Dynacord AXM 12A User manual

Dynacord AXM 12A User manual

AXM 12A

en | User manual

AXM 12A Table of Contents | en 3

Table of contents

1

Safety

4

2

Quick overview

6

2.1

Shipping contents and warranty

6

3





Product overview

7

4





Installation

8

4.1

Floor monitor

8

4.2

Tripod

8

5





Connection

9

5.1

Mains input (MAINS IN)

9

5.2

Audio inputs

9

5.2.1

Microphone/line input

9

5.2.2

Aux input

10

5.3

Audio outputs

10

5.3.1

Thru output

10

5.3.2

Mix output

10

6





Configuration

11

6.1

Audio level

11

6.2

Display

11

6.2.1

Home screen

11

6.2.2

Menu

12

6.2.3

Functions

14

7





Operation

15

7.1

Quickstart

15

8





Troubleshooting

16

8.1

Avoid acoustical feedback

16

8.2

Replace a blown fuse

16

9





Maintenance

18

10

Technical data

19

10.1

Block diagram

21

10.2

Frequency response

22

10.3

Directivity

23

10.4

Dimensions

25

11





Appendices

26

11.1

System examples

26

Bosch Sicherheitssysteme GmbH

User manual

18-Mar-14 | 02 | F01U290507

4

en | Safety

AXM 12A







1 Safety

Danger!

The lightning symbol inside a triangle notifies the user of high-voltage, uninsulated lines and contacts inside the devices that could result in fatal electrocution if touched.

Warning!

!An exclamation mark inside a triangle refers the user to important operating and service instructions in the documentation for the equipment.

1.Read these safety notes.

2.Keep these safety notes in a safe place.

3.Heed all warnings.

4.Observe all instructions.

5.Do not operate the device in close proximity to water.

6.Use only a dry cloth to clean the unit.

7.Do not cover any ventilation slots. Always refer to the manufacturer's instructions when installing the device.

8.Do not install the device close to heaters, ovens, or other heat sources.

9.Note: The device must only be operated via the mains power supply with a safety ground connector. Do not disable the safety ground connection function of the supplied power cable. If the plug of the supplied cable does not fit your mains socket, please contact your electrician.

10.Ensure that it is not possible to stand on the mains cable. Take precautions to ensure the mains cable cannot become crushed, particularly near the device connector and mains plug.

11.Only use accessories/extensions for the device that have been approved by the manufacturer.

12.Unplug the device if there is risk of lightning strike or in the event of long periods of inactivity. However, this does not apply if the device is to be used as part of an evacuation system!

13.Have all service work and repairs performed by a trained customer service technician only. Service work must be carried out immediately following any damage such as damage to the mains cable or plug, if fluid or any object enters the device, if the device has been used in rain or become wet, or if the device has been dropped or no longer works correctly.

14.Please ensure that no dripping water or spray can penetrate the inside of the device. Do not place any objects filled with fluids, such as vases or drinking vessels, on top of the device.

18-Mar-14 | 02 | F01U290507

User manual

Bosch Sicherheitssysteme GmbH

AXM 12A

Safety | en

5







15.To ensure the device is completely free of voltage, unplug the device from the power supply.

16.When installing the device, ensure that the plug is freely accessible.

17.Do not place any sources of open flame, such as lit candles, on top of the device.

18.This PROTECTION CLASS I device must be connected to a MAINS socket with a safety ground connection.

Caution!

Use only manufacturer-approved carts, stands, brackets, or tables that you acquired together with the device. When using carts to move the device, make sure the transported equipment and the cart itself cannot tip over or cause injury or material damage.

IMPORTANT SERVICE INFORMATION

Caution!

This service information is for use by qualified service personnel only. To avoid the risk of

!electric shock, do not perform any maintenance work that is not described in the operating instructions unless you are qualified to do so. Have all service work and repairs performed by a trained customer service technician.

1.Repair work on the device must comply with the safety standards specified in EN 60065 (VDE 0860).

2.A mains isolating transformer must be used during any work for which the opened device is connected to and operated with mains voltage.

3.The device must be free of any voltage before performing any alterations with upgrade sets, switching the mains voltage, or performing any other modifications.

4.The minimum distance between voltage-carrying parts and metal parts that can be touched (such as the metal housing) or between mains poles is 3 mm, and must be observed at all times.

5.The minimum distance between voltage-carrying parts and circuit parts that are not connected to the mains (secondary) is 6 mm, and must be observed at all times.

6.Special components that are marked with the safety symbol in the circuit diagram (note) must only be replaced with original parts.

7.Unauthorized changes to the circuitry are prohibited.

8.The protective measures issued by the relevant trade organizations and applicable at the place of repair must be observed. This includes the properties and configuration of the workplace.

9.Observe the guidelines with respect to handling MOS components.

Danger!

SAFETY COMPONENT (MUST BE REPLACED BY ORIGINAL PART)

Old electrical and electronic appliances

Electrical or electronic devices that are no longer serviceable must be collected separately and sent for environmentally compatible recycling (in accordance with the European Waste Electrical and Electronic Equipment Directive).

To dispose of old electrical or electronic devices, you should use the return and collection systems put in place in the country concerned.

Bosch Sicherheitssysteme GmbH

User manual

18-Mar-14 | 02 | F01U290507

6 en | Quick overview AXM 12A

2 Quick overview

Your AXM 12A is designed so that you can easily set it up and start using it right away. Follow the steps on the next few pages to set up your AXM 12A.

Caution!

!Read all the instructions in this document and the safety notes starting on page 4 before you plug your AXM 12A into a power outlet.

2.1

Shipping contents and warranty









Quantity

Component









1

AXM 12A









1

Power cord









1

User manual









1

Important safety instructions









Warranty



For information regarding the warranty, see www.dynacord.com

18-Mar-14 | 02 | F01U290507

User manual

Bosch Sicherheitssysteme GmbH

AXM 12A Product overview | en 7

3 Product overview

Number

Description





1

Operation and connection panel





2

Bar carry handle





3

Recessed grip





4

Pole mount adaptor





5

Bottom rubber feet





6

Protective bumper





Bosch Sicherheitssysteme GmbH

User manual

18-Mar-14 | 02 | F01U290507

8 en | Installation AXM 12A

4

Installation

4.1

Floor monitor

When using the DYNACORD AXM 12A as a floor monitor, make sure to:

Place the speaker on a level, stable surface that is solid and secure.

Route cables so that performers, production crew and audience members will not trip over the cables. Secure cables with wire ties or tape whenever possible.

4.2 Tripod

The AXM 12A loudspeaker includes a 35 mm (1-3/8 in) stand mount to allow mounting on tripod stands or above a subwoofer. Make sure to:

Check the specifications of the speaker stand to be certain it is capable of supporting the weight of the speaker.

Check that the speaker stand is placed on a flat, stable surface and be sure to fully extend the legs of the stand. Do not try to make the stand “taller” and compromise its structural integrity.

Route cables and position the stand so that performers, production crew and audience members will not trip over the stand or cables and pull the speaker system over. Secure cables with wire ties or tape whenever possible.

Do not attempt to suspend more than one speaker on a stand designed for a single speaker.

Unless you are confident that you can safely handle lifting the weight of the speaker onto the stand, ask another person to help you place it.

18-Mar-14 | 02 | F01U290507

User manual

Bosch Sicherheitssysteme GmbH

AXM 12A Connection | en 9

5

Connection

5.1

Mains input (MAINS IN)





























































































The device receives its power supply via the MAINS IN socket. Only the provided power cord



may be used. Connect the device only to a mains network, which corresponds to the



requirements indicated on the type plate.



The power switch allows for switching the power ON or OFF. The LCD screen lights up when



the power is turned ON.

5.2

Audio inputs

Caution!

High sound level

!Before making any connections or disconnections, make sure to set the corresponding level controls in the fully counterclockwise position -∞.

5.2.1

Microphone/line input

















Electronically balanced INPUT 1/2 MIC/LINE for the connection of a line level signal source (such as mixer etc.) or a microphone. Phantom power can be enabled (see menu item Phantom 1 or 2 in section Menu, page 12) if a condenser microphone is being used. Establishing a connection is possible via TRS or XLR-type plugs. Whenever possible, balanced signal feed is always preferable to guard against potential noise or HF-interference.

Bosch Sicherheitssysteme GmbH

User manual

18-Mar-14 | 02 | F01U290507

10 en | Connection AXM 12A

5.2.2 Aux input



























Stereo unbalanced RCA type INPUT 3 AUX IN for connecting sources such as CD players or



MP3 players. See menu item MIX OUT link in section Menu, page 12 how this input can be



used.

5.3

Audio outputs

5.3.1

Thru output



The THRU output socket is connected in parallel to INPUT 1, it is used for “carrying through”



the pre-fader input signal to additional powered loudspeaker or subwoofer.

5.3.2

Mix output

The post-fader audio signals of INPUT 1, INPUT 2 and INPUT 3 are mixed and passed to MIX OUT. The ratio of the input signals changes when the level controls INPUT 1, 2 or 3 are adjusted. This feature allows the loudspeaker to act as a basic three-channel mixer that can send the mix to another loudspeaker via the MIX OUT socket.

This output is laid out in GND-SENSING technology, a special pin assignment of the output socket, offering all advantages of the balanced signal transmission, but lets you also connect monaural plugs without a problem.

18-Mar-14 | 02 | F01U290507

User manual

Bosch Sicherheitssysteme GmbH
