Electrolux ERB 34001W User Manual

ERB 34001W

kühl - gefrierkombination

refrigerator- freezer combination

gebrauchsanleitung

instruction book

We were thinking of you

when we made this product

electrolux 31

WWeellccoommee ttoo tthhee wwoorrlldd ooff EElleeccttrroolluuxx

Thank you for choosing a first class product from Electrolux, which hopefully will provide you with lots of pleasure in the future. The Electrolux ambition is to offer a wide variety of quality products that make your life more comfortable. You find some examples on the cover in this manual. Please take a few minutes to study this manual so that you can take advantage of the benefits of your new machine. We promise that it will provide a superior User Experience delivering Ease-of-Mind. Good luck!

32 electrolux

Before installing and using the appliance read this user's instruction book carefully. It contains safety precautions, hints, information and ideas. If the refrigerator is used in compliance with the instructions written, it will operate properly and provide you with greatest satisfaction.

The symbols below help you to find things more easily:

Safety precautions

Warnings and information at this symbol serve safety for you and your appliance.

Hints, useful information

Environmental information

Symbol for ideas

At this symbol ideas can be found according to food and its storing.

The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

electrolux 33

Contents

Important safety information....................................................................35

General safety precautions.....................................................................35

Precautions for child safety ....................................................................36

Safety precautions for installation ............................................................36

Safety precautions for isobutane .............................................................36

Instructions for the User ..........................................................................37

General information...............................................................................37

Putting it into use ..................................................................................37

Controlling the temperature, setting .........................................................37

How to use the refrigerator.....................................................................38

Storing in the refrigerator...................................................................38

Storage time and temperature of foods................................................38

Freezing .........................................................................................39

Storing in the freezer ........................................................................39

Some useful information and advice ....................................................40

Hints and ideas ................................................................................41

How to save energy ..........................................................................41

The appliance and environment ..........................................................41

Maintenance ........................................................................................41

Defrosting .......................................................................................41

Regular cleaning..............................................................................43

When the refrigerator is not in use ......................................................43

Trouble shooting...................................................................................43

How to change the bulb ....................................................................43

If something does not work................................................................43

Instructions for the Installer .....................................................................46

Technical data......................................................................................46

Installing the appliance ..........................................................................46

Transportation, unpacking .................................................................46

Cleaning.........................................................................................46

Placement ......................................................................................46

Electrical connection ........................................................................50

Storage time chart (1) .............................................................................51

Storage time chart (2) .............................................................................52

Warranty and service...............................................................................52

Guarantee conditions ............................................................................52

Service and spare parts ....................................................................52

Guarantee/Customer Service .................................................................53

European Guarantee ..............................................................................56

34 electrolux

electrolux 35

Important safety information

General safety precautions

Keep these instructions and they should remain at the appliance when moving away or changing owner. This appliance is designed for storing food, domestic use according to these instructions only.

Specialised companies that are qualified to do so by the manufacturer must carry out service and repairs including repairing and changing the power cord. Accessory parts supplied by

them should be used only for repairing. Otherwise the appliance can be damaged or can cause other damage or injury. The appliance is out of circuit only in that case if the plug is removed from the socket. Before cleaning and maintenance always unplug it (do not get it by the cable). If the socket is difficult to reach, switch off the appliance by cutting off the current. Power cord must not be lengthened.

Make sure that the power plug is not squashed or damaged by the back of the fridge/freezer.

- A damaged power plug may overheat and cause a fire.

Do not place heavy articles or the fridge/freezer itself on the power cord.

- There is a risk of a short circuit and fire.

Do not remove the power cord by pulling on its lead, particularly when the fridge/freezer is being pulled out of its niche.

- Damage to the cord may cause a short-circuit, fire and/or electric shock.

- If the power cord is damaged, it must be replaced by a certified service agent or qualified service personnel.

If the power plug socket is loose, do not insert the power plug.

- There is a risk of electric shock or fire.

Without the lamp cover of interior lighting you must not operate the appliance. When cleaning, defrosting, taking out frozen food or ice tray do not use sharp, pointed or hard devices, as they can cause damage to the appliance. Be careful not to allow liquids to the temperature control and lighting box. Ice and ice-cream can cause hurt if they are eaten immediately after removal from the frozen food compartment. After dissolving frozen food must not be refrozen, it must be used up as soon as possible. Store pre-packed frozen food in accordance with the frozen food manufacturer's instructions. You must not make defrosting faster with any electric heating appliance or chemicals. Do not put hot pot to the plastic parts. Do not store flammable gas and liquid in the appliance, because they may explode. Do not store carbonated drinks, bottled drinks and bottled fruits in the frozen food compartment. Check and clean the outlet of melting water coming during defrosting regularly - a label inside the appliance warns you for this. If it is clogged the melting water gathered can cause earlier failure.

36 electrolux

Precautions for child safety

Do not allow children to play with the packaging of the appliance. Plastic foil can cause suffocation. Adults must handle the appliance. Do not allow children to play with it or its controlling parts. If you are discarding the appliance pull the plug out of the socket, cut the connection cable (as close to the appliance as you can) and remove the door to prevent playing children to suffer electric shock or to close themselves into it.

Safety precautions for installation

Put the appliance to the wall to avoid touching or catching warm parts (compressor, condenser) to prevent possible burn. When moving the appliance take care of the plug not to be in the socket. When placing the appliance take care not to stand it on the power cord. Adequate air circulation should be around the appliance, lacking this leads to overheating. To achieve sufficient ventilation follow the instructions relevant to installation. See chapter "Placement".

For the safety of life and

property keep the precautions of these user's instructions as the manufacturer is not responsible for damages caused by omission.

Safety precautions for isobutane

Warning

The refrigerant of the appliance is isobutane (R600a) that is inflammable and explosive to a greater extent. Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. Do not use mechanical devices or other means to accelerate the

defrosting process, other than those recommended by the manufacturer. Do not damage the refrigerant circuit. Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

electrolux 37

General information

The official designation of the appliance is "refrigeratorfreezercombination with one motor compressor and freezer placed in the lower part". The appliance has - besides the general services- a freezer with its own door and is completely separated from the other unit.

According to this the appliance is suitable for storing frozen and deep-frozen food, freezing products in quantity given in

the user's instructions at home and making ice. The appliance can meet the requirements of standardsbetween different temperature limits according to theclimate class.

The letter symbol for climate class can be found on the data label.

Putting it into use

Place the accessories into the appliance then plug to the mains socket.

The thermostat knob is on the light box in the refrigerator. You can switch the appliance on and set the temperature with it by turning the knob clockwise.

The next paragraph will give instructions for setting.

Controlling the temperature, setting

The thermostat interrupts the operation of the appliance automatically for more or less time depending on the setting then restarts it assuring the required temperature.

Instructions for the User

The closer it is set to maximum position the more intensive the refrigerating will be. When the thermostat knob is set to a medium position (between minimum and maximum), in the freezing compartment 18 °C, in the fresh food compartment +5 °C can be reached. Setting it to a medium position is adequate for everyday use.

The temperature coming about in the refrigerator is effected by not only the position of the thermostat but the ambient temperature, frequency of door openings and the quantity of food put into it newly, etc.

In the maximum position - in

case of increased demand e.g. during heatwaves - the compressor may operate continually. This does not cause damages to the appliance.

38 electrolux

Storing in the refrigerator

When placing the different kinds of food take into consideration the sketch below in figure:

1. Confectionery, ready-cooked foods, foods in dishes, fresh meat, cold cuts, drinks

2. Milk, dairy products, foods in dishes

3. Fruits, vegetables, salads

4. Cheese, butter

5. Eggs

6. Yoghurt, sour cream

7. Small bottles, soft drinks

8. Big bottles, drinks

Storage time and temperature of foods

The storage time chart at the end of the instruction book gives information about storage time.

The storage time can not be determined exactly in advance, as it depends on the freshness and handling of the cooled food. That is why the storage time made known is only informative.

If you do not want to use up deep-frozen foods bought immediately they can be stored for about 1 day (until dissolving) in the refrigerator.

How to use the refrigerator

For adequate cooling

developing interior air circulation is necessary. For this reason you are asked not to cover the air circulation gaps behind the shelves (e.g. with tray etc.).

Do not put hot food into the

refrigerator. Allow it to reach room temperature naturally. In this way the unnnecessary frost building up can be avoided.

Foods can take over odours

from each other. So it is essential to put foods in closed dishes or wrap them in cellophane, aluminium foil, grease-proof paper or cling film before placing them into the refrigerator. This way foods will keep their moisture e.g. vegetables will not dry out after some days.
