LE-AS 18 S

EINHELL LE-AS 18 S Operating Instructions Manual

Download
LE-AS 18 S
Operating Instructions
Battery Powered Hammer Drill / Screwdriver with Adjustable Torque
Art.-No.: 45.131.71 I.-No.: 01016
Important: Read and note the operating
instructions and safety regulations before using!
2
3
1. Layout:
1: Torque adjustment facility 2: Bit holder 3: Forward / Reverse selector switch 4: On/Off switch 5: Battery pack 6: Battery charger 7: Selector switch for 1st/2nd gear 8: Pushlock button 9: Selecting drill or hammer mode
2. Safety information
Please refer to the booklet included in delivery for the safety instructions.
3. Important information
Be sure to read the following information before you use your cordless screwdriver for the first time:
1. Charge the battery pack with the charger supplied. An empty battery pack requires a charging period of approximately 1 hour.
2. Only use sharp drill bits which are suitable for the purpose intended.
3. Always check for concealed electric cables, gas and water pipes BEFORE drilling or screwing in walls.
4. Starting up
Charging the NC battery pack
1. Take the rechargeable battery pack out of the handle, pressing the pushlock buttons at the side to do so.
2. Check that your mains voltage is the same as that marked on the rating plate of the battery charger. Plug the battery charger in the socket.
3. The green LED will come on. Insert the battery pack in the battery charger. The red LED will come on to indicate that the battery pack is being charged. The green LED will come on to indicate that charging has been completed. Empty battery packs will require approx. 1 hour for charging. The temperature of the battery pack may rise slightly during the charging operation. This is normal.
If the battery pack fails to become charged, please check
whether there is voltage at the socket-outletwhether there is proper contact at the charging
contacts on the charger.
If the battery still fails to become charged, please return
the chargerthe battery pack
to our Customer Service Department.
Timely recharging of the Ni-Cd battery pack is recommended in the interest of long battery life. Recharging is always necessary when you notice that the power of the battery-powered drill/screwdriver is decreasing.
Never allow the battery pack to discharge completely. This will result in damage to the Ni-Cd battery pack!
Adjusting the torque (1)
The battery-powered drill/screwdriver is equipped with a 16-step mechanical torque adjustment facility. The torque for a specific size of screw is selected with the set-collar (1). The correct torque depends on several factors:
on the type and hardness of material in questionon the type and length screws usedon the requirements needing to be met by the
screwed joint.
The clutch disengages with a grating sound to indicate when the set torque is reached.
Important! The tool must be at a standstill when you set the torque with the setting ring.
Drilling
For drilling purposes, move the set-collar to the last step „Drill“ (Figure 1). In this setting the slip clutch is inactive. The maximum torque is available in drilling mode.
Selecting drill or hammer mode (9)
For normal drilling, turn the front set-collar to the „drill“ symbol. For drilling with hammer action, turn the front set-collar to the „hammer“ symbol and the set-collar for torque adjustment to the „drill“ symbol.
Forward/Reverse switch (3)
With the slide switch above the On/Off switch you can select the direction of rotation of the battery-
4
GB
powered drill/screwdriver and secure it against being switched on accidentally. You can choose between clockwise and anticlockwise rotation. To avoid causing damage to the gearing it is advisable to change the direction of rotation only when the tool is at a standstill. The On/Off switch is blocked when the slide switch is in centre position.
On/Off switch (4)
Infinitely variable speed control is possible with the On/Off switch. The further you press the switch, the higher the speed of the battery-powered drill/screwdriver.
Changing over from 1st gear to 2nd gear (7)
You can work at a higher or lower speed depending on the position of the selector switch. To avoid damaging the gear unit you should only change over gears when the tool has stopped.
Screwdriving
We recommend using self-centering screws (e.g. Torx screws, recessed head screws) designed for reliable working. Be sure to use a bit that matches the screw in shape and size. Set the torque, as described elsewhere in these operating instructions, to suit the size of screw.
Technical data
Voltage supply 18 V = Speed 0-400/0-1150 rpm Torque 16 levels Forward and reverse rotation yes Chuck clamping width max. 10 mm Battery charging voltage 18 V = Battery charging current 2 A Mains voltage for charger 230 V ~ 50 Hz Sound pressure level LPA: 72,8 dB(A) Sound power level LWA: 83,8 dB(A) Vibration a
–
w
≤ 2,5 m/s
2
Weight 1,5 kg
Ordering replacement parts
Please quote the following data when ordering replacement parts:
Type of machineArticle number of the machineIdentification number of the machineReplacement part number of the part required
5
GB
6
Landau/Isar, den 23.03.2006
Vogelmann
Product-Management
Akkuschrauber LE-AS 18 S
Weichselgartner
Leiter QS Konzern
ISC GmbH Eschenstraße 6 D-94405 Landau/Isar
Konformitätserklärung
Art.-Nr.: 45.131.71 I.-Nr.: 01016 Archivierung: 4257070-19-4155050 Subject to change without notice
EN 60745-1; EN 60745-2-1; EN 60745-2-2; EN 55014-1; EN 55014-2; EN 61000-3-2;
EN 61000-3-3, EN 60335-1; EN 60335-2-29; EN 50366
98/37/EG
73/23/EWG_93/68/EEC
97/23/EG
89/336/EWG_93/68/EEC
90/396/EWG
89/686/EWG
87/404/EWG
R&TTED 1999/5/EG
2000/14/EG:
95/54/EG:
97/68/EG:
x
x
x
D
erklärt folgende Konformität gemäß EU-Richtlinie und Normen für Artikel
declares conformity with the EU Directive and standards marked below for the article
F
déclare la conformité suivante selon la directive CE et les normes concernant l’article
verklaart de volgende conformiteit in overeen­stemming met de EU-richtlijn en normen voor het artikel
E
declara la siguiente conformidad a tenor de la directiva y normas de la UE para el artículo
P
declara a seguinte conformidade de acordo com a directiva CE e normas para o artigo
S
förklarar följande överensstämmelse enl. EU­direktiv och standarder för artikeln
ilmoittaa seuraavaa Euroopan unionin direkti­ivien ja normien mukaista yhdenmukaisuutta tuotteelle
erklærer herved følgende samsvar med EU­direktiv og standarder for artikkel
заявляет о соответствии товара следующим директивам и нормам EC
izjavljuje sljedeću uskladjenost s odredbama i normama EU za artikl.
declarå urmåtoarea conformitate cu linia direc­toare CE μi normele valabile pentru articolul.
ürün ile ilgili olarak AB Yönetmelikleri ve Normlar∂ gere©ince aμa©∂daki uygunluk aç∂kla mas∂n∂ sunar.
‰ЛПТУВИ ЩЛУ ·ОfiПФ˘ıЛ Ы˘МКˆУ›· Ы‡МКˆУ· МВ ЩЛУ √‰ЛБ›· ∂∂ О·И Щ· ЪfiЩ˘Ф БИ· ЩФ ЪФ˚fiУ
I dichiara la seguente conformità secondo la
direttiva UE e le norme per l’articolo
attesterer følgende overensstemmelse i henhold til EU-direktiv og standarder for produkt
prohlašuje následující shodu podle směrnice EU a norem pro výrobek.
H
a következő konformitást jelenti ki a termékek­re vonatkozó EU-irányvonalak és normák szerint
pojasnjuje sledečo skladnost po smernici EU in normah za artikel.
deklaruje zgodność wymienionego poniżej artykułu z następującymi normami na podstawie dyrektywy WE.
vydáva nasledujúce prehlásenie o zhode podľa smernice EÚ a noriem pre výrobok.
деклаpиpа следното съответствие съгласно диpективите и ноpмите на ЕС за пpодукта.
заявляє про відповідність згідно з Директивою ЄС та стандартами, чинними для даного товару
deklareerib vastavuse järgnevatele EL direktiivi dele ja normidele
deklaruoja atitikti pagal ES direktyvas ir normas straipsniui
izjavljuje sledeçi konformitet u skladu s odred bom EZ i normama za artikl
Atbilstības sertifikāts apliecina zemāk minēto preču atbilstību ES direktīvām un standartiem
EE
SCG
7
WARRANTY CERTIFICATE
The product described in these instructions comes with a 2 year warranty covering defects. This 2-year warranty period begins with the passing of risk or when the customer receives the product. For warranty claims to be accepted, the product has to receive the correct maintenance and be put to the proper use as described in the operating instructions.
Your statutory rights of warranty are naturally unaffected during these 2 years.
This warranty applies in Germany, or in the respective country of the manufacturer’s main regional sales partner, as a supplement to local regulations. Please note the details for contacting the customer service center responsible for your region or the service address listed below.
GARANTIEURKUNDE
Auf das in der Anleitung bezeichnete Gerät geben wir 2 Jahre Garantie, für den Fall, dass unser Produkt mangelhaft sein sollte. Die 2-Jahres-Frist beginnt mit dem Gefahrenübergang oder der Übernahme des Gerätes durch den Kunden. Voraussetzung für die Geltendmachung der Garantie ist eine ordnungsgemäße Wartung entsprechend der Bedienungsanleitung sowie die be­stimmungsgemäße Benutzung unseres Gerätes.
Selbstverständlich bleiben Ihnen die gesetzlichen Gewähr­leistungsrechte innerhalb dieser 2 Jahre erhalten. Die Garan-
tie gilt für den Bereich der Bundesrepublik Deutschland oder der jeweiligen Länder des regionalen Hauptvertriebspartners als Er­gänzung der lokal gültigen gesetzlichen Vorschriften. Bitte be­achten Sie Ihren Ansprechpartner des regional zuständigen Kun­dendienstes oder die unten aufgeführte Serviceadresse.
ISC GmbH · International Service Center
Eschenstraße 6 · D-94405 Landau/Isar (Germany) Info-Tel. 0180-5 120 509 • Telefax 0180-5 835 830
Service- und Infoserver: http://www.isc-gmbh.info
Technical changes subject to change
Einhell UK Ltd
Unit 5 Morpeth Wharf Twelve Quays Birkenhead, Wirral
CH 41 1NG
Tel. 0151 61491500, Fax 0151 6491501
For EU countries only
Never place any electric tools in your household refuse.
To comply with European Directive 2002/96/EC concerning old electric and electronic equipment and its implementation in national laws, old electric tools have to be separated from other waste and disposed of in an environment-friendly fashion, e.g. by taking to a recycling depot.
Recycling alternative to the demand to return electrical devices: As an alternative to returning the electrical device, the owner is obliged to cooperate in ensuring that the device is properly recycled if ownership is relinquished. This can also be done by handing over the used device to a returns center, which will dispose of it in accordance with national commercial and industrial waste management legislation. This does not apply to the accessories and auxiliary equipment without any electrical components which are included with the used device.
The reprinting or reproduction by any other means, in whole or in part, of documentation and papers accompanying products is permitted only with the express consent of ISC GmbH.
EH 05/2006
