Duro-Last Scuppers User Manual

DATA SHEET

Material – Flange Only

Gauge

Finish

Aluminum

.032

Mill or Kynar®

Stainless Steel

24-gauge

N/A

Bonderized Steel

24-gauge

N/A

Galvalume

24-gauge

Mill or Kynar®

Copper

16 oz.

Mill

Single Skirt Scupper

Double Skirt Scupper

Single Skirt Scupper with Metal Flange

Scuppers

Description:

Scuppers are designed to be used on rectangular
outlets extending through walls or raised roof edges.
Scuppers are custom prefabricated with one or two
skirts or with a single skirt and metal flange.

Fabricated in 24-gauge vinyl-coated metal with

one or two 40-mil 6” membrane skirts.

Custom configurations, including incorporating

the scupper with a collector box, are available
upon request.

Prefabricated scuppers with a 2” terminating

flange reduce field fabrication and installation
time.

Available in white, tan, gray, and dark gray vinyl-

coated metal.

Contact Duro-Last® or EXCEPTIONAL® Metals to
request a color chart, samples and information
regarding custom metals and finishes.

Installation:

1. Install in accordance with Duro-Last detail
drawings #2041, #2060, and #2061.

2. Any deviation from the requirements set forth in
the detail drawings must be pre-approved, in
writing, by the EXCEPTIONAL Metals Technical
Department.

Warranty:

Duro-Last offers a wide range of warranty coverage for
EXCEPTIONAL Metals products when used with the
Duro-Last roofing system, including paint and finish.

Technical Services:

Product samples, detail sheets, color chips, and color
chart are available for your submittal package. For
assistance with questions or submittals, contact your
local representative or call EXCEPTIONAL Metals.

“Duro-Last” and “EXCEPTIONAL” are registered marks owned by Duro-Last Roofing, Inc. Revised 8/12/2012
