EIKI LC-XT5A Product Sheet

up-to 6,142 BTU/hr

LC-XT5

15,000 ANSI lumens bright with 90% uniformity and a 2000:1 contrast ratio.
Native XGA resolution. Compatible with inputs up-to UXGA and WXGA.
Supports analog and digital video input in all color standards up-to 1080p.
3 panel LCD imaging delivers a rich, color-saturated picture.
10-bit color processing, for superior color reproduction.
A wide range of optional lenses is available. Projects images up-to 600” diagonal.
Vertical and horizontal power lens shift and digital keystone correction.
Includes most professional input configurations, including 5BNC and DVI-D.
Optional modules include dual (HD/SD) SDI and HD wireless receiver.
Optional network module for projector monitoring and control.
Quick change lens installation system. Wide choice of lenses available.
Capable of extended operation (up to 23 hours / day) with regular maintenance.
Supplied software permits the preconfiguration of color adjustments.
Wireless/wired remote control. Digital zoom 50-700%.
3 year projector warranty.

LC-XT5

15,000 ANSI Lumens / XGA / 3LCD

Theater Series Projector

LC-XT5

Included Accessories:

Wireless/Wired Remote Control (with 2 AA Batteries), Color Management Software on CD-ROM,Lens Adapter x 2, Lens Spacer, Lens Light Block
Sheets x 3.

Optional Accessories:

& Blending Module, RJ45 Network Control Module, ATA-Style Shipping Case with Wheels and Telescoping Handle, Ceiling Mount, Ceiling Post & Plate,

Brightness
Contrast Ratio
Illumination Uniformity (corner to center)
Resolution and Aspect Ratio
Color Reproduction
Projection Lamp
Estimated Lamp Life
Imaging System
Total Pixels 2,359,296 ((1024x768) x 3)
Scanning Frequency

Image Diagonal
Image Width
Projector Elevation Adjustment (legs)
Maximum Pitch
Vertical Lens Shift (% of image height)
Horizontal Lens Shift (% of image width)
Vertical Keystone Correction
Horizontal Keystone Correction Digital: up-to 20° Left or Right
Image Orientation
Local Control / Power Management
RS232 Control Ports (In & Out)
Remote Projector Control
Wired Remote Control Port

Computer Input in Pixels up-to 1600x1200 (4:3), 1280x800 (16:10)
Analog 4x3 Inputs
Analog Wide Inputs
Digital 4x3 Inputs
Digital Wide Inputs
Image Signal Resizing Smart Scaling Technology

Quick Start Guide, Owner's Manual on CD-ROM, Power Cord, VGA Computer Input Cable (Dsub15 to Dsub15),

Wideangle, Midrange and Telephoto Lenses, Replacement Lamps, DVI, Dsub15, 5BNC, and HD/SD-SDI Input Modules, Warp

up-to 15,000 ANSI Lumens (with AH-22051 lens)

up-to 2000:1

90%

XGA (1024x768), 4:3

10-bit (1.07 billion colors)

330 Watts NSHA x 4

up-to 3,000 Hours

1.8 in (46 mm) LCD Panels x 3

Auto: H: 15-120 kHz; V: 48-120 Hz

up-to 230 MHzPixel Clock

40-600 in (102-1,524 cm)

2.67-40 ft (0.82-12.2 m)
up-to 6° Up

up-to 10° Up or Down

up-to 50% Up or Down

up-to 10% Left or Right

Digital: up-to 40° Up or Down

Normal, Reversed, Inverted

Full Function / Auto Shutdown

Dsub9 x 2

Wireless/Wired x 1

MiniStereo x 1

UXGA, SXGA+, SXGA, XGA, SVGA, VGA, MAC

WXGA

SXGA+, SXGA, XGA, SVGA, VGA

WXGA

Video Input Analog
Video Input Digital
Video Formats NTSC / PAL / SECAM / NTSC 4.43 / PAL-M&N
Image Signal Inputs

1a. Analog / Digital Dsub15 x 1
1b. Digital Computer / Digital Video with HDCP DVI-D x 1
2a. Analog (RGBHV) BNC x 5

Component Video (Y, Pb/Cb, Pr/Cr), 3BNC
Composite Video, 1BNC

2b. S-Video S-Video x 1

3. Unpopulated Module Bay

4. Unpopulated Module BayLens Changeable - Does not come with Lens
Fan Noise as low as 51 dBA
Cabinet Size (HxWxD)
Weight
Packaged Size (HxWxD)
PackagedWeight 111.3 lb (50.5 kg)
Power Requirements
Power Consumption
Heat
Power Cord 10 ft (3 m) Type C13, Detachable
Electrical Safety Compliance
Electromagnetic Compatibility
Security Facilities
Operating Temperature
User Maintenance Clean Air Filter, Change Lamps
UPC 4571194671940
Limited Warranty: to the original end-use customer only

Projector
Lamp

6 months ownership / 500 hours use (whichever occurs first)

9.9 x 22.9 x 32.1 in (25.2 x 58.2 x 81.6 cm)

480i/p, 575i/p, 720p, 1035i, 1080i

480p, 575p, 720p, 1035i, 1080i/p

80.5 lb (36.5 kg)

25.2 x 34.7 x 48.4 in (64 x 88 x 123 cm)
200-240V AC, 50/60 Hz

up-to 1,800 W

IEC / UL / cUL

FCC Class A, CE Mark

PIN Code and Key Locks

41-95°F (5-35°C)

3 years

Lamp contains Mercury.Do not put in trash. Dispose of as Hazardous Waste, according to Local, State or Federal Laws.

Eiki International, Inc., 30251 Esperanza, RanchoSanta Margarita, CA 92688-2132. Tel: [phone]; Fax: [phone], E-mail: [e-mail]

In Canada: 310 First St., Unit 2, P.O.Box 156, Midland, ON L4R 4K8. Tel: [phone], Fax: [phone], E-mail: [e-mail]

Specifications subject to change without notice. ©2010 Eiki International, Inc. Issued Nov. 8, 2010.

EIKI®is a registered trademarkof Eiki International, Inc.
