d'évaporation.
Sélectionnez une températu­re plus élevée.
Sélectionnez une températu­re plus basse.
Consultez le paragraphe "Fermeture de la porte".
Laissez le produit revenir à température ambiante avant de le ranger dans l'appareil.
Introduisez moins de pro­duits en même temps.
Assurez-vous que l'air froid circule dans l'appareil.
REMPLACEMENT DE L'ÉCLAIRAGE
FERMETURE DE LA PORTE
1.
Nettoyez les joints de la porte.
2.
Si nécessaire, ajustez la porte. Repor­tez-vous au chapitre « Installation ».
1.
Débranchez l'appareil de la prise sec­teur.
2.
Retirez la vis du diffuseur.
3.
Retirez le diffuseur (voir l'illustration).
4.
Remplacez l'ampoule défectueuse par une ampoule neuve de puissance identique, spécifiquement conçue pour les appareils électroménagers. (La puissance maximale est indiquée sur le diffuseur.)
5.
Installez le diffuseur de l'ampoule.
6.
Serrez la vis du diffuseur.
7.
Branchez l'appareil sur le secteur.
8.
Ouvrez la porte. Vérifiez que l'ampoule s'allume.
3.
Si nécessaire, remplacez les joints de porte défectueux. Contactez votre ser­vice après-vente.
INSTALLATION
AVERTISSEMENT
Pour votre sécurité et le bon fonc­tionnement de l'appareil, veuillez li­re attentivement les « Consignes de sécurité » de cette notice d'utilisa­tion avant de procéder à l'installa­tion.
EMPLACEMENT
Installez cet appareil à un endroit où la température ambiante correspond à la classe climatique indiquée sur la plaque si­gnalétique de l'appareil :
Classe clima­tique
SN +10 à + 32 °C N +16 à + 32 °C ST +16 à + 38 °C T +16 à + 43 °C
BRANCHEMENT ÉLECTRIQUE
Contrôlez, avant de brancher l'appareil, si la tension et la fréquence indiquées sur la plaque signalétique correspondent à celles de votre réseau. L'appareil doit être relié à la terre. La fiche du câble d'alimentation comporte un loge­ment pour mise à la terre. Si la prise de courant murale n'est pas mise à la terre, branchez l'appareil sur une prise de terre conformément aux normes en vigueur, en demandant conseil à un électricien qualifié. Le fabricant décline toute responsabilité en cas d'incident suite au non-respect des consignes de sécurité sus-mentionnées. Cet appareil est conforme aux directives communautaires.
Température ambiante
Consultez la notice de montage lors de l'installation.
FRANÇAIS 31
www.electrolux.com
32
BRUITS
L'appareil émet certains bruits pendant son fonctionnement (compresseur, circuit frigo­rifique).
SSSRRR!
HISSS!
CLICK!
BRRR!
OK
CLICK!
BRRR!
CRACK!
BLUBB!
CLICK!
BRRR!
BLUBB!
BLUBB!
HISSS!
FRANÇAIS 33
HISSS!
SSSRRR!
CRACK!
CARACTÉRISTIQUES TECHNIQUES
Dimensions de la niche d'encastrement
Hauteur 1225 mm Largeur 560 mm Profondeur 550 mm Temps de levée 12 h Tension 230-240 V Fréquence 50 Hz
Les caractéristiques techniques figurent sur la plaque signalétique située sur le côté
SSSRRR!
CRACK!
gauche à l'intérieur de l'appareil et sur l'éti­quette énergétique.
www.electrolux.com
34
EN MATIÈRE DE PROTECTION DE L'ENVIRONNEMENT
Recyclez les matériaux portant le symbole
. Déposez les emballages dans les
conteneurs prévus à cet effet. Contribuez à la protection de l'environnement et à votre sécurité, recyclez vos produits électriques et
électroniques. Ne jetez pas les appareils portant le symbole
ménagères. Emmenez un tel produit dans votre centre local de recyclage ou contactez vos services municipaux.
avec les ordures
DEUTSCH 35
INHALT
SICHERHEITSHINWEISE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
BETRIEB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
TÄGLICHER GEBRAUCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
PRAKTISCHE TIPPS UND HINWEISE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
REINIGUNG UND PFLEGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
WAS TUN, WENN … . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
MONTAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
GERÄUSCHE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
TECHNISCHE DATEN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
UMWELTTIPPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
WIR DENKEN AN SIE
Vielen Dank, dass Sie sich für ein Electrolux Gerät entschieden haben. Sie haben ein Produkt gewählt, hinter dem eine jahrzehntelange professionelle Erfahrung und Innovation steht. Bei der Entwicklung dieses großartigen und eleganten Geräts haben wir an Sie gedacht. So haben Sie bei jedem Gebrauch die Gewissheit, dass Sie stets großartige Ergebnisse erzielen werden.
Willkommen bei Electrolux.
Besuchen Sie uns auf unserer Website, um:
Anwendungshinweise, Prospekte, Fehlerbehebungs- und Service-Informationen zu erhalten:
www.electrolux.com
Ihr erworbenes Produkt zu registrieren, um den besten Service dafür zu gewährleisten:
www.electrolux.com/productregistration
Zubehör, Verbrauchsmaterial und Original-Ersatzteile für Ihr Gerät zu erwerben:
www.electrolux.com/shop
KUNDENDIENST UND -BETREUUNG
Bitte verwenden Sie ausschließlich Original-Ersatzteile für Ihre Produkte. Halten Sie folgende Angaben bereit, wenn Sie sich an den Kundendienst wenden (diese Informationen finden Sie auf dem Typenschild): Modell, Produktnummer (PNC), Seriennummer.
Warnungs-/ Sicherheitshinweise. Allgemeine Hinweise und Ratschläge Hinweise zum Umweltschutz
Änderungen vorbehalten.
www.electrolux.com
36
SICHERHEITSHINWEISE
Lesen Sie zu Ihrer Sicherheit und für die optimale Geräteanwendung vor der Instal­lation und dem Gebrauch des Gerätes die vorliegende Benutzerinformation aufmerk­sam durch, einschließlich der Ratschläge und Warnungen. Es ist wichtig, dass zur Vermeidung von Fehlern und Unfällen alle Personen, die das Gerät benutzen, mit der Bedienung und den Sicherheitsvorschriften vertraut sind. Heben Sie die Benutzerinfor­mation gut auf und übergeben Sie sie bei einem Weiterverkauf des Gerätes dem neu­en Besitzer, so dass jeder während der ge­samten Lebensdauer des Gerätes über Gebrauch und Sicherheit informiert ist. Halten Sie sich zu Ihrer Sicherheit und zum Schutz Ihres Eigentums strikt an die Vor­sichtsmaßnahmen der vorliegenden Benut­zerinformation, da der Hersteller bei Miss­achtung derselben von jeder Haftung frei­gestellt ist.
SICHERHEIT VON KINDERN UND HILFSBEDÜRFTIGEN PERSONEN
•Das Gerät darf von Personen (einschließ­lich Kindern), deren physische, sensori­sche Fähigkeiten und deren Mangel an Erfahrung und Kenntnissen einen siche­ren Gebrauch des Gerätes ausschließen nur unter Aufsicht oder nach ausreichen­der Einweisung durch eine verantwor­tungsbewusste Person benutzt werden, die sicherstellt, dass sie sich der Gefah­ren des Gebrauchs bewusst sind.
Kinder müssen beaufsichtigt werden, da­mit sie nicht am Gerät herumspielen kön­nen.
• Halten Sie das Verpackungsmaterial un­bedingt von Kindern fern. Erstickungsge­fahr!
• Ziehen Sie vor der Entsorgung des Gerä­tes den Netzstecker, schneiden Sie das Netzkabel (so nah wie möglich am Gerät) ab und entfernen Sie die Tür, so dass spielende Kinder vor elektrischem Schlag geschützt sind und sich nicht in dem Ge­rät einschließen können.
• Wenn dieses Gerät mit magnetischer Türdichtung ein älteres Modell mit Schnappverschluss (Türlasche) an der Tür oder auf dem Deckel ersetzt, ma-
chen Sie den Schnappverschluss vor dem Entsorgen des Altgerätes un­brauchbar. So verhindern Sie, dass das Gerät nicht zu einer Todesfalle für Kinder wird.
ALLGEMEINE SICHERHEITSHINWEISE
WARNUNG!
Achten Sie darauf, dass die Belüftungsöff­nungen im Gehäuse oder in der Einbauni­sche nicht blockiert sind.
• Das Gerät ist für die Aufbewahrung von Lebensmitteln und/oder Getränken in ei­nem normalen Haushalt bestimmt, wie in der vorliegenden Gebrauchsanweisung beschrieben wird.
• Benutzen Sie keine mechanischen oder sonstigen Hilfsmittel, um den Abtaupro­zess zu beschleunigen.
• Verwenden Sie keine anderen Elektroge­räte (wie Speiseeisbereiter) in Kühlgerä­ten, wenn solche Geräte nicht ausdrück­lich vom Hersteller für diesen Zweck zu­gelassen sind.
• Beschädigen Sie nicht den Kältekreis­lauf.
• Das Kältemittel Isobutan (R600a) im Käl­tekreislauf des Gerätes ist ein natürliches und sehr umweltfreundliches Gas, das jedoch leicht entflammbar ist.
Achten Sie beim Transport und bei der Aufstellung des Gerätes darauf, nicht die Komponenten des Kältekreislaufs zu be­schädigen.
Bei einer eventuellen Beschädigung des Kältekreislaufs:
– Offene Flammen und Zündfunken ver-
meiden
– Den Raum, in dem das Gerät installiert
ist, gut lüften
• Technische und anderweitige Änderun­gen am Gerät sind gefährlich. Ein defek­tes Netzkabel kann Kurzschlüsse und ei­nen Brand verursachen und/oder zu Stromschlägen führen.
WARNUNG!
Elektrische Bauteile (Netzkabel, Stecker, Kompressor) dürfen zur Vermeidung von Gefahren nur vom Kundendienst oder einer Fachkraft ausgewechselt werden.
1.
Das Netzkabel darf nicht verlängert werden.
2.
Vergewissern Sie sich, dass der Netzstecker nicht von der Geräte­rückseite geklemmt oder beschädigt wird. Ein geklemmter oder beschä­digter Netzstecker überhitzt und kann einen Brand verursachen.
3.
Vergewissern Sie sich, dass der Netzstecker des Geräts frei zugäng­lich ist.
4.
Ziehen Sie nicht am Netzkabel.
5.
Stecken Sie den Netzstecker nie in eine lockere Steckdose. Es besteht Brand- und Stromschlaggefahr.
6.
Betreiben Sie das Gerät nicht ohne Lampenabdeckung (wenn vorgese­hen) der internen Beleuchtung.
• Dieses Gerät ist schwer. Vorsicht beim Transport.
• Entnehmen oder berühren Sie nie mit nassen/feuchten Händen Tiefkühlgut, da dies zu Hautverletzungen oder Kältever­brennungen führen kann.
• Das Gerät nicht direkter Sonneneinstrah­lung aussetzen.
• Die Leuchtmittel (wenn vorgesehen) in diesem Gerät sind Speziallampen, die nur für Haushaltsgeräte geeignet sind. Sie eignen sich nicht zur Raumbeleuch­tung.
TÄGLICHER GEBRAUCH
• Stellen Sie keine heißen Töpfe auf die Kunststoffteile des Gerätes.
• Lagern Sie keine feuergefährlichen Gase oder Flüssigkeiten in dem Gerät. Explosi­onsgefahr.
• Legen Sie Lebensmittel nicht direkt vor den Luftauslass in der Rückwand. (Wenn es ein No-Frost-Gerät ist)
• Ein aufgetautes Produkt darf nicht wie­der eingefroren werden.
• Abgepackte Tiefkühlkost immer entspre­chend den Herstellerangaben aufbewah­ren.
DEUTSCH 37
• Die Lagerempfehlungen des Gerätehers­tellers sollten strikt eingehalten werden. Halten Sie sich an die betreffenden An­weisungen.
• Keine kohlensäurehaltigen Getränke oder Sprudel in den Tiefkühlschrank stellen, da der Druckanstieg in den Behältern zur Explosion führen und das Gerät beschä­digen kann.
• Eis am Stiel kann Kälteverbrennungen verursachen, wenn es direkt nach der Entnahme aus dem Gefrierschrank ge­gessen wird.
REINIGUNG UND PFLEGE
• Schalten Sie vor Wartungsarbeiten im­mer das Gerät ab und ziehen Sie den Netzstecker aus der Steckdose.
• Reinigen Sie das Gerät nicht mit Metall­gegenständen.
• Keine scharfen Gegenstände zum Ent­fernen von Reif und Eis im Gerät verwen­den. Verwenden Sie einen Kunststoffsc­haber.
• Kontrollieren Sie den Tauwasserabfluss im Kühlraum in regelmäßigen Abständen. Reinigen Sie den Ablauf, falls nötig. Bei verstopftem Wasserabfluss sammelt sich das Wasser auf dem Boden des Geräts an.
MONTAGE
Halten Sie sich für den elektrischen Anschluss strikt an die Anweisun­gen der betreffenden Abschnitte.
• Kontrollieren Sie nach dem Auspacken das Gerät auf eventuelle Beschädigun­gen. Nehmen Sie das Gerät nicht in Be­trieb, wenn es beschädigt ist. Melden Sie die Schäden umgehend dem Händler, bei dem Sie es erworben haben. Bewah­ren Sie in diesem Fall die Verpackung auf.
• Lassen Sie das Gerät mindestens vier Stunden stehen, bevor Sie es elektrisch anschließen, damit das Öl in den Kom­pressor zurückfließen kann.
• Ausreichenden Freiraum zur Luftzirkulati­on um das Gerät lassen; anderenfalls besteht Überhitzungsgefahr. Halten Sie sich für die Belüftung an die Installations­anweisungen.
www.electrolux.com
38
• Das Gerät sollte zur Vermeidung von
• Das Gerät darf nicht in der Nähe von
• Vergewissern Sie sich, dass der Netzste-
• Wenn ein Wasseranschluss vorgesehen
KUNDENDIENST
• Sollte die Wartung des Gerätes elektri-
• Wenden Sie sich für Reparaturen und
UMWELTSCHUTZ
Verbrennungen durch Berührung von heißen Bauteilen (Kompressor, Konden­sator) möglichst mit der Rückseite gegen eine Wand aufgestellt werden.
Heizkörpern oder Kochern installiert wer­den.
cker des Gerätes nach der Installation frei zugänglich ist.
ist, verbinden Sie das Gerät nur mit dem Trinkwasseranschluss.
sche Arbeiten verlangen, so dürfen diese nur von einem qualifizierten Elektriker oder einem Elektro-Fachmann durchge­führt werden.
Wartung nur an Fachkräfte der autori­sierten Kundendienststellen und verlan­gen Sie stets Original-Ersatzteile.
Das Gerät enthält im Kältekreis oder in dem Isoliermaterial keine ozonschädigenden Gase. Das Ge­rät darf nicht wie normaler Haus­müll entsorgt werden. Die Isolie­rung enthält entzündliche Gase: das Gerät muss gemäß den gelten­den Vorschriften entsorgt werden; sie erhalten diese bei Ihrer Gemein­deverwaltung. Nicht das Kälteag­gregat beschädigen, insbesondere nicht in der Nähe des Wärmetau­schers. Die Materialien, die bei der Herstellung dieses Geräts verwen­det wurden und mit dem Symbol
markiert sind, können recycelt
werden.
BETRIEB
EINSCHALTEN DES GERÄTS
Stecken Sie den Stecker in die Wandsteck­dose. Drehen Sie den Temperaturregler im Uhr­zeigersinn auf eine mittlere Einstellung.
AUSSCHALTEN DES GERÄTS
Drehen Sie den Temperaturregler zum Aus­schalten des Geräts in die Position "O".
TEMPERATURREGELUNG
Die Temperatur wird automatisch geregelt. Bedienen Sie das Gerät wie folgt:
• drehen Sie den Temperaturregler auf ei-
• drehen Sie den Temperaturregler auf ei-
Allerdings muss für eine exakte Einstellung berücksichtigt werden, dass die Tempera­tur im Innern des Gerätes von verschiede­nen Faktoren abhängt:
• von der Raumtemperatur
• von der Häufigkeit der Türöffnung
• von der Menge der eingelagerten Le-
• und vom Standort des Geräts.
DEUTSCH 39
ne niedrigere Einstellung, um die minimal mögliche Kühlung zu erreichen.
ne höhere Einstellung, um die maximal mögliche Kühlung zu erreichen.
eine mittlere Einstellung ist im All­gemeinen am besten geeignet.
bensmittel
Ist die Umgebungstemperatur hoch oder das Gerät voll beladen, dieses aber auf die niedrigste Temperatur eingestellt, so kann es bei andau­erndem Betrieb des Geräts an der Rückwand zu Frostbildung kom­men. In diesem Fall muss eine hö­here Temperatur gewählt werden, die ein automatisches Abtauen er­möglicht und damit auch einen niedrigeren Energieverbrauch.
www.electrolux.com
40
TÄGLICHER GEBRAUCH
REINIGUNG DES INNENRAUMS
Bevor Sie das Gerät in Betrieb nehmen, beseitigen Sie den typischen „Neugeruch“ am besten durch Reinigen der Innenteile mit lauwarmem Wasser und einer neutralen Seife. Sorgfältig nachtrocknen.
Verwenden Sie keine aggressiven Reinigungsmittel oder Scheuerpul­ver, die die Oberfläche beschädi­gen.
EINFRIEREN FRISCHER LEBENSMITTEL
Das Gefrierfach eignet sich zum Einfrieren von frischen Lebensmitteln und zum La­gern von gefrorenen und tiefgefrorenen Le­bensmitteln für einen längeren Zeitraum. Für das Einfrieren frischer Lebensmittel ist eine Änderung der mittleren Einstellung nicht erforderlich. Möchten Sie den Gefriervorgang beschleu­nigen, drehen Sie bitte den Temperaturreg­ler auf eine höhere Einstellung, um die ma­ximal mögliche Kühlung zu erreichen.
In diesem Fall kann die Temperatur im Kühlschrank unter 0°C fallen. Ist dies der Fall, drehen Sie den Tem­peraturregler auf eine wärmere Ein­stellung.
das Gerät nicht benutzt wurde, mindestens zwei Stunden lang auf den höheren Einstel­lungen laufen, bevor Sie Lebensmittel in das Gefrierfach hinein legen.
Kam es zum Beispiel durch einen Stromausfall, der länger dauerte als der in der Tabelle mit den techni­schen Daten angegebene Wert (siehe "Ausfalldauer") zu einem un­gewollten Abtauen, dann müssen die aufgetauten Lebensmittel sehr rasch verbraucht oder sofort ge­kocht und (nach dem Abkühlen) er­neut eingefroren werden.
AUFTAUEN
Tiefgefrorene oder gefrorene Lebensmittel können vor der Verwendung je nach der zur Verfügung stehenden Zeit im Kühl­schrank oder bei Raumtemperatur aufge­taut werden. Kleinere Gefriergutteile können unter Um­ständen sogar direkt aus dem Gefrier­schrank entnommen und anschließend so­fort gekocht oder gegart werden: in diesem Fall dauert der Garvorgang allerdings etwas länger.
LAGERUNG GEFRORENER PRODUKTE
Lassen Sie das Gerät vor der ersten In­betriebnahme oder nach einer Zeit, in der
VERSTELLBARE ABLAGEN/EINSÄTZE
Die Wände des Kühlschranks sind mit einer Reihe von Führungsschienen ausgestattet, die verschiedene Möglichkeiten für das Ein­setzen der Ablagen bieten.
FEUCHTIGKEITSREGULIERUNG
In die Glasablage ist eine Vorrichtung mit (über einen Schieber verstellbaren) Schlit­zen integriert, die die Temperaturregelung in den Gemüsefächern ermöglicht. Bei geschlossenen Lüftungsschlitzen: bleibt der natürliche Feuchtegehalt der Le­bensmittel in den Obst- und Gemüsefä­chern für längere Zeit erhalten. Bei geöffneten Lüftungsschlitzen: führt die höhere Luftzirkulation zu einem niedrigeren Feuchtegehalt der Luft in den Obst- und Gemüsefächer.
POSITIONIEREN DER TÜRABLAGEN
Die Türablagen können in unterschiedlicher Höhe positioniert werden, womit das La­gern verschieden großer Lebensmittelpa­ckungen ermöglicht wird. Gehen Sie dazu wie folgt vor: Ziehen Sie den Einsatz langsam in Pfeilrich­tung, bis er sich herausheben lässt, und setzen Sie ihn dann nach Wunsch wieder ein.
DEUTSCH 41
1
2
www.electrolux.com
42
PRAKTISCHE TIPPS UND HINWEISE
ENERGIESPARTIPPS
• Öffnen Sie die Tür nicht zu häufig, und lassen Sie diese nicht länger offen als unbedingt notwendig.
• Wenn die Umgebungstemperatur hoch ist und der Temperaturregler auf eine niedrige Temperatur eingestellt und das Gerät voll beladen ist, kann es zu andau­erndem Betrieb des Kompressors und damit zu Reif- oder Eisbildung am Ver­dampfer kommen. Stellen Sie in diesem Fall den Temperaturregler auf eine höhe­re Einstellung ein, die ein automatisches Abtauen und damit auch einen niedrig­eren Energieverbrauch ermöglicht.
HINWEISE FÜR DIE KÜHLUNG FRISCHER LEBENSMITTEL
So erzielen Sie beste Ergebnisse:
• Legen Sie bitte keine warmen Lebens­mittel oder dampfende Flüssigkeiten in den Kühlschrank.
• Decken Sie die Lebensmittel ab oder verpacken Sie diese entsprechend, be­sonders wenn diese stark riechen.
• Legen Sie die Lebensmittel so hinein, dass um sie Luft frei zirkulieren kann.
HINWEISE FÜR DIE KÜHLUNG
Tipps: Fleisch (alle Sorten): wickeln Sie Fleisch in lebensmittelechte Tüten und legen Sie die­se auf die Glasablage über der Gemüse­schublade. Bitte lagern Sie Fleisch aus Sicherheits­gründen nur einen oder maximal zwei Tage auf diese Weise. Gekochte Lebensmittel, kalte Gerichte usw.: diese können abgedeckt auf eine Ab­lage gelegt werden. Obst und Gemüse: bitte waschen Sie Obst und Gemüse gründlich und legen Sie es in die speziell dafür vorgesehene(n) Schubla­de(n). Butter und Käse: diese sollten stets in spe­ziellen luftdichten Behältern verpackt sein oder in Aluminiumfolie bzw. in lebensmitte­lechte Tüten eingepackt werden, um so wenig Luft wie möglich in der Verpackung zu haben.
Milchflaschen: bitte bewahren Sie Milchfla­schen stets mit Deckel im Flaschenregal in der Tür auf. Bananen, Kartoffeln, Zwiebeln und Knob­lauch sollten nicht im Kühlschrank aufbe­wahrt werden, außer diese sind dafür spe­ziell verpackt.
HINWEISE ZUM EINFRIEREN
Im Folgenden finden Sie einige wertvolle Tipps für einen optimalen Gefriervorgang:
• die maximale Menge an Lebensmitteln, die innerhalb von 24 Stunden eingefroren werden kann. ist auf dem Typschild an­gegeben;
• der Gefriervorgang dauert 24 Stunden. Legen Sie während dieses Zeitraums keine weiteren einzufrierenden Lebens­mittel in das Gefrierfach;
• frieren Sie ausschließlich frische und gründlich gewaschene Lebensmittel von sehr guter Qualität ein;
• teilen Sie die Lebensmittel in kleinere Portionen ein, damit diese schnell und vollständig gefrieren und Sie später nur die Menge auftauen müssen, die Sie ge­rade benötigen;
• die einzufrierenden Lebensmittelportio­nen sollten stets luftdicht in Aluminiumfo­lie oder in lebensmittelechte Gefrierbeutel verpackt werden, um so wenig Luft wie möglich in der Verpackung zu haben;
• achten Sie beim Hineinlegen von fri­schen, noch ungefrorenen Lebensmitteln darauf, dass diese keinen Kontakt mit Gefriergut bekommen, da dieses sonst antauen kann;
• weniger fetthaltige Lebensmittel lassen sich besser lagern als fetthaltigere; Salz verkürzt die Lagerzeit von Lebensmitteln im Gefrierfach;
• werden Gefrierwürfel direkt nach der Entnahme aus dem Gefrierfach verwen­det, können Sie zu Frostbrand auf der Haut führen;
• es empfiehlt sich, das Einfrierdatum auf jeder einzelnen Packung zu notieren, um einen genauen Überblick über die Lager­zeit zu haben.
HINWEISE ZUR LAGERUNG GEFRORENER PRODUKTE
So erzielen Sie die besten Ergebnisse mit Ihrem Gerät:
• Vergewissern Sie sich, dass die gefrore­nen Lebensmittel vom Händler ange­messen gelagert wurden.
• Achten Sie unbedingt darauf, die einge­kauften gefrorenen Lebensmittel in der kürzest möglichen Zeit in das Gefrierge­rät zu bringen.
• Öffnen Sie die Tür nicht zu häufig, und lassen Sie die Tür nicht länger offen als notwendig.
• Aufgetaute Lebensmittel verderben sehr schnell und eignen sich nicht für ein er­neutes Einfrieren.
• Das Haltbarkeitsdatum auf der Tiefkühl­kostverpackung darf nicht überschritten werden.
DEUTSCH 43
www.electrolux.com
44
REINIGUNG UND PFLEGE
VORSICHT!
Ziehen Sie bitte vor jeder Reini­gungsarbeit immer den Netzste­cker aus der Steckdose.
Der Kältekreis des Gerätes enthält Kohlenwasserstoffe; Wartungsar­beiten und Nachfüllen von Kältemit­tel dürfen daher nur durch vom Hersteller autorisiertes Fachperso­nal ausgeführt werden.
REGELMÄSSIGE REINIGUNG
Der gesamte Kühlschrank muss regelmäßig gereinigt werden:
• Reinigen Sie die Innenseiten und die Zu­behörteile mit lauwarmem Wasser und etwas Neutralseife.
• Prüfen und säubern Sie die Türdichtun­gen in regelmäßigen Abständen und kontrollieren Sie, dass diese sauber und frei von Verunreinigungen sind.
• Spülen und trocknen Sie diese sorgfältig ab.
Ziehen Sie nicht an Leitungen und/ oder Kabeln im Innern des Kühl­schranks und achten Sie darauf, diese nicht zu verschieben oder zu beschädigen. Benutzen Sie zur Reinigung des In­nenraums keinesfalls Putzmittel, Scheuerpulver, stark parfümierte Reinigungsmittel oder Wachspolitu­ren, da diese die Oberfläche des Innenraums beschädigen und ei­nen starken Eigengeruch hinterlas­sen können.
Reinigen Sie den Kondensator (schwarzes Gitter) und den Kompressor auf der Gerä­terückseite mit einer Bürste. Dadurch ver­bessert sich die Leistung des Geräts und es verbraucht weniger Strom.
Bitte achten Sie darauf, das Kühl­system nicht zu beschädigen.
Viele Haushaltsreiniger für Küchen enthal­ten Chemikalien, die den im Gerät verwen­deten Kunststoff angreifen können. Aus diesem Grund ist es empfehlenswert, das Gerät außen nur mit warmem Wasser und etwas flüssigem Tellerspülmittel zu reinigen. Schließen Sie das Gerät nach der Reini­gung wieder an die Netzversorgung an.
ABTAUEN DES KÜHLSCHRANKS
ABTAUEN DES GEFRIERFACHES
Im Innern des Gefrierfachs wird sich stets etwas Reif bilden.
Tauen Sie das Gefrierfach ab, wenn die Reifschicht eine Stärke von etwa 3 bis 5 mm erreicht hat.
Entfernen Sie den Reif wie nachstehend er­läutert:
1.
Schalten Sie das Gerät aus.
2.
Nehmen Sie das gesamte Gefriergut heraus, verpacken Sie es in mehrere Schichten Zeitungspapier und lagern Sie es an einem kühlen Ort.
3.
Öffnen Sie die Tür.
4.
Wenn das Gefrierfach vollständig ab­getaut ist, wischen Sie das Fachinnere sorgfältig trocken.
5.
Schalten Sie das Gerät ein.
6.
Drehen Sie den Temperaturregler auf eine höhere Einstellung, um die maxi­mal mögliche Kühlung zu erreichen, und lassen Sie das Gerät zwei bis drei Stunden mit dieser Einstellung laufen.
7.
Legen Sie die ausgelagerten Lebens­mittel wieder in das Fach hinein.
DEUTSCH 45
Bei normalem Betrieb wird Reif bei jedem Anhalten des Kompressors automatisch aus dem Verdampfer des Kühlschranks entfernt. Das Tauwasser läuft durch eine Rinne in einen speziellen Behälter an der Rückseite des Geräts über dem Motorkom­pressor, wo es verdampft. Reinigen Sie deshalb regelmäßig die Ab­flussöffnung des Tauwassers in der Mitte des Kühlschrankkanals, damit das Wasser nicht überfließt und auf die gelagerten Le­bensmittel tropft. Benutzen Sie dazu bitte das mitgelieferte Reinigungswerkzeug, das sich bereits in der Ablauföffnung befindet.
WARNUNG!
Verwenden Sie niemals scharfe Gegenstände zum Entfernen von Reif und Eis vom Verdampfer, da dieser dadurch beschädigt werden könnte. Benutzen Sie keine me­chanischen oder sonstigen Hilfs­mittel, um den Abtauprozess zu beschleunigen; halten Sie sich da­zu ausschließlich an die Angaben des Geräteherstellers. Ein Tempe­raturanstieg des Gefrierguts wäh­rend des Abtauens des Gerätes kann die Lagerzeit dieser Lebens­mittel verkürzen.
STILLSTANDZEITEN
Bei längerem Stillstand des Gerätes müs­sen Sie folgendermaßen vorgehen:
trennen Sie das Gerät von der Netz-
versorgung
• entnehmen Sie alle Lebensmittel
• Tauen Sie das Gerät ab (sofern vorgese­hen). Reinigen Sie den Innenraum und das gesamte Zubehör.
• lassen Sie die Türen offen/angelehnt, um das Entstehen unangenehmer Gerüche zu vermeiden.
Möchten Sie bei einer längeren Abwesen­heit den Gefrierschrank weiter laufen las­sen, bitten Sie jemanden, gelegentlich die Temperatur zu prüfen, damit das Gefriergut bei einem möglichen Stromausfall nicht im Innern des Gerätes verdirbt.
www.electrolux.com
46
WAS TUN, WENN …
WARNUNG!
Ziehen Sie vor der Fehlersuche im­mer den Netzstecker aus der Steckdose. Die Fehlersuche, die in der vorlie­genden Gebrauchsanweisung nicht beschrieben ist, darf nur von einem qualifizierten Elektriker oder einer kompetenten Person durchgeführt werden.
Während das Gerät in Betrieb ist, entstehen bestimmte Geräusche (Kompressor und Kühlkreislauf).
Störung Mögliche Ursache Abhilfe Das Gerät funktio-
Das Gerät ist abgeschaltet. Gerät einschalten.
niert nicht. Die Lam­pe funktioniert nicht.
Der Netzstecker steckt
nicht richtig in der Steckdo-
Stecken Sie den Netzste­cker richtig in die Steckdose.
se.
Das Gerät bekommt keinen
Strom. Es liegt keine Span­nung an der Netzsteckdose an.
Testen Sie bitte, ob ein an­deres Gerät an dieser Steck­dose funktioniert. Kontaktieren Sie gegebe­nenfalls einen qualifizierten Elektriker.
Die Lampe funktio­niert nicht.
Die Lampe befindet sich im Standby-Modus.
Schließen und öffnen Sie die Tür.
Die Lampe ist defekt. Siehe hierzu „Austauschen
der Lampe“.
Der Kompressor ar­beitet ständig.
Die Tür ist nicht richtig ge-
Die Tür wurde zu häufig ge-
Die Temperatur der einzu-
Die Temperatur ist nicht richtig eingestellt.
schlossen.
öffnet.
frierenden Lebensmittel ist zu hoch.
Stellen Sie eine höhere Tem­peratur ein.
Siehe hierzu „Schließen der Tür“.
Lassen Sie die Tür nicht län­ger als erforderlich offen.
Lassen Sie Lebensmittel auf Raumtemperatur abkühlen, bevor Sie sie in das Gerät le­gen.
Die Raumtemperatur ist zu
hoch.
Wasser fließt an der Rückwand des Kühl­schranks hinunter.
Beim automatischen Ab­tauen fließt das abgetaute Wasser an der Rückwand
Senken Sie die Raumtempe­ratur.
Das ist normal.
des Kühlschranks hinunter.
Wasser fließt in den Kühlschrank.
Der Wasserablauf ist ver­stopft.
Reinigen Sie den Ablauf.
Störung Mögliche Ursache Abhilfe
Die eingelagerten Lebens-
mittel verhindern, dass das Wasser zum Wasserablauf
Stellen Sie sicher, dass die Lebensmittel nicht die Rück­wand berühren.
fließt.
Wasser fließt auf den Boden.
Der Tauwasserablauf läuft nicht in die Verdampfer­schale über dem Kompres-
Befestigen Sie den Tauwas­serablauf an der Verdamp­ferschale.
sor.
Die Temperatur im Gerät ist zu niedrig.
Die Temperatur im Gerät ist zu hoch.
Die Tür ist nicht richtig ge-
Die Temperatur der einzu-
Die Temperatur ist nicht richtig eingestellt.
Die Temperatur ist nicht richtig eingestellt.
schlossen.
frierenden Lebensmittel ist zu hoch.
Stellen Sie eine höhere Tem­peratur ein.
Stellen Sie eine niedrigere Temperatur ein.
Siehe hierzu „Schließen der Tür“.
Lassen Sie Lebensmittel auf Raumtemperatur abkühlen, bevor Sie sie in das Gerät le­gen.
Es wurden zu viele Lebens-
mittel auf einmal eingelegt.
Die Kaltluft kann nicht im
Gerät zirkulieren.
Legen Sie weniger Lebens­mittel auf einmal ein.
Stellen Sie sicher, dass die Kaltluft im Gerät zirkulieren kann.
DEUTSCH 47
ERSETZEN DER LAMPE
SCHLIESSEN DER TÜR
1.
Reinigen Sie die Türdichtungen.
1.
Ziehen Sie den Netzstecker aus der Netzsteckdose.
2.
Lösen Sie die Schraube an der Lam­penabdeckung.
3.
Nehmen Sie die Lampenabdeckung ab (siehe hierzu die Abbildung).
4.
Ersetzen Sie die defekte Lampe durch eine Lampe mit der gleichen Leistung, die speziell für Haushaltsgeräte vorge­sehen ist. (Die maximale Leistung ist auf der Lampenabdeckung angege­ben.)
5.
Bringen Sie die Lampenabdeckung an.
6.
Ziehen Sie die Schraube an der Lam­penabdeckung fest.
7.
Stecken Sie den Netzstecker in die Netzsteckdose.
8.
Öffnen Sie die Tür. Prüfen Sie, ob die Lampe brennt.
2.
Stellen Sie die Tür nach Bedarf ein. Siehe hierzu „Montage“.
www.electrolux.com
48
3.
Ersetzen Sie die defekten Türdichtun­gen, falls erforderlich. Wenden Sie sich hierzu an den Kundendienst.
MONTAGE
AUFSTELLUNG
Installieren Sie dieses Gerät an einem Ort, an dem die Umgebungstemperatur mit der Klimaklasse übereinstimmt, die auf dem Typschild des Geräts angegeben ist:
Klima­klasse
SN +10°C bis + 32°C N +16°C bis + 32°C ST +16°C bis + 38°C T +16°C bis + 43°C
ELEKTRISCHER ANSCHLUSS
Kontrollieren Sie vor der ersten Benutzung des Gerätes, ob die Netzspannung und ­frequenz Ihres Hausanschlusses mit den auf dem Typenschild angegebenen An­schlusswerten übereinstimmen. Das Gerät muss geerdet sein. Zu diesem Zweck ist die Netzkabelsteckdose mit ei­nem Schutzkontakt ausgestattet. Falls die Steckdose Ihres Hausanschlusses nicht geerdet sein sollte, lassen Sie das Gerät bitte gemäß den geltenden Vorschriften er­den und fragen Sie dafür einen qualifizier­ten Elektriker. Der Hersteller übernimmt keinerlei Haftung für Schäden oder Verletzungen, die durch Missachtung der oben genannten Sicher­heitshinweise entstehen. Das Gerät entspricht den EU- Richtlinien.
DEUTSCH 49
WARNUNG!
Lesen Sie bitte die „Sicherheitshin­weise“ vor der Montage des Geräts sorgfältig durch, um Gefahren für sich selbst zu vermeiden und einen korrekten Betrieb des Geräts zu gewährleisten.
Umgebungstemperatur
Beachten Sie bei der Installation die Montageanleitung.
www.electrolux.com
50
GERÄUSCHE
Während das Gerät in Betrieb ist, entste­hen bestimmte Geräusche (Kompressor und Kühlkreislauf).
SSSRRR!
HISSS!
CLICK!
BRRR!
OK
CLICK!
BRRR!
CRACK!
BLUBB!
CLICK!
BRRR!
BLUBB!
BLUBB!
HISSS!
DEUTSCH 51
HISSS!
SSSRRR!
TECHNISCHE DATEN
Abmessung der Ausspa­rung
Höhe 1225 mm Breite 560 mm Tiefe 550 mm Ausfalldauer 12 h Spannung 230-240 V Frequenz 50 Hz
Die technischen Informationen befinden sich auf dem Typenschild innen links im Gerät sowie auf der Energieplakette.
SSSRRR!
CRACK!
CRACK!
www.electrolux.com
52
UMWELTTIPPS
Recyceln Sie Materialien mit dem Symbol
. Entsorgen Sie die Verpackung in den
entsprechenden Recyclingbehältern. Recyceln Sie zum Umwelt- und Gesundheitsschutz elektrische und
elektronische Geräte. Entsorgen Sie Geräte mit diesem Symbol
Hausmüll. Bringen Sie das Gerät zu Ihrer örtlichen Sammelstelle oder wenden Sie sich an Ihr Gemeindeamt.
nicht mit dem
ҚАЗАҚ 53
МАЗМҰНЫ
ҚАУІПСІЗДІК ТУРАЛЫ МАҒЛҰМАТТАР . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
ЖҰМЫС ЖҮЙЕСІ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
ӘРКҮНДІК ҚОЛДАНУ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
ПАЙДАЛЫ НҰСҚАУЛАР МЕНЕН КЕҢЕСТЕР . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
КҮТУ МЕНЕН ТАЗАЛАУ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
НЕ ІСТЕРСІҢІЗ, ЕГЕР... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
ОРНАТУ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
ШУЫЛ ТҮРЛЕРІ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
ТЕХНИКАЛЫҚ СИППАТАМА . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
ҚОРШАҒАН ОРТАҒА ЗИЯН КЕЛДІРМЕУ ТУРАЛЫ МАҒЛҰМАТТАР . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
СІЗ ОЙЫМЫЗДА БОЛДЫҢЫЗ
Electrolux құрылғысын сатып алғаныңызға рахмет. Сіз ондаған жылдар бойғы кәсіби тәжірибе мен инновацияға сүйеніп жасалған құрылғыны таңдадыңыз. Тапқырлықтың туындысы болған, көз тартарлық бұл құрылғыны жасау барысында сіз ойымызда болдыңыз. Сондықтан, қолданған сайын тамаша нәтижеге қол жеткізе алатыныңызға сенімді болыңыз.
Electrolux әлеміне қош келдіңіз.
Біздің веб-сайтқа барып келесіні қараңыз:
Қолдануға қатысты кеңестер, кітапшалар, ақаулықты түзету, қызмет көрсету туралы ақпарат: www.electrolux.com
Сізге барынша жақсы қызмет көрсету үшін өніміңізді мына жерге тіркеңіз: www.electrolux.com/productregistration
Құрылғыңызға қажетті керек-жарақтарды, шығынды материалдарды және фирмалық қосалқы бөлшектерді сатып алу үшін: www.electrolux.com/shop
ТҰТЫНУШЫҒА КӨМЕК, ҚЫЗМЕТ КӨРСЕТУ
Фирмалық заттарды қолдануды ұсынамыз. Қызмет көрсету орталығына хабарласқанда келесі деректердің дайын болуын қамтамасыз етіңіз. Деректерді техникалық ақпарат тақтайшасынан табуға болады. Үлгісі, Өнім нөмірі, Сериялық нөмірі
Ескерту / Абайлаңыз - Қауіпсіздік туралы маңызды мағлұмат. Жалпы мағлұматтар менен кеңестер Қорғаған ортаға зиян келдірмей пайдалану туралы нұсқаулар
Өндіруші ескертусіз өзгеріс енгізу құқығына ие.
www.electrolux.com
54
ҚАУІПСІЗДІК ТУРАЛЫ МАҒЛҰМАТТАР
Құрылғыны орнатып, ең алғаш пайдаланбас бұрын, өз қауіпсіздігіңіз бен құрылғыны дұрыс қолдану мақсатында, пайдаланушыға арналған бұл нұсқаулықты, оның ішінде кеңестері мен ескертулеріне назар салып оқып шығыңыз. Осы құрылғыны пайдаланатын адамдардың барлығы, қажетсіз ақаулықтар мен тұрмыстық апаттардың алдын алу үшін,оны пайдалану тәсілдерімен және қауіпсіздікті қамтамасыз ететін функцияларымен жете таныс болуы керек. Осы қолдану туралы нұсқаулықты сақтап қойыңыз және тоңазытқышты басқа адамдарға бергеніңізде немесе сатқаныңызда, оны пайдаланатын әрбір адамның бұйымның қолданыс мерзімі аяқталғанға дейін оған қатысты пайдалану және қауіпсіздік шараларынан хабардар болуы үшін нұсқаулықты да қоса беруді ұмытпаңыз. Адам өмірі мен құрылғының қауіпсіздігін қамтамасыз ету үшін осы пайдаланушы нұсқаулығындағы ескертулерді орындаңыз, себебі қадағалаудың жеткіліксіздігінен туған ақаулық үшін өндіруші жауапкершілік көтермейді.
БАЛАЛАР МЕН ӘЛСІЗ АДАМДАРДЫҢ ҚАУІПСІЗДІГІ
• Бұл құрылғыны физиологиялық, сезімдік не болмаса ақыл-ой деңгейіне байланысты не пеш жұмысына қатысты тәжрибиесі мен білімінің аздығына байланысты пайдалана алмайтын адамдар (балаларды қоса алғанда), пешті пайдалану туралы ерекше нұсқауларды алмайынша не олардың қауіпсіздігіне ие адамның қадағалауынсыз пайдаланбауға тиіс.
Балалар құрылғымен ойнамас үшін оларды қадағалап отыру қажет.
• Машинаның орауыштары мен қорабын балалардың қолы жетпейтін жерде сақтаңыз. Тұншығып кету қаупі бар.
• Егер құрылғыны тастасаңыз, оның ашасын розеткадан суырыңыз да, қорек сымын қиып(құрылғыға барынша тақата)балалар ішіне кіріп қамалып не электр тогының қатерлі әсеріне ұшырамас үшін есігін ағытып алып тастаңыз.
• Егер есігі магнитті тығыздағышпен жабдықталған бұл құрылғыны, есігінде не қақпағында серіппелі құлыбы бар ескі
құрылғының орнына қоймақ болсаңыз, ескі құрылғыны ең алдымен оның серіппелі құлыбын жарамсыз етіп барып тастаңыз. Бұл құрылғыны бала ішіне қамалып қалатын қауіп көзіне айналудан сақтайды.
ЖАЛПЫ ҚАУІПСІЗДІК ТУРАЛЫ МАҒЛҰМАТТАР
Назарыңызда болсын!
Құрылғының корпусындағы немесе кіріктірілген элементіндегі желдеткіш саңылауларды бітемей, ашық ұстаңыз.
• Осы нұсқаулықта айтылғандай, бұл құрылғы әдеттегі үй жағдайларында тамақты және/немесе сусындарды сақтау үшін арналған.
• Жібіту үдерісін жылдамдату мақсатында ешқандай механикалық немесе кез келген басқа жасанды құралды пайдаланушы болмаңыз.
• Өндіруші рұқсат бермеген болса, тоңазытқыш құрылғылардың ішіне басқа электр құрылғыларды (балмұздақ жасайтын құрылғы сияқты) салып қолданушы болмаңыз.
• Салқындатқыш зат ағатын жүйеге зақым келтірмеңіз.
• Құрылғының салқындатқыш зат ағатын жүйесінде изобутан (R600a) және қоршаған ортамен сыйысымдылығы жоғары, бірақ сонда да жанғыш зат болып табылатын, табиғи газ болады.
Құрылғының тасымалдау және орнату кезінде салқындатқыш зат жүйесіне зақым келтірілмейтініне көз жеткізіңіз.
Салқындатқыш зат жүйесі зақымдалса: – жалын от пен тұтату көздері болмауы
тиіс
– құрылғы орналасқан бөлмені жақсылап
желдетіңіз
• Осы өнімді немесе оның сипаттарын өзгерту қауіпті. Кабельге зақым келсе қысқа тұйықталу, өрт шығу және/немесе тоқ соғу қаупі төнеді.
Назарыңызда болсын! Кез келген электрлік бөлшектерін (қуат сымы, аша, компрессор), қатерлі жағдай орын алмас үшін, куәлігі бар қызмет көрсетуші маманы немесе білікті техник маман ауыстыруға тиіс.
1.
Қуат кабелін ұзартуға болмайды.
2.
Қуат кабелі құрылғының артқы жағында мыжылып немесе зақымдалып қалмағанына көз жеткізіңіз. Мыжылған немесе зақымдалған қуат кабелі тым қызып кетіп, өрт шығуына әкелуі мүмкін.
3.
Құрылғының айыры қол жетерлік жерде орналасқанына көз жеткізіңіз.
4.
Айырды қуат кабелін ұстап тартпаңыз.
5.
Розетка босап кеткен болса, айырды оған қоспаңыз. Тоқ соғу немесе өрт шығу қаупі бар.
6.
Құрылғыны ішкі жарықтама шамының қақпағы (егер бар болса) жабылмаса іске қосуға болмайды.
• Бұл құрылғы ауыр. Оны жылжытқан кезде абай болу керек.
• Қолыңыз сулы болса, мұздатқыш бөліктен заттарды алмаңыз және оларға тимеңіз, себебі қолыңыздың терісі сыдырылып кетуі немесе қарылып қалуы мүмкін.
• Құрылғыны ұзақ уақытқа тікелей күн сәулелерінің астына қоймаңыз.
• Осы құрылғыда тек тұрмыстық құрылғыларда пайдалануға арналған арнайы шамдар (егер бар болса) ғана қолданылған. Олар үйді жарықтандыру үшін қолдануға жарамайды.
КҮНДЕЛІКТІ ПАЙДАЛАНУ
• Ыстық ыдысты құрылғы ішіндегі пластик жерлерге қоймаңыз.
• Құрылғы ішіне тұтанғыш газ бен сұйықты қоймаңыз, себебі олар жарылып кетуі мүмкін.
• Тағамдарды артқы қабырғадағы ауа шығатын саңылауға қарама-қарсы қоюға болмайды. (Егер құрылғыға мұз қатпайтын болса)
• Мұздатылған тағамды жібітіп алған соң оны қайта мұздатуға болмайды.
• Алдын ала оралған тағамды мұздатылған тағам өндірушінің нұқсауларына сай сақтаңыз.
ҚАЗАҚ 55
• Құрылғы өндірушінің тағам сақтауға қатысты ұсыныстарын қатаң орындау керек. Тиісті нұсқауларға қараңыз.
• Көмірқышқылдандырылған не көпіршитін сусындарды тоңазытқыш камераға қоймаңыз, себебі ыдысқа түскен қысым оның жарып, нәтижесінде құрылғыға нұқсан келуі мүмкін.
• Мұздақтарды тоңазытқыштан алған бетте пайдаланғанда аяз қарып жіберуі мүмкін.
КҮТІМ ЖӘНЕ ТАЗАЛАУ
• Құрылғыға қызмет көрсетуді бастамас бұрын құрылғыны өшіріп, ашаны электр желісіндегі розеткадан суырып алыңыз.
• Құрылғыны металл заттармен тазаламаңыз.
• Құрылғы қырауын тазалау үшін өткір заттарды пайдаланбаңыз. Пластик қырғышты пайдаланыңыз.
• Еріген суды жинайтын табақшаны мезгіл­мезгіл тексеріп отырыңыз. Қажет болса, табақшаны тазалап отырыңыз. Табақша толып қалған жағдайда су құрылғының астыңғы жағына жиналады.
ОРНАТУ
Электр желісіне қосарда, арнайы бөлімдерде берілген нұсқауларды мұқият орындаңыз.
• Құрылғы орамын ашып, оның еш жерінің бүлінбегенін тексеріп алыңыз. Құрылғының бір жері бүлініп қалса қоспаңыз. Қандай да бір бүлінушілік орын алғанда, құрылғыны сатып алған жерге дереу хабарлаңыз. Бұндай жағдайда қорабын сақтап қойыңыз.
• Құрылғыны қоспас бұрын оның майы компрессорға ағып құйылу үшін кем дегенде екі сағат күтіңіз.
• Құрылғы айналасында ауа жеткілікті түрде айналуға тиіс, ауа айналымы жеткіліксіз болса құрылғы қызып кетеді. Желдету жеткілікті болу үшін орнатуға қатысты нұсқауларды орындаңыз.
• Мүмкін болса, құрылғының жылы тұратын бөлшектерін (компрессор, конденсатор) ұстап қалып не оларға қол тигізіп алып күйіп қалмас үшін тоңазытқыштың арт жағын әрқашан қабырғаға қаратып қойыңыз.
• Құрылғыны радиатор не пештердің қасына жақын орналастыруға болмайды.
www.electrolux.com
56
• Құрылғыны орнатқан соң оның ашасының
• Тек ауыз суы жүйесіне ғана қосыңыз (егер
ҚЫЗМЕТ
• Құрылғыны жөндеу үшін қажет электр
• Бұл өнімге қызмет көрсетуді тек уәкілетті
ҚОРШАҒАН ОРТАНЫ ҚОРҒАУ
қол оңай жететін жерде болуын қамтамасыз етіңіз.
суға қосу қажет болса).
жұмыстарын электр маманы не білікті адам жүзеге асыруға тиіс.
қызмет көрсету орындары жүзеге асыру керек және құрылғының нағыз өз бөлшектері ғана пайдаланылуға тиіс.
Бұл құрылғының салқындатқыш сұйығының құрамында да, изоляция материалдарында да озон қабатына зиян келтіретін газдар жоқ. Бұл құрылғыны тұрмыстық қалдық пен қоқыстар тасталатын жерге тастауға болмайды. Оның изоляция қабаттамасында тұтанғыш газдар бар: құрылғыны жергілікті құзырлы мекемелерден алынатын жарамды ережелерге сай тастау қажет. Салқындатқыш құралға, әсіресе оның қызу алмастырғышқа жақын артқы бөлігіне зиян келтірмеңіз. Құрылғыда
пайдаланылған белгіленген материалдар қайта өңдеуден өткізуге жарайды.
белгішесімен
ЖҰМЫС ЖҮЙЕСІ
ҚОСУ
Ашаны розеткаға сұғыңыз. Температура түймешесін сағат бағытымен бұрай отырып орташа температураға қойыңыз.
ӨШІРУ
Құрылғыны өшіру үшін температура түймешесін "O" қалпына қойыңыз.
ТЕМПЕРАТУРАНЫ БАПТАУ
Температура автоматты түрде қойылады. Құрылғыны іске қосу үшін төмендегі әрекетті орындаңыз:
• суықтықты азайту үшін температура түймешесін суықтың төменгі деңгейіне қарай бұраңыз.
• суықтықты жоғары деңгейге қою үшін температура түймешесін суықтың максимум деңгейіне қарай бұраңыз.
Әдетте орташа суықтықты таңдаған дұрыс.
ҚАЗАҚ 57
Дегенмен, параметрді дәл тауып орнату үшін құрылғының ішіндегі температураның төмендегі жағдайларға:
• бөлме температурасына
• есіктің қаншалықты жиі ашылғандығына
• сақталатын тағамның мөлшеріне
• құрылғы орнатылған жерге байланысты екендігін есте ұстау қажет.
Егер бөлме температурасы жоғары болса не тағам тоңазытқыш ішіне толтыра салынса және құрылғы төменгі температурада тұрса, құрылғы үздіксіз жұмыс жасап оның қабырғасына қырау тұруы мүмкін. Бұндай жағдайда түймешені жоғары температураға қойып,құрылғы мұзын қуатты көп шығындамай, өздігінен еріп кетуіне мүмкіндік беру қажет.
www.electrolux.com
58
ӘРКҮНДІК ҚОЛДАНУ
ІШІН ТАЗАЛАУ
Құрылғыны ең алғаш пайдаланбас бұрын, жаңа бұйымға тән иісті арылту үшін оның іші мен ішкі керек-жарақтарын сәл нейтрал сабын салынған жылы сумен жуып, содан соң мұқият құрғатыңыз.
Жуғыш зат не жеміргіш ұнтақтарды пайдаланбаңыз, бұл құрылғының сыртқы қабатына зиян келтіреді.
ЖАҢА ТАҒАМДЫ МҰЗДАТУ
Мұздатқыш камера жаңа тағамды мұздату мен тоңазыған және мұздатылған тағамдарды ұзақ уақыт сақтауға жарайды. Жаңа тағамды мұздату үшін орташа температураны өзгертудің қажеті жоқ. Дегенмен, тағамды тезірек мұздатқыңыз келсе, температура түймешесін максимум суықтыққа қою үшін жоғары параметрге қойыңыз.
Бұндай жағдайда, тоңазытқыш камерадағы температура 0°C градустан төмен түсіп кетуі мүмкін. Бұндай жағдай орын алса, температура түймешесін жылырақ параметрге әкеліп қойыңыз.
МҰЗДАТЫЛҒАН ТАҒАМДЫ САҚТАЙТЫН КАМЕРА
Құрылғыны ең алғаш қолданғанда не ұзақ уақыт пайдаланбағаннан кейін қосқан кезде,
камераға тамақ салмас бұрын құрылғыны ең кем дегенде 2 сағат ең жоғарғы параметрлерге қойып жұмыс істетіп алыңыз.
Кездейсоқ еріп кету, мысалы электр қуаты өшіп, ток техникалық сипаттамалар кестесіндедегі "көтеру уақыты" бөлімінде берілген мәндерден де ұзақ уақыт бойы қосылмай тұрса, еріп кеткен тағамды жылдам пайдаланып не дереу пісіріп алып барып қайта тоңазыту (салқындатқан соң) қажет.
ЖІБІТУ
Мұздатылған не тоңазытылған тағамды қажетке жаратпас бұрын, осы жұмысқа арналған уақыттың шамасына қарай отырып, оны тоңазытқыш ішінде не бөлме температурасында жылытуға болады. Тағамның кіші кесектерін тоңазытқыштан алған бетте мұздаған қалпы пісіре беруге болады. бұндай жағдайда пісіру уақыты ұзағырақ болады.
ЖЫЛЖЫМАЛЫ СӨРЕЛЕР
Тоңазытқыштың қабырғасында сөрелерді қалауыңызша орналастыруға арналған бірнеше бағыттауыш бар.
ЫЛҒАЛДЫЛЫҚТЫ БАҚЫЛАУ
Шыны сөре көкөніс салынатын сөре(лер)дің температурасын реттеуге мүмкіндік беретін саңылаулары (сырғыма тетіктің көмегімен реттелетін) бар құралмен жабдықталған. Желдету саңылаулары жабық тұрған кезде: жеміс пен көкөніс тартпасына салынған тағамның құрамындағы табиғи ылғалдылық ұзағырақ сақталады. Желдету саңылаулары ашық тұрған кезде: ауа көбірек айналып тұрса, жеміс пен көкөніс салынатын бөліктердегі ауаның ылғалдылығы төменірек болады.
ЕСІКТІҢ СӨРЕЛЕРІН ОРНАЛАСТЫРУ
Әр түрлі мөлшерде оралған тағамдарды орналастыру үшін есіктегі сөрелерді түрлі биіктікке қоюға болады. Бұл үшін төмендегі әрекеттерді жасаңыз: сөрелерді көрсеткі бағыты бойынша еппен тартып шығарыңыз да, қажетті орынға қойыңыз.
ҚАЗАҚ 59
1
2
www.electrolux.com
60
ПАЙДАЛЫ НҰСҚАУЛАР МЕНЕН КЕҢЕСТЕР
ҚУАТТЫ ҮНЕМДЕУГЕ ҚАТЫСТЫ АҚЫЛ-КЕҢЕС
• Есікті жиі-жиі ашпаңыз не қажетті уақыттан артық уақыт ашып тұрмаңыз.
• Орта температурасы жоғары болса, температура регуляторы ең жоғарғы параметрге қойылса және тоңазытқыш ішіне тамақ толтырылса салынса, компрессор буландырғыш құралдың үстіне мұз қатырып, үздіксіз жұмыс жасауы мүмкін. Бұндай жағдай орын алса, температура регуляторын құрылғы электр қуатын үнемдей отырып өздігінен жібу үшін төменгі көрсеткішке қойыңыз.
ЖАҢА ТАҒАМДЫ ТОҢАЗЫТУҒА ҚАТЫСТЫ АҚЫЛ-КЕҢЕС
Ең жақсы нәтижеге жету үшін:
• жылы не буы бұрқырап тұрған сұйық заттарды тоңазытқышқа қоймаңыз
• тағамның бетін жабыңыз не оны орап салыңыз, әсіресе ол өткір иісті болса
• тағамды ауа оның айналасында еркін айнала алатындай етіп орналастырыңыз
ТОҢАЗЫТУҒА ҚАТЫСТЫ АҚЫЛ­КЕҢЕС
Пайдалы кеңестер: Ет (барлық түрлері) : полиэтилен қалтаға орап көкөніс суырмасының үстіңгі жағындағы шыны сөреге қойыңыз. Сақтық мақсатында тағамды осылайша тек бір, көп дегенде екі күн ғана сақтау керек. Пісірілген тағамдар, суық тағамдар т.б.: бұлардың бетін жауып кез келген сөреге қоюға болады. Жемістер мен көкөністер: бұларды мұқият тазалап арнайы сөреге (лер) салу қажет. Сарымай мен ірімшік: бұларды арнайы ауа өткізбейтін сауыттарға салып не алюминий қағазға не полиэтилен қалтаға орап, мүмкіндігінше ауа өткізбеуге тырысу қажет. Сүт бөтелкелері: бұлардың тығындарын жауып, есіктегі бөтелке қойылатын қатарға қою қажет. Оралмаған банан, картоп, пияз бен сарымсақты тоңазытқышта ұстауға болмайды.
ТОҢАЗЫТУ ТУРАЛЫ КЕҢЕС
Төменде тоңазыту үрдісін барынша тиімді жүзеге асыру үшін бірнеше маңызды кеңестер берілген:
• 24 сағат ішінде тоңазытуға болатын ең көп тағам мөлшері техникалық ақпарат тақтайшасында берілген;
• мұздату үрдісі 24 сағатқа созылады. Осы уақыт аралығында тоңазытылуға тиіс ешбір қосымша тағамды қосып салуға болмайды;
• тек аса жоғары сапалы, жаңа және мұқият тазаланған тағамдарды ғана тоңазытыңыз;
• тағамды жылдам әрі толықтай мұздатып, қажетті кезде оның тек қажетті мөлшерін ғана жібіту үшін кішкене бөлшектерге бөліп дайындаңыз;
• тағамды алюминий қағазға не полиэтилен қалтаға орап, орамының ауа өткізбейтіндігіне көз жеткізіп алыңыз;
• жаңа, мұздамаған тағамды әлдеқашан мұздаған тағамға, оның температурасы көтеріле бастамас үшін тигізбеңіз;
• майы аз тағамдар майлы тағамдарға қарағанда жақсы әрі ұзақ сақталады; тұз тағамның сақталу уақытын азайтады;
• мұз текшелерін мұздатқыш камерадан алған бетте тура пайдаланса, аяз теріні қарып кетуі мүмкін;
• Тағамдарды сақтау уақытының кестесін жасау үшін, тағамның әрбір жеке орамасына оның тоңазытылған ай-күнін жазып қою ұсынылады;
ТОҢАЗЫТЫЛҒАН ТАҒАМДАРДЫ САҚТАУҒА ҚАТЫСТЫ АҚЫЛ­КЕҢЕС
Құрылғының барынша жақсы жұмыс істеуін қамтамасыз ету үшін мына әрекеттерді орындау керек:
• сатушының мұздаған қалпы сатылатын тағамдарды тиісті түрде мұздатқанына көз жеткізіңіз;
• мұздатылған тағамдарды дүкеннен мұздатқышқа барынша аз уақыт ішінде жеткізіңіз;
• егер аса қажет болмаса есігін жиі ашпаңыз немесе ұзақ уақыт ашып қалдырмаңыз;
• мұздап тұрған тағамды жібіткеннен кейін сапасы дереу түсе бастайды және оны қайта мұздатуға болмайды;
• тағамды өндіруші көрсеткен жарамдылық мерзімінен артық уақыт сақтамаңыз.
ҚАЗАҚ 61
www.electrolux.com
62
КҮТУ МЕНЕН ТАЗАЛАУ
Сақтандыру туралы ескерту! Жөндеу жұмысын жүргізбес бұрын құрылғыны электр желісінен ағытыңыз.
Бұл құрылғының салқындатқыш құралында сутегілі көміртек бар; сондықтан да, жөндеу жұмыстары мен оны қайта толтыруды тек уәкілетті маман ғана жүзеге асыруға тиіс.
МЕЗГІЛІМЕН ТАЗАЛАП ОТЫРУ
Құрылғыны мезгіл-мезгіл тазалап отыру қажет:
• іші мен керек-жарақтарын аздап нейтрал сабын салынған жылы сумен тазалаңыз.
• есік тығыздағышын мезгіл-мезгіл тазалап, кір тұрып қалмас үшін сүртіп алып отырыңыз.
• шайып мұқият құрғатыңыз.
Құрылғы ішіндегі түтікшелер және/не сымдардың ешқайсысын тартпаңыз, жылжытып не бүлдірмеңіз. Құрылғының ішін тазалау үшін жуғыш заттарды, жеміргіш ұнтақтар мен аса хош иістендірілген тазалағыш заттарды не балауыз жылтыратқыштарды пайдаланбаңыз, себебі бұндай заттар құрылғының беткі қабатын бүлдіріп, онда ерекше иіс қалдырады.
Құрылғының артындағы конденсатор (қара гриль) мен компрессорды шөтке не шаңсорғышпен тазалаңыз. Бұлай істеу құрылғы жұмысын жақсартып, электр шығынын азайтады.
Салқындатқыш жүйеге еш нұқсан келтірмеуге тырысыңыз.
Ас үй құрылғыларының бетін тазалауға арналған көпшілік заттардың құрамында осы құрылғы үшін пайдаланылған пластиктерге зиянды әсер ететін химикаттар бар. Сондықтан да осы құрылғы корпусының сыртын, тек аздаған жуғыш зат салынған жылы сумен тазалау ұсынылады. Тазалап болған соң құрылғыны электр желісіне қайта қосыңыз.
ТОҢАЗЫТҚЫШ МҰЗЫН-ҚЫРАУЫН ЕРІТУ
Құрылғы қалыпты жұмыс істеп тұрса, қырау тоңазытқыш камерадағы буландырғыштан, мотор компрессоры тоқтаған сайын автоматты түрде шығарылады. Еріген су науа арқылы құрылғының артқы жағында, мотор компрессорының үстінде орналасқан арнайы сауытқа жиналады да, сол жерде буға айналады. Жиналған су ағып, тоңазытқыштағы тағамға тамшыламас үшін тоңазытқыш бөліктегі науаның ортасындағы еріген су ағатын саңылауды мезгіл-мезгіл тазалаңыз. Құрылғымен бірге жеткізілетін арнайы тазалағыш құралды пайдаланыңыз, оны су ағатын тесіктен аласыз.
МҰЗДАТҚЫШ КАМЕРАНЫҢ МҰЗЫН ЕРІТУ
Үстіңгі камераның айналасына белгілі бір мөлшерде әрқашан қырау жиналады.
Мұздатқыш камераның қырауының қалыңдығы шамамен 3-5 мм болған кезде, оны жібітіңіз.
Қырауды кетіру үшін мына әрекеттерді жасаңыз:
1.
Құрылғыны өшіріңіз.
2.
Ішінде тағам тұрса, оны алып, бірнеше қабат газетке ораңыз да, салқын жерге қойыңыз.
3.
Есікті ашыңыз.
4.
Мұзды ерітіп болғаннан кейін құрылғының ішін жақсылап құрғатыңыз.
5.
Құрылғыны іске қосыңыз.
6.
Температура түймешесін ең үлкен суықтыққа қойыңыз да, құрылғыны осы параметрде тұрған қалпы екі немесе үш сағат жұмысқа қосыңыз.
7.
Алдында алып қойған тағамдарды қайта салыңыз.
Назарыңызда болсын! Буландырғыштағы қырауды ешқашан өткір металл қырғышпен қырмаңыз, оны бүлдіріп алуыңыз мүмкін. Мұзды жылдам еріту үшін өндіруші ұсынған құралдардан өзге механикалық немесе басқа жасанды заттарды ешқашан қолданбаңыз. Құрылғының мұзын еріту кезінде, оралып мұздатылған тағамдардың температурасының жоғарылауы олардың қауіпсіз сақталу мерзімін қысқартуы мүмкін.
ҚАЗАҚ 63
Егер құрылғы пайдаланылып тұратын болса, электр қуаты өшіп қалған жағдайда ішіндегі тағам бұзылып кетпес үшін басқа бір адамның арасында бір рет бақылап қойып отыруын сұраңыз.
ҰЗАҚ УАҚЫТ БОЙЫ ПАЙДАЛАНБАУ
Құрылғы ұзақ уақыт бойы пайдаланылмайтын жағдайда мына сақтық шараларын орындаңыз:
• құрылғыны электр желісінен ажыратыңыз
• барлық тағамдарды шығарыңыз
• мұзын ерітіп (егер бар болса), құрылғыны және керек-жарақтарын тазалаңыз
• жағымсыз иіс пайда болмас үшін есік/ есіктерді ашық қалдырыңыз.
www.electrolux.com
64
НЕ ІСТЕРСІҢІЗ, ЕГЕР...
Назарыңызда болсын! Ақаулық себебін іздестірмес бұрын ашаны розеткадан суырып алыңыз. Осы нұсқаулықта көрсетілмеген ақаулық түрін тек білікті маман не білікті адам ғана іздестіруге тиіс.
Құрылғы қалыпты режимде жұмыс жасап тұрғанда біраз шуыл (компрессор, салқындатқыш сұйықтың айналуы) естіліп тұрады.
Ақаулық Мүмкін себептері Шешімі Құрылғы жұмыс жасамай
Құрылғы өшірулі. Құрылғыны қосыңыз. тұр. Құрылғы шамы қосылмай тұр.
Аша электр желісіндегі
розеткаға дұрыс
Ашаны электр желісіндегі розеткаға дұрыс сұғыңыз.
жалғанбаған. Құрылғыда қуат жоқ.
Розеткада кернеу жоқ.
Розеткаға әртүрлі электр құрылғыларын қосып көріңіз. Білікті электр маманын
шақырыңыз. Шам жанбай тұр. Шам күту режимінде тұр. Есікті жауып, қайта ашыңыз. Шамда ақау бар. "Шамды айырбастау" тарауын
қараңыз. Компрессор үздіксіз
жұмыс жасайды.
Температура дұрыс орнатылған жоқ.
Жоғарырақ температураны
орнатыңыз. Есік дұрыс жабылған жоқ. "Есікті жабу" тарауын қараңыз. Есік жиі-жиі ашылған. Есікті қажет болмаса ұзақ
ашпаңыз. Тағам температурасы тым
жоғары.
Тағамның температурасын
бөлме температурасына дейін
төмендетіп барып сақтаңыз. Бөлме температурасы тым
жоғары.
Тоңазытқыштың артқы тақтасына су ағады.
Тоңазытқышты өздігінен еріткен кезде еріген қырау
Бөлме температурасын
азайтыңыз.
Бұл дұрыс.
артқы тақта үстіне қарай ағады.
Су тоңазытқыштың ішіне ағады.
Тағамдар судың коллекторға
Су жерге ағады. Еріген суды ағызатын түтік
Суды ағызатын түтік бітелген.
қарай ағуына бөгет жасайды.
суы компрессордың үстіндегі буландырғыш науаға
Су ағызатын түтікті тазалаңыз.
Тағамдардың артқы тақтаға
тимеуіне көз жеткізіңіз.
Еріген суды ағызатын түтікті
буландырғыш науаға
жалғаңыз.
ақпайды.
Құрылғының ішіндегі температура тым төмен.
Температура түймешесі дұрыс қалыпқа қойылмаған.
Жоғарырақ температураны
орнатыңыз.
ҚАЗАҚ 65
Ақаулық Мүмкін себептері Шешімі Құрылғының ішіндегі
температура тым
Температура түймешесі дұрыс қалыпқа қойылмаған.
Төмен температураны
орнатыңыз. жоғары.
Есік дұрыс жабылған жоқ. "Есікті жабу" тарауын қараңыз. Тағам температурасы тым
жоғары.
Тағамның температурасын
бөлме температурасына дейін
төмендетіп барып сақтаңыз. Көп мөлшердегі тағам бір
мезетте салынып сақталған.
Құрылғы ішінде суық ауа
айналып тұрған жоқ.
Тағамды бір салғанда көп
мөлшерде салып сақтамаңыз.
Құрылғы ішінде суық ауаның
айналуын қамтамасыз етіңіз.
ШАМДЫ АУЫСТЫРУ
1.
Ашаны розеткадан ағытыңыз.
2.
Шамның қақпағындағы бұранданы алыңыз.
3.
Шамның қақпағын алыңыз (суретке қараңыз).
4.
Қолданылған шамның орнына қуат параметрі дәл осындай және тұрмыстық құрылғыларға арналған шамды салыңыз. (қуат параметрінің ең үлкен мәні шамның қақпағында көрсетілген).
5.
Шамның қақпағын орнына қойыңыз.
6.
Шамның қақпағын бұрандамен қатайтыңыз.
7.
Ашаны розеткаға сұғыңыз.
8.
Есікті ашыңыз. Шамның жанатындығын тексеріңіз.
ЕСІКТІ ЖАБЫҢЫЗ
1.
Есік тығыздағыштарын тазалаңыз.
2.
Қажет болса, есікті лайықтаңыз. "Орнату" тарауын қараңыз.
3.
Қажет болса, есіктің нұқсан келген тығыздағыштарын айырбастаңыз. Қызмет көрсету орталығына хабарласыңыз.
www.electrolux.com
66
ОРНАТУ
ОРНАЛАСТЫРУ
Бұл құрылғыны температурасы құрылғының техникалық ақпараттар тақтайшасында көрсетілген климат санатына сай келетін жерге орналастыру қажет:
Климат санаты
SN +10°C бастап + 32°C дейін N +16°C бастап + 32°C дейін ST +16°C бастап + 38°C дейін T +16°C бастап + 43°C дейін
ЭЛЕКТР ЖЕЛІСІНЕ ЖАЛҒАУ
Электр желісіне қоспас бұрын техникалық ақпарат тақтайшасында көрсетілген кернеу мен жиіліктің үйдегі электр желісінің қуатына сай келетіндігін тексеріп алыңыз. Құрылғы жерге қосылуға тиіс. Осы мақсатта қорек сымы контактпен қатар жеткізілген. Егер үйдегі розетка жерге қосылмаған болса, білікті электр маманынан ақыл-кеңес ала отырып, құрылғыны қолданыстағы ережелерге сай жерге жекелей қосыңыз. Жоғарыда айтылып өткен ережелер сақталмаса, өндіруші қандай да бір жауапкершілікті өз мойнына алудан бас тартады. Бұл құрылғы E.E.C. ережелеріне сай келеді.
Назарыңызда болсын! Өз қауіпсіздігіңіз үшін және құрылғы дұрыс жұмыс істеуі үшін құрылғыны орнатар алдында "Қауіпсіздік туралы ақпарат" тарауын мұқият оқыңыз.
Қоршаған орта температурасы
Орнату және құрастыру нұсқауларын орындаңыз.
ШУЫЛ ТҮРЛЕРІ
Құрылғы қалыпты жұмыс істеп тұрған кезде түрлі шуыл естіледі (компрессор, салқындатқыш сұйықтықтың айналуы).
SSSRRR!
HISSS!
ҚАЗАҚ 67
CLICK!
BRRR!
OK
CLICK!
BRRR!
CRACK!
BLUBB!
CLICK!
BRRR!
BLUBB!
BLUBB!
www.electrolux.com
68
HISSS!
HISSS!
SSSRRR!
CRACK!
ТЕХНИКАЛЫҚ СИППАТАМА
Ұяның өлшемдері Биіктігі 1225 мм Ені 560 мм Тереңдігі 550 мм Көтерілу уақыты 12 сағ. Кернеу 230-240 В Жиілік 50 Гц
Техникалық ақпарат құрылғының сол жақ ішкі қабырғасындағы техникалық ақпарат
SSSRRR!
CRACK!
тақтайшасында және электр қуатының жапсырмасында көрсетілген.
ҚАЗАҚ 69
ҚОРШАҒАН ОРТАҒА ЗИЯН КЕЛДІРМЕУ ТУРАЛЫ МАҒЛҰМАТТАР
Белгі өңдеуден өткізуге тапсырыңыз. Орам
материалдарын қайта өңдеуден өткізу үшін тиісті контейнерлерге салыңыз. Электрлік және электроникалық құрылғылардың қалдығын қайта өңдеуден өткізу арқылы, қоршаған ортаға және
салынған материалдарды қайта
адамның денсаулығына зиын келтіретін жағдайларға жол бермеуге өз үлесіңізді
қосыңыз. Белгі тұрмыстық қалдықтармен бірге тастамаңыз.
Өнімді жергілікті қайта өңдеу орталығына өткізіңіз немесе жергілікті мекемеге хабарласыңыз.
салынған құрылғыларды
www.electrolux.com
70
ÍNDICE DE MATERIAS
INFORMACIÓN SOBRE SEGURIDAD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
FUNCIONAMIENTO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
USO DIARIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
CONSEJOS ÚTILES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
MANTENIMIENTO Y LIMPIEZA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
QUÉ HACER SI… . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
INSTALACIÓN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
RUIDOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
DATOS TÉCNICOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
ASPECTOS MEDIOAMBIENTALES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
PENSAMOS EN USTED
Gracias por adquirir un producto Electrolux. Ha escogido un producto que contiene décadas de experiencia e innovación profesionales. Ingenioso y elegante, se ha diseñado pensando en usted. Así que, siempre que lo utilice puede tener la seguridad de que conseguirá excelentes resultados.
Bienvenido a Electrolux.
Visite nuestro sitio web para:
Obtener consejos, folletos, soluciones a problemas e información de servicio:
www.electrolux.com
Registrar su producto para recibir un mejor servicio:
www.electrolux.com/productregistration
Adquirir accesorios, artículos de consumo y recambios originales para su aparato:
www.electrolux.com/shop
ATENCIÓN Y SERVICIO AL CLIENTE
Le recomendamos que utilice recambios originales. Al contactar con el Servicio, cerciórese de tener la siguiente información a mano. La información se puede encontrar en la placa de características. Modelo, PNC, Número de serie.
Advertencia - Precaución-Información sobre seguridad. Datos y recomendaciones generales Información medioambiental
Salvo modificaciones.
INFORMACIÓN SOBRE SEGURIDAD
ESPAÑOL 71
Por su seguridad y para garantizar el fun­cionamiento correcto del aparato, antes de instalarlo y utilizarlo por primera vez lea atentamente este manual del usuario, in­cluidos los consejos y advertencias. Para evitar errores y accidentes, es importante que todas las personas que utilicen el apa­rato estén perfectamente al tanto de su funcionamiento y de las características de seguridad. Conserve estas instrucciones y no olvide mantenerlas junto al aparato en caso de su desplazamiento o venta para que quienes lo utilicen a lo largo de su vida útil dispongan siempre de la información adecuada sobre el uso y la seguridad. Por la seguridad de personas y bienes, si­ga las normas de seguridad indicadas en estas instrucciones, ya que el fabricante no se hace responsable de daños provocados por omisiones.
SEGURIDAD DE NIÑOS Y PERSONAS VULNERABLES
• Este electrodoméstico no está diseñado para que lo usen personas (incluidos ni­ños) con discapacidad física, sensorial o mental, o con experiencia y conocimien­to insuficientes, a menos que una perso­na responsable de su seguridad les su­pervise o instruya en el uso del electro­doméstico.
No permita que los niños jueguen con el electrodoméstico.
• Mantenga los materiales de embalaje alejados de los niños. Existe riesgo de asfixia.
• Si va a desechar el aparato, extraiga el enchufe de la toma, corte el cable de co­nexión (tan cerca del aparato como pue­da) y retire la puerta para impedir que los niños al jugar puedan sufrir descargas eléctricas o quedar atrapados en su inte­rior.
• Si este aparato, que cuenta con juntas de puerta magnéticas, sustituirá a un aparato más antiguo con cierre de mue­lle (pestillo) en la puerta, cerciórese de inutilizar el cierre de muelle antes de de­sechar el aparato antiguo. Evitará así que se convierta en una trampa mortal para niños.
INSTRUCCIONES GENERALES DE SEGURIDAD
ADVERTENCIA
Mantenga libres de obstrucciones las aber­turas de ventilación del alojamiento del aparato o de la estructura empotrada
• El aparato está diseñado para conservar los alimentos y bebidas de una vivienda normal, como se explica en este folleto de instrucciones.
• No utilice dispositivos mecánicos ni me­dios artificiales para acelerar el proceso de descongelación.
• No utilice otros aparatos eléctricos (co­mo máquinas para hacer helados) den­tro de los aparatos de refrigeración, a menos que el fabricante haya autorizado su utilización para estos fines.
• No dañe el circuito del refrigerante.
• El circuito del refrigerante del aparato contiene isobutano (R600a). Se trata de un gas natural con un alto nivel de com­patibilidad medioambiental, aunque es inflamable.
Durante el transporte y la instalación del aparato, cerciórese de no provocar da­ños en el circuito de refrigeración.
Si el circuito de refrigeración se daña: – mantenga el aparato alejado de las lla-
mas y de cualquier fuente de encendi­do
– ventile bien la habitación en la que se
encuentra el aparato
• Es peligroso alterar las especificaciones o modificar este producto en modo algu­no. Cualquier daño en el cable de ali­mentación puede provocar un cortocir­cuito, un incendio o una descarga eléc­trica.
ADVERTENCIA
Los componentes eléctricos (cable de alimentación, enchufe, compre­sor) debe sustituirlos un técnico autorizado o personal de repara­ciones profesional a fin de evitar riesgos.
www.electrolux.com
72
• Este aparato es pesado. Debe tener pre-
• No retire ni toque elementos del compar-
• Evite la exposición prolongada del apa-
• Las bombillas que se utilizan en este
USO DIARIO
• No coloque recipientes calientes sobre
• No almacene gas ni líquido inflamable en
• No coloque alimentos directamente con-
• Los alimentos que se descongelen no
• Guarde los alimentos congelados, que
• Se deben seguir estrictamente las reco-
• No coloque bebidas carbonatadas o con
1.
El cable de alimentación no se debe prolongar.
2.
Compruebe que la parte posterior del aparato no aplaste ni dañe el en­chufe. Un enchufe aplastado o da­ñado puede recalentarse y provocar un incendio.
3.
Cerciórese de que tiene acceso al enchufe del aparato.
4.
No tire del cable de alimentación.
5.
Si la toma de red está floja, no intro­duzca el enchufe. Existe riesgo de descarga eléctrica o incendio.
6.
No utilice el aparato sin la tapa de la bombilla (si está provisto de ella) de iluminación interior.
cauciones durante su desplazamiento.
timento congelador con las manos hú­medas o mojadas, ya que podría sufrir abrasión de la piel o quemaduras por congelación.
rato a la luz solar directa.
aparato (si está provisto de ellas) son es­peciales, y se han seleccionado exclusi­vamente para uso en aparatos domésti­cos. No pueden utilizarse para la ilumina­ción de la vivienda.
las piezas plásticas del aparato.
el aparato, ya que podrían estallar.
tra la salida de aire de la pared posterior. (Si el aparato es No Frost, es decir, no acumula escarcha.)
deben volver a congelarse.
se adquieren ya envasados, siguiendo las instrucciones del fabricante.
mendaciones del fabricante del aparato sobre el almacenamiento. Consulte las instrucciones correspondientes.
gas en el congelador, ya que se genera
presión en el recipiente, que podría esta­llar y dañar el aparato.
• Si se consumen polos helados retirados directamente del aparato, se pueden su­frir quemaduras causadas por el hielo.
CUIDADO Y LIMPIEZA
• Antes de realizar tareas de mantenimien­to, apague el aparato y desconecte el enchufe de la toma de red.
• No limpie el aparato con objetos metáli­cos.
• No utilice objetos afilados para eliminar el hielo del aparato. Utilice un raspador plástico.
• Inspeccione habitualmente el desagüe del agua descongelada del frigorífico. Si es necesario, limpie el desagüe. Si el de­sagüe se bloquea, el agua se acumulará en la base del aparato.
INSTALACIÓN
Para realizar la conexión eléctrica, siga atentamente las instrucciones de los párrafos correspondientes.
• Desembale el aparato y compruebe que no tiene daños. No conecte el aparato si está dañado. Informe de los posibles da­ños de inmediato a la tienda donde lo adquirió. En ese caso, conserve el mate­rial de embalaje.
• Es recomendable esperar al menos dos horas antes de conectar el aparato, para permitir que el aceite regrese al compre­sor.
• El aparato debe contar con circulación de aire adecuada alrededor, ya que de lo contrario se produce recalentamiento. Para conseguir una ventilación suficien­te, siga las instrucciones correspondien­tes a la instalación.
• Siempre que sea posible, la parte poste­rior del producto debe estar contra una pared, para evitar que se toquen las par­tes calientes (compresor, condensador) y se produzcan quemaduras.
• El aparato no debe colocarse cerca de radiadores ni de hornillas de cocina.
• Asegúrese de que es posible acceder al enchufe después de instalar el electro­doméstico.
• Realice la conexión sólo a un suministro de agua potable (si está prevista una co­nexión de agua).
SERVICIO TÉCNICO
• Un electricista homologado deberá reali­zar las tareas que se requieran para eje­cutar el servicio o mantenimiento de este electrodoméstico.
• Las reparaciones de este aparato debe realizarlas un centro de servicio técnico autorizado y sólo se deben utilizar re­cambios originales.
PROTECCIÓN DEL MEDIO AMBIENTE
Este aparato no contiene gases perjudiciales para la capa de ozo­no, ni en el circuito de refrigerante ni en los materiales aislantes. El aparato no se debe desechar junto con los residuos urbanos. La espu­ma aislante contiene gases infla­mables: el aparato se debe dese­char de acuerdo con la normativa vigente, que puede solicitar a las autoridades locales. No dañe la unidad de refrigeración, en especial la parte trasera, cerca del inter­cambiador de calor. Los materiales de este aparato marcados con el
símbolo
son reciclables.
ESPAÑOL 73
www.electrolux.com
74
FUNCIONAMIENTO
ENCENDIDO
Introduzca el enchufe en la toma. Gire el regulador de temperatura hacia la derecha, a un ajuste intermedio.
APAGADO
Para apagar el aparato, gire el regulador de temperatura hasta la posición "O".
REGULACIÓN DE LA TEMPERATURA
La temperatura se regula automáticamen­te. Para utilizar el aparato, proceda de la ma­nera siguiente:
• Gire el regulador de temperatura hacia ajustes más bajos para obtener el frío mínimo.
• Gire el regulador de temperatura hacia ajustes más altos para obtener el frío máximo.
Lo más conveniente es ajustar la temperatura en una posición inter­media.
Sin embargo, el ajuste exacto debe elegir­se teniendo en cuenta que la temperatura interior del aparato depende de:
• la temperatura ambiente
• la frecuencia con que se abre la puerta
• la cantidad de alimentos guardados
• la ubicación del aparato.
Si la temperatura ambiente es ele­vada o el aparato está totalmente lleno y se ha ajustado a las tempe­raturas más bajas, puede mante­nerse en marcha de manera conti­nua provocando la formación de escarcha en la pared posterior. En tal caso, el mando debe colocarse a temperatura más elevada para permitir la descongelación automá­tica y reducir así el consumo ener­gético.
USO DIARIO
ESPAÑOL 75
LIMPIEZA DE LAS PARTES INTERNAS
Antes del empleo limpiar todas las partes internas con agua tibia y jabón neutro, a fin de eliminar el característico olor de nuevo y secarlas luego cuidadosamente.
No utilice detergentes ni polvos abrasivos, ya que podrían dañar el acabado
CONGELACIÓN DE ALIMENTOS FRESCOS
El compartimento congelador está ideado para la congelación de alimentos frescos y para la conservación a largo plazo de ali­mentos congelados y ultracongelados. Para congelar alimentos frescos no es ne­cesario cambiar el ajuste intermedio. Sin embargo, para lograr una congelación más rápida, gire el regulador de temperatu­ra a un ajuste más alto para obtener el frío máximo.
En esa situación, la temperatura del compartimento frigorífico puede descender por debajo de 0 °C. En ese caso, sitúe el regulador de temperatura en un ajuste menos frío.
lo en marcha al menos durante 2 horas con un ajuste alto antes de colocar los pro­ductos en el compartimento.
En caso de producirse una des­congelación accidental, por ejem­plo, por un corte del suministro eléctrico, si la interrupción ha sido más prolongada que el valor indi­cado en la tabla de características técnicas bajo "tiempo de eleva­ción", los alimentos descongelados deben consumirse cuanto antes o cocinarlos de inmediato y volverlos a congelar (después de que se ha­yan enfriado).
DESCONGELACIÓN
Los alimentos ultracongelados o congela­dos, antes de utilizarlos, se pueden des­congelar en el compartimento frigorífico o a temperatura ambiente, dependiendo del tiempo de que se disponga. Es posible incluso cocinar piezas pequeñas congeladas, tomadas directamente del congelador; en tal caso, el tiempo de coc­ción será más prolongado.
ALMACENAMIENTO DE ALIMENTOS CONGELADOS
Al poner en marcha el aparato por primera vez o después de un periodo sin uso, déje-
ESTANTES MÓVILES
Las paredes del frigorífico cuentan con una serie de guías para colocar los estantes del modo que se prefiera.
www.electrolux.com
76
CONTROL DE HUMEDAD
COLOCACIÓN DE LOS ESTANTES DE LA PUERTA
El estante de cristal incorpora un dispositi­vo con ranuras (ajustables mediante un pa­lanca deslizante), que permite regular la temperatura de los cajones para verduras Cuando las ranuras de ventilación están cerradas: la humedad natural de los alimentos guar­dados en los compartimentos para frutas y verduras se mantiene durante más tiempo. Cuando las ranuras de ventilación están abiertas: el aumento del aire circulante reduce el contenido de humedad de los alimentos.
Para poder guardar alimentos de distintos tamaños, los estantes de la puerta se pue­den colocar a diferentes alturas. Para cambiar la posición de los estantes: mueva paulatinamente el estante en la di­rección de las flechas hasta retirarlo del so­porte y colóquelo en la posición que desee.
1
2
CONSEJOS ÚTILES
ESPAÑOL 77
CONSEJOS PARA AHORRAR ENERGÍA
• No abra la puerta con frecuencia ni la deje abierta más tiempo del estrictamen­te necesario.
• Si la temperatura ambiente es elevada, la temperatura del aparato se ha ajustado en los valores más altos y está totalmen­te lleno, el compresor podría funcionar de manera continua, provocando la for­mación de escarcha o hielo en el evapo­rador. Si esto sucede, gire el regulador de temperatura a valores inferiores para permitir la descongelación automática y ahorrar en el consumo eléctrico.
CONSEJOS PARA LA REFRIGERACIÓN DE ALIMENTOS FRESCOS
Para obtener los mejores resultados:
• no guarde en el frigorífico alimentos ca­lientes ni líquidos en evaporación;
• cubra o envuelva los alimentos, en espe­cial si tienen sabores fuertes;
• coloque los alimentos de modo que el aire pueda circular libremente entre ellos.
CONSEJOS PARA LA REFRIGERACIÓN
Consejos útiles: Carne (de todo tipo): guárdela en bolsas de plástico y colóquela en el estante de vidrio, sobre el cajón de las verduras. Por razones de seguridad, guárdela de ese modo durante uno o dos días, como máxi­mo. Alimentos cocinados, platos fríos, etc..: los debe cubrir y puede colocarlos en cual­quiera de los estantes. Frutas y verduras: se deben limpiar a con­ciencia y colocar en los cajones especiales suministrados a tal efecto. Mantequilla y queso: colóquelos en reci­pientes herméticos especiales o envueltos en papel de aluminio o en bolsas de plásti­co, para excluir tanto aire como sea posi­ble. Botellas de leche: deben tener tapa y se colocarán en el estante para botellas de la puerta.
Los plátanos, las patatas, las cebollas y los ajos, si no están empaquetados, no deben guardarse en el frigorífico.
CONSEJOS SOBRE LA CONGELACIÓN
Estos consejos son importantes para po­der aprovechar al máximo el proceso de congelación:
• la cantidad máxima de alimentos que puede congelarse en 24 horas se mues­tra en la placa de datos técnicos;
• el proceso de congelación requiere 24 horas. Durante ese periodo no deben añadirse otros alimentos para congela­ción;
• congele sólo productos alimenticios de máxima calidad, frescos y perfectamente limpios;
• prepare los alimentos en porciones pe­queñas para que se congelen de manera rápida y total, así como para poder des­congelar posteriormente sólo las canti­dades necesarias;
• envuelva los alimentos en papel de alu­minio o polietileno y compruebe que los envoltorios quedan herméticamente ce­rrados;
• no permita que alimentos frescos y sin congelar entren en contacto con alimen­tos ya congelados, para evitar el aumen­to de temperatura de los segundos;
• los alimentos magros se congelan mejor que los grasos; la sal reduce el tiempo de almacenamiento de los alimentos;
• el hielo, si se consume inmediatamente después de retirarlo del compartimento congelador, puede provocar quemadu­ras por congelación en la piel;
• es recomendable etiquetar cada paque­te con la fecha de congelación para con­trolar el tiempo que permanecen alma­cenados.
CONSEJOS PARA EL ALMACENAMIENTO DE ALIMENTOS CONGELADOS
Para obtener el máximo rendimiento de es­te aparato, deberá:
www.electrolux.com
78
• comprobar que el comerciante ha man-
• procurar que los alimentos congelados
• evitar la apertura frecuente de la puerta o
• los alimentos descongelados se deterio-
• no supere el tiempo de almacenamiento
tenido los productos congelados correc­tamente almacenados;
pasen de la tienda al congelador en el menor tiempo posible;
dejarla abierta más del tiempo estricta­mente necesario;
ran con rapidez y no pueden congelarse de nuevo;
indicado por el fabricante de los alimen­tos.
MANTENIMIENTO Y LIMPIEZA
ESPAÑOL 79
PRECAUCIÓN
Antes de realizar tareas de mante­nimiento, desenchufe el aparato.
Este equipo contiene hidrocarbu­ros en la unidad de refrigeración; por tanto, el mantenimiento y la re­carga deben estar a cargo exclusi­vamente de técnicos autorizados.
LIMPIEZA PERIÓDICA
El equipo debe limpiarse de manera habi­tual:
• Limpie el interior y los accesorios con agua templada y un jabón neutro.
• Revise y limpie periódicamente las juntas de la puerta para mantenerlas limpias y sin restos.
• Aclare y seque a fondo.
No mueva, dañe ni tire de los con­ductos o cables del interior del ar­mario. No utilice detergentes, polvos abrasivos, productos de limpieza perfumados ni cera para limpiar el interior, ya que dañarán la superfi­cie y dejarán un fuerte olor.
Limpie el condensador (rejilla negra) y el compresor de la parte posterior del aparato con un cepillo. Esa operación mejorará el rendimiento del aparato y reducirá el con­sumo eléctrico.
Muchas marcas de limpiadores de superfi­cies de cocina contienen químicos que pueden atacar o dañar los plásticos del aparato. Por tal razón, se recomienda que el exterior del aparato se limpie sólo con agua templada a la que se añadirá un poco de líquido lavavajillas. Después de la limpieza, vuelva a conectar el aparato a la toma de red.
DESCONGELACIÓN DEL FRIGORÍFICO
Tenga cuidado para no dañar el sistema de refrigeración.
DESCONGELACIÓN DEL CONGELADOR
Junto al compartimento superior suele formarse siempre cierta can­tidad de escarcha
La escarcha se elimina automáticamente del evaporador del frigorífico cada vez que se detiene el compresor, durante el funcio­namiento normal. El agua de la desconge­lación se descarga por un canal hacia un recipiente especial situado en la parte pos­terior del aparato, sobre el motor compre­sor, desde donde se evapora. Limpie periódicamente el orificio de salida del agua de descongelación situado en la mitad del canal del compartimento frigorífi­co para evitar que el agua se desborde y caiga sobre los alimentos del interior Utilice el limpiador especial suministrado, que ha­llará ya colocado en el orificio de desagüe.
Descongele el congelador sólo cuando la capa de escarcha alcan­ce un grosor de unos 3 a 5 mm.
Para eliminar la escarcha, siga estos pa­sos:
1.
Apague el aparato.
www.electrolux.com
80
2.
3.
4.
5.
6.
7.
Retire los alimentos congelados, en­vuélvalos en varias hojas de papel pe­riódico y colóquelos en un sitio fresco.
Abra la puerta. Cuando la descongelación haya termi-
nado, seque a fondo el interior del aparato.
Encienda el aparato. Ajuste el regulador de temperatura pa-
ra obtener el máximo frío y haga fun­cionar el aparato durante dos o tres horas con dicho ajuste.
Vuelva a introducir los alimentos que retiró previamente.
ADVERTENCIA
No utilice herramientas metálicas afiladas para raspar la escarcha del evaporador, ya que podría dañarlo. No utilice dispositivos mecánicos ni medios artificiales para acelerar el proceso de descongelación, ex­cepto los recomendados por el fa­bricante. El aumento de la tempe­ratura de los paquetes de alimen­tos congelados durante la descon­gelación puede acortar su tiempo de almacenamiento.
PERIODOS SIN FUNCIONAMIENTO
Si el aparato no se utiliza durante un tiem­po prolongado, tome las siguientes pre­cauciones:
desconecte el aparato de la red
eléctrica;
• extraiga todos los alimentos;
• descongele (si así está previsto) y limpie el aparato y todos sus accesorios.
• deje la puerta(s) entreabierta para preve­nir olores desagradables.
Si va a mantener el armario en marcha, so­licite a alguien que lo inspeccione de vez en cuando para evitar que los alimentos se echen a perder en caso de un corte de energía.
QUÉ HACER SI…
ESPAÑOL 81
ADVERTENCIA
Antes de realizar cualquier repara­ción, desconecte el enchufe del aparato de la toma de red. Sólo un electricista o un técnico profesional debe llevar a cabo cual­quier reparación que no figure en este manual.
Se producen ruidos durante el fun­cionamiento normal (compresor, circulación del refrigerante).
Problema Causa probable Solución El aparato no funcio-
El aparato está apagado. Encienda el aparato.
na. La bombilla no funciona.
El aparato no está correc-
tamente enchufado a la to­ma de corriente.
El aparato no recibe co-
rriente. No hay tensión en la toma de corriente.
Enchufe el aparato correcta­mente a la toma de corrien­te.
Enchufe otro aparato eléctri­co a la toma de corriente. Llame a un electricista cuali­ficado.
La bombilla no fun-
La bombilla está en espera. Cierre y abra la puerta.
ciona.
La bombilla está defectuo-
sa.
El compresor funcio­na continuamente.
La temperatura no se ha ajustado correctamente.
La puerta no está bien ce-
rrada.
La puerta se ha abierto con
excesiva frecuencia.
Consulte "Cambio de la bombilla".
Seleccione una temperatura más alta.
Consulte "Cierre de la puer­ta".
No mantenga abierta la puerta más tiempo del nece­sario.
La temperatura de los pro-
ductos es demasiado alta.
Deje que la temperatura de los alimentos descienda a la temperatura ambiente antes de guardarlos.
La temperatura ambiente
es demasiado alta.
El agua fluye por la placa posterior del frigorífico.
Durante el proceso de des­congelación automática, el hielo se descongela en la
Reduzca la temperatura am­biente.
Esto es normal.
placa posterior.
El agua fluye al inte­rior del frigorífico.
Los productos impiden que
La salida de agua está obs­truida.
el agua fluya al colector de agua.
Limpie la salida de agua.
Asegúrese de que los ali­mentos no entran en con­tacto con la placa posterior.
www.electrolux.com
82
Problema Causa probable Solución El agua fluye hacia el
suelo.
La temperatura del aparato es demasia­do baja.
La temperatura del aparato es demasia­do alta.
La puerta no está bien ce-
La temperatura de los pro-
Se han guardado muchos
No hay circulación de aire
El agua de la descongela­ción no fluye hacia la ban­deja de evaporación situa­da sobre el compresor.
El regulador de temperatu­ra no se ha ajustado co­rrectamente.
El regulador de temperatu­ra no se ha ajustado co­rrectamente.
rrada.
ductos es demasiado alta.
productos al mismo tiem­po.
frío en el aparato.
Fije la salida de agua de descongelación a la bandeja de evaporación.
Seleccione una temperatura más alta.
Seleccione una temperatura más baja.
Consulte "Cierre de la puer­ta".
Deje que la temperatura de los alimentos descienda a la temperatura ambiente antes de guardarlos.
Guarde menos productos al mismo tiempo.
Compruebe que el aire frío circula libremente en el apa­rato.
CAMBIO DE LA BOMBILLA
CIERRE DE LA PUERTA
1.
Limpie las juntas de la puerta.
2.
Si es necesario, ajuste la puerta. Con­sulte "Instalación".
1.
Desenchufe el aparato de la toma de red.
2.
Retire el tornillo de la tapa de la bombi­lla.
3.
Extraiga la tapa de la bombilla (consul­te la ilustración).
4.
Cambie la bombilla usada por otra de la misma potencia diseñada específi­camente para aparatos domésticos (la potencia máxima se indica en la tapa de la bombilla).
5.
Instale la tapa de la bombilla.
6.
Apriete el tornillo de la tapa de la bom­billa.
7.
Conecte el enchufe a la toma de red.
8.
Abra la puerta. Compruebe que la bombilla se ilumina.
3.
Si es necesario, cambie las juntas de­fectuosas. Póngase en contacto con el servicio técnico.
INSTALACIÓN
ADVERTENCIA
Antes de instalar el aparato, lea atentamente el apartado "Informa­ción sobre seguridad" para garanti­zar su propia seguridad y el funcio­namiento correcto del aparato.
COLOCACIÓN
Instale el aparato en un punto en el que la temperatura ambiente se corresponda con la clase climática indicada en la placa de datos técnicos del aparato:
Clase climá­tica
SN +10°C a + 32°C N +16°C a + 32°C ST +16°C a + 38°C T +16°C a + 43°C
CONEXIÓN ELÉCTRICA
Antes de conectar el aparato, compruebe que el voltaje y la frecuencia que aparecen en la placa de datos técnicos se corres­ponden con el suministro de la vivienda. El aparato debe tener conexión a tierra. El enchufe del cable de alimentación se sumi­nistra con un contacto para tal fin. Si la to­ma de red de la vivienda carece de cone­xión a tierra, conecte el aparato a una toma de tierra conforme con la normativa, des­pués de consultar a un electricista profe­sional. El fabricante rechaza toda responsabilidad si no se toman las precauciones antes indi­cadas. Este aparato es conforme con las directi­vas de la CEE.
Consulte las instrucciones de mon­taje para la instalación.
ESPAÑOL 83
Temperatura ambiente
www.electrolux.com
84
RUIDOS
Durante el funcionamiento normal del apa­rato suelen producirse ciertos ruidos (com­presor, circulación del refrigerante).
SSSRRR!
HISSS!
CLICK!
BRRR!
OK
CLICK!
BRRR!
CRACK!
BLUBB!
CLICK!
BRRR!
BLUBB!
BLUBB!
HISSS!
ESPAÑOL 85
HISSS!
DATOS TÉCNICOS
Medidas de la cavidad Altura 1225 mm Anchura 560 mm Profundidad 550 mm Tiempo de estabilización 12 h Voltaje 230-240 V Frecuencia 50 Hz
La información técnica se encuentra en la placa de características, situada en el lado
SSSRRR!
CRACK!
SSSRRR!
CRACK!
interior izquierdo del aparato, y en la eti­queta de consumo energético.
www.electrolux.com
86
ASPECTOS MEDIOAMBIENTALES
Recicle los materiales con el símbolo Coloque el material de embalaje en los
contenedores adecuados para su reciclaje. Ayude a proteger el medio ambiente y la salud pública, así como a reciclar residuos de aparatos eléctricos y electrónicos. No
.
deseche los aparatos marcados con el símbolo
domésticos. Lleve el producto a su centro de reciclaje local o póngase en contacto con su oficina municipal.
junto con los residuos
ESPAÑOL 87
www.electrolux.com/shop 212358511-A-472011
Loading...
