Page 1
Model EOD 984
Page 2
TECHNICAL DETAILS
MODEL NO. EOD 984
Voltage: 230/240 Volts AC 50Hz
Wattage: 5.3/5.8kW
Height: 897mm
Width: 592mm
Depth: 563mm
(excluding handles and knobs)
Weight: 53kg
This appliance complies with: European Council Directive 73/23/EEC.
EMC Directive 89/336/EEC.
CE Marking Directive 93/68/EEC.
2
Page 3
`
CONTENTS
Please follow these instructions step by step to install and operate your oven safely and easily
Technical Details
Contents
Safety
Installation Instructions ................................................................7
Getting Things Ready
Making the Electrical Connections
...............................................................................
...................................................................................
Before Installation .................................................................5
During Operation ................................................................. 5
After Use ......................................................................... 6
General ..........................................................................6
Things You Need to Know
Warnings ......................................................................... 7
Things to Note ....................................................................7
Choice of Electrical Connection
Preparing Cabinet for Fitting Oven ................................................. 7
Recommended Cabinet Dimensions ............................................... 8
How to Finish Unpacking .......................................................... 9
Tools Required ................................................................... 9
Preparing Cable
To Remove Cover of Mains Terminal ..............................................9
Connecting to the Mains Terminal ................................................10
Connecting to a Hob or Cooker Point .............................................10
Checking Electrical Connections ..................................................10
.......................................................................
.........................................................
..................................................................
....................................................
.....................................................
..................................................................
.
2
3
5
7
7
7
9
9
Fitting Into The Cabinet
Introduction
Getting to Know Your Oven ......................................................12
Rating Plate
General Notes on Using The Ovens ..............................................13
When First Switching On .........................................................13
About Condensation and Steam ..................................................13
Cookware .......................................................................13
The Shelf Positions ..............................................................13
The Cooling Fan for the Controls .................................................14
Control Panel Indicator Neons ....................................................14
Grill and Oven Furniture ..........................................................14
The Dual Grill
Uses of the Dual Grill ............................................................15
Selecting the Dual Grill ...........................................................15
Things to Note ...................................................................15
The Grill Pan and Handle .........................................................16
Hints and Tips ...................................................................16
Grilling Chart ....................................................................17
The Top Oven .........................................................................18
Uses of the Top Oven ............................................................18
Selecting the Top Oven ..........................................................18
Things To Note ..................................................................18
To Fit the Top Oven Shelf ........................................................18
Hints and Tips ...................................................................19
Top Oven Cooking Chart .........................................................19
...........................................................................
..........................................................................
...............................................................
.....................................................................
11
12
13
15
3
Page 4
CONTENTS
The Main Fan Oven ....................................................................20
Uses of the Fan Oven ............................................................20
Selecting the Fan Oven ..........................................................20
Things to Note ...................................................................20
To Fit the Main Oven Shelves ....................................................20
Hints and Tips ...................................................................21
Defrost Feature ........................................................................22
Uses of Defrost Feature ..........................................................22
Selecting Defrost ................................................................22
Hints and Tips ...................................................................22
The Conventional Oven ...............................................................23
Uses of the Conventional Oven ...................................................23
Selecting the Conventional Oven .................................................23
Things to Note ...................................................................23
Hints and Tips ...................................................................24
The Zoned Oven .......................................................................25
Uses of the Zoned Oven .........................................................25
Selecting the Zoned Oven ........................................................25
Things to Note ...................................................................25
Hints and Tips ...................................................................26
Oven Cooking Chart ...................................................................27
Thermal Grilling .......................................................................28
Uses of Thermal Grilling ..........................................................28
Selecting Thermal Grilling ........................................................28
Things to Note ...................................................................28
Hints and Tips ...................................................................29
Thermal Grilling Chart ............................................................30
Oven Clean Feature
Uses of Oven Clean Feature .....................................................31
Selecting Oven Clean ............................................................31
Things to Note ...................................................................31
Hints and Tips ...................................................................31
The Electronic Timer ..................................................................32
Helpful Hints when Buying and Preparing Food ......................................34
Care and Cleaning .....................................................................35
Cleaning Materials ...............................................................35
Cleaning the Outside of the Appliance ............................................35
Cleaning Inside the Ovens .......................................................35
Cleaning the Meat Tin, Grill Pan, Grill Pan Grid and Oven Shelves .................35
Cleaning Between the Outer and Inner Door Glass ................................36
Care of Stayclean Surfaces ......................................................37
Hints and Tips ...................................................................37
Replacing an Oven Light Bulb ....................................................37
...................................................................
31
Something Not Working? .............................................................38
Service and Spare Parts
Customer Service Centres ............................................................40
Guarantee Conditions .................................................................42
...............................................................
39
4
Page 5
SAFETY
THESE WARNINGS ARE PROVIDED IN
THE INTERESTS OF YOUR SAFETY.
ENSURE THAT YOU UNDERSTAND THEM
ALL BEFORE INSTALLING OR USING
THE APPLIANCE.
PLEASE
READ
CAREFULLY
BEFORE INSTALLATION
This appliance is heavy and care
must be taken when moving it.
Ensure that all packaging, both
inside and outside the appliance has
been removed before the appliance is
used.
DURING OPERATION
Do not use this appliance if it is in contact
with water. Never operate it with wet
hands.
This appliance is designed to be operated
by adults. Young children must not be
allowed to tamper with the controls or play
near or with the appliance.
During use the appliance becomes Hot.
Care should be taken to avoid touching
heating elements inside the oven.
Caution accessible parts especially
around the grill area may become hot
when the appliance is in use. Children
should be kept away until it has cooled.
lift
Do Not try to
appliance by pulling the door handles.
Refer to installation instructions.
The appliance must be installed
according to the instructions supplied.
Any electrical installation work must
be undertaken by a qualified
electrician/competent person.
It is dangerous to alter the
specifications or modify the
appliance in any way.
Do not allow young children to play
with any part of the packaging.
After installation, please dispose of
the packaging with due regard to the
environment, your local authority can
arrange this.
or move the
Take great care when heating fats and
oils as they will ignite if they become too
hot.
This appliance has been designed for
cooking edible foodstuffs only, and must
not be used for any other purposes.
Never place plastic or any other material
which may melt in or on the oven.
Ensure cooking utensils are large enough
to contain foods to prevent spillages and
boil overs.
Take care to follow the recommendations
given for tending the food when grilling.
Use the handle provided in the
recommended way (see page 16).
Always use oven gloves to remove and
replace food in the oven.
5
Page 6
Ensure that you support the grill pan
when it is in the withdrawn or partially
withdrawn position.
Ensure that all vents are left
unobstructed to ensure ventilation of
the oven cavity.
You must ensure that the grill control
is in the 'OFF' position when the timer
control has been set for automatic
cooking.
Ensure that the anti-tilt shelves are
put in place correctly. Refer to
instructions on pages 18 and 20.
Never line any part of the appliance
with aluminium foil. Do not allow
heatproof cooking material, e.g.
roasting bags to come into contact
with oven elements.
Always stand back from the
appliance when opening the oven
door to allow any build up of steam or
heat to release.
Do not leave utensils containing foodstuffs,
e.g. fat or oil in or on the appliance in case
it is inadvertently switched ON.
Cookers and hobs become very hot, and
retain their heat for a long period of time
after use. Children should be kept well
away from the appliance until it has
cooled.
GENERAL
Under no circumstances should repairs
be carried out by inexperienced persons as
this may cause injury or serious
malfunction.
This appliance should be serviced by an
authorised Service Engineer and only
genuine approved spare parts should be
used. Details of servicing and repair
arrangements are supplied on page 39 of
this book.
Do not stand on the appliance or on the
open oven door.
AFTER USE
Stand clear when opening the drop
down oven door. Do not allow it to
fall open - support it using the door
handle until it is fully open.
Never leave the appliance
unattended when the oven doors
are open.
Do not place sealed cans or aerosols
inside the oven. They may explode if
they are heated.
Ensure that all control knobs are in
the OFF position when not in use.
For hygiene and safety reasons
this appliance should be kept
clean at all times. A build-up of
fats or other foodstuffs could
result in a fire, especially in the
grill pan.
Do not hang towels, dishcloths or clothes
from the appliance or its handle. They are
a safety hazard.
Always allow the cooling fan to cool the
appliance down before switching off at the
wall prior to carrying out any cleaning or
maintenance work.
Only clean this appliance in accordance
with the instructions given on page 35.
Your safety is of paramount importance.
Therefore, if you are unsure about any of
the meanings of these WARNINGS
contact the:
Customer Care Department
Telephone: 0870 5 950950
6
Page 7
INSTALLATION INSTRUCTIONS
THINGS YOU NEED TO KNOW
WARNINGS:
l
This appliance must be installed by a qualified
electrician/competent person. Safety may be
impaired if installation is not carried out in
accordance with these instructions.
l
This appliance must be earthed.
l
Do not remove the screws from the earth tab
extending from the oven mains terminal block
(Fig. 6).
l
Before connecting the appliance make sure that
the voltage of your electricity supply is the same
as that indicated on the rating plate. This is
situated on the lower front frame of the appliance
upon opening the main cavity door. Alternatively
the rating plate may also be found on the back or
top of some models (where applicable).
l
Do not alter the electrical circuitry of this
appliance.
THINGS TO NOTE
l
This appliance is designed to be fitted in cabinets
of the recommended dimensions as shown in Fig.
2. If your cabinet interior dimension is between
565-570mm the oven may still be fitted. However
a minor modification to the cabinet will be
required.
GETTING THINGS READY
CHOICE OF ELECTRICAL CONNECTION
l
There are three possible ways to connect your
appliance. In each case the appliance should be
operated using at least 6mm² twin core and earth PVC
insulated multicore cable. Please choose from the
most appropriate after reading the descriptions:
a) By connecting the appliance to a cooker point having a
double pole isolating switch with at least 3mm contact
separation in all poles and neutral, and protected with
a fuse or miniature circuit breaker at your mains fuse
box.
Subject to Regional Electricity Company
regulations if you wish to connect the oven
and hob to the power supply you may use one
of the following two methods:-
b) By connecting the appliance together with a hob box
directly to a cooker point(s). Having a double pole
isolating switch with at least 3mm contact separation in
all poles and neutral.
c) If you wish to connect an oven and a hob to a cooker
point you can by connecting the oven and hob
separately to the cooker point. Oven and hob units
should be separately connected to a control panel. See
Fig. 1.
l
The dimensions given provide adequate air
circulation around the unit within the cabinet,
ensuring compliance with BS EN60-335.
l
Enquiries regarding the installation of the cooker
point if required should be made to your Regional
Electricity Company to ensure compliance with
their regulations.
l
The cooker point should be within 2m of the
appliance to make it accessible to switch off the
appliance in case of an emergency.
l
To protect the hands wear gloves when lifting the
oven into its housing.
NOTE: HOUSE CIRCUIT
Earth leakage and continuity tests must be carried out
before the appliance is connected to the mains supply
and re-checked after fitting.
Fig. 1
NOTE: It is good practice to:
l
Fit an Earth Leakage Circuit Breaker to your house
wiring.
l
Wire your appliance to the latest IEE regulations.
PREPARING CABINET FOR FITTING OVEN
l
Make sure the cabinet is the correct size for the
appliance to be fitted (Ref. Fig. 2).
l
If the size is between 565-570*mm, then the cabinet
should be modified so that at the screw fixing points
the recommended dimension of at least 560-565mm is
maintained. The modification should ideally be
localised to ensure that after screw fitment the oven is
securely fixed into position.
l
The cabinet must be stable and level by firmly securing
it to the wall or floor. If necessary, make arrangements
to ensure the shelf upon which the oven will rest is
level
l
When the appliance is installed ensure a minimum gap
of 2mm is maintained between the trim on the
bottomedge of the appliance and any corresponding
door/ panel underneath.
7
Page 8
RECOMMENDED CABINET DIMENSIONS (IN MILLIMETRES)
6
0
0
m
i
n
5
6
0
m
i
n
5
7
0
m
a
5
5
8
8
7
2
907 min
See
Below
x
n
i
m
0
5
5
d
e
d
n
e
m
m
o
c
e
R
0
0
0
2
300 min
5
6
1
Cross section
through
cabinet
showing oven
positioned
897
872
9
7
8
-
4
7
8
9
5
Fig.2 Built In Installation
542
8
Page 9
HOW TO FINISH UNPACKING
TO REMOVE COVER OF MAINS TERMINAL
l
Place packed appliance next to the cabinet in
which it will be installed.
l
Remove the appliance packing except for bottom
tray which should be left in position until the
appliance is ready to be fitted into its cabinet.
NOTE: It is imperative that the appliance is left
in the base to protect both the appliance and the
floor.
l
Ensure the owner is given these operating
instructions.
TOOLS REQUIRED
The following tools will be needed and its helps to
assemble them before starting to install your oven:
A terminal screwdriver (3mm wide blade)
A pozidrive screwdriver
Pliers
Wirestrippers
Knife
Sidecutters
Adhesive Tape
Tape Measure
From the rear of the appliance, remove mains input
terminal cover to gain access to terminal block.
l
First remove retaining screw with pozidrive
screwdriver. See Fig. 3.
Fig.3
l
Prise cover loose using screwdriver in position
(1) then lever off with screwdriver in position (2)
at either side. See Fig. 4.
MAKING THE ELECTRICAL CONNECTIONS
Important: Switch off at mains, miniature
circuit breaker and, if appropriate, remove
fuse before commencing any electrical work.
PREPARING CABLE
We recommend you use a new length of cable to
ensure your safety.
l
Ensure you have the correct length of cable
appropriate to the wiring method you are using.
When fitting new cable allow sufficient cable for
removal of the unit at a later date, should it be
necessary.
l
Score, but do not cut through, around the
sheathing with a knife 100mm (4in) from each
end of the cable and break through to the
encased wires by bending the cable backwards
and forwards to fatigue the sheathing.
l
Carefully score down from each end of the cable
sheathing along the length of the bare earth wire
(if a cut was made along the length of the live
and neutral wires, it might cut into their
sheathing) to the cuts already made.
Fig.4
l
Lift cover and remove screw from cable clamp.
See Fig. 5.
Fig.5
l
Carefully prise open the sheathing at each end of
the cable to expose the encased wiring.
9
Page 10
CONNECTING TO THE MAINS TERMINAL
NOTE: HOUSE CIRCUIT
Warning: This appliance must be earthed.
l
Make connection as shown in Fig. 6 by
proceeding as follows:-
Fig.6
l
Preform wires to the appropriate shape to suit
fitting into the mains terminal block.
l
Strip inner insulation on wires using wirestrippers.
l
Twist the bared wires using pliers.
l
Cut bared wires 10mm away from the end of the
inner insulation. Where uninsulated Earth wires
are used ensure they are suitably sheathed to
leave 10mm bare wire to fit into the terminal.
Earth leakage and continuity tests must be carried
out before the appliance is connected to the mains
supply and re-checked after fitting.
l
Clamp bare wires into the relevant terminal and
check they are held by tugging each one in turn.
l
Clamp the mains cable securely ensuring 5mm of
the outer insulation is inside the terminal block
and that the wires are not taught but not so slack
as to cause any fouling. See Fig. 6.
l
Place fuse/ miniature circuit breaker in circuit and
switch on at mains.
CONNECTING TO A HOB OR COOKER POINT
Warning: This appliance must be earthed.
l
Either follow in general terms the instructions for
connecting to the terminal block or refer to the
hob suppliers installation instructions.
Feed the cable through the cabinet and
arrange to route the cable away from the
appliance which may become hot.
CHECKING ELECTRICAL CONNECTIONS
l
Confirm the appliance is correctly connected by
switching on and observing the various oven
functions indicators.
l
The electronic timer will flash on and off.
10
Page 11
FITTING INTO THE CABINET
IMPORTANT: Ensure that the oven is switched
off at the wall before any further work is carried
out.
l
Using a tape measure establish the internal width
of the cabinet. Refer to page 7 if greater than
565mm.
l
Position the appliance in front of the cabinet. See
Fig. 7.
l
Take out all oven furniture before installation to
reduce the weight you need to lift. The oven door
should be taped up to keep it closed whilst lifting.
l
To place the appliance into the cabinetry follow
the procedure below:
l
N.B. Two people will be required to carry out
the lifting procedure.
a) Each person should squat either side of the
appliance.
Fig.7
b) Tilt the appliance so that your hands can support
the underside of the appliance.
Warning: Do Not attempt to lift this
appliance by the handles.
c) Keeping your back straight, raise the appliance to
the cabinet by straightening at the knees.
d) Rest the rear underside of the appliance on the
cabinet floor while your hands support the front.
e) The appliance can be pushed fully into the
cabinet. Take care to avoid damaging the mains
lead.
f) Ensure the appliance is central in the cabinet and
level.
g) Do not remove spacers fitted behind fixing holes.
h) When the appliance is fully housed, screw the
stability screws (supplied with the appliance) into
the side of the cabinet taking care not to distort
the side trims (see Fig. 8). It is advisable to turn
each screw alternately to avoid damaging the
trims.
Fig.8
i) Switch on the appliance then refer to the
operating instructions in the following pages.
11
Page 12
INTRODUCTION
WARNING: THIS APPLIANCE MUST BE EARTHED
GETTING TO KNOW YOUR OVEN
A G B C D E F
A - Main Oven Temperature Control
B - Main Oven Indicator Neon
C - Multifunction Selector
Fan Oven
Conventional Oven
Zoned Oven
Defrost
Oven Clean
Thermal Grilling
Oven Light
D - Electronic Timer
E - Top Oven Temperature Control
F - Top Oven Indicator Neon
G - Dual Grill Control
12
Page 13
INTRODUCTION
RATING PLATE
This is situated on the lower front frame of the
appliance upon opening the main cavity door.
Alternatively the rating plate may also be found on
the back or top of some models (where applicable).
The appliance must be protected by a suitably rated
fuse or circuit breaker. The rating of the appliance is
given on the rating plate.
Do not remove the rating plate from the
appliance as this may invalidate the guarantee.
We suggest that you run all the elements for a short
period to burn off any residue from their surfaces.
To do this, run the ovens at 220°C for approximately
45 minutes. The procedure should be repeated with
the grill for approximately 5 - 10 minutes.
During this period an unpleasant odour may be
emitted, it is therefore advisable to open a window
for ventilation.
GENERAL NOTES ON USING THE OVENS
COOKWARE
Baking trays, oven dishes etc., should not be placed
directly against the grid covering the fan at the back
of the oven.
Do not use baking trays larger than 30cm x 35cm
(12" x 14") as they will restrict the circulation of heat
and may affect performance. Advice on the effect of
different materials and finishes of bakeware is given
in 'Hints and Tips' in the appropriate oven section.
THE SHELF POSITIONS
Recommended shelf positions have been shown in
the cooking chart on page 27.
If not fitted correctly the shelf will lie at an angle and
the safety stop will not be effective. To ensure that
the shelf has the correct side uppermost, the wire
stringers which make up the shelf should lie on top of
the surrounding frame.
WHEN FIRST SWITCHING ON
The timer must be set to manual before the ovens
can be operated. See page 32. This must be done
whenever the appliance is switched off at the wall or
when there has been a power failure.
If the oven indicator neons do not glow when the
controls are switched on, it is most likely that the
timer is set for automatic cooking.
ABOUT CONDENSATION AND STEAM
When food is heated it produces steam in the same
way as a boiling kettle does. The oven is vented to
allow some of this steam to escape. However,
always stand back from the appliance when opening
the oven door to allow any build up of steam or heat
to release.
If the steam comes into contact with a cool surface
on the outside of the appliance, e.g. a trim, it will
condense and produce water droplets. This is quite
normal and is not caused by a fault on the appliance.
To prevent discolouration, regularly wipe away
condensation and also soilage from surfaces.
13
Page 14
THE COOLING FAN FOR THE
CONTROLS
The cooling fan comes on immediately when the grill
is switched on and after a short time when either of
the ovens are in use and switches off when cooking
is completed.
During the initial period the cooling fan may turn ON
and OFF, this is quite normal.
1 grill pan handle
(311468100)
NOTE
If you require an additional handle for your grill pan,
this can be ordered from your local Service Force
Centre by quoting part number 311479800\6.
It may run on after the ovens or grill are switched off
to keep the controls cool.
Always allow the cooling fan to cool the appliance
down before switching off at the wall prior to carrying
out any cleaning or maintenance work.
NOTE
The action of the cooling fan will depend on how long
the oven(s) or grill have been used and at what
temperature. It may not switch in at all at lower
temperature settings nor run on where the grill or
oven has only been used for a short time.
CONTROL PANEL INDICATOR NEONS
These lights indicate whether the ovens are switched
ON. The neons also indicate when the set
temperature has been reached. They will turn on and
off during use to show that the temperature is being
maintained.
If the neons do not operate as the instructions
indicate the controls have been incorrectly set.
Return all controls to zero and re-set following the
instructions for the required setting.
1 grill pan grid
(311419801)
1grill deflector
1 meat tin
(311409401)
2 straight shelves
When the oven has been set for automatic cooking
the neon should remain unlit during OFF periods.
GRILL AND OVEN FURNITURE
The following items of oven furniture have been
supplied with the appliance. If you require
repalcements of any of the items listed below, please
contact your local Service Force Centre quoting the
relevant part number.
1 grill pan
(311409401)
1 cranked shelf for
grilling and top oven
cooking only
The grill deflector sits above the grill element and
prevents fat splashing onto the top oven roof.
The deflector may be easily removed for cleaning.
14
Page 15
THE GRILL
USES OF THE DUAL GRILL
CAUTION - ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD
BE KEPT AWAY.
The grill is a dual circuit grill which means that the full area of the grill can be used or for economy purposes the
centre section only can be used when cooking smaller quantities of food.
SELECTING THE DUAL GRILL
l
Turn the grill control clockwise for full grill or
anticlockwise for the centre section only.
l
Ensure the top oven control is in the OFF
position 'O'.
l
The dual grill operates independently of the oven.
THINGS TO NOTE
THE GRILL DOOR MUST BE LEFT OPEN DURING
GRILLING
1. The cooling fan for the controls will operate
immediately in conjunction with the grill.
2. The outer grill element may appear to glow
slightly brighter than the inner element. This is
quite normal.
NOTE
Do not leave food unattended when grilling.
15
Page 16
THE GRILL PAN AND HANDLE
The grill pan is supplied with a removable handle.
To attach the handle, place the wirework under the
cut out in the pan so that the metal plate hooks over
the top of the grill pan.
Slide the handle to the left and over the central bump
on the grill pan.
Ensure the handle is correctly located. It is not
necessary to remove the grill pan handle during
grilling.
HINTS AND TIPS
l
In order to become acquainted with the
performance of the Dual Grill it is advisable to
check food regularly when grilling.
l
Food should be thoroughly dried before grilling to
minimise splashing. Brush lean meats and fish
lightly with a little oil or melted butter to keep
them moist during cooking.
l
Adjust the height of the grilling grid and grill pan
runner position to allow for different foods.
l
Most food should be placed on the grill pan grid
in the 'high' position in the grill pan to allow
maximum circulation of air around the food.
l
Accompaniments such as tomatoes and
mushrooms may be placed underneath the grid
when grilling meats.
To remove the handle, slide the handle to the right
and lift the handle away from the cut out on the grill
pan.
Place the grill pan on the shelf so that the pan is
positioned centrally beneath the grill.
l
When toasting bread use the cranked shelf in
position 2 with the grid in the high position.
l
Preheat the grill on a full setting for a few
minutes before sealing steaks or toasting. Adjust
the heat setting and the shelf as necessary
during cooking.
l
The food should be turned over during cooking
as required.
l
When using the centre section of the dual grill,
ensure food is positioned centrally on the grill pan
grid in the grill pan.
NOTE
If you require an additional handle for your grill pan,
this can be ordered from your local Service Force
Centre by quoting part number 311479800\6.
16
Page 17
GRILLING CHART
FOOD SHELF GRILL TIME
Bacon Rashers
2 crk.
(mins)
2-3 each side
Beefburgers
Chicken Joints
Chops - Lamb
Pork
Fish - Whole
Trout/Mackerel
Fillets - Plaice/Cod
Kebabs
Kidneys - Lamb/Pig
Liver - Lamb/Pig
Sausages
Steaks - Rare
Medium
Well Done
Toasted Sandwiches
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
6-10 each side
15-20 each side
7-10 each side
10-15 each side
8-12 each side
4-6 each side
10-15 each side
4-6 each side
5-10 each side
10-15 each side
3-6 each side
6-8 each side
7-10 each side
1¼-1½ each side
crk. = cranked shelf
Shelf positions are counted from the bottom
upwards.
The times quoted above are given as a guide and
should be adjusted to suit personal taste.
17
Page 18
THE TOP OVEN
USES OF THE TOP OVEN
The top oven is the smaller of the two ovens. It is
heated by elements in the top and bottom of the
oven. It is designed for cooking smaller quantities of
food. It gives especially good results if used to cook
fruit cakes, sweet and savoury flans or quiche.
SELECTING THE TOP OVEN
l
Ensure the grill control is in the off 'O' position .
The top oven is also ideal for use as a warming
compartment to warm dishes and keep food hot.
Use a temperature setting of 90° - 100°C on the top
oven temperature control.
TO FIT THE TOP OVEN SHELF
l
Turn the top oven temperature control to the
required setting.
THINGS TO NOTE
1. The top oven light will come on.
2. The top oven neon will glow until the oven has
reached the desired temperature and then go
out. It will turn ON and OFF periodically during
cooking showing that the temperature is being
maintained.
3. The controls cooling fan will operate after a time.
See page 14 for more information on the cooling
fan.
4. The top oven works independently of the main
oven and is not controlled by the selector.
5. Dishes, tins and trays should not be placed
directly on oven floor as it becomes very hot
and damage will occur.
The shelf should be fitted with the straight rods
uppermost on the frame and the forms towards the
back of the oven. If not fitted correctly the anti-tilt and
safety stop mechanism will be affected.
18
Page 19
HINTS AND TIPS
l
There should always be at least 2.5cm (1")
between the top of the food and the element.
This gives best cooking results and allows room
for rise in yeast mixtures, Yorkshire puddings etc.
When cooking cakes, pastry, scones bread etc.,
place the tins or baking trays centrally below the
element.
l
Ensure that food is placed centrally on the shelf
and there is sufficient room around the baking
tray/dish to allow for maximum circulation.
TOP OVEN COOKING CHART
FOOD Shelf
Position
Biscuits
Bread
Casseroles
Cakes:
Small/queen
Sponges
Madeira
Rich Fruit
Christmas
Meringues
2crk.
1crk.*
1crk.*
2 crk.
2crk.
1crk.
1crk.
1crk.
1crk.
Cooking
Temp°C
180-190
210-220
130-140
180-190
160-170
140-150
130-140
130-140
90-100
l
Stand dishes on a suitably sized baking tray on
the shelf to prevent spillage onto the oven base
and to help reduce cleaning.
l
The material and finish of the baking tray and
dishes will affect the degree of base browning of
the food. Enamelware, dark, heavy or non-stick
utensils increase base browning. Shiny
aluminium or polishes steel trays reflect the heat
away and give less base browning.
l
DO NOT place dishes or baking trays directly
onto the oven base as it becomes very hot and
damage may occur.
l
DO NOT use the grill pan or meat tin as a baking
tray as this will increase base browning of the
food.
l
Because of the smaller cooking space and lower
temperatures shorter cooking times are
sometimes required. Be guided by the
recommendations below.
Fish
Fruit Pies & Crumble
Milk Puddings
Pastry: Choux
- Shortcrust
- Flaky
- Puff
Plate Tarts
Quiches/Flans
Scones
Roasting:
Meat & Poultry
crk. = Cranked shelf
* or on a straight shelf from the main oven on the
base.
Shelf positions are counted from the bottom of the
oven upwards.
1crk.
1crk.
1crk.
1crk.
Depending
on dish
2crk.
1crk.
2crk.
1crk.*
170-190
190-200
140-150
160-170
190
180
210-220
170-180
l
For economy leave the door open for the
shortest possible time, particularly when placing
food into a pre-heated oven.
19
Page 20
THE MAIN FAN OVEN
USES OF THE FAN OVEN
The oven is heated by an element around the fan situated behind the back panel. The fan draws air from the oven
and the element heats the air which is circulated into the oven via the vents in the back panel. The advantages of
fan oven cooking are:
PREHEATING
The fan oven quickly reaches its temperature, so it is not usually necessary to preheat the oven. Without
preheating however, you may find you need to add an extra 5-10 minutes on the recommended cooking times. For
recipes needing high temperatures, e.g. bread, pastries, scones, soufflés, etc., best results are achieved if the oven
is preheated first. For best results when cooking frozen or cooked chilled ready meals always preheat the oven
first.
COOKING TEMPERATURES
Fan oven cooking generally requires lower temperatures than conventional cooking. Follow the temperatures
recommended in the chart on page 27. As a guide reduce temperatures by about 20°C-25°C for your own recipes.
BATCH BAKING
The fan oven cooks evenly on all shelf levels, especially useful when batch baking.
SELECTING THE FAN OVEN
l
Turn the Function selector to Fan Oven .
l
Turn the main oven temperature control to the
required setting.
THINGS TO NOTE
1. The oven fan will operate continually during
cooking.
2. The oven indicator neon will glow until the oven
has reached the desired temperature. It will turn
ON and OFF periodically during cooking showing
that the temperature is being maintained.
3. The oven light operates when the selector is set.
4. The cooling fan for the controls will operate after
a time. See page 14 for further details on the
operation of the cooling fan.
5. If an automatic programme is set, the oven fan
and oven light do not come on until the cook time
begins.
TO FIT THE MAIN OVEN SHELVES
The shelves should be fitted with the straight rods
uppermost on the frame and the forms towards the
back of the oven. If not fitted correctly the anti-tilt and
safety stop mechanism will be affected.
20
Page 21
HINTS AND TIPS
l
Arrange the shelves in the required positions
before switching the oven ON. Shelves are
numbered from the bottom upwards.
l
When cooking more than one dish in the fan
oven, place dishes centrally on different shelves
rather than cluster several dishes on one shelf,
this will allow the heat to circulate freely for the
best cooking results.
l
When batch baking one type of food, e.g. Victoria
sandwich cakes, those of similar size will be
cooked in the same time.
l
Do not place dishes or baking trays directly on
the oven floor as it interferes with the oven air
circulation and can lead to base burning; use the
lower shelf position. However non critical dishes
can be placed on the oven base when more
space is required.
l
The use of excessively high temperatures can
cause uneven browning. It may be necessary to
reduce temperatures slightly. Refer to the
recommendations given in the oven cooking
chart, see page 27.
l
It is recommended that when baking larger
quantities, the shelf positions should be evenly
spaced to suit the load being cooked. A slight
increase in cooking time may be necessary.
21
Page 22
DEFROST FEATURE
USES OF DEFROST FEATURE
This function enables you to defrost most foods
faster than some conventional methods as the oven
fan circulates air around the food. It is particularly
suitable for delicate frozen foods which are to be
served cold e.g. cream filled gateaux, cakes covered
with icings or frostings, cheesecakes, biscuits,
scones etc.
It is preferable to thaw fish, meat and poultry slowly
in the fridge. However, this process can be
accelerated by using the defrost function.
SELECTING DEFROST
Small or thin fish fillets, frozen peeled prawns, cubed
or minced meat, liver, thin chops, steaks etc., can be
thawed in 1 - 2 hours.
A 1kg/2¼lb oven ready chicken will be thawed in
approximately 5 hours. Remove the giblets as soon
as possible during the thawing process.
Joints of meat up to 2kg/4½lb in weight can be
thawed using the defrost function.
ALL JOINTS OF MEAT AND POULTRY MUST BE
THAWED THOROUGHLY BEFORE COOKING.
ALWAYS COOK THOROUGHLY IMMEDIATELY
AFTER THAWING.
l
Turn the Function selector to Defrost .
l
This function DOES NOT require a temperature
setting on the main oven temperature control.
l
The oven fan and internal oven light will operate.
HINTS AND TIPS
l
Place the frozen food in a single layer where
possible and turn it over half way through the
defrosting process.
22
l
The actual speed of defrosting is influenced by
room temperature. On warm days defrosting will
be faster than on cooler days.
l
DO NOT leave food at room temperature once it
is defrosted. Cook raw food immediately or store
cooked food in the fridge, once it has cooled.
l
Care must always be taken when handling foods
in the home. Always follow the basic rules of food
hygiene to prevent bacterial growth and cross
contamination when defrosting, preparing,
cooking cooling and freezing foods. See Helpful
Hints on Buying and Preparing Food on page 34.
Page 23
THE CONVENTIONAL OVEN
USES OF THE CONVENTIONAL OVEN
This function uses the top and lower elements to give single level cooking. This is particularly suitable for dishes
which require extra base browning such as pizzas, quiches and flans. Gratins, lasagnes and hotpots which require
extra top browning also cook well in the conventional oven. This form of cooking gives you the opportunity to cook
without the fan oven in operation.
SELECTING THE CONVENTIONAL OVEN
l
Turn the Function selector to Conventional
Oven.
l
Turn the main oven temperature control to the
required setting.
THINGS TO NOTE
1. The oven indicator neon will glow until the oven
has reached the desired temperature and then
go OUT. It will then turn ON and OFF showing
that the oven temperature is being maintained.
2. The internal oven light operates when the
selector is set. If an automatic programme is set,
the oven light will come on when the cook time
starts.
3. The control cooling fan will operate after a short
time and runs on after the controls are switched
off until the appliance has cooled. See page 14
for more details on the cooling fan.
23
Page 24
HINTS AND TIPS
l
The middle shelf allows for the best heat
distribution. To increase base browning simply
lower the shelf position. To increase top
browning, raise the shelf position.
l
The material and finish of the baking trays and
dishes used will affect base browning.
Enamelware, dark heavy or non-stick utensils
increase base browning, while oven glassware,
shiny aluminium or polished steel trays reflect the
heat away and give less base browning.
l
For faster preheating use the fan oven function to
preheat the oven until the oven indicator neon
goes out, then switch the selector to the
conventional oven setting.
l
Single level cooking gives best results. If you
require more than oven level cooking use the fan
or zoned oven functions.
l
Always place dishes centrally on the shelf to
ensure even browning.
l
Stand dishes on suitably sized baking trays to
prevent spillage onto the base of the oven and
make cleaning easier.
l
Dishes, tins and trays should not be placed
directly on oven floor as it becomes very hot
and damage will occur.
24
Page 25
THE ZONED OVEN
USES OF THE ZONED OVEN
When the Zoned Oven is selected the element at the top of the oven operates in conjunction with the fan with effect
that the top of the oven is hotter than the bottom. As there is a difference of up to 30°C between the top and bottom
of the oven this feature is especially useful for dishes requiring different temperatures at the same time, making it
ideal for cooking a complete meal on two shelves.
SELECTING THE ZONED OVEN
l
Turn the Function selector to Zoned Oven.
l
Turn the main oven temperature control to the
required setting.
THINGS TO NOTE
1. The internal oven light will operate.
If an automatic programme is set, the internal
oven light will come on when the cook time
starts.
2. The oven indicator neon will glow until the oven
has reached the desired temperature and then
go OUT. It will then turn ON and OFF showing
that the oven temperature is being maintained.
3. The control cooling fan will operate after a short
time. It runs on after the controls are switched off
until the appliance has cooled. See page 14 for
further details on the cooling fan.
25
Page 26
HINTS AND TIPS
l
Remember that the top of the oven is hotter than
the bottom. The approximate difference in
temperature between the top and the bottom is
30°C.
l
If a higher shelf position is used than is
recommended in the chart on page 27, it may be
necessary to lower the cooking temperature by
approximately 10°C.
l
Be prepared to interchange dishes between the
higher and lower shelf position during cooking
where necessary.
l
Ensure that food is placed centrally on the
shelves and that there is sufficient room around
the dishes to allow for maximum air circulation.
l
The use of enamelware or dark, heavy or nonstick utensils will help to increase base browning
for dishes such as Yorkshire Pudding, Plate Pies
etc.
l
For faster preheating use the fan oven function to
preheat the oven until the oven indicator neon
goes out, then switch to the zoned oven following
the times, temperatures and shelf positions
recommended.
l
It is best to cover dishes where practical for part
of the cooking time to prevent over browning.
Covering the food will also reduce fat splashing
onto the oven interior and help to keep the oven
clean. Uncover food for the last 15-30 minutes of
cooking time to allow the food to brown.
26
Page 27
OVEN COOKING CHART
The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the
temperatures by 10°C to suit individual preferences and requirements.
Note: Shelf positions are counted from the bottom of the oven.
Food
Biscuits
Bread
Casseroles
Cakes: Small & Queen
Sponges
Madeira
Rich Fruit
Christmas
Meringues
Fish
Fruit Pies and Crumbles
Milk Puddings
Pastry: Choux
Shortcrust
Flaky
Puff
Plate Tarts
Quiches/Flans
Scones
Roasting: Meat and Poultry
FAN OVEN ZONED OVEN CONVENTIONAL
Shelf
Position
Shelf
positions
are not
critical
but ensure
that oven
shelves are
evenly
spaced
when more
than one is
used
Cooking
Temp °C
180-190
210-220
130-140
160-170
160-170
140-150
130-140
130-140
90-100
170-190
190-200
130-140
190-200
180-190
170-180
210-220
160-180
Shelf
Position
1/3
2
3
1/3
1/3
2
1
1/3
1/3
3
3
3
1/3
1/3
3
1/3
2
Cooking
Temp °C
160-170
200-210
160-170
160-170
160-170
140-150
130-140
-
90-100
160-180
190-200
130-140
160
170-180
170-180
170-180
210-220
160-180
Shelf
Position
2
2
2
2
2
2
2
1
2
2
3
3
2
3
2
2
3
2
OVEN
Cooking
Temp °C
180-190
210-220
150-180
170-180
170-180
160-170
150-160
130-140
100-110
170-190
190-200
130-140
160-170
190-200
190-200
190-200
230
180-200
Do not use the cranked shelf from the grill/top oven in the main oven.
27
Page 28
THERMAL GRILLING
USES OF THERMAL GRILLING
Thermal grilling offers an alternative method of
cooking food items normally associated with
conventional grilling.
The grill element and the fan operate together,
circulating hot air around the food. The need to
check and turn food is reduced. Thermal grilling
helps to minimise cooking smells in the kitchen and
allows you to grill with the oven door closed. With the
exception of toast and rare steaks you can thermal
grill all the foods you would normally cook under a
conventional grill.
SELECTING THERMAL GRILLING
The lower part of the oven can be used to cook
accompaniments at the same time, e.g. tomatoes
and mushrooms with a mixed grill or breakfast.
Dishes prepared in advance such as shepherd's pie,
lasagne and au gratins can be heated through and
browned on the top using the thermal grilling
function.
l
Turn the Function selector to Thermal Grill.
l
Turn the main oven temperature control to the
required setting. (A temperature of between
140°C and 220°C is suitable for thermal grilling).
NOTE:
Thermal grilling helps to minimise cooking smells in
the kitchen and is carried out with the main oven
door closed.
THINGS TO NOTE
1. The oven indicator neon will glow until the oven
has reached the desired temperature and then
go OFF. It will turn ON and OFF showing that the
oven temperature is being maintained.
2. The oven fan and internal oven light will come
on.
3. The control cooling fan will operate after a short
time. It will run on after the controls are switched
off until the appliance has cooled. See page 14
for more details on the operation of the cooling
fan.
4. Always thermal grill with the door closed and with
the grill pan handle removed.
28
Page 29
HINTS AND TIPS
l
Prepare foods in the same way as for
conventional grilling. Brush lean meats and fish
lightly with a little oil or butter to keep them moist
during cooking.
l
Most food should be placed on the grill pan grid
in the 'high' position in the grill pan to allow
maximum circulation of air around the food.
l
Accompaniments such as tomatoes and
mushrooms may be placed below the grid when
grilling meats, or in a separate dish on a lower
shelf.
l
Turn food over during cooking as necessary.
l
Ensure that ready prepared or cooked chilled
dishes e.g. shepherds pie, moussaka, lasagne,
etc., are piping hot throughout before serving.
l
A temperature range of 140-220°C and shelf
positions 3 and 4 are suitable for most foods. Be
prepared to make suitable adjustments during
cooking to suit individual requirements. If thermal
grilling on more than one level, it may be
necessary to interchange the food on the shelves
during cooking.
l
Foods will cook more quickly the closer they are
to the grill element and the higher the
temperatures selected. Be prepared to adjust
temperatures and shelf positions during cooking
if necessary.
COOKING TIMES
Cooking is more gentle, therefore food generally
takes a little longer to cook when thermal grilling
compared with conventional grilling. One of the
advantages is that larger loads can be cooked at the
same time.
A general guide to cooking times is given on page 30
but these times may vary slightly depending on the
thickness and quantity of food being cooked.
29
Page 30
THERMAL GRILLING CHART
FOOD SHELF TEMP
Bacon Rashers
Beefburgers
Chicken Joints
Chops -Lamb/Pork
Fish -Whole
Trout/Mackerel
Fillets -Plaice/Cod
Kebabs
Kidneys -Lamb/Pig
Liver -Lamb/Pig
Sausages
Steaks -Medium
Steaks -Well Done
Heating through and
Browning, e.g. au-gratin,
lasagne, shepherd's pie.
TIME
(°C)
4
4
4
4
4
3
3
4
4
4
4
4
4
3
200
190
160
170
170
170
170
170
180
180
190
220
220
170
(mins in
total)
8-12
10-15
35-45
20-25
25-35
10-20
10-15
20-30
10-15
20-30
10-15
8-10
each
side
10-12
each
side
20-30
depends
on size
NOTE: Shelf positions are counted from the bottom of the oven.
The times quoted above are given as a guide and should be adjusted to suit personal taste.
30
Page 31
OVEN CLEAN FEATURE
USES OF OVEN CLEAN FEATURE
During normal use the Stayclean coating within the oven will become splashed with fats and food residues. When
the oven clean feature is selected the Stayclean surfaces burn off any soilage. See Care of Stayclean Surfaces on
page 37 for more details. Regular use of the oven clean function will keep the Stayclean panels in good condition.
SELECTING OVEN CLEAN
HINTS AND TIPS
ll
Remove oven shelves and bakeware from oven.
l
Turn the Function selector to oven clean.
l
Turn the main oven temperature control to 220°C.
THINGS TO NOTE
1. The oven indicator neon will glow until the oven has
reached the desired temperature and then go out. It
will then turn ON and OFF showing that the oven
temperature is being maintained.
2. The internal oven light operates when the selector is
set.
3. The control cooling fan will operate after a short
time when oven clean is selected. See page 14 for
more details on the operation of the cooling fan.
l
Manual cleaning of the Stayclean surfaces is NOT
recommended.
Damage will occur if soap impregnated steel
wool pads, aerosol cleaners or any abrasive
cleaners are used.
l
Slight discolouration and polishing of the Stayclean
surfaces may occur in time, but this will not affect
their self cleaning properties.
l
Use the oven clean function for an hour or two per
week to avoid a build up of soilage which could
prevent the Stayclean enamel from working
properly.
31
l
A good time to use the oven clean function is after
the weekly roast. Simply select oven clean function
as described above and allow the oven to run for an
hour or so.
l
Surfaces which are not Stayclean coated e.g. the
oven base, the oven exterior etc., will require
manual cleaning. Refer to the Care and Cleaning
Section on page 35 for details.
l
Useful hints and tips are given on page 37 on how
to keep soilage to a minimum.
Page 32
THE ELECTRONIC TIMER
Please note that this is a 24 hour clock, for example
2.00 pm is shown as 1400.
In the following pages we explain how to set the
controls. Read through them a few times until you are
familiar with the procedure.
If the oven is switched off on the wall, or there is a loss
of power, the clock will stop and you will not be able to
use the ovens. When you first switch the electricity
supply on, the timer display will flash.
TO SET THE TIME OF DAY
Turn the selector knob to 'Manual' then turn to 'Time
setting'.
Set the correct time by turning and holding the setting
knob clockwise. Adjust the time by turning the setting
knob in either direction.
Turn the selector knob back to 'Manual'.
Cookpot symbol Bell symbol
Selector
Setting knob
TO USE THE COUNTDOWN
Turn the selector knob to 'Countdown'. Turn the setting
knob clockwise until the display shows the time you
want. The bell symbol ( ) will be showing and this will
stay lit up during the time. Our diagram shows the timer
set to 5 minutes.
If you change your mind and want to cancel the time
you have set, simply turn the setting knob
anticlockwise. Then turn the selector to 'Manual'.
When you are using the 'Countdown' you can make the
clock show the time of day by turning the selector knob
to 'Manual'. The bell symbol will stay on to remind you
that the 'Countdown' is set. At the end of the timed
period an alarm will sound and the bell symbol will go
out.
Switch off the alarm by turning the selector knob to
'Time setting'. Then turn to 'Manual' and the time of day
will show in the display.
Note:
You can use the minute minder when an automatic
sequence has been set, as long as you remember the
following point.
1 Turn the selector knob to 'Automatic' as soon as
you have entered the timed period into the display.
32
Page 33
AUTOMATIC CONTROL
The automatic control can be used to control either
oven but you can only use the control for both ovens at
the same time if the cooking time is the same.
When you use the automatic controls for the first time
it's probably best to choose a time when you are at
home. That way you can check to make sure you've set
everything correctly and you'll feel much more confident
when you are away from home in the future.
SETTING THE CONTROLS FOR
AUTOMATIC USE
This is very easy. All you have to do is work through the
steps below. The clock will work out the rest for itself.
1 Is the electricity supply on?
2 Is the clock
showing the
correct time?
To adjust turn the selector knob
to 'Manual' then turn to 'Time
setting'. Turn the setting knob in
either direction.
3 How long will
the food take
to cook?
4 What time do
you want the
food to be
cooked by?
5 Set to
automatic.
6 Turn on the
oven control.
The time shown on the right gives an example of setting
the automatic controls when the time is 9.00 am, the
food is to be cooked for 2½ hours and the food is
needed at 6.00 pm (1800 hours).
The clock will work out what time the oven will switch
itself on and it will turn the oven off at the end. Once the
automatic sequence is finished there will be an alarm to
remind you that you need to set the oven for manual
operation. To do this turn the timer selector knob to
'manual'. Turn off the oven control.
If you change your mind and want to cancel a
programme that you have set simply turn to 'Time
setting' and then to 'manual'.
Turn the selector knob to 'Cook
time'. Then turn the setting knob
until the length of time you want
the food to cook shows in the
display. The maximum cooking
time is 10 hours. 'Auto' will show
in the display.
Turn the selector knob to 'End
time'. Turn the setting knob until
the time the oven is to switch off
shows in the display. The
cookpot ( ) will go out.
The 'End time' must not be more
than 23 hours 59 minutes from
the time of day. For example if
the time of day is 9.00 am the
latest 'End time' will be 8.59 am
the next day.
Turn the timer selector knob to
'Automatic'.
Turn the oven control to the
required setting and if using the
main oven select required
function.
33
Page 34
HELPFUL HINTS WHEN BUYING AND PREPARING FOOD
Care must be taken when handling foods in the home.
Always follow the basic rules of food hygiene to prevent
bacterial and microbial growth and cross contamination
when preparing, reheating, cooking, cooling, defrosting
and freezing foods.
1. Always ensure food you purchase is of good quality
and in prime condition. Shop at a reliable source
and buy the 'freshest' looking package - avoid shop
worn labels or produce covered in dust.
2. Avoid buying chilled or frozen products if you cannot
store them straight away. The use of an insulated
container when shopping is advisable.
3. Buy and consume foods prior to the 'Sell by' or 'Best
Before' date.
4. When you arrive home, place perishable foods in
the refrigerator or freezer immediately. Ensure they
are well covered to prevent them drying out and to
prevent any possible cross contamination with
bacteria from raw to cooked foods.
5. Follow the cooking instructions on packets of
prepacked and cooked chilled foods, but be
prepared adjust cooking times and temperatures to
suit your particular oven. For example, the Fan
Oven generally requires 20-25°C lower temperature
than Conventional Oven.
10. Cook meat thoroughly - use a meat thermometer if
preferred, which penetrates the joint to check that
the centre temperature has reached the required
temperature (see table below)
MEAT TEMPERATURES
Beef Rare - 60°C
Medium - 70°C
Well Done - 80°C
Pork Well Done - 80°C
Lamb Medium - 70°C
Well Done - 80°C
11. If not eaten straight away after cooking, food should
be cooled as quickly as possible (within one hour)
and then refrigerated or frozen as required. Do not
put hot food into a refrigerator or freezer.
12. In the kitchen keep worktops, chopping boards and
utensils clean with hot soapy water between
preparation stages. Ideally, keep one chopping
board for raw meat and another for other foods.
Keep your dish cloths and tea towels clean.
6. Always ensure that cooked chilled foods are
thoroughly reheated until they are piping hot
throughout.
7. It is preferable to defrost frozen foods slowly in the
refrigerator. Alternatively, a microwave oven or the
Defrost function on your oven may be used.
8. Always cook defrosted foods immediately after
thawing. Thawed food should never be refrozen.
9. Joints of meat and poultry should be thoroughly
defrosted before cooking.
34
Page 35
.
CARE AND CLEANING
BEFORE CLEANING THE APPLIANCE
ALWAYS ALLOW THE COOLING FAN TO
COOL THE APPLIANCE DOWN BEFORE
SWITCHING OFF THE ELECTRICITY
SUPPLY.
CLEANING MATERIALS
Before using any cleaning materials on your appliance,
check that they are suitable and that their use is
recommended by the manufacturer.
Cleaners that contain bleach should NOT be used as
they may dull the surface finishes. Harsh abrasives
should also be avoided.
CLEANING THE OUTSIDE OF THE
APPLIANCE
DO NOT use abrasive cleaning materials eg Hob Brite,
Brillo pads or scourers on painted or printed finishes as
damage may occur. Regularly wipe over the control
panel and oven doors using a soft cloth well wrung out
in warm water to which a little liquid detergent has been
added.
CLEANING INSIDE THE OVENS
The Stayclean surface inside the ovens should not be
cleaned manually. See page 37 "Care of Stayclean
Surfaces" and the Oven Clean Feature for the main
oven on page 31.
The vitreous enamel oven base can be cleaned using
normal oven cleaners or aerosol oven cleaners with
care. Ensure that the manufacturers instructions are
followed and that all parts are well rinsed afterwards.
Aerosol cleaners must not be used on Stayclean
surfaces and must not come into contact with
elements or the door seal as this may cause
damage.
DO NOT ATTEMPT TO REMOVE ANY OF THE
CONTROL KNOBS FROM THE PANEL AS THIS
MAY CAUSE DAMAGE AND IS A SAFETY HAZARD.
CLEANING THE GRILL DEFLECTOR, MEAT
TIN, GRILL PAN, GRILL PAN GRID AND
OVEN SHELVES
All parts, except the grill pan handle can be washed in
the dishwasher. Alternatively, soak them in hot soapy
water if they are heavily soiled. They will then clean
more easily.
The grill pan, meat tin and grill deflector may be cleaned
using a soap impregnated steel wool pad. The grill pan
grid and oven shelves should be cleaned using hot
soapy water. Soaking first in soapy water will make
cleaning easier.
CLEANING THE DOOR GLASS
To prevent damaging or weakening the
door glass panels avoid the use of the
following:
ll
Household detergents and bleaches
ll
Impregnated pads unsuitable for
non-stick saucepans
ll
Brillo/Ajax pads or steel wool pads
ll
Chemical oven pads or aerosols
ll
Rust removers
ll
Bath/Sink stain removers
Under no circumstances should the
door assembly be detached from the
product for cleaning. Please refer to the
cleaning instructions.
35
Page 36
CLEANING BETWEEN THE OUTER AND
INNER DOOR GLASS
Under no circumstances should the
door assembly be detached from the
product for cleaning. Please refer to the
cleaning instructions.
The outer door glass is removable for cleaning.
TO REMOVE THE OUTER GLASS
1. Open the oven door slightly to gain access to the
two cross head screws on the top of the oven door.
2. Loosen the two screws using a Pozidrive
screwdriver.
Grill Door Trim
TO REPLACE THE OUTER GLASS
1. Open the oven door with care and place in the park
position at an angle of approximately 30°.
2. Holding the oven glass with both hands, gently
place the locators into the holes of the brackets at
the bottom of the oven door.
3. Push the top of the oven glass towards the oven
door ensuring the screw location holes line up.
4. Ensure the trim is correctly positioned on the top
oven / grill door.
3. Hold the door glass securely with one hand, before
removing the screws completely with the other
hand.
The screws and washers retain the trim on the top
of the grill / top oven door.
Note the position of the trim on the door.
4. Using both hands, gently tilt the top of the door
glass towards you. Lift slightly to disengage the
locators from the two bottom brackets. The door will
remain in a parked position at an angle of
approximately 30°.
5. Clean the outer and inner glass using hot soapy
water or Hob Brite may be used with care. DO NOT
use Hob Brite on the Stainless Steel or painted
finishes. DO NOT try to clean the foil which is
inside the door. The foil is there to help keep the
door cool, if it is damaged it will not work. Ensure
that all parts are well rinsed and thoroughly dried
before attempting to replace the outer door panel.
5. Hold the glass in place at the top of the door. Insert
the cross head screw into the location holes. Give
the screws one turn to ensure the glass is secure.
6. Tighten the screws positively with the Pozidrive
screwdriver before closing the oven door.
DO NOT attempt to use the oven without the
glass being in place.
If the door glass panel becomes
chipped or has deep scratches the
glass will be weakened and must be
replaced to prevent the possibility of
the panel shattering. Please contact
your local Service Force Centre who
will be pleased to advise further.
TO CLEAN THE INNER GLASS DOOR
PANELS
Clean the inner door glass panels using a soft cloth and
hot water to which a little washing up has been added.
If the inner panel is heavily soiled, Hob Brite may be
used. Do not use abrasive cleaning materials on the
door glass. Ensure that all parts are well rinsed and
thoroughly dried before attempting to replace the glass.
36
Page 37
CARE OF STAYCLEAN SURFACES
REPLACING AN OVEN LIGHT BULB
Stayclean surfaces destroy splashes of food and fats
when the oven temperature is raised to around 220°C.
To aid this process it is a good idea to run the Top oven
for an hour or two per week without food. to ensure
continued good performance from the Stayclean finish.
Use the Oven Clean function for the main oven. See
page 31.
HINTS AND TIPS
l
Manual cleaning of Stayclean is not recommended.
Damage will occur if oven sprays or abrasives of
any kind are used.
l
Slight discolouration and polishing of the Stayclean
surface may occur in time. This does not affect the
Stayclean properties in any way.
The type of bulb required is a 300°C. 25 watt small
Edison Screw. Part number 572 491 5431-00/1.
(Available through Service Force Centres).
CAUTION: DISCONNECT THE APPLIANCE FROM
THE ELECTRICITY SUPPLY BEFORE REPLACING
THE BULB.
Open the oven door and remove the shelves to enable
easy access to the oven light assembly.
Insert a flat blade screwdriver between the oven side
and the glass which covers the bulb. Support the glass
with your hand and prise out sufficiently to release the
glass cover. Unscrew the bulb in an anticlockwise
direction until it is possible to remove the bulb with
ease.
Fit the new bulb by turning in a clockwise direction until
it is secure. Ensuring the indent to the flange is pointing
to the rear of the oven, replace the glass by pushing it
firmly into the hole to cover the bulb assembly.
Replace the shelves. Restore the electricity supply and
adjust the time of day as necessary.
l
A good time to allow the oven to run on is after the
weekly roast. After removing the roast, turn the
oven up to 220°C and allow to run for an hour or so.
It is important not to allow a build-up of soilage as
this can prevent the Stayclean from working.
l
Follow the recommendations below to keep oven
soilage to a minimum.
l
Cook at the recommended temperatures. Higher
temperatures during roasting will increase soilage.
Try cooking at lower temperatures for an increased
length of time, you will save energy and often the
joint is more tender.
l
Use minimal, if any, extra oil or fat when roasting
meat; potatoes only require brushing with fat before
cooking. Extra fat in the oven during roasting will
increase splashing and soilage.
l
It is not necessary to add water to a meat tin when
roasting. The water and the fat juices from the joint
create excessive splattering during cooking even at
normal temperatures as well as causing
condensation.
l
Covering joints during cooking will also prevent
splashing onto the interior surfaces; removing the
covering for the last 20-30 minutes will allow extra
browning, if required. Some large joints and turkeys
especially benefit by this method of cooking,
allowing the joint to cook through before the outside
is overbrowned.
37
Page 38
SOMETHING NOT WORKING?
We strongly recommend that you carry out the following
checks on your appliance before calling a Service
Engineer. It may be that the problem is a simple one
which you can solve yourself without the expense of a
service call.
If our Service Engineer finds that the problem is listed
below you will be charged for the call whether or not the
appliance is under guarantee.
The grill, oven and timer do not work.
l
l
Check that the main appliance fuse is working.
l
Check that the timer is set to manual (see page
If you have checked the above:
* Switch OFF appliance at the wall and allow the
Check that the appliance has been wired in and
is switched on at the wall.
32.
appliance to cool for a couple of hours. Switch
ON again. The appliance should now be
working normally.
The grill does not work or cuts out after being used
for a long period of time.
* Leave the oven to cool for a couple of hours.
Check that the grill operates normally. Ensure
that the door is left open during grilling.
* If the cooling fan fails, the grill will not operate
correctly. Please contact your Service Force
Centre.
The oven temperature is too high or low:
* Check that the recommended temperatures are
being used (see pages 19 and 27). Be
prepared to adjust the temperature up or down
by 10° C to achieve the results you want.
* Care should be taken if using an oven
thermometer to check oven temperatures as
they may be inaccurate.
The following factors should be considered.
* Ensure you purchase an accurate good quality
instrument.
The grill works but the oven does not:
* Check that the timer is set to manual operation
(see page 32).
* Check that the grill control is in the OFF
position.
* If you have checked that the timer is set for
manual switch OFF at the wall to allow the
oven to cool. After a couple of hours the oven
should be working normally.
The Top oven and grill work but the main oven
does not.
* Check that the timer is set for manual
operation. See page 32.
* For Top oven check that the grill control is in
the OFF position.
* If you have checked the timer is set to manual
switch OFF at the wall to allow oven to cool.
Check that the oven is now working normally.
* Ovens will cycle about a set temperature and
will not be constant.
If the oven is not cooking evenly.
* Check that the appliance is correctly installed
and that it is level.
* Check that the recommended temperatures
and shelf positions are being used.
The oven light fails to illuminate:
* Refer to page 37 'Replacing an Oven Light
Bulb'.
The oven fan is noisy:
* Check that the oven is level.
* Check that bakeware and shelves are not
vibrating in contact with the back panel in the
oven.
The indicator neons are not working correctly or
the function selected is not working.
The timer control does not work.
* Check that the operating instructions are being
closely followed. See page 32.
* Check that you have correctly selected only
the oven function you require. Ensure all the
other controls are in the OFF 'O' position.
NB. If the selector is set to 'O' and the oven
temperature control to a setting the main oven
neon will illuminate and the cooling fan will
operate. This is not a fault.
38
Page 39
SERVICE AND SPARE PARTS
In the event of your appliance requiring service, or if you
wish to purchase spare parts please contact your local
Service Force Centre by telephoning:
0870 5 929929
Your call will be routed to the Service Force Centre
covering your post code area. The address of your local
Service Force Centre is detailed on the following pages.
For Service in the Republic of Ireland contact
Electrolux
Long Mile Road
Dublin 12
Telephone: 01 4090753
Before calling out an engineer, please ensure you have
read the details under the heading ' Something Not
Working'.
When you contact the Service Force Centre you will
need to give the following details:
1. Your name, address and post code
2. Your telephone number
3. Clear and concise details of the fault
4. The model, product and serial number of the
appliance (found on the rating plate)
5. The purchase date
CUSTOMER CARE DEPARTMENT
For general enquiries concerning your Electrolux appliance, or further information on Electrolux products, you
are invited to contact our Customer Care Department by letter or telephone as follows:
Customer Care Department
Electrolux
55 - 77 High Street
Slough
Berkshire
SL1 1DZ
Tel: 0870 5 950950 *
( *calls to this number may be recorded for training purposes. )
39
Page 40
To contact your local Service Force Centre telephone 08705 929 929
CHANNEL ISLANDS
GUERNSEY
JERSEY
ABERDEEN
AUCHTERMUCHY
BLANTYRE
DUMFRIES
DUNOON
EDINBURGH
GLASGOW
INVERNESS
ISLE OF ARRAN
ISLE OF BARRA
ISLE OF BUTE
Guernsey Electricity
PO Box 4
Vale , Guernsey
Channel Islands
Jersey Electricity Company
Haut de L'orme
Rue De Haut De L'orme
Trinity
Jersey
Channel Islands JE3 5FG
SCOTLAND
54 Claremont Street
Aberdeen AB10 6RA
33a Burnside
Auchtermuchy
Fife KY14 7AJ
Unit 5
Block 2
Auchenraith Ind. Estate
Rosendale Way
Blantyre G72 0NJ
93 Irish Street
Dumfries
DG1 2PQ
7 Hill Street,
Dunoon
Argyll
PA23 7AL
Unit 12
Dumbryden Ind. Estate
2 Dumbryden Road
Edinburgh
EH14 2AB
Unit 4
Wellington Road
Bishopriggs
Glasgow G64 2SA
Unit 3Bl
Smithton Ind. Estate
Smithton
Inverness IV2 7WL
Arran Domestics
The Douglas Centre
Brodick
Isle of Arran KA27 8AJ
J Zerfah
244 Bruernish
Isle of Barra
Western Islands HS9 5QY
Walker Engineering
Glenmhor
Upper Serpentine Road
Rothesay
Isle of Bute PA20 9EH
GY1 3AD
ISLE OF LEWIS
KELSO
ORKNEY 7 King Street
PERTH
(OWN SALES)
SHETLAND
(OWN SALES)
SHETLAND
(OWN SALES)
WHALSAY
(OWN SALES)
ND Macleod
16 James Street
Stornoway
Isle of Lewis PA87 2QW
2, 6 & 8 Woodmarket
Kelso
Borders
TD5 7AX
Kirkwall
Orkney
KW15 1JF
Scottish Hydro Electric
Central Warehouse
Inveralmond
Perth PH1 3AF
3-4 Carlton Place
Lerwick
Shetland
ZE1 0PW
Bolts Shetland
26 North Road
Lerwick
Shetland ZE1 0PE
Leask Electrical
Harisdale
Symbister, Whalsay
Shetland ZE2 9AA
NORTHERN IRELAND
BELFAST
Owenmore House
Kilwee Business Park
Dunmurry
Belfast
BT17 0HD
WALES
CARDIFF
CLYWD
DYFED
OSWESTRY
Unit 4
Guardian Industrial Estate
Clydesmuir Road
Cardiff
CF2 2QS
Unit 6-7 Coed Parc
Abergele Road
Rhuddlan
Clwyd
LL18 5UG
Unit 9
St. Clears Business Park
Tenby Road
St. Clears
Carmarthen
SA33 4JW
Plas Ffynnon Warehouse
Middleton Road
Oswestry
SY11 2PP
NORTH EAST
GATESHEAD
GRIMSBY
HULL
LEEDS
NEWTON AYCLIFFE
SHEFFIELD
NORTH WEST
BIRKENHEAD
CARLISLE
ISLE OF MAN
BOLTON
PRESTON
STOCKPORT
Unit 356a
Dukesway Court
Dukesway
Gateshead NE11 0BH
15 Hainton Avenue
Grimsby
N. E. Lincs
DN32 9AS
Unit 1
Boulevard Industrial Estate
Hull
HU3 4AY
64-66 Cross Gates Road
Cross Gates
Leeds
LS15 7YS
Unit 23
Northfield Way
Aycliffe Industrial Park
Newton Aycliffe
DL5 6EJ
Pennine House
Roman Ridge Road
Sheffield
S9 1GB
1 Kelvin Park
Dock Road
Birkenhead
CL41 1LT
Unit 7
James Street Workshops
James Street
Carlisle
Cumbria CA2 5AH
South Quay Ind. Estate
Douglas
Isle of Man
IM1 5AT
Unit B
Central Industrial Estate
St Marks Street
Bolton
BL3 6NR
Unit 250
Dawson Place
Bamber Bridge
Preston
Lancashire PR5 8AL
Unit 20 Haigh Park
Haigh Avenue
Stockport
SK4 1QR
40
Page 41
To contact your local Service Force Centre telephone 08705 929 929
BIRMINGHAM
BOURNE
BRIDGNORTH
GLOUCESTER
HEREFORD
HIGHAM FERRERS
ILKESTON
LEICESTER
LINCOLN
REDDITCH
TAMWORTH
WORCESTER
MIDLANDS
66 Birch Road East
Wyrley Trading Estate
Witton
Birmingham
B6 7DB
Pinfold Road
Bourne
PE10 9HT
68 St.Mary's Street
Bridgnorth
Shropshire
WV16 4DR
101 Rycroft Street
Gloucester
GL1 4NB
& 4
Unit 3
Bank Buildings
Cattle Market
Hereford
HE4 9HX
30 High Street
Higham Ferrers
Northants
NN10 8PL
Unit 2
Furnace Road
Ilkeston DE7 5EP
Unit 7
Oaks Industrial Estate
Coventry Road
Narborough
Leicestershire
LE9 5GF
Unit 8
Clifton Street
Stone Field Park
Lincoln
LN5 8LQ
18-21 Croft Road
Brampton Ind. Estate
Newcastle under Lyme
Staffordshire
ST5 0TW
13 Thornhill Road
North Moons Moat
Redditch
Worcestershire
B98 9ND
Unit 3
Sterling Park
Claymore
Tamworth
B77 5DQ
& 2
Unit 1
Northbrooks Close
Gregorys Mill Ind. Estate
Worcester
WR3 8BP
LONDON & EAST ANGLIA
BECKENHAM
CHELMSFORD
COLINDALE
ELTHAM
ENFIELD
GRAVESEND
IPSWICH
LETCHWORTH
LONDON
MAIDENHEAD
MOLESEY
NEWBURY
NORWICH
SUNBURY
11a Gardner Ind. Estate
Kent House Lane
Beckenham
Kent BR3 1QZ
Hanbury Road
Widford Ind. Estate
Chelmsford
Essex
CM12 3AE
Unit 14
Capitol Park
Capitol Way
Colindale
London NW9 0EQ
194 Court Road
Mottingham
Eltham
London SE9 4EW
284 Alma Road
Enfield
London
EN3 7BB
Unit B4,
Imperial Business Estate
West Mill
Gravesend
Kent
DA11 0DL
Unit 6C
Elton Park Business Centre
Hadleigh Road
Ispwich
IP2 0DD
16-17 Woodside Ind. Park
Works Road
Letchworth
Herts
SG6 1LA
2 - 4 Royal Lane
Yiewsley
West Drayton
Middlesex
UB7 8DL
Reform Road
Maidenhead
Berkshire
SL6 8BY
10 Island Farm Avenue
West Molesey
Surrey
KT8 2UZ
9 Pipers Court
Berkshire Drive
Thatcham
Berkshire
RG19 4ER
2b Trafalgar Street
Norwich
NR1 3HN
Unit 1a
The Summit
Hanworth Road
Sunbury on Thames
TW16 5DB
SOUTH EAST
ASHFORD
FLEET
HAYWARDS
HEATH
TONBRIDGE Unit 30
Unit 2
Bridge Road Business Centre
Bridge Road
Ashford
Kent TN23 1BB
Unit 1
Redfields Ind. Estate
Church Crookham
Fleet
Hampshire GU13 0RD
21-25 Bridge Road
Haywards Heath
Sussex RH16 1UA
Deacon Trading Estate
Morley Road
Tonbridge
TN9 1RA
SOUTH WEST
BARNSTAPLE
BOURNEMOUTH
BRIDGEWATER
BRISTOL
EMSWORTH
ISLE OF WIGHT
NEWTON ABBOT
REDRUTH
Main Road
Fremington
Barnstaple
North Devon EX31 2NT
63-65 Curzon Road
Bournemouth
Dorset
BH1 4PW
6 Herswell Business Park
Salmon Parade
Bridgewater
Somerset TA6 5PY
11 Eldon Way
Eldonwall Trading Estate
Bristol
BS4 3QQ
266 Main Road
Southbourne
Emsworth
PO10 8JL
Unit 8
Enterprise Court
Ryde Business Park
Ryde
Isle of Wight PO33 1DB
Unit 2
Zealley Ind.Estate
Kingsteignton
Newton Abbot
TQ12 3TD
Unit 7D
Pool Ind. Estate
Druids Road
Redruth
Cornwall TR15 3RH
41
Page 42
GUARANTEE CONDITIONS
Standard guarantee conditions
We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part
thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or
replace the same FREE OF CHARGE for labour, materials or carriage on condition that:
l
The appliance has been correctly installed and used only on the electricity supply stated on the rating plate.
l
The appliance has been used for normal domestic purposes only, and in accordance with the manufacturer's
instructions.
l
The appliance has not been serviced, maintained, repaired, taken apart or tampered with by any person not
authorised by us.
l
All service work under this guarantee must be undertaken by a Service Force Centre.
l
Any appliance or defective part replaced shall become the Company's property.
l
This guarantee is in addition to your statutory and other legal rights.
Home visits are made between 8.30am and 5.30pm Monday to Friday. Visits may be available outside these hours
in which case a premium will be charged.
Exclusions
This guarantee does not cover:
l
Damage or calls resulting from transportation, improper use or neglect, the replacement of any light bulbs or
removable parts of glass or plastic.
l
Costs incurred for calls to put right an appliance which is improperly installed or calls to appliances outside the
United Kingdom.
l
Appliances found to be in use within a commercial environment, plus those which are subject to rental
agreements.
l
Products of Electrolux manufacture which are not marketed by Electrolux.
European Guarantee
If you should move to another country within Europe then your guarantee moves with you to your new home subject
to the following qualifications:
l
The guarantee starts from the date you first purchased your product.
l
The guarantee is for the same period and to the same extent for labour and parts as exists in the new country of
use for this brand or range of products.
l
This guarantee relates to you and cannot be transferred to another user.
l
Your new home is within the European Community (EC) or European Free Trade Area.
l
The product is installed and used in accordance with our instructions and is only used domestically, i.e. a
normal household.
l
The product is installed taking into account regulations in your new country.
Before you move please contact your nearest Customer Care centre, listed below, to give them details of your new
home. They will then ensure that the local Service Organisation is aware of your move and able to look after you
and your appliances.
France Senlis +33 (0) 3 44 62 20 13
Germany Nürnberg +49 (0) 800 234 7378
Italy Pordenone +39 (0) 800117511
Sweden Stockholm +46 (0) 20 78 77 50
UK Slough +44 (0) 1753 219898
EOD 984 - 311445512
42
Page 43
N O T E S
43
Page 44
IMPORTANT NOTICE
In line with our continuing policy of research and development, we reserve the right to alter models and
specifications without prior notice.
This instruction booklet is accurate at the date of printing, but will be superseded if specifications or appearance
are changed.
ELECTROLUX
55 - 77 HIGH STREET,
SLOUGH,
BERKSHIRE,
SL1 1DZ
TELEPHONE 0870 5 950950
Part Number: 311445512
© Electrolux Household Appliances Limited 2001
Page 45
documentation manual, user maintenance, brochure, user reference, pdf manual
This file has been downloaded from:
User Manual and User Guide for many equipments like mobile phones, photo cameras, monther board, monitors, software, tv, dvd, and othes..
Manual users, user manuals, user guide manual, owners manual, instruction manual, manual owner, manual owner's, manual guide,
manual operation, operating manual, user's manual, operating instructions, manual operators, manual operator, manual product,
Loading...
