Super Duty and Heavy Duty
Nominal
Size OD
(Tube)
P Series
Part Number
L W H
TH G A B D
Reinforcement
Plates
2
DXE-SDS-200P
3.64
2.00
1.57
0.565
0.060
1.000
2.40
0.390
DXE-SDSBP-200
2-1/2
DXE-SDS-250P
4.15
2.25
1.82
0.565
0.060
1.125
2.90
0.390
DXE-SDSBP-250
3
DXE-SDS-300P
4.65
2.50
2.06
0.556
0.060
1.250
3.40
0.390
DXE-SDSBP-300
Nominal
Size OD
(Tube)
AP Series Part
Number
L W H
TH G A B D Reinforcement Plates
3/4
DXE-HDS-075AP
1.898
0.75
0.690
0.375
0.12
0.375
1.00
0.266
DXE-HDSBP-075A
1
DXE-HDS-100AP
2.148
1.00
0.815
0.375
0.12
0.50
1.25
0.266
DXE-HDSBP-100A
1-1/4
DXE-HDS-125AP
2.398
1.00
1.065
0.500
0.12
0.50
1.50
0.266
DXE-HDSBP-125A
1-1/2
DXE-HDS-150AP
2.898
1.00
1.190
0.500
0.12
0.50
1.75
0.266
DXE-HDSBP-150A
1-3/4
DXE-HDS-175AP
3.148
1.00
1.315
0.500
0.12
0.50
2.00
0.266
DXE-HDSBP-175A
2
DXE-HDS-200AP
3.648
1.00
1.565
0.625
0.12
0.50
2.375
0.397
DXE-HDSBP-200A
HDS Part Number
Bolt
Size
Length
Thread
Length
SDS Part Number
Bolt Size
Length
Thread
Length
DXE-HDSBOLT2-5S
1/4-20
2-1/2
3/4 to 1
DXE-SDSBOLT-4-5S
3/8-16
4-1/2
1 to 1-5/16
DXE-HDSBOLT2-75S
1/4-20
2-3/4
3/4 to 1
DXE-SDSBOLT-5S
3/8-16
5
1 to 1-5/16
DXE-HDSBOLT3-25S
1/4-20
3-1/4
3/4 to 1
DXE-SDSBOLT-5-5S
3/8-16
5-1/2
1 to 1-5/16
DXE-HDSBOLT3-5S
1/4-20
3-1/2
3/4 to 1
DXE-SDSBOLT-6S
3/8-16
6
1 to 1-5/16
DXE-HDSBOLT3-75S
1/4-20
3-3/4
3/4 to 1
DXE-SDSBOLT-6-5S
3/8-16
6-1/2
1 to 1-9/16
DXE-HDSBOLT4-5S
3/8-16
4-1/2
3/4 to 1
©DX Engineering 2019
1200 Southeast Ave. - Tallmadge, OH 44278 USA
Phone: 800-777-0703 - Tech Support and International: 330-572-3200
Fax: 330-572-3279
E-mail: DXEngineering@DXEngineering.com Rev. 9b
Saddle Clamps
Super Duty and Heavy Duty Saddle clamps must be used
on a flat surface or a customer supplied backing plate
Reinforcement plates (included with SDS P series) laser from premium 1/4" thick steel. All dimensions are in Inches
Reinforcement plates (included with HDS AP series) laser cut from premium 1/8" thick steel. All dimensions are in Inches
Always use a lubricant such as Jet-Lube™ SS-30, Never Seez®, or Anti Seize to prevent the stainless steel hardware from seizing
Stainless Steel Hex Bolt Sets for Heavy Duty and Super Duty Saddle Clamps
P Series Sets contain 2 Bolts, 2 Nuts, 2 Flat Washers and 2 Split Washers
AP Series Sets contain 2 Bolts, 2 Nuts, 4 Flat Washers and 2 Split Washers
Personal injury and property damage can occur without proper installation
