ELECTROLUX ERG23610 User Manual

user manual

Fridge

ERG23610

2 electrolux

Electrolux. Thinking of you.

Share more of our thinking at www.electrolux.com

CONTENTS

Safety information 2
Control panel 4
First use 5
Daily use 5
Helpful hints and tips 5

SAFETY INFORMATION

In the interest of your safety and to ensure
the correct use, before installing and first us­ing the appliance, read this user manual
carefully, including its hints and warnings.
To avoid unnecessary mistakes and acci­dents, it is important to ensure that all peo­ple using the appliance are thoroughly famil­iar with its operation and safety features.
Save these instructions and make sure that
they remain with the appliance if it is moved
or sold, so that everyone using it through its
life will be properly informed on appliance
use and safety.
For the safety of life and property keep the
precautions of these user's instructions as
the manufacturer is not responsible for dam­ages caused by omission.

Children and vulnerable people safety

• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge, un­less they have been given supervision or
instruction concerning use of the appli­ance by a person responsible for their
safety.
Children should be supervised to ensure
that they do not play with the appliance.

• Keep all packaging well away from chil­dren. There is risk of suffocation.

• If you are discarding the appliance pull
the plug out of the socket, cut the con­nection cable (as close to the appliance
as you can) and remove the door to pre­vent playing children to suffer electric
shock or to close themselves into it.

• If this appliance featuring magnetic door
seals is to replace an older appliance hav­ing a spring lock (latch) on the door or lid,

Care and Cleaning 6
What to do if… 7
Technical data 9
Installation 9
Environmental concerns 10

Subject to change without notice

be sure to make that spring lock unusa­ble before you discard the old appliance.
This will prevent it from becoming a
death trap for a child.

General safety

Caution! Keep ventilation openings

clear of obstruction.

• The appliance is intended for keeping
foodstuff and/or beverages in a normal
household as explained in this instruction
booklet.

• Do not use a mechanical device or any ar­tificial means to speed up the thawing
process.

• Do not use other electrical appliances
(such as ice cream makers) inside of re­frigerating appliances, unless they are ap­proved for this purpose by the manufac­turer.

• Do not damage the refrigerant circuit.

• The refrigerant isobutane (R600a) is con­tained within the refrigerant circuit of the
appliance, a natural gas with a high level
of environmental compatibility, which is
nevertheless flammable.
During transportation and installation of
the appliance, be certain that none of the
components of the refrigerant circuit be­come damaged.
If the refrigerant circuit should become
damaged:
– avoid open flames and sources of igni-

tion

– thoroughly ventilate the room in which

the appliance is situated

• It is dangerous to alter the specifications
or modify this product in any way. Any

electrolux 3

damage to the cord may cause a short­circuit, fire and/or electric shock.

Warning! Any electrical component
(power cord, plug, compressor) must
be replaced by a certified service agent
or qualified service personnel.

1. Power cord must not be lengthened.

2. Make sure that the power plug is not
squashed or damaged by the back of
the appliance. A squashed or dam­aged power plug may overheat and
cause a fire.

3. Make sure that you can come to the
mains plug of the appliance.

4. Do not pull the mains cable.

5. If the power plug socket is loose, do
not insert the power plug. There is a
risk of electric shock or fire.

6. You must not operate the appliance
without the lamp cover

1)

of interior

lighting.

• This appliance is heavy. Care should be
taken when moving it.

• Do not remove nor touch items from the
freezer compartment if your hands are
damp/wet, as this could cause skin abra­sions or frost/freezer burns.

• Avoid prolonged exposure of the appli­ance to direct sunlight.

•

Bulb lamps

2)

used in this appliance are
special purpose lamps selected for house­hold appliances use only. They are not
suitable for household room illumination.

Daily use

• Do not put hot pot on the plastic parts in
the appliance.

• Do not store flammable gas and liquid in
the appliance, because they may explode.

• Appliance's manufacturers storage rec­ommendations should be strictly adhered
to. Refer to relevant instructions.

Care and cleaning

• Before maintenance, switch off the appli­ance and disconnect the mains plug from
the mains socket.

• Do not clean the appliance with metal ob­jects.

• Regularly examine the drain in the refriger­ator for defrosted water. If necessary,
clean the drain. If the drain is blocked, wa­ter will collect in the bottom of the appli­ance.

Installation

Important! For electrical connection

carefully follow the instructions given in
specific paragraphs.

• Unpack the appliance and check if there
are damages on it. Do not connect the ap­pliance if it is damaged. Report possible
damages immediately to the place you
bought it. In that case retain packing.

• It is advisable to wait at least four hours
before connecting the appliance to allow
the oil to flow back in the compressor.

• Adequate air circulation should be
around the appliance, lacking this leads
to overheating. To achieve sufficient ven­tilation follow the instructions relevant to
installation.

• Wherever possible the back of the prod­uct should be against a wall to avoid
touching or catching warm parts (com­pressor, condenser) to prevent possible
burn.

• The appliance must not be located close
to radiators or cookers.

• Make sure that the mains plug is accessi­ble after the installation of the appliance.

•

Connect to potable water supply only.

3)

Service

• Any electrical work required to do the serv­icing of the appliance should be carried
out by a qualified electrician or compe­tent person.

• This product must be serviced by an au­thorized Service Centre, and only genu­ine spare parts must be used.

1) If the lamp cover is foreseen

2) If the lamp is foreseen

3) If a water connection is foreseen

F

4 electrolux

Environment Protection

This appliance does not contain gasses
which could damage the ozone layer,
in either its refrigerant circuit or insula­tion materials. The appliance shall not
be discarded together with the urban re­fuse and rubbish. The insulation foam
contains flammable gases: the appli-

CONTROL PANEL

Fridge Control panel

ON/OF

1 2 3 4 5 6 7

1. Pilot light

2. ON/OFF switch

3. Temperature regulator (warmest)

4. Temperature indicator

5. Temperature regulator (coldest)

6. Action Cool light

7. Action Cool switch

Switching on

Insert the plug into the wall socket.
Press the ON/OFF switch .
The Pilot Light will light up.

Important! At start-up the displayed
temperature don't correspond with the set
temperature until stabilised (within 24 hours).

Switching off

Press ON/OFF switch until a countdown
from -3 -2 -1 is completed.
The temperature indicator switches off. The
Pilot light switches off.

Temperature regulation

The temperature can be adjusted between
+2°C and +8°C.
By pressing the Temperature regulators,
the current temperature setting flashes on
the Temperature indicator. It is possible to
modify the setting temperature only with
flashed indicator. To set a warmer tempera­ture, press warmest Temperature regulator.
To set a colder temperature, press coldest
Temperature regulator. The Temperature in­dicator displays the newly selected temper-

ance shall be disposed according to
the applicable regulations to obtain
from your local authorities. Avoid dam­aging the cooling unit, especially at the
rear near the heat exchanger. The ma­terials used on this appliance marked

by the symbol

are recyclable.

ature for a few seconds and then shows
again the inside compartment temperature.
The newly selected-temperature must be
reached after 24 hours.

Temperature indicator

During normal functioning the Temperature
indicator shows the temperature inside the
fridge.

Important! Difference between the
temperature displayed and temperature
setting is normal. Especially when:

• a new setting has recently been selected.

• the door has been left open for a long time.

• warm food has been placed in the com­partment.

Action Cool function

The maximum performance is obtained by
setting the Action Coolfunction. It’s recom­mended when loading large quantities of
food.
You can activate the Action Cool function
by pressing the Action Cool switch.
The Action Cool light will light up.

Important! The internal temperature goes
down to +2°C.
After about 6 hours the Action Cool func­tion switches off automatically.

Holiday function

This function allows you to keep the refriger­ator shut and empty during a long holiday
