Welcome
This document describes how to install and use Echelon’s U10 and U20 USB
Network Interface products. The U10 and U20 USB Network Interfaces are lowcost, high-performance LONWORKS interfaces for USB-enabled PCs and
controllers. The U10 USB Network Interface connects directly to TP/FT-10 Free
Topology Twisted Pair (ANSI/CEA-709.3) L
quality removable connector, and is fully compatible with link powered channels.
The U20 USB Network Interface connects to PL-20 C-Band Power Line
(ANSI/CEA-709.2) L
circuit/power supply (either 120VAC with US plug, or 230VAC with Continental
Europe plug). The U20 USB Network Interface can also be connected directly to
10.8-18VDC power systems (such as those in automobiles, trucks and buses)
without a coupling circuit, or to virtually any powered line through a customersupplied coupling circuit/power supply.
The USB Network Interfaces are certified USB 2.0 compliant by the USB
Implementers Forum, work with USB 1.1 certified controllers, and work with
USB and Hi-Speed USB systems, peripherals and cables. The drivers are
available on an included CD-ROM, as well as on Microsoft
and are accepted into Microsoft's Designed for Windows XP logo testing program.
The interfaces also carry the CE, UL, cUL and TÜV agency listings.
ONWORKS channels through a high
ONWORKS channels through an included wall-plug coupling
®
Windows® Update,
The USB Network Interfaces can be used with virtually any PC-based
ONWORKS application, including all LNS
L
including but not limited to:
®
• LonMaker
• NodeBuilder
• Mini EVK Evaluation Kit
The USB Network Interfaces can also be used with the LonScanner
Analyzer.
Integration Tool
®
Development Tool
Related Documentation
The following documents may be useful to you when using the USB Network
Interface products. These documents can be downloaded from Echelon’s website
at www.echelon.com
• LNS Programmer’s Guide
• OpenLDV Programmer’s Guide
• PL 3120
• Neuron C Programmer’s Guide
:
®
/ PL 3150® Power Line Smart Transceiver Data Book
®
and OpenLDV™ based applications,
™
Protocol
System Requirements
• Pentium® III, 366MHz equivalent processor or higher
• Microsoft
LONWORKS USB Network Interface User’s Guide i
Windows XP, Windows 2000, or Windows Server 2003
• 128MB RAM or more as required by operating system
This chapter introduces the USB Network Interfaces, and
describes how to install the software included with the USB
Network Interfaces.
LONWORKS USB Network Interface User’s Guide 1
Overview
The USB Network Interfaces are low-cost, high-performance LONWORKS network
interfaces for USB-enabled PCs and controllers. Designed for use in L
control networks that require a PC for monitoring, managing and diagnosing the
network, the USB Network Interfaces are ideal for industrial control, building
automation, process control and transportation applications. The USB Network
Interfaces feature easy to install, auto-configuring drivers for Microsoft Windows
XP, Windows 2000 and Windows Server 2003, and are compatible with all LNS
and OpenLDV applications, as well as with the LonScanner Protocol Analyzer.
U10 USB Network Interface
The U10 USB Network Interface (U10 interface) connects to TP/FT-10
(ANSI/CEA-709.3) Free Topology L
detachable, quality network connector (included). The U10 interface is fully
compatible with TP/FT-10 channels with or without link power.
Figure 1.1 shows the U10 interface. The network connector is on the right side of
Figure 1.1, and the USB Series “A” plug is on the left side.
ONWORKS channels directly through a
ONWORKS
Figure 1.1 U10 USB Network Interface
U20 USB Network Interface
The U20 USB Network Interface (U20 interface) connects to PL-20 C-Band
Power Line (ANSI/CEA-709.2) L
coupling circuit/power supply. The U20 interface can also be connected directly
to 10.8-18VDC power systems (such as those in automobiles, trucks and buses)
without a coupling circuit, or to virtually any powered line through a customersupplied coupling circuit/power supply, as described in Appendix A, Alternate Power Line Coupling Circuit.
2LONWORKS USB Network Interface User’s Guide
ONWORKS channels through an included plug-in
Figure 1.2 shows the U20 interface. The coupling circuit/power supply
connection is on the right side of Figure 1.2, and the USB Series “A” plug is on
the left side.
Figure 1.2 U20 USB Network Interface
USB Network Interface LEDs
Each USB interface has three LEDs that you can use to determine the interface’s
current state. These LEDs become operational as soon as power is applied to the
interface’s USB Series “A” plug.
SVC LED
When the USB interface is not configured, the SVC LED (Service LED) will blink
on and off continuously, with a 2 second period and 50% duty cycle. After an
application opens and configures the interface, the SVC LED will turn off.
In addition, the SVC LED will illuminate for several seconds after you wink the
USB interface from the L
wink command allows you to differentiate one interface from another if you have
more than one USB interface attached to your PC. The L
application and the wink command are described in Chapter 2 of this document.
ONWORKS Interfaces application in Control Panel. The
ONWORKS Interfaces
TX LED
The TX LED (Transmit LED) illuminates when a message is sent through the
USB interface to the network. The LED will illuminate for at least 40ms at a
time. On TP/FT-10 channels, multiple messages can be transmitted with less
than 40ms between them. As a result, the TX LED may be illuminated for
extended periods of time on the U10 interface due to the transmission of multiple
closely-spaced messages.
RX LED
The RX LED (Receive LED) illuminates when the USB interface receives a
message from the network. This LED will illuminate for at least 40ms at a time.
On TP/FT-10 channels, multiple messages can be received with less than 40ms
between them. As a result, the RX LED may be illuminated for extended periods
of time on the U10 interface due to the receipt of multiple closely-spaced
messages.
LONWORKS USB Network Interface User’s Guide 3
