Eden WTDI User Manual [en, de, es, fr]
Eden WTDI
HI FIDELITY FOR LOW FREQUENCY
Quick Start Guide
DIRECT BOX PREAMP PEDAL
2 | HI FIDELITY FOR LOW FREQUENCY
EDEN | WTDI PEDAL |
SAFETY INSTRUCTIONS
HI FIDELITY FOR LOW FREQUENCY
| 3
EDEN | WTDI PEDAL |
SAFETY INSTRUCTIONS
4 | HI FIDELITY FOR LOW FREQUENCY
EDEN | WTDI PEDAL |
MANUAL CONTENT - 1
Manual Content:
1. Safety Information ................................2-3
2. Manual Content .....................................4
3. Eden Introduction ..................................5
4. WTDI Navigation ....................................6
5. Product Support ....................................7
6. Présentation Eden .................................8
7. WTDI Navigation ....................................9
8. Support Produit .....................................10-11
9. Eden Einführung ....................................12
10. WTDI Navigation ....................................13
11. Produkt-Support ....................................14
12. Eden Introducción ..................................15
13. WTDI Navegación ...................................16
14. Soporte de Producto ..............................17
15. エデンのご紹介 ........................................18
16. WTDIナビゲーション ...................................19
17. 製品サポート ...........................................20
18. WTDI Panel Navigation .............................21
HI FIDELITY FOR LOW FREQUENCY
| 5
EDEN | WTDI PEDAL |
INTRODUCTION - 2
Thank you for choosing Eden.
We hope that this product provides you with not only years of faithful service, but also the inspiration and capability
to take your music and express yourself in your own way.
At Eden we realize that having the right gear can mean the difference between having the condence and ability to perform
or not, so we strive to provide you with the tools that you need, whether at home, in the studio or
in a stadium.
Your new WTDI Direct box Preamp pedal is designed to provide you with great tone and performance and the ability to
truly take your tone anywhere.
This quick start guide is designed to provide you with the information you need to use your new pedal right
out of the box. Remember every instrument is different so to ensure you get the best performance you should
try various settings to ensure you get the most out of
your WTDI.
6 | HI FIDELITY FOR LOW FREQUENCY
EDEN | WTDI PEDAL |
PANEL NAVIGATION
- 3
WTDI Panel Navigation:
1. XLR out; Connect to your mixer or other outboard equipment.
2. Groundlift for XLR output; Lifts ground for XLR output.
3. Jack socket output; Connect your WTDI to your amplifier or other equipment from.
4. Gain; Controls the input gain for your WTDI. (Tip if your sound is distorting even with this setting on low reduce the
output volume from your instrument to remove distortion before increasing this control) .
5. Bass; Increase or cut the bass frequency level.
6. Enhance; Use this Eden EQ sweep to enhance your EQ.
7. Bass boost; Add a bass boost to your sound with this switch.
8. Bypass switch; Turn your pedal off and on.
9. Mid; Increase or cut the mid frequency level.
10. Compressor; Increase the level of this control for more compression or set to 0 to turn the compression feature off.
11. Mid shift; Toggle between 550hz and 2.2kz mid range frequencies.
12. Power input; Input your included power supply cord.
13. Treble; Increase or cut the mid frequency level with this control.
14. Master; Control the output level of your WTDI.
15. Input; Plug your instrument into your WTDI.
HI FIDELITY FOR LOW FREQUENCY
| 7
EDEN | WTDI PEDAL |
PRODUCT SUPPORT - 4
Your Eden equipment has been designed to provide you with years of faithful service however should you ever need help
with one of our products we have dedicated support teams all over the world. Visit your local Eden dealer or contact your
regional distributor for more details. Alternately visit our website to see if you can nd a solution www.edenamps.com
Simple rules to remember when using your unit:
DO: Keep your unit clean and free from dust and obstructions to ensure adequate cooling and maximum performance.
DO: Ensure you use the best quality cables and connections when using your unit for peak performance.
DON'T: Use this unit with any power supply that was not supplied by Eden. This unit requires a 15v dc supply and should not be used with
multi-way power supplies.
DON'T: Store liquids on or near the unit during use, or store in an overly humid environment.
DON'T: Modify or attempt to modify your unit, there are no user serviceable components inside. Any modication or repair by an unauthorized
technician will void any warranty oered in your region and can pose a serious risk of electrocution or death.
DON'T: Use your unit for any purpose other than for which it was intended.
REMEMBER: Follow all the warnings and instructions which are provided in this handbook, always keep this handbook for future reference.
Eden has tested or had the unit tested and approved for sale in your region. Any markings of approval and or warning labels
on an Eden product are provided to ensure you as a user are aware of the efforts Eden goes through so your product is
suitable for use in your country. If you have any concerns about anything relating to your product then please contact
Eden immediately.
Please check your individual unit for the relevant markings and symbols which may apply.
Merci d'avoir choisi Eden.
8 | HI FIDELITY FOR LOW FREQUENCY
EDEN | WTDI PEDAL |
INTRODUCTION - 5
Nous espèrons que ce produit vous apportera non seulement des annèes de bons et loyaux services mais ègalement
l'inspiration et la possibilitè pour vous et votre musique de vous exprimer comme vous le souhaitez.
Chez Eden, nous savons que le bon matèriel peut faire la diffèrence entre avoir ou non la conance et la capacitè de se
produire, aussi nous nous efforàons de vous fournir les outils dont vous avez besoin, que ce soit à la maison, en studio ou
dans un stade.
Votre nouvelle pèdale prèampli boótier de direct WTDI est conàue pour vous fournir un son et des performances
remarquables ainsi que la possibilitè de vraiment emporter votre son n'importe o˘.
Ce guide de prise en main est conàu pour vous fournir les informations dont vous avez besoin an d'utiliser
immèdiatement votre nouvelle pèdale. Rappelez-vous que chaque instrument est diffèrent, aussi pour vous garantir les
meilleures performances, vous devez essayer diffèrents règlages an de tirer le meilleur parti de votre WTDI.
