Electrohome EAAC600 User Manual

www.electrohome.com
Thank you for your purchase of this Electrohome product. Please read this instruction manual
carefully before using product to ensure proper use. Keep this manual in a safe place for
future reference.
Merci d’avoir fait l’achat de cet appareil Electrohome. Veuillez lire le présent guide attentivement
avant de faire fonctionner l’appareil pour vous assurer de l’utiliser correctement. Conservez le
EAAC600
SelfSet™ Clock Radio
with Dual Alarm
Radio- réveil SelfSet™
avec double alarme
USER MANUAL
GUIDE DE L’UTILISATEUR
- 2 -
For more product information visit www.ELECTROHOME.com
NEED HELP?
DO NOT RETURN THIS
PRODUCT TO THE STORE
Please contact an ELECTROHOME customer support representative rst regarding any additional information on product features, specications or assistance with setup.
Please contact us via one of the methods below:
Fax:
1.888.771.1701
Email:
support@electrohome.com
- 3 -
WARNINGS
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
To reduce the risk of re or electic shock, do not expose this appliance to rain
or moisture.
CAUTION
Use of controls or adjustments or performance of procedures other than those specied may result in hazardous radiation exposure.
CAUTION - TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICABLE PARTS INSIDE, REFER TO QUALIFIED USER PERSONNEL.
The lightning ash with arrowhead symbol, within an equilateral traingle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufcient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- 4 -
Warnings .....................................................................................................................................................3
Table of Contents ....................................................................................................................................4
Product Information ...............................................................................................................................7
Operating Instructions ..........................................................................................................................8
Power Connection ..........................................................................................................................8
DST - Daylight Savings Time ........................................................................................................8
Reset ....................................................................................................................................................8
Manually Set the Clock Time and Date ....................................................................................9
Setting Alarm Output and Alarm On/O ...............................................................................9
Alarm Length and Snooze Function .........................................................................................9
Change Display Content ...............................................................................................................10
Sleep Function .................................................................................................................................10
Radio Operation ..............................................................................................................................10
Projection Unit .................................................................................................................................10
Troubleshooting .....................................................................................................................................11
Care and Maintenance ..........................................................................................................................11
Specications ............................................................................................................................................12
Warnings .....................................................................................................................................................12
ELECTROHOME WARRANTY ................................................................................................................13
TABLE OF CONTENTS
- 5 -
WARNING
TO PREVENT ELECTRIC SHOCK; DO NOT USE THIS PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURES. TO PREVENT FIRE OR SHOCK HAZARD; DO NOT INSTALL THIS PRODUCT IN A CONFINED SPACED SUCH AS A BOOK CASE OR SIMILAR UNIT.
IMPORTANT SAFETY INFORMATION
LASER SAFETY
The unit uses a laser. Only a qualied service
technician should remove the cover or attempt to
service this product to avoid possible eye injury.
CAUTION: USE OF CONTROLS OR ADJUSTMENT
OF PERFORMANCE OR PROCEDURES OTHER
THAN SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
LASER SAFETY
DANGER
INVISIBLE LASER RADIATION WHEN OPEN
AND INTERLOCK FAILED OR DEFEATED.
AVOID DIRECT EXPOSURE TO LASER BEAM.
CAUTION: RETAIN THIS MANUAL FOR FUTURE REFERENCE
1. Read these instructions.
2. Keep these instructions.
3. Read all warnings.
4. Follow all instructions.
5. Do not use this product near water.
6. Clean only with a dry cloth.
7. Clean the screen only with a dry cloth, moistened slightly if needed. Do not clean the inside ofthis product.
8. Check that the power voltage stated on the rating label corresponds to your local electricity supply.
9. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
10. Do not place this product near any heat sources such as radiators, heat registers, stoves or other apparatus (including ampliers) that produce heat.
11. Do not immerse this product, the power cord or any accessories in water or any other liquid.
12. Unplug the power adaptor from the wall when the product is unused for a long period of time and during thunderstorms.
13. Only use attachments / accessories specied by the manufacturer.
14. Unwind and straighten the power cord before use.
- 6 -
IMPORTANT SAFETY INFORMATION
15. Damage Requiring Service Unplug the power cord and refer servicing to qualied service professional under the following conditions:
A. If liquid has been spilled on or into the product. B. If the product has been exposed to rain, water, or other liquids.
C. If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating instructions Improper adjustment of other controls may result in damage and will often require extensive work by a qualied technician to restore the
product to its normal operation. D. If the product has been dropped or damaged in any way. E. When the product exhibits a distinct change in performance. This may
indicate a need for service.
16. Servicing
Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltages or other hazards. Refer all servicing to a qualied service professional.
17. Replacement Parts
When replacement parts are required, be sure the service technician has used replacement parts specied by the manufacturer, or have the same characteristics as the original parts. Unauthorized substitutions may result in re, electric shock, or other hazards.
18. Safety Check
Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.
- 7 -
PRODUCT INFORMATION
1. Projection Unit
2. AM/FM Band
3. Snooze/Sleep/Time Zone
4. ON/OFF
5. Alarm 1 Radio/Buzz
6. Alarm2 Radio/Buzz
7. Line In Jack
8. Rating Label
9. Reset
10. Focus Adjustment for Projection
11. Projection Time 180º Flip
12. Projection ON/OFF
13. Temperature Sensor (indoor)
14. FM Antenna
15. AC Power Cord
16. Alarm Set
17. <</MONTH-DAY/ºC/ºF
18. >>/YEAR/DST
19. Mode/Set
20. Display Light-Auto O/Low/High Dimmer
21. LCD Display
22. Volume Dial
23. Tuning Dial
24. Battery Door
25. Speaker
- 8 -
PRODUCT INFORMATION
PACKAGING CONTENTS
• Projection Dual Alarm Clock Radio with Auto Time Set
• Backup Battery “CR2032”
• Instructional Manual
ATTENTION
1. Do not plug or unplug the power cable if you have wet hands.
2. If you are not planning to use the unit for an extended period of time, disconnect the power cable from the wall outlet.
3. When disconnecting the power cord from the wall outlet. In order to avoid damage to the power cord and electric shock, do not pull on the cord; pull rmly at the base of the plug.
POWER CONNECTION
1. Plug the AC power cord into a household AC outlet.
2. Clock display will ash “3” indenitely.
3. Unit will go to Zone 3, which is the default setting, and correct time will be displayed.
SETTING THE TIME ZONE (FACTORY PRESET TO ZONE “3”- EST)
Press the >> / YEAR / DST(18) or << / MONTH - DAY (17) to select time zone 1-6. Press MODE (19) to conrm when the correct time zone appears on the display.
Reset the time zone:
Press SNOOZE/SLEEP/TIME ZONE(3) and hold for 3 seconds to change the time zone when you are in dierent location.
SETTING DST – Daylight Savings Time
Press >> / YEAR / DST (18) and hold for 3 seconds to toggle on and o the DST function.
RESET
The RESET(9) is located on the back of unit. Use a ballpoint pen to press it whenever you change the batteries, or unit is not performing as expected. This will return all settings to default value, you will lose any stored data (alarm and clock settings).
OPERATING INSTRUCTIONS
Zone 1 Newfoundland Zone 2 Atlantic time Zone 3 Eastern time
Zone 4 Central time Zone 5 Mountain time Zone 6 Pacic time
- 9 -
OPERATING INSTRUCTIONS
SETTING TIME AND CALENDAR MANUALLY
Press MODE SET (19) in normal mode and keep pressing over 2 seconds to enter time set mode, after enter the setting mode, press MODE SET (19) to change the mode cycle as follows :
Normal → Year → Month → Day → 12/24 H → RTC Hour → RTC Min →
Normal
Action (during manual adjustment):
• Press << / MONTH-DAY / °C/°F (17) to adjust data backward.
• Press >> / YEAR / DST (18) to adjust data forward.
• Keep pressing << or >> for 2 seconds to enable auto forward.
Setting Alarm 1 and Alarm 2
Press ALARM SET (16) during normal mode and keep pressing to enter alarm set mode, after enter the setting mode, press ALARM SET (16) to change the mode cycle as follows :
Normal → AL 1 Hour → AL 1 Min → AL 1 weekend Alarm → AL 2 Hour → AL 2 Min → AL 2 weekend alarm → Normal
Select alarm weekday mode as follows 1-5 : Monday to Friday 1-7 : Whole week 6-7 : Saturday & Sunday
Action (during manual adjustment):
• Press << / MONTH-DAY / °C/°F BUTTON (17) to adjust data backward.
• Press>> / YEAR / DST BUTTON (18) to adjust data forward.
• Press and Hold << or >> for 2 seconds to enable auto forward.
SETTING ALARM OUTPUT & ALARM ON/OFF
Changing Alarm Output
1. Press AL 1 (5) button / AL 2 (6) button to music
position to select wake to Radio, set to Buzzer position to select wake to Buzzer, set to Alarm o position to disable all alarms.
2. Select the Display Auto o / low / high dimmer (20) to the Auto o mode, display will turn on automatically when alarm sounds.
ALARM LENGTH AND SNOOZE FUNCTION
Alarm Duration – Buzzer alarm or Radio alarm will continue to sound for 30 minutes if no keys are pressed, it will stop automatically and be set for the next day.
