Elechomes BFP-2800MT User Manual

www.elechomes.com

Model: BFP-2800MT

Baby Food Processor

User's Manual

◆

Security System

Thank you for choosing Elechomes's products!

In order to use the product well, please read the user's manual carefully and keep it well. The pictures here are only for reference. Any discrepancy in future, please adhere to the actual product instead.

Warning

Caution

Product Introduction

◆

Specification

◆

Panel Features

◆

Parts Of Product

Preparation For Operation

Functions & Operation

Cleaning & Maintenance

◆

Electromagnetic Fields

◆

Environmental Protection

◆

Storage

◆

Accessories Option

◆

Extended Functions

Baby Food Guidelines

◆

The stage of swallowing For 4-6 months old baby

◆

The stage of togue grinding For 7-9 months old baby

◆

The stage of chewing for Above 10 months old baby

Others

The Role Of Nutrients

Nutritious Food

Warning

Caution

1. Check if the voltage indicated on the bottom of the appliance corresponds to the local mains

voltage before connecting the power.

2. Do not use the appliance, if the plug, the mains cord or the appliance itself is damaged.

3. If the mains cord is damaged, you must have it replaced by Elechomes , a service center

authorized by Elechomes or similarly qualified persons in order to avoid a hazard.

4. If the blade is stuck, cleaning the ingredients after removing the plug.

5. In order to avoid scalding, please do not touch the water tank & stirring cup which could

reach high temperature when steaming. Please do use the stirring cup with the handle.

6. Please be careful with high-temperature steam which comes from the stirring cup, when

steaming or opening the cup.

7. Please be careful when adding water or cleaning. Do not add too much water, otherwise the

water will overflow into the appliance. It may cause the short circuit or other problems.

8. The blade is very sharp, be careful when handing the blade, emptying the bowl and during

cleaning.

9. Switch off the appliance and disconnect from supply before changing accessories.

10. Always disconnect the appliance from the supply if it is left unattended and before

assembling, disassembling or cleaning.

11. This appliance shall not be used by children. Keep the appliance and its cord out of reach of

children.

12. This appliances can’t be used by persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge.

13. To protect against electric shock, do not immerse main parts of the product, cord or plug in

water or other liquids.

1. Do not use accessories or parts produced by other manufacturers or not recommended by

Elechomes . If used, the warranty will become invalid.

2. Do not immerse the main body in water. Do not put the appliance on or near the stove or

cooker which are being used or heating.

3. Do not use a sterilizer or microwave oven to disinfect the stirring cup or any parts of the

appliance. Because this method is not suitable for handle or blade.

4. The appliance is designed for household use only. If operated inappropriately ( used for

commercial / semi commercial purposes or not according to the user’s Manual ), the warranty

will become invalid. The loss caused by inappropriately operating, Elechomes will not take any

responsibility.

5. Place the appliance on a stable, flat position and make sure there is enough space to avoid

the damage to cabinet and other items caused by the steam from the appliance.

6. Do not steam without adding water.

7. Please make sure that the stirring cup could be put into proper position. Otherwise, it won’t

work.

8. After steaming, keep the appropriate amount of broth according to the food consistency.

9. After steaming, please make sure that the stirring cup is cooled before opening it and the

food can not exceed 300ml logo of the stirring cup.

10. Empty the water tank and add purified water before steaming.

11. Do not add water to the tank when steaming. Otherwise, the hot water or steam may be

expelled.

12. Do check the uniformity of food to ensure there is no other objects or coagulation in the

cooked food.

13. The interval is 3 minutes if steaming next time.

Product Introduction

14. Any bones, nuts ( walnuts, macadamia nuts ) are forbidden to stir.

15. Do not stir in empty cup, don’t stir food continuously for more than 15 seconds at a time.

Waiting 10 senconds to restart each time after the previous stirring .

16. It is possible that the stirring cup and the steaming basketis are colored by food, it is a

normal phenomenon. Please clean it as soon as possible after use.

17. Do remember to test the temperature of baby food by hand before feeding.

18. Do not lift or move the appliance when using.

19. Do not insert any objects into water inlet or steam outlet.

20. Do not drip the puree or juice into water tank to prevent coating of heating plate corroded by acidity and basicity of the food.

21. Be careful if hot liquid is poured into the food processor as it can be ejected out of the appliance due to a sudden steaming.

22. This appliance is intended to be used in household and similar applications such as: – staff kitchen areas in shops, offices and other working environments; – farm houses; – by clients in hotels, motels and other residential type environments; – bed and breakfast type environments.

23. If there is any breakage or damages, please do not use it again. Send it to the service center which is authorized by Elechomes for repair.

Specification

Product Name : Baby Food Processor

Model : BFP-2800MT

Color/Surface : Light blue

Total Power : 430W

Heating Power : 300W

Stirring Power : 130W

Rated Power : 120V~ 60Hz

Water Tank Capacity : 200ml

Stirring Capacity : 300ml

Net Weight : 1.93kg

Gross Weight : 2.68kg

Product Size : 295*167*245mm

Panel Features

Stirring Button

Timer Knob

0/I

Steam Indicator Light

Steaming Time

24. Steaming with food twice before using, and no less than 15 minutes each time.

25. Before each use, make sure there is enough water in the tank. And after each use, please pour the remaining water out of the tank and keep it dry.

26. Don't pour olive or peanut oil into the stirring cup to prevent any breakage.

03 04

Put the plug into the power socket and the appliance is in stand-by mode. Rotate the timer knob

to the right so that the “ ” on the knob panel is aligned with the steaming time you choose. Then

the steaming function is working now(The steam indicator light is on). The timer knob will turn

back slowly counterclockwise . When the “ ” logo is aligned with the “ ” with a sound of “Ding”

,the steaming work is completed. Then the appliance is in stand-by model. When holding the

stirring button, the stirring function is working. Once the hand leaves the button，the appliance

stops stirring. Then appliance is in stand-by mode again.

min

Parts Of Product

Preparation

Adding water to the tank: Pour the purified water or distilled water into the tank to reach the

MAX logo then rotate the cover on the tank.

Caution:

1.Do not use tap water or mineral water. Because it is easy to cause the incrustation scale on water tank.

2.Make sure not to add too much water to the tank .Water can not exceed the MAX logo.

3.Only the purified water can be poured into the tank.

Functions & Operation

Item

Name

Rotary cover

of water tank

Main body

Lid of the

stirring cup

Steaming rack

Splash-proof cover

Steaming basket

Blade

Waterproof circle

Stirring cup

Blade holder

Material

Food-grade PP

ABS

Food-grade PP

Food-grade PA

Food-grade silicone

Tritan

Food-grade PA

05 06

Heat Resistant

Temperature

120℃

115℃

120℃

200℃

109℃

120℃

Cold Resistant

Temperature

-20℃

Quantity

BlendSteam

The appliance has powerful two functional modules (Steam, Stir ). The appliance is designed for

making fresh food to feed the babies. Operate these two functional modules easily according to

the “ Function & Operation ” from the user’s manual.
