40
L OUDSPEAKERS
Forum Line
F12
The demands on modern high-performance systems regarding their long-throw capability, low distortion, and
intelligible sound are constantly growing. The introduction
of DYNACORD’s patented Planar Waveguide technology
marks a quantum leap in the field of high-efficiency, direct
radiating subwoofer systems.
Typical long-throw systems offer extreme throw on the
cost of a comparably small directivity angle, so that several
cabinets need to be employed to provide coverage of the
entire audience area.
The Conical Waveguide horn F 12 CWH is a very compact
Mid/Hi-component offering an immense SPL and a comparably wide radiation pattern. The speaker components
are coaxially mounted, which provides a smooth extended
frequency response within the entire radiation range.
In the Mid-Bass range works an ELECTRO-VOICE DL12 ST
high-performance transducer mounted on a Conical Wave
guide horn. The high-frequency range above 800 Hz is
reproduced by an ELECTRO-VOICE DH6-8 driver, firing
into a coaxially mounted 80°x55° wide coverage horn.
This coaxial design ensures extreme linear transmission,
without the occurrence of Dead-Spots as they are usually
found with conventional systems.
The sound of the F 12 CWH provides is marked through
its noticeably high dynamic range with comparably low
distortion. The linear frequency response between 100 Hz
– 19 kHz (-10 dB) is as excellent as its SPL of 106 dB
1W/1m and the cabinet’s off-axis sound is still impressively
neutral and uncoloured.
Because of its exceptional level of efficiency and
outstanding power handling capacity of 350 W (EIA RS426A), Even when employed as stand-alone cabinet, the
F 12 CWH offers excellent long-throw coverage, stable
intelligible sound and superb performance.
The F 12 CWH represents a truly economic solution for a
wide range of applications in festival tents, halls and at
medium-size open-air events when compared to conventional long-throw systems (e.g. 35° x 35°) and because of
its wide radiation angle of 80° x 55° and its superior
medium and long-throw capability. Despite its wide
coverage, the Conical Waveguide design awards the F 12
CWH with an on-axis sound pressure level that is identical
to that of a typical long-throw component.
Integrated in the cabinet is a passive horn-EQ, which
allows using the F 12 CWH for vocal reproduction when
directly connecting it to any common linear power amplifier. Only employing a 160 Hz Lo-Cut filter is recommended to protect the 12” horn system against low-frequency
overload.
Multi-stage protection circuitry guards the F12CWH driver
systems from being damaged by thermal overload.
FREQUENCY RESPONSE
THROW CAPABILITY
USAGE
PROTECTION
L OUDSPEAKERS
41
The F9CWH is an extremely powerful and yet compact Mid/Hicabinet that has been designed for medium and long-throw
applications. The Constant Directivity horn HT94 is coaxially aligned
in a conical mid-frequency horn and offers a nominal radiation angle
of 90° x 40°, which provides extremely smooth transmission without
distressing interference in the x-over frequency range between the
mid and high-frequency horns.
The mid-frequency range is reproduced by an Electro-Voice DL 12ST
speaker system, while high frequency reproduction is taken care of
by an Electro-Voice DH2T driver with titanium diaphragm, which is
renowned for his excellent vocal definition and crystal-clear treble
sound. The SPL of 105dB/1W/1m allows almost doubling the
throw-capability of conventional direct-radiating loudspeaker cabinets.
Employing at least two Lo-cabinets per side – e.g. two F5 or two
F118 – for bass sound reproduction is recommended to match bassSPL to the exceptionally high efficiency of the F9CWH.
(also refer to “Xa5-System” in the Application Guide on page 54).
F9
F120
By designing its 2-way speaker system F120, DYNACORD set a new
standard for professional 12" 2-way cabinets. A sound pressure level
of 100 dB, wide coverage and its excellent sound quality make the
F120 equally suitable to be used as full-range cabinet or as Mid-Hi
component in active 2-way applications. When comparing the F120
to conventional 12" 2-way speaker systems, it provides nearly
double the throw and power as well as a convincingly natural
reproduction of vocals. An Electro-Voice DL12 ST 12" speaker serves
a s woofer system while an Electro-Voice DH2T driver with titanium
diaphragm and HT94 Constant Directivity horn provides
exceptionally powerful mid-range sound and crystal-clear trebles.
The newly designed frequency x-over is furnished with halogen
lamps and thermal-breakers, which provide reliable protection
against overload. The system-switch on the connection board allows
easily configuring the F120 for full-range operation or connection to
DYNACORD system power amps like the PM 2600 or Xa2600. The
carrying handles are prepared for retrofitting a TÜV-approved
rigging-kit to allow trouble-free “flying” applications.
42
L OUDSPEAKERS
F5
The F5 is a compact, but yet high-efficiency subwoofer system. An EV
DL15Y woofer works in the optimally vented cabinet, ensuring highest
power handling, efficiency and low distortion. The integrated passive
PowerMax x-over (x-over frequency 160Hz) features a parallel output and
an additional crossover output offering trouble-free parallel or x-over
operation when combined with professional full-range or Mid-Hi cabinets.
Reliably protecting the woofer against critical peak levels and thermal
overload are a thermal breaker and professional halogen lamps. The 4-pole
SPEAKON-type connectors wired-through, allowing active system installations that employ DYNACORD system power amps PM2600 or Xa2600 for
instance can be set up using 4-pole SPEAKON-type cables, without the risk
of inadvertent mismatching. Four extremely robust castors are located on
the cabinet’s rear and four ergonomically optimised recessed handles facilitate handling and transportation. Frontal protection is provided through a
robust steel grille that is covered with acoustic foam.
F150
A professional 15" 2-way cabinet offering optimal sound, low weight and
an outstanding price-performance ratio – that was the challenge for our
engeneering. A sound pressure level of 102 dB, wide coverage and its
excellent sound quality make the F150 equally suitable to be employed as
full-range cabinet or as Mid-Hi component in active 2-way applications
offering an convincingly natural reproduction of vocals. An Electro-Voice
DL15Y 15" speaker serves a s woofer system.
An Electro-Voice DL12 ST 12" speaker serves as woofer system while an
Electro-Voice DH2T driver with titanium diaphragm and HT94 Constant
Directivity horn provides exceptionally powerful mid-range sound and
crystal-clear trebles. The newly designed frequency x-over is equipped with
halogen lamps and thermal-breakers, which provide reliable protection
against overload. The system-switch on the connection board allows easily
configuring the F150 for full-range operation or connection to DYNACORD
system power amps like the PM 2600 or Xa2600. Frontal protection is
provided through a robust steel grille that is covered with acoustic foam.
The carrying handles are prepared for retrofitting a TÜV-approved riggingkit to allow trouble-free “flying” applications.
L OUDSPEAKERS
43
F8
F18 PWH
The F18 PWH is mostly used serving as high-performance subwoofer.
Especially its supreme long-throw ability and mid-bass range directivity
make the F18PWH the predestined subwoofer to be employed in basically
any system configuration. Both Planar Waveguide™ bass-horns are equipped with an ELECTRO-VOICE EVX180B 18“ high-performance chassis with
a power handling of 500 watts RMS / 1,000 watts program into 8 Ω.
F17 PWH
The F17PWH is a highly efficient bass-cabinet with optimally matched
dimensions an enclosure geometry to perfectly complement the F12CWH
Mid-Hi cabinet. Its compact size, castors on the rear as a standard and low
weight make the F17PWH the first choice for medium and long-throw onthe-road applications. Through its high efficiency of 99 dB (1 W/1 m) and a
power handling capacity of 500 watts, the F17PWH accomplishes coverage
distances of 60 m – 80 m in two-stack operation and of 120 m – 160 m
when stacked in four. The recommended transition frequency to Mid-Hi
cabinets is 160 Hz/18 dB/oct. Butterworth or 24 dB/oct. Linkwitz-Riley.
The F8 subwoofer marks DYNACORD’s consequent further development of
the meanwhile legendary F118. The highly efficient Electro-Voice EVX180B
18" woofer is capable of handling a continuous program power capacity of
500 W offering a peak-SPL of 130dB and lowest non-linear distortion. The
integrated passive PowerMax x-over (x-over frequency 160Hz) features a
parallel output and an additional crossover output offering trouble-free
parallel or x-over operation when combined with professional full-range or
Mid-Hi cabinets. Reliable protection of the Electro-Voice EVX180B woofer
against critical peak levels and thermal overload is guaranteed through a
thermal breaker and professional halogen lamps. The SPEAKON-type
connectors wired-through, allowing active system installations that employ
DYNACORD system power amps PM2600 or Xa2600 for instance can be
set up using 4-pole SPEAKON-type cables, without the risk of inadvertent
mismatching. Four extremely robust castors are located on the cabinet’s rear
and four ergonomically optimised recessed handles facilitate handling and
transportation. Frontal protection is provided through a robust steel grille
that is covered with acoustic foam.
44
L OUDSPEAKERS
Type F 12 CWH F9 CHW F120 F150
Design 2-way Cabinet Waveguide Horn 2-way 2-way
Components
LO: 1 x 12“ 1 x 12“ 1 x 12“ 1 x 15“
DL12 ST DL12 ST DL12 ST DL15 Y
OEM
HI: DH 6-8 DH 2T DH 2T DH 2T
HP 8055 HT 94 HT 94 HT 94
Nominal power rating RMS 350 W* 300 W 300 W 400 W
Program power capacity 700 W 600 W 600 W 800 W
Frequency response (-10 dB) 100-1900 Hz 140 Hz - 1900 Hz 75 Hz-18 kHz 70 Hz-18 kHz
Nominal SPL (1W/1m) 106 dB 105 dB 100 dB 102 dB
Max. SPL* 134 dB 133 dB 128 dB 131 dB
Crossover Frequ. (passive) 800 Hz
Impedance: 8Ω 8 Ω 8 Ω
Crossover frequencies 800/7 kHz 1.6 kHz 1.6 kHz
Dimensions
Width 606 mm 436 mm 436 mm 522 mm
Height 625 mm 517 mm 629 mm 755 mm
Depth 792 mm 471 mm 339 mm 395 mm
Weight 54 kg 28.5 kg 21.5 kg 26.5 kg
* EIA RS-426A
Type F5 F8 F 17 PWH F 18 PWH
Design Subwoofer Subwoofer 18“ Planar 18“ Planar
Waveguide Horn Waveguide Horn
Impedance 8Ω 8Ω 8Ω 8Ω
Rated Power Capacity RMS 400 W 500 W 500 W 500 W
Program Power Capacity 800 W 1000 W 1000 W 1000 W
SPL (1W/1m) 100 dB 100 dB 99 dB 103 dB
max. SPL (calc.) 129 dB 130 dB 129 dB 130 dB
Frequency Range (-10 dB) 48-280 Hz 40 -300 Hz 39-255 Hz 40-2000 Hz
Crossover Frequ. (passive) 160 Hz 160 Hz
Components
LO 1 x 15“ 1 x 18“ 1 x 18“ 1 x 18“
DL15 Y EVX 180B EVX 180 B EVX 180 B
HI
Dimensions
Width: 436 mm 522 mm 606 mm 606 mm
Height: 617 mm 737 mm 625 mm 760 mm
Depth: 674 mm 674 mm 792 mm 1176 mm
Weight 30.5 kg 38.0 kg 42.5 kg 53.0 kg
54
APPLICATION GUIDE
The Xa 5 System is a truly powerful, outstandingly compact loudspeaker system offering superior efficiency in
medium and long throw applications.
The system is meant to be used in an active 2-way installation, i. e. together with the XA2600 system power amplifier, or in a passive configuration, i. e. directly connected to
a PowerMate 1000, or together with any regular power
amplifier. Because of the horn-loaded system’s tremendous
SPL of 105 dB/1W/1m it is possible to achieve spectacular
dynamic results and – compared to conventional direct
radiating speaker systems – nearly double the long throw
capability. The Xa 5 System includes a F9CWH Mid/Hi
cabinet and two F5 sub woofers, on each side. When operating the Xa5 system in active 2-way confi-guration, the
recommended crossover frequency between the F5 sub
woofers and the F9CWH Mid/Hi cabinet is 160 Hz with a
slope of 18 dB/octave and Butterworth characteristics.
The DYNACORD XA2600 system power amplifier provides
these filter parameters as a factory preset.
Super-compact, horn-loaded system meant to be used for
medium throw applications with identical dispersion capabilities. The Xa28 System is ideally suitable for medium
halls or clubs. Being equipped with two F17PWH Planar
Waveguide bass-horns, it is equally appropriate to provide
the sound reinforcement at pop/rock live concerts, delivering ”fat” bass drum and ”slappy” bass guitar sound.
Lo + Hi
Xa 2600
F 12CWH F 12CWH
F 17PWH F 17PWH F 17PWH F 17PWH
Lo + Hi
Hi
Lo
Hi
Lo
Xa 28 System
Standard Configuration
Lo + Hi
Xa 2600
F 5
F 5
F 9
F 5
F 5
F 9
Lo + Hi
Hi
Hi
Xa 5 System
Micro
Medium / Long-Throw
Audio System
APPLICATION GUIDE
55
Lo + Hi
Xa 2600
F 12CWH F 12CWH
F 18PWH F 17PWH F 17PWH F 18PWH
Lo + Hi
Hi
Lo
Hi
Lo
Xa 48 System
”Variable Bass“
Combination
Lo + Hi
Xa 2600
F 12CWH F 12CWH
F 18PWH F 18PWH F 18PWH F 18PWH
Lo + Hi
Hi
Lo
Hi
Lo
Xa 38 System
”Medium-Throw“
Combination
The artist that calls hip-hop, techno and similar music styles
his domain, where energetic ultra-low bass sounds are an
absolute ”must”, will simply love the Xa38 System. Employing a total of four FORUM LINE F18PWH sub woofers
together with two FORUM LINE F12CWH Mid/Hi-cabinets,
this configuration provides outstanding dispersion capabili-
ties that are universally suitable for any medium-throw
application. Compared to the Xa28, this system offers
extended bass response allowing to re-produce extremely
low ”techno bass sounds” without a problem. Besides,
when using the Xa38 for jazz or rockabilly, the upright bass
sounded never more powerful and voluminous.
For medium-throw applications you need a system that is
capable of handling any musical style? The extended bassperformance of the Xa48 System configuration with its
combination of FORUM LINE F18PWH and FORUM LINE
F17PWH speaker systems covering the bass range provides the listener with the bass impact that makes any live
concert a long-lasting experience. For smaller events only
the F 17 PWH sub woofers are necessary. In case you will
need a system for halls where the coverage has to exceed
100m, ”upgrading” the Xa48 is no problem at all. You just
supplement the configuration with additional loudspeaker
systems.
56
APPLICATION GUIDE
There is a perfect solution for long-throw applications with
coverages between 120m - 160m – i. e. huge halls or tents that
at the same time require wide dispersion: the Xa58 System.
Utilizing a total of four F12CWH for the Hi/Mid-range provides the opportunity to cover an extremely wide area, when
their cabinets are turned slightly against each other. And another four F17PWH provide low frequency sound with tremendous impact. Non matter which musical style or how big the
event, the Xa58 is capable to deliver sound reinforcement at its
finest - in any location and even in the furthest corner .
Open-air heavy-metal, rave event at an industrial estate or
pop-festival in a huge hall – the powerful bass performance at
these long-throw events mostly means lots of watts and even
more wood. The Xa68 is the ultimate solution for any major
live application employing a minimal amount of material and
most of all at unbeatable low cost. The Xa68 System provides
very clear and outstandingly intelligible Hi/Mid-sound reproduction and, by incorporating the Planar Waveguide Technology, fundamental impact and directivity in the bass and subbass range. If necessary, each stereo-side of the Xa68 can be
enhanced by a F18PWH and a F12CWH cabinet, each; without the need for additional power amplifiers.
Lo + Hi
Xa 2600
F 12CWH F 12CWH
F 17PWH F 17PWH F 17PWH F 17PWH
Lo + Hi
Hi
F 12CWH
Hi
Lo
F 12CWH
Hi
Lo
Xa 58 System
Standard
”Long-Throw“
Configuration
Lo + Hi
Xa 2600
F 12CWH F 12CWH
F 18PWH F 18PWH F 18PWH F 18PWH
Lo + Hi
Hi
F 12CWH
Hi
Lo
Hi
F 12CWH
Hi
Lo
Xa 68 System
THE Standard
Hi
Loading...
