Elechomes CHS2003 User Manual

Model: CHS2003

H i g h S p e e d

Blender

User Manual

Product Introduction Product Illustration

This kitchen high-speed blender uses high-speed motor to provide power for
rotating stainless steel blade assembly to achieve the purpose of chopping
ingredients. Featuring refined motor with adjustable rotating speed as well as
unique blade and PC jar structure, it can achieve a variety of blending effect.

Bearing imported from Japan, the rotating speed of this motor reaches

1.
up to 30000r/min with little noise. With fan cooling device, the blender
can run for a long time to meet the commercial premises requirements.
Motor has designed with overheat protection device to prevent burning.

2.

The machine is equipped with circuit system to control the rotating speed,
stabilize current, protect the motor and reduce external interference.
The machine is equipped with over-current protector which can protect

3.
the device when current or voltage fluctuates.
The machine has a speed tuning switch and momentary switch, hence

4.
can provide a variety of mixing effects.

5.

The rotating connector of the machine is a pair of upper and lower
stainless steel parts, so it will not be damaged.
The waterproof glue on the bearing is made of special wear resistant

6.
material which is hard to wear for a long time.
The specially processed blade assembly is hard enough to chop or grind

7.
herbs, beans and other ingredients.
Its PC jar is made of imported PC material and undergone high temperature

8.
processing, wear resistant and crash resistant.

9.

If the power cord is damaged, it can only be replaced or repaired by
manufacturer's service department staff or equivalent personnel in order
to avoid danger.

Stir Bar

Speed Tuning Knob

Power Switch

Motor

Refill Cover
Jar Lid

Tritan Jar

Blade Assembly
Securing Plate

Instantaneous
Rotation Switch

Body Cover

Stand Base
