EcoFlow Wave 2
User Manual
V1.0
Disclaimer
Please read the product document and ensure that you understand it fully before using the
product. After reading this document, keep it for future reference. Improper use of this product
may cause serious injury to yourself or others, or cause product damage and property loss.
Once you use this product, it is deemed that you understand, approve and accept all the terms
and content in this document. EcoFlow is not liable for any loss caused by the user's failure to
use the product in compliance with the Disclaimer and Safety Instructions.
this document and all documents related to the product. This document is subject to changes
to obtain the latest product information.
Contents
Use 2
Grounding Guide 3
Overview 5
Light Effect 6
1
2
4
4
5
LCD 6
Control Buttons 7
8
How to Install 8
11
How to Drain 13
How to Clean 14
14
Model EFKT210
Cooling Capacity/Heating Capacity 1500/1800W (5100/6100BTU)
Temperature Setting Range
Refrigerant R290 (130g)
Air Flow Volume 290m³/h
Cooling/Heating Rated Input (AC) 550W/600W (AU: 580W/600W)*
Cooling/Heating Rated Input (DC) 495W/540W (AU: 520W/540W)*
Maximum Cooling/Heating Power 700W
AC Input
Car Charging Input 12V/24V 8A, 200W max
Solar Input 13A, 400W max
External Battery Pack Input 700W max
Supported (in cooling state)
Supported
IP Rating IPX4
Noise Level
Permissible Pressure Range
(High Pressure/Low Pressure)
2.24MPa/0.74MPa
Ambient Temperature for Operation
Ambient Temperature for Storage
Cooling/Heating (AC) 2.7/3.0 (AU: 2.6/3.0)*
Cooling/Heating (DC) 3.0/3.3 (AU: 2.9/3.3)*
Net Weight Approximately 14.5 kg (32.0 lbs)
Dimensions (L × W × H) 518×297×336 mm (20.4 x 11.7 x 13.2 inches)
1
EU/UK/CH/AU/ZA:
Maximum output power:
US: 0.071W
EU/UK/CH/AU/ZA: 16.54dBm
BR: 0.339W
Bluetooth
Maximum output power:
US: 0.005W
EU/UK/CH/AU/ZA: 0.02dBm
BR: 0.147W
*The parameters may vary due to local testing conditions.
Use
dioxide.
working in a wet location.
4. If the product is wet inside, immediately turn the power off, remove the power cord,
and place them in a safe open area. Stay away from the product until it is dry. Please
take measures to prevent electric shock when touching it. Do not operate or discard the
properly.
5. If there is dirt in any outlets, clean it with a dry cloth.
(such as a thunderstorm).
7. Do not touch product outlets with wires or other metal objects, otherwise the product may
short circuit.
2
10. If the product components or power cords are damaged, they must be repaired and
conditions.
11. Do not place the battery where the air pressure is extremely low, as this may cause
12. Do not stand or sit on the product.
13. Do not pile heavy objects on the product.
14. Do not obstruct the air inlet/outlet or exhaust pipe during operation.
15. During the operation or transportation of the product, please avoid external damages , such
as dropping the appliance in order to avoid harming the internal compressor. If the product
is tilted (for over 10 minutes) or impacted by a strong external force, immediately turn the
power off and remove the power cord. Leave it to stand for at least 2 hours before using.
16. Please store the product where it is dry and ventilated, and ensure that the distance
between the air inlet/outlet and the wall is >0.5 m.
channels.
18. Please keep the product out of the reach of pets. Children should not operate this product
without supervision.
implants or personal medical devices, such as pacemakers, cochlear implants, hearing
manufacturers about the restrictions on the use of relevant devices to ensure that a safe
distance is maintained between this product and the implanted medical devices (such as
21. This appliance can be used by children aged 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance in a safe way and
and maintenance should not be done by children without supervision.
22. This product should not be disposed with other household wastes
throughout the EU. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it responsibly to promote
the sustainable reuse of material resources. To return your used device,
please use the return and collection systems or contact the retailer where
the product was purchased. They can take this product for environmentally
safe recycling.
3
1. This product must be grounded. The product may fail when it is charged. The risk of
power cord which has a grounding conductor and a ground plug. The ground plug must be
connected to a socket with a ground wire in compliance with local laws.
2. Improper ground connection may lead to the risk of electric shock. If you are not sure
the EcoFlow app.
4
Wave 2
Safety Instructions, Quick
Start Guide & Warranty Card
Exhaust duct
adapter cover A
Window vent board
Exhaust duct
adapter cover B
Exhaust duct D
Exhaust duct
adapter cover C
Exhaust duct E
Winder
Drain pipe
The type of AC charging cable (pluggable/embedded) varies due to local regulatory
5
1. LCD
2. Control buttons
6. AC charging cable
3. Front air outlet fan blade
4. Ambient light
8. Solar/car charging socket (XT60)
9. Charging port cover
10. Winder socket
11. Rear air outlet 13. Drainage outlet & drainage
outlet connector
6
Pulsating blue Cooling status
Pulsating orange Heating status
Pulsating white Fan status
Solid red Error alarm
Flashing white Firmware update
2. Water level indicator
3. External drainage indicator
4. Cooling/Heating/Fan function
5. Max/Sleep/Eco mode
6. Fan speed
7
7. Timer (Supported in app settings only)
8. Remaining charge/discharge time
10. Temperature setting/Error code
11. Error alarm
12. Ambient/air outlet temperature
If Wave 2 is idle for 5 minutes, the LCD and ambient light will turn off automatically
(The power standby time can be set in the app). Press any button to wake them up.
Press and hold it for 3 seconds to shutdown.
Switch cooling /heating /fan functions.
When switching between cooling and heating, there will be 2 minutes of down time*
to protect the device.
and Bluetooth .
time is inaccurate. Please recheck it when Wave 2 starts cooling or heating.
Switch max /sleep /eco /custom modes.
In max mode, Wave 2 operates at high fan speed of 16°C (60°F) for cooling or 30°C
(86°F) for heating by default, and the temperature or fan speed cannot be changed.
In sleep or eco mode, it operates at low fan speed of 26°C (79°F) for cooling or 20°C
(68°F) for heating by default. For eco mode in cooling state, Wave 2 operates for 20
minutes in cooling, then blows air for 10 minutes, and repeats the process.
to switch temperature units .
/
.
8
Fan speed setting (low /medium /high ).
Press and hold it for 3 seconds to enable external drainage function *,
repeat the process to disable the function.
read before using the external drainage function.
When using the cooling or heating function, please make sure you've installed the exhaust
duct and adapter cover to Wave 2, otherwise it will affect the air conditioner's working
When the air conditioner is used in an enclosed space, you can get rid of waste air through
the exhaust ducts. The exhaust duct should not be excessively stretched or bent when it is
E
9
the board and the window, and vent the exhaust air through the ducts.
E
D
It is not suggested to use the exhaust duct in rainy and snowy weather to avoid
damaging the products.
10
outdoors and deliver cooling or heating through the front air outlet.
11
A
This product supports multiple power supply methods. Open the charging port cover before
using it, then power on. Please close the cover to prevent dust during charging, and wind the
AC charging cable around the winder.
For shutdown, please press and hold the power button before removing the charging
cable. Do not directly remove the cable to avoid damaging the battery cell.
and make sure the working current of the outlet should continuously exceed 10A .
AC charging
2 series are recommended) can be used to supply power to Wave 2. These products and
12
manual.
(XT150 DC output port is recommended)
DC charging
(Extra Battery connection cable)
AC charging
When charging
using the
car charging port,
if the car battery is too low.
current of 8A.
cigarette lighter.
sure that the car charging port and charging cable are securely connected to the
Make
Wave 2 supports 12V/24V car charging and a maximum charging
Solar panel
Solar panel charging cable
13
Car charging cable
Car charging port
If car or solar panel power is low or voltage is unstable, only fan function will work. If
station.
When the cooling function is on, condensation
When the heating function is in use or the ambient humidity is too
high, . Check the water
level indication on the LCD for more information. When it cannot collect anymore water,
Wave 2 will shut down automatically (switch to fan function if it is currently in cooling mode.).
Do not shake or move the air conditioner to avoid water leakage.
When the drain pipe is the drainage outlet, press and hold
the speed button for 3 seconds, and LCD displays [External drainage indicator]. Press and hold
it again to turn off drainage function. If not turned off, the product will continue to drain out
when reaching high water level.
A small amount of residual water will be left at the bottom of the water
tank after external drainage. Please remove the connecter, and tilt the unit back slightly until
the condensation is completely drained.
14
The air inlet may get blocked with large dust particles and impurities in the air during outdoor
mild detergent, dry them in the air, and then reassemble them.
1. Please close the socket cover after the unit is stored to prevent dust.
2. After the unit is stored after shutdown, manually drain the unit to prevent bacteria breeding
time.
3. It is recommended to store this product within the range of ambient temperature range of
metal objects.
15
