Page 1
ESBS-51
CPESBS51 05.15
WC
8
Precision MaxView
Digital Bathroom Scale
Model ESBS-51
EatSmart Products
Oak Brook, IL 60523
Call: 866-843-3905 (8 to 5 MST)
eatsmartproducts.com
Connect with EatSmart
EatSmart Products
EatSmartScales
EatSmart Products
EatSmartScales
www.eatsmartproducts.com
www.eatsmartblog.com
Page 2
3
2
Battery Installation and First Time Setup
1. This scale operates on 2 'AAA' batteries. Batteries are included and
located in the underside of the polyfoam packing. Unwrap batteries
before proceeding. Always replace both batteries at the same time: do
not combine old and new batteries. Do not mix Alkaline, Carbon-Zinc
(standard) or Nickel-Cadmium (rechargeable) batteries.
2. Locate the battery cover on the underside of the unit. Press the battery
cover tab inward and lift it to remove.
3. Insert batteries as indicated by the polarity symbols (+ and –) marked
inside the battery cover. Replace the battery cover by snapping into
place.
4. The scale needs to be initialized and calibrated before rst use and
after moving your scale. Place scale on at, hard surface. The harder
the surface the more accurate your readings will be. Carpeted or
uneven oors may affect accuracy.
5. Firmly press the glass platform to activate the backlight but do not
stand on the platform. Allow the scale to read '0.0' and wait for it to
turn off. Your scale is now calibrated and you can step on and weigh
yourself normally.
6. If you move the scale again you must repeat step #5 to calibrate again.
7. Replace batteries when the scale indicates 'Lo' on the display.
NOTE:
1. New batteries should last for approximately one year under moderate
use (less than 3 times daily). Batteries included with your scale are
trial batteries and may last a shorter length of time.
2. Dispose of batteries within the legal restrictions of local government.
3. Batteries may pose a choking hazard. As with all small items, do not
let children handle batteries. If swallowed, seek medical attention
immediately.
4. Do not dispose of batteries in re. Batteries may explode or leak.
Remove the batteries if the scale will not be used for a long period of
time.
INTRODUCTION
Thank you for purchasing an EatSmart Product. Your EatSmart Precision
MaxView Digital Bathroom Scale has been specically designed for your use,
with an easy to use interface and superior EatSmart accuracy. All of our
precision instruments for weight measurement are engineered and designed to
meet the highest quality standards.....to assure you years of uncompromising
accuracy and consistently dependable, convenient performance.
Please read this instruction manual carefully before use.
Your EatSmart Bathroom Scale comes with the following:
• EatSmart Digital Bathroom Scale
• Instruction Manual
• 2 AAA batteries located on the underside of the polyfoam packing
• 2 Year EatSmart Guarantee
Please ll out your purchase information for future reference:
Date Purchased: ___________________
Place of Purchase: __________________
Order ID (if any): __________________
OPERATION
If you have any questions please contact us -
eatsmartproducts.com.
Page 3
5
4
TROUBLESHOOTING
PROBLEM SOLUTION
Scale is inaccurate or weight varies
Place feet in center of glass platform and stand still.
Allow weight to lock in before looking down at display.
Flooring may be reason for uctuation. Use on the
hardest oor available for accuracy. Do not move scale
unnecessarily.
First weight is higher than normal
or weight reads 4.6 or 4.8 lbs and
then says “CAL”
Your scale must be allowed to auto-calibrate. Follow
instructions under “Operation” for proper use.
Scale displays “Err” Place scale on hard, at surface. Allow scale to shut off
and restart.
Scale displays “Lo” for low battery
No power
Check batteries for proper installation (polarities are
correct). Replace both worn batteries.
Problem persists or other conditions
Call Eat Smart for support at 866-843-3905 (8 to 5 MST).
CARE & MAINTINANCE
To protect and maintain your EatSmart bathroom scale in the best
possible condition follow these directions as closely as possible.
1. Store and operate the unit in a safe dry location.
Drastic changes in temperature over time can affect the quality of
weight measurement. Do not expose to direct sunlight, extreme hot/
cold or high humidity.
2. Clean with a damp, soft cloth. Avoid abrasive cleaners and never sink
or submerge in water.
3. Remove batteries if not in use for three months or longer.
4. Do not store scale where you store cleaning chemicals. The vapors
from some household products may affect the electronic components
of your scale. Do not store scale on its side.
5. This scale is designed to read weights between 35 and 400 lbs/ 15 and
180kgs/ 2 and 28 st 8 lbs. on it.
6. Use unit consistent with instructions provided in this manual.
Weighing Operation
Your EatSmart Bathroom Scale operates as a basic body
weighing scale. No special programming is required.
1. Select your desired measurement unit. Your scale is set
to default to pounds at the factory but you can switch the
measurements to kilograms or stones by pressing the unit
button, located on the underside of your scale.
2. Place the scale on a hard, at surface.
Carpeted, uneven
or cushioned ooring can negatively affect the accuracy of the
reading. When in doubt, call 866-843-3905 (8 to 5 MST).
3. Initialize the scale. If you are placing the scale down for the
rst time or moving your unit you must rst auto-calibrate the
scale (see steps 4-6 under "Operation" section of this manual.)
4. Step on.
Place both feet on the center of the glass and stand still.
5. Your weight will appear on the LCD. Your weight will blink 3
times when your nal weight has been calculated.
6. Step off the scale. The scale will turn off automatically after
approximately 10 seconds.
Important: Your EatSmart scale operates with "Step-On"
technology but still needs to be auto-calibrated after battery
installation or after the scale is moved, to ensure accuracy.
Firmly press the glass platform to activate the backlight but
DO NOT stand on the platform. Allow the scale to read '0.0'
and wait for it to turn off. Your scale is now calibrated and
you can step on and weigh yourself normally.
Scale displays “O_Ld”
Too much weight has been placed on the scale and it
is overcapacity. Remove weight before proceeding.
Page 4
7
6
FCC INFORMATION
Caution: Changes or modications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Note: This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference and (2) this device must accept any
interference received, including interference that may cause undesired operation. This equipment
has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
SPECIFICATIONS
Model: EatSmart Precision Maxview Digital Bathroom Scale ESBS-51
WARRANT Y
The EatSmart warranty covers defects in material and workmanship of
the product under normal use for a period of two (2) years from the
date of retail purchase. The warranty does not cover damages resulting
from misuse, abuse, immersion, normal wear and tear or unauthorized
modication.
Should this scale require service (or replacement at our option) while
under warranty, please contact EatSmart for return authorization and
troubleshooting.
EatSmart 866-843-3905 (8 to 5 MST) or eatsmartproducts.com
There are no expressed warranties except as listed above. This warranty
gives you specic legal rights which may vary from state to state.
NOT LEGAL FOR TRADE.
Capacity: 400 lbs / 180 kgs / 28 st 8 lbs
Measurement Units: Pounds / Kilograms / Stones
Graduation: 0.2lb / 0.1kg
Display: 4.5” Backlit LCD
Low Battery Indicator: “Lo”
Overload Indicator: “O_Ld”
Unit Dimensions: Approximately 12” x 12” x 1.00”
Unit Weight: Approximately 4.4 lbs
Power: 2 ‘AAA’ Batteries (included)
Made in China
