Eagle ST1836Z-13 User Manual
Specification Sheet
Catalog Specification Sheet No.
Item No.:
Project No.:
S.I.S. No.:
Short Form Specifications
Stencil shelves are paired with opposing design top and
bottom. Footprint is 18˝ width x 36˝ length, with EAGLEbrite
zinc plating. Divider wires to provide 2˝ inside dimension and
4˝ up and down support. Adjustable in 1˝ increments. Each
shelving tier to hold up to 15 stencils. May be used with any
other wire shelving product on the same centers.
two tiers of stencil shelves—
shown in mobile unit
configuration
Stencil Shelves
®
MODELS:
ST1836Z-13
Design and Construction Features
• One #ST1836Z-13 includes one bottom and one top shelf.
One #ST1836Z-13 is required for each tier.
• Each unit has (15) 2˝ (51mm) partitions.
• The stencil shelf may be used with any combination of
posts* and casters** that best meets your requirements.
• A stationary unit can be made conductive with the use of
optional aluminum split sleeves.
• A mobile unit may be made conductive with the use of
optional aluminum split sleeves and optional anti-static
drag chain.
• Zinc finish.
EG07.08
Stencil Shelves
* See catalog sheet #EG01.00 for posts available.
** See catalog sheet #EG01.05 for casters available.
A stencil shelf consists of one top
and one bottom partitioned shelf.
Options / Accessories
Aluminum split sleeves
Anti-static drag chain
EAGLE GROUP
100 Industrial Boulevard, Clayton, DE 19938-8903 USA
Phone: 302-653-3000 • Fax: 302-653-2065
www.eaglegrp.com
Foodservice Division: Phone 800-441-8440
MHC/Retail Display Divisions: Phone 800-637-5100
For custom configuration or fabrication needs, contact our SpecFAB®Division.
Phone: 302-653-3000 • Fax: 302-653-3091 • e-mail: specfab@eaglegrp.com
Spec sheets available for viewing, printing or downloading from our online literature library at www.eaglegrp.com
Eagle Foodservice Equipment, Eagle MHC, SpecFAB®, and Retail Display are divisions of Eagle Group. ©2012 by the Eagle Group
EG07.08 Rev. 04/12
EG07.08
Stencil Shelves
Catalog Specification Sheet No.
Item No.:
Project No.:
S.I.S. No.:
TOP VIEW
Stencil Shelves
FRONT VIEW
model # in. mm in. mm lbs. kg capacity
ST1836Z-13* 18˝ 457 36˝ 914 18 8.2 holds (15) stencils
* Note: #ST1836Z-13 includes two shelves—one for top and one for bottom.
EAGLE GROUP
100 Industrial Boulevard, Clayton, DE 19938-8903 USA
Phone: 302-653-3000 • Fax: 302-653-2065
www.eaglegrp.com
Foodservice Division: Phone 800-441-8440
MHC/Retail Display Divisions: Phone 800-637-5100
Spec sheets available for viewing, printing or downloading from our online literature library at www.eaglegrp.com
Although every attempt has been made to ensure the accuracy of the information provided, we cannot be held responsible for
typographical or printing errors. Information and specifications are subject to change without notice. Please confirm at time of order.
SIDE VIEW
(note: only bottom shelf shown)
width length weight
Printed in U.S.A.
©2012 by Eagle Group
Rev. 04/12
