Page 1
EEC87315L
EN Dishwasher User Manual
Page 2
www.electrolux.com2
CONTENTS
1. SAFETY INFORMATION....................................................................................2
2. SAFETY INSTRUCTIONS..................................................................................4
3. PRODUCT DESCRIPTION................................................................................ 6
4. CONTROL PANEL............................................................................................. 7
5. PROGRAMME SELECTION.............................................................................. 8
6. BASIC SETTINGS ........................................................................................... 10
7. BEFORE FIRST USE....................................................................................... 14
8. DAILY USE....................................................................................................... 15
9. HINTS AND TIPS............................................................................................. 18
10. CARE AND CLEANING..................................................................................20
11. TROUBLESHOOTING....................................................................................24
12. TECHNICAL INFORMATION......................................................................... 29
13. ENVIRONMENTAL CONCERNS................................................................... 29
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.electrolux.com/support
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
Page 3
ENGLISH 3
responsible for any injuries or damage that are the result
of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
• Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.
• Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
• Children should be supervised to ensure that they do
not play with the appliance.
• Keep detergents away from children.
• Keep children and pets away from the appliance when
the door is open.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
• This appliance is intended to be used in household
and similar applications such as:
– farm houses; staff kitchen areas in shops, offices
and other working environments;
– by clients in hotels, motels, bed & breakfast and
other residential type environments.
• Do not change the specification of this appliance.
• The operating water pressure (minimum and
maximum) must be between 0.5 (0.05) / 10 (1.0) bar
(MPa)
Page 4
www.youtube.com/electrolux
www.youtube.com/aeg
How to install your 60 cm
Dishwasher Sliding Hinge
www.electrolux.com4
• Follow the maximum number of 14 place settings.
• If the supply cord is damaged, it must be replaced by
the manufacturer, its Authorised Service Centre or
similarly qualified persons in order to avoid a hazard.
• WARNING: Knives and other utensils with sharp
points must be loaded in the basket with their points
down or placed in a horizontal position.
• Do not leave the appliance with the open door
unattended to avoid stepping accidentally onto it.
• Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
• Do not use high pressure water sprays and/or steam
to clean the appliance.
• If the appliance has ventilation openings in the base,
they must not be covered e.g. by a carpet.
• The appliance is to be connected to the water mains
using the new supplied hose-sets. Old hose sets must
not be reused.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Do not use the appliance before
installing it in the built-in structure due
to safety manner.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not install or use the appliance
where the temperature is less than
0 °C.
• Install the appliance in a safe and
suitable place that meets installation
requirements.
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• Warning: this appliance is designed to
be installed / connected to a
grounding connection in the building.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
Page 5
ENGLISH 5
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need to
be replaced, this must be carried out
by our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• This appliance is fitted with a 13 A
mains plug. If it is necessary to
change the mains plug fuse, use only
a 13 A ASTA (BS 1362) fuse (UK and
Ireland only).
2.3 Water connection
• Do not cause damage to the water
hoses.
• Before connection to new pipes, pipes
not used for a long time, where repair
work has been carried out or new
devices fitted (water meters, etc.), let
the water flow until it is clean and
clear.
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
• The water inlet hose has a safety
valve and a sheath with an inner
mains cable.
WARNING!
Dangerous voltage.
• If the water inlet hose is damaged,
immediately close the water tap and
disconnect the mains plug from the
mains socket. Contact the Authorised
Service Centre to replace the water
inlet hose.
2.4 Use
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Dishwasher detergents are
dangerous. Follow the safety
instructions on the detergent
packaging.
• Do not drink and play with the water in
the appliance.
• Do not remove the dishes from the
appliance until the programme is
complete. Some detergent may
remain on the dishes.
• Do not store items or apply pressure
on the open door of the appliance.
• The appliance can release hot steam
if you open the door while a
programme operates.
2.5 Internal lighting
WARNING!
Risk of injury.
• This appliance has an internal lamp
that comes on when you open the
door and goes off when the door is
closed.
• To replace the internal lighting,
contact the Authorised Service
Centre.
2.6 Service
• To repair the appliance contact the
Authorised Service Centre. Use
original spare parts only.
• Please note that self-repair or nonprofessional repair can have safety
consequences and might void the
guarantee.
• The following spare parts will be
available for 7 years after the model
has been discontinued: motor,
circulation and drain pump, heaters
and heating elements, including heat
pumps, piping and related equipment
including hoses, valves, filters and
aquastops, structural and interior
parts related to door assemblies,
printed circuit boards, electronic
displays, pressure switches,
thermostats and sensors, software
and firmware including reset software.
Please note that some of these spare
Page 6
5
4
9
67
13
12
11
10
14
2
3
1
8
www.electrolux.com6
parts are only available to
professional repairers, and that not all
spare parts are relevant for all
models.
• The following spare parts will be
available for 10 years after the model
has been discontinued: door hinge
and seals, other seals, spray arms,
drain filters, interior racks and plastic
peripherals such as baskets and lids.
• Concerning the lamp(s) inside this
product and spare part lamps sold
separately: These lamps are intended
to withstand extreme physical
conditions in household appliances,
such as temperature, vibration,
humidity, or are intended to signal
3. PRODUCT DESCRIPTION
information about the operational
status of the appliance. They are not
intended to be used in other
applications and are not suitable for
household room illumination.
2.7 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
Ceiling spray arm
1
Upper spray arm
2
Lower spray arm
3
Filters
4
Rating plate
5
Salt container
6
Air vent
7
Rinse aid dispenser
8
Detergent dispenser
9
ComfortLift basket
10
Trigger handle
11
Lower basket handle
12
Upper basket
13
Cutlery drawer
14
Page 7
1 2 3
4 5 6
ECO
ENGLISH 7
3.1 Internal light
The appliance has an internal lamp. It
comes on when you open the door or
switch the appliance on while the door is
open.
4. CONTROL PANEL
On/Off button / Reset button
1
Delay Start button
2
Display
3
MY TIME selection bar
4
4.1 Display
The display shows the following
information:
• ECOMETER
• Indicators
• Programme names and durations
• Delay start time
• Information texts
The lamp goes off when you close the
door or switch the appliance off.
Otherwise, it goes off automatically after
some time to save energy.
EXTRAS buttons
5
AUTO Sense program button
6
The ECOMETER indicates how the
programme selection impacts energy
and water consumption. The more bars
are on, the lower the consumption is.
indicates the most
environmentally friendly programme
selection for a normally soiled
dishwashing load.
4.2 ECOMETER
4.3 Indicators
Indicator Description
Rinse aid indicator. It is on when the rinse aid dispenser needs refill‐
ing. Refer to "Before first use".
Salt indicator. It is on when the salt container needs refilling. Refer to
"Before first use".
Machine Care indicator. It is on when the appliance needs internal
cleaning with the Machine Care programme. Refer to "Care and
cleaning".
Page 8
CA B D E
www.electrolux.com8
Indicator Description
Drying phase indicator. It is on when you select a programme with the
drying phase. It flashes when the drying phase operates. Refer to
"Programme selection".
Delay Start indicator. It is on when you set the delay start. Refer to
"Daily use".
Pause indicator. It flashes when you pause a wash cycle or the delay
countdown by opening the appliance door. Refer to "Daily use".
Alert indicators. They are on when a malfunction of the appliance oc‐
curs. Refer to "Troubleshooting".
5. PROGRAMME SELECTION
5.1 MY TIME
MY TIME selection bar allows to select a
suitable dishwashing cycle based on
programme duration.
A. • Quick is the shortest programme
(30min) suitable for dishwashing
a load with fresh and light soil.
• Pre-rinse (15min) is a
programme for rinsing off food
remains from the dishes. It
prevents odours forming in the
appliance. Do not use detergent
with this programme.
B. 1h is a programme suitable for
dishwashing a load with fresh and
lightly dried-on soil.
C. 1h 30min is a programme suitable
for dishwashing and drying normally
soiled items.
D. 2h 40min is a programme suitable
for dishwashing and drying heavily
soiled items.
E. ECO is the longest programme
offering the most efficient use of
energy and water consumption for
crockery and cutlery with normal soil.
This is the standard programme for
test institutes.
1)
5.2 AUTO Sense
The AUTO Sense programme
automatically adjusts the dishwashing
cycle to the type of load.
The appliance senses the degree of soil
and the amount of dishes in the baskets.
It adjusts the temperature and quantity of
water as well as the wash duration.
5.3 EXTRAS
You can adjust the programme selection
to your needs by activating EXTRAS.
ExtraHygiene
ExtraHygiene provides better
hygiene results by keeping the
temperature between 65 and 70 °C for at
least 10 minutes during the last rinsing
phase.
ExtraPower
ExtraPower improves the
dishwashing results of the selected
programme. The option increases the
wash temperature and duration.
1)
This programme is used to assess compliance with the Ecodesign Comission Regulation
(EU) 2019/2022.
Page 9
ENGLISH 9
GlassCare
GlassCare prevents delicate load,
glassware in particular, from damaging.
5.4 Programmes overview
Programme Dishwasher
Quick Crockery,
Pre-rinse
1h Crockery,
1h 30min Crockery,
2h 40min Crockery,
ECO Crockery,
AUTO
Sense
Machine
Care
load
cutlery
All All • Prewash Not applicable
cutlery
cutlery, pots,
pans
cutlery, pots,
pans
cutlery, pots,
pans
Crockery,
cutlery, pots,
pans
For cleaning the appliance
interior. Refer to "Care and
Cleaning".
Degree of
soil
Fresh • Dishwashing 50 °C
Fresh, lightly
dried-on
Normal, lightly
dried-on
Normal to
heavy, driedon
Normal, lightly
dried-on
All • Prewash
The option prevents rapid changes in the
dishwashing temperature of the selected
programme and reduces it to 45 °C.
Programme phases EXTRAS
• Intermediate rinse
• Final rinse 45 °C
• AirDry
• Dishwashing 60 °C
• Intermediate rinse
• Final rinse 50 °C
• AirDry
• Dishwashing 60 °C
• Intermediate rinse
• Final rinse 55 °C
• Drying
• AirDry
• Prewash
• Dishwashing 60 °C
• Intermediate rinse
• Final rinse 60 °C
• Drying
• AirDry
• Prewash
• Dishwashing 50 °C
• Intermediate rinse
• Final rinse 55 °C
• Drying
• AirDry
• Dishwashing 50 60 °C
• Intermediate rinse
• Final rinse 60 °C
• Drying
• AirDry
• Cleaning 70 °C
• Intermediate rinse
• Final rinse
• AirDry
• ExtraPower
• GlassCare
• ExtraHy‐
giene
• ExtraPower
• GlassCare
• ExtraHy‐
giene
• ExtraPower
• GlassCare
• ExtraHy‐
giene
• ExtraPower
• GlassCare
• ExtraHy‐
giene
• ExtraPower
• GlassCare
• ExtraHy‐
giene
Not applicable
Not applicable
Page 10
www.electrolux.com10
Consumption values
Programme 1)
Quick 11.0 0.620 30
Pre-rinse 5.0 0.010 15
1h 30min 11.9 1.110 90
2h 40min 11.9 1.210 160
ECO 11.0 0.848 240
AUTO Sense 12.1 1.220 170
Machine Care 10.6 0.710 60
1)
The pressure and the temperature of the water, the variations of the mains supply, the
options, the quantity of dishes and the degree of soil can change the values.
2)
The values for programmes other than ECO are indicative only.
2)
1h 11.8 0.970 60
Information for test institutes
To receive the necessary information for
conducting performance tests (e.g.
according to: EN60436 ), send an email
to:
6. BASIC SETTINGS
You can configure the appliance by
changing basic settings according to
your needs.
Water (l) Energy (kWh) Duration (min)
In your request, include the product
number code (PNC) from the rating plate.
For any other questions regarding your
dishwasher, refer to the service book
provided with your appliance.
Settings Values Description
Water hardness From level 1 to lev‐
el 10 (default: 5)
Rinse aid level From level 0 to lev‐
el 6 (default: 4)
End sound ON
OFF (default)
Auto door open ON (default)
OFF
Key tones ON (default)
OFF
Adjust the level of the water softener ac‐
cording to the water hardness in your
1)
area.
Adjust the level of the rinse aid according
to the necessary dosage.
Activate or deactivate the acoustic signal
for the end of a programme.
Activate or deactivate AirDry.
Activate or deactivate the sound of the
buttons when pressed.
1)
1)
1)
Page 11
BA C
ENGLISH 11
Settings Values Description
Latest prog. selec‐
tion
Display on floor ON (default)
Brightness From level 0 to lev‐
Language List of languages
Reset settings YES
PNC number Number Check the PNC number of your appli‐
1)
For more details, refer to the information provided in this chapter.
ON
OFF (default)
OFF
el 9
(default: English)
NO
Enable or disable the automatic selection
of the most recently used programme and
1)
options.
Activate or deactivate TimeBeam.
Adjust the brightness of the display.
Set the preferred language.
Reset the appliance to the factory settings.
1)
ance.
1)
6.1 Setting mode
How to navigate in setting mode
You can navigate in setting mode using
MY TIME selection bar.
A. Previous button
B. OK button
C. Next button
Use Previous and Next to switch
between the basic settings and to
change their value.
Use OK to enter the selected setting and
to confirm changing its value.
How to enter setting mode
You can enter setting mode before
starting a programme. You cannot enter
setting mode while the programme is
running.
To enter setting mode, press and hold
simultaneously and for
about 3 seconds.
• The lights related to the
Previous, OK and Next are on.
• The display shows the first
available setting and its current
value.
How to change a setting
Make sure the appliance is in setting
mode.
1. Use Previous or Next to select the
desired setting.
The display shows the setting name and
its current value.
2. Press OK to enter the setting.
The display shows available values.
3. Press Previous or Next to change
the value.
4. Press OK to confirm the setting.
• The new setting is saved.
• The appliance returns to the basic
settings list.
5. Press and hold simultaneously
and for about 3
seconds to exit setting mode.
The appliance returns to the programme
selection.
The saved settings remain valid until you
change them again.
Page 12
www.electrolux.com12
6.2 The water softener
The water softener removes minerals
from the water supply, which would have
a negative effect on the washing results
and on the appliance.
The higher the content of these minerals,
The water softener should be adjusted
according to the hardness of the water in
your area. Your local water authority can
advise you on the hardness of the water
in your area. Set the right level of the
water softener to assure good washing
results.
the harder your water is. Water hardness
is measured in equivalent scales.
Water hardness
German de‐
grees (°dH)
French de‐
grees (°fH)
mmol/l Clarke de‐
grees
47 - 50 84 - 90 8.4 - 9.0 58 - 63 10
43 - 46 76 - 83 7.6 - 8.3 53 - 57 9
37 - 42 65 - 75 6.5 - 7.5 46 - 52 8
29 - 36 51 - 64 5.1 - 6.4 36 - 45 7
23 - 28 40 - 50 4.0 - 5.0 28 - 35 6
19 - 22 33 - 39 3.3 - 3.9 23 - 27
15 - 18 26 - 32 2.6 - 3.2 18 - 22 4
11 - 14 19 - 25 1.9 - 2.5 13 - 17 3
4 - 10 7 - 18 0.7 - 1.8 5 - 12 2
<4 <7 <0.7 < 5
1)
Factory setting.
2)
Do not use salt at this level.
Water softener
level
1)
5
2)
1
Regardless of the type of detergent
used, set the proper water hardness
level to keep the salt refill indicator
active.
Multi-tabs containing salt are
not effective enough to
soften hard water.
Regeneration process
For the correct water softener operation,
the resin of the softener device needs to
be regenerated regularly. This process is
automatic and is the part of the normal
dishwasher operation.
When the prescribed quantity of water
(see values in the table) has been used
since the previous regeneration process,
a new regeneration process will be
initiated between the final rinse and the
programme end.
Water softener
level
1 250
2 100
3 62
4 47
5 25
6 17
7 10
8 5
9 3
10 3
Amount of water
(l)
Page 13
ENGLISH 13
In case of the high water softener setting,
it may occur also in the middle of the
programme, before the rinse (twice
during a programme). Regeneration
initiation has no impact on the cycle
duration, unless it occurs in the middle of
a programme or at the end of a
programme with a short drying phase. In
such cases, the regeneration prolongs
the total duration of a programme by
additional 5 minutes.
Subsequently, the rinsing of the water
softener that lasts 5 minutes may begin
in the same cycle or at the beginning of
the next programme. This activity
increases the total water consumption of
a programme by additional 4 litres and
the total energy consumption of a
programme by additional 2 Wh. The
rinsing of the softener ends with a
complete drain.
Each performed softener rinse (possible
more than one in the same cycle) may
prolong the programme duration by
another 5 minutes when it occurs at any
point at the beginning or in the middle of
a programme.
All the consumption values
mentioned in this section are
determined in line with the
currently applicable standard
in laboratory conditions with
water hardness 2.5mmol/L
(water softener: level 3)
according to the regulation:
2019/2022 .
The pressure and the
temperature of water as well
as the variations of the
mains supply can change
the values.
6.3 Rinse aid level
The rinse aid helps to dry the dishes
without streaks and stains. It is
automatically released during the hot
rinse phase. It is possible to set the
released quantity of rinse aid.
When the rinse aid dispenser is empty,
the display shows the indicator and
Rinse aid low. If the drying results are
satisfactory while using multi-tablets only,
it is possible to deactivate the dispenser
and the refill notification. However, for
best drying performance, always use
rinse aid and keep the notification active.
To deactivate the rinse aid dispenser and
the notification, set the rinse aid level to
0.
6.4 End sound
You can activate an acoustic signal that
sounds when the programme is
completed.
Acoustic signals sound also
when a malfunction of the
appliance occurs. It is not
possible to deactivate these
signals.
6.5 AirDry
AirDry improves the drying results. The
appliance door opens automatically
during the drying phase and remains
ajar.
AirDry is automatically activated with all
programmes other than Pre-rinse.
The duration of the drying phase and the
door opening time vary depending on the
selected programme and options.
When AirDry opens the door, the display
shows the remaining time of the running
programme.
CAUTION!
Do not try to close the
appliance door within 2
minutes after automatic
opening. This can cause
damage to the appliance.
Page 14
www.electrolux.com14
CAUTION!
If children have access to
the appliance, we advise to
deactivate AirDry. The
automatic opening of the
door may pose a danger.
6.6 Latest programme selection
You can set the automatic selection of
the most recently used programme and
options.
The latest programme that was
completed before the appliance
deactivation is saved. It is then selected
automatically after you activate the
appliance.
When the latest programme selection is
disabled, the default programme is ECO.
6.7 TimeBeam
TimeBeam displays the following
information on the floor below the
appliance door:
• The programme duration when the
programme begins.
• 0:00 and CLEAN when the
programme is completed.
• DELAY and the countdown duration
when the delay start begins.
• An alarm code when the appliance
has a malfunction.
When AirDry opens the
door, TimeBeam is off. To
check the remaining time of
the running programme, look
at the control panel display.
6.8 PNC number
If you contact an Authorised Service
Centre, you need to provide the product
number code (PNC number) of your
appliance.
The number can be found on the rating
plate on the appliance door. You can
also check the number on the display.
Select PNC number from the setting list
to check the number.
7. BEFORE FIRST USE
1. Make sure that the current level of
the water softener agrees with the
hardness of the water supply. If
not, adjust the level of the water
softener.
2. Fill the salt container.
3. Fill the rinse aid dispenser.
4. Open the water tap.
5. Start the programme Quick to
remove any residuals from the
manufacturing process. Do not use
detergent and do not put dishes in
the baskets.
After starting the programme, the
appliance recharges the resin in the
water softener for up to 5 minutes. The
washing phase starts only after this
procedure is complete. The procedure is
repeated periodically.
7.1 The salt container
CAUTION!
Use rough salt designed for
dishwashers only. Fine salt
increases the risk of
corrosion.
The salt is used to recharge the resin in
the water softener and to assure good
washing results in daily use.
Page 15
A
B
C
ENGLISH 15
How to fill the salt container
Make sure that the
ComfortLift basket is empty
and locked in the raised
position.
1. Turn the cap of the salt container
counterclockwise and remove it.
2. Put 1 litre of water in the salt
container (only for the first time).
3. Fill the salt container with dishwasher
salt (until it is full).
4. Carefully shake the funnel by its
handle to get the last granules inside.
5. Remove the salt around the opening
of the salt container.
6. Turn the cap of the salt container
clockwise to close the salt container.
CAUTION!
Water and salt can come out
of the salt container when
you fill it. After you fill the
salt container, immediately
start the shortest programme
to prevent corrosion. Do not
put dishes in the baskets.
7.2 How to fill the rinse aid dispenser
CAUTION!
The compartment (B) is for
rinse aid only. Do not fill it
with detergent.
CAUTION!
Only use rinse aid designed
specifically for dishwashers.
1. Open the lid (C).
2. Fill the dispenser (B) until the rinse
aid reaches the marking ''MAX''.
3. Remove the spilled rinse aid with an
absorbent cloth to prevent excessive
foam formation.
4. Close the lid. Make sure that the lid
locks into position.
Fill the rinse aid dispenser
when the indicator (A) is
clear.
8. DAILY USE
1. Open the water tap.
2. Press and hold until the appliance
is activated.
3. Fill the salt container if it is empty.
4. Fill the rinse aid dispenser if it is
empty.
5. Load the baskets.
6. Add the detergent.
7. Select and start a programme.
Page 16
A
B
C
www.electrolux.com16
8. Close the water tap when the
programme is complete.
8.1 ComfortLift
CAUTION!
Do not sit on the rack or put
excessive pressure on the
locked basket.
CAUTION!
Do not exceed the max load
capacity of 18 kg.
CAUTION!
Make sure that items do not
stick out of the basket frame
as it can cause damage to
the items and the ComfortLift
mechanism.
The ComfortLift mechanism allows to lift
the lower rack up (to the second rack
level) and put it down to load and unload
dishes easily.
To load or unload the lower basket:
1. Lift the basket by pulling the rack out
of the dishwasher by the basket
handle. The trigger handle should not
be used.
Once the basket is unlocked, push
the rack down. The mechanism
returns to its default position on the
lower level.
There are two ways of lowering the
basket depending on the loading:
• If there is a full load of plates,
slightly push the basket down.
• If the basket is empty or halfloaded, press the basket down.
8.2 Using the detergent
CAUTION!
Only use detergent
specifically designed for
The basket is automatically locked on the
upper level.
2. Carefully place items in the basket or
remove them (refer to the basket
loading leaflet).
3. Lower the basket by connecting the
trigger handle with the basket frame
as shown below. Lift the trigger
handle completely and the basket
handle slightly until the basket is
disengaged on both sides.
1. Press the release button (A) to open
2. Put the detergent (gel, powder or
3. If the programme has a prewash
4. Close the lid. Make sure that the lid
dishwashers.
the lid (C).
tablets) in the compartment (B).
phase, put a small quantity of
detergent on the inner part of the
appliance door.
locks into position.
Page 17
ENGLISH 17
For information about the
detergent dosage, refer to
the manufacturer's
instructions on the
packaging of the product.
Usually, 20 - 25 ml of gel
detergent is adequate for
washing a load with normal
soil.
The upper ends of the two
vertical ribs inside the
compartment (B) indicate
the maximum level for filling
the dispenser with gel (max.
30ml).
8.3 How to select and start a programme using MY TIME selection bar
1. Slide your finger across MY TIME
selection bar to choose a suitable
programme.
• The light related to the selected
programme is on.
• The ECOMETER indicates the
level of energy and water
consumption.
• The display shows the
programme duration.
2. Activate applicable EXTRAS if
desired.
3. Close the appliance door to start the
programme.
8.4 How to select and start the
programme Pre-rinse
1. To select Pre-rinse, press and
hold
• The light related to the button is
on.
• The ECOMETER is off.
• The display shows the
programme name and duration.
2. Close the appliance door to start the
programme.
for 3 seconds.
8.5 How to activate EXTRAS
1. Select a programme using MY TIME
selection bar.
2. Press the button dedicated to the
option you want to activate.
• The light related to the button is
on.
• The display shows the updated
programme duration.
• The ECOMETER indicates the
updated level of energy and water
consumption.
By default, options must be
activated every time before
you start a programme.
If the latest programme
selection is enabled, the
saved options are activated
automatically along with the
programme.
It is not possible to activate
or deactivate options while a
programme is running.
Not all options are
compatible with each other.
Activating options often
increases the water and
energy consumption as well
as the programme duration.
8.6 How to start the AUTO
Sense program
1. Press .
• The light related to the button is
on.
• The display shows the longest
possible program duration.
2. Close the appliance door to start the
program.
The appliance senses the type of load
and adjusts a suitable wash cycle.
During the cycle, the sensors operate
several times and the initial program
duration can decrease.
8.7 How to delay the start of a
programme
1. Select a programme.
2. Press
shows the desired delay time (from 1
to 24 hours).
repeatedly until the display
Page 18
www.electrolux.com18
The light related to the button is on.
3. Close the appliance door to start the
countdown.
During the countdown, you cannot
change the delay time and the
programme selection.
When the countdown is complete, the
programme starts.
8.8 Opening the door while the
appliance operates
Opening the door while a programme is
running pauses the wash cycle. The
display shows the remaining duration of
the programme. The programme bar at
the bottom of the display indicates the
current progress of the wash cycle. The
length of the bar decreases along with
the programme duration. After closing
the door, the wash cycle resumes from
the point of interruption.
If you open the door during the delay
start countdown, the countdown is
paused. The display shows the current
countdown status. After closing the door,
the countdown resumes.
Opening the door while the
appliance operates may
affect the energy
consumption and the
programme duration.
If the door is opened for
more than 30 seconds
during the drying phase, the
running programme ends. It
does not happen if the door
is opened by the AirDry
function.
Press and hold for about 3 seconds.
The appliance returns to the programme
selection.
If you cancel the delay start,
you have to select the
programme again.
8.10 How to cancel a running programme
Press and hold for about 3 seconds.
The appliance returns to the programme
selection.
Make sure that there is
detergent in the detergent
dispenser before you start a
new programme.
8.11 The Auto Off function
This function saves energy by switching
the appliance off when it is not operating.
The function comes into operation
automatically:
• When the programme is completed.
• After 5 minutes if a programme was
not started.
8.12 End of the programme
When the programme is complete, the
display shows Dishes clean.
The Auto Off function switches the
appliance off automatically.
All buttons are inactive except for the
on/off button.
8.9 How to cancel the delay start while the countdown operates
9. HINTS AND TIPS
9.1 General
Follow the hints below to ensure optimal
cleaning and drying results in daily use
and to protect the environment.
• Washing dishes in the dishwasher as
instructed in the user manual usually
consumes less water and energy than
washing dishes by hand.
• Load the dishwasher to its full
capacity to save water and energy.
Page 19
ENGLISH 19
For best cleaning results, arrange
items in the baskets as instructed in
the user manual and do not overload
the baskets.
• Do not pre-rinse dishes by hand. It
increases the water and energy
consumption. When needed, select a
programme with a prewash phase.
• Remove larger residues of food from
the dishes and empty cups and
glasses before putting them inside the
appliance.
• Soak or slightly scour cookware with
firmly cooked-on or baked-on food
before washing it in the appliance.
• Make sure that items in the baskets
do not touch or cover each other.
Only then can the water completely
reach and wash the dishes.
• You can use dishwasher detergent,
rinse aid and salt separately or you
can use the multi-tablets (e.g. ''All in
1''). Follow the instructions on the
packaging.
• Select a programme according to the
type of load and the degree of soil.
ECO offers the most efficient use of
water and energy consumption.
• To prevent limescale buildup inside
the appliance:
– Refill the salt container whenever
necessary.
– Use the recommended dosage of
the detergent and rinse aid.
– Make sure that the current level of
the water softener agrees with the
hardness of the water supply.
– Follow the instructions in the
chapter "Care and cleaning".
9.2 Using salt, rinse aid and
detergent
• Only use salt, rinse aid and detergent
designed for dishwasher. Other
products can cause damage to the
appliance.
• In areas with hard and very hard
water, we recommend to use basic
dishwasher detergent (powder, gel,
tablets containing no additional
agents), rinse aid and salt separately
for optimal cleaning and drying
results.
• Detergent tablets do not fully dissolve
with short programmes. To prevent
detergent residues on the tableware,
we recommend that you use tablets
with long programmes.
• Always use the correct quantity of
detergent. Insufficient dosage of
detergent can result in poor cleaning
results and hard-water filming or
spotting on the items. Using too much
detergent with soft or softened water
results in detergent residues on the
dishes. Adjust the amount of
detergent based on the water
hardness. Refer to the instructions on
the detergent packaging.
• Always use the correct quantity of
rinse aid. Insufficient dosage of rinse
aid decreases the drying results.
Using too much rinse aid results in
bluish layers on the items.
• Make sure that the water softener
level is correct. If the level is too high,
the increased quantity of salt in the
water might result in rust on cutlery.
9.3 What to do if you want to
stop using multi-tablets
Before you start using separately
detergent, salt and rinse aid, complete
the following steps:
1. Set the highest level of the water
softener.
2. Make sure that the salt and rinse aid
containers are full.
3. Start the Quick programme. Do not
add detergent and do not put dishes
in the baskets.
4. When the programme is completed,
adjust the water softener according
to the water hardness in your area.
5. Adjust the released quantity of rinse
aid.
9.4 Before starting a
programme
Before you start the selected
programme, make sure that:
• The filters are clean and correctly
installed.
• The cap of the salt container is tight.
• The spray arms are not clogged.
• There is enough salt and rinse aid
(unless you use multi-tablets).
Page 20
www.electrolux.com20
• The arrangement of the items in the
baskets is correct.
• The programme is suitable to the type
of load and the degree of soil.
• The correct quantity of detergent is
used.
9.5 Loading the baskets
• Always use the whole space of the
baskets.
• Use the appliance to wash
dishwasher-safe items only.
• Do not wash in the appliance items
made of wood, horn, aluminium,
pewter and copper as they could
crack, warp, get discoloured or pitted.
• Do not wash in the appliance items
that can absorb water (sponges,
household cloths).
• Put hollow items (cups, glasses and
pans) with the opening facing
downwards.
• Make sure that glass items do not
touch each other.
10. CARE AND CLEANING
WARNING!
Before any maintenance
other than running the
programme Machine Care,
deactivate the appliance and
disconnect the mains plug
from the main socket.
Make sure that the
ComfortLift basket is empty
and locked in the raised
position.
Dirty filters and clogged
spray arms negatively affect
the washing results. Check
these elements regularly
and, if necessary, clean
them.
10.1 Machine Care
Machine Care is a programme designed
to clean the appliance interior with
optimal results. It removes limescale and
grease buildup.
• Put light items in the upper basket.
Make sure that the items do not move
freely.
• Put cutlery and small items in the
cutlery drawer.
• Move the upper basket upwards to
accommodate large items in the lower
basket.
• Make sure that the spray arms can
move freely before you start a
programme.
9.6 Unloading the baskets
1. Let the tableware cool down before
you remove it from the appliance. Hot
items can be easily damaged.
2. First remove items from the lower
basket, then from the upper basket.
After the programme is
completed, water can still
remain on the inside
surfaces of the appliance.
When the appliance senses the need for
cleaning, the display shows the reminder
message Please run MachineCare and
the indicator . Start the Machine Care
programme to clean the appliance
interior.
How to start the Machine Care programme
Before starting the Machine
Care programme, clean the
filters and spray arms.
1. Use a descaler or a cleaning product
designed specifically for
dishwashers. Follow the instructions
on the packaging. Do not put dishes
in the baskets.
2. Press and hold simultaneously
and for about 3 seconds.
The indicator flashes. The display
shows the programme duration.
3. Close the appliance door to start the
programme.
Page 21
When the programme is complete, the
C
B
A
reminder message is disabled.
10.2 Internal cleaning
• Clean the appliance interior with a soft
damp cloth.
• Do not use abrasive products,
abrasive cleaning pads, sharp tools,
strong chemicals, scourer or solvents.
• Wipe clean the door, including the
rubber gasket, once a week.
• To maintain the performance of your
appliance, use a cleaning product
designed specifically for dishwashers
at least once every two months.
Carefully follow the instructions on the
packaging of the product.
• For optimal cleaning results, start the
programme Machine Care.
10.3 Removal of foreign objects
Check the filters and the sump after each
use of the dishwasher. Foreign objects
(e.g. pieces of glass, plastic, bones or
toothpicks, etc) decrease the cleaning
performance and can cause damage to
the drain pump.
CAUTION!
If unable to remove the
foreign objects, contact an
Authorised Service Centre.
ENGLISH 21
1. Turn the filter (B) counterclockwise
and remove it.
1. Disassemble the filters system as
instructed in this chapter.
2. Remove any foreign objects
manually.
3. Reassemble the filters as instructed
in this chapter.
2. Remove the filter (C) out of filter (B).
3. Remove the flat filter (A).
10.4 External cleaning
• Clean the appliance with a moist soft
cloth.
• Only use neutral detergents.
• Do not use abrasive products,
abrasive cleaning pads or solvents.
4. Wash the filters.
10.5 Cleaning the filters
The filter system is made of 3 parts.
Page 22
www.electrolux.com22
5. Make sure that there are no residues
of food or soil in or around the edge
of the sump.
6. Put back in place the flat filter (A).
Make sure that it is correctly
positioned under the 2 guides.
10.6 Cleaning the lower spray arm
We recommend to clean the lower spray
arm regularly to prevent soil from
clogging the holes.
Clogged holes can cause unsatisfactory
washing results.
1. To remove the lower spray arm, pull
it upwards.
2. Wash the spray arm under running
water. Use a thin pointed tool, e.g. a
toothpick, to remove particles of soil
from the holes.
7. Reassemble the filters (B) and (C).
8. Put back the filter (B) in the flat filter
(A). Turn it clockwise until it locks.
CAUTION!
An incorrect position of the
filters can cause bad
washing results and damage
to the appliance.
3. To install the spray arm back, press it
downwards.
Page 23
10.7 Cleaning the upper spray
C
B
A
1
2
arm
We recommend to clean the upper spray
arm regularly to prevent soil from
clogging the holes.
Clogged holes can cause unsatisfactory
washing results.
1. Pull out the upper basket.
2. To detach the spray arm from the
basket, press the spray arm upwards
and simultaneously turn it clockwise.
3. Wash the spray arm under running
water. Use a thin pointed tool, e.g. a
toothpick, to remove particles of soil
from the holes.
ENGLISH 23
10.8 Cleaning the ceiling spray
arm
We recommend to clean the ceiling spray
arm regularly to prevent soil from
clogging the holes. Clogged holes can
cause unsatisfactory washing results.
The ceiling spray arm is placed on the
ceiling of the appliance. The spray arm
(C) is installed in the delivery tube (A)
with the mounting element (B).
1. Release the stoppers on the sides of
the sliding rails of the cutlery drawer
and pull the drawer out.
4. To install the spray arm back, press
the spray arm upwards and
simultaneously turn it
counterclockwise until it locks into
place.
Page 24
www.electrolux.com24
2. Move the upper basket to the lowest
level to reach the spray arm more
easily.
3. To detach the spray arm (C) from the
delivery tube (A), turn the mounting
element (B) counterclockwise and
pull the spray arm downwards.
4. Wash the spray arm under running
water. Use a thin pointed tool, e.g. a
toothpick, to remove particles of soil
from the holes. Run the water
through the holes to wash soil
particles away from the inside.
11. TROUBLESHOOTING
5. To install the spray arm (C) back,
insert the mounting element (B) in
the spray arm and fix it in the delivery
tube (A) by turning it clockwise. Make
sure that the mounting element locks
into place.
6. Install the cutlery drawer on the
sliding rails and block the stoppers.
WARNING!
Improper repair of the
appliance may pose a
danger to the safety of the
user. Any repairs must be
performed by qualified
personnel.
The majority of problems that may
occur can be solved without the need
Problem and alarm code Possible cause and solution
You cannot activate the
appliance.
• Make sure that the mains plug is connected to the
mains socket.
• Make sure that there is no damaged fuse in the fuse
box.
to contact an Authorised Service
Centre.
Refer to the below table for information
on possible problems.
With some problems, the display shows
an alarm code.
Page 25
Problem and alarm code Possible cause and solution
The programme does not
start.
• Make sure that the appliance door is closed.
• If the delay start is set, cancel the setting or wait for
the end of the countdown.
• The appliance recharges the resin inside the water
softener. The duration of the procedure is approxi‐
mately 5 minutes.
The appliance does not fill
with water.
The display shows , Er‐
ror i10 or Error i11 and
No intake of water.
• Make sure that the water tap is open.
• Make sure that the pressure of the water supply is
not too low. For this information, contact your local
water authority.
• Make sure that the water tap is not clogged.
• Make sure that the filter in the inlet hose is not clog‐
ged.
• Make sure that the inlet hose has no kinks or bends.
The appliance does not
drain the water.
The display shows , Er‐
ror i20 and Water is not
• Make sure that the sink spigot is not clogged.
• Make sure that the interior filter system is not clog‐
ged.
• Make sure that the drain hose has no kinks or bends.
draining.
The anti-flood device is on.
The display shows , Er‐
• Close the water tap and contact an Authorised Serv‐
ice Centre.
ror i30 and Risk of flood
detected.
Malfunction of the water
level detection sensor.
• Make sure that the filters are clean.
• Switch the appliance off and on.
The display shows i41 i44.
Malfunction of the wash
• Switch the appliance off and on.
pump or the drain pump.
The display shows i51 i59 or i5A - i5F.
The temperature of the wa‐
ter inside the appliance is
too high or malfunction of
• Make sure that the temperature of the inlet water
does not exceed 60°C.
• Switch the appliance off and on.
the temperature sensor oc‐
curred.
The display shows i61 or
i69.
Technical malfunction of
• Switch the appliance off and on.
the appliance.
The display shows iC0 or
iC3.
ENGLISH 25
Page 26
www.electrolux.com26
Problem and alarm code Possible cause and solution
The level of water inside
the appliance is too high.
The display shows iF1.
• Switch the appliance off and on.
• Make sure that the filters are clean.
• Make sure that the outlet hose is installed at the right
height above the floor. Refer to the installation in‐
structions.
The appliance stops and
starts more times during
• It is normal. It provides optimal cleaning results and
energy savings.
operation.
The programme lasts too
long.
• If the delay start option is set, cancel the delay set‐
ting or wait for the end of the countdown.
• Activating options often increases the programme
duration.
The displayed programme
duration is different than
the duration in the con‐
sumption values table.
The remaining time in the
display increases and
• The pressure and the temperature of the water, the
variations of the mains supply, the options, the quan‐
tity of dishes and the degree of soil can change the
programme duration.
• This is not a defect. The appliance is working cor‐
rectly.
skips nearly to the end of
the programme duration.
Small leak from the appli‐
ance door.
• The appliance is not levelled. Loosen or tighten the
adjustable feet (if applicable).
• The appliance door is not centred on the tub. Adjust
the rear foot (if applicable).
The appliance door is diffi‐
cult to close.
• The appliance is not levelled. Loosen or tighten the
adjustable feet (if applicable).
• Parts of the tableware are protruding from the bas‐
kets.
The appliance door opens
during the wash cycle.
Rattling or knocking
sounds from the inside of
the appliance.
The appliance trips the cir‐
cuit-beaker.
• The AirDry function is activated. You can deactivate
the function. Refer to "Basic settings".
• The tableware is not properly arranged in the bas‐
kets. Refer to basket loading leaflet.
• Make sure that the spray arms can rotate freely.
• The amperage is insufficient to supply simultaneous‐
ly all the appliances in use. Check the socket amper‐
age and the capacity of the meter or turn off one of
the appliances in use.
• Internal electrical fault of the appliance. Contact an
Authorised Service Centre.
The appliance is switched
on but does not operate.
The display shows Power
• Power supply is out of the operating range. The
wash cycle is temporarily interrupted and resumes
automatically once the power is restored.
Fail.
Page 27
Problem and alarm code Possible cause and solution
The appliance switches off
during operation.
• Complete power outage. The wash cycle is tempora‐
rily interrupted and resumes automatically once the
power is restored.
ENGLISH 27
Once you have checked the appliance,
deactivate and activate the appliance. If
the problem occurs again, contact an
Authorised Service Centre.
For alarm codes not described in the
table, contact an Authorised Service
Centre.
Before contacting an
Authorised Service Centre,
write down the PNC number.
Refer to "Basic settings".
WARNING!
We do not recommend using
the appliance until the
problem has been
completely fixed. Unplug the
appliance and do not plug it
in again until you are certain
that it operates correctly.
11.1 The dishwashing and drying results are not satisfactory
Problem Possible cause and solution
Poor washing results. • Refer to "Daily use", "Hints and tips" and the
Poor drying results. • Tableware was left for too long inside the closed
There are whitish streaks or
bluish layers on glasses and
dishes.
There are stains and dry wa‐
ter drops on glasses and
dishes.
The interior of the appliance
is wet.
basket loading leaflet.
• Use more intensive washing programme.
• Activate the ExtraPower option to improve the
washing results of a selected programme.
• Clean spray arm jets and filter. Refer to "Care and
Cleaning".
appliance. Activate the function AirDry to set the
automatic opening of the door and to improve the
drying performance.
• There is no rinse aid or the dosage of rinse aid is
not sufficient. Fill the rinse aid dispenser or set the
dosage of rinse aid to a higher level.
• The quality of the rinse aid can be the cause.
• Always use rinse aid, even with multi-tablets.
• Plastic items may need to be towel dried.
• The programme does not have the drying phase.
Refer to "Programmes overview".
• The released quantity of rinse aid is too high. Ad‐
just the rinse aid dosage to a lower level.
• The quantity of detergent is too high.
• The released quantity of rinse aid is not sufficient.
Adjust the rinse aid dosage to a higher level.
• The quality of the rinse aid can be the cause.
• This is not a defect of the appliance. Humidity con‐
densates on the appliance walls.
Page 28
www.electrolux.com28
Problem Possible cause and solution
Unusual foam during wash‐
ing.
• Use the detergent designed specifically for dish‐
washers.
• Use a detergent from a different manufacturer.
• Do not pre-rinse dishes under running water.
Traces of rust on cutlery. • There is too much salt in the water used for wash‐
ing. Refer to "The water softener".
• Silver and stainless steel cutlery were placed to‐
gether. Do not place silver and stainless steel items
close together.
There are residues of deter‐
gent in the dispenser at the
end of the programme.
• The detergent tablet was stuck in the dispenser
and was not washed away by water.
• Water cannot wash away the detergent from the
dispenser. Make sure that the spray arms are not
blocked or clogged.
• Make sure that items in the baskets do not impede
the lid of the detergent dispenser from opening.
Odours inside the appliance. • Refer to "Internal cleaning".
• Start the Machine Care programme with a descaler
or a cleaning product designed for dishwashers.
Limescale deposits on the
tableware, on the tub and on
the inside of the door.
• The level of salt is low, check the refill indicator.
• The cap of the salt container is loose.
• Your tap water is hard. Refer to "The water soft‐
ener".
• Use salt and set regeneration of the water softener
even when multi-functional tablets are used. Refer
to "The water softener".
• Start the Machine Care programme with a descaler
designed for dishwashers.
• If limescale deposits persist, clean the appliance
with the suitable detergents.
• Try a different detergent.
• Contact the detergent manufacturer.
Dull, discoloured or chipped
tableware.
• Make sure that only dishwasher-safe items are
washed in the appliance.
• Load and unload the basket carefully. Refer to the
basket loading leaflet.
• Place delicate items in the upper basket.
• Activate the GlassCare option to ensure special
care for glassware and delicate items.
Refer to "Before first use",
"Daily use", or "Hints and
tips" for other possible
causes.
Page 29
12. TECHNICAL INFORMATION
Dimensions Width / height / depth (mm) 596 / 818 - 898 / 550
Electrical connection
Water supply pressure bar (minimum and maximum) 0.5 - 10
Water supply
Capacity Place settings 14
1)
Refer to the rating plate for other values.
2)
If the hot water comes from alternative source of energy (e.g. solar panels), use the hot
water supply to decrease energy consumption.
1)
Voltage (V) 200 - 240
Frequency (Hz) 50 - 60
MPa (minimum and maximum) 0.05 - 1.0
Cold water or hot water
ENGLISH 29
2)
max 60 °C
12.1 Link to the EU EPREL database
The QR code on the energy label
supplied with the appliance provides a
web link to the registration of this
appliance in the EU EPREL database.
Keep the energy label for reference
together with the user manual and all
other documents provided with this
appliance.
It is possible to find information related to
the performance of the product in the EU
EPREL database using the link https://
eprel.ec.europa.eu and the model name
and product number that you can find on
the rating plate of the appliance. Refer to
the chapter "Product description".
For more detailed information about the
energy label, visit
www.theenergylabel.eu.
13. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol .
Put the packaging in relevant containers
to recycle it. Help protect the
environment and human health by
recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
*
Page 30
Page 31
Page 32
www.electrolux.com/shop
117843390-A-482021
Loading...
