Electrolux ERES35800 User Manual
User manual
Benutzerinformation
refrigerator
kühlgeräte
ERES35800
We were thinking of you
when we made this product
Welcome to the world of Electrolux
Thank you for choosing a first class product from Electrolux, which hopefully will
provide you with lots of pleasure in the future. The Electrolux ambition is to offer
a wide variety of quality products that make your life more comfortable. You find
some examples on the cover in this manual. Please take a few minutes to study
this manual so that you can take advantage of the benefits of your new machine.
We promise that it will provide a superior User Experience delivering
Ease-of-Mind. Good luck!
3
The following symbols are used in this manual:
T
Important information concerning your personal safety an d
information on how to avoid damaging the appliance
General information and tips
Environmental information
Scrapping old appliances
he symbol on the product or on its packaging indicates that this product
may not be treated as household waste. Instead it should be taken to the
appropriate collection point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handling of
this product. For more detailed information about recycling of this product,
please contact your local council, your household waste disposal service or the
shop where you purchased the product.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they h ave been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
4
Safety instructions
Your new fridge may have other
functions compared to your previous
one.
Carefully read these instructions
learn how the appliance works
how to care for it. Keep the
booklet. It will come in handy if
later sell the cabinet or give it
somebody else.
These warnings are provided in the
interests of your safety. Ensure that
you understand them all before
installing or using the appliance. Your
safety is of paramount importance. If
you are unsure about any of the
meanings or warnings contact the
Customer Care Department.
to
and
instruction
you
to
For the User
· The refrigerator is intended for the
storage of foodstuffs and the
production of cold water, with or
without carbon dioxide, for normal
household use in accordance with
these instructions.
· If the gas cylinder is used for other
purposes than that intended or if it is
filled by an unauthorised person, all
guarantees automatically become null
andvoid.Inordertoensurereliable
functioning, only an Electrolux Cylinder
may be used.
· Do not keep explosive gases or
liquids in the refrigerator or freezer
compartment. They may explode and
cause injury an d material damage.
· Do not let sharp objects come into
contact with the refrigerating system
on the back of and inside the cabinet.
If the refrigerating system is punctured,
the cabinet will be damaged and
foodstuff inside may spoil.
· Do not keep carbonised drinks or
bottles in the freezer compartment.
The glass bottles may break.
· The cabinet is heavy. The edges
and projecting parts of the cabinet
may be sharp. Be careful when moving
the cabinet and always use gloves.
Child Safety
· Pay attention so that small children
do not gain access to the operating
controls or the inside of the cabinet.
WARNING
Keep ventilation openings, in the
appliance enclosure or in the built-in
structure, clear of obstruction.
WARNING
Do not use mechanical devices or
other means to accelerate the
defrosting process, other than those
recommended by the manufacturer.
WARNING
Do not damage the refrigerant circuit.
WARNING
Do not use electrical appliance inside
the food storage compartments of the
appliance, unless they are of the type
recommended by the manufacturer.
WARNING
Connect to potable water supply only.
5
Contents
Welcome to the world of Electrolux 3.
Scrapping old cabinets 4...........
Safety instructions 5............
Contents 6......................
USE 7...........................
Control Panel 7...................
DISPLAY 7.......................
Functions Menu 8.................
Select /Switch off /Switch on 8......
Temperature regulation 8...........
Switching off 8....................
Child Lock Function 9..............
Shopping Function 9...............
Eco mode Function 9..............
Drinks Chill Function 9.............
Use of the fridge compartment 9.....
Temperature regulation 9...........
Holiday Function "H" 10............
Door open acoustic alarm 10........
Control Panel (water dispenser) 10...
Cabinet interior 12.................
HINT and TIPS 13.................
Saving energy 13..................
Food Storage 13..................
Protect the environment 13.........
MAINTENANCE and CLEANING 14..
Removing the ventilation grille 14....
Cleaning 14......................
Servicing and cleaning the water
dispenser. 14..................
Service during operation 15.........
To ch an ge the lamp 15.............
Change of carbon filter 15..........
Defrosting the fridge 16.............
When the appliance is not in use 16..
SOMETHING NOT WORKING 16....
TECHNICAL SPECIFICATION 18....
Permissible water pressure (to ensure
reliable function). 18............
INSTALLATION 19.................
Unpacking 19.....................
Remove the transport supports 19...
Cleaning 19......................
Connecting the water hose. 19......
Electrical cord 20..................
Installation of carbon filter 20........
Installing the cabinet 20............
When the water system is started for the
first time 22...................
Electrical connection 23............
6
USE
Position and clean the cabinet as
explained in the section "Installation".
Check that the drain hose at the rear
of the cabinet discharges into the drip
tray.
Before inserting the power plug into the outlet and switching on the cabinet for
the first time, leave it standing upright for about 2 hours. Otherwise the
compressor may sustain damage. This time will allow the oil sufficient time to
return to the compressor .
Control Panel
AE
B
A - Appliance button ON/OFF
B - Temperature regulation button
C - Temperature and function indicator
DISPLAY
Excessive temperature alarm and
Door open acoustic alarm
Indicator (if foreseen)
PositiveTemperature indicator
Temperature indicator
7
C
D
D - Function button
E - Confirmation button
If on the Child Lock function is on
If on the Shopping function is on
If on the Drink Chill mode function
is on
If on the Eco Mode function is on
First switch on
After plugging the plug into the power
outlet, if the display is not illuminated,
press key (A), appliance on.
For a correct storage of the food select
the Eco mode function that guarantee
the following temperature i s set:
+5°C in the fridge
· To select a different temperature
see "Temperature regulation".
Functions Menu
By activating the key D the fun ctions
menu is operating. Each function
could be confirmed by pressing button
E. If there is no confirmation after
some seconds the display will go out
from the menu and return in normal
condi-tion.
The following functions are indicated:
the buzzer).
Then the indicator shows the inside
compartment temperature again.
The newly selected-temperature must
be reached after 24 hours.
It is not n ecessary to set the temperature again after long periods of non
use as the temperature remains
stored.
Attention!
During the stability period by the first
starting the temperature displayed can
not correspond to the setting temperature. During this time it is possible
that the temperature displayed is
different than the setting temperature.
Switching off
Child Lock function
Shopping function
Eco Mode function
Drinks Chill fun ction
Select /Switch off /Switch on
Temperature regulation
The temperature may be regulated by
pressing the key (B) to set the desired
temperature.
By pressing the key B the current temperature setting flashes on the indicator and by pressing the key B again it
is possible to change it.
Youconfirmthechoiceofthetemperature either by pressing the key E,
(you will hear the buzzer) or by waiting
for some seconds (you will not hear
The appliance is shut off by pressing
key (A) for more than 1 second. After
this, a countdown of the temperature
from -3 -2 -1 will be shown.
8
Child Lock Function
The Child Lock function is activated by
pressing key D (several times if
necessar y) until the correspo nd ing icon
appears
You must confirm the choice by pres sing key E within few seconds. You will
hear the buzzer and the icon remains
lighted.
In this condition any possible operation
through the keys does not cause any
change as long as this fu n ction is
activated.
It is possible to de-activate the function
atanytimebypressingkeyDuntilthe
corresponding icon flashes and then
key E.
.
Shopping Function
If you need to insert a large amount of
warm food, for example after doing the
grocery shopping, we suggest you
activate the Shopping function to chill
the products more rapidly and to avoid
warming the other food which is
already in the refrigerator.
The Shopping function is activated by
pressing key D (several times if necessary) until the corresponding icon
appears
choice by pressing key E within a few
seconds. You will hear the buzzer and
the icon will remain lit.
The Shopping function shuts off automatically after approximately 6 h ours.
It is possible to de-activate the function
atanytimebypressingkeyDuntilthe
corresponding icon will flashes and
then key E.
. You must confirm the
Eco mode Function
The Eco mode function is activated by
pressing key D (several times if necessary) until the corresponding icon
appears
choice by pressing key E within few
seconds. You will hear the buzzer and
the icon remains lighted.
In this condition the chosen temperatures are au tomatically set (+ 5°C and
- 18°C), in the best conditions for
storing food.
It is possible to de-activate the function
at any time by changing the selected
temperature in one of the compartments.
. You must confirm the
Drinks Chill Function
The Quick Chill function permits the
rapid cooling of cans and bottles
taking forced cold air into them.
Put the drinks on the Quick Chill shelf
and open the air lever to the
maximum.
The Quick Chill function is activated by
pressing key D (several times if
necessary) until the corresponding icon
appears
When the cooling is finished de-activate the function by pressing key D
until the corresponding icon will flash,
then key E and reset the air lever to the
minimum .
.
Use of the fridge compartment
Temperature regulation
The temperature of this compartment
may be regulated between +2°C and
+8°C.
During normal functioning the indicator
shows the temperature inside the
fridge.
9
Attention!
Difference between the temperature
displayed and temperature setting is
normal. Especially when:
- a new setting has recently been
selected
- the door has been left open for a
long time
- warm food has been placed in the
compartment.
Holiday Function " H"
The holiday function sets the temperature at + 15°C.
This function allows you to keep the
refrigerator shut and empty during a
long holiday period ( e. g. the summer
holidays) without the formation of a
bad smell.
The Holiday Function H may be regulated by pressing the key B. By pressing the key B the current temperature
setting flashes on the indicator. Press
the key B again. When the letter H
appears on the display, confirm the
choice of the temperature or by
pressing the key E, (you will hear the
buzzer) or by waiting for some
seconds (you will not h ear the buzzer).
Now the refrigerator is in the Holiday
function in the energy saving mode
and the indicator shows the letter H.
It is possible to de-activate the function
at any time by changing the selected
temperature in the compartment.
Attention!
The fridge compartment must be
empty whilst the Holiday function is on.
Door open acoustic alarm
An acoustic alarm will sound when the
door is left open for around 5 minutes.
The door open alarm conditions are
indicated by:
- flashing of the icon
- sounding of buzzer.
Press the key (E) to stop the acoustic
alarm.
When normal conditions are resto red
(door closed):
- the acoustic alarm will stop.
;
Control Panel (water dispenser)
H
H. Yellow indicator lamp
Lights up when the locking function
has been activated.
I. Button for carbonated water.
-Usedforthechoiceofcarbonated
water.
I
M
L
N
- For the engagement and
disengagement of the locking fu n ction.
J. Button for ordinary water.
- Used for the choice of ordinary water.
- Switches the background lighting on
and off.
K
J
10
- Switches off the indicator lamp for
water filter replacement.
K. Yellow indicator lamp
Lights up when the water filter must be
changed.
L. Water out-feed
Activated when a glass or something
similar is pressed upwards against the
flap.
M. Flap
N. Lighting
The functions of the waterdispenser
The locking function:
The locking fun ction is activated by the
production plant.
For temporary unlocking:
Keep the button (I) pressed in for about
three seconds until the yellow indicator
lamp (H) goes out. The locking
function is re-activated automatically
after about three seconds.
For permanent unlocking:
Keep the buttons (I) and (J) pressed in
at the same time for about three
seconds. The button (I) or (J) lights up
to indicate unlocking.
To activate the locking fun ction:
Keep the buttons (I) and (J) pressed in
at the same time for about three
seconds. Activation is indicated by the
yellow indicator lamp (H) lighting up.
Selecting and obtaining water:
Before obtaining water, selection is
carried out either by pressing the
button for carbonated water (I) or the
button for ordinary water (J). The
actual choice i s indicated by the
button which lights up. The selection
of water can be changed while the
water is running.
Water is obtained by pressing a glass
or other container against the opening
(M). Stop the water flow by moving the
glass or container downwards away
from the opening (M). Any water that
drips or is spilled is collected in the
drip bowl below the water dispenser.
When the carbonated water is being
obtained, there is a slight afterflow
when the glass is removed. The drip
bowl can be detached and emptied
when necessary.
Lighting:
The water dispenser lighting (N) illuminates automatically when water is
obtained.
For continuous lighting:
1. Make sure that the water dispenser
is unlocked.
2. Then hold the button for ordinary
water (J) pressed in for about three
seconds until the illuminates.
The lighting then illuminates with about
50 % of its full intensity.
To switch off the lighting:
1. Ensure that the water dispenser is
unlocked.
2. Then hold the button for ordinary
water (J) pressed in for about three
seconds until the lighting goes out.
11
Indicator lamp for the water filter:
The water dispenser is fitted with an
indicator lamp (K) which shows when it
is time to change the water filter. When
the indicator lamp stays on, then the
water filter has been utilised to about
80 % of its expected lifetime. In this
situation, it is recommended that you
buy a replacement filter. When the
indicator lamp starts flashing, the
water filter has been utilised to 100%
of its lifetime. Replace the filter without
delay.
After replacing the filter cartridge, see
the section "Service during operation".
The indicator lamp can be switched off
by holding the button for ordinary
water (J) pressed in for about three
seconds until the indicator lamp goes
out.
Carbon filter's function:
The built-in carbon filter means that
strong smelling groceries can be
placed near other groceries without
affecting their taste or aroma.
Certain shelves must be lifted up by
the rear edge to enable them to be
removed.
The lower door compartment and the
glass shelf above the vegetable drawer
must not be moved. They are fitted to
ensure air circulation inside the
cabinet.
Shelves with a raised edge should be
placed with the raised edge facing the
rear wall of the cabinet.
The vegetable drawer has a ventilation
edging to increase the circulation of air
and reduce the risk of condensation.
Cabinet interior
The shelves and door compartments
are removable and can easily be
re-arranged.
Quick chill shelf:
The lower Quick chill shelf can be
placed in one of the upper grooves. To
maintain the best performance the
shelf should be placed in the second
groove from the top.
12
Bottleholder
Thesideofthebottleholderis
moveable to enable a more flexible
placement of bottles in front of the
grid. During chilling of bottles the
article should be centrally placed in
front of the grid to obtain the best
chilling effect.
The bottle support can be pulled out
when chilling larger bottles.
For a description of this functions start
and stop, see u n der heading Quick
Chill.
Dismantling of the bottleholder.
To loosen the holder from the shelf.
HINT and TIPS
Saving energy
· Pay careful attention to where the
cabinet is placed. See the section
"Installation". When installed correctly,
the cabinet will consume less energy.
· Try to avoid keeping the door open
for long periods, or opening the door
too frequently as warm air will enter the
cabinet, and cau se the compressor to
switch on unnecessarily often.
· Ensure there are no obstructions
preventing the door from closing
properly.
· Thaw frozen food in the fridge. This
will ensure safer defrosting of foods
and reduce the work of the
refrigeration unit
· It is advisable to periodically clean the
refrigeration system at the back of the
appliance with a duster or vacuum
cleaner.
· Always leave warm food to cool
down to room temperature before
placing in the fridge.
· Make sure the door gasket is
complete and always clean.
Food Storage
· To obtain the best results from your
appliance, neither hot foods n or liquids
which may evaporate, should be
placed in the larder compartment.
· Avoid buying frozen food if you can
not store it straight away. The use of
an insulated container is advisable.
When you arrive home place the
frozen food in the freezer immediately.
· Ensure that food placed in the freezer
is dated and labelled and u sed in date
order to ensure that food is consumed
at its best. Remove suspect food from
you appliance and clean, refer to
cleaning and maintenance.
Protect the environment
· Hand over the cabinet packaging
and discarded fridges and freezers to a
recycling station. Contact your local
council or Environmental Health office
for more information.
· Keep foodstuff in re-usable
containers. Cut down on disposable
material as much as possible.
· When cleaning the cabinet, use a
mild washing-up detergent.
· Follow the advice in the section
"Saving energy"
· The door gasket and coolant used in
this cabinet will not harm the ozone
layer.
· All parts in the packaging can be
recycled.
· The cabinet has been designed for
easy dismantling and subsequent
recycling.
13
MAINTENANCE and
CLEANING
Removing the ventilation grille
The ventilation grille can be removed,
e.g. to wash the grille.
Make sure the door is open when
removing the ventilation grille. Unsnap
the upper edge of the grille by pulling
outward/downward. Then pull the grille
straight out to completely remove it.
Cleaning
Clean the cabinet at regular intervals.
Internal Cleaning
Disconnect the appliance from
electricity supply.
Clean the inside and accessories with
warm water and bicarbonate of soda
(5ml to 0,5 litre water) Rinse and dry
thoroughly.
Regularly check the door seals and
wipe clean to ensure they are clean
and free from debris.
External Cleaning
Use water/neutral soap emulsion for
cleaning the surface of stainless steel,
anti-finger-print coated. Do NOT u se
abrasive paste.
Wash the outer cabinet with warm
soapy water. Remove the ventilation
grille (see the section "Removing the
ventilation grille") and vacuum-clean
under the cabinet. Once or twice a
year dust the condenser (black grille)
and the compressor at the back of the
appliance, with a brush or vacuum
cleaner, as an accumulation of dust
will affect the performance of the
appliance and cause excessive
electricity consumption.
When moving the cabinet, lift it by the
front edge to avoid scratching the floor.
Servicing and cleaning the water
dispenser.
Never use cleaning agents with a
grinding or aggressive effect.
When necessary, clean the surfaces of
the dispenser and the water container
that are accessible from the outside,
using only a soft cloth and warm water.
The dispenser drip bowl can be
cleaned with a tepid solution of
washing up liquid.
If the system is not be used for a long
period turn off the water connection to
the refrigerator. A filter that has been in
service shall not be exposed to
temperatures below 0 °C as cracking
of the filter body may occur due to
freezing expansion.
If the filter still is to be preserved for
later reuse, suitable storage
temperature will be +5 °C.
14
When the refrigerator is to be used
again, rinse the system through
thoroughly by draining off at least three
litres (5 pints) of water.
If necessary , all systems containing
water must be sanitized by ordering
the necessary sanitizing kit through
Electrolux Service Force Centre (tel:
+44 8705 929 929) or through our
website www.electrolux.co.uk.
Service during operation
The water filter is replaced as follows:
Place a piece of kitchen tissue or a
dishcloth in the space under the filter.
Remove the filter by turning it
clockwise. A small amount of water will
run out. Dry off and fit the new filter.
See the section " When starting the
water system for the first time".
The water connection does not need
to be switched off when changing the
filter.
Replacement filters can be ordered
from Electrolux Service Force Centre.
See the section "Service and
replacement parts".
The gas cylinder is replaced as follows:
remove the gas cylinder and transfer
the adapter to the new cylinder.
The replacement gas cylinder is
obtained through your local dealer.
into a centred position and press until
it snaps into place.
Use a halogen bulb of the same type,
maximum rating of 20 W.
Change of carbon filter
To main tain the best performance the
carbon filter should be changed once
a year with normal usage.
New carbon filters can be purchased
from your local dealer. The filter is
placed behind the grill and can be
reached by opening the cover. The
cover can be opened by turning the
cover outward. The carbon filter is
pulled out of its slot.
The new carbon filter is placed in the
existing slot - The filter should be
handled carefully so fragments do not
loosen from the surface.
1
To change the lamp
The light is switched on automatically
when the door is opened. Before
replacing the light bulb, disconnect the
power plug from the outlet.
Disassemble the lamp by using a
screwdriver in the recess on the lamp
insert. To prise it out of its location.
Assemble a new lamp by guiding it
15
Loading...
