Widescreen LCD Monitors
FlexScan EV
A Simple Equation For Economy
2
165
mm
Right
90°
30°
344°
Tilt
Height
Adjustment
Portrait Swivel
The FlexScan EV series embodies EIZO’s
“EcoView” concept of combining ergonomic
and environmental features for an economi-
cal result. A compact design, flexible stand,
and energy-saving LED backlights make these
monitors ideal for trading floors, government
facilities, offices, and homes.
Ergonomics
Clear View from Different Angles
The FlexScan EV2335W has a non-glare IPS panel
with 178° viewing angles so it exhibits minimal
change in contrast and hue when viewed from off
center, making it ideal for a multi-monitor setup.
The FlexScan EV2315W has 170° vertical and 160°
horizontal viewing angles. It comes with an “Up
View” function which minimizes the washing out of
colors for improved visibility in environments where
the user must look up to see the screen.
Panel with narrow
viewing angles
Up View Off Up View On
IPS panel
Paper Mode and EyeCare Filter
Reduce Eye Fatigue
Designed to reduce eye fatigue, Paper mode simulates
the look of printed paper and helps prevent eyestrain
when reading documents. What’s more, a new feature called EyeCare Filter, available with the bundled
ScreenManager Pro software, comes with several
filter patters that resemble different types of paper.
sRGB Mode
Paper Mo de
Versatile Positioning
These monitors come with the highly versatile
FlexStand 2 which offers tilt, swivel, portrait
rotation, laptop-like screen placement, and 165 mm
of height adjustment.
Adjustable to Just 1% of
Maximum Brightness
In a dimly-lit work environment, a monitor with low
brightness settings will be more comfortable to use.
Both models come with LED backlights that allow for
adjusting the brightness to just 1% (about 3 cd/m2)
of the maximum. With typical CCFL backlights
the lowest you could adjust to would be a much
brighter 20%.
250 cd/ m2 (100% brightnes s)3 cd/m2 (1% brightness)
EyeCare Manager
EIZO’s EyeCare Manager, another feature available
with the bundled ScreenManager Pro software,
prompts workers to take scheduled breaks to avoid
eye fatigue caused by prolonged monitor use. EyeCare
also totals and displays on-screen the monitors’ usage
hours for each day and month to promote worker
awareness of how much time they spend in front of
their monitors.
EyeCare
reminds workers
to take regular
breaks to prevent eye fatigue.
Choice of filter patterns
Paper Mo de with EyeCare Filter
3
Network
CentralPC
Secondary
power on/off
PC power
on/off
Control button
lock
Brightness
control
Receive data
ON
Auto EcoView
on/off
ON
Power save command
ON
Increases in Quantity of Monitor Work
Quanti ty of work
Measurement Condition
Standard
(maximum brightness)
Appropriate
brightness
Appropriate brightness
+ correct working posture,
regular breaks
[%]
115
110
105
100
0
4.6%
increase
7. 9%
increase
100
%
104.6%
112.5%
Environment
Auto EcoView Sensor
Economy
Environmentally-Friendly LED Backlight
Both models use an LED
backlight which contains
no mercury. The backlight
also provides significant
power savings compared to
conventional CCFL backlights,
requiring just 16 watts during normal use and less
than 0.1 watts in power-save mode.
Optimized Brightness
Two original EIZO features are included for optimal
screen brightness. Auto EcoView measures the
ambient light and automatically adjusts the screen’s
brightness accordingly. A new function called
EcoView Optimizer fine-tunes these changes by
further adjusting the screen’s brightness depending on
the kind of content being displayed. Together, these
two features trim power usage by up to 54% while
reducing eye fatigue.
Improved Work Efficiency,
Reduced Visual Fatigue
EIZO conducted a survey to establish the relationship
between eye fatigue and monitor use. The results
showed that features like Auto EcoView and
ergonomic stands helped reduce eye fatigue and
improved work efficiency by 12.5%.
Lower Power Consumption
for Greater Savings
Auto EcoView cuts power consumption by up to 54%
compared to operating the monitor at the default
brightness of 100%.
Model* Auto EcoView OFF* Auto EcoView ON Power Reduction
FlexScan EV2335 W 35 W 16 W 54%
FlexScan EV2315W 31 W 16 W 48%
*Figures for Auto E coView turned off as sume monitors are set to t he default factory brightness of 100 %.
Recycled Plastic
The front and rear cabinets as well as the front
buttons are partially made of recycled plastic.
Power Management Software
EIZO EcoView NET software allows your organization to
reduce its electric bills while minimizing its burden on the
environment by centralizing control over the power settings of monitors on a network. For FlexScan EV series
and other EIZO monitors that support DDC/CI, you can
adjust the brightness, turn the Auto EcoView function on
and off, and lock the control buttons to prevent tampering
with screen settings. You can also switch a PC's primary
power and a monitor's secondary power on and off
regardless of the manufacturer.
EcoView NET summarizes and displays how much power
is saved for each monitor as a result of using it over a
5-Year Manufacturer’s Limited Warranty
EIZO backs these monitors with a
5-year warranty. This makes them
an investment that pays off over time
— doing away with worries of frequent product
replacement and resultant downtime.
specified period of time. It is compatible with various Windows operating systems and is available free of charge.
Please see www.eizo.com for details.
DisplayPort Connectivity
,THPS
>VYK7YVJLZZVY
)YV^ZLY
A DisplayPort input with the FlexScan EV2335W
allows digital audio and video signal transmission via
a single, high-bandwidth cable at distances up to 15
meters without any signal degradation. DVI-D and
D-Sub inputs are also included with both monitors.
Built-In Speaker and Headphone Jack
One 0.5-watt internal speaker and a headphone jack
are included.
Smooth Playback of Moving Images
An overdrive circuit on the FlexScan EV2335W
reduces gray-to-gray response time of just 6 ms to
ensure that moving images look clean and sharp.
Detailed Color Control
The OSD menu offers a wide array of color adjustment
function including brightness, contrast, gamma,
saturation, hue, gain, and color temperature from
4,000 K to 10,000 K in 500 K increments.
Preset Modes for Optimum Viewing
Paper, Movie, sRGB, and two Custom (user-defined
settings) preset modes are included for optimum
viewing of different kinds of content.
ScreenManager Pro
Also bundled, this software lets you adjust your
monitor’s color with your mouse rather than the OSD
menu buttons. You can also set the off timer, adjust
speaker volume, and assign a preset mode to a specific
application so that mode becomes active whenever the
application is in use (Windows 7 and Vista compatible).
EIZO ScreenSlicer
This bundled
software utility lets you more
effectively use
your screen
through partitioning. Simply drop
your windows
into configurable
Software windows aligned in partitioned areas.
partitioned areas and they will be aligned instantly
(Windows 7, Vista, and XP compatible).
Eco Labeling
These models comply with stringent international
labels for ergonomics and energy savings like TCO
Displays 5.1, EPA Energy Star, and EPEAT Gold.
Panel Size
Active Display Size (H × V )
Panel Type
Viewing Angles (H, V)
Brightness
Contrast
Response Time ( Typical )
Native Resolution
Pixel Pitch
Display Colors
D-Sub mini 15-pin
DVI-D 24 pin
DisplayPort
Analog Scanning Freq. (H, V )
Digital Scanning Freq. (H, V )
Speakers
Input / Output Terminals
Power Requirements
Power Consumption
Power Save Mode
Height Adj. Range
Tilt / Swivel / Pivot
Dimensions (W × H × D)
Net Weight
Auto EcoView
EcoView Index
EcoView Optimizer
Screen Adjustment
Color Adjustment
Power Management
Sound
Other S ettings
Preset Modes
Available Cabinet Colors
Certifications and
Standards
Supplied Accessories
Warranty
1
The bundled Scree nManager Pro for LCD i s needed to activate A uto Fine Contrast a nd is compatible w ith Windows 7/ Vista. 2 The usage
time is limited to 30 ,000 hou rs or less, and the wa rranty period of the LCD panel is limited to three years from t he date of purchase.
23" / 58 cm ( 584 mm diagonal) 23" / 58 cm ( 584 mm diagonal)
509.8 × 286.7 mm 509.8 × 286.7 mm
IPS (with overdrive circuit) TN
178°, 178° (at contrast ratio of 10:1) 170°, 160° (at contrast ratio of 10 :1)
2
250 cd /m
1000:1 1000:1
Gray-to-gray: 6 ms, black-white-black:
16 ms
1920 × 1080 (16: 9 aspect r atio) 1920 × 1080 (16: 9 aspect r atio)
0.2655 × 0.26 55 mm 0.2655 × 0.2655 mm
16.77 million, 8-bit display 16.77 million, 8-bit display
• •
• (with HDCP) • (with HDCP)
• (with HDCP) –
31 – 81 kHz, 55 – 76 Hz 31 – 68 kHz, 55 – 61 Hz
31 – 68 kHz, 59 – 61 Hz (VGA Text:
69 – 71 Hz)
0.5 W speaker 0.5 W speaker
3.5 mm stereo jack / 3.5 mm headphone
jack
AC 100 – 120 V / 200 – 240 V, 50 / 60 Hz AC 100 – 120 V / 200 – 240 V, 50 / 60 Hz
16 W (typical), 35 W (ma ximum) 16 W (typical), 31 W (maximum)
Less than 0.1 W Less than 0.1 W
With Stand: 165 mm With Stand: 165 mm
With Stand: 30° Up, 0° Down / 172° Right,
172° Left / 9 0°
With Stand:547 × 360 – 518 × 245.5 mm
Without Stand: 547 × 334 × 63.5 mm
With Stand: 6.7 kg, Without Stand: 4.0 kg With Stand: 6.2 kg, Without St and: 3.5 kg
• •
• •
• •
Clock, Phase, Position, Range (Auto) ,
Screen Size (full screen, enlarge, normal ),
Smoothing (5 stages) , Border Intensity
Brightness, Contrast, Gamma, Tempera-
ture, Saturation, Hue, Gain, Overdrive,
Reset
Power Save ( VESA DPM, DisplayPort Rev.
1.1a, and DVI DMPM ), Off Timer
Volume, Power Save, Source (DisplayPor t) Volume, Power S ave
Signal Switching, Product Information
(name, serial number, resolution, operating
time, etc.), OSD Menu Settings, Adjustment Lock, DDC /CI Lock, Languages (Eng-
lish, French, German, Italian, Japanese,
Simplified and Traditional Chinese, Span-
ish, Swedish), Power Indicator, Reset
Fine Contrast ( Paper, Movie, sRGB, User1,
User2 ), Auto Fine Contrast
Black, Gray & Black Black, Gray & Black
TCO Displays 5.1, EPEAT Gold (US), TÜV/
Ergonomics (including ISO 9 241-307),
TÜV/GS, C-tick, CE, CB, cTÜVus, FCC-B,
Canadian ICES-003-B, TÜV/S, VCCI-B,
EPA Energy Star, RoHS, WEEE
AC power cord, signal cables (DVI-D –
DVI-D, DisplayPort), audio cable, EIZO
LCD Utility Disk (PDF user’s manual,
ScreenManager Pro for LCD [ DDC/CI],
EIZO ScreenSlicer software, warrant y
card) , setup guide
2
Five Years
1
2
250 cd /m
black-white-black: 5 ms
31 – 68 kHz, 59 – 61 Hz
3.5 mm stereo jack / 3.5 mm headphone
jack
With Stand: 30° Up, 0° Down / 172° Right,
172° Left / 9 0°
With Stand: 547 × 360 – 518 × 245.5 mm
Without Stand: 547 × 334 × 63.5 mm
Clock, Phase, Position, Range (Auto) ,
Screen Size (full screen, enlarge), Smoothing (5 stages), Border Intensity
Brightness, Contrast, Gamma, Tempera-
ture, Saturation, Hue, Gain, Reset
Power Save ( VESA DPM, and DVI DMPM ),
Off Timer
Signal Switching, Up View, Product
Information (name, serial number,
resolution, operating time, etc.), OSD
Menu Settings, Adjustment Lock, DDC/
CI Lock, Languages (E nglish, French,
German, I talian, Japanese, Simplified and
Traditional Chinese, Spanish, Swedish) ,
Power Indicator, Reset
Fine Contrast ( Paper, Movie, sRGB, User1,
User2 ), Auto Fine Contrast
TCO Displays 5.1, EPEAT Gold (US), TÜV/
Ergonomics (including ISO 9 241-307),
TÜV/GS, C-tick, CE, CB, cTÜVus, FCC-B,
Canadian ICES-003-B, TÜV/S, VCCI-B,
EPA Energy Star, RoHS, WEEE
AC power cord, signal cables (DVI-D –
DVI-D, D-Sub – D-Sub), audio cable,
EIZO LCD Utility Disk ( PDF user’s manual,
ScreenManager Pro for LCD [ DDC/CI],
EIZO ScreenSlicer software, warrant y
card) , setup guide
2
Five Years
1
153 Shimokashiwano, Hakusan, Ish ikawa 924-8566 Japan
Phone +81-76-277-6792 Fax: +81-76-277- 6793
www.eizo.com
© 2011 Eizo Nanao Corporation
All product names and logos ar e tradema rks or registered t rademar ks of their r espective compa nies. EcoView Net is a trademark, and FlexScan and EIZO are regis tered
trademarks of Eizo N anao Corporat ion.
Specifi cations are subjec t to change w ithout n otice.
Loading...
