Eizo FLEXSCAN S2401W, FLEXSCAN S2231W, FLEXSCAN S2201W, FLEXSCAN S2431W, FLEXSCAN S2001W User Manual

...
FlexScan Widescreen Monitors
Broaden your business horizons
2
o bring widescreen benefi ts to trading
T
fl oors and back offi ces, EIZO
introduces a new series of FlexScan monitors.
Available in 24.1", 22" and 20.1" sizes with
a choice of VA or TN technology, this
series of six models meets a broad range of
performance needs. And combining built-in
features that reduce energy use and eye strain
with a design that allows more open, better-
fi tting confi gurations, they will be welcomed
by traders and business users alike.
FEATURES
Widescreen Format
The wide format design (16:10 aspect ratio) offers increased horizontal space compared to con­ventional monitors so you can keep tool palettes open without covering the window you’re working or simultaneously work in multiple windows.
4:3 aspect ratio 16:10 aspect ratio
Full Color Display & Detailed Color Control
All models come with 8-bit display for each RGB and 10-bit gamma correction. This produces
16.7 million displayable colors from a palette of over one billion for detailed rendering of similar shades of color. Color control options in the OSD menu include brightness, contrast, gamma, hue, saturation, gain, and color temperature from 4,000 to 10,000 K in 500 K increments.
The FlexScan S2231W has a wide color gamut that reproduces 92% vs. the NTSC standard, which allows it to display a wider range or colors than conventional monitors and cover most of the CMYK spaces used in printing.
Fine Contrast Mode Selection
For optimum viewing of different kinds of content, EIZO’s Fine Contrast function includes modes for offi ce applications (Text mode), video clips (Movie mode), graphics (Picture mode), web browsing (sRGB mode), and user-defi ned settings (Custom mode). Switching between modes is done by pressing a button on the front panel or by using the bundled ScreenManager Pro for LCD software, which supports automatic mode switching such as changing to Text mode when an e-mail application is selected.
High Contrast Ratios
Contrast ratios range from 900:1 for the FlexScan S2031W to 1500:1 for the FlexScan S2231W. This outstanding performance makes it easier to distin­guish between similarly-colored fi gures in large spreads of data, and so helps reduce reading errors.
Placement Flexibility
Three stand/mount options are available for meeting the different placement requirements of trad­ing fl oors and back offi ces. A height adjustable stand features 82 mm of height adjustment, tilt, swivel as well as pivot for portrait mode viewing. EIZO’s EzUp stand provides even greater fl exibility with more than 150 mm height adjustment, 25° tilt, 344° swivel, and
2
portrait mode display. For the trading fl oor or other installations that prepare their own mounting solu­tions but frequently move their equipment around, EIZO offers the QM1 quick mount attachment. The QM1 allows the monitor to be mounted or demount­ed with the pull of a lever.
Height
adjustable
stand
EzUp stand
QM1
quick mount
attachment
USB 2.0 Hub
A high speed (480 Mb/s) USB 2.0 hub in­cludes one upstream and two downstream ports for connection of peripherals directly to the monitor.
HDCP Support
Support for high-bandwidth digital content protection (HDCP) through the DVI-I input allows for viewing of content from HDCP-equipped devices.
Accessories
Accessories available include an attachable sound unit, mounting arms, and panel protectors with both glossy and non-glare sides. For detailed informa­tion, please see www.eizo.com/products/accessories.
Built for Moving Image Playback
The inclusion of an overdrive circuit with three models (S2431W, S2231W, S2031W) provides smooth playback of moving images such as stream­ing video.
Digital and Analog Signal Support
DVI-I (digital or analog) and D-Sub (ana­log) inputs offer connection with one or two PCs. Switching among the inputs can be done with a front panel button.
Certifi cations and Standards
All models have received the Windows Vista Premium logo, and are TCO’03 and TÜV Rheinland certifi ed which ensures compliance with strict guidelines for ergonomics, emissions, and energy consumption. They also carry the EIZO Eco products 2006 logo meaning they meet a strict set of internal requirements for design, manufacturing, packaging, and usage.
3
EIZO WIDESCREEN ADVANTAGES
Hole for Light Trans­mission
Backside of Panel
Main
Board
Sensor
A Full Range of Monitors
With six monitors in three sizes and two panel technologies, this lineup offers a range of performance that can meet the many individual needs of an organi­zation. Both VA and TN panels are available in each size — VA technology offers the image quality and wider viewing angles required for the trading fl oor, while TN technology is suitable for back offi ce appli­cations. And because all models share the same sleek design as the latest EIZO 17" and 19" models, your operation looks consistent and professional through­out.
Energy Savings
For operations that use a large number of monitors, any reduction in power consumption per screen can signifi cantly lower costs. The BrightRegula­tor function plays an important part in this by reading the ambient light of the offi ce environment and adjust­ing the brightness of the backlight accordingly. As a result, energy is saved because the screen is never too bright. While the typical user can turn up the monitor to compensate for bright light then forget to turn it down later if ambient light is dimmed, BrightRegula­tor optimizes brightness automatically throughout the day so there is nothing to forget. These monitors also reduce energy costs with a convenient off timer. By switching the monitor to power-off status at a user­specifi ed time, energy can be saved even if monitors are left on at the end of the day.
EIZO monitors are used together because there’s no need to manually adjust brightness for each screen. Should the user want to make the screen a little brighter or a little darker, the manual adjustment in the OSD menu is still an option and BrightRegulator will remember the setting.
Brightness Adjustment with BrightRegulator
Higher Brightness
Adjustment Range
Monitor brightness
The monitor’s optimum brightness as determined by BrightRegulator can be further adjusted manually if a lighter or darker screen is preferred
BrightRegulator Setting
Lower Brightness
Ambient luminance
Eye fatigue can also result from the fl uctua­tions in backlight brightness that normally occur from screen startup and can last for up to two hours. Changes in temperature can cause backlight levels to change, as can the inevitable deterioration of the monitor’s fl uorescent light over time. In addition, a backlight can suffer deterioration from power surges. An EIZO patented backlight sensor detects and coun­teracts these infl uences so brightness stays stable and product life is extended. (Backlight sensor included with the S2431W, S2401W, and S2231W.)
Optimized Brightness
In many offi ces, especially those with larger windows, levels of light are constantly changing. Re­fl ective surfaces, such as papers, walls, and tabletops refl ect the differing levels of light at different times of the day and in different weather. Meanwhile, the level of monitor brightness stays the same, which means the pupil of the eye has to adjust every time you look away from, or back at the screen. This leads to eye fatigue, which compromises performance.
EIZO overcomes this problem with BrightReg­ulator, which detects changes in ambient luminance and adjusts the brightness of the monitor accord­ingly. When the room is bright, screen brightness is increased to make for easy reading. And when lighting levels drop, screen brightness decreases. In this way the eyes are protected from excess brightness through­out the day or night. Because the function is entirely automatic, the benefi ts are magnifi ed when multiple
These features ensure the user will have the same perceived image regardless of actual changes in ambient lighting and the backlight’s stability.
Brightness Stabilization with Backlight Sensor
)
2
Brightness (cd/m
With Brightness Drift Correction
Preset Value
Without Brightness Drift Correction
Minutes
4
Unobtrusive Speakers
Because 0.5 watt speakers are
hidden at the bottom of all
models, users enjoy sound while bezel size is kept to a mini­mum. For
those
requiring greater volume, the separate i-Sound L3 sound unit with dual 0.9 watt speakers can be attached to the bottom of the screen to focus sound directly at the user.
i-Sound L3 sound unit
Confi gurations Conducive To Trade
These monitors let companies make the best use of widescreen-optimized Windows Vista features, such as the Sidebar function and Media Center. When grouped with other EIZO monitors, they allow more open and better-fi tting multi-panel confi gurations, such as in the diagrams below, where the central wi­descreen monitors provide greater overall screen space with minimal bezel. By combining a 24.1" widescreen monitor with 21" monitors, or a 22" widescreen monitor with 19" monitors, the confi gurations are a perfect fi t to the standard 1,500 mm trading desk or the common 1,300 mm desk. One advantage of this kind of confi guration is the open line of sight that al­lows traders to communicate face to face and not feel ‘fenced in’ like they can with conventional two-row
confi gurations. It also contributes to work safety as traders will have better visibility of what is happening in front of them. Because they have the same or simi­lar number of pixels per inch as other EIZO monitors, eye strain is not a concern when glancing from screen to screen.
5-Year Manufacturer Warranty
While many other manufacturers outsource production to an overseas third party, EIZO uses only its own factories and staff. As a result, EIZO keeps closer control over pro­duction quality, which translates into higher reliability, and allows EIZO to offer its exclusive 5-year guarantee. That’s why EIZO monitors are an investment that pays off over time — doing away with worries of fre­quent product replacement and resultant downtime.
Commitment to Quality
EIZO seals its commitment to quality with the opening of its new R&D center at its corporate headquarters in Hakusan, Japan. Built adjacent to the factory and quality control department, this new addition means all essential EIZO business functions, from product planning to packaging, are now central­ized in one location. Bringing 600 personnel together on 13,000 square meters of fl oor space, it will allow EIZO to achieve further effi ciency and increase its competitive edge.
21" and 24" Widescreen Trading Confi guration
21"
(FlexScan S2100)
line of sight
21"
(FlexScan S2100)
94.07
pixels per inch
324 mm 324 mm
19" and 22" Widescreen Trading Confi guration
19"
(FlexScan S1961)
19"
(FlexScan S1961)
86.4
pixels per inch
301 mm 296 mm
24" Widescreen 21"
94.07
pixels per inch
1,496 mm
line of sight
22" Widescreen 19"
90.05
pixels per inch
1,292 mm
21"
(FlexScan S2100)
(FlexScan S2100)
19"
(FlexScan S1961)
(FlexScan S1961)
EIZO’s new R&D center at its corporate headquarters in Hakusan, Japan
5
SPECIFICATIONS
Panel
Panel Size and Type Viewing Angles (H, V)
Brightness / Contrast On/Off Response Time Midtone Response Time Native Resolution Active Display Size (H × V) Viewable Image Size Pixel Pitch Gamut Coverage Display Colors
Cabinet Colors
Dot Clock
Scanning Frequency (H, V)
Analog Digital
Input Signals
Input Terminals
USB Por t / Standard
Plug & Play
Power
Power Requirements Power Consumption Power Save Mode
Physical Specifi ca­tions
Height Adjustment Range
Tilt / Swivel / Pivot
Dimensions (W × H × D)
Net Weight
Auto Brightness Functions
Auto Adjustment Functions (analog only)
Display Mode Options
Screen-
Screen Adjustment
Manager OSD Adjust-
Color Adjustment
ment Functions
Power Save Settings
Analog
Digital Sound Other Settings
Audio
Certifi cations and Standards
Supplied Accessories
Warrant y
1
Average response time measured between each grayscale level of 31, 63, 95, 127, 159, 191, and 223. 2 Display with audio/video devices is not supported. 3 WindowMovie mode is selectable only when Auto Fine Contrast is active. 4 Bundled ScreenManager Pro for LCD is necessary to activate Auto Fine Contrast. Support for those functions varies with the graphics board used. 5 ScreenManager Pro for LCD is compatible with the Microsoft® Windows® Vista/XP/2000 operating systems only. 6 The usage time is limited to 30,000 hours or less, and the warranty period of the LCD panel and backlight is limited to three years from the date of purchase.
61 cm (24.1") TFT color LCD panel 61 cm (24.1") TFT color LCD panel 56 cm (22") TFT color LCD panel 178°, 178° (at contrast ratio of 10 :1) 170°, 160° (at contrast ratio of 10:1)
178°, 178° (at contrast ratio of 5 :1)
178°, 178° (at contr ast ra tio of 10:1)
450 cd/m2 / 1000:1 360 cd /m2 / 1000:1 250 cd /m2 / 1500:1 16 ms 5 ms (typical) 16 ms (typical)
1
6 ms 8 ms 1920 × 1200 1920 × 1200 1680 × 1050
518.4 × 324 mm 518.4 × 324 mm 473.8 × 296.1 mm Diagonal: 611 mm Diagonal: 611 mm Diagonal: 558 mm
0.270 × 0.270 mm 0.270 × 0.270 mm 0.282 × 0.282 mm ––92% of Adobe RGB, 92% vs NTSC
16.77 million from a palette of 1.04 billion 16.77 million from a palette of 1.04 billion 16.77 million from a palette of 1.04 billion Gray, Black Gray, Black Gray, Black Analog: 202.5 MHz, Digital: 162 MHz Analog: 202.5 MHz, Digital: 162 MHz Analog: 150 MHz, Digital: 120 MHz 24 – 94 KHz, 49 – 86 Hz 24 – 94 KHz, 49 – 86 Hz 24 – 82 KHz, 49 – 86 Hz 31 – 76 KHz, 59 – 61 Hz (VGA Text : 69 – 71 Hz) 31 – 76 KHz, 59 – 61 Hz (VGA Text : 69 – 71 Hz) 31 – 65 KHz, 59 – 61 Hz (VGA Text : 69 – 71 Hz) Analog: RGB Analog, Digital : DVI Standard 1.0 Analog: RGB Analog, Digital : DVI Standard 1.0 Analog: RGB Analog, Digital : DVI Standard 1.0 D-Sub mini 15 pin, DVI-I 29 pin (switchable), HDCP
2
supported
D-Sub mini 15 pin, DVI-I 29 pin (switchable), HDCP
2
supported
D-Sub mini 15 pin, DVI-I 29 pin (switchable), HDCP
2
supported 1 upstream, 2 downstream / USB Standard Rev. 2.0 1 upstream, 2 downstream / USB Standard Rev. 2.0 1 upstream, 2 downstream / USB Standard Rev. 2.0 VESA DDC/CI, DDC 2B VESA DDC/CI, DDC 2B VESA DDC/CI, DDC 2B AC 100 – 120 V, 200 – 240 V: 50 / 60 Hz AC 100 – 120 V, 200 – 240 V: 50 / 60 Hz AC 100 – 120 V, 200 – 240 V: 50 / 60 Hz 110 W (maximum) , 34 W (typical) 110 W (maximum), 34 W (typical) 75 W (maximum), 38 W (typical) Less than 2 W Less than 2 W Less than 2 W With Height Adjustable Stand : 82 mm
With EzUp Stand: 153.1 mm With Height Adjustable Stand : 40° Up, 0° Down / 35°
Right, 35° Left / 90°; With EzUp Stand: 25° Up, 0° Down / 172° Rig ht, 172 ° Left / 90°
With Height Adjustable Stand : 566 × 456 – 538 ×
208.5 mm; With EzUp Stand: 566 × 380.4 – 533.5 ×
279.9 – 307.6 mm; With QM1: 566 × 367 × 101 mm With Height Adjustable Stand : 10.6 Kg; With EzUp Stand:
12.4 Kg; With QM1: 8.3kg
With Height Adjustable Stand: 82 mm With EzUp Stand: 153.1 mm
With Height Adjustable Stand : 40° Up, 0° Down / 35° Right, 35° Left / 90°; With EzUp Stand: 25° Up, 0° Down / 172° Right, 172° Left / 90°
With Height Adjustable Stand : 566 × 456 – 538 ×
208.5 mm; With EzUp Stand: 566 × 380.4 – 533.5 ×
279.9 – 307.6 mm; With QM1: 566 × 367 × 101 mm With Height Adjustable Stand : 10.6 Kg; With EzUp Stand:
12.4 Kg; With QM1: 8.3kg
With Height Adjustable Stand : 82 mm
With EzUp Stand: 165 mm
With Height Adjustable Stand : 40° Up, 0° Down / 35°
Right, 35° Left / 90°; With EzUp Stand: 25° Up, 0° Down /
172° Right, 172° Left / 90°
With Height Adjustable Stand : 507 × 439 – 521 ×
230 mm; With EzUp Stand: 507 × 351.5 – 516.5 ×
279.9 – 296.4 mm; With QM1: 507 × 333 × 90 mm
With Height Adjustable Stand : 11.2 Kg; With EzUp Stand :
12.5 Kg; With Q M1: 8.4 Kg Auto Brightness Stabilization, BrightRegulator Auto Brightness Stabilization, BrightRegulator Auto Brightness Stabilization, BrightRegulator Auto Setup Auto Setup Auto Setup Fine Contrast (Text, Picture, Movie, sRGB, Custom,
WindowMovie Clock, Phase, Position, Range Adjustment (Auto), Signal
Filter, Screen Size (full screen, enlarge, normal), Smooth­ing (5 stages), Border Intensity
Brightness, Contrast, Gamma, Temperature (in 500 K increments from 4,000 K – 10,000 K including 9,300 K), Saturation, Hue, Gain, Reset
3
), Auto Fine Contrast
4
Fine Contrast (Text, Picture, Movie, sRGB, Custom, WindowMovie3), Auto Fine Contrast
Clock, Phase, Position, Range Adjustment (Auto), Signal Filter, Screen Size (full screen, enlarge, normal), Smooth­ing (5 stages), Border Intensity
Brightness, Contrast, Gamma, Temperature (in 500 K increments from 4,000 K – 10,000 K including 9,300 K), Saturation, Hue, Gain, Reset
4
Fine Contrast ( Text, Picture, Movie, sRGB, Custom, WindowMovie3), Auto Fine Contrast
Clock, Phase, Position, Range Adjustment (Auto), Signal Filter, Screen Size (full screen, enlarge, normal), Smooth­ing (5 stages), Border Intensity
Brightness, Contrast, Gamma, Temperature (in 500 K increments from 4,000 K – 10,000 K including 9,300 K), Saturation, Hue, Gain, Reset
4
PowerManager (VESA DPMS) PowerManager (VESA DPMS) PowerManager (VESA DPMS) PowerManager (DVI DMPM) PowerManager (DVI DMPM) PowerManager (DVI DMPM) Volume (adjustable with front panel volume buttons) Volume (adjustable with front panel volume buttons) Volume (adjustable with front panel volume buttons) Signal Switching, Product Information (product name,
serial number, resolution, operating time), OSD Menu Settings, Adjustment Lock, DDC/CI Lock, Languages (English, French, German, Italian, Japanese, Simplifi ed Chinese, Spanish, Swedish, Traditional Chinese), Beep, BrightRegulator, Power Indicator, Off Timer, Reset
Signal Switching, Product Information (product name, serial number, resolution, operating time), OSD Menu Settings, Adjustment Lock, DDC/CI Lock, Languages (English, French, German, Italian, Japanese, Simplifi ed Chinese, Spanish, Swedish, Traditional Chinese), Beep, BrightRegulator, Power Indicator, Off Timer, Reset
Signal Switching, Product Information (product name, serial number, resolution, operating time), OSD Menu Settings, Adjustment Lock, DDC/CI Lock, Languages (English, French, German, Italian, Japanese, Simplifi ed Chinese, Spanish, Swedish, Traditional Chinese), Beep,
BrightRegulator, Power Indicator, Off Timer, Reset Dual 0.5 W built-in speakers, input / headphone jacks Dual 0.5 W built-in speakers, input / headphone jacks Dual 0.5 W built-in speakers, input / headphone jacks TCO’03, TÜV/Ergonomics (including ISO 13406-2),
TÜV/GS, c-Tick, CE, CB, UL (cTÜVus), CSA (cTÜVus), FCC­B, Canadian ICES-003-B, TÜV/S, VCCI-B, EPA ENERGY
®
, RoHS, WEEE, EIZO Eco Products 2006
STAR AC power cord, signal cables ( DVI-D – DVI-D, D-Sub – D-
Sub), USB cable, audio cable, EIZO LCD Utility Disk (PDF user’s manual, ScreenManager Pro for LCD5, ICC Profi le), setup guide, 4 screws for mount option, warranty card, cable holder (EzUp stand option only)
6
Five Years
TCO’03, TÜV/Ergonomics (including ISO 13406-2), TÜV/GS, c-Tick, CE, CB, UL (cTÜVus), CSA (cTÜVus), FCC­B, Canadian ICES-003-B, TÜV/S, VCCI-B, EPA ENERGY STAR®, RoHS, WEEE, EIZO Eco Products 2006
AC power cord, signal cables ( DVI-D – DVI-D, D-Sub – D­Sub), USB cable, audio cable, EIZO LCD Utility Disk (PDF user’s manual, ScreenManager Pro for LCD5, ICC Profi le), setup guide, 4 screws for mount option, warranty card, cable holder (EzUp stand option only)
6
Five Years
TCO’03, TÜV/Ergonomics (including ISO 13406-2),
TÜV/GS, c-Tick, CE, CB, UL (cTÜVus), CSA (cTÜVus), FCC-
B, Canadian ICES-003-B, TÜV/S, VCCI-B, EPA ENERGY
STAR®, RoHS, WEEE, EIZO Eco Products 2006
AC power cord, signal cables ( DVI-D – DVI-D, D-Sub – D-
Sub), USB cable, audio cable, EIZO LCD Utility Disk (PDF
user’s manual, ScreenManager Pro for LCD5, ICC Profi le),
setup guide, 4 screws for mount option, warranty card,
cable holder (EzUp stand option only)
6
Five Years
6
56 cm (22") TFT color LCD panel 51 cm (20.1") TFT color LCD panel 51 cm (20.1") TFT color LCD panel 170°, 160° (at contrast ratio of 10:1)
178°, 178° (at contrast ratio of 5 :1)
2
300 cd/m
/ 1000:1 300 cd /m2 / 900 :1 300 cd /m2 / 1000:1
178°, 178° (at contrast ratio of 10 :1) 170°, 170° (at contrast ratio of 10 :1)
176°, 176° (at contr ast ra tio of 5:1)
5 ms (typical) 16 ms (typical) 5 ms (typical) –8 ms– 1680 × 1050 1680 × 1050 1680 × 1050
473.8 × 296.1 mm 433.4 × 270.9 mm 433.4 × 270.9 mm Diagonal: 558 mm Diagonal: 511 mm Diagonal: 511 mm
0.282 × 0.282 mm 0.258 × 0.258 mm 0.258 × 0.258 mm –––
16.77 million from a palette of 1.04 billion 16.77 million from a palette of 1.04 billion 16.77 million from a palette of 1.04 billion Gray, Black Gray, Black Gray, Black Analog: 150 MHz, Digital: 120 MHz Analog: 150 MHz, Digital: 120 MHz Analog: 150 MHz, Digital: 120 MHz 24 – 82 KHz, 49 – 86 Hz 24 – 82 KHz, 49 – 86 Hz 24 – 82 KHz, 49 – 86 Hz 31 – 65 KHz, 59 – 61 Hz (VGA Text : 69 – 71 Hz) 31 – 65 KHz, 59 – 61 Hz (VGA Text : 69 – 71 Hz) 31 – 65 KHz, 59 – 61 Hz (VGA Text : 69 – 71 Hz) Analog: RGB Analog, Digital : DVI Standard 1.0 Analog: RGB Analog, Digital : DVI Standard 1.0 Analog: RGB Analog, Digital: DVI Standard 1.0 D-Sub mini 15 pin, DVI-I 29 pin (switchable), HDCP
2
supported
D-Sub mini 15 pin, DVI-I 29 pin (switchable), HDCP
2
supported
D-Sub mini 15 pin, DVI-I 29 pin (switchable), HDCP
2
supported 1 upstream, 2 downstream / USB Standard Rev. 2.0 1 upstream, 2 downstream / USB Standard Rev. 2.0 1 upstream, 2 downstream / USB Standard Rev. 2.0 VESA DDC/CI, DDC 2B VESA DDC/CI, DDC 2B VESA DDC/CI, DDC 2B AC 100 – 120 V, 200 – 240 V: 50 / 60 Hz AC 100 – 120 V, 200 – 240 V: 50 / 60 Hz AC 100 – 120 V, 200 – 240 V: 50 / 60 Hz 60 W (ma ximum), 31 W (typical) 70 W (maximum), 29 W (typical) 60 W (maximum), 24 W (typical) Less than 1 W Less than 2 W Less than 1 W With Height Adjustable Stand : 82 mm
With EzUp Stand: 165 mm With Height Adjustable Stand : 40° Up, 0° Down / 35°
Right, 35° Left / 90°; With EzUp Stand: 25° Up, 0° Down / 172° Rig ht, 172 ° Le ft / 90°
With Height Adjustable Stand : 507 × 439 – 521 × 230 mm; With EzUp Stand: 507 × 351.5 – 516.5 ×
279.9 – 296.4 mm; With QM1: 507 × 333 × 90 mm With Height Adjustable Stand : 11.2 Kg; With EzUp Stand :
12.5 Kg; With QM1: 7.4 Kg
With Height Adjustable Stand : 82 mm With EzUp Stand: 165 mm
With Height Adjustable Stand : 40° Up, 0° Down / 35° Right, 35° Left / 90°; With EzUp Stand: 25° Up, 0° Down / 172° Rig ht, 172 ° Le ft / 90°
With Height Adjustable Stand : 469 × 427 – 509 ×
208.5 mm; With EzUp Stand: 469 × 339.5 – 504.5 ×
279.9 – 291.9 mm; With QM1: 469 × 309 × 85.5 mm With Height Adjustable Stand : 9.6 Kg; With EzUp Stand:
11.4 Kg; With QM1: 7.3 Kg
With Height Adjustable Stand: 82 mm
With EzUp Stand: 165 mm
With Height Adjustable Stand : 40° Up, 0° Down / 35°
Right, 35° Left / 90°; With EzUp Stand: 25° Up, 0° Down /
172° Right, 172° Left / 90°
With Height Adjustable Stand : 469 × 427 – 509 ×
208.5 mm; With EzUp Stand: 469 × 339.5 – 504.5 ×
279.9 – 291.9 mm; With QM1: 469 × 309 × 85.5 mm
With Height Adjustable Stand : 9.6 Kg; With EzUp Stand:
11.4 Kg; With QM1: 6.4 Kg BrightRegulator BrightRegulator BrightRegulator Auto Setup Auto Setup Auto Setup Fine Contrast ( Text, Picture, Movie, sRGB, Custom,
WindowMovie Clock, Phase, Position, Range Adjustment (Auto), Signal
Filter, Screen Size (full screen, enlarge, normal), Smooth­ing (5 stages), Border Intensity
Brightness, Contrast, Gamma, Temperature (in 500 K increments from 4,000 K – 10,000 K including 9,300 K), Saturation, Hue, Gain, Reset
3
), Auto Fine Contrast
4
Fine Contrast ( Text, Picture, Movie, sRGB, Custom, WindowMovie3), Auto Fine Contrast
Clock, Phase, Position, Range Adjustment (Auto), Signal Filter, Screen Size (full screen, enlarge, normal), Smooth­ing (5 stages), Border Intensity
Brightness, Contrast, Gamma, Temperature (in 500 K increments from 4,000 K – 10,000 K including 9,300 K), Saturation, Hue, Gain, Reset
4
Fine Contrast ( Text, Picture, Movie, sRGB, Custom, WindowMovie3), Auto Fine Contrast4
Clock, Phase, Position, Range Adjustment (Auto), Signal Filter, Screen Size (full screen, enlarge, normal), Smooth­ing (5 stages), Border Intensity
Brightness, Contrast, Gamma, Temperature (in 500 K increments from 4,000 K – 10,000 K including 9,300 K),
Saturation, Hue, Gain, Reset PowerManager (VESA DPMS) PowerManager (VESA DPMS) PowerManager (VESA DPMS) PowerManager (DVI DMPM) PowerManager (DVI DMPM) PowerManager (DVI DMPM) Volume (adjustable with front panel volume buttons ) Volume ( adjustable with front panel volume buttons) Volume (adjustable with front panel volume buttons) Signal Switching, Product Information (product name,
serial number, resolution, operating time), OSD Menu Settings, Adjustment Lock, DDC/CI Lock, Languages (English, French, German, Italian, Japanese, Simplifi ed Chinese, Spanish, Swedish, Traditional Chinese), Beep, BrightRegulator, Power Indicator, Off Timer, Reset
Signal Switching, Product Information ( product name, serial number, resolution, operating time), OSD Menu Settings, Adjustment Lock, DDC/CI Lock, Languages (English, French, German, Italian, Japanese, Simplifi ed Chinese, Spanish, Swedish, Traditional Chinese), Beep, BrightRegulator, Power Indicator, Off Timer, Reset
Signal Switching, Product Information (product name,
serial number, resolution, operating time), OSD Menu
Settings, Adjustment Lock, DDC/CI Lock, Languages
(English, French, German, Italian, Japanese, Simplifi ed
Chinese, Spanish, Swedish, Traditional Chinese), Beep,
BrightRegulator, Power Indicator, Off Timer, Reset Dual 0.5 W built-in speakers, input / headphone jacks Dual 0.5 W built-in speakers, input / headphone jacks Dual 0.5 W built-in speakers, input / headphone jacks TCO’03, TÜV/Ergonomics (including ISO 13406-2),
TÜV/GS, c-Tick, CE, CB, UL (cTÜVus), CSA (cTÜVus), FCC­B, Canadian ICES-003-B, TÜV/S, VCCI-B, EPA ENERGY
®
, RoHS, WEEE, EIZO Eco Products 2006
STAR AC power cord, signal cables ( DVI-D – DVI-D, D-Sub – D-
Sub), USB cable, audio cable, EIZO LCD Utility Disk (PDF user’s manual, ScreenManager Pro for LCD5, ICC Profi le), setup guide, 4 screws for mount option, warranty card, cable holder (EzUp stand option only)
6
Five Years
TCO’03, TÜV/Ergonomics (including ISO 13406-2), TÜV/GS, c-Tick, CE, CB, UL (cTÜVus), CSA (cTÜVus), FCC­B, Canadian ICES-003-B, TÜV/S, VCCI-B, EPA ENERGY STAR®, RoHS, WEEE, EIZO Eco Products 2006
AC power cord, signal cables ( DVI-D – DVI-D, D-Sub – D­Sub), USB cable, audio cable, EIZO LCD Utility Disk (PDF user’s manual, ScreenManager Pro for LCD5, ICC Profi le), setup guide, 4 screws for mount option, warranty card, cable holder (EzUp stand option only)
6
Five Years
TCO’03, TÜV/Ergonomics (including ISO 13406-2),
TÜV/GS, c-Tick, CE, CB, UL (cTÜVus), CSA (cTÜVus), FCC-
B, Canadian ICES-003-B, TÜV/S, VCCI-B, EPA ENERGY
STAR®, RoHS, WEEE, EIZO Eco Products 2006
AC power cord, signal cables ( DVI-D – DVI-D, D-Sub – D-
Sub), USB cable, audio cable, EIZO LCD Utility Disk (PDF
user’s manual, ScreenManager Pro for LCD5, ICC Profi le),
setup guide, 4 screws for mount option, warranty card,
cable holder (EzUp stand option only)
6
Five Years
7
© 2007 Eizo Nanao Corporation.
FlexScan and EIZO are registered trademarks of Eizo Nanao Corporation.
Specifi cations are subject to change without notice.
Published on chlorine-free paper.
1
(070501C) Printed in Japan 12, 2007, 3K
153 Shimokashiwano, Hakusan, Ishikawa 924-8566 Japan
Phone +81-76-277-6792 Fax: +81-76-277-6793
www.eizo.com
Loading...
