EatSmart ESBS-07 User Manual

Precision Tracker

Digital Bathroom Scale

Model ESBS-07

Health Tools LLC

Mahwah, NJ

201-465-4381 9-5 EST

[e-mail]

INTRODUCTION

r

r

AAA

r

Thank you for purchasing the EatSmart Precision Tracker Bathroom Scale. The
Precision Tracker is engineered and designed to give users the ability to track
their short and long term weight goals. The touch screen interface and automatic
person identification technology make it one of the most user friendly bathroom
scales on the market today.

Your EatSmart Tracker Bathroom Scale comes with the following:

• EatSmart Tracke

• Instruction Manual — Please review before using you

• 4

• 2 Yea

If you have any questions regarding the operation of your Precision Tracker,
please call 201-465-4381 from 9:00AM to 5:00PM EST, Monday through Friday.
For quickest response on weekends or any other non-work hours, please email
[e-mail].

batteries

EatSmart Guarantee

Digital Bathroom Scale

scale

Please fill out your purchase information for future reference:

Date Purchased: …………………………………………………

Place Purchased: ………………………………………………..

Order ID (if any): ………………………………………………....

About the Precision Tracker Bathroom Scale

r

r

Tracking body weight is a great way to stay motivated and focused on your health goals.
Let the EatSmart Precision Tracker Bathroom Scale do the work of tracking weight
changes for you. Simply lock in your starting weight and work towards long term weight
goals, while monitoring your short term progress. At each weigh in, the scale will display
three readings: your current weight, your weight change from your last weigh in and
total change from your starting weight.

The EatSmart Tracker allows you to see short term losses or gains that will help keep
you focused on your long term progress.

Your starting weight is an important reference point. For long term weight management,
each subsequent weigh in will be measured against the initial weight recorded. This will
help you determine the best diet and exercise strategies for your lifestyle. For reference,
you may want to write down your starting date and place on the bottom of the scale.

By using the latest technology, the Precision Tracker has the capability to stor
different users’ personal profiles. After initial setup, the scale will automatically identify
each individual user as soon as they step onto the scale. This allows for each user’s
personal data to be stored privately.

Notes:

• We recommend weighing yourself bi-weekly o
focus on your long term goals.

• It is normal fo
For example, drinking a glass of water can add one lb to your weight. Weigh
yourself at the same time of day and under the same conditions for the most
accurate results, preferably when you wake up in the morning.

weight to fluctuate during the day and from one day to the next.

weekly, ratherthan daily, with a

e up to 8

CONSISTENCY IS KEY FOR ACCURATE RESULTS !

HOW TO OPERATE YOUR PRECISON TRACKER

Before First Use

1. Inserting Batteries and Selecting Measurement Unit

a) Open the battery compartment door on the back of the scale.
b) Put the batteries in, flat end (negative terminal) against the spring. The LCD will

display.

c) Close the battery door and wait until is shown on the

LCD.

d) Press “UNIT” button (located underneath scale) to select the desired

measurement unit; pounds or kilograms. The default is set to lbs.

2. Calibration

Place the scale on a hard, flat surface.

a)

down on the floor, allow the scale to turn off without standing on it. If the
scale does not turn on when placed down, press the glass platform with
one foot to turn the scale on. Step off. Allow the scale weight to go to 0.0
and turn off without standing on it.

If the scale is turned on when placed

Note: Avoid carpet or other soft flooring like Pergo™ or types of linoleum

Your Precision Tracker operates via “Step-On” technology but still needs to be calibrated
upon first use or after the scale is moved to ensure accuracy.

Note: When you pick up the scale, move the scale or replace batteries, the scale may lose
calibration. You can either calibrate (see above) or disregard the first weight after the scale is
moved. If the scale is not calibrated it will add 4.2 lbs to your weight and that represents the
weight of the glass platform.
If you step on and off the scale repeatedly you should obtain the same weight. Uneven
flooring or softness in f looring may cause weight fluctuation. Move the scale to a different
surface and re-calibrate or call support at 201 465 4381 9-5 EST.

Weight Only Operation Instructions

A

If a user wants to obtain a weight reading only, please follow the directions below.
Please note that results will not be recorded by the scale for tracking purposes.

a)

fterinstalling batteries, immediately place the scale on solid, flat surface. Note:

Avoid carpet or other softer flooring like Pergo™ or types of linoleum or vinyl.

b) Calibrate the scale (see pg 3).

c) Step on the scale with both feet and remain steady. When the weight has

locked in, the scale will blink three times and remain on the screen for 10
seconds before automatically shutting off.

Tracking Mode Operation Instruction

If a user wants to track short and long term changes in weight, you must first set
up a user profile. Note: The weight tracking feature will be activated unless the
user profile is deleted.

1. Place the scale on a hard, flat floor Please leave the scale on the floor
during setup.
types of linoleum and vinyl.

Note: Avoid carpet or other softer flooring like Pergo or

2. Calibrate the scale as follows:

If the scale is turned on when placed down on the floor, allow the scale to
turn off without standing on it.

If the scale does not turn on when placed down, press the glass platform with
one foot to turn the scale on. Step off. Allow the scale weight to go to 0.0 and
turn off without standing on it.

3. Locate the “SET” button. Touch and hold until the useridentity function
appears.

4. Touch the

and keys to select the desired user.
The user number will blink until a user number is selected. Touch the “SET”
button to confirm the user.

scale

】

When the LCD show below picture , step on th

【

5. If this is the first time using the scale, the unit will weigh the userand then
display the following screen showing current weight only:

6. If this is the second time, the scale will cycle through the following screens, showing
current weight and last weight results:

7. If this is the third or subsequent uses, the scale will cycle through the following

r

b

r

r

A

screens, including the current, last and total weight changes:

Auto User Recognition

After you have programmed your user and weighed yourself once, the scale will
automatically recognize you for future weigh-ins. It does this based upon the weight
of the user (it will detect all profiles within +/- 6.6lbs).
a. If the scale recognizes the use

and weight changes.

. If several users profiles are in a similarweight range (within +/- 6.6lbs), they will

both be shown on the LCD in cycles after weighing.

See (2) examples below:

successfully, the scale will show current weight

c. To resolve the use

you are.

d.

below)

conflict press eitherthe orkey, depending on which use

lternatively, if userprofiles are not in use they can be deleted. (See directions

Deleting User Profiles

r

r

After setting up your users, it’s easy to delete a user profile.
Note: Deleting a user profile will also delete all data associated with that profile.

a) Select the use

the same time, press and release the
b) The scale will delete the first weight, the last weight and current weight.
c) The screen will display “CLR” fo

will return to normal weighing mode.

that you want to delete. Touch and hold the “SET” button.At

button (left button) three times.

2 seconds as pictured below.Afterthis, it

Troubleshooting

a)Low Battery Indicator
When “Lo” is shown, the scale will turn off after a few seconds.

Solution: Check that the batteries are inserted correctly. Change the batteries if
message continues, otherwise call EatSmart Products.

b) Overload Indicator
Solution: Please remove the weight on the scale to protect the load cells. If error
continues call EatSmart Products or e-mail [e-mail]

All other issues please call Eatsmart Products at 201 465 4381 (9-5 EST) or e-mail
[e-mail]

.

Helpful Tips:

r

r

r

r

• Please do not put the scale on carpet o
wood)or types of linoleum. These surfaces will negatively affect the accuracy of
the scale

• Best surfaces are concrete, hardwood (NOT engineered wood), marble o
12x12” ceramic tile.

• If you are seeing weight fluctuations of 1 or 2lbs, please bring the scale to a
different hard surface to eliminate discrepancies.

• If you see a weight fluctuations of 4 lbs o
platform weights approx. 4 lbs.

the most accurate results, place yourhands at yoursides, look straight

• Fo
ahead and count to 4. At this time, you can step off and your weight will stay
visible for a few seconds and cycle last weight and start weight twice.

• Clean the scale with a soft cloth.

• Treat the scale with care and do not store anything on top of the scale. It

contains sensitive electronic parts that can get damaged.

soft flooring like Pergo (engineered

more, recalibrate and try again. Glass

Features

, , SET, UNIT (on back of scale)

cally according to the last measuring weight

a

Battery Precautions

r

r

• Do not mix old and new batteries.

• Do not mix alkaline, standard (carbon-zinc), o

• Remove depleted batteries promptly.

• If the unit is not going to be used fo

months), remove batteries to prevent damage due to possible battery leakage.

Note: Please recycle or dispose of batteries according to local regulations.

a long period of time (greaterthan three

rechargeable (ni-cad) batteries.

Warranty

Health Tools LLC warranty covers defects in material and product workmanship under
normal use for a period of two (2) years. The warranty does not cover damages
resulting from misuse, abuse, immersion, normal wear and tear or unauthorized
modification.

Should this scale require service or replacement, while under warranty, please contact
Health Tools for trouble shooting and/or return authorization.

Phone: [phone] EST M-F
Email: [e-mail]

There are no expressed warranties except as listed above. This warranty gives you specific legal rights which may
vary from state to state. NOT LEGAL FOR TRADE.
