LAVAMAT 50435
Washing Machine
User information
Dear Customer,
Please read this instruction book carefully before using the appliance.
Please ensure you fully understand the safety instructions on the first
pages of this instruction book.
Retain the instruction book for future reference, and pass it on to any
future owners.
The warning triangle and / or key words (Warning!, Caution!, Impor-
1
tant!) give information that is important for your safety or the function of the appliance is highlighted. It is imperative that this
information is observed.
0 1. This symbol guides you step by step through the operation of the
appliance.
2. ...
This symbol gives you additional information and practical tips on using
3
the appliance.
Tips and information about the economical and environmentally
2
friendly use of the machine are marked with the clover leaf.
In the event of a malfunction, these operating instructions contain
information on how to remedy these faults yourself. See the section
"What to do if ..."
Printed on recycled paper.
Thinking ecologically means acting ecologically ...
2
Contents
CONTENTS
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Environmental tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Description of the Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Front view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Detergent Dispenser Drawer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Program Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Temperature Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Program Option Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
ON/OFF Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Consumption Data and Wash Times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Before the First Wash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Preparing a Wash Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Sorting and preparing a wash load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Washing Types and Care Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Detergent and Conditioners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Which detergent and conditioner? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
How much detergent and conditioner? . . . . . . . . . . . . . . . . . . . . . . . . . 17
Water Softening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Running a Wash Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Brief instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Loading the washing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Add detergent conditioner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Setting the Washing Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Changing the Spin Speed/Selecting Rinse Hold . . . . . . . . . . . . . . . . . . . . . 21
Starting the Washing Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Wash Program Progress . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Changing/Interrupting the Washing Program . . . . . . . . . . . . . . . . . . . . . . . 22
Washing Cycle is complete/Removing Washing . . . . . . . . . . . . . . . . . . . . . . 23
3
Contents
Program Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Washing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Separate Rinse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Separate Conditioning/Starching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Separate Spin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Maintenance and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Detergent Dispenser Drawer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Washing Machine Drum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Main door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Cleaning the drain pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
What to do if ... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
If the washing results are not satisfactory . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Carrying out an emergency emptying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Child Safety Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Installation and connection instructions . . . . . . . . . . . . . . . . 35
Installation Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Installation of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Transporting the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Remove transport packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Installation-Site preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Installation on a Suspended Floor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Levelling the Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
4
Contents
Electrical Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Water connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Water pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Inlet Hose Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Water Drainage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Pump head of greater than 1m . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Warranty conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Service & Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
5
Operating Instructions
OPERATING INSTRUCTIONS
1 Safety
The safety features of AEG electrical appliances comply with accepted
technical standards and the German Appliance Safety Law. However, we
also consider it our obligation as a manufacturer to inform you about
the following safety information.
Prior to initial start-up
• Observe the "Installation and Connection Instructions" in this
instruction book.
• If the appliance is delivered in the winter months and temperatures
are below freezing: Store the washing machine at room temperature
for a few hours before putting it into operation.
Intended Use
• The washing machine is only intended for washing normal domestic
washing. If the appliance is used for any other purpose or incorrectly
operated, the manufacturer accepts no liability for any damages
which may result.
• It is dangerous to alter the specifications or attempt to modify this
product in any way.
• Only use detergents which are suitable for automatic washing
machines, and follow the recommendations of the detergent manufacturer.
• Garments which have been in contact with flammable solvents
should not be washed. Also bear this in mind when washing precleaned washing.
• Do not use the washing machine for dry-cleaning.
• Dyes and bleaching agents may only be used if specifically permitted
by the manufacturer of these products. We cannot be held liable for
any damages.
• This appliance must be connected to the cold water supply only.
• Damage due to frost is not covered by the guarantee. If the washing
machine is located in a room in which below freezing temperatures
may occur, emergency emptying must be carried out (see "carrying
out an emergency emptying“).
6
Operating Instructions
Child Safety
• Packaging materials (e.g. films, styrofoam) can be dangerous for children. There is a risk of suffocation! Keep all packaging well away from
children.
• This appliance is designed to be operated by adults. Do not allow
children to tamper with the controls or play with the appliance.
• Pets and children have been known to climb into washing machines.
Please check the drum before use.
• When disposing of the appliance, cut off the mains cable, and destroy
the plug. Disable the door lock to prevent young children being
trapped inside.
General Safety
• Repairs to washing machines must only be carried out by qualified
personnel. Repairs carried out by inexperienced persons may cause
injury or serious malfunctioning. Contact your local AEG Service
Force Centre.
• Never operate the washing machine if the mains cable is damaged or
the control panel, work top or base area are damaged allowing internal components to be accessible.
• Switch off the appliance and isolate from the mains supply before
carrying out any cleaning or maintenance work.
• Do not use the mains cable to remove the plug from the socket.
Always pull the plug itself.
• Adapters and extension cables must not be used. There is a danger
of overheating!
• Do not clean the washing machine with a water jet. There is a danger
of electric shock!
• During high temperature wash programmes the glass of the door may
become hot. Do not touch!
• Allow the water to cool down before cleaning the drain pump, carrying out emergency emptying or opening the door in an emergency.
• Small animals/pets can chew on power cables and water hoses. This
can lead to the risk of electric shock and water damage to the appliance and property. Keep small animals away from the appliance.
7
Operating Instructions
2 Disposal
Packaging
Dispose of the packaging material correctly. All packaging materials
used are environmentally friendly and can be disposed of without any
danger to the environment.
• Plastic parts can be recycled and are identified as follows:
>PE<
>PS< for polystyrene, e.g. padding (always CFC-free)
>POM< for polyoxymethylene, e.g. plastic clips
• Cardboard packaging is manufactured from recycled paper and
should be deposited in the waste paper collection for recycling.
When disposing of the washing machine!
Cut off the mains cable and destroy the plug. Disable the door catch to
prevent young children becoming trapped inside. Use an authorised
disposal site.
for polyethylene, e.g. the outer covering and the bags in
the interior.
2 Environmental tips
To save water and energy, and to help protect the environment, we recommend that you follow these tips.
• Do not use a pre-wash for normally soiled washing.
• It is more economical to wash full loads.
• When washing small loads, reduce the detergent by half to two
thirds.
• Pre-treat stains, and then wash at a lower temperature.
• Use the energy-saving program when washing light to normally
soiled garments.
• In hard water areas, the use of a water softening agent can reduce
the amount of detergent necessary. See manufacturers recommendations.
8
Description of the Appliance
Front view
Detergent
dispenser
drawer
Operating Instructions
Control panel
Rating plate
(behind door)
Main door
Screw feet
(height-adjustable)
Detergent Dispenser Drawer
Main wash detergent
in powder form and
water softening
agent if required
Stain removers
Flap in front of
drain pump.
Pre-wash detergent/
Soaking agent
Liquid conditioner
(fabric softener,
starch)
9
Operating Instructions
Control panel
ON/OFF button with
power indicator light
STAIN button
SOAKING button
QUICK WASH
Program Selector
The program selector determines
the type of wash cycle (eg. water
level, drum movement, number of
rinses, spin speed) according to
the type of articles to be washed.
Selector dial
Spin speed/RINSE HOLD
Temperature selector
button
Program selector
10
Important! Only turn the program selector in a clockwise
direction!
Programs COTTONS/LINEN
PRE WASH
Pre wash for cottons/linen (approx. 30 minutes, temperature limited to
a maximum of 40 °C). The main wash follows immediately afterwards.
MAIN WASH
Main wash cycle for cottons/linen (cold up to 95 °C).
Operating Instructions
RINSE
Separate rinse followed by spin or rinse hold, eg. for rinsing handwashed cottons/linen.
Rinse hold means: The washing remains in the last rinsing water and is
3
not spun.
CONDITIONER
Separate conditioning, separate starching or separate finishing for
damp cottons/linen (1 rinse, liquid conditioner is flushed in from the
compartment æ followed by spin or rinse hold).
SPIN
Spin after rinse hold or separate spin for handwashed cottons/linen.
EASY-CARES programs
PRE WASH
Pre wash for easy-care fabrics (approx. 30 minutes, temperature limited
to a maximum of 40 °C). The main wash cycle follows automatically.
EASY-CARES
Main wash cycle for easy-care fabrics (cold to 60 °C).
RINSE
Separate rinse followed by spin or rinse hold, eg. for rinsing handwashed easy-care articles.
CONDITIONER
Separate conditioning, separate starching or separate finishing for
damp easy-care fabrics (1 rinse, liquid conditioner is flushed in from
the compartment æ followed by spin or rinse hold).
SPIN
Spin after rinse hold or separate spin for handwashed easy-care articles, woollens and delicates.
Programs WOOL/DELICATES
WOOL
Main wash cycle for machine washable woollens and particularly delicate fabrics (cold to 40 °C).
DELICATES
Main wash cycle for delicates (cold to 40 °C).
11
Operating Instructions
GENTLE RINSE
Separate gentle rinse followed by short spin or rinse hold, eg. for rinsing hand-washed woollens or delicates.
CONDITIONER
Separate gentle conditioning for damp woollens or delicates (1 gentle
rinse, liquid conditioner is washed in from the compartment æ followed by short spin or rinse hold).
Pump out
Water pumped out without spin, eg. after rinse hold.
Temperature Selector
The following settings are possible:
COLD, 30, 40, 50, 60, E, 80, 95 °C.
Position E (Energy-saving program):
2
For lightly or normally soiled cottons, the
energy- saving program (approx. 70 °C) can
be used instead of a wash cycle at 95 °C.
Program Option Buttons
12
The program option buttons are used to adapt the wash program to suit
the degree of soiling of the washing. Program options are not required
for normally soiled washing.
The additional can only be used in conjunction with the COTTONS/
3
LINEN and EASY-CARES programs.
SOAKING
Soaking time approx. 35 minutes;
Temperature limited to a maximum of 40 °C.
SOAKING can be used in conjunction with
program selector settings:
– PRE WASH (COTTONS/LINEN);
– PRE WASH (EASY-CARES ).
At the end of the soaking program the washing will remain in the water
until you release the SOAKING button by pressing it again. The main
wash cycle for COTTONS/LINEN or EASY-CARES will follow.
STAIN
For dealing with heavily soiled or stained
washing (in-wash stain treatment is added
at the optimum time during the course of
the program).
STAIN can be used in conjunction with the
program selector settings:
– PRE WASH (COTTONS/LINEN);
– PRE WASH (EASY-CARES );
– MAIN WASH;
– EASY-CARES.
QUICK WASH
Shorter washing cycle for lightly soiled
washing.
QUICK WASH can be used in conjunction
with the program selector settings:
– MAIN WASH;
– EASY-CARES.
ON/OFF Button
Operating Instructions
Pressing the ON/OFF button switches the washing
machine on and starts the selected program. Pressing
the button again switches the washing machine off.
13
Operating Instructions
Consumption Data and Wash Times
The values given in the following table for selected programs were calculated under standardized conditions. They provide a useful guide for
operation in the home.
Program Selector
COTTONS/LINEN
MAIN WASH
COTTONS/LINEN
MAIN WASH
COTTONS/LINEN
MAIN WASH
EASY-CARES 40 2.5 45 0.40 65
DELICATES 30 2.5 40 0.25 40
WOOL 30 2 43 0.25 50
1) Note: The selected program is tested in accordance with EN 60 456. The consumption values, however, can deviate depending on the following: water pressure, water hardness, water inlet temperature, room temperature, washing type
and quantity, the detergent used, fluctuations in the mains voltage and the
selected program options.
Tempera-
ture Selector
95 5 57 1.90 140
1
60
40 5 54 0.60 11 5
Load in kg
5 54 0.95 128
Water
in Litres
Energy
in kWh
Before the First Wash
0 1. Pull the washing powder drawer out slightly.
2. Pour about 1 litre of water through the detergent disperser drawer into
the washing machine. The next time a program is started the solution
container will be closed and the OKO valve can function correctly.
3. Run one wash cycle without washing:
– MAIN WASH Program;
– Temperature 95 °C;
– use half the quantity of detergent recommended by the manufac-
turer for a full load.
This removes any residues from the drum and solution container which
may have been left during manufacturing.
Time in
Minutes
14
Operating Instructions
Preparing a Wash Load
Sorting and preparing a wash load
• Sort washing according to the care symbol and type (see "Washing
types and care symbols").
• Empty all pockets.
• Remove metal objects (paper clips, safety pins etc.).
• In order to prevent bunching up of washing and damage to washing,
close zippers, button up duvet covers and pillow cases, and tie up
loose straps such as from aprons.
• Turn articles with double layered textiles inside out (sleeping bags,
anoraks etc.).
• Coloured, knitted fabrics, as well as wool and fabrics with appliqués
should be turned inside out.
• Place small and delicate items (e.g. socks, tights and stockings, bras
etc.) in a washing net, or pillow case.
• Handle curtains with care. Metal rollers or burred, plastic rollers must
be removed or tied into a net or bag. We cannot accept liability for
damage.
• Do not wash coloured and white washing together. This could discol-
our white washing or turn it grey.
• New, coloured washing often contains excessive dye. Wash these sep-
arately the first time.
• Mix small and large items of washing. This improves washing effi-
ciency and the washing is more evenly distributed during the spin-
ning cycle.
• Shake out washing before placing into the washing machine.
• Do not place folded washing into the drum.
• Observe tips such as "wash separately“ and "wash separately several
times".
15
Operating Instructions
Washing Types and Care Symbols
The care symbols help you choose the correct washing program. Washing should be sorted according to type and care symbol. The temperatures indicated in the care symbols are all maximum temperatures.
Cottons ç
Fabrics made from cotton and linen with this care symbol will withstand maximum wash actions and high temperatures. The COTTONS/
LINEN program is appropriate for this type of washing.
Linen è ë
Fabrics made from cotton and linen which carry this care symbol will
withstand maximum wash actions. The COTTONS/LINEN program is
appropriate for this type of washing.
Easy-care washing ê í
Fabrics such as treated cotton, cotton mixed fabrics, viscose and synthetics which carry this care symbol need a softer wash action. The
EASY-CARES program is appropriate for this type of washing.
Delicates ì
Fabrics such as those with layered fibres, micro fibres, viscose, synthetics,
as well as curtains with this care symbol require particularly careful handling. The DELICATES program is appropriate for this type of washing..
16
Woollens and particularly delicate washing 9 ì
Fabrics such as wool, wool mixtures and silk which carry these care
symbols require a very gentle wash cycle. The WOOL program is appropriate for this type of fabric.
Important! Fabrics with care symbols ï (Handwash) or ñ (Do not
wash!) must not be washed in washing machines.
Operating Instructions
Detergent and Conditioners
Which detergent and conditioner?
Use only detergents and conditioners which are suitable for use in
automatic washing machines. Always follow the manufacturer's
instructions.
How much detergent and conditioner?
The required quantity depends upon:
• the extent of soiling of the washing
• the hardness class of the mains water
• the amount of washing
Should the detergent manufacturer not specify the dosage quantity for
2
less than full loads, reduce the detergent accordingly:
for a half load reduce the quantity by 1/3.
for a small load reduce the quantity by 1/2.
Observe the instructions for use and dosing provided by the detergent
and conditioner manufacturer.
Water Softening
For medium to high water hardness (hardness class II upwards) a watersoftening agent can be used. Refer to the manufacturer's instructions.
Then always add the appropriate amount of detergent (underdosing)
for hardness class I (soft). Your local Water Authority can advise you on
the hardness of the water in your area.
Water hardness scales
Water Hardness in °dH
Hardness Category
I – soft 0 - 7 to 125
II – medium hard 7 - 14 125 - 250
III – hard 14 - 21 250 - 375
IV – very hard greater than 21 Greater than 375
(German degrees of
hardness)
Water Hardnness in ppm
(Parts Per Million)
17
Operating Instructions
Running a Wash Cycle
Brief instructions
A wash cycle consists of the following steps:
0 1. Open the door and load the washing.
2. Close the door.
3. Add detergent/conditioner.
4. Set the wash program:
– Set the program using the program selector;
– Set the temperature using the temperature selector;
– Set any program options if required.
5. If necessary, change the spin speed or select RINSE HOLD.
You can alter this setting and the temperature at any time during the
wash.
6. Press the ON/OFF button. Power indicator light comes on.
The washing machine has been switched on. The wash program will
start.
When the wash program has ended:
Important! If the wash cycle ended with a rinse hold, carry out PUMP
OUT or SPIN before opening the door.
For safety reasons, the door remains locked for 1-2 minutes after the
3
end of the program.
7. Open the door and remove the washing.
8. Press the ON/OFF button. The power indicator light will go out.
The washing machine has been switched off.
Loading the washing
See "Program Tables" for maximum loads.
3
For information about the correct preparation of the washing see "Sort
and prepare washing".
0 1. Sort and prepare the washing according to type.
2. Open the door: Pull the handle on the door.
3. Load the washing.
Important! Do not trap washing when closing the door. The fabrics and
the machine could be damaged.
4. Close the door firmly.
18
Operating Instructions
Add detergent conditioner
For instructions concerning detergents and conditioners see section
3
“Detergents and conditioners”.
0 1. Pull the detergent dispenser drawer out as far as it will go.
2. Add detergent/conditioner
Compartment for in-wash
stain treatment
(only for additional
program STAIN)
Compartment for main wash
detergent (powder only) and
water softener if required
(If you are using water softener,
add it to the main wash detergent.)
Compartment for liquid care agent
(Conditioner, finisher, starch)
Important! Do not fill the compartment above the MAX mark.
Dilute viscous agent if necessary up to
the MAX mark, and dissolve starch powder.
Compartment for pre-wash agent/soaking agent
(only for PRE WASH or SOAKING programmes)
3. Push the detergent dispenser drawer in fully.
If using liquid detergent/tablets
3
Use containers supplied by the detergent manufacturers to add liquid
detergent or tablets. Follow the instructions on the washing detergent
package.
19
Operating Instructions
Setting the Washing Program
See “Program Tables” for a suitable program, correct temperature and
3
possible program options to suit the type of washing.
Important! Only turn the
program selector in a clockwise
direction.
0 1. Set the program selector to the
desired wash program.
2. Set the temperature selector to the
desired temperature.
3. Select program options if required:
• SOAKING can be used in conjunction with the
program settings:
– PRE WASH (from COTTONS/LINEN program group);
– PRE WASH (from EASY-CARES program group).
• STAIN can be used in conjunction with the
program settings:
– PRE WASH (from COTTONS/LINEN program group);
– PRE WASH (from EASY-CARES program group).
– MAIN WASH;
– EASY-CARES.
• QUICK WASH can be used in conjunction with the
program settings:
– MAIN WASH;
– EASY-CARES.
20
Operating Instructions
Changing the Spin Speed/Selecting Rinse Hold
0 If required, change the spin speed for
the final spin speed or select RINSE
HOLD: Turn the selector dial to the
required speed or to RINSE HOLD.
If RINSE HOLD is selected, the washing remains in the final rinse water. It
is not spun.
If the set spin speed is too high for the selected wash program, the final
3
spin speed will be adjusted automatically:
– COTTONS/LINEN 1000 revolutions per minute
– EASY-CARES 850 revolutions per minute
– DELICATES 650 revolutions per minute
– WOOL 850 revolutions per minute
The speed of the intermediate spin is dependent on the selected program and cannot be changed.
Starting the Washing Program
0 1. Check that the water tap is open.
2. Press ON/OFF button. The power indicator
light will come on.
The washing machine has been switched on.
The wash program will start.
21
Operating Instructions
Wash Program Progress
Program progress display
The program selector is also a
program progress display. It turns
clockwise as the program
progresses until it ends, showing
the stage of the program that is
currently being carried out.
The speed at which the program
selector turns varies.
Changing/Interrupting the Washing Program
Changing settings
Whilst the wash program is in progress you can
– change the spin speed;
– select RINSE HOLD.
To select a different program you must first interrupt the program that
is running and then re-set.
Interrupting the wash program
0 1. Press ON/OFF button. The power indicator light will go out.
2. Turn the program selector clockwise either to PUMP OUT or to SPIN.
3. Press ON/OFF button again. The power indicator light will come on.
Water is:
– pumped out or
– pumped out and the washing then spun.
22
Operating Instructions
Washing Cycle is complete/Removing Washing
A wash program normally ends with the final spin.
If SOAKING has been selected:
0 Release the SOAKING button (main wash for COTTONS/LINEN or EASY-
CARES will run).
If RINSE HOLD has been selected:
The water must first be pumped out or the washing must still be spun.
0 Either turn the spin speed selector dial to the required speed
(water will be pumped out and the washing spun according to the program that has been run; the spin speed can still be changed even during the spin),
or
turn the program selector clockwise to PUMP OUT
(water is pumped out without spinning),
or
turn the program selector clockwise to SPIN
(water is pumped out and the washing spun at the set speed; the spin
speed can still be changed even during the spin).
Once the program is completed:
For safety reasons, the door remains locked for 1-2 minutes after the
3
end of the program.
0 1. Open the door.
2. Remove the washing.
3. Press ON/OFF button. The power indicator light will go out.
The washing machine has been switched off.
4. Turn off the water tap.
5. Pull the washing detergent dispenser drawer out slightly to allow it to
dry. Leave the door ajar so that air can circulate in the drum.
Important! If the washing machine is not to be used for a long period:
Close the water tap and disconnect the washing machine from the
electricity mains.
23
Operating Instructions
Program Tables
Not all possible settings are listed below, only those which are useful
and meaningful in everyday use.
Washing
Type of Washing
Care Symbols
Cottons
ç
Energy-saving
program:
Cottons ç
Linen
èë
Easy-cares
êí
Delicates
ì
Woollens
9 ì
2)
Max. Load
(dry weight)
5kg
5kg
5kg
2.5kg
2.5kg
(or 15-20m
Net curtains)
2kg WOOL COLD to 40
Program
1)
Selector
PRE WASH 60 to 95
MAIN WASH 60 to 95
PRE WASH
MAIN WASH
PRE WASH 30 to 60
MAIN WASH 30 to 60
PRE WASH 30 to 60
EASY-CARES 30 to 60
2
DELICATES COLD to 40
Temperature
Selector
E
Possible
Program
Options
SOAKING
STAIN
STAIN
QUICK WASH
SOAKING
STAIN
STAIN
QUICK WASH
SOAKING
STAIN
STAIN
QUICK WASH
SOAKING
STAIN
STAIN
QUICK WASH
24
1) A 10 litre bucket holds approximately 2.5kg of dry washing (cotton).
2) Woollen articles with a woolmark may only be washed in the machine if the label
also states “machine-washable”.
This machine is capable of washing 5.5 kg, however, to achieve optimum wash results it is recommended that the wash loads quoted in this
instruction book are adhered to.
Separate Rinse
Operating Instructions
Type of Washing
Cottons/Linen 5kg RINSE
Easy-cares 2.5kg RINSE
Delicates 2.5 kg
Woollens 2kg
Max. Load
(dry weight)
Separate Conditioning/Starching
Type of Washing
Cottons/Linen 5kg CONDITIONER
Easy-cares 2.5kg CONDITIONER
Delicates 2.5 kg
Woollens 2kg
Max. Load
(dry weight)
Separate Spin
Type of Washing
Max. Load
(dry weight)
Program Selector
GENTLE RINSE
Program Selector
CONDITIONER
Program Selector
Cottons/Linen 5kg SPIN
Easy-cares 2.5kg
SPINDelicates 2.5 kg
Woollens 2kg
25
Operating Instructions
Maintenance and Cleaning
Control panel
Important! Do not use household furniture polish or abrasive cleaners
to clean panel and operating parts.
0 Wipe over the operating panels with a damp cloth. Use warm water.
Detergent Dispenser Drawer
The detergent dispenser drawer should be cleaned from time to time.
0 1. Pull the detergent dispenser drawer out as far as it will go.
2. Remove the detergent dispenser drawer by pulling sharply.
3. Take the conditioner insert out of the
middle compartment.
4. Clean the conditioner insert under
running water.
5. Clean the separate compartments
with warm water. It is best to use
a flat brush.
6. Push on the conditioner insert
as far as it will go so that it is
securely in place.
26
Operating Instructions
7. Use a brush to clean the entire
compartment area of the washing
machine, particularly also the
nozzles on the top side of the
compartment.
8. Set the detergent dispensing
drawer into the guide tracks and
push it in.
Washing Machine Drum
The washing machine drum is made from rust-free stainless steel. Any
objects left in the laundry which are likely to rust can stain the drum.
Important! Do not clean the stainless steel drum with descaling agents
containing acids, scouring agents containing chlorine or iron, or steel
wool. Your local AEG Service Force Centre has suitable agents available.
0 Remove any rust stains on the drum using a stainless steel cleaning
agent.
Maintenance Wash
With the use of low temperature washes it is possible to get a build up
3
of residues inside the drum.
We recommend that a maintenance wash be performed on a regular
basis.
To run a maintenance wash:
The drum should be empty of laundry.
0 1. Select the hottest cotton wash program.
2. Use a normal measure of detergent, must be a powder.
Main door
0 Regularly check to see if there are deposits or foreign objects in the
rubber seal behind the door, and remove them.
27
Operating Instructions
Cleaning the drain pump
Paper clips, nails and so on can sometimes get into the washing
machine with the washing and remain in the drain pump casing. Fluff
and strands of fabric can gather on these items and block the drain
pump.
Therefore the drain pump should be cleaned at least once a year.
Warning! Switch off the washing machine and pull out the mains plug
1
before cleaning the drain pump.
0 1. First carry out emergency emptying (see section "Carrying out emer-
gency emptying“).
2. Place a towel on the floor in front of the cover of the drain pump.
Surplus water may flow out.
3. Unscrew the drain pump cover anticlockwise and pull it out.
4. Remove any foreign bodies from the
pump housing.
5. Replace the cover. Insert the webs on
the cover laterally into the guide slots
and screw on the cover securely clockwise.
6. Close the emergency emptying hose and
place it in the holder.
7. Close the flap.
28
Operating Instructions
What to do if ...
Trouble Shooting
Try to rectify minor faults on the washing machine with the aid of the
instructions given here. If you call out an engineer to resolve a fault
listed here, or to repair a fault caused by incorrect use or installation, a
charge will be made even if the appliance is under guarantee.
Problem Possible Cause Remedy
The washing machine
does not work.
Door cannot be closed.
The machine does not
take in water.
Excessive foaming during the main wash.
The mains plug is not
plugged in.
The house fuse has blown. Replace the fuse.
The door is not closed correctly.
The child safety feature is
set.
The door is not correctly
closed.
Water tap is closed. Open the water tap.
Filter in screw connection of
the inlet hose is blocked.
Probably too much detergent
was used
Insert the mains plug.
Close the door; The lock must
engage audibly.
Cancel the child safety feature (see the section “Child
Safety Feature”).
Close the door; The lock must
engage audibly.
Close the water tap. Unscrew
the hose from the tap,
remove the filter and clean it
under running water.
It may be necessary to
reduce the amount of detergent used. Follow the detergent manufacturer's
recommendations.
29
Operating Instructions
Problem Possible Cause Remedy
The washing machine
vibrates during operation or is unstable.
Water runs out from
under the washing
machine.
The transport packaging has
not been removed.
The machine is not level.
There is very little washing in
the drum (e.g. only one
dressing gown).
The water could not be completely pumped out before
spinning because
the drain hose is kinked or
the drain pump is blocked.
The screw connection on the
inlet hose is leaking.
The drainage hose is leaking.
The drain pump cover is not
correctly closed.
Washing is caught in the
door.
Remove transport packaging
according to the installation
and connection instructions.
Adjust the feet according to
the installation and connection instructions.
This does not impair the
function.
Check the drain hose and
remove any kink if necessary,
or clean the drain pump and,
if required, remove foreign
bodies from the pump housing.
Tighten the inlet hose screw
connection
Check the drainage hose and
replace it if necessary.
Close cover correctly.
Stop the program and
remove the washing caught
in the door. Restart the program.
30
The washing machine
does not spin; there is
water in the drum.
The emergency emptying
hose is not correctly sealed
or is leaking.
RINSE HOLD has been
selected.
Soaking program has finished.
Seal the emergency emptying hose correctly (see section “Carrying Out an
Emergency Emptying“). Call
your local AEG Service Force
Centre if the emergency
emptying hose leaks.
Cancel RINSE HOLD.
Release SOAKING button
(main wash program will follow).
Operating Instructions
Problem Possible Cause Remedy
Fabric softener was not
washed into machine;
drawer æ for conditioner is filled with
water.
Washing is heavily
creased
Washing has not been
spun properly. Water is
left in the drum.
Remnants of detergent
are building up in the
detergent dispenser
drawer.
The conditioner insert has
not been correctly positioned
inside the conditioner compartment or is blocked.
Probably too much washing
was put into the drum.
Drain hose is kinked. Remove the kink.
Maximum pump head (discharge height 1 m from the
appliance’s base) is exceeded.
Drain pump is blocked.
Water tap is not fully open. Open the water tap fully.
The inlet hose filter in the
coupling inlet hose at the
tap is blocked.
Clean the detergent dispenser drawer and attach the
conditioner insert securely.
Pay attention to the maximum load quantity (see Program tables). In the case of
easy-care fabrics, select the
EASY IRON program.
Contact your local Service
Force Centre. For pumping
heights over 1 m a conversion kit is available as a special accessory.
Switch off the appliance and
pull out the mains plug.
Clean the drain pump.
Close the water tap. Unscrew
the inlet hose from the water
tap and from the appliance.
Clean the filter.
The rinsing water is
cloudy.
Door cannot be
opened.
The cause is probably a
detergent with a high silicate
content.
Door is locked for safety reasons.
No negative effect on the
rinse results; use a liquid
detergent if necessary.
Wait for 1 or 2 minutes after
the end of the program.
31
Operating Instructions
If the washing results are not satisfactory
If the washing turns greyish and limescale deposits are present in
the drum
• Insufficient detergent has been added.
• Incorrect detergent was used.
• Stains were not pre-treated.
• Program or temperature was not set correctly.
• If using modular detergents, the individual components were not
used in the correct ratio.
If there are still grey stains on the washing
• Soiled garments with ointments, grease or oils were washed with
insufficient detergent.
• The temperature selected for the wash was too low.
• A frequent cause is that fabric softener - particularly a concentrated
one - has come into contact with the washing. Wash out these types
of stains as soon as possible and use the fabric softener carefully.
If after the last rinse foam is still visible
• Modern detergents can still cause foam in the final rinse cycle. How-
ever, the washing is still sufficiently rinsed.
32
If there are white residues on the washing
• These are insoluble contents of modern detergents. They are not the
result of an insufficient rinse. Shake out the washing or brush it off.
Turn the washing inside out before washing it. Review your choice of
detergent and if necessary use liquid detergent.
Operating Instructions
Carrying out an emergency emptying
• If the washing machine no longer pumps out the water, emergency
emptying must be carried out.
• If the washing machine is located in a room in which below freezing
temperatures might occur, emergency emptying must be carried out.
Furthermore: unscrew the inlet hose from the water tap and drain off
the water. Empty the drainage hose.
Warning! Switch off the washing machine and pull out the mains plug
1
prior to performing emergency emptying.
Warning! The water, which flows out of the emergency emptying hose
can be hot. First allow the water to cool down before you carry out the
emergency emptying.
0 1. Have a flat container on hand to catch the water.
2. Pull down the flap in the right corner of
the base strip outwards and pull it off.
3. Remove the emergency emptying hose
from its holder.
4. Place the container under the hose.
5. Detach the plug of the emergency emp-
tying hose by turning it anticlockwise
and pull it out.
The water runs out. Depending on the
amount of water, it may be necessary to
empty the collecting vessel several
times. To do this, close the emergency
emptying hose temporarily with the
plug.
Discard the water from the container, replace it under the emergency
emptying hose and remove the plug from the hose.
33
Operating Instructions
When the water is completely drained:
6. Push the plug securely into the emergency emptying hose and turn it
clockwise to secure it.
7. Replace the emergency emptying hose in its holder.
8. Put on the flap and close.
Child Safety Feature
If the child safety feature is set,
the door cannot be closed and no
washing program can be started.
Setting the child safety feature
0 Use a coin to turn the rotary knob
on the inside of the door clockwise as far as it will go.
Warning! The rotary knob must
1
not be in a vertical position after
adjustment, otherwise the child
safety feature is not active. The
rotary knob must project as shown
in the diagram.
Cancelling the child safety
feature
0 Turn the rotary knob anticlockwise
as far as it will go.
34
Installation and connection instructions
INSTALLATION AND CONNECTION
INSTRUCTIONS
Installation Safety Precautions
• When moving do not tilt the washing machine onto its front or onto
its right hand side (viewed from the front). This is to prevent the possibility of the electronic components becoming wet.
• Before installation inspect the machine for transport damage. Do not
connect the appliance if it is damaged - contact your retailer.
• Ensure all packaging and transit bolts/bars have been removed, see
„Removal of Transit Packaging“. Failure to remove transit bolts/bars
may cause serious damage to the appliance or property.
• Always insert the plug into a correctly installed earthed socket.
• Any plumbing work required to install this appliance should be
carried out by a plumber or competent person.
• Check that the electricity supply is the same as that indicated on the
appliance´s rating plate.
• Any electrical work required to install this appliance should be carried
out by an electrician or competent person.
35
Installation and connection instructions
Installation of the appliance
Transporting the appliance
• Do not place the washing machine on its front or on its right hand
side (viewed from the front). This is to prevent the possibility of the
electronic components becoming wet.
• Never transport the unit without the transport packaging and bolts/
bars. Do not remove the transport packaging until the appliance is at
the installation location. Transporting the unit without the transport
packaging can damage it.
• Never lift the appliance by the door.
• When transporting the unit with a sack trolley: Attach the sack trol-
ley at the side only.
Remove transport packaging
Important! It is essential to
remove the transport packaging
before putting the appliance into
operation. Keep all parts of the
transport packaging in a safe
place for future use.
0 1. Open both hose holders on the
appliance's rear side and remove
the hoses and mains cable.
2. Pull both hose holders off the
appliance with a strong pull.
36
The special spanner (E) and the
3
caps (D) (2 each) and (G) (1 each)
are supplied with it.
3. Remove the two screws (A) with
the special spanner.
4. Remove the 4 screws (B).
5. Remove the transit bar (C).
6. Screw the 4 screws (B) back in for
safe keeping.
7. Close the 2 large holes with the
caps (D).
Important! When fitting the
plastic caps, press until they snap
into the rear panel securely.
8. Remove the screw F, including the
sleeve, compression spring and
washer, with the special spanner
E.
9. Cover the hole with the cap G.
Important! When fitting the
plastic caps, press until they snap
into the rear panel securely.
Installation and connection instructions
37
Installation and connection instructions
Installation-Site preparation
• The installation surface must be clean, dry and level. Do not install on
a deep pile carpet.
• Minor unevenness of the floor surface should never be levelled out by
laying pieces of wood, card or similar materials, but should always be
compensated for by adjusting the screw feet.
• If the appliance is installed next to a heat source (e.g. cooking appli-
ance), a heat insulating pad (87 x 57 cm) must be placed between the
appliance and the heat source.
• Do not install the appliance in locations where the temperature may
fall below freezing.
• Please ensure that when the appliance is installed it is easily accessi-
ble for the engineer in the event of a breakdown.
Installation on a Suspended Floor
Suspended wooden floors are particularly susceptible to vibration. To
help prevent vibration we recommend you place a waterproof wood
panel, at least 15 mm thick under the appliance, secured to at least
2 floor beams with screws. If possible install the appliance in one of the
corners of the room, where the floor is more stable.
38
Installation and connection instructions
Levelling the Appliance
Floor unevenness can be compensated for and the height can be corrected with the four adjustable screw feet. The height can be adjusted
in a range of +10 ... -5 mm.
To adjust the feet use the special spanner supplied.
0 1. Slide the special key firmly onto
the hexagon head of the
threaded foot as far as it will go.
2. Adjust the screw feet so that the
appliance is horizontal and stable.
3. Check that the appliance is level
using a spirit level.
Important. Never use strips or
shins of wood or cardboard etc.
To compensate for any unevenness in the floor. Always use the
adjustable feet.
39
Installation and connection instructions
Electrical Connection
Any electrical work required to install this appliance should be carried
out by a qualified electrician or competent person.
WARNING - THIS APPLIANCE MUST BE EARTHED.
1
The manufacturer declines any liability should these safety
measures not be observed.
Before switching on, make sure
the electricity supply voltage is
the same as that indicated on the
appliance rating plate.
The rating plate is located at the
top of the rim of the open door.
The appliance is supplied with a
13amp plug fitted. In the event of
having to change the fuse in the
plug supplied, a 13amp ASTA
approved (BS 1362) fuse must be
used.
Should the plug need to be replaced
for any reason, proceed as described
below.
The wires in the mains lead are
coloured in accordance with the
following code:
Blue
Green & Yellow
Brown
40
Green and Yellow: Earth
Blue: Neutral
Brown: Live
• The wire coloured green and yellow must be connected to the termi-
nal marked with the letter “E“ or by the earth symbol or coloured
green and yellow.
• The wire coloured blue must be connected to the terminal “N“ or
coloured black.
• The wire coloured brown must be connected to the terminal marked
“L“ or coloured red.
• Upon completion there must be no cut, or stray strands of wire
present and the cord clamp must be secure over the outer sheath.
Cord Clamp
Installation and connection instructions
WARNING! A cut off plug inserted into a 13 amp socket is a
1
serious safety (shock) hazard. Ensure that the cut off plug is
disposed of safely.
Permanent Connection
In the case of a permanent connection it is necessary that you install a
double pole switch between the appliance and the electricity supply
(mains), with a minimum gap of 3 mm between the switch contacts
and of a type suitable for the required load in compliance with the
current electrical regulations.
The switch must not break the yellow and green earth cable at any
point.
This appliance is in accordance with the following EU Guidelines:
;
– Low Voltage Guidelines 73/23 EEC dated 19 February 1973, include
Guideline Change Notice 93/68 EEC
– EMC Guideline 89/336 EEC dated 3 May 1989, including Guideline
Change Notice 92/31 EEC.
This appliance complies with the requirements laid out in the EEC
Directive 76/899.
Voltage 240 V AC: Fuse rating 13 amps
See rating plate for further information.
This appliance meets VDE requirements.
Particular regulations of local electricity authorities must be observed.
This appliance conforms to EEC Directive No. 82/499/EWG on radio
interference.
WARNING! Repairs to electrical appliances must only be carried out by
1
trained personnel. Improper repairs may lead to serious risks for the
user.
41
Installation and connection instructions
Water connection
The washing machine is provided with safety devices preventing back-
3
contamination of the water supply and complies with local water
authority requirements.
This appliance is designed to be permanently plumbed into your home’s
water supply.
Before connecting up the machine to new pipework or to pipework
that has not been used for some time, run off a reasonable amount of
water to flush out any debris that may have collected in the pipes.
Important!
– Appliances for connecting to cold water must not be connected to
hot water.
– Only use new hose sets for the connection.
Water pressure
The appliance is designed to operate within the following water
pressure units. Minimum 1 bar (= 10N/cm
10 bar (= 100N/cm
• If more than 10 bar: Install a pressure-reduction valve upstream
• If less than 1 bar: Unscrew the inlet hose from the appliance at the
inlet solenoid valve and remove the flow regulator (to do this, remove
the filter with needle nose pliers and remove the rubber washer
behind the filter). Replace the filter.
2
= 1 Mpa).
2
= 0.1 Mpa), maximum
42
Installation and connection instructions
Inlet Hose Connection
A pressure hose of 1.35m in length is supplied.
If a longer inflow hose is required, only a VDE-approved, complete set
of hoses with fitted hose screw connections is permissible, available
from AEG Service Force Centres.
– Hose sets in lengths of 2.2 m, 3.5 m, and 5 m are available for washing
machines without Aqua-Control.
– Hose sets in lengths of 2.0m, 2.9m and 3.9m are available for wash-
ing machines with Aqua-Control.
Important! Never cut into pieces in order to extend the hoses!
Sealing rings are supplied either in the plastic
3
nuts of the hose screw connection or in the
enclosed pack. Do not use other seals!
0 1. Connect the hose with the angled connection to
the machine.
Important!
– Do not lay the inlet hose verti-
cally downwards, instead run it
to the right or left as shown in
the diagram.
– Only tighten the hose screw
connection by hand.
2. Connect the hose with the straight connection
to a water tap with a screw thread R 3/4 (inches)
Important! Only tighten the screw connection
by hand.
3. By slowly opening the water tap before putting
the washing machine into operation, check that
the connection is free of leaks.
43
Installation and connection instructions
Water Drainage
The appliance drain hose should hook into a standpipe, the hook in the
drain hose is formed using the plastic “U-Piece“ supplied. The standpipe
should have an internal diameter of approximately 38 mm (see diagram) thus ensuring there is an air break between the drain hose and
standpipe.
Important! It is essential to lay
the drainage hose without kinks.
When discharging into a standpipe ensure that the top of the
curve in the hose end is no more
than 90 cm (35.4’’) and no less
than 60 cm (23.6’’) above floor
level.
44
The upright standpipe should
have a minimum, length of
30 cm (12’’) from the bottom of
the elbow to the top of the pipe
(see diagram). Make sure that it is
designed in such a way that the
end of the drain hose cannot be
covered with water.
Longer drain hoses are available
in lengths of 2.7 and 4 metres
from your AEG Service Force
Centre.
Installation and connection instructions
If you intend the drain hose from
the washing machine to empty
into a sink, make sure that the
sink is empty and the plug hose
is not blocked. Use the plastic
“U-Piece“ supplied.
Important! The end of the
drainage hose must not be
submerged in the pumped-out
water. Otherwise, the water
could be sucked back into the
appliance.
Pump head of greater than 1m
Every washing machine includes a wash water pump for the removal of
wash and rinse water, which can pump fluids through the outlet hose
up to a height of 1m, measured from the surface on which the machine
stands.
For pump heads of greater than 1m please contact your local
AEG Service Force Centre.
45
Installation and connection instructions
Technical data
Height Adjustment approx. +10 / -5mm
Load (depending on the program) max. 5kg
Area of use Domestic
Drum speed, spinning see rating plate
Water pressure 1-10bar
(=10-100 N/cm
Dimensions
2
= 0.1-1.0 Mpa)
46
(dimensions in mm)
Warranty conditions
WARRANTY CONDITIONS
Great Britain
Guarantee Conditions
AEG offer the following guarantee to the first purchaser of this appliance.
1. The guarantee is valid for 12 months commencing when the appliance is handed over
to the first retail purchaser, which must be verified by purchase invoice or similar documentation.
The guarantee does not cover commercial use.
2. The guarantee covers all parts or components which fail due to faulty workmanship or
faulty materials. The guarantee does not cover appliances where defects or poor performance are due to misuse, accidental damage, neglect, faulty installation,
unauthorised modification or attempted repair, commercial use or failure to observe
requirements and recommendations set out in the instruction book.
This guarantee does not cover such parts as light bulbs, removable glassware or plastic,
dust bags or filters.
3. Should guarantee repairs be necessary the purchaser must inform the nearest customer
service office (manufacturer´s service or authorised agent). AEG reserves the right to
stipulate the place of the repair (i. e. the customer´s home, place of installation or AEG
workshop).
4. The guarantee or free replacement includes both labour and materials.
5. Repairs carried out under guarantee do not extend the guarantee period for the appli-
ance. Parts removed during guarantee repairs become the property of AEG.
6. The purchaser´s statutory rights are not affected by this guarantee.
European Guarantee
If you should move to another country within Europe then your guarantee moves with
you to your new home subject to the following qualifications:
– The guarantee starts from the date you first purchased your product.
– The guarantee is for the same period and to the same extent for labour and parts as
exist in the new country of use for this brand or range of products.
– This guarantee relates to you and connot be transferred to another user.
– Your new home is within the European Community (EC) or European Free Trade Area.
– The product is installed and used in accordance with our instructions and is only used
domestically, i. e. a normal household.
– The product is installed taking into account regulations in your new country.
Before you move please contact your nearest Customer Care Centre, listed below, to
give them details of your new home. They will then ensure that the local Service Organisation is aware of your move and able to look after you and your appliances.
France Senlis +33 (0) 44 62 29 29
Germany Nürnberg +49 (0) 911 323 2600
Italy Pordenone +39 (0) 1678 47053
Sweden Stockholm +46 (0) 8 738 7910
UK Slough +44 (0) 1753 219899
47
48
49
Index
INDEX
C
Care agent . . . . . . . . . . . . . . . . . . . . 9, 17, 19
Care symbols
Child safety feature
Circulation pump
Conditioner
Cottons
Curtains
Customer Service
. . . . . . . . . . . . . . . . . . . . . . . . 16
. . . . . . . . . . . . . . .29, 34
. . . . . . . . . . . . . . . . . . 9, 28
. . . . . . . . . . . . 9, 11, 12, 19, 25
. . . . . . . . . . . . . . . . . . .10, 16, 24, 25
. . . . . . . . . . . . . . . . . . . . . . . . .15, 24
. . . . . . . . . . . . . . . . .27, 51
D
Delicates . . . . . . . . . . . . . . . . . .11, 16, 24, 25
Detergent
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
E
Easy-cares . . . . . . . . . . . . . . . .11, 16, 24, 25
Emergency emptying
Energy saving
. . . . . . . . . . . . . . . . . 33
. . . . . . . . . . . . . . . . . . . . . . . 24
F
Filling quantity . . . . . . . . . . . . . . . . . . .14, 24
G
Gentle rinse . . . . . . . . . . . . . . . . . . . . . .12, 25
I
In-wash stain treatment . . . . . . . . . . . .9, 19
L
Linen . . . . . . . . . . . . . . . . . . . . .10, 16, 24, 25
M
Main wash . . . . . . . . . . . . . . . . . . . . . . .10, 24
O
OKO valve . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Opening the door
. . . . . . . . . . . . . 18, 23, 31
P
Pre wash . . . . . . . . . . . . . . . . . . . . . 10, 19, 24
Pre-wash detergent
Programme
changing
interrupting
setting
. . . . . . . . . . . . . . . . . . . . . . . .20, 24
Programme progress display
Pump out
. . . . . . . . . . . . . . . . . . . . 18, 22, 23
. . . . . . . . . . . . . . . .9, 19
. . . . . . . . . . . . . . . . . . . . . . . . . 22
. . . . . . . . . . . . . . . . . . . . . . . 22
. . . . . . . . . . . 22
Q
Quick wash . . . . . . . . . . . . . . . . . . 13, 20, 24
R
Rating plate . . . . . . . . . . . . . . . 9, 40, 41, 51
Rinse
. . . . . . . . . . . . . . . . . . . . . . . . . . . 11, 25
Rinse hold
Risk of frost
. . . . . . . . . . . . . 11, 18, 21, 22, 23
. . . . . . . . . . . . . . . . . . . . . . 6, 33
S
Service & Spare Parts . . . . . . . . . . . . . . . . .51
Silk
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Soaking
. . . . . . . . . . . . . . .12, 19, 20, 23, 24
Soaking agent
Spin
. . . . . . . . . . . . . . . . . . . . . 18, 21, 22, 25
Stain
. . . . . . . . . . . . . . . . . . . . . . . .13, 20, 24
Starching
. . . . . . . . . . . . . . . . . . . . 9, 19
. . . . . . . . . . . . . . . . . . . . . . . . . . . .11
W
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . 6, 47
Washing
coloureds
heavily soiled
lightly soiled
sensitive
Washing powder
Washing powder drawer
Water
hardness
pumping out
softener
Woollens
. . . . . . . . . . . . . . . . . . . . . . . . .15
. . . . . . . . . . . . . . . . . . . . . .13
. . . . . . . . . . . . . . . . . . . . 8, 13
. . . . . . . . . . . . . . . . . . . . . . . . . .16
. . . . . . . . . . . . . . . 9, 17, 19
. . . . . . . . . . . . 9, 19
. . . . . . . . . . . . . . . . . . . . . . . . . .17
. . . . . . . . . . . . . . . .18, 22, 23
. . . . . . . . . . . . . . . . . . . . . 9, 17, 19
. . . . . . . . . . . . . . . . . 11, 16, 24, 25
50
Service & Spare Parts
SERVICE & SPARE PARTS
If after carrying out the necessary checks there is still a fault with your
appliance please contact your local AEG Service Force Centre.
In guarantee customers should ensure that the suggested checks
have been made as the engineer will make a charge if the fault is
not a mechanical or electrical breakdown.
Please note that proof of purchase is required for in-guarantee service
calls.
Service & Spare Parts
If you require a service engineer or wish to purchase spare parts,
contact your local AEG Service Force Centre, by telephoning:
0870 5 929 929
Help us to help you
Please determine your type of enquiry before telephoning. When you
contact us we need to know.
1. Your name, address and post code.
2. Your telephone number.
3. Clear and concise details of the fault.
– What is the fault?
– When does the fault occur?
4. The model, production number and product identification number.
5. Date of purchase.
This information can be found on
the rating plate, so you have these
numbers to hand we recommend
you write them below.
PNC .....................................................
S-No. .....................................................
Customer Care
For general enquiries regarding your AEG appliance, or further information on AEG products please contact our customer care department
by letter or telephone at the address below or visit our website at
www.aeghome.co.uk
.
Customer Care Department
AEG Domestic Appliances
55-77 High Street, Slough, Berkshire SL1 1DZ
Tel: 08705 350350*
*Calls to this number may be recorded for training purposes.
51
AEG Hausgeräte GmbH
Postfach 1036
D-90327 Nürnberg
http://www.aeg.hausgeraete.de
© Copyright by AEG
822 942 537 -01- 0301-03
Loading...
