Section 23 83 13.16
Radiant Heating Electric Mats
EasyHeatTM Sno*MelterTM Mats
Section 23 83 13.16 │ Radiant Heating Electric Mats
Page 1 of 4
EasyHeatTM Sno*MelterTM Mats │ Specification 14266-001 Rev 0 │ 1/20 │ Emerson
PART 1 – GENERAL
1.1 SUMMARY
A. This Section includes a UL Listed and CSA Certified electric snow melting system
consisting of constant wattage, series resistance heating mats / cables and electronic
controller.
1.2 RELATED SECTIONS
A. Section 03 06 00 – Schedules for Concrete
B. Section 03 10 00 – Concrete Forming and Accessories
C. Section 03 30 00 – Cast-In Place Concrete
D. Section 23 09 00 – Instrumentation and Control for HVAC
E. Section 26 00 00 – Electrical
F. Section 32 12 16 – Asphalt Paving
G. Section 32 13 13 – Concrete Paving
H. Section 32 14 00 – Unit Paving
1.3 SYSTEM DESCRIPTION
A. System for surface snow melting, embedded in concrete, asphalt or underneath pavers,
with ambient and moisture sensing controls.
1.4 REFERENCES
A. Underwriter’s Laboratories (UL)
B. Canadian Standards Association (CSA)
C. National Electric Code (NEC)
1.5 SUBMITTALS
A. Product Data
1. Heating cable data sheet
2. UL, CSA approval certificates for snow melting
3. Sno*Melter Systems Cable Kits and Mats Installation Instructions
4. System installation details
5. Controller/Power Panel Installation and Operating Instructions
1.6 QUALITY ASSURANCE
A. Manufacturers’ Qualifications
1. Manufacturer to show minimum of thirty (30) years experience in manufacturing
constant wattage, resistance heating cables.
2. Manufacturer to provide products consistent with IEEE 515.1 and CSA 22.2 No
130-03 requirements.
B. Installer Qualifications
1. System installer shall have complete understanding of product and product
literature from manufacturer or authorized representative prior to installation.
Electrical connections shall be performed by a licensed electrician.
C. Regulatory Requirements and Approvals
1. The system (heating cable, and controller) shall be UL Listed and CSA Certified for
snow melting
2. Electrical Components, Devices, and Accessories: Listed and labelled as defined in
NFPA 70, Article 100, by a Nationally Recognized Testing Laboratory (NRTL), and
marked for intended use.
Section 23 83 13.16 │ Radiant Heating Electric Mats
Page 2 of 4
EasyHeatTM Sno*MelterTM Mats │ Specification 14266-001 Rev 0 │ 1/20 │ Emerson
1.7 DELIVERY, STORAGE AND HANDLING
A. General Requirements: Deliver, store and handle products to prevent their deterioration or
damage due to moisture, temperature changes, contaminates or other causes.
B. Delivery and Acceptance Requirements: Deliver products to site in original, unopened
containers or packages with intact and legible manufacturers’ labels identifying the
following:
1. Product and Manufacturer
2. Length/Quantity
3. Lot Number
4. Installation and Operation Manual
C. Storage and Handling Requirements
1. Store the heating cable in a clean, dry location with a temperature range 0°F to
140°F (-18°C to 60°C).
2. Protect the heating cable from mechanical damage.
1.8 WARRANTY
A. Extended Warranty
1. Manufacturer shall make available a limited warranty for Sno*Melter mats, cable
kits and components. Provide one (1) year warranty for all heat trace controllers.
2. Contractor shall submit to owner the results of all installation tests required by the
manufacturer.
PART 2 – PRODUCTS
2.1 MANUFACTURERS AND PRODUCTS
A. Contract Documents are based on manufacturer and products named below to establish
a standard of quality.
B. Basis of Design
1. Basis of Design Product Selections
a. Manufacturer
• Manufacturer to show minimum of thirty (30) years of experience in
manufacturing constant wattage, resistance heating cables.
• Manufacturer shall provide UL and CSA approval certificates for snow
melting. Manufacturer shall be Emerson – EasyHeat
b. Snow Melting System
• Sno*Melter constant wattage, resistance heating mats and/or cable kits
• MSC1 snow/icing melting controller, with MSP1 pavement sensor and/or
MSA1 aerial sensor OR SA1 controller [Select one]
2.2 PRODUCTS, GENERAL
A. Single Source Responsibility: Furnish heat tracing system for snow melting from a single
manufacturer.
B. The system (heating cable and controller) shall be UL Listed and CSA Certified for snow
melting. No parts of the system may be substituted or exchanged.
2.3 PRODUCTS
A. PVC Jacketed, XLPE Sheathed Series Resistance Cable
1. Heating cable shall be Sno*Melter, series resistance heating mats/cables by
EasyHeat.
2. The heating cable shall consist of two solid copper conductors, cross-linked
polyethylene insulation and a PVC outer sheath.
3. The heating cable shall be factory terminated with a minimum 20-foot cold lead
(unheated) length.
Section 23 83 13.16 │ Radiant Heating Electric Mats
Page 3 of 4
EasyHeatTM Sno*MelterTM Mats │ Specification 14266-001 Rev 0 │ 1/20 │ Emerson
4. The heating cable shall operate on line voltages of 120, 208, 240, 277, 347, 480 or
600 volts [Select one] without the use of transformers.
5. The heating cable shall be part of a UL Listed and CSA Certified system.
6. The Sno*Melter mats/cables tag shall have the following markings:
a. Complete heating cable model number
b. Agency listings
c. Lot/Batch ID
B. Heating Cable Installation Accessories
1. Snow Melting Caution Sign – The snow melting caution sign is required by national
electrical codes to indicate that an electrical snow melting system is installed in the
slab. (Catalog Number: NMPLT)
C. Control Methodology [Select one]
1. [Option 1] Non-Programmable Control
a. Single circuit snow/ice melting controller shall be SA1.
b. Electronic snow/ice melting controller shall operate with supply voltage of
120V single phase.
c. Electronic snow/ice melting controller shall have integrated ambient
temperature and moisture sensors that activate the system when
specified conditions exist
d. Enclosure type shall be NEMA 3R polycarbonate.
e. Electronic snow/ice melting controller shall have a two (2) hour pre-set
hold-on timer
f. Controller shall have c-UL-us approvals.
2. [Option 2] Programmable Zone Control
a. Single circuit snow/ice melting controller shall be MSC1.
b. Temperature Sensor shall be TS1
c. Electronic snow/ice melting controller shall operate with supply voltage of
120V single phase.
d. Electronic snow/ice melting controller shall have an ambient temperature
sensor that is physically separated and operates independently from any
moisture sensor
e. Electronic snow/ice melting controller shall be capable of supporting up
to six (6) type MSA1 aerial and/or three (3) type MSP1 slab mounted
moisture sensors.
f. Electronic snow/ice melting controller shall have an adjustable hold-on
timer (0 – 10 hours).
g. Electronic snow/ice melting controller shall have adjustable on/off
temperature settings.
h. Electronic snow/ice melting controller shall be capable of operating up to
three (3) independent zones
i. Enclosure type shall be NEMA 3R polycarbonate.
j. Digital controller shall have c-UL-us approvals.
2.4 SYSTEM LISTING
A. The system (heating cable, connection kits, and controller) shall be UL Listed and CSA
Certified for snow melting.
B. The snow melting system shall have design and installation and operating manuals.
Section 23 83 13.16 │ Radiant Heating Electric Mats
Page 4 of 4
EasyHeatTM Sno*MelterTM Mats │ Specification 14266-001 Rev 0 │ 1/20 │ Emerson
PART 3 – EXECUTION
3.1 INSTALLERS
A. Acceptable Installers
1. Subject to compliance with requirements of Contract Documents, installer shall be
familiar with installing snow melting, mats and/or cable and equipment.
3.2 INSTALLATION
A. Comply with manufacturer’s recommendations in the Sno*Melter Systems Cable Kits
and Mats Installation Instructions (11001-128).
B. Install and secure the mat(s) / cable(s) in accordance with the Sno*Melter Systems
Cable Kits and Mats Installation Instructions (11001-128).
C. The installer shall be responsible for providing a complete functional system, installed in
accordance with applicable national and local requirements.
D. Grounding of controller shall be equipment according to Section 26 05 26 "Grounding
and Bonding for Electrical Systems."
E. Connection of all electrical wiring shall be according to Section 26 05 19 "Low-Voltage
Electrical Power Conductors and Cables."
3.3 FIELD QUALITY CONTROL
A. Field Testing and Inspections
1. The system shall be commissioned in accordance to the Sno*Melter Systems
Cable Kits and Mats Installation Instructions (11001-128).
2. Sno*Melter System integrity shall be tested using a megohmmeter set at 500 Vdc
(min) at the following intervals below. Minimum acceptable insulation resistance
shall be 50 megohms or greater.
a. Before installing the heating cable
b. After heating cable has been attached to welded-wire mesh or rebar
(concrete); affixed to base asphalt layer with binder (asphalt); placed in sand
bed (paver)
c. After final pour (concrete); after application of finish coat (asphalt); after
placement of stones (paver)
d. Prior to initial start-up (commissioning)
e. As part of the regular system maintenance
3. The installer shall verify that the MSC1 snow/icing melting controller control
parameters are set to the application requirements.
4. All commissioning results will be recorded and presented to the owner.
3.4 MAINTENANCE
A. Maintenance Service
1. Comply with manufacturer’s recommendations in Sno*Melter Systems Cable Kits
and Mats Installation Instructions (11001-128)
END OF SECTION
