OVEN USER MANUAL
Page 2
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have
created it to give you impeccable performance for many
years, with innovative technologies that help make life
simpler – features you might not find on ordinary
appliances. Please spend a few minutes reading to get
the very best from it.
ACCESSORIES AND CONSUMABLES
In the AEG webshop, you’ll find everything you need to
keep all your AEG appliances looking spotless and
working perfectly. Along with a wide range of
accessories designed and built to the high quality
standards you would expect, from specialist cookware
to cutlery baskets, from bottle holders to delicate
laundry bags…
Visit the webshop at:
www.aeg-electrolux.com/shop
2
Page 3
CONTENTS
4 Safety information
7 Product description
8 Before first use
8Daily use
10 Using the accessories
11 Additional functions
11 Helpful hints and tips
20 Care and cleaning
23 What to do if…
24 Environment concerns
The following symbols are used in this user
manual:
Important information concerning your
personal safety and information on how to
avoid damaging the appliance.
General information and tips
Environmental information
Subject to change without notice
Contents
3
Page 4
SAFETY INFORMATION
Before the installation and use, read this manual carefully:
• For your personal safety and the safety of your property
• For the respect of the environment
• For the correct operation of the appliance.
Always keep these instructions with the appliance also if you move or sell it.
The manufacturer is not responsible if incorrect installation or use results in damage.
Children and vulnerable people safety
• This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in
safe way and understand the hazards involved. Children shall not play with the appliance.
• Keep all packaging away from children. There is the risk of suffocation or physical injury.
• Keep children and animals away from the appliance when the door is open or the appliance is in operation. There is the risk of injury or other permanent disability.
• If the appliance has Child Lock or Key Lock (Control Lock) function, use it. It prevents
children and animals from accidental operation of the appliance.
General safety
• Do not change the specifications of this appliance. There is the risk of injury and damage to the appliance.
• Do not let the appliance stay unattended during operation.
• Switch off the appliance after each use.
Installation
• Only an approved electrician can install and connect the appliance. Contact an approved service centre. This is to prevent the risks of structural damage or physical injury.
• Make sure that the appliance is not damaged because of transport. Do not connect a
damaged appliance. If necessary, contact the supplier.
• Remove all packaging, stickers and layers from the appliance before first use. Do not
remove the rating plate. It can invalidate the guarantee.
• Make sure that the appliance is disconnected from the power supply during the installation.
• Be careful when you move the appliance. The appliance is heavy. Always use safety
gloves. Do not lift the appliance by the handle.
• The electrical installation must have an isolation device which lets you disconnect the
appliance from the mains at all poles. The isolation device must have a contact opening width of minimum 3 mm.
4
Safety information
Page 5
• You must have correct isolation devices: line protecting cut-outs, fuses (screw type
fuses removed from the holder), earth leakage trips and contactors.
• Before the installation, make sure that the kitchen cabinet has the recess dimensions
applicable.
• Make sure that the appliance is installed below and adjacent safe structures.
• Keep the minimum distances to the other appliances and units.
• The appliance cannot be positioned on a base.
• Built in ovens and built in cooking surfaces are attached with special connection system. To prevent damage to the appliance, only use an appliance with the appliances
from the same manufacturer.
Electrical connection
• The appliance must be earthed.
• Make sure that the electrical data on the rating plate agree with your domestic power
supply.
• Information on the voltage is on the rating plate.
• Always use a correctly installed shockproof socket.
• Do not use multi-way plugs, connectors and extension cables. There is the risk of fire.
• Do not replace or change the mains cable. Contact the service centre.
• Make sure not to squash or cause damage to the mains plug (if applicable) and cable
behind the appliance.
• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug –
if applicable.
Use
• The appliance is only for domestic use. Do not use the appliance for commercial and
industrial use.
• Only use the appliance for domestic cooking tasks. This is to prevent physical injury to
persons or prevent damage to property.
• Do not use the appliance as a work surface or storage surface.
• The interior of the appliance and the accessories become hot during use. There is the
risk of burns. Use safety gloves when you insert or remove the accessories or pots.
• Be careful when you remove or install the accessories to prevent damage to the oven
enamel.
• Always stay away from the appliance when you open the door while the appliance is
in operation. Hot steam can release. There is the risk of skin burns.
• To prevent damage or discoloration to the enamel:
– do not put any objects directly on the appliance floor and do not cover it with alu-
minium foil;
– do not put hot water directly into the appliance;
– do not keep moist dishes and food in the appliance after you finish the cooking.
• Discoloration of the enamel has no effect on the performance of the appliance so it is
not a defect in the sense of the warranty law.
Safety information
5
Page 6
• Do not apply pressure on the open door.
• Always close the appliance door when you cook, even while grilling.
Care and cleaning
• Before maintenance, switch off the appliance and disconnect the appliance from the
power supply.
• Before maintenance, make sure that the appliance is cold. There is the risk of burns.
There is the risk that the glass panels can break.
• Keep the appliance clean at all times. A build-up of fats or other foodstuff can result
in a fire.
• Regular cleaning prevents the surface material from deteriorating
• Use a deep baking tray for very moist cakes to prevent that fruit juices cause stains
that can be permanent.
• For your personal safety and the safety of your property, only clean the appliance with
water and a soap. Do not use flammable products or products that can cause corrosion.
• Do not clean the appliance with steam cleaners, high-pressure cleaners, sharp objects,
abrasive cleaning agents, abrasive sponges and stain removers
• If you use an oven spray, follow the instructions from the manufacturer.
• Do not clean the glass door with abrasive cleaning agents or metal scraper. Heat resistant surface of the inner glass can break and shatter.
• When the door glass panels are damaged they become weak and can break. You must
replace them. Contact the service centre.
• Be careful when you remove the door from the appliance. The door is heavy!
• Do not clean catalytic enamel (if applicable).
Risk of fire
• Open the door carefully. The use of ingredients with alcohol can cause a mixture of
alcohol and air. There is the risk of fire.
• Do not let sparks or open flames come near the appliance when you open the door.
• Do not put flammable products or items that are wet with flammable products, and/or
fusible objects (made of plastic or aluminium) in, near or on the appliance.
Oven lamp
• Bulb lamps used in this appliance are special lamps selected for household appliances
use only. They cannot be used for the full or partial illumination of a household room.
• If it becomes necessary to replace the lamp use one of the same power and specifically designed for household appliances only.
• Disconnect the appliance from the power supply before the replacement of the oven
lamp. There is the risk of electrical shock.
Service centre
• Only an approved engineer can repair or work on the appliance. Contact an approved
service centre.
6
Safety information
Page 7
• Use only original spare parts.
Disposal of the appliance
• To prevent the risk of physical injury or damage
– Disconnect the appliance from the power supply.
– Cut off the mains cable and discard it.
– Discard the door catch. This prevents children or small animals from being closed
inside of the appliance. There is the risk of suffocation.
PRODUCT DESCRIPTION
General overview
2 2
1
3 4 5 6
8
9
11
13 5
4
3
2
1
12
7
10
1 Control panel
2 Lamps/symbols of the cooking zones
3 Power lamp/symbol
4 Control knob for oven functions
5 Control knob for temperature
6 Temperature lamp/symbol/indicator
7 Control knobs for cooking zones
8 Heating element
9 Oven lamp
Product description
7
Page 8
10 Fan and heating element
11 Bottom heat
12 Oven shelf runners, removable
13 Shelf positions
Oven accessories
• Wire shelf
For cookware, cake tins, roasts.
• Baking tray
For cakes and biscuits.
BEFORE FIRST USE
WARNING!
Refer to "Safety information" chapter.
Initial Cleaning
• Remove all parts from the appliance.
• Clean the appliance before first use.
Refer to chapter "Care and Cleaning".
DAILY USE
WARNING!
Refer to "Safety information" chapter.
To use the appliance, press the control knob. The control knob comes out.
8
Before first use
Page 9
Activating and deactivating the appliance
1. Turn the control knob for the oven functions to select an oven function.
2. Turn the control knob for the temperature to select a temperature.
3. To deactivate the appliance turn the control knobs for the oven functions and tem-
perature to off position.
Knob symbol, indicator or lamp (depends on the model - refer to the appliance
overview):
• The indicator comes on when the oven heats up.
• The lamp comes on when the appliance operates.
• The symbol shows whether the knob controls one of the cooking zones, the oven
functions or the temperature.
Oven Functions
Oven function Application
Light Use this function to light up the oven interior.
True Fan Cooking To bake maximum on three oven levels at the same time.
Decrease the oven temperatures (20-40 °C) compared
with Conventional. And to dry food.
Pizza Setting To bake on one oven level food with a more intensive
browning and a crispy base. Decrease the oven temperatures (20-40 °C) compared with Conventional
Conventional Cooking To bake and roast on one oven level.
Bottom Heat To bake cakes with crispy or crusty bases and to preserve
food
Defrost To defrost frozen food.
Grilling To grill flat food in the middle of the grill and to toast.
Fast Grilling To grill flat food in large quantities and to toast.
Turbo Grilling To roast larger joints of meat or poultry on one level. Also
for browning food e.g. gratin.
Cooking zones
You can operate the hob with the control knobs for the cooking zones. Refer to the user
manual for hob.
Hob cooking zones
Indicators for the cooking zones (refer to "General overview ") show which zone you set.
Daily use
9
Page 10
Control knob Function
Keep warm setting
0 Off position
1-9 Heat settings
(1 = lowest heat setting; nine = highest heat setting)
Operating the hob:
1. Turn the temperature control knob to set the temperature.
2. To end the cooking process, turn the control knob to the off position.
Automatic heat-up function
This information is applicable only if you install the hob with Automatic heat up function!
The automatic heat-up function heats the cooking zone with full power for some time.
Activating heat-up function:
1. To activate the function turn the control knob clockwise as far as possible (beyond
the highest heat setting).
2. To continue the cooking process turn the control knob to set the temperature.
3. To end the cooking process turn the control knob to the off position.
USING THE ACCESSORIES
WARNING!
Refer to "Safety information" chapter.
Inserting the Oven Accessories
The wire shelf has side edges. These edges and
the shape of the guide-bars causes the anti-tilt
safety for the oven accessories.
10
Using the accessories
Page 11
ADDITIONAL FUNCTIONS
Cooling fan
When the appliance operates, the cooling fan activates automatically to keep the surfaces of the appliance cool. If you deactivate the appliance, the cooling fan can continue
to operate until the appliance cools down.
HELPFUL HINTS AND TIPS
Examples of cooking applications
The data in the table is for guidance only.
Heat
setting
Use to: Time Hints
1 Keep cooked foods warm as re-
quired
Cover
1-2 Hollandaise sauce, melt: butter, choco-
late, gelatine
5-25
min
Mix occasionally
1-2 Solidify: fluffy omelettes, baked eggs 10-40
min
Cook with a lid on
2-3 Simmer rice and milkbased dishes,
heating up ready-cooked meals
25-50
min
Add at least twice as much liquid
as rice, stir milk dishes part way
through
3-4 Steam vegetables, fish, meat 20-45
min
Add a few tablespoons of liquid
4-5 Steam potatoes 20-60
min
Use max. ¼ l water for 750 g of
potatoes
4-5 Cook larger quantities of food, stews
and soups
60-150
min
Up to 3 l liquid plus ingredients
6-7 Gentle fry: escalope, veal cordon bleu,
cutlets, rissoles, sausages, liver, roux,
eggs, pancakes, doughnuts
as required
Turn halfway through
7-8 Heavy fry, hash browns, loin steaks,
steaks
5-15
min
Turn halfway through
9 Boil large quantities of water, cook pasta, sear meat (goulash, pot roast), deep fry chips
Inner side of door
In some models on the inner side of the oven door you can find:
• the numbers of the shelf levels (selected models)
• information about the oven functions, recommended shelf levels and temperatures
for typical dishes (selected models).
The temperature and baking times in the tables are guidelines only. They depend on the
recipes, quality and quantity of the ingredients used.
Additional functions
11
Page 12
Baking
General instructions
• Your new oven may bake or roast differently to the appliance you had before. Adapt
your usual settings (temperature, cooking times) and shelf levels to the values in the
tables.
• With longer baking times, the oven can be switched off about 10 minutes before the
end of baking time, to use the residual heat.
When you use frozen food, the trays in the oven can twist during baking. When the
trays get cold again, the distortion will be gone.
How to use the Baking Tables
• We recommend to use the lower temperature the first time.
• If you cannot find the settings for a special recipe, look for the one that is almost the
same.
• Baking time can be extended by 10-15 minutes, if you bake cakes on more than one
level.
• Cakes and pastries at different heights do not always brown equally at first. If this occurs, do not change the temperature setting. The differences equalize during the baking procedure.
Baking on one oven level:
Baking in tins
Type of baking Oven function Oven
level
Temperature
°C
Time
Hours:Mins.
Ring cake or brioche True Fan Cooking 1 150-160 0:50-1:10
Madeira cake/fruit cakes True Fan Cooking 1 140-160 1:10-1:30
Sponge cake True Fan Cooking 2 140 0:35-0:50
Sponge cake Conventional Cook-
ing
2 160 0:35-0:50
Flan base - short pastry True Fan Cooking 2
170-180
1)
0:10-0:25
Flan base - sponge mixture True Fan Cooking 2 150-170 0:20-0:25
Apple pie (2tins Ø20cm,
diagonally off set)
True Fan Cooking 2 160 1:10-1:30
Apple pie (2tins Ø20cm,
diagonally off set)
Conventional Cook-
ing
2 180 1:10-1:30
Cheesecake Conventional Cook-
ing
1 170-190 1:00-1:30
1) Pre-heat the oven
12
Helpful hints and tips
Page 13
Cakes/pastries/breads on baking trays
Type of baking Oven function
Oven
level
Temperature °C
Time
Hours:Mins.
Plaited bread/bread crown Conventional
Cooking
3 170-190 0:30-0:40
Christmas stollen Conventional
Cooking
2
160-180
1)
0:50-1:10
Bread (rye bread)
1. First part of baking
proc- ess.
2. Second part of baking
proc- ess.
Conventional
Cooking
1
1.
230
1)
2. 160-180
1. 0:20
2. 0:30-1:00
Cream puffs/eclairs Conventional
Cooking
3
190-210
1)
0:20-0:35
Swiss roll Conventional
Cooking
3
180-200
1)
0:10-0:20
Cake with crumble topping
(dry)
True Fan Cooking 3 150-160 0:20-0:40
Buttered almond cake/sugar
cakes
Conventional
Cooking
3
190-210
1)
0:20-0:30
Fruit flans (made with yeast
dough/sponge mixture)
2)
True Fan Cooking 3 150 0:35-0:50
Fruit flans (made with yeast
dough/sponge mixture)
2)
Conventional
Cooking
3 170 0:35-0:50
Fruit flans made with short
pastry
True Fan Cooking 3 160-170 0:40-1:20
Yeast cakes with delicate
toppings (e. g, quark, cream,
custard)
Conventional
Cooking
3
160-180
1)
0:40-1:20
1) Pre-heat the oven
2) Use the drip tray or roasting tray
Biscuits
Type of baking Oven function
Oven lev-
el
Temperature °C
Time
Hours:Mins.
Short pastry biscuits True Fan Cooking 3 150-160 0:10-0:20
Short bread/ Pastry
Stripes
True Fan Cooking 3 140 0:20-0:30
Short bread/ Pastry
Stripes
Conventional Cooking 3
160
1)
0:20-0:30
Biscuits made with
sponge mixture
True Fan Cooking 3 150-160 0:15-0:20
Helpful hints and tips
13
Page 14
Type of baking Oven function
Oven lev-
el
Temperature °C
Time
Hours:Mins.
Pastries made with egg
white, merungues
True Fan Cooking 3 80-100 2:00-2:30
Macaroons True Fan Cooking 3 100-120 0:30-0:50
Biscuits made with
yeast dough
True Fan Cooking 3 150-160 0:20-0:40
Puff pastries 0:20-0:30
Rolls True Fan Cooking 3
160
1)
0:10-0:25
Rolls Conventional Cooking 3
190-210
1)
0:10-0:25
Small cakes (20per tray) True Fan Cooking 3
140
1)
0:20-0:30
Small cakes (20per tray) Conventional Cooking 3
170
1)
0:20-0:30
1) Pre-heat the oven
Multileveled Baking
Cakes/pastries/breads on baking trays
Type of baking
True Fan Cooking True Fan Cooking
Temperature in °C
Time
Hours:Mins.
Shelf positions from bottom
2 levels 3 levels
Cream puffs/Eclairs 1/4 -
160-180
1)
0:25-0:45
Dry streusel cake 1/4 - 150-160 0:30-0:45
1) Pre-heat the oven
Biscuits/small cakes/pastries/rolls
Type of baking
True Fan
Cooking
True Fan
Cooking
Temperature in °C
Time
Hours:Mins.
Shelf positions from bottom
2 levels 3 levels
Short pastry biscuits 1/4 1/3/5 150-160 0:20-0:40
Short bread/ Pastry Stripes 1/4 1/3/5 140 0:25-0:50
Biscuits made with sponge
mixture
1/4 - 160-170 0:25-0:40
Biscuits made with egg
white, meringues
1/4 - 80-100 2:10-2:50
Macaroons 1/4 - 100-120 0:40-1:20
Biscuits made with yeast
dough
1/4 - 160-170 0:30-0:60
Puff pastries 1/4 -
170-180
1)
0:30-0:50
Rolls 1/4 - 180 0:30-0:55
14
Helpful hints and tips
Page 15
Type of baking
True Fan
Cooking
True Fan
Cooking
Temperature in °C
Time
Hours:Mins.
Shelf positions from bottom
2 levels 3 levels
Small cakes (20per tray) 1/4 -
150
1)
0:25-0:40
1) Pre-heat the oven
Tips on baking
Baking results Possible cause Remedy
The cake is not browned
enough underneath
Wrong oven level Place cake lower
The cake sinks (becomes soggy, lumpy, streaky)
Oven temperature too
high
Use a slightly lower setting
The cake sinks (becomes soggy, lumpy, streaky)
Baking time too short
Set a longer baking time. Baking
times cannot be reduced by setting
higher temperatures
The cake sinks (becomes soggy, lumpy, streaky)
Too much liquid in the
mixture
Use less liquid. Pay attention to mix-
ing times, especially if using mixing
machines
Cake is too dry
Oven temperature too
low
Set oven temperature higher
Cake is too dry Baking time too long Set a shorter baking time
Cake browns unevenly
Oven temperature too
high and baking time
too short
Set a lower oven temperature and a
longer baking time
Cake browns unevenly
Mixture is unevenly dis-
tributed
Spread the mixture evenly on the
baking tray
Cake does not cook in the
baking time given
Temperature too low Use a slightly higher oven setting
Bakes and gratins
Dish Oven function
Shelf po-
sition
Temperature
°C
Time
Hours:Mins.
Pasta bake Conventional Cooking 1 180-200 0:45-1:00
Lasagne Conventional Cooking 1 180-200 0:25-0:40
Vegetables au gratin
Turbo Grilling or True Fan
Cooking
1 160-170 0:15-0:30
Baguettes topped
with melted cheese
Turbo Grilling or True Fan
Cooking
1 160-170 0:15-0:30
Sweet bakes Conventional Cooking 1 180-200 0:40-0:60
Fish bakes Conventional Cooking 1 180-200 0:30-1:00
Helpful hints and tips
15
Page 16
Dish Oven function
Shelf po-
sition
Temperature
°C
Time
Hours:Mins.
Stuffed vegetables
Turbo Grilling or True Fan
Cooking
1 160-170 0:30-1:00
Roasting
Roasting dishes
• Use heat-resistant ovenware to roast (please read the instructions of the manufacturer).
• Large roasting joints can be roasted directly in the grill/roasting pan or on the wire
shelf above the grill/roasting pan (If present).
• Roast lean meats in a roasting tin with a lid. This will keep the meat more succulent.
• All types of meat, that can be browned or have crackling, can be roasted in the roasting tin without the lid.
Roasting with Turbo Grilling
Beef
Type of meat Quantity
Oven func-
tion
Shelf posi-
tion
Temperature
°C
Time mins.
Pot roast 1-1.5 kg
Conventional
Cooking
1 230 120-150
Roast beef or fillet: rare
per cm. of
thickness
Turbo Grilling 1
190-200
1)
5-6
Roast beef or fillet: medium
per cm. of
thickness
Turbo Grilling 1
180-190
1)
6-8
Roast beef or fillet: well done
per cm. of
thickness
Turbo Grilling 1
170-180
1)
8-10
1) Pre-heat the oven
Pork
Type of meat Quantity
Oven func-
tion
Shelf position
Temperature
°C
Time mins.
Shoulder, neck,
ham joint
1-1.5 kg
Turbo Grill-
ing
1 160-180 90-120
Chop, spare rib 1-1.5 kg
Turbo Grill-
ing
1 170-180 60-90
Meat loaf 750 g-1 kg
Turbo Grill-
ing
1 160-170 50-60
Porkknuckle
(precooked)
750 g-1 kg
Turbo Grill-
ing
1 150-170 90-120
Veal
Type of meat Quantity Oven function Shelf position Temperature °C Time mins.
Roast veal 1 kg Turbo Grilling 1 160-180 90-120
16
Helpful hints and tips
Page 17
Type of meat Quantity Oven function Shelf position Temperature °C Time mins.
Knuckle of veal 1.5-2 kg Turbo Grilling 1 160-180 120-150
Lamb
Type of meat Quantity Oven function Shelf posi-
tion
Temperature °C Time mins.
Leg of lamb, roast
lamb
1-1.5 kg Turbo Grilling 1 150-170 100-120
Saddle of lamb 1-1.5 kg Turbo Grilling 1 160-180 40-60
Game
Type of meat Quantity Oven function Shelf po-
sition
Temperature
°C
Time
mins.
Saddle of hare, leg
of hare
up to 1 kg Conventional Cook-
ing
1
230
1)
30-40
Saddle of venison 1.5-2 kg Conventional Cook-
ing
1 210-220 35-40
Haunch of venison 1.5-2 kg Conventional Cook-
ing
1 180-200 60-90
1) Pre-heat the oven
Poultry
Type of meat Quantity Oven function Shelf posi-
tion
Temperature °C Time mins.
Poultry portions 200-250g each Turbo Grilling 1 200-220 30-50
Half chicken 400-500g each Turbo Grilling 1 190-210 35-50
Chicken, poulard 1-1.5 kg Turbo Grilling 1 190-210 50-70
Duck 1.5-2 kg Turbo Grilling 1 180-200 80-100
Goose 3.5-5 kg Turbo Grilling 1 160-180 120-180
Turkey 2.5-3.5 kg Turbo Grilling 1 160-180 120-150
Turkey 4-6 kg Turbo Grilling 1 140-160 150-240
Fish (steamed)
Type of meat Quantity Oven function Shelf position Temperature °C Time mins.
Whole fish 1-1.5 kg Conventional Cooking 1 210-220 40-60
Grilling
Always grill with the maximum temperature setting.
CAUTION!
Always grill with the oven door closed.
Always pre-heat the empty oven with the grill functions for 5 minutes.
Helpful hints and tips
17
Page 18
• Set the shelf in the shelf level as recommended in the grilling table.
• Always set the pan to collect the fat into the first shelf level.
• Grill only flat pieces of meat or fish.
Grilling
Food to be grilled Temperature Oven level
Grilling time (mins.)
1st side 2nd side
Roast beef 210-230 2 30-40 30-40
Filet of beef 230 3 20-30 20-30
Back of pork 210-230 2 30-40 30-40
Back of veal 210-230 2 30-40 30-40
Back of lamb 210-230 3 25-35 20-25
Whole Fish,
500-1000g
210-230 3/4 15-30 15-30
Fast Grilling
Food to be grilled Oven level
Grilling time(mins.)
1st side 2nd side
Burgers 4 8-10 6-8
Pork fillet 4 10-12 6-10
Sausages 4 10-12 6-8
Fillet steaks, veal steaks 4 7-10 6-8
Toast
1)
5 1-3 1-3
Toast with topping 4 6-8 -
1) Pre-heat the oven
Pizza Setting
Type of baking Shelf position Temperature °C Time Mins.
Pizza (thin crust)
2
200 - 230
1)2)
15 - 20
Pizza (with a lot of topping) 2 180 - 200 25 - 35
Tarts 1 180 - 200 40 - 55
Spinach flan 1 160 - 180 45 - 60
Quiche Lorraine 1 170 - 190 45 - 55
Swiss Flan 1 170 - 190 45 - 55
Apple cake, covered 1 150 - 170 50 - 60
Vegetable pie 1 160 - 180 50 - 60
Unleavened bread
2
230 - 250
1)
10 - 20
Puff pastry flan
2
160 - 180
1)
45 - 55
18
Helpful hints and tips
Page 19
Type of baking Shelf position Temperature °C Time Mins.
Flammekuchen (Pizza-like dish from Alsace)
2
230 - 250
1)
12 - 20
Piroggen (Russian version of calzone)
2
180 - 200
1)
15 - 25
1) Pre-heat the oven
2) Use roasting pan
Defrosting Table
Dish
Defrosting time
(mins.)
Further defrosting
time (mins.)
Comment
Chicken, 1000 g 100-140 20-30
Place the chicken on an upturned saucer placed on a
large plate Turn halfway
through
Meat, 1000 g 100-140 20-30 Turn halfway through
Meat, 500 g 90-120 20-30 Turn halfway through
Trout, 150 g 25-35 10-15 -
Strawberries, 300 g 30-40 10-20 -
Butter, 250 g 30-40 10-15 -
Cream, 2 x 200 g 80-100 10-15
Cream can also be whipped
when still slightly frozen in
places
Gateau, 1400 g 60 60 -
Drying - True Fan Cooking
Cover the oven shelves with baking parchment.
Vegetables
Food to be dried Temperature in °C
Oven level
Time in hours (Guideline)
1 level 2 levels
Beans 60-70 3 1/4 6-8
Peppers 60-70 3 1/4 5-6
Vegetables for sour 60-70 3 1/4 5-6
Mushrooms 50-60 3 1/4 6-8
Herbs 40-50 3 1/4 2-3
Fruit
Food to be dried Temperature in °C
Oven level
Time in hours (Guideline)
1 level 2 levels
Plums 60-70 3 1/4 8-10
Apricots 60-70 3 1/4 8-10
Apple slices 60-70 3 1/4 6-8
Helpful hints and tips
19
Page 20
Food to be dried Temperature in °C
Oven level
Time in hours (Guideline)
1 level 2 levels
Pears 60-70 3 1/4 6-9
Information on acrylamides
Important! According to the newest scientific knowledge, if you brown food (specially
the one which contains starch), acrylamides can pose a health risk. Thus, we recommend
that you cook at the lowest temperatures and do not brown food too much.
CARE AND CLEANING
WARNING!
Refer to "Safety information" chapter.
Notes on cleaning:
• Clean the front of the appliance with a soft cloth with warm water and cleaning
agent.
• To clean metal surfaces use a usual cleaning agent
• Clean the oven interior after each use. Thus you can remove dirt more easily and it
does not burn on.
• Clean stubborn dirt with a special oven cleaner.
• Clean all oven accessories (with a soft cloth with warm water and cleaning agent) after each use and let them dry.
• If you have nonstick accessories, do not clean them using an aggressive agents, sharp
edged objects or dishwasher. It can cause a damage to the nonstick coating.
Shelf support
You can remove the shelf support to clean the side walls.
Removing the shelf support
1. Pull the front of the shelf support away
from the side wall.
20
Care and cleaning
Page 21
2. Pull the shelf support from the back of
the side wall to remove it.
To install the shelf support follow the procedure in reverse.
Valid with telescopic runners:
The retaining pins on the telescopic shelf
runners must point to the front!
Oven lamp
WARNING!
There is a risk of electrical shock.
Oven lamp and the lamp glass cover can be hot.
Before you change the oven lamp:
• Deactivate the appliance.
• Remove the fuses from the fuse box or deactivate the circuit breaker.
CAUTION!
Put a cloth on the bottom of the interior of the appliance. It prevents damage to the
lamp glass cover and the cavity.
Replacing the oven lamp:
1. You can find the lamp glass cover at the back of the cavity.
Turn the lamp glass cover counterclockwise to remove it.
2. Clean the glass cover.
3. If necessary, replace the oven lamp with applicable 300°C heat-resistant oven lamp.
Use the same oven lamp type.
4. Install the glass cover.
Oven Ceiling
You can fold down the heating element on the oven ceiling to clean the oven ceiling
easily.
WARNING!
Before you fold down the heating element deactivate the appliance. Make sure that the
appliance is cold. There is a risk of burns!
1
2
Care and cleaning
21
Page 22
Folding down the heating element
1. Remove the shelf support.
2. Hold the heating element with the two
hands at the front
3. Pull it forwards against the spring pres-
sure and out along the support on both
sides.
4. The heating element folds down.
The oven ceiling is ready to clean.
Installing the heating element
1. Install the heating element in opposite
sequence.
Install the heating element correctly on the two sides above the support on the inner
wall of the appliance.
2. Install shelf support.
Oven door and glass panels
To clean the oven door remove it.
CAUTION!
Be careful when you remove the door from the appliance. The door is heavy!
Removing the oven door
1. Open the oven door as far as it goes.
2. Lift up clamping levers (A) on the two
door hinges fully.
3. Close the oven door until the first posi-
tion (angle approximately 45°).
4. Hold of the oven door with one hand on
each side and pull it away from the oven
at an upwards angle.
5. Now you can remove the inner glass
panels and clean them.
To install the door follow the procedure in reverse.
The number of glass panels depends on the model.
CAUTION!
Put the oven door with the outer side down on a soft and level surface to prevent
scratches
Removing and cleaning the door glass panels
1. Remove the oven door.
A
A
22
Care and cleaning
Page 23
2. Hold the door t (B) on the top edge of
the door at the two sides and push inwards to release the clip seal.
3. Pull the door t to the front to remove it.
4. Hold the door glass panels on their top
edge one by one and pull them up out of
the guide
5. Clean the door glass panels.
To install panels follow the procedure in reverse. Install the smaller panel first, then the
larger.
WHAT TO DO IF…
WARNING!
Refer to "Safety information" chapter.
Problem Possible cause Remedy
The cooking zones do
not operate
Consult the operating instructions for the built-in cooking surface
The oven does not heatupThe oven is not switched on Switch on the oven (refer to chapter
"Daily use")
The oven does not heatupThe fuse in the fuse box is
released
Control the fuse. If the fuse is released
more than one time, refer to a qualified electrician.
The oven lamp does not
operate
The oven lamp is defective Replace the oven lamp
Steam and condensation settle on the food
and in the oven cavity
You left the dish in the
oven for too long
Do not leave the dishes in the oven for
longer than 15-20 minutes after the
cooking process ends
If you cannot find a solution to the problem yourself, contact your dealer or the service
centre.
The necessary data for the service centre is on the rating plate. The rating plate is on the
front frame of the oven cavity.
We recommend that you write the data here:
Model (MOD.) .........................................
B
What to do if…
23
Page 24
Product number (PNC) .........................................
Serial number (S.N.) .........................................
ENVIRONMENT CONCERNS
The symbol on the product or on its packaging indicates that this product may not be
treated as household waste. Instead it should be taken to the appropriate collection
point for the recycling of electrical and electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential negative consequences for the
environment and human health, which could otherwise be caused by inappropriate
waste handling of this product. For more detailed information about recycling of this
product, please contact your local council, your household waste disposal service or the
shop where you purchased the product.
Packaging material
The packaging material is environmentally-friendly and recyclable. Plastic parts are
marked with international abbreviations such as PE, PS, etc. Dispose of the packaging
material in the containers provided for this purpose at your local waste management facility.
24
Environment concerns
Page 25
25
Page 26
26
Page 27
27
Page 28
www.aeg-electrolux.com/shop 892945567-C-342010
Loading...
