Thank you for your purchase of this ELECTROHOME® product. Please read this instruction manual carefully before
using product to ensure proper use. Keep this manual in a safe place for future reference.
www.electrohome.com
INSTRUCTION MANUAL
SIGNATURE MUSIC SYSTEM
EANOS700
- 2 -
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET
UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers)
that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one
wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the
third prong is provided for your safety. If the provided plug does not t into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and point
where they exit from the apparatus.
11. Only use attachments / accessories specied by the manufacturer.
12. Unplug this apparatus during lightning storms or when unused for long periods of time.
13. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
14. This appliance shall not be exposed to dripping or splashing water and no object lled with liquids such as vases shall
be placed on the apparatus.
15. Do not overload wall outlet. Use only power source as indicated.
16. Use replacement parts as specied by the manufacturer.
17. The product may be mounted to a wall only if recommended by the manufacturer.
18. Upon completion of any service or repairs to this product, ask the service technician to perform safety checks.
The lightning ash with arrowhead
symbol within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product’s enclosure
that may be of sucient magnitude
to constitute a risk of electric shock to
persons.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing) instructions
in the literature accompanying the
appliance.
WARNING:TO REDUCE THE RISK OF
ELECTRIC SHOCK DO NOT REMOVE
COVER (OR BACK), NO USER
SERVICEABLE PARTS INSIDE REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
- 3 -
CLASS 1
LASER PRODUCT
APPAREIL À LASER DE CLASSE 1
PRODUCTO LASER DE CLASE 1
CAUTION
INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCKS DEFEATED.
AVOID EXPOSURE TO BEAM
• Avoid installing this unit in places exposed to direct sunlight or close to heat radiating appliances such as electric
heaters, on top of other stereo equipment that radiates too much heat, places lacking ventilation or dusty areas,
places subject to constant vibration and/or humid or moist areas.
• Do not attempt to clean this unit with chemical solvents as this might damage the nish. Use a clean dry cloth.
• Operate controls and switches as described in the manual. Before turning on the power, make certain that power
cord is properly installed.
• Store your CDs in a cool area to avoid damage from heat.
• When moving the set, be sure to rst disconnect the power cord.
FCC INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
IMPORTANT
Since digital circuitry may cause interference to other radio or television tuners nearby, switch this unit o when not in use
or move it away from the aected radio/television tuner.
NOTE: This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in
the Radio Interference Regulations of Industry Canada. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television operation
(which can be determined by turning the equipment o), the user is encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
IMPORTANT SAFETY INSTRUCTIONS
- 4 -
Important Safety Instructions ..................................................................................................................... 2
What’s Included ........................................................................................................................................... 4
Buttons and Connections ............................................................................................................................. 5
Preparation for Use ...................................................................................................................................... 7
Unpacking and Setup ........................................................................................................................... 7
Power Source ....................................................................................................................................... 7
Battery Installation for Remote Control ................................................................................................ 8
Operation ..................................................................................................................................................... 8
Raising and Lowering the Lid ............................................................................................................... 8
Protect Your Furniture .......................................................................................................................... 8
Powering on the Unit ........................................................................................................................... 8
AUX IN Operation ................................................................................................................................. 9
Playing a CD ......................................................................................................................................... 9
USB Operation ...................................................................................................................................... 9
Removing the USB Drive .....................................................................................................................10
Playing in MP3 Mode .........................................................................................................................10
Memory Function ................................................................................................................................10
Listening to the Radio .........................................................................................................................11
Playing Records ...................................................................................................................................11
Recording ............................................................................................................................................11
Deleting Files from the USB Device......................................................................................................12
Care and Maintenance.................................................................................................................................13
ELECTROHOME Warranty ............................................................................................................................15
WHAT’S INCLUDED
• Retro Music Player
• Remote Control
• 45 Adapter
• Instruction Manual
• 1 Year Warranty
• Lifetime Live Customer Support
TABLE OF CONTENTS
- 5 -
Main Unit
Control Panel
BUTTONS AND CONNECTIONS
1
3
2
4 6 7 8
11
5 10
12
13
2318
161514
17 19
2625
24
2221
20
9
27
1. Phonograph Lid
2. Phonograph Lid Support
Bracket
3. Speakers
4. USB input
5. Volume Control
6. Power ON/OFF button
7. Record Button
8. Function Button
9. LCD Display
10. Remote Control Sensor
11. Power Indicator
12. FM ST. Indicator
13. AM Button
14. FM Button
15. CD/USB Button
16. AUX IN Button
17. Phono Button
18. FM Dial Scale
19. AM Dial Scale
20. CD Drawer
21. Play/Pause Button
22. Stop Button
23. DN/F-R Button
24. Tuning Control
25. UP/F-F Button
26. PLAY-MODE Button
27. OP/CL Button
- 6 -
28. AUX IN (L/R) Input
29. FM Antenna
30. AC Cord
31. Turntable
32. 45 RPM Adapter
33. Transit Screw
34. Cue Lever
35. Speed Selector
(33/45/78 RPM)
36. Tone Arm Lock
37. Tone Arm with Stylus
38. Open/Close Button
39. Repeat Button
40. DB/FB (Skip Reverse)
Button
41. Stop Button
42. Track - 10 Button
43. Random Button
44. Record Button
45. Play/Pause Button
46. UP/FF (Skip Forward)
Button
47. Track +10 Button
48. Delete Button
49. Program Button
BUTTONS AND CONNECTIONS
28
29 30
Back of Unit
Turntable
Remote
42
43
49
38
41
40
39
44
47
46
45
48
31
32
33
37
35
34
36
All of the buttons on the remote control have the same function as the buttons on the
main unit. The remote is used in CD/MP3 and USB mode.
- 7 -
AC plug
AC outlet
PREPARATION FOR USE
Transit Screw
Tone Arm
Lock Lever
Stylus Cover
UNPACKING AND SETUP
• Carefully remove the unit from the display carton and remove
all packing material from the unit
• Unwind the AC power cord and extend it to its full length
• Unwind the FM Antenna wire and extend it to its full length
• Place the unit on a stable, level surface, close to an AC outlet,
out of direct sunlight, and away from sources of excess heat,
dust, moisture, humidity, or strong magnetic elds
• Raise the lid to expose the record player. The record player has been
secured for shipment with a transit screw. Use a coin or screwdriver
to TURN THE TRANSIT SCREW CLOCKWISE – THIS WILL ALLOW
THE TURNTABLE TO "FLOAT" AND TURN FREELY.
• Remove the opaque white plastic stylus cover from the turn-table
stylus by sliding it in the direction of the arrow.
• Discard the stylus cover.
• Remove the twist-tie that was used to secure the tone arm
during shipment.
• Release the tone arm lock lever.
• Connect the plug to your AC outlet, as shown below.
POWER SOURCE
This system is designed to operate on normal 120V 60Hz AC only. Attempting to operate this system from
any other power source may cause damage to the system, and such damage is not covered by your warranty.
This system is equipped with a polarized AC power plug having one blade wider than the other. This is a
safety feature. If this plug does not t into your existing AC outlet, do not try to defeat this safety feature
by altering the wide blade to make it t into your outlet. If this plug will not t into your outlet, you
probably have an outdated non-polarized AC outlet. Have the obsolete outlet changed by a qualied
licensed electrician.
- 8 -
BATTERY INSTALLATION OF REMOTE CONTROL
• The remote control is equipped with one CR2025 (3V) lithium battery.
• To replace the battery, hold the remote level and press the clasp with
the thumb in the right direction of the arrow in the illustration, and take
out the battery compartment by sliding with forenger towards you.
Take out the battery compartment from the remote control. Install a
lithium battery (CR-2025) in the compartment with the positive polarity
turned up. Hold level and push the battery compartment into the
remote control lightly until it clicks into place.
RAISING AND LOWERING THE LID
IMPORTANT:
To open the lid, raise it as far as it will go until the lid support bracket "locks" in the open position. To close
the lid, lift it upward slightly and pull the bracket gently towards you until the bracket "unlocks", and then
gently lower the lid.
TO AVOID DAMAGING THE CABINET OR THE LID, NEVER FORCE THE LID CLOSED. ALWAYS RAISE THE LID TO
RELEASE THE LID SUPPORT BRACKET.
PROTECT YOUR FURNITURE
This model is equipped with non-skid rubber "feet" to prevent the product from moving when you operate
the controls. These ‘feet’ are made from non-migrating rubber material specially formulated to avoid
leaving any marks or stains on your furniture. However, certain types of oil based furniture polishes, wood
preservatives, or cleaning sprays may cause the rubber "feet" to soften, and leave marks or a rubber residue
on the furniture. To prevent any damage to your furniture we strongly recommend that you purchase small
self-adhesive felt pads, available at hardware stores and home improvement centers everywhere, and
apply these pads to the bottom of the rubber "feet" before you place the product on ne wooden furniture.
POWERING ON THE UNIT
1. To turn the system ON, press the POWER button on the front panel, and set the volume to a low level.
The POWER indicator lights up.
2. Press the FUNCTION selector buttons(AM/FM/CD/USB/AUX IN/PHONO) to select your desired function.
3. Start to adjust the volume by using the VOLUME control.
4. When you have nished using the system, press the POWER button again to turn o the unit. The
POWER indicator will turn o.
PREPARATION FOR USE
OPERATION
- 9 -
OPERATION
AUX IN OPERATION
Connect your MP3 player or smartphone and listen to music via the AUX IN input. Press the AUX IN button
to select AUX MODE. Insert the audio cable (not included) into the corresponding AUX IN (L/R) Inputs at the
back of the EANOS700. Connect the other end of the cable to your device (item B). Adjust the volume using
the Volume Control knob on the front of the EANOS700.
INSERTING AND PLAYING A CD
1. Press the POWER button on the front panel to turn the system ON, set the
volume to a low level. Press the CD/USB button.
2. Press the OP/CL button to open the CD drawer. Place a CD in the tray, with
the printed label facing up. Press the OP/CL button again to close the
CD drawer.
3. The disc will spin for a few seconds while the player is reading the disc and
the total track number will appear in the display. The unit will start playing
the rst track of the disc. Adjust the VOLUME control to set the volume
as desired.
4. To skip forward or backward through the tracks on the disc, press the UP/F.F
or DN/F.R buttons.
5. Press the PLAY/PAUSE button to pause playback. The PLAY/PAUSE indicator
will blink in the display. Press again to resume playback. When the disc is
through playing, it will stop rotating.
6. To stop playback entirely, press the STOP button.
USB OPERATION
1. Press the CD/USB button rst and the FUNCTION button second to enter
USB mode, the "- - -" and USB icon will appear on the LED screen.
2. Insert a USB device into the USB input. The player will begin to play the
rst song of the USB.
3. The MP3 icon will be shown while MP3 is detected.
4. The PLAY/PAUSE, DN/F.R/UP/F.F and STOP functions are the same as in CD play mode.
You may press the FUNCTION button on the unit or the PLAY/PAUSE button on the remote
control to change the playing mode between CD and USB.
Item B
EANOS700
- 10 -
REMOVING THE USB DRIVE
Make sure to stop the playback and turn the unit o before removing the USB drive to avoid damage to the
USB and the system.
PLAYING IN MP3 MODE(UNDER CD/USB OPERATION)
1. Press PLAY/PAUSE button to start or pause playback of the selected track in
the CD/USB mode.
2. While playing the song, the song number and folder number of your selected
track will be shown on the screen. The MP3 icon and
► icon will be shown.
3. You can stop the playback at any time by pressing the STOP button.
TRACK SKIP AND HIGH SPEED TRACK SEARCH IN CD/USB MODE
During CD/USB playback, pressing the UP/F.F (Fast Forward) or the DN/F.R (Fast Reverse) button repeatedly
will skip to higher or lower tracks. Release the button when the desired track number is shown. The disc
will begin to play from your selected track.
Press the DN/F.R or the UP/F.F button to select a track from a folder. Both "ALBUM" and "001", "002" will
ash. Press the PLAY.MODE four times or press the RANDOM button on the remote control and you will see
RANDOM on the LED screen. Press the DN/F.R or the UP/F.F button to manually select tracks randomly.
MEMORY FUNCTION IN CD/MP3 MODE
1. Press STOP then press PLAY.MODE on the unit or PROGRAM on the remote
control to program your tracks. Both "PROG" (ashing) and "P01" will
appear on the screen. Press the UP/F.F or DN/F.R button to select your track
then press the PLAY.MODE or PROGRAM button to conrm your selection.
2. Press the PLAY.MODE or PROGRAM button to program the next track.
Repeat for all of your selected tracks.
3. To set the memory while in MP3 mode (CD/USB), repeat steps 1 and 2.
4. Press the PLAY/PAUSE button to play the stored tracks, press UP/F.F or DN/F.B to select a track in the
sequence saved.
5. Press the STOP button twice to exit the program mode. This will clear the memory of your
previous selections.
OPERATION
Folders are only available when a USB is detected, not during CD playback.
You can store a total of 99 MP3 tracks and 20 CD tracks.
Loading...
