MD-K400

Durabrand MD-K400 Service Manual

Download
Service Manual
Model MD-K400
CODE: 1.01.52280.51
MD-K400
1
INDEX
MD-K400
2
1. GENERAL
1.1 Product Front View a) Front Panel
a.1) Front Panel Functions and Indications
1 Power- Standby 12 - Forward Radio/CD 2 Open/Close 13 REC 3 Tuner - Band 14 EQUAL 4 AUX 15 Disc 1, Disc 2, Disc 3 5 Volume 16 - Stop 6 Deck 2 17 - Play/Pause 7 Deck1 18 CD Compartment 8 Tuner 19 Display 9 Tape 20 Remote Control Sensor 10 CD 21 CD – Disc Change 11 - Rewind Radio/CD 22 TAPE
MD-K400
3
1.2 Product Back View
a) Back Panel
a.1) Back Panel Functions and Indications
01 Edges for Ventilation 05 AUX
02 FM antena 06 Service
03 Speakers L and R 07 Force Cable
04 Voltage Selector 110 / 220V
b) Functions
Functions CD Top
Tape Double Deck Radio AM / FM - PLL digital – 10 memories
AUX Input Yes Display FTD Clock 24:00h – Timer Function (ON) Surround Yes
MD-K400
4
c) Characteristics
Product Dimensions 265 x 310 x 333 mm
Weight 4,9 kg Speaker Dimensions 195 x 310 x 208 mm
Weight 1,5 kg Impedance
8Ω
d) Supply
Unit Nominal Min. Max.
Supply Voltage Vac 110 - -
Vac 220 - ­Supply Frequency Hz 50/60 - ­Consumed Power Stand by W 7,7 - 8,0
In Operation W 60 - 62
CD Player:
Type of Laser 3 beams ( λ = 780 nm)
Reproductivity
Realized Test Utilized Test Disc Utilized Track Conclusion
Interruption TCD 725A - Abex 01 to 04 OK Black dots TCD 725A - Abex 07 and 08 OK
Fingerprints TCD 725A - Abex 13 OK Vertical Deviation TCD 731RA - Abex 01 to 15 OK Eccentricity TCD 710A - Abex 01 to 15 OK
MD-K400
5
1.3 REMOTE CONTROL
1.3.1) Remote Control Functions
1 Power 14 Prog/Rpt 2 Numerical key 3 (Disc 3) 15 - Stop CD/Tape 3 Numerical key 6 (Clock) 16 Vol + 4 Numerical key 5 (Sleep) 17 - Rewind Radio/CD/Tape 5 Numerical key 9 (Memo) 18 Tape 6 Tuner 19 CD 7 Numerical key 0 (Hi Bass) 20 Numerical key 8 (Demo) 8 AUX 21 Numerical key 7 (Mode)
9 - Forward Radio/CD/Tape 22 Numerical key 4 (Timer) 10 Vol - 23 Numerical key 2 (Disc 2) 11 - Play/Pause CD/Tape 24 Numerical key 1 (Disc 1) 12 Shuf/Scan 25 Mute 13 Shift 26 Loud
MD-K400
6
2. TECHNICAL SPECIFICATION
AMPLIFICADOR
AMPLIFIER
ENTRADA: AUX./ VIDEO = 1KHz ALIMENTAÇÃO : 127VAC
INPUT: AUX./ VIDEO = 1KHz POWER SOURCE: 127VAC
SAÍDA: CARGAS 8 OHMS
OUTPUT: OUT LOAD 8 OHMS
N°
ÍTEM
ITEM
CONDIÇÕES
CONDITIONS
VALOR TÍPICO
TYPI CAL VALUE
VALOR LIMITE
LIMIT VALUE
1
POTÊNCIA DE SAÍDA
POWER OUTPUT
1KHz 0Dbv (127V) 10% THD
10 + 10 W
8,95 + 8,95 V
≥ 10 +10 W
≥ 8,95 + 8,95V
2
DISTORÇÃO
DISTORTION
1KHz 0dBV, CARGA 2V
2V OUTPUT LOAD , FLAT
0,1%
0,5%
3
SENSIBILIDADE DE ENTRADA
INPUT SENSITIVITY
1KHz 0dBV VOLUME MAXIMO
MAXIMUM VOLUM
400 mV
±100 mV
4
RUÍDO RESIDUAL
RESIDUAL NOISE
ENTRADA CURTO-CIRCUITADA VOLUME MÍN. MIC. VOL. MIN
INPUT SHORTED
MIN. VOL MIC. VOL. MIN.
1 mV
10 mV
5
NÍVEL DE RUÍDO
LEVEL NOISE
ENTRADA CURTO-CIRCUITADA VOLUME MAX. MIC. VOL. MIN
INPUT SHORTED
MAX. VOL MIC. VOL. MIN.
10 mV
120 mV
-3dB UP
60 kHz ± 10 kHz
6
RESPOSTA EM FREQUÊNCIA
FREQUENCY RESPONSE
1KHz 0dBV CARGA 2V
2V OUTPUT LOAD , FLAT
-3dB DOWN
20 Hz ± 10 Hz
7
SEPARAÇÃO DE CANAIS
CHANNEL SEPARATION
1KHz 0dBV, CARGA 2V
2V OUTPUT LOAD , FLAT
45 dB 40 dB
8
GANHO Av DO AMPLIFICADOR
AMPLIFIER Av
1KHz 0dBV, CARGA 2V
2V OUTPUT LOAD , FLAT
23 dB 20 dB
9
RELAÇÃO SINAL/ RUÍDO
SIGNAL NOISE RELATION
1KHz 0dBV, CARGA 2V
2V OUTPUT LOAD , FLAT
60 dB 50 dB
MODO STBY
STBY MODE
8W 12W
MEIO VOLUME - 1KHz 0dB
HALF VOLUM
20W 25W
10
POTÊNCIA DE CONSUMO
POWER CONSUMER
VOLUME MÁXIMO - 1KHz 0dB
MINIMUM VOLUM
55W 60W
MD-K400
7
RÁDIO FM
FM RADIO
NÍVEL PADRÃO DE ENTRADA
STANDARD INPUT LEVEL
MODULAÇÃO
MODULATION
ANTENA
ANTENNA
IMPEDÂNCIA DE ENTRADA
IMPEDANCE OF IMPUT
60dB
MONO: 1kHz, DESVIO: 75kHz
MONO: 1KHz, DEVIATION: 75kHz
ESTÉREO: L + R, 37,5kHz
STEREO: L + R , 37,5kHz
PILOTO: 7,5kHz
PILOT : 7,5kHz
DUMMY DA VI ACOPLAGEM DIRETA
DIRECT COUPLING
PONTO DE MEDIÇÃO: SAÍDA DO RÁDIO
MEASUREMENT POINTS: OUTPUT RADIO
50 OHMS
N°
N°
ITEM
ITEM
CONDIÇÕES
CONDITION
VALOR TÍPICO
TYPICAL VALUE
VALOR LIMITE
LIMIT VALUE
MÍNIMO
MINIMUM
87,5 MHz 87,5 MHz
1
FAIXA DE SINTONIA
TUNNING RANGER
MÁXIMO
MAXIMUM
108,1 MHz 108,1 MHz
90,1MHz 18 dB 23 dB 98,1MHz 18 dB 23 dB2
SENSIBILIDADE USUAL 30dB S/N
USABLE SENSITIVITY
106,1MHz 18 dB 23 dB
3
REL. SINAL/RUÍDO
SIGNAL / NOISE
98,1MHz
40 dB 35 dB
4 DISTORÇÃO
DISTORTION
98,1MHz 0,3 % 1,2 %
5
REJEIÇÃO DE IMAGEM
IMAGE REJECTION
98.1MHz 20 dB 15 dB
100 Hz ± 1 dB ±3 dB
6
RESPOSTA DE FREQUÊNCIA
FREQUENCY RESPONSE
98.1MHz 1kHz
6 KHz -9 dB -10 dB
90.1MHz 25 dB 30 dB 98,1MHz 25 dB 30 dB
7
PARADA DO AUTO SCAM
AUTO-STOP LEVEL
106.1MHz 25 dB 30 dB
8
SEPARAÇÃO DE CANAIS
CHANNEL SEPARATION
98,1MHz
25 dB 20 dB
ON 15 dB 20 dB
9
SENSIBILIDADE DO INDICADOR ESTÉREO
STEREO INDICATION SENSITIVITY
98,1MHz 1KHz
OFF 15 dB 20 dB
10
REJEIÇÃO DE FI
FI REJECTION
98,1MHz 50 dB 70 dB
UP 100 kHz 300 kHz
11
ATUAÇÃO DO AFC
AFC ATUACTION
98,MHz
DOWN 100 kHz 300 kHz
MD-K400
8
RÁDIO AM
AM RADIO
NÍVEL PADRÃO DE ENTRADA: 74dBµV, MODULAÇÃO 30% 400Hz, ANTENA LOOP
STANDARD INPUT LEVEL : 74dBµV, MODULATION: 30% 400Hz, ANTENNA LOOP
N°
N°
ITEM
ITEM
CONDIÇÕES
CONDITION
VALOR TÍPICO
TYPICAL VALUE
VALOR LIMITE
LIMIT VALUE
MINIMO
MINIMUM
520kHz 520kHz
1
FAIXA DE SINTONIA
RANGE TUNNER
MÁXIMO
MAXIMUM
1650kHz 1650kHz
600kHz 70 dB 72 dB 1000kHz 65 dB 72 dB
2
SENSIBILIDADE USUAL 20dB S/N
USABLE SENSITIVITY
1400kHz 65 dB 70 dB
3
REL. SINAL/RUÍDO
SIGNAL / NOISE
1000Hz
30 dB 25 dB
4
AGC
AGC
1000kHz 60 dB
≥50 dB
5
DISTORÇÃO
DISTORTION
1000kHz 0.8% <2%
100Hz
± 3 dB ±5 dB
6
RESPOSTA DE FREQUÊNCIA
FREQUENCY RESPONSE
1000kHz 400Hz
3kHz -8 dB -10 dB
DECK REPRODUÇÃO
REPRODUCTION DECK
N°N°ITEM
ITEM
CONDIÇÕES
CONDITION
VALOR TÍPICO
TYPICAL VALUE
VALOR LIMITE
LIMIT VALUE
W&F
0,1% 0,3%
1 WOW & FLUTER
MTT 111
FREQ .
3 kHz ± 3% 3 kHz ± 6%
125Hz
± 1 dB ± 3 dB
2
RESPOSTA EM FREQUENCIA
FREQUENCY RESPONSE
MTT 117 MTT 117 ( 1KHz = 0dB )
6,3KHz ± 1 dB ± 3 dB
3
SEPARAÇÃO DE CANAIS
CHANNEL SEPARATION
MTT 141 30 dB 20 dB
VOLUME MÍNIMO
MINIMUM VOLUM
5 mV 10 mV
4
RUÍDO TAPE PLAY
TAPE NOISE PLAY
VOLUME MÁXIMO
MAXIMUM VOLUM
50 mV 100 mV
5
RELAÇÃO SINAL RUÍDO
SIGNAL NOISE RELATION
MTT 118 ( PLAY/STOP ) 35 dB 30 dB
6
DISTORÇÃO
DISTORTION
MTT 118 1% 2 %
MD-K400
9
7
DIFERENÇA DE CANAIS
CHANNEL DIFFERENCE
MTT 118 1dB 2dB
DECK GRAVAÇÃO
WRITING DECK
N°N°ITEM
ITEM
CONDIÇÕES
CONDITION
VALOR TÍPICO
TYPICAL VALUE
VALOR LIMITE
LIMIT VALUE
1
DIFERENÇA DE NÍVEL REC/PLAY
LEVEL DIFERENCE REC/PLAY
MTT 118 -1,0dB -3,0dB
2
RELAÇÃO SINAL RUÍDO
SIGNAL NOISE RELATION
1kHz -10dB via CD 30 dB 25 dB
125Hz
±3 dB ±5 dB
3
RESPOSTA EM FREQUENCIA
FREQUENCY RESPONSE
( 1KHz = 0dB )
6,3KHz ±3 dB ±5 dB
4
SEPARAÇÃO DE CANAIS L/R
CHANNEL SEPARATION
1KHz - L/R 30 dB 25 dB
VOLUME MÍNIMO
MINIMUM VOLUM
5 mV 10 mV
5
RUÍDO TAPE REC/PLAY
TAPE NOISE REC/PLAY VOLUME MÁXIMO
MAXIMUM VOLUM
50 mV 120 mV
6
DISTORÇÃO
DISTORTION
MTT 118 1,5 % 3 %
CD
CD
N°
N°
ITEM
ITEM
CONDIÇÕES
CONDITION
VALOR TÍPICO
TYPICAL VALUE
VALOR LIMITE
LIMIT VALUE
1
RELAÇÃO SINAL RUÍDO
SIGNAL NOISE RELATION
TNO 24 CD Yeds 18 80 dB 70 dB
125Hz
± 0,5 dB ± 3 dB
2
RESPOSTA EM FREQUENCIA
FREQUENCY RESPONSE
TNO 04 TNO 09 ( 1KHz = 0dB )
6,3KHz ± 0,5 dB ± 3 dB
3
SEPARAÇÃO DE CANAIS L/R
CHANNEL SEPARATION
TNO 33/34 - CD Yeds 18 1KHz - L/R
45 dB 40 dB
VOLUME MÍNIMO
MINIMUM VOLUM
5 mV 10 mV
4
RUÍDO TAPE REC/PLAY
TAPE NOISE REC/PLAY
VOLUME MÁXIMO
MAXIMUM VOLUM
50 mV 120 mV
5
DISTORÇÃO
DISTORTION
TNO 24 - CD Yeds 18 0,3 % 1 %
MD-K400
10
EQUALIZADOR
EQUALIZATOR
Nº
ÍTEM
ITEM
CONDIÇÕES
CONDITION
VALOR TÍPICO
TYPICAL VALUE
VALOR LIMITE
LIMIT VALUE
1 LOUDNESS ON 100Hz – Vol.10 12dB ± 5dB
2 HI BASS ON 100Hz – Vol.10 3,5dB
± 1dB
3
PERSON (Vol.10)
BASS +6 BASS –6 TREB +6 TREB –6
±6dB ±1dB
MD-K400
11
3. CALIBRATION SCRIPT
Obs.: This procedures can be used to orientation , some item can be
changed by the factory engineering for best application and improve the factoring process.
FM RANGE
Tunning in 87,5 MHz, adjust the coil OSC-FM (L.102) to obtain ~ 2,0 V in the
tunnig voltage (terminal 28 of IC101 with resistor of 10K in serie with the
voltimeter ). Tunnig in 108,1 MHz, and verify if the tunnig voltage is ~ 7,1 V. The voltage values can be slightly changed to help the production.
FI-FM
Connect a FM sweepings generator in the FM input. Tunning the radio in 98,1 MHz.
Verify the shape of curve “S”, in the pin 23 of the IC101.
TRACKING FM
Connect a FM sweeping generator in the FM input. The generator output must have a very low RF signal and cannot saturate the
IC output (pin 23 of the IC101 ). Tunning in 90,1 MHz and adjust the RF-FM coil (L.101) to obtain maximum output signal.
Tunning in 106,1 MHz and adjust VC.102 to obtain maximum output signal
AM RANGE
Tunning in 520 kHz, adjust the OSC-AM coil (T.101) to obtain ~ 1,0 V in the tunning voltage. Tunning in 1650 kHz, and verify if the tunning voltage is ~ 6,5 V. The voltage values can be slightly changed to help the production.
FI-AM
Adjust an AM generator to1000 kHz with 30% of modulation in 400 Hz.
Tunning the radio in 1000 kHz .
Must be used a very low RF signal.
If haves undesirable noises, this frequency can be displaced for + or -, together
with a frequency of generator frequency.
Adjust the FI-AM coil (T.104) to obtain the maximum detected signal.
MD-K400
12
TRACKING-AM
Irradiate a AM sweeping to the ferrite antenna. Tunning in 600 kHz and adjust the coil ANT-AM (T.102) to obtain maximum output signal. Tunning in 1400 kHz and adjust VC.101 to obtain maximum output signal. Remake the adjust three times to obtain the best adjust point.
COMMENTS
The FM signal generator have be connected in the FM input through of DUMMY DA-V. The AM signal generator have be irradiated for a LOOP antenna and captured
by itself ferrite antenna of the device. As much in the calibration of AM as in the one of FM, the used tool for calibrate
the coils have be of material not magnetic.
45
1060( 50 : 75 )
OSC. BIAS
Connect a VTVM in the point TP5 e TP6. The VTVM output must be linked in a frequencymeter. Put a tape with the unbroken rec constraint. Select a AUX function whitout input signal. Adjust T903 to obtain 59.068 Hz +/- 20Hz in the frequencymeter. Verify if in the VTVM have a 0,035V signal.
MD-K400
13
4. MATERIAL LIST
MAIN PCB
CAPACITORS
CODE DESCRIPTION POSITION
1491047004 CAP.SMD NP0 47PF/50V J 0603 C606 1491047004 CAP.SMD NP0 47PF/50V J 0603 C607 1491047004 CAP.SMD NP0 47PF/50V J 0603 C608 1491047004 CAP.SMD NP0 47PF/50V J 0603 C609 1491047004 CAP.SMD NP0 47PF/50V J 0603 C611 1491047004 CAP.SMD NP0 47PF/50V J 0603 C614 1491047004 CAP.SMD NP0 47PF/50V J 0603 C615 1491047004 CAP.SMD NP0 47PF/50V J 0603 C618 1491047004 CAP.SMD NP0 47PF/50V J 0603 C619 1491047004 CAP.SMD NP0 47PF/50V J 0603 C620 1491047004 CAP.SMD NP0 47PF/50V J 0603 C621 1491047004 CAP.SMD NP0 47PF/50V J 0603 C622 1491047004 CAP.SMD NP0 47PF/50V J 0603 C624 1491047004 CAP.SMD NP0 47PF/50V J 0603 C625 1491047004 CAP.SMD NP0 47PF/50V J 0603 C626 1491047004 CAP.SMD NP0 47PF/50V J 0603 C632 1491047004 CAP.SMD NP0 47PF/50V J 0603 C633 1491047004 CAP.SMD NP0 47PF/50V J 0603 C634 1491047004 CAP.SMD NP0 47PF/50V J 0603 C635 1490447004 CAP.SMD NPO 47PF/50V J 0805 C606 1490447004 CAP.SMD NPO 47PF/50V J 0805 C607 1490447004 CAP.SMD NPO 47PF/50V J 0805 C608 1490447004 CAP.SMD NPO 47PF/50V J 0805 C609 1490447004 CAP.SMD NPO 47PF/50V J 0805 C611 1490447004 CAP.SMD NPO 47PF/50V J 0805 C614 1490447004 CAP.SMD NPO 47PF/50V J 0805 C615 1490447004 CAP.SMD NPO 47PF/50V J 0805 C618 1490447004 CAP.SMD NPO 47PF/50V J 0805 C619 1490447004 CAP.SMD NPO 47PF/50V J 0805 C620 1490447004 CAP.SMD NPO 47PF/50V J 0805 C621 1490447004 CAP.SMD NPO 47PF/50V J 0805 C622 1490447004 CAP.SMD NPO 47PF/50V J 0805 C624 1490447004 CAP.SMD NPO 47PF/50V J 0805 C625 1490447004 CAP.SMD NPO 47PF/50V J 0805 C626 1490447004 CAP.SMD NPO 47PF/50V J 0805 C632 1490447004 CAP.SMD NPO 47PF/50V J 0805 C633 1490447004 CAP.SMD NPO 47PF/50V J 0805 C634 1490447004 CAP.SMD NPO 47PF/50V J 0805 C635 1490447000 CAP.SMD NPO 47PF/50V K 0805 C606 1490447000 CAP.SMD NPO 47PF/50V K 0805 C607 1490447000 CAP.SMD NPO 47PF/50V K 0805 C608 1490447000 CAP.SMD NPO 47PF/50V K 0805 C609 1490447000 CAP.SMD NPO 47PF/50V K 0805 C611 1490447000 CAP.SMD NPO 47PF/50V K 0805 C614 1490447000 CAP.SMD NPO 47PF/50V K 0805 C615 1490447000 CAP.SMD NPO 47PF/50V K 0805 C618 1490447000 CAP.SMD NPO 47PF/50V K 0805 C619 1490447000 CAP.SMD NPO 47PF/50V K 0805 C620
MD-K400
14
CODE DESCRIPTION POSITION
1490447000 CAP.SMD NPO 47PF/50V K 0805 C621 1490447000 CAP.SMD NPO 47PF/50V K 0805 C622 1490447000 CAP.SMD NPO 47PF/50V K 0805 C624 1490447000 CAP.SMD NPO 47PF/50V K 0805 C625 1490447000 CAP.SMD NPO 47PF/50V K 0805 C626 1490447000 CAP.SMD NPO 47PF/50V K 0805 C632 1490447000 CAP.SMD NPO 47PF/50V K 0805 C633 1490447000 CAP.SMD NPO 47PF/50V K 0805 C634 1490447000 CAP.SMD NPO 47PF/50V K 0805 C635 1492022300 CAP.SMD X7R 22KPF/25V K 0603 C128 1492022300 CAP.SMD X7R 22KPF/25V K 0603 C129 1492022300 CAP.SMD X7R 22KPF/25V K 0603 C506 1492022300 CAP.SMD X7R 22KPF/25V K 0603 C507 1492022300 CAP.SMD X7R 22KPF/25V K 0603 C519 1492022300 CAP.SMD X7R 22KPF/25V K 0603 C520 1492022300 CAP.SMD X7R 22KPF/25V K 0603 C617 1492022300 CAP.SMD X7R 22KPF/25V K 0603 C629 1492022300 CAP.SMD X7R 22KPF/25V K 0603 C636 1490522300 CAP.SMD X7R 22KPF/50V K 0805 C128 1490522300 CAP.SMD X7R 22KPF/50V K 0805 C129 1490522300 CAP.SMD X7R 22KPF/50V K 0805 C506 1490522300 CAP.SMD X7R 22KPF/50V K 0805 C507 1490522300 CAP.SMD X7R 22KPF/50V K 0805 C519 1490522300 CAP.SMD X7R 22KPF/50V K 0805 C520 1490522300 CAP.SMD X7R 22KPF/50V K 0805 C617 1490522300 CAP.SMD X7R 22KPF/50V K 0805 C629 1490522300 CAP.SMD X7R 22KPF/50V K 0805 C636 1490522303 CAP.SMD X7R 22KPF/25V K 0805 C128 1490522303 CAP.SMD X7R 22KPF/25V K 0805 C129 1490522303 CAP.SMD X7R 22KPF/25V K 0805 C506 1490522303 CAP.SMD X7R 22KPF/25V K 0805 C507 1490522303 CAP.SMD X7R 22KPF/25V K 0805 C519 1490522303 CAP.SMD X7R 22KPF/25V K 0805 C520 1490522303 CAP.SMD X7R 22KPF/25V K 0805 C617 1490522303 CAP.SMD X7R 22KPF/25V K 0805 C629 1490522303 CAP.SMD X7R 22KPF/25V K 0805 C636 1492010300 CAP.SMD X7R 10KPF/50V K 0603 C637 1492010300 CAP.SMD X7R 10KPF/50V K 0603 C817 1492010300 CAP.SMD X7R 10KPF/50V K 0603 C818 1490510300 CAP.SMD X7R 10KPF/50V K 0805 C637 1490510300 CAP.SMD X7R 10KPF/50V K 0805 C817 1490510300 CAP.SMD X7R 10KPF/50V K 0805 C818 1363103303 C.C.D.Y5U 10KPF>=100V Z C215 1363103303 C.C.D.Y5U 10KPF>=100V Z C216 1363103303 C.C.D.Y5U 10KPF>=100V Z C217 1363103303 C.C.D.Y5U 10KPF>=100V Z C501 1363103303 C.C.D.Y5U 10KPF>=100V Z C502 1363103303 C.C.D.Y5U 10KPF>=100V Z C503 1363103303 C.C.D.Y5U 10KPF>=100V Z C504 1363103601 C.C.D. Y5U 10KPF/500V Z C510 1380229622 ELCO 2,2UF/100V M 5X11MM C406 1380229622 ELCO 2,2UF/100V M 5X11MM C407 1380229622 ELCO 2,2UF/100V M 5X11MM C408
MD-K400
15
CODE DESCRIPTION POSITION
1380229622 ELCO 2,2UF/100V M 5X11MM C409 1380229622 ELCO 2,2UF/100V M 5X11MM C410 1380229622 ELCO 2,2UF/100V M 5X11MM C411 1380229622 ELCO 2,2UF/100V M 5X11MM C421 1380229622 ELCO 2,2UF/100V M 5X11MM C422 1380229622 ELCO 2,2UF/100V M 5X11MM C424 1380229622 ELCO 2,2UF/100V M 5X11MM C425 1330104106 C.POLYEMT 100KPF/63V K C404 1330104106 C.POLYEMT 100KPF/63V K C405 1339104106 C.POLYM.100KPF/63V K MINI BLUE C404 1339104106 C.POLYM.100KPF/63V K MINI BLUE C405 1330104106 C.POLYEMT 100KPF/63V K C414 1330104106 C.POLYEMT 100KPF/63V K C415 1330104106 C.POLYEMT 100KPF/63V K C416 1330104106 C.POLYEMT 100KPF/63V K C417 1339104106 C.POLYM.100KPF/63V K MINI BLUE C414 1339104106 C.POLYM.100KPF/63V K MINI BLUE C415 1339104106 C.POLYM.100KPF/63V K MINI BLUE C416 1339104106 C.POLYM.100KPF/63V K MINI BLUE C417 1330224122 C.POLYMET 220KPF/63V K C207 1330224122 C.POLYMET 220KPF/63V K C208 1339224122 C.POLYM. 220KPF/63V K MINIBLUE C207 1339224122 C.POLYM. 220KPF/63V K MINIBLUE C208 1330272100 CAP. POLYMET MKT 2,7KPF/63V K C402 1330272100 CAP. POLYMET MKT 2,7KPF/63V K C403 1339272100 C.POLYM.2,7KPF/63V K MINIBLUE C402 1339272100 C.POLYM.2,7KPF/63V K MINIBLUE C403 1380100524 ELCO 10UF/50V M 5X11MM C201 1380100524 ELCO 10UF/50V M 5X11MM C202 1380100524 ELCO 10UF/50V M 5X11MM C212 1380100524 ELCO 10UF/50V M 5X11MM C419 1380100524 ELCO 10UF/50V M 5X11MM C420 1380100524 ELCO 10UF/50V M 5X11MM C602 1380100524 ELCO 10UF/50V M 5X11MM C630 1380101328 ELCO 100UF/25V M 6,3X11MM C211 1491033004 CAP.SMD NP0 33PF/50V J 0603 C639 1491033004 CAP.SMD NP0 33PF/50V J 0603 C640 1490433004 CAP.SMD NPO 33PF/50V J 0805 C639 1490433004 CAP.SMD NPO 33PF/50V J 0805 C640 1490433000 CAP.SMD NPO 33PF/50V K 0805 C639 1490433000 CAP.SMD NPO 33PF/50V K 0805 C640 1380470324 ELCO 47UF/25V M 5X11MM C603 1380470324 ELCO 47UF/25V M 5X11MM C803 1380471225 ELCO 470UF/16V M 8X11,5MM C508 1380471229 ELCO 470UF/16V M 10X12,5MM C508 1380221231 ELCO 220UF/16V M 6,3X11MM C509 1380101224 ELCO 100UF/16V M 5X11MM C521 1380101228 ELCO 100UF/16V M 6,3x11MM C521 1380101531 ELCO 100UF/50V M 8X11MM C511 1380101531 ELCO 100UF/50V M 8X11MM C512 1380101532 ELCO 100UF/63V M 8X11MM C511 1380101532 ELCO 100UF/63V M 8X11MM C512 1380101533 ELCO 100UF/50V M 8X11MM 105ºC C511
MD-K400
16
CODE DESCRIPTION POSITION
1380101533 ELCO 100UF/50V M 8X11MM 105ºC C512 1493010405 CAP.SMD Y5V 100KPF/25V Z 0603 C1901 1490610406 CAP.SMD Y5V 100KPF/25V Z 0805 C1901 1380101224 ELCO 100UF/16V M 5X11MM C205 1380101224 ELCO 100UF/16V M 5X11MM C206 1380101224 ELCO 100UF/16V M 5X11MM C401 1380101224 ELCO 100UF/16V M 5X11MM C418 1380101224 ELCO 100UF/16V M 5X11MM C522 1380101228 ELCO 100UF/16V M 6,3x11MM C205 1380101228 ELCO 100UF/16V M 6,3x11MM C206 1380101228 ELCO 100UF/16V M 6,3x11MM C401 1380101228 ELCO 100UF/16V M 6,3x11MM C418 1380101228 ELCO 100UF/16V M 6,3x11MM C522 1363103303 C.C.D.Y5U 10KPF>=100V Z C218 1492033300 CAP.SMD X7R 33KPF/25V K 0603 C638 1491047004 CAP.SMD NP0 47PF/50V J 0603 C604 1491047004 CAP.SMD NP0 47PF/50V J 0603 C605 1491047004 CAP.SMD NP0 47PF/50V J 0603 C610 1491047004 CAP.SMD NP0 47PF/50V J 0603 C612 1491047004 CAP.SMD NP0 47PF/50V J 0603 C613 1491047004 CAP.SMD NP0 47PF/50V J 0603 C616 1491047004 CAP.SMD NP0 47PF/50V J 0603 C623 1491047004 CAP.SMD NP0 47PF/50V J 0603 C631 1491047004 CAP.SMD NP0 47PF/50V J 0603 C641 1490447004 CAP.SMD NPO 47PF/50V J 0805 C604 1490447004 CAP.SMD NPO 47PF/50V J 0805 C605 1490447004 CAP.SMD NPO 47PF/50V J 0805 C610 1490447004 CAP.SMD NPO 47PF/50V J 0805 C612 1490447004 CAP.SMD NPO 47PF/50V J 0805 C613 1490447004 CAP.SMD NPO 47PF/50V J 0805 C616 1490447004 CAP.SMD NPO 47PF/50V J 0805 C623 1490447004 CAP.SMD NPO 47PF/50V J 0805 C631 1490447004 CAP.SMD NPO 47PF/50V J 0805 C641 1490447000 CAP.SMD NPO 47PF/50V K 0805 C604 1490447000 CAP.SMD NPO 47PF/50V K 0805 C605 1490447000 CAP.SMD NPO 47PF/50V K 0805 C610 1490447000 CAP.SMD NPO 47PF/50V K 0805 C612 1490447000 CAP.SMD NPO 47PF/50V K 0805 C613 1490447000 CAP.SMD NPO 47PF/50V K 0805 C616 1490447000 CAP.SMD NPO 47PF/50V K 0805 C623 1490447000 CAP.SMD NPO 47PF/50V K 0805 C631 1490447000 CAP.SMD NPO 47PF/50V K 0805 C641 1494047004 CAP.SMD CH 47PF/50V J 0805 C604 1494047004 CAP.SMD CH 47PF/50V J 0805 C605 1494047004 CAP.SMD CH 47PF/50V J 0805 C610 1494047004 CAP.SMD CH 47PF/50V J 0805 C612 1494047004 CAP.SMD CH 47PF/50V J 0805 C613 1494047004 CAP.SMD CH 47PF/50V J 0805 C616 1494047004 CAP.SMD CH 47PF/50V J 0805 C623 1494047004 CAP.SMD CH 47PF/50V J 0805 C631 1494047004 CAP.SMD CH 47PF/50V J 0805 C641 1491010004 CAP.SMD NP0 10PF/50V J 0603 C119 1491010004 CAP.SMD NP0 10PF/50V J 0603 C120
MD-K400
17
CODE DESCRIPTION POSITION
1490410004 CAP.SMD NPO 10PF/50V J 0805 C119 1490410004 CAP.SMD NPO 10PF/50V J 0805 C120 1494010003 CAP.SMD CH 10PF/50V D 0805 C119 1494010003 CAP.SMD CH 10PF/50V D 0805 C120 1490410000 CAP.SMD NPO 10PF/50V K 0805 C119 1490410000 CAP.SMD NPO 10PF/50V K 0805 C120 1491015004 CAP.SMD NP0 15PF/50V J 0603 C103 1492047300 CAP.SMD X7R 47KPF/16V K 0603 C102 1492047300 CAP.SMD X7R 47KPF/16V K 0603 C110 1492047300 CAP.SMD X7R 47KPF/16V K 0603 C111 1492047300 CAP.SMD X7R 47KPF/16V K 0603 C112 1492047300 CAP.SMD X7R 47KPF/16V K 0603 C114 1492047300 CAP.SMD X7R 47KPF/16V K 0603 C122 1492047300 CAP.SMD X7R 47KPF/16V K 0603 C124 1492047300 CAP.SMD X7R 47KPF/16V K 0603 C130 1492047300 CAP.SMD X7R 47KPF/16V K 0603 C132 1490547303 CAP.SMD X7R 47KPF/25V K 0805 C102 1490547303 CAP.SMD X7R 47KPF/25V K 0805 C110 1490547303 CAP.SMD X7R 47KPF/25V K 0805 C111 1490547303 CAP.SMD X7R 47KPF/25V K 0805 C112 1490547303 CAP.SMD X7R 47KPF/25V K 0805 C114 1490547303 CAP.SMD X7R 47KPF/25V K 0805 C122 1490547303 CAP.SMD X7R 47KPF/25V K 0805 C124 1490547303 CAP.SMD X7R 47KPF/25V K 0805 C130 1490547303 CAP.SMD X7R 47KPF/25V K 0805 C132 1380101224 ELCO 100UF/16V M 5X11MM C123 1380101224 ELCO 100UF/16V M 5X11MM C131 1380101228 ELCO 100UF/16V M 6,3x11MM C123 1380101228 ELCO 100UF/16V M 6,3x11MM C131 1380101228 ELCO 100UF/16V M 6,3x11MM C123 1380101228 ELCO 100UF/16V M 6,3x11MM C131 1380101224 ELCO 100UF/16V M 5X11MM C123 1380101224 ELCO 100UF/16V M 5X11MM C131 1493010405 CAP.SMD Y5V 100KPF/25V Z 0603 C116 1490610406 CAP.SMD Y5V 100KPF/25V Z 0805 C116 1380109622 ELCO 1UF/100V M 5x11mm C125 1380109622 ELCO 1UF/100V M 5x11mm C127 1380109622 ELCO 1UF/100V M 5x11mm C513 1380109622 ELCO 1UF/100V M 5x11mm C518 1380109622 ELCO 1UF/100V M 5x11mm C601 1380478622 ELCO 0,47UF/100V M 5x11mm C113 1380478622 ELCO 0,47UF/100V M 5x11mm C126 1380220528 ELCO 22UF/50V M 5X11MM C115 1380220528 ELCO 22UF/50V M 5X11MM C121 1380220528 ELCO 22UF/50V M 5X11MM C305 1380479622 ELCO 4,7UF/100V M 5x11mm C118 1380479522 ELCO 4,7UF/50V M 5X11MM C118 1380479522 ELCO 4,7UF/50V M 5X11MM C118 1380479622 ELCO 4,7UF/100V M 5x11mm C118 1491039104 CAP.SMD NP0 390PF/50V J 0603 C105 1491039104 CAP.SMD NP0 390PF/50V J 0603 C117 1494039104 CAP.SMD CH 390PF/50V J 0805 C105 1494039104 CAP.SMD CH 390PF/50V J 0805 C117
MD-K400
18
CODE DESCRIPTION POSITION
1491022004 CAP.SMD NP0 22PF/50V J 0603 C109 1490422004 CAP.SMD NPO 22PF/50V J 0805 C109 1490422000 CAP.SMD NPO 22PF/50V K 0805 C109 1492010200 CAP.SMD X7R 1KPF/50V K 0603 C106 1490510200 CAP.SMD X7R 1KPF/50V K 0805 C106 1494210200 CAP.SMD Y5P 1KPF/50V K 0805 C106 1491039004 CAP.SMD NP0 39PF/50V J 0603 C104 1490439000 CAP.SMD NPO 39PF/50V J 0805 C104 1492047300 CAP.SMD X7R 47KPF/16V K 0603 C134 1490547303 CAP.SMD X7R 47KPF/25V K 0805 C134 1492010200 CAP.SMD X7R 1KPF/50V K 0603 C135 1492010200 CAP.SMD X7R 1KPF/50V K 0603 C136 1490510200 CAP.SMD X7R 1KPF/50V K 0805 C135 1490510200 CAP.SMD X7R 1KPF/50V K 0805 C136 1494210200 CAP.SMD Y5P 1KPF/50V K 0805 C135 1494210200 CAP.SMD Y5P 1KPF/50V K 0805 C136 1492047100 CAP.SMD X7R 470PF/50V K 0603 C108 1490547100 CAP.SMD X7R 470PF/50V K 0805 C108 1494047104 CAP.SMD CH 470PF/50V J 0805 C108 1492047100 CAP.SMD X7R 470PF/50V K 0603 C203 1492047100 CAP.SMD X7R 470PF/50V K 0603 C204 1494047104 CAP.SMD CH 470PF/50V J 0805 C203 1494047104 CAP.SMD CH 470PF/50V J 0805 C204 1380229622 ELCO 2,2UF/100V M 5X11MM C412 1380229622 ELCO 2,2UF/100V M 5X11MM C413 1380221231 ELCO 220UF/16V M 6,3X11MM C514 1291102419 ELCO 1000UF/25V M 10X20MM C209 1291102419 ELCO 1000UF/25V M 10X20MM C210 1291222423 ELCO 2200UF/25V M 13X25MM C505 1291222422 ELCO 2200UF/25V M 16X20MM C505 1279006110 CAPACITOR TRIMER 10PF VC101 1279006110 CAPACITOR TRIMER 10PF VC102 1292222631 ELCO 2200UF/50V M 18X35MM C213
RESISTORS
CODE DESCRIPTION POSITION
1502547203 RES.SMD 4,7K 5% 0603 R1925 1502547203 RES.SMD 4,7K 5% 0603 R1931 1502547202 RES.SMD 4,7K 5% 0805 R1925 1502547202 RES.SMD 4,7K 5% 0805 R1931 1502510303 RES.SMD 10K 5% 0603 R645 1502510302 RES.SMD 10K 5% 0805 R645 1502547303 RES.SMD 47K 5% 0603 R214 1502547303 RES.SMD 47K 5% 0603 R414 1502547303 RES.SMD 47K 5% 0603 R415 1502547302 RES.SMD 47K 5% 0805 R214 1502547302 RES.SMD 47K 5% 0805 R414 1502547302 RES.SMD 47K 5% 0805 R415 1502512303 RES.SMD 12K 5% 0603 R417 1502512303 RES.SMD 12K 5% 0603 R418 1502512302 RES.SMD 12K 5% 0805 R417 1502512302 RES.SMD 12K 5% 0805 R418 1502510203 RES.SMD 1K 5% 0603 R503
MD-K400
19
CODE DESCRIPTION POSITION
1502510203 RES.SMD 1K 5% 0603 R505 1502510203 RES.SMD 1K 5% 0603 R508 1502510203 RES.SMD 1K 5% 0603 R610 1502510203 RES.SMD 1K 5% 0603 R619 1502510203 RES.SMD 1K 5% 0603 R626 1502510203 RES.SMD 1K 5% 0603 R627 1502510203 RES.SMD 1K 5% 0603 R628 1502510203 RES.SMD 1K 5% 0603 R633 1502510203 RES.SMD 1K 5% 0603 R647 1502510203 RES.SMD 1K 5% 0603 R648 1502510203 RES.SMD 1K 5% 0603 R802 1502510203 RES.SMD 1K 5% 0603 R803 1502510203 RES.SMD 1K 5% 0603 R822 1502510203 RES.SMD 1K 5% 0603 R823 1502510203 RES.SMD 1K 5% 0603 R824 1502510203 RES.SMD 1K 5% 0603 R825 1502510202 RES.SMD 1K 5% 0805 R503 1502510202 RES.SMD 1K 5% 0805 R505 1502510202 RES.SMD 1K 5% 0805 R508 1502510202 RES.SMD 1K 5% 0805 R610 1502510202 RES.SMD 1K 5% 0805 R619 1502510202 RES.SMD 1K 5% 0805 R626 1502510202 RES.SMD 1K 5% 0805 R627 1502510202 RES.SMD 1K 5% 0805 R628 1502510202 RES.SMD 1K 5% 0805 R633 1502510202 RES.SMD 1K 5% 0805 R647 1502510202 RES.SMD 1K 5% 0805 R648 1502510202 RES.SMD 1K 5% 0805 R802 1502510202 RES.SMD 1K 5% 0805 R803 1502510202 RES.SMD 1K 5% 0805 R822 1502510202 RES.SMD 1K 5% 0805 R823 1502510202 RES.SMD 1K 5% 0805 R824 1502510202 RES.SMD 1K 5% 0805 R825 1502522903 RES.SMD 2,2R 5% 0603 R207 1502522903 RES.SMD 2,2R 5% 0603 R208 1502522902 RES.SMD 2,2R 5% 0805 R207 1502522902 RES.SMD 2,2R 5% 0805 R208 1502522303 RES.SMD 22K 5% 0603 R1911 1502522303 RES.SMD 22K 5% 0603 R211 1502522303 RES.SMD 22K 5% 0603 R212 1502522303 RES.SMD 22K 5% 0603 R310 1502522303 RES.SMD 22K 5% 0603 R312 1502522303 RES.SMD 22K 5% 0603 R604 1502522302 RES.SMD 22K 5% 0805 R1911 1502522302 RES.SMD 22K 5% 0805 R211 1502522302 RES.SMD 22K 5% 0805 R212 1502522302 RES.SMD 22K 5% 0805 R310 1502522302 RES.SMD 22K 5% 0805 R312 1502522302 RES.SMD 22K 5% 0805 R604 1502510303 RES.SMD 10K 5% 0603 R1929 1502510303 RES.SMD 10K 5% 0603 R1930 1502510303 RES.SMD 10K 5% 0603 R201 1502510303 RES.SMD 10K 5% 0603 R202
MD-K400
20
CODE DESCRIPTION POSITION
1502510303 RES.SMD 10K 5% 0603 R216 1502510303 RES.SMD 10K 5% 0603 R217 1502510303 RES.SMD 10K 5% 0603 R218 1502510303 RES.SMD 10K 5% 0603 R219 1502510303 RES.SMD 10K 5% 0603 R601 1502510303 RES.SMD 10K 5% 0603 R646 1502510303 RES.SMD 10K 5% 0603 R845 1502510303 RES.SMD 10K 5% 0603 R846 1502510302 RES.SMD 10K 5% 0805 R1929 1502510302 RES.SMD 10K 5% 0805 R1930 1502510302 RES.SMD 10K 5% 0805 R201 1502510302 RES.SMD 10K 5% 0805 R202 1502510302 RES.SMD 10K 5% 0805 R216 1502510302 RES.SMD 10K 5% 0805 R217 1502510302 RES.SMD 10K 5% 0805 R218 1502510302 RES.SMD 10K 5% 0805 R219 1502510302 RES.SMD 10K 5% 0805 R601 1502510302 RES.SMD 10K 5% 0805 R646 1502510302 RES.SMD 10K 5% 0805 R845 1502510302 RES.SMD 10K 5% 0805 R846 1502510303 RES.SMD 10K 5% 0603 R1905 1502510303 RES.SMD 10K 5% 0603 R1909 1502510303 RES.SMD 10K 5% 0603 R602 1502510303 RES.SMD 10K 5% 0603 R603 1502510303 RES.SMD 10K 5% 0603 R605 1502510303 RES.SMD 10K 5% 0603 R616 1502510303 RES.SMD 10K 5% 0603 R638 1502510303 RES.SMD 10K 5% 0603 R641 1502510303 RES.SMD 10K 5% 0603 R642 1502510303 RES.SMD 10K 5% 0603 R643 1502510303 RES.SMD 10K 5% 0603 R644 1502510302 RES.SMD 10K 5% 0805 R1905 1502510302 RES.SMD 10K 5% 0805 R1909 1502510302 RES.SMD 10K 5% 0805 R602 1502510302 RES.SMD 10K 5% 0805 R603 1502510302 RES.SMD 10K 5% 0805 R605 1502510302 RES.SMD 10K 5% 0805 R616 1502510302 RES.SMD 10K 5% 0805 R638 1502510302 RES.SMD 10K 5% 0805 R641 1502510302 RES.SMD 10K 5% 0805 R642 1502510302 RES.SMD 10K 5% 0805 R643 1502510302 RES.SMD 10K 5% 0805 R644 1502510203 RES.SMD 1K 5% 0603 R624 1502510203 RES.SMD 1K 5% 0603 R625 1502510202 RES.SMD 1K 5% 0805 R624 1502510202 RES.SMD 1K 5% 0805 R625 1502510603 RES.SMD 10M 5% 0603 R640 1502510602 RES.SMD 10M 5% 0805 R640 1502510003 RES.SMD 10R 5% 0603 R401 1502510003 RES.SMD 10R 5% 0603 R618 1502510003 RES.SMD 10R 5% 0603 R632 1502510002 RES.SMD 10R 5% 0805 R401 1502510002 RES.SMD 10R 5% 0805 R618
MD-K400
21
CODE DESCRIPTION POSITION
1502510002 RES.SMD 10R 5% 0805 R632 1502510203 RES.SMD 1K 5% 0603 R209 1502510203 RES.SMD 1K 5% 0603 R210 1502510203 RES.SMD 1K 5% 0603 R607 1502510203 RES.SMD 1K 5% 0603 R608 1502510203 RES.SMD 1K 5% 0603 R609 1502510203 RES.SMD 1K 5% 0603 R614 1502510203 RES.SMD 1K 5% 0603 R615 1502510203 RES.SMD 1K 5% 0603 R620 1502510203 RES.SMD 1K 5% 0603 R621 1502510203 RES.SMD 1K 5% 0603 R622 1502510203 RES.SMD 1K 5% 0603 R623 1502510203 RES.SMD 1K 5% 0603 R629 1502510203 RES.SMD 1K 5% 0603 R634 1502510203 RES.SMD 1K 5% 0603 R636 1502510203 RES.SMD 1K 5% 0603 R637 1502510202 RES.SMD 1K 5% 0805 R209 1502510202 RES.SMD 1K 5% 0805 R210 1502510202 RES.SMD 1K 5% 0805 R607 1502510202 RES.SMD 1K 5% 0805 R608 1502510202 RES.SMD 1K 5% 0805 R609 1502510202 RES.SMD 1K 5% 0805 R614 1502510202 RES.SMD 1K 5% 0805 R615 1502510202 RES.SMD 1K 5% 0805 R620 1502510202 RES.SMD 1K 5% 0805 R621 1502510202 RES.SMD 1K 5% 0805 R622 1502510202 RES.SMD 1K 5% 0805 R623 1502510202 RES.SMD 1K 5% 0805 R629 1502510202 RES.SMD 1K 5% 0805 R634 1502510202 RES.SMD 1K 5% 0805 R636 1502510202 RES.SMD 1K 5% 0805 R637 1502510403 RES.SMD 100K 5% 0603 R317 1502510403 RES.SMD 100K 5% 0603 R318 1502510403 RES.SMD 100K 5% 0603 R502 1502510403 RES.SMD 100K 5% 0603 R839 1502510402 RES.SMD 100K 5% 0805 R317 1502510402 RES.SMD 100K 5% 0805 R318 1502510402 RES.SMD 100K 5% 0805 R502 1502510402 RES.SMD 100K 5% 0805 R839 1502510103 RES.SMD 100R 5% 0603 R430 1502510103 RES.SMD 100R 5% 0603 R431 1502510103 RES.SMD 100R 5% 0603 R805 1502510103 RES.SMD 100R 5% 0603 R829 1502510103 RES.SMD 100R 5% 0603 R830 1502510103 RES.SMD 100R 5% 0603 R831 1502510103 RES.SMD 100R 5% 0603 R832 1502510103 RES.SMD 100R 5% 0603 R834 1502510103 RES.SMD 100R 5% 0603 R835 1502510103 RES.SMD 100R 5% 0603 R836 1502510103 RES.SMD 100R 5% 0603 R837 1502510103 RES.SMD 100R 5% 0603 R838 1502510102 RES.SMD 100R 5% 0805 R430 1502510102 RES.SMD 100R 5% 0805 R431
MD-K400
22
CODE DESCRIPTION POSITION
1502510102 RES.SMD 100R 5% 0805 R805 1502510102 RES.SMD 100R 5% 0805 R829 1502510102 RES.SMD 100R 5% 0805 R830 1502510102 RES.SMD 100R 5% 0805 R831 1502510102 RES.SMD 100R 5% 0805 R832 1502510102 RES.SMD 100R 5% 0805 R834 1502510102 RES.SMD 100R 5% 0805 R835 1502510102 RES.SMD 100R 5% 0805 R836 1502510102 RES.SMD 100R 5% 0805 R837 1502510102 RES.SMD 100R 5% 0805 R838 1502510903 RES.SMD 1,0R 5% 0603 R804 1502510902 RES.SMD 1,0R 5% 0805 R804 1502510403 RES.SMD 100K 5% 0603 R419 1502510403 RES.SMD 100K 5% 0603 R420 1502510402 RES.SMD 100K 5% 0805 R419 1502510402 RES.SMD 100K 5% 0805 R420 1502522103 RES.SMD 220R 5% 0603 R114 1502522103 RES.SMD 220R 5% 0603 R220 1502522103 RES.SMD 220R 5% 0603 R509 1502522103 RES.SMD 220R 5% 0603 R810 1502522103 RES.SMD 220R 5% 0603 R811 1502522103 RES.SMD 220R 5% 0603 R812 1502522103 RES.SMD 220R 5% 0603 R813 1502522103 RES.SMD 220R 5% 0603 R814 1502522103 RES.SMD 220R 5% 0603 R815 1502522103 RES.SMD 220R 5% 0603 R816 1502522103 RES.SMD 220R 5% 0603 R817 1502522103 RES.SMD 220R 5% 0603 R818 1502522103 RES.SMD 220R 5% 0603 R819 1502522103 RES.SMD 220R 5% 0603 R820 1502522103 RES.SMD 220R 5% 0603 R821 1502522103 RES.SMD 220R 5% 0603 R841 1502522103 RES.SMD 220R 5% 0603 R842 1502522103 RES.SMD 220R 5% 0603 R843 1502522102 RES.SMD 220R 5% 0805 R114 1502522102 RES.SMD 220R 5% 0805 R220 1502522102 RES.SMD 220R 5% 0805 R509 1502522102 RES.SMD 220R 5% 0805 R810 1502522102 RES.SMD 220R 5% 0805 R811 1502522102 RES.SMD 220R 5% 0805 R812 1502522102 RES.SMD 220R 5% 0805 R813 1502522102 RES.SMD 220R 5% 0805 R814 1502522102 RES.SMD 220R 5% 0805 R815 1502522102 RES.SMD 220R 5% 0805 R816 1502522102 RES.SMD 220R 5% 0805 R817 1502522102 RES.SMD 220R 5% 0805 R818 1502522102 RES.SMD 220R 5% 0805 R819 1502522102 RES.SMD 220R 5% 0805 R820 1502522102 RES.SMD 220R 5% 0805 R821 1502522102 RES.SMD 220R 5% 0805 R841 1502522102 RES.SMD 220R 5% 0805 R842 1502522102 RES.SMD 220R 5% 0805 R843 1502512403 RES.SMD 120K 5% 0603 R1915
MD-K400
23
CODE DESCRIPTION POSITION
1502512403 RES.SMD 120K 5% 0603 R1916 1502512402 RES.SMD 120K 5% 0805 R1915 1502512402 RES.SMD 120K 5% 0805 R1916 1502515403 RES.SMD 150K 5% 0603 R1917 1502515403 RES.SMD 150K 5% 0603 R1918 1502515402 RES.SMD 150K 5% 0805 R1917 1502515402 RES.SMD 150K 5% 0805 R1918 1502518103 RES.SMD 180R 5% (0603) R606 1502518102 RES.SMD 180R 5% 0805 R606 1502556203 RES.SMD 5,6K 5% 0603 R402 1502556203 RES.SMD 5,6K 5% 0603 R403 1502556202 RES.SMD 5,6K 5% N 0805 R402 1502556202 RES.SMD 5,6K 5% N 0805 R403 1502547203 RES.SMD 4,7K 5% 0603 R1913 1502547203 RES.SMD 4,7K 5% 0603 R1914 1502547203 RES.SMD 4,7K 5% 0603 R850 1502547202 RES.SMD 4,7K 5% 0805 R1913 1502547202 RES.SMD 4,7K 5% 0805 R1914 1502547202 RES.SMD 4,7K 5% 0805 R850 1502547303 RES.SMD 47K 5% 0603 R215 1502547302 RES.SMD 47K 5% 0805 R215 1502533003 RES.SMD 33R 5% 0603 R847 1502533403 RES.SMD 330K 5% 0603 R639 1502533402 RES.SMD 330K 5% 0805 R639 1502522203 RES.SMD 2,2K 5% 0603 R1919 1502522203 RES.SMD 2,2K 5% 0603 R1920 1502522203 RES.SMD 2,2K 5% 0603 R1921 1502522203 RES.SMD 2,2K 5% 0603 R1922 1502522203 RES.SMD 2,2K 5% 0603 R412 1502522203 RES.SMD 2,2K 5% 0603 R413 1502522203 RES.SMD 2,2K 5% 0603 R426 1502522203 RES.SMD 2,2K 5% 0603 R427 1502522203 RES.SMD 2,2K 5% 0603 R806 1502522203 RES.SMD 2,2K 5% 0603 R807 1502522203 RES.SMD 2,2K 5% 0603 R808 1502522202 RES.SMD 2,2K 5% 0805 R1919 1502522202 RES.SMD 2,2K 5% 0805 R1920 1502522202 RES.SMD 2,2K 5% 0805 R1921 1502522202 RES.SMD 2,2K 5% 0805 R1922 1502522202 RES.SMD 2,2K 5% 0805 R412 1502522202 RES.SMD 2,2K 5% 0805 R413 1502522202 RES.SMD 2,2K 5% 0805 R426 1502522202 RES.SMD 2,2K 5% 0805 R427 1502522202 RES.SMD 2,2K 5% 0805 R806 1502522202 RES.SMD 2,2K 5% 0805 R807 1502522202 RES.SMD 2,2K 5% 0805 R808 1502510303 RES.SMD 10K 5% 0603 R213 1502510302 RES.SMD 10K 5% 0805 R213 1502510203 RES.SMD 1K 5% 0603 R635 1502510202 RES.SMD 1K 5% 0805 R635 1502510003 RES.SMD 10R 5% 0603 R612 1502510003 RES.SMD 10R 5% 0603 R613 1502510002 RES.SMD 10R 5% 0805 R612
MD-K400
24
CODE DESCRIPTION POSITION
1502510002 RES.SMD 10R 5% 0805 R613 1502510303 RES.SMD 10K 5% 0603 R107 1502510303 RES.SMD 10K 5% 0603 R113 1502510302 RES.SMD 10K 5% 0805 R107 1502510302 RES.SMD 10K 5% 0805 R113 1502533103 RES.SMD 330R 5% 0603 R111 1502533103 RES.SMD 330R 5% 0603 R1923 1502533103 RES.SMD 330R 5% 0603 R1924 1502533102 RES.SMD 330R 5% 0805 R111 1502533102 RES.SMD 330R 5% 0805 R1923 1502533102 RES.SMD 330R 5% 0805 R1924 1502533203 RES.SMD 3,3K 5% 0603 R110 1502533203 RES.SMD 3,3K 5% 0603 R504 1502533203 RES.SMD 3,3K 5% 0603 R506 1502533202 RES.SMD 3,3K 5% 0805 R110 1502533202 RES.SMD 3,3K 5% 0805 R504 1502533202 RES.SMD 3,3K 5% 0805 R506 1502547203 RES.SMD 4,7K 5% 0603 R108 1502547202 RES.SMD 4,7K 5% 0805 R108 1502582203 RES.SMD 8,2K 5% 0603 R105 1502582202 RES.SMD 8,2K 5% 0805 R105 1502510203 RES.SMD 1K 5% 0603 R106 1502510202 RES.SMD 1K 5% 0805 R106 1502510403 RES.SMD 100K 5% 0603 R102 1502510402 RES.SMD 100K 5% 0805 R102 1502533303 RES.SMD 33K 5% 0603 R101 1502533303 RES.SMD 33K 5% 0603 R103 1502533303 RES.SMD 33K 5% 0603 R104 1502533302 RES.SMD 33K 5% 0805 R101 1502533302 RES.SMD 33K 5% 0805 R103 1502533302 RES.SMD 33K 5% 0805 R104 1502568103 RES.SMD 680R 5% 0603 R112 1502568103 RES.SMD 680R 5% 0603 R1907 1502568102 RES.SMD 680R 5% 0805 R112 1502568102 RES.SMD 680R 5% 0805 R1907 1183522292 RES.METAL FILME 1/2W 2,2K 5% N R501 1502527203 RES.SMD 2,7K 5% 0603 R203 1502527203 RES.SMD 2,7K 5% 0603 R204 1502527202 RES.SMD 2,7K 5% 0805 R203 1502527202 RES.SMD 2,7K 5% 0805 R204 1502547103 RES.SMD 470R 5% 0603 R205 1502547103 RES.SMD 470R 5% 0603 R206 1502500003 RES.SMD 0R 5% 0603 R515 1502500002 RES.SMD 0R 5% 0805 R515 1502510303 RES.SMD 10K 5% 0603 R115 1502510303 RES.SMD 10K 5% 0603 R116 1502510302 RES.SMD 10K 5% 0805 R115 1502510302 RES.SMD 10K 5% 0805 R116 1502500003 RES.SMD 0R 5% 0603 J1 1502500003 RES.SMD 0R 5% 0603 J101 1502500003 RES.SMD 0R 5% 0603 J1901 1502500003 RES.SMD 0R 5% 0603 J1902 1502500003 RES.SMD 0R 5% 0603 J801
MD-K400
25
CODE DESCRIPTION POSITION
1502500003 RES.SMD 0R 5% 0603 J802 1502500003 RES.SMD 0R 5% 0603 J803 1502500003 RES.SMD 0R 5% 0603 J804 1502500003 RES.SMD 0R 5% 0603 J805 1502500003 RES.SMD 0R 5% 0603 R507 1502500003 RES.SMD 0R 5% 0603 R611 1502500002 RES.SMD 0R 5% 0805 J1 1502500002 RES.SMD 0R 5% 0805 J101 1502500002 RES.SMD 0R 5% 0805 J1901 1502500002 RES.SMD 0R 5% 0805 J1902 1502500002 RES.SMD 0R 5% 0805 J801 1502500002 RES.SMD 0R 5% 0805 J802 1502500002 RES.SMD 0R 5% 0805 J803 1502500002 RES.SMD 0R 5% 0805 J804 1502500002 RES.SMD 0R 5% 0805 J805 1502500002 RES.SMD 0R 5% 0805 R507 1502500002 RES.SMD 0R 5% 0805 R611 1502547303 RES.SMD 47K 5% 0603 R421 1502547303 RES.SMD 47K 5% 0603 R422 1502547302 RES.SMD 47K 5% 0805 R421 1502547302 RES.SMD 47K 5% 0805 R422 1502533303 RES.SMD 33K 5% 0603 R423 1502533303 RES.SMD 33K 5% 0603 R424 1502533302 RES.SMD 33K 5% 0805 R423 1502533302 RES.SMD 33K 5% 0805 R424 1502522203 RES.SMD 2,2K 5% 0603 R428 1502522203 RES.SMD 2,2K 5% 0603 R429 1502522202 RES.SMD 2,2K 5% 0805 R428 1502522202 RES.SMD 2,2K 5% 0805 R429 1185522925 RES.M.FILME 1W 2,2R 5% D.KINK R530 1185522925 RES.M.FILME 1W 2,2R 5% D.KINK R531 1184522945 RES.M.FILME 2W 2,2R 5% N MG R530 1184522945 RES.M.FILME 2W 2,2R 5% N MG R531 1184522940 RES.METAL FILME 2W 2,2R 5% N R530 1184522940 RES.METAL FILME 2W 2,2R 5% N R531
SEMICONDUCTORS
CODE DESCRIPTION POSITION
1700100011 TRANSISTOR SMD BC856B Q203 1320091000 TRANSISTOR BC337/25 Q501 1320030102 TRANSISTOR BC337/16 Q501 1320030102 TRANSISTOR BC337/16 Q501 1700100015 TRANSISTOR SMD BC846B Q1905 1700100015 TRANSISTOR SMD BC846B Q1907 1700100015 TRANSISTOR SMD BC846B Q1908 1700100015 TRANSISTOR SMD BC846B Q1911 1700100015 TRANSISTOR SMD BC846B Q1912 1700100015 TRANSISTOR SMD BC846B Q201 1700100015 TRANSISTOR SMD BC846B Q202 1700100015 TRANSISTOR SMD BC846B Q204 1700100015 TRANSISTOR SMD BC846B Q301 1700100015 TRANSISTOR SMD BC846B Q601 1700100015 TRANSISTOR SMD BC846B Q602
MD-K400
26
CODE DESCRIPTION POSITION
1320030403 TRANSISTOR BC327/25 Q1903 1320030403 TRANSISTOR BC327/25 Q1909 1320030403 TRANSISTOR BC327/25 Q1910 1320030403 TRANSISTOR BC327/25 Q502 1700100015 TRANSISTOR SMD BC846B Q101 1700100003 TRANSISTOR SMD BC847B Q101 1700100015 TRANSISTOR SMD BC846B Q101 1700100015 TRANSISTOR SMD BC846B Q102 1414621902 DIODO 1N4148 75V SINAL D510 1414621902 DIODO 1N4148 75V SINAL D511 1415170601 DIODO ZENER BZX79C24V D506 1415168901 DIODO ZENER BZX79C3V3 D601 1550100010 DIODO SMD BZV55-F3V3 D601 1412004302 DIODO ZENER 1N5226B 3,3V D601 1415169901 DIODO ZENER BZX79C10V D507 1550100002 DIODO SMD BZV55F10 D507 1415168901 DIODO ZENER BZX79C3V3 D105 1415169501 DIODO ZENER BZX79C5V6 D104 1412064302 DIODO ZENER 1N5232B 5,6V D104 1550100055 DIODO VARICAP SMD SVC383S D101 1414621902 DIODO 1N4148 75V SINAL D508 1414621902 DIODO 1N4148 75V SINAL D509 1414621902 DIODO 1N4148 75V SINAL D515 1414621902 DIODO 1N4148 75V SINAL D801 1414621902 DIODO 1N4148 75V SINAL D802 1414621902 DIODO 1N4148 75V SINAL D803 1415180901 DIODO RETIFICADOR SK107 D1902 1415180901 DIODO RETIFICADOR SK107 D1903 1415180901 DIODO RETIFICADOR SK107 D501 1415180901 DIODO RETIFICADOR SK107 D502 1415180901 DIODO RETIFICADOR SK107 D503 1415180901 DIODO RETIFICADOR SK107 D504 1415180901 DIODO RETIFICADOR SK107 D505 1410430015 DIODO RETIFICADOR 1N4004 D1902 1410430015 DIODO RETIFICADOR 1N4004 D1903 1410430015 DIODO RETIFICADOR 1N4004 D501 1410430015 DIODO RETIFICADOR 1N4004 D502 1410430015 DIODO RETIFICADOR 1N4004 D503 1410430015 DIODO RETIFICADOR 1N4004 D504 1410430015 DIODO RETIFICADOR 1N4004 D505 1415172201 DIODO UF-4004 D1902 1415172201 DIODO UF-4004 D1903 1415172201 DIODO UF-4004 D501 1415172201 DIODO UF-4004 D502 1415172201 DIODO UF-4004 D503 1415172201 DIODO UF-4004 D504 1415172201 DIODO UF-4004 D505 1410430015 DIODO RETIFICADOR 1N4004 D1902 1410430015 DIODO RETIFICADOR 1N4004 D1903 1410430015 DIODO RETIFICADOR 1N4004 D501 1410430015 DIODO RETIFICADOR 1N4004 D502 1410430015 DIODO RETIFICADOR 1N4004 D503 1410430015 DIODO RETIFICADOR 1N4004 D504
MD-K400
27
CODE DESCRIPTION POSITION
1410430015 DIODO RETIFICADOR 1N4004 D505 1459523500 DIODO LED VD 5MM LTL-307GW D805 1459523500 DIODO LED VD 5MM LTL-307GW D806 1459523500 DIODO LED VD 5MM LTL-307GW D807 1459521500 DIODO LED VD SLR-342MG3F D805 1459521500 DIODO LED VD SLR-342MG3F D806 1459521500 DIODO LED VD SLR-342MG3F D807 1124508900 DIODO GT-202/PS-201 D202 1124508900 DIODO GT-202/PS-201 D203 1124508900 DIODO GT-202/PS-201 D204 1124508900 DIODO GT-202/PS-201 D205 1122503600 DIODO VARICAP SVC201SPA D102 1122503600 DIODO VARICAP SVC201SPA D103 1710100200 I.C. SMD PT6318 IC801 1710100065 I.C. SMD PT-2314 IC401 1711100150 I.C. GRAVADO 1711100000 (V1.0) IC601 1711100050 IC.SOFT V1.0(MC908GP32CFBR2/1) 1711100000 I.C. OTP MC68HC908GP32CFBR2/1 1710100213 I.C. SMD LV23002M IC101 1710100141 I.C. SMD LV23000M IC101 1149341399 I.C. LA4282 IC201 1149376899 I.C. 7805 (PLASTICO) IC502 1149376899 I.C. 7805 (PLASTICO) IC501 1149399999 I.C. REGULADOR 12V KA78R12STU IC503
MISCELLANEOUS
CODE DESCRIPTION POSITION
1025228004 PCI LAT/FRONT/RAD MAN/MONT 1025228014 PCI LAT/FRONT/RAD IA/SMD 1105228002 PCI CONJUNTO 1449010300 CHAVE TOQUE 4,3MM 260GF SW801 1449010300 CHAVE TOQUE 4,3MM 260GF SW802 1449010300 CHAVE TOQUE 4,3MM 260GF SW803 1449010300 CHAVE TOQUE 4,3MM 260GF SW804 1449010300 CHAVE TOQUE 4,3MM 260GF SW805 1449010300 CHAVE TOQUE 4,3MM 260GF SW806 1449010300 CHAVE TOQUE 4,3MM 260GF SW807 1449010300 CHAVE TOQUE 4,3MM 260GF SW808 1449010300 CHAVE TOQUE 4,3MM 260GF SW809 1449010300 CHAVE TOQUE 4,3MM 260GF SW810 1449010300 CHAVE TOQUE 4,3MM 260GF SW811 1449010300 CHAVE TOQUE 4,3MM 260GF SW812 1449010300 CHAVE TOQUE 4,3MM 260GF SW813 1449010300 CHAVE TOQUE 4,3MM 260GF SW814 1449010300 CHAVE TOQUE 4,3MM 260GF SW815 1449009600 CHAVE DE TOQUE 4,3MM 260g SW801 1449009600 CHAVE DE TOQUE 4,3MM 260g SW802 1449009600 CHAVE DE TOQUE 4,3MM 260g SW803 1449009600 CHAVE DE TOQUE 4,3MM 260g SW804 1449009600 CHAVE DE TOQUE 4,3MM 260g SW805 1449009600 CHAVE DE TOQUE 4,3MM 260g SW806 1449009600 CHAVE DE TOQUE 4,3MM 260g SW807 1449009600 CHAVE DE TOQUE 4,3MM 260g SW808
MD-K400
28
CODE DESCRIPTION POSITION
1449009600 CHAVE DE TOQUE 4,3MM 260g SW809 1449009600 CHAVE DE TOQUE 4,3MM 260g SW810 1449009600 CHAVE DE TOQUE 4,3MM 260g SW811 1449009600 CHAVE DE TOQUE 4,3MM 260g SW812 1449009600 CHAVE DE TOQUE 4,3MM 260g SW813 1449009600 CHAVE DE TOQUE 4,3MM 260g SW814 1449009600 CHAVE DE TOQUE 4,3MM 260g SW815 1479910534 INDUTOR 100UH K AXIAL L801 1479910565 INDUTOR FIXO 100UH 26MM L801 1479910565 INDUTOR FIXO 100UH 26MM L801 1479910534 INDUTOR 100UH K AXIAL L801 1633207400 CJT. TOMADA DO FALANTE CN201 1425011400 CRISTAL 32,768KHZ X601 1442903023 ENCODER ROTATIVO C/PORCA E801 1271206100 RECPETOR IR 36KHZ TSOP34836 IR801 1271205900 RECEPTO IR 36KHZ TSOP1836SS3V3 IR801 1271206300 RECEPTOR IR 36KHZ KSM-602LM2D IR801 1271205100 RECEPTOR IR 90º(36KHZ) IR801 1271205200 RECEPTOR IR 180º 36KHZ IR801 1271205700 RECEPTOR IR 36KHZ TSOP4836 IR801 1639504900 TOMADA 2RCA VT VM/BR CN401 1647682200 CJT.CHICOTE 26AWG 13V 470MM CN602 P/CN701 1633220000 JACK FONE MINIATURA (MONO) CNTP9 1461051202 FUS.ACAO RET.20AG 0,5A/250V FS501 1461052002 FUS. ACAO RET. 20AG 1A/250V FS502 1637615640 GARRA P/FUSIVEL 1442903022 CHAVE DESLIZANTE 2PLX2PS 90 SW501 1647680800 CJT.CHICOTE 24AWG 6V 220MM CN1904/MECHA DEC 1425010700 CRISTAL 75.000KHZ CL=12.5PF X101 1421507000 DISCRIM.CERAM.CDA10.7MG46-A CF104 1421505400 DISCR.CER.CDA10.7-MG40 CF104 1421507900 FILTRO CERAMICO 10.7MA5 CF103 1421101434 FILTRO CERAMICO 450B CF102 1421505600 FILTRO CERAMICO SFZ-450HL CF102 1319959500 BOBINA OSC AM T101 1319959600 BOBINA FI AM T104 1319959700 BOBINA ANTENA AM FERRITE T102 1421508400 FILTRO CERAMICO BPF GFMB5-T CF101 1633214300 TERMINAL ANTENA 02V PR CN101 1311503000 BOBINA NUCLEO AR 4-3,5-22 L102 1311501200 BOBINA NUCLEO AR 4,0-4,5-20 L101 1647680900 CJT.CHICOTE 24AWG 6V 360MM CN1903/MECHA DEC 1631281411 GUIA P/FIOS 11VIAS CN601 1631281211 GUIA FIOS 11V CN601 1631281211 GUIA FIOS 11V CN601 1631281402 GUIA P/FIOS 02VIAS CN906 1404006200 DISPLAY VFD VFD801 1725222304 SUPORTE DO TRAFO 14(E9) 1600016120 PAR.AA.P.PH.BEMLI3,0X10ZNA RES 13(2C8) 1655225001 DISSIPADOR POTENCIA 15(E9) 1600015120 PAR.AA.P.PH.PP1 3,0X10 ZNA RES 6(2F8) 1600007107 PAR.AA.PAN.PH.BEMLI3,0X8 ZNA 16(2F8) 1600007107 PAR.AA.PAN.PH.BEMLI3,0X8 ZNA 16(F7)
MD-K400
29
CODE DESCRIPTION POSITION
1725225001 APOIO DO IC 28(E7) 1600007107 PAR.AA.PAN.PH.BEMLI3,0X8 ZNA 16(E7) 1657200402 DISSIPADOR B 23(F7) 1777229704 ESPACADOR DISPLAY 1775214711 CALCO 1525228401 MEC.CD3 PHONIC PORT MONT 1644507400 CABO DE FORCA 2X18X2 C/CONECT. AC 1644502000 CABO FORCA 2X18X2P.CH.DP IS.BI 1345228001 TRAFO DE FORCA TF501 1644507100 ANTENA FM TIPO T 2,3MT 1068130005 ETIQ.NUMERO DE SERIE - DL 1067223803 ETIQ.ALERTA CABO DE FORCA 1055228005 CAIXA DE EMBALAGEM 1677241113 EMBLEMA DURABRAND 1065228002 ETIQ.PROMOCIONAL B 1065228001 ETIQ.PROMOCIONAL A 1675228002 CONJUNTO PAINEL FRONTAL 1(H4) 1575228008 TAMPA DO CD 5(F2) 1675225020 KNOB VOLUME 4(H2) 1575228009 TAMPA TRASEIRA 21(D11) 1575220103 LATERAL DIREITA 25(E11) 1575220104 LATERAL ESQUERDA 26(A4) 1775217202 TAMPA SUPERIOR 27(A8) 1685228003 MOLA DA TAMPA CASSETE-A 6(G5) 1685228004 MOLA TAMPA CASSETE-B 7(G4) 1775211311 SUPORTE ENGR.AMORTECEDORA 2(2G4) 1665211302 ENGRENAGEM AMORTECEDORA 3(2G4) 1775225108 ESPACADOR 1600005107 PAR.AA.PAN.PH.PP1 3,0X8 ZNA 6(6F6) 1695221302 CHASSI 10(F7) 1767203701 PRENSA CABO 12(F7) 1775221207 PE DE SUSTENTACAO 11(4H7) 1600005120 PAR.AA.PAN.PH.PP1 3,0X10 ZNA 9(2H6) 1600016120 PAR.AA.P.PH.BEMLI3,0X10ZNA RES 13(B9) 1600016120 PAR.AA.P.PH.BEMLI3,0X10ZNA RES 13(2D7) 1600016120 PAR.AA.P.PH.BEMLI3,0X10ZNA RES 13(2H6) 1600005120 PAR.AA.PAN.PH.PP1 3,0X10 ZNA 9(9C7) 1600015508 PAR.AA.P.PH.PP1 3,0X12 ZNP RES 24(2F2) 1600015509 PAR.AA.P.PH.PP1 3,0X15 ZNP RES 29(2A10) 1600015507 PAR.AA.P.PH.PP1 3,0X8 ZNP RES 30(2A10) 1600015520 PAR.AA.P.PH.PP1 3,0X10 ZNP RES 22(2B2) 1600015520 PAR.AA.P.PH.PP1 3,0X10 ZNP RES 22(4C11) 1600015520 PAR.AA.P.PH.PP1 3,0X10 ZNP RES 22(2G10) 1600015520 PAR.AA.P.PH.PP1 3,0X10 ZNP RES 22(2A2.2F10) 1600015520 PAR.AA.P.PH.PP1 3,0X10 ZNP RES 22(2B10) 1600015520 PAR.AA.P.PH.PP1 3,0X10 ZNP RES 22(C10)FX.TOM.AU 1769900121 SACO PLASTICO 650X750X0,04 BD 1584223401 CAIXA ACUSTICA D/E CL-K400MD 1584215006 CINTA P/CAIXA ACUSTICA 1876316300 ADESIVO DE BORRACHA PT 1644511900 CABO PAR.POL.22AWG 1500MM 2TER 2(C7) 1876311800 ADESIVO HOT MELT 1876304100 ADESIVO JET MELT
MD-K400
30
CODE DESCRIPTION POSITION
1584215011 BAFLE 4(C5) 1584215304 TAMPA TRASEIRA 6(A6) 1584218002 TAMPA TRASEIRA CX.ACUSTICA 6(A6) 1584218001 PAINEL FRONTAL CX.ACUSTICA 3(E5) 1510956041 ALTO FALANTE 412WFPS/60D-DF 5(D3) 1510956054 ALTO FALANTE 412WFPS/60D-DFB 5(D3) 1584208813 VEDACAO FRONTAL B 10(6B4) 1876307460 ADESIVO PVA 045 1600015509 PAR.AA.P.PH.PP1 3,0X15 ZNP RES 7(2E2) 1584215005 TELA DO FALANTE 8(E1) 1876315600 ADESIVO PVA 450 BAR 50(V450B2) 1677241113 EMBLEMA DURABRAND 11(D3) 1769900123 SACO PLASTICO 500X600X0,05 AD 1769900006 SACO PLASTICO 50X60X0,05 1889323000 FITA A.PP.BASE BORR.SINTET.MR 1889300500 FITA DUREX L= 12,0MM 1065229803 ETIQ.DE IMPEDANCIA CX.ACUSTICA 1065224210 ETIQUETA DE IMPEDANCIA 1065228014 MANUAL DE INSTRUCOES MD-K400 1065228008 ETIQUETA FUNCOES 1055225099 CJT.CALCO PROTETOR INF/SUP 1769900122 SACO PLATICO 250X400X0,05 AD 1775224305 PE DE BORRACHA 10X10X1 1761602600 FIXADOR DE FIOS 101mm 1633211202 BASE CONECTORA 2VIAS PITCH 7,5 1065228013 ETIQ.IDENTIFICAÇÃO 1065230003 ETIQ.ALERTA DE VOLTAGEM 1065228015 ETIQ.IMPORTADOR 1067301907 ETIQ.A.ADES.PIMACO A4364 1880500900 SOLDA TRIFLUXO 60X40X1,5MM 1880500100 SOLDA TRIFLUXO 60 X 40 X 1.
DECK PCB
CAPACITORS
CODE DESCRIPTION POSITION
1380109622 ELCO 1UF/100V M 5x11mm C920 1380109622 ELCO 1UF/100V M 5x11mm C921 1040330023 ELCO 1UF/50V M C920 1040330023 ELCO 1UF/50V M C921 1040330037 ELCO 1UF/50V M C920 1040330037 ELCO 1UF/50V M C921 1040370015 ELCO 1UF/50V M C920 1040370015 ELCO 1UF/50V M C921 1040640432 CAP.ELCO 1UF/50V C920 1040640432 CAP.ELCO 1UF/50V C921 1040850098 CAP.ELCO 1UF/50V C920 1040850098 CAP.ELCO 1UF/50V C921 1491082004 CAP.SMD NP0 82PF/50V J 0603 C928 1491082004 CAP.SMD NP0 82PF/50V J 0603 C929 1492010200 CAP.SMD X7R 1KPF/50V K 0603 C915 1492010200 CAP.SMD X7R 1KPF/50V K 0603 C916 1492010300 CAP.SMD X7R 10KPF/50V K 0603 C914 1492010300 CAP.SMD X7R 10KPF/50V K 0603 C941
MD-K400
31
CODE DESCRIPTION POSITION
1492012300 CAP.SMD X7R 12KPF/25V K 0603 C924 1492012300 CAP.SMD X7R 12KPF/25V K 0603 C925 1492010300 CAP.SMD X7R 10KPF/50V K 0603 C924 1492010300 CAP.SMD X7R 10KPF/50V K 0603 C925 1492022300 CAP.SMD X7R 22KPF/25V K 0603 C907 1492022300 CAP.SMD X7R 22KPF/25V K 0603 C945 1492027200 CAP.SMD X7R 2,7KPF/50V K 0603 C942 1492027200 CAP.SMD X7R 2,7KPF/50V K 0603 C943 1492027200 CAP.SMD X7R 2,7KPF/50V K 0603 C944 1492047100 CAP.SMD X7R 470PF/50V K 0603 C930 1492047100 CAP.SMD X7R 470PF/50V K 0603 C931 1492068200 CAP.SMD X7R 6,8KPF/50V K 0603 C926 1492068200 CAP.SMD X7R 6,8KPF/50V K 0603 C927 1492082200 CAP.SMD X7R 8,2KPF/50V K 0603 C903 1492082200 CAP.SMD X7R 8,2KPF/50V K 0603 C904 1492082200 CAP.SMD X7R 8,2KPF/50V K 0603 C910 1492082200 CAP.SMD X7R 8,2KPF/50V K 0603 C911 1493010405 CAP.SMD Y5V 100KPF/25V Z 0603 C917 1493010405 CAP.SMD Y5V 100KPF/25V Z 0603 C940 1493010405 CAP.SMD Y5V 100KPF/25V Z 0603 C953 1493010405 CAP.SMD Y5V 100KPF/25V Z 0603 C954 1492018200 CAP.SMD X7R 1,8KPF/50V K 0603 C901 1492018200 CAP.SMD X7R 1,8KPF/50V K 0603 C902 1492018200 CAP.SMD X7R 1,8KPF/50V K 0603 C908 1492018200 CAP.SMD X7R 1,8KPF/50V K 0603 C909 1380101224 ELCO 100UF/16V M 5X11MM C905 1380101224 ELCO 100UF/16V M 5X11MM C906 1380101224 ELCO 100UF/16V M 5X11MM C918 1380101224 ELCO 100UF/16V M 5X11MM C919 1380101228 ELCO 100UF/16V M 6,3x11MM C905 1380101228 ELCO 100UF/16V M 6,3x11MM C906 1380101228 ELCO 100UF/16V M 6,3x11MM C918 1380101228 ELCO 100UF/16V M 6,3x11MM C919 1380101924 ELCO 100UF/10V M 5X11MM C905 1380101924 ELCO 100UF/10V M 5X11MM C906 1380101924 ELCO 100UF/10V M 5X11MM C918 1380101924 ELCO 100UF/10V M 5X11MM C919 1380221928 ELCO 220UF/10V M 6,3X11MM C934 1040040035 CAP. ELCO 330UF/10V M SME C934 1040330083 ELCO 220UF/10V M C934 1040640429 CAP.ELCO 220UF/10V C934 1492022200 CAP.SMD X7R 2,2KPF/50V K 0603 C922 1492022200 CAP.SMD X7R 2,2KPF/50V K 0603 C923 1330332100 MYLLARCAP 3,3KPF/63V K C933 1380109622 ELCO 1UF/100V M 5x11mm C920 1380109622 ELCO 1UF/100V M 5x11mm C921 1491082004 CAP.SMD NP0 82PF/50V J 0603 C928 1491082004 CAP.SMD NP0 82PF/50V J 0603 C929 1492010200 CAP.SMD X7R 1KPF/50V K 0603 C915 1492010200 CAP.SMD X7R 1KPF/50V K 0603 C916 1492010300 CAP.SMD X7R 10KPF/50V K 0603 C914 1492010300 CAP.SMD X7R 10KPF/50V K 0603 C941 1492012300 CAP.SMD X7R 12KPF/25V K 0603 C924
MD-K400
32
CODE DESCRIPTION POSITION
1492012300 CAP.SMD X7R 12KPF/25V K 0603 C925 1492010300 CAP.SMD X7R 10KPF/50V K 0603 C924 1492010300 CAP.SMD X7R 10KPF/50V K 0603 C925 1492022300 CAP.SMD X7R 22KPF/25V K 0603 C907 1492022300 CAP.SMD X7R 22KPF/25V K 0603 C945 1492027200 CAP.SMD X7R 2,7KPF/50V K 0603 C942 1492027200 CAP.SMD X7R 2,7KPF/50V K 0603 C943 1492027200 CAP.SMD X7R 2,7KPF/50V K 0603 C944 1492047100 CAP.SMD X7R 470PF/50V K 0603 C930 1492047100 CAP.SMD X7R 470PF/50V K 0603 C931 1492068200 CAP.SMD X7R 6,8KPF/50V K 0603 C926 1492068200 CAP.SMD X7R 6,8KPF/50V K 0603 C927 1492082200 CAP.SMD X7R 8,2KPF/50V K 0603 C903 1492082200 CAP.SMD X7R 8,2KPF/50V K 0603 C904 1492082200 CAP.SMD X7R 8,2KPF/50V K 0603 C910 1492082200 CAP.SMD X7R 8,2KPF/50V K 0603 C911 1493010405 CAP.SMD Y5V 100KPF/25V Z 0603 C917 1493010405 CAP.SMD Y5V 100KPF/25V Z 0603 C940 1493010405 CAP.SMD Y5V 100KPF/25V Z 0603 C953 1493010405 CAP.SMD Y5V 100KPF/25V Z 0603 C954 1492018200 CAP.SMD X7R 1,8KPF/50V K 0603 C901 1492018200 CAP.SMD X7R 1,8KPF/50V K 0603 C902 1492018200 CAP.SMD X7R 1,8KPF/50V K 0603 C908 1492018200 CAP.SMD X7R 1,8KPF/50V K 0603 C909 1380101224 ELCO 100UF/16V M 5X11MM C905 1380101224 ELCO 100UF/16V M 5X11MM C906 1380101224 ELCO 100UF/16V M 5X11MM C918 1380101224 ELCO 100UF/16V M 5X11MM C919 1380101228 ELCO 100UF/16V M 6,3x11MM C905 1380101228 ELCO 100UF/16V M 6,3x11MM C906 1380101228 ELCO 100UF/16V M 6,3x11MM C918 1380101228 ELCO 100UF/16V M 6,3x11MM C919 1380101924 ELCO 100UF/10V M 5X11MM C905 1380101924 ELCO 100UF/10V M 5X11MM C906 1380101924 ELCO 100UF/10V M 5X11MM C918 1380101924 ELCO 100UF/10V M 5X11MM C919 1380221928 ELCO 220UF/10V M 6,3X11MM C934 1492022200 CAP.SMD X7R 2,2KPF/50V K 0603 C922 1492022200 CAP.SMD X7R 2,2KPF/50V K 0603 C923 1330332100 MYLLARCAP 3,3KPF/63V K C933
RESISTORS
CODE DESCRIPTION POSITION
1502510003 RES.SMD 10R 5% 0603 R915 1502510003 RES.SMD 10R 5% 0603 R916 1502510203 RES.SMD 1K 5% 0603 R939 1502510203 RES.SMD 1K 5% 0603 R959 1502510203 RES.SMD 1K 5% 0603 R960 1502510203 RES.SMD 1K 5% 0603 R982 1502510203 RES.SMD 1K 5% 0603 R983 1502510203 RES.SMD 1K 5% 0603 R986 1502510203 RES.SMD 1K 5% 0603 R987 1502510303 RES.SMD 10K 5% 0603 R919
MD-K400
33
CODE DESCRIPTION POSITION
1502510303 RES.SMD 10K 5% 0603 R921 1502510303 RES.SMD 10K 5% 0603 R922 1502510303 RES.SMD 10K 5% 0603 R923 1502510303 RES.SMD 10K 5% 0603 R963 1502510303 RES.SMD 10K 5% 0603 R974 1502510303 RES.SMD 10K 5% 0603 R975 1502510303 RES.SMD 10K 5% 0603 R994 1502510403 RES.SMD 100K 5% 0603 R961 1502510403 RES.SMD 100K 5% 0603 R962 1502510903 RES.SMD 1,0R 5% 0603 R940 1502512203 RES.SMD 1,2K 5% 0603 R903 1502512203 RES.SMD 1,2K 5% 0603 R904 1502512203 RES.SMD 1,2K 5% 0603 R926 1502512203 RES.SMD 1,2K 5% 0603 R927 1502512203 RES.SMD 1,2K 5% 0603 R988 1502512203 RES.SMD 1,2K 5% 0603 R989 1502518303 RES.SMD 18K 5% 0603 R905 1502518303 RES.SMD 18K 5% 0603 R906 1502518303 RES.SMD 18K 5% 0603 R928 1502518303 RES.SMD 18K 5% 0603 R929 1502518303 RES.SMD 18K 5% 0603 R936 1502518303 RES.SMD 18K 5% 0603 R937 1502518303 RES.SMD 18K 5% 0603 R968 1502518303 RES.SMD 18K 5% 0603 R969 1502522203 RES.SMD 2,2K 5% 0603 R972 1502522203 RES.SMD 2,2K 5% 0603 R973 1502522203 RES.SMD 2,2K 5% 0603 R976 1502522203 RES.SMD 2,2K 5% 0603 R979 1502522303 RES.SMD 22K 5% 0603 R942 1502522303 RES.SMD 22K 5% 0603 R965 1502522303 RES.SMD 22K 5% 0603 R970 1502522303 RES.SMD 22K 5% 0603 R971 1502533403 RES.SMD 330K 5% 0603 R901 1502533403 RES.SMD 330K 5% 0603 R902 1502533403 RES.SMD 330K 5% 0603 R924 1502533403 RES.SMD 330K 5% 0603 R925 1502539003 RES.SMD 39R 5% 0603 R911 1502539003 RES.SMD 39R 5% 0603 R912 1502539003 RES.SMD 39R 5% 0603 R933 1502539003 RES.SMD 39R 5% 0603 R941 1502539403 RES.SMD 390K 5% 0603 R909 1502539403 RES.SMD 390K 5% 0603 R910 1502539403 RES.SMD 390K 5% 0603 R930 1502539403 RES.SMD 390K 5% 0603 R931 1502547003 RES.SMD 47R 5% 0603 R913 1502547003 RES.SMD 47R 5% 0603 R914 1502547003 RES.SMD 47R 5% 0603 R932 1502547003 RES.SMD 47R 5% 0603 R935 1502547103 RES.SMD 470R 5% 0603 R917 1502547103 RES.SMD 470R 5% 0603 R918 1502547103 RES.SMD 470R 5% 0603 R966 1502547103 RES.SMD 470R 5% 0603 R967 1502547203 RES.SMD 4,7K 5% 0603 R907
MD-K400
34
CODE DESCRIPTION POSITION
1502547203 RES.SMD 4,7K 5% 0603 R908 1502547303 RES.SMD 47K 5% 0603 R920 1502547303 RES.SMD 47K 5% 0603 R943 1502547303 RES.SMD 47K 5% 0603 R946 1502547303 RES.SMD 47K 5% 0603 R947 1502547303 RES.SMD 47K 5% 0603 R948 1502547303 RES.SMD 47K 5% 0603 R949 1502547303 RES.SMD 47K 5% 0603 R954 1502547303 RES.SMD 47K 5% 0603 R964 1502547303 RES.SMD 47K 5% 0603 R977 1502547303 RES.SMD 47K 5% 0603 R978 1502556303 RES.SMD 56K 5% 0603 R990 1502556303 RES.SMD 56K 5% 0603 R991 1502568203 RES.SMD 6,8K 5% 0603 R980 1502568203 RES.SMD 6,8K 5% 0603 R981 1502582903 RES.SMD 8,2R 5% 0603 R934 1502500003 RES.SMD 0R 5% 0603 J901 1502500003 RES.SMD 0R 5% 0603 J902 1502568103 RES.SMD 680R 5% 0603 R984 1502568103 RES.SMD 680R 5% 0603 R985 1502582203 RES.SMD 8,2K 5% 0603 R992 1502582203 RES.SMD 8,2K 5% 0603 R993 1502510003 RES.SMD 10R 5% 0603 R915 1502510003 RES.SMD 10R 5% 0603 R916 1502510203 RES.SMD 1K 5% 0603 R939 1502510203 RES.SMD 1K 5% 0603 R959 1502510203 RES.SMD 1K 5% 0603 R960 1502510203 RES.SMD 1K 5% 0603 R982 1502510203 RES.SMD 1K 5% 0603 R983 1502510203 RES.SMD 1K 5% 0603 R986 1502510203 RES.SMD 1K 5% 0603 R987 1502510303 RES.SMD 10K 5% 0603 R919 1502510303 RES.SMD 10K 5% 0603 R921 1502510303 RES.SMD 10K 5% 0603 R922 1502510303 RES.SMD 10K 5% 0603 R923 1502510303 RES.SMD 10K 5% 0603 R963 1502510303 RES.SMD 10K 5% 0603 R974 1502510303 RES.SMD 10K 5% 0603 R975 1502510303 RES.SMD 10K 5% 0603 R994 1502510403 RES.SMD 100K 5% 0603 R961 1502510403 RES.SMD 100K 5% 0603 R962 1502510903 RES.SMD 1,0R 5% 0603 R940 1502512203 RES.SMD 1,2K 5% 0603 R903 1502512203 RES.SMD 1,2K 5% 0603 R904 1502512203 RES.SMD 1,2K 5% 0603 R926 1502512203 RES.SMD 1,2K 5% 0603 R927 1502512203 RES.SMD 1,2K 5% 0603 R988 1502512203 RES.SMD 1,2K 5% 0603 R989 1502518303 RES.SMD 18K 5% 0603 R905 1502518303 RES.SMD 18K 5% 0603 R906 1502518303 RES.SMD 18K 5% 0603 R928 1502518303 RES.SMD 18K 5% 0603 R929 1502518303 RES.SMD 18K 5% 0603 R936
MD-K400
35
CODE DESCRIPTION POSITION
1502518303 RES.SMD 18K 5% 0603 R937 1502518303 RES.SMD 18K 5% 0603 R968 1502518303 RES.SMD 18K 5% 0603 R969 1502522203 RES.SMD 2,2K 5% 0603 R972 1502522203 RES.SMD 2,2K 5% 0603 R973 1502522203 RES.SMD 2,2K 5% 0603 R976 1502522203 RES.SMD 2,2K 5% 0603 R979 1502522303 RES.SMD 22K 5% 0603 R942 1502522303 RES.SMD 22K 5% 0603 R965 1502522303 RES.SMD 22K 5% 0603 R970 1502522303 RES.SMD 22K 5% 0603 R971 1502533403 RES.SMD 330K 5% 0603 R901 1502533403 RES.SMD 330K 5% 0603 R902 1502533403 RES.SMD 330K 5% 0603 R924 1502533403 RES.SMD 330K 5% 0603 R925 1502539003 RES.SMD 39R 5% 0603 R911 1502539003 RES.SMD 39R 5% 0603 R912 1502539003 RES.SMD 39R 5% 0603 R933 1502539003 RES.SMD 39R 5% 0603 R941 1502539403 RES.SMD 390K 5% 0603 R909 1502539403 RES.SMD 390K 5% 0603 R910 1502539403 RES.SMD 390K 5% 0603 R930 1502539403 RES.SMD 390K 5% 0603 R931 1502547003 RES.SMD 47R 5% 0603 R913 1502547003 RES.SMD 47R 5% 0603 R914 1502547003 RES.SMD 47R 5% 0603 R932 1502547003 RES.SMD 47R 5% 0603 R935 1502547103 RES.SMD 470R 5% 0603 R917 1502547103 RES.SMD 470R 5% 0603 R918 1502547103 RES.SMD 470R 5% 0603 R966 1502547103 RES.SMD 470R 5% 0603 R967 1502547203 RES.SMD 4,7K 5% 0603 R907 1502547203 RES.SMD 4,7K 5% 0603 R908 1502547303 RES.SMD 47K 5% 0603 R920 1502547303 RES.SMD 47K 5% 0603 R943 1502547303 RES.SMD 47K 5% 0603 R946 1502547303 RES.SMD 47K 5% 0603 R947 1502547303 RES.SMD 47K 5% 0603 R948 1502547303 RES.SMD 47K 5% 0603 R949 1502547303 RES.SMD 47K 5% 0603 R954 1502547303 RES.SMD 47K 5% 0603 R964 1502547303 RES.SMD 47K 5% 0603 R977 1502547303 RES.SMD 47K 5% 0603 R978 1502556303 RES.SMD 56K 5% 0603 R990 1502556303 RES.SMD 56K 5% 0603 R991 1502568203 RES.SMD 6,8K 5% 0603 R980 1502568203 RES.SMD 6,8K 5% 0603 R981 1502582903 RES.SMD 8,2R 5% 0603 R934 1502500003 RES.SMD 0R 5% 0603 J901 1502500003 RES.SMD 0R 5% 0603 J902 1502568103 RES.SMD 680R 5% 0603 R984 1502568103 RES.SMD 680R 5% 0603 R985 1502582203 RES.SMD 8,2K 5% 0603 R992
MD-K400
36
CODE DESCRIPTION POSITION
1502582203 RES.SMD 8,2K 5% 0603 R993
SEMICONDUCTORS
CODE DESCRIPTION POSITION
1700100011 TRANSISTOR SMD BC856B Q901 1700100011 TRANSISTOR SMD BC856B Q902 1700100011 TRANSISTOR SMD BC856B Q907 1700100011 TRANSISTOR SMD BC856B Q909 1700100011 TRANSISTOR SMD BC856B Q910 1700100011 TRANSISTOR SMD BC856B Q912 1700100011 TRANSISTOR SMD BC856B Q913 1700100021 TRANSISTOR SMD BC858B Q901 1700100021 TRANSISTOR SMD BC858B Q902 1700100021 TRANSISTOR SMD BC858B Q907 1700100021 TRANSISTOR SMD BC858B Q909 1700100021 TRANSISTOR SMD BC858B Q910 1700100021 TRANSISTOR SMD BC858B Q912 1700100021 TRANSISTOR SMD BC858B Q913 1700100034 TRANSISTOR SMD BC856B Q901 1700100034 TRANSISTOR SMD BC856B Q902 1700100034 TRANSISTOR SMD BC856B Q907 1700100034 TRANSISTOR SMD BC856B Q909 1700100034 TRANSISTOR SMD BC856B Q910 1700100034 TRANSISTOR SMD BC856B Q912 1700100034 TRANSISTOR SMD BC856B Q913 1700100014 TRANSISTOR SMD BC817/25 Q905 1700100015 TRANSISTOR SMD BC846B Q903 1700100015 TRANSISTOR SMD BC846B Q904 1700100015 TRANSISTOR SMD BC846B Q906 1700100015 TRANSISTOR SMD BC846B Q908 1700100015 TRANSISTOR SMD BC846B Q911 1700100015 TRANSISTOR SMD BC846B Q914 1700100015 TRANSISTOR SMD BC846B Q915 1700100015 TRANSISTOR SMD BC846B Q916 1700100022 TRANSISTOR BC848B Q903 1700100022 TRANSISTOR BC848B Q904 1700100022 TRANSISTOR BC848B Q906 1700100022 TRANSISTOR BC848B Q908 1700100022 TRANSISTOR BC848B Q911 1700100022 TRANSISTOR BC848B Q914 1700100022 TRANSISTOR BC848B Q915 1700100022 TRANSISTOR BC848B Q916 1700100011 TRANSISTOR SMD BC856B Q901 1700100011 TRANSISTOR SMD BC856B Q902 1700100011 TRANSISTOR SMD BC856B Q907 1700100011 TRANSISTOR SMD BC856B Q909 1700100011 TRANSISTOR SMD BC856B Q910 1700100011 TRANSISTOR SMD BC856B Q912 1700100011 TRANSISTOR SMD BC856B Q913 1700100021 TRANSISTOR SMD BC858B Q901 1700100021 TRANSISTOR SMD BC858B Q902 1700100021 TRANSISTOR SMD BC858B Q907 1700100021 TRANSISTOR SMD BC858B Q909
MD-K400
37
CODE DESCRIPTION POSITION
1700100021 TRANSISTOR SMD BC858B Q910 1700100021 TRANSISTOR SMD BC858B Q912 1700100021 TRANSISTOR SMD BC858B Q913 1700100014 TRANSISTOR SMD BC817/25 Q905 1700100015 TRANSISTOR SMD BC846B Q903 1700100015 TRANSISTOR SMD BC846B Q904 1700100015 TRANSISTOR SMD BC846B Q906 1700100015 TRANSISTOR SMD BC846B Q908 1700100015 TRANSISTOR SMD BC846B Q911 1700100015 TRANSISTOR SMD BC846B Q914 1700100015 TRANSISTOR SMD BC846B Q915 1700100015 TRANSISTOR SMD BC846B Q916 1700100022 TRANSISTOR BC848B Q903 1700100022 TRANSISTOR BC848B Q904 1700100022 TRANSISTOR BC848B Q906 1700100022 TRANSISTOR BC848B Q908 1700100022 TRANSISTOR BC848B Q911 1700100022 TRANSISTOR BC848B Q914 1700100022 TRANSISTOR BC848B Q915 1700100022 TRANSISTOR BC848B Q916 1710100002 I.C. SMD 4558 IC901 1710100002 I.C. SMD 4558 IC902 1710100002 I.C. SMD 4558 IC903 1710100093 I.C.SMD NJM14558M-TE1 IC901 1710100093 I.C.SMD NJM14558M-TE1 IC902 1710100093 I.C.SMD NJM14558M-TE1 IC903 1040450111 I.C. NJM-14558MD-TE IC901 1040450111 I.C. NJM-14558MD-TE IC902 1040450111 I.C. NJM-14558MD-TE IC903 1710100002 I.C. SMD 4558 IC901 1710100002 I.C. SMD 4558 IC902 1710100002 I.C. SMD 4558 IC903 1710100093 I.C.SMD NJM14558M-TE1 IC901 1710100093 I.C.SMD NJM14558M-TE1 IC902 1710100093 I.C.SMD NJM14558M-TE1 IC903
MISCELLANEOUS
CODE DESCRIPTION POSITION
1025225155 CJT.DECK C/PCI DECK MONT 1025225132 CJT.PCI MAN/MONT DECK 1025225133 CJT.PCI AUT/SMD DECK 1105225106 PCI DECK LOGICO 1319955100 BOBINA OSCILADORA BIAS T903 1319959900 BOBINA OSCILADORA BIAS T903 1161300552 CABO FRAY 2,54 24AWG 6V 330MM CN901 1161300551 CABO FRAY 2,54 24AWG 5V 330MM CN901 1647659600 CABO FLAT 2.54 24AWG 5V 320MM CN901 1161300112 CABO FRAY 300V 24AWG PR 150MM 1169200243 CAB.FRAY300V24AWGPR 160MM CLIC 1631281411 GUIA P/FIOS 11VIAS CN901 1631281211 GUIA FIOS 11V CN901 1025225130 CJT.PCI MAN/MONT DECK 1025225131 CJT.PCI AUT/SMD DECK
MD-K400
38
CODE DESCRIPTION POSITION
1105225106 PCI DECK LOGICO 1319955100 BOBINA OSCILADORA BIAS T903 1319959900 BOBINA OSCILADORA BIAS T903 1161300552 CABO FRAY 2,54 24AWG 6V 330MM CN901 1161300551 CABO FRAY 2,54 24AWG 5V 330MM CN901 1647659600 CABO FLAT 2.54 24AWG 5V 320MM CN901 1161300112 CABO FRAY 300V 24AWG PR 150MM 1169200243 CAB.FRAY300V24AWGPR 160MM CLIC 1631281411 GUIA P/FIOS 11VIAS CN901 1631281211 GUIA FIOS 11V CN901 1521027100 MECANISMO DUPLO DECK LOGICO 1161300545 CABO FRAY 2V 270MM C/ABER.30MM MOTOR 1744028000 TERMINAL 1760206000 FIXADOR DE FIOS 200mm AMARRAR FIOS DEC 1600057402 PAR.AA.PAN.PH.TRILOB.2X5 NIQ 1600007104 PAR.AA.PAN.PH. BEMLI2,6X 6 Z 1775225113 SUPORTE DO PCI DECK 1655225101 BLINDAGEM DO PCI DECK 1647681200 CJT.CHICOTE 03V 60MM CAB.PLAY 1647681300 CJT.CHICOTE 04V 60MM CAB.R/P 1647681400 CJT.CHICOTE 02V 60MM CAB.APAG
REMOTE CONTROL PCB
CODE DESCRIPTION POSITION
1025225190 CONTROLE REMOTO MONTADO RC101 1025223803 PCI CONTROLE REM.MAN.MONT 1025223813 PCI CONTROLE REM.SMD/AUT MONT 1105223830 PCI CONTROLE REMOTO (15PCS) 1710100137 I.C.SMD PT1140/PT0249 IC1 1700100014 TRANSISTOR SMD BC817/25 TR1 1700100014 TRANSISTOR SMD BC817/25 TR1 1502518903 RES.SMD 1,8R 5% 0603 R1 1502522902 RES.SMD 2,2R 5% 0805 R1 1502518902 RES.SMD 1,8R 5% 0805 R1 1502533103 RES.SMD 330R 5% 0603 R2 1459522700 DIODO LED I.V SIR-563ST3F 1459523600 DIODO LED IR LTE-3271TLLENTEAZ 1459524000 DIODO LED INFRARED TLN115A 1459515500 DIODO LED IR LTE-3271T 1459523600 DIODO LED IR LTE-3271TLLENTEAZ 1459523800 DIODO LED IR LTE-3371TLLENTEAZ 1421508100 RESSONADOR CERAMICO 3.45MHZ X1 1421507400 RESS.CER.CST-3.45MGW X1 1380470324 ELCO 47UF/25V M 5X11MM C1 1040330015 ELCO 47UF/25V M C1 1040330017 ELCO 47UF/10V M C1 1040370006 ELCO 47UF/25V M C1 1040370008 ELCO 47UF/10V M C1 1040640431 CAP.ELCO 47UF/25V C1 1575225108 GABINETE SUPERIOR C.REMOTO 1577225408 GABINETE INFERIOR CONTR.REMOTO 1577225409 TAMPA PORTA PILHAS 1777218504 TECLADO DE BORRACHA
MD-K400
39
CODE DESCRIPTION POSITION
1687218501 MOLA DE CONTATO PILHA NEG 1687218502 MOLA DE CONTATO PILHA POS 1687218503 MOLA CONTATO PILHA POS/NEG 1600059545 PAR.AA.BIND.PH.PP1 2,0X6 ZNP 1769900064 SACO PLASTICO 90X280X0,04B.D. 1886000100 PILHA PEQUENA AA 1.5V
MD-K400
40
5. ELECTRICAL SCHEME
5.1 FRONTAL PCB
5.2 LATERAL PCB
5.3 CD PCB
5.4 DECK PCB
5.5 REMOTE CONTROL PCB
6. SILKTOP AND SOLDERS
6.1 MAIN PCB
6.2 CD PCB
6.3 DECK PCB
6.4 REMOTE CONTROL PCB
7. EXPLODED VIEW
8. SPEAKERS – TECHNICAL SPECIFICATION
8.1 PRODUCT MODEL
8.2 MATERIAL LIST AND EXPLODED VIEW
MODE_SWAMODE_SWA
+12V+12V
CLKCLK
MODE_SWBMODE_SWB
SOLEN_R/PSOLEN_R/P
SOLEN_PLAYSOLEN_PLAY
REMREM
MOSIMOSI
MISOMISO
STBSTB
-VFD-VFD
FIL_BFIL_B
+5VB+5VB
E1BE1B
E1AE1A
FIL_AFIL_A
+5V+5V
+5V+5V +5V+5V
+5V+5V
+5V+5V
+5V+5V
GND2GND2
SEN_BSEN_B
PULSE_PLAYPULSE_PLAY
PULSE_PLAYPULSE_PLAY
ANO_AANO_A
SOL_ASOL_A
PULSE_R/PPULSE_R/P
PULSE_R/PPULSE_R/P
SOL_BSOL_B
SEN_ASEN_A
REC_SWREC_SW
REC_SWREC_SW
ANO_BANO_B
GNDGND
GNDGND
GNDGND
GNDGND
+12V+12V
+12V+12V
SK-107SK-107
4K74K7
2K22K2
2K22K2
150K150K
120K120K
BC846BBC846B
BC846BBC846B
VERDEVERDE
VOLUMEVOLUME
ENCODERENCODER
10K10K
10n10n
VERDEVERDE
VERDEVERDE
SK-107SK-107
4K74K7
220R220R
4K74K7
10K10K
220R220R
220R220R
BC327/25BC327/25
4K74K7
2K22K2
SURRSURR
S_RWS_RW
DISC1DISC1
DISC3DISC3
TUNERTUNER
EQUALEQUAL
OP/CLOP/CLTAPETAPE
DISC2DISC2
2K22K2
OPC.OPC.
100uH100uH
220R220R
220R220R
220R220R
220R220R
220R220R
220R220R
220R220R
220R220R
220R220R
220R220R
100R100R
220R220R
1K1K
1K1K
1K1K
100R100R
100R100R
100R100R
1K1K
100R100R
100R100R
100R100R
100R100R
100R100R
2K22K2
2K22K2
1N41481N4148
1N41481N4148
1N41481N4148
47uF/25V47uF/25V
33R33R
220R220R
PT6318PT6318
RPM6936/V4RPM6936/V4
CDCD
S_FFS_FF
STOPSTOP
RECREC
POWERPOWER
PL/PSPL/PS
BC846BBC846B
330R330R
BC327/25BC327/25
4K74K7
1K1K
100R100R
1K1K
1R1R
10K10K
100K100K
10K10K
2K22K2
BC846BBC846B
10n10n
120K120K
150K150K
330R330R
D1903D1903
R1925R1925
R1922R1922
R1920R1920
R1918R1918
R1915R1915
Q1907Q1907
CN1901CN1901
Q1908Q1908
CN1902CN1902
D805D805
E801E801
R846R846
C817C817
D806D806
D807D807
D1902D1902
R1913R1913
R841R841
R1931R1931
R1929R1929
R843R843
R842R842
Q1909Q1909
R1914R1914
R1919R1919
R808R808
C802C802
L801L801
R811R811
R812R812
R813R813
R814R814
R815R815
R816R816
R817R817
R818R818
R819R819
R820R820
R838R838
R821R821
R822R822
R823R823
R825R825
R829R829
R830R830
R831R831
R824R824
R834R834
R835R835
R836R836
R832R832
R837R837
R806R806
R807R807
D802D802
D803D803
D801D801
C803C803
R847R847
R810R810
IC801IC801
IR801IR801
Q1912Q1912
R1924R1924
Q1910Q1910
R850R850
R803R803
R805R805
R802R802
R804R804
R845R845
CN1904CN1904
R839R839
R1930R1930
R1921R1921
Q1911Q1911
C818C818
R1916R1916
R1917R1917
R1923R1923
CN1903CN1903
VFD801VFD801
5252
5151
5050
4949
4848
4747
4646
4545
4444
4343
4242
4141
4040
2727282829293030313132323333343435353636373738383939
2626
2525
2424
2323
2222
2121
2020
1919
1818
1717
1616
1515
1414
1313121211111010998877665544332211
VddVdd
Seg1/KS1Seg1/KS1
Seg2/KS2Seg2/KS2
Seg3/KS3Seg3/KS3
Seg4/KS4Seg4/KS4
Seg5/KS5Seg5/KS5
Seg6/KS6Seg6/KS6
Seg7/KS7Seg7/KS7
Seg8/KS8Seg8/KS8
Seg9/KS9Seg9/KS9
Seg10/KS10Seg10/KS10
Seg11/KS11Seg11/KS11
Seg12/KS12Seg12/KS12
Seg13/Grid16Seg13/Grid16
Seg14/Grid15Seg14/Grid15
Seg15/Grid14Seg15/Grid14
Grid6Grid6
Seg16/Grid13Seg16/Grid13
Seg17/Grid12Seg17/Grid12
Seg18/Grid11Seg18/Grid11
VddVdd
VeeVee
Seg19/Grid10Seg19/Grid10
Seg20/Grid9Seg20/Grid9
Grid8Grid8
Grid7Grid7
Grid5Grid5
Grid4Grid4
Grid3Grid3
Grid2Grid2
Grid1Grid1
VddVdd
VssVss
LED5LED5
LED4LED4
LED3LED3
LED2LED2
LED1LED1
OSCOSC
KEY4KEY4
KEY3KEY3
KEY2KEY2
KEY1KEY1
STBSTB
CLKCLK
ICIC
DinDin
DoutDout
SW4SW4
SW3SW3
SW2SW2
SW1SW1
332211
REMOTOREMOTO
SENSORSENSOR
3131 11551010151520202525
VFD DISPLAYVFD DISPLAY
1.00.52318.021.00.52318.02
MCP-314 /MD-K400 /DMD-K400MCP-314 /MD-K400 /DMD-K400
ROBERTOROBERTO
THIAGOTHIAGO
THIAGOTHIAGO
25/07/0325/07/03
25/07/0325/07/03
23/07/0323/07/03
CDCD
1.52.10271.001.52.10271.00
4444
3030
2929
2828
2727
2626
2525
2424
2323
2222
2121
2020
1919
1818
1717
1616
1515
4343
4242
4141
4040
3838
3737
3636
3939
TUNERTUNER TAPETAPE
APEXAPEX
APEXAPEX
SUNMAXSUNMAX
SUNMAXSUNMAX
66
66
55
55
55
33
33
22
22
11
11
11
11
44
44
44
ESQUEMA ELETRICO PCI FRONTALESQUEMA ELETRICO PCI FRONTAL
FRONTAL PCB SCHEMATIC ELECTRICFRONTAL PCB SCHEMATIC ELECTRIC
+5V+5V
+5V+5V
CICUITO OPCIONAL USADOCICUITO OPCIONAL USADO
PARA MONTAGEM DO DECK SUNMAXPARA MONTAGEM DO DECK SUNMAX
++
++
VERIF.VERIF.
TITLE:TITLE:
A2A2
mmmmememdimensoesdimensoes
PROJECAOPROJECAO
DISCRIMINACAODISCRIMINACAO
TITULO:TITULO:
DATADATAVISTOVISTO
COD.COD.
N.N.TOL.TOL.TOL.TOL.
MOD.MOD.
ACAB.ACAB.
ESC.ESC.
MAT.MAT.DATADATA
PROJ.PROJ.
DES.DES.
NOMENOME
P.A.P.A.ALT.ALT.
GNDGND
ININ OUTOUT
GNDGND
ININOUTOUT
VdisVdis
VoVo VinVin
GNDGND
FAL_LFAL_L
L_OUTL_OUT
R_OUTR_OUT
R_OUTR_OUT
RST_CDRST_CD
RST_CDRST_CDRST_CDRST_CD
RADIO_LRADIO_L
RADIO_LRADIO_L RADIO_LRADIO_L
SDASDA
SDASDA SDASDASDASDA
CD_LCD_L
MODE_SWAMODE_SWA
FAL_RFAL_R
+9VA+9VA
+9VA+9VA
+9VA+9VA
+9VA+9VA
+9VA+9VA+12V+12V
+12V+12V
+12V+12V
+12V+12V
+12V+12V
CLKCLK
MODE_SWBMODE_SWB
L_INL_IN
L_INL_IN
CD_RCD_R
R_INR_IN
R_INR_IN
MOTOR-MOTOR-
MOTOR-MOTOR- MOTOR-MOTOR-
FF_REWFF_REW
FF_REWFF_REW
FF_REWFF_REW
FF_REWFF_REW
SCLSCL
SCLSCL SCLSCLSCLSCL
MUTE_PWMUTE_PW
MUTE_PWMUTE_PW
L_RECL_REC
RADIO_RRADIO_R
RADIO_RRADIO_R RADIO_RRADIO_R
CECE
DIDI
CLCL
STBYSTBY
STBYSTBY
STBYSTBY
STBYSTBY
SURROUNDSURROUND
CAR-CAR-
CAR-CAR-
DODO
STATUSSTATUS
RECREC
RECREC
RECREC
SOLEN_R/PSOLEN_R/P
CAR+CAR+
CAR+CAR+
CAR_POSCAR_POS
CAR_POSCAR_POS
PB_1/2PB_1/2
PB_1/2PB_1/2
PB_1/2PB_1/2
R_RECR_REC
R_RECR_REC
SOLEN_PLAYSOLEN_PLAY
REMREM
CDM_POSCDM_POS
CDM_POSCDM_POS
MOSIMOSI
MISOMISO
MOTOR+MOTOR+
MOTOR+MOTOR+
MOTOR+MOTOR+
STBSTB
-VFD-VFD
-VFD-VFD
FIL_BFIL_B
FIL_BFIL_B
+5VB+5VB
E1BE1B
E1AE1A
FIL_AFIL_A
FIL_AFIL_A
+5V+5V
+5V+5V
+5V+5V
GND2GND2
REC_SWREC_SW REC_SWREC_SWREC_SWREC_SW
REC_SWREC_SW
REC_SWREC_SW
REC_SWREC_SW
+5V+5V
GNDGND
88 77 66 55
44332211
GNDGND
+5V+5V
+9VA+9VA
TP8TP8
TP7TP7
TP6TP6
TP5TP5
TP4TP4
TP3TP3
TP2TP2
TP1TP1 TP10TP10
+5V+5V
1K1K
1K1K
100uF/50V100uF/50V
10n/500V10n/500V
1N40041N4004
1N41481N4148
220R220R
220R220R
270R270R
47n47n
1K1K
8K28K2
GARRAGARRA
1n1n
10K10K
BC846BBC846B
1n1n
OPC.OPC.
SVC201-SPASVC201-SPA
GNDGND
FMFM
47n47n
47n47n
BZX79C5V6BZX79C5V6
680R680R
AM_ANTAM_ANT
44
33
22
11
FI_AMFI_AM
33
66
44
22
33K33K
470p470p
OPC.OPC.
10p10p
47n47n
RF_FMRF_FM
33K33K
SVC201-SPASVC201-SPA
OSC_FMOSC_FM
10K10K
75KHz75KHz
10p10p
10p10p
47n47n
BZX79C3V3BZX79C3V3
100uF/16V100uF/16V
22n22n
100n100n
CDA10.7-MG46CDA10.7-MG46
1uF/100V1uF/100V
0,47uF/100V0,47uF/100V
1uF/100V1uF/100V
SFE10.7MA5-ASFE10.7MA5-A
SFU450BSFU450B
100uF/16V100uF/16V
47n47n
47n47n
22uF/50V22uF/50V
4,7uF/100V4,7uF/100V
390p390p
10n10n
22uF/50V22uF/50V
4K74K7
0R0R
0,47uF/100V0,47uF/100V
47n47n
1K1K
47n47n
AM_OSCAM_OSC
66
44 33
11
39p39p
390p390p
22K22K
15p15p
33K33K
100n/63V100n/63V
47p47p
47p47p
1K1K
1K1K
47p47p
1K1K
47p47p
47p47p
47p47p
100n/63V100n/63V
1K1K
SVC383SVC383
10K10K
BC846BBC846B
0R0R
1K1K
BC846BBC846B
10K10K
LV23000MLV23000M
10uF/50V10uF/50V
BC846BBC846B
7805PL7805PL
1K1K
220n/63V220n/63V
2R22R2
2R22R2
GT202GT202
47p47p
GARRAGARRA
47K47K
BZX79C24VBZX79C24V
10K10K
47p47p
1K1K
10K10K
10K10K
10K10K
47K47K
47K47K
10uF/50V10uF/50V
22K22K
470p470p
470R470R
100uF/16V100uF/16V
10K10K
47K47K
100uF/16V100uF/16V
470R470R
1K1K
100R100R
47p47p
100K100K
2K22K2
22K22K
100K100K
22uF/50V22uF/50V
10n/100V10n/100V
100uF/16V100uF/16V
22n22n
2200uF/50V2200uF/50V
LA4282LA4282
10n/100V10n/100V
100K100K
1K1K
22n22n
330K330K
2K22K2
10n/100V10n/100V
33p33p
2K2_1/2W2K2_1/2W
100K100K
OPC.OPC.
GARRAGARRA
0,5A/250V0,5A/250V
100uF/10V100uF/10V
47uF/25V47uF/25V
GT202GT202
10K10K
GT202GT202
2K22K2
7805PL7805PL
2200uF/25V2200uF/25V
2K22K2
220R220R
220n/63V220n/63V
1uF/100V1uF/100V
100uF/25V100uF/25V
4444434342424141404039393838373736363535
3333
3232
3131
3030
2929
2828
2727
2626
2525
2424
2222 2121 2020 1919 1818 1717 1616 1515 1414 1313
99887766554433
22
PTB0/AD0PTB0/AD0
44444343424241414040393938383737363635353434
3333
3232
3131
3030
2929
2828
2727
2626
2525
2424
2323
2222 2121 2020 1919 1818 1717 1616 14141515 1313 1212
1111
1010
998877665544332211
VssaVssa
OSC1OSC1
OSC2OSC2
CBMXFCCBMXFC
VddsVdds
PTA7/KBO7PTA7/KBO7
PTA6/KBO6PTA6/KBO6
PTA3/KBO3PTA3/KBO3
PTA4/JBO5PTA4/JBO5
PTA5/KBO5PTA5/KBO5
PTA2/KBO2PTA2/KBO2
Vssad/Vref1Vssad/Vref1 PTA1/KBD1PTA1/KBD1
PTA0/KBD0PTA0/KBD0Vddad/VrefhVddad/Vrefh
PTB7/AD7PTB7/AD7
PTB6/AD6PTB6/AD6
PTB5/AD5PTB5/AD5
PTB4/AD4PTB4/AD4
PTB3/AD3PTB3/AD3
PTB2/AD2PTB2/AD2
PTB1/AD1PTB1/AD1
PTD7/T2CH1PTD7/T2CH1
PTD6/T2CHOPTD6/T2CHO
PTD5/TACH1PTD5/TACH1
PTD4/T1CHOPTD4/T1CHO
VddVdd
VssVss
PTD3/SPSCKPTD3/SPSCK
PTD2/MOSIPTD2/MOSI
PTD1/MISOPTD1/MISO
PTD0/SSPTD0/SS
IRQIRQ
PTE1/RxDPTE1/RxD
PTE0/TxDPTE0/TxD
PTC6PTC6
PTC5PTC5
PTC4PTC4
PTC3PTC3
PTC2PTC2
PTC1PTC1
PTCOPTCO
RSTRST
MC68HC908GP32MC68HC908GP32
10K10K
10K10K
10n/100V10n/100V
GT202GT202
10n/100V10n/100V
10K10K
100K100K
10uF/50V10uF/50V
BC856BBC856B
32,768KHz32,768KHz
10M10M
33p33p
BC846BBC846B
OPC.OPC.
10p10p
1K1K
47p47p
10K10K
BC846BBC846B
1K1K
47K47K
1K1K
47p47p
47p47p
1K1K
47p47p
470p470p
1K1K
10K10K
47n47n
5K65K6
2,2uF/100V2,2uF/100V
2n7/63V2n7/63V
100n/63V100n/63V
100uF/16V100uF/16V
47p47p
10R10R
1K1K
2,2uF/100V2,2uF/100V
2,2uF/100V2,2uF/100V
100n/63V100n/63V
100n100n
2,2uF/100V2,2uF/100V
2,2uF/100V2,2uF/100V
2,2uF/100V2,2uF/100V
2,2uF/100V2,2uF/100V
2,2uF/100V2,2uF/100V
2,2uF/100V2,2uF/100V
10uF/50V10uF/50V
100n/63V100n/63V
100uF/16V100uF/16V
2,2uF/100V2,2uF/100V
5K65K6
2n7/63V2n7/63V
47p47
p
1K
1K
10R10R
10uF/50V10uF/50V
10K10K
BC846BBC846B
BC846BBC846B
22K22K
BZX79C3V3BZX79C3V3
10K10K
OPC.OPC.
1uF/100V1uF/100V
180R180R
10uF/50V10uF/50V
22n22n
47p47p
100n/63V100n/63V
22p22p
GFMB5GFMB5
10R10R
47p47p
22n22n
47p47p
47p47p
47uF/25V47uF/25V
47p47p
10K10K
1K1K
47p47p
47p47p
1K1K
10uF/50V10uF/50V
22n22n
47p47p
47K47K
10K10K
10K10K
10K10K
BC327/25BC327/25
47p47p
100R100R
1N40041N4004
1N40041N4004
1N40041N4004
1N40041N4004
10n/100V10n/100V
10n/100V10n/100V
10n/100V10n/100V
47p47p
47p47p
1K1K
47p47p
10R10R
1K1K
1K1K
1K1K
0R0R
1K1K
1K1K
47p47p
47p47p
1K1K
330R330R
47p47p
1uF/100V1uF/100V
3K33K3
10K10K
1K1K
1K1K
33n33n
1K1K
22n22n
10R10R
10K10K
1K1K
4K74K7
47K47K
BC337/25BC337/25
3R3_1/2W3R3_1/2W
--++
BC327/25BC327/25
10K10K
BC327/25BC327/25
680R680R
10K10K
BC846BBC846B
680R680R
22K22K
BC846BBC846B
22K22K
10K10K
1n1n
BC337/25BC337/25
470R470R
BC337/25BC337/25
470R470R
KIA6903PKIA6903P
22uH22uH
10K10K
100uF/50V100uF/50V
100K100K
GARRAGARRA
110V110V
220V220V
1A/250V1A/250V
1N41481N4148
1N41481N4148 1N41481N4148
2K72K7
220uF/16V220uF/16V
OPC.OPC.
1N41481N4148
1000uF/25V1000uF/25V
2K72K7
1000uF/25V1000uF/25V
2R2/1W2R2/1W
2R2/1W2R2/1W
2K22K2
2,2uF/100V2,2uF/100V
2,2uF/100V2,2uF/100V
47K47K
33K33K
47K47K
33K33K
2K22K2
OPC.OPC.
KA78R12KA78R12
22K22K
220R220R
BC337/25BC337/25
22n22n
BZX79C10VBZX79C10V
470uF/16V470uF/16V
220uF/16V220uF/16V
0R0R
22n22n
R505R505
R503R503
C512C512
C510C510
D505D505
D515D515
R1902R1902
R220R220
R1901R1901
C134C134
R621R621
R105R105
CN601CN601
GF503GF503
CN201CN201
C135C135
R116R116
Q102Q102
C106C106
C133C133
D102D102
CN101CN101
C102C102
C130C130
D104D104
R112R112
T102T102
T104T104
R103R103
C108C108
C107C107
VC102VC102
C110C110
L101L101
R104R104
D103D103
L102L102
R107R107
X101X101
C119C119
C120C120
C132C132
D105D105
C131C131
C129C129
C116C116
CF104CF104
C127C127
C126C126
C125C125
CF103CF103
CF102CF102 C123C123
C124C124
C122C122
C121C121
C118C118
C117C117
C637C637
C115C115
R108R108
R515R515
C113C113
C114C114
R106R106
C112C112
T101T101
C104C104
C105C105
R312R312
C103C103
R101R101
C414C414
C634C634
C635C635
R636R636
R634R634
C631C631 R633R633
C609C609
C641C641
C621C621
JC35JC35
C415C415
VR1901VR1901
CN602CN602
D101D101
R113R113
Q301Q301
R507R507
R630R630
Q204Q204
R644R644
IC101IC101
C202C202
Q201Q201
IC502IC502
R210R210
C207C207
R208R208
R207R207
D205D205
C622C622
GF504GF504
R417R417
D506D506
R616R616
C623C623
R648R648
R638R638
R201R201
R213R213
R214R214
R414R414
C201C201
R212R212
C203C203
R206R206
C206C206
R216R216
R215R215
C205C205
R205R205
R209R209
R430R430
C611C611
R317R317
R413R413
R310R310
R318R318
C305C305
C215C215
C522C522
C519C519
CN507CN507
C213C213
IC201IC201
C216C216
R420R420
R508R508
C520C520
R639R639
R426R426
C503C503
C639C639
R501R501
R502R502
R506R506
GF501GF501
FS501FS501
C521C521
C1902C1902
D202D202
R643R643
D204D204
R412R412
IC501IC501
C505C505
R427R427
R114R114
C208C208
C513C513
C211C211
IC601IC601
R218R218
R202R202
C217C217
D203D203
C218C218
R217R217
R419R419
C212C212
Q203Q203
X601X601
R640R640
C640C640
Q202Q202
C101C101
VC101VC101
R622R622
C608C608
R219R219
Q601Q601
R607R607
CN402CN402
R418R418
R625R625
C633C633
C613C613
R635R635
C612C612
C204C204
R624R624
R646R646
IC401IC401
C111C111
R402R402
C425C425
C403C403
C417C417
C418C418
C618C618
R401R401
R631R631
C424C424
C422C422
C404C404
C1901C1901
C421C421
C408C408 C406C406
C410C410
C409C409
C407C407
C419C419
C416C416
C401C401
C411C411
R403R403
C402C402
C625C625
R620R620
R613R613
C420C420
R601R601
Q101Q101
Q602Q602
R604R604
D601D601
R605R605
R504R504
C601C601
R606R606
C602C602
C617C617
C616C616
C405C405
C109
C109
CF101CF101
R632R632
C624C624
C636C636
C607C607
C628C628
C603C603
C604C604
R642R642
R647R647
C619C619
C606C606
R627R627
C630C630
C629C629
C610C610
R415R415
CNTP9CNTP9
R641R641
R602R602
R603R603
Q502Q502
C620C620
R431R431
D501D501
D504D504
D503D503
D502D502
C504C504
C502C502
C501C501
C627C627
CN601CN601
C626C626
R629R629
C605C605
R612R612
R623R623
R614R614
R619R619
R611R611
R608R608
R609R609
C614C614
C615C615
R610R610
R111R111
C632C632
C518C518
R110R110
R645R645
R626R626
R637R637
C638C638
R628R628
C128C128
R618R618
R1905R1905
R615R615
R1926R1926
R1927R1927
Q1913Q1913
R1928R1928
CN906CN906
Q1903Q1903
R1906R1906
Q1904Q1904
R1907R1907
R1910R1910
Q1905Q1905
R1908R1908
R1911R1911
Q1906Q1906
R1912R1912
R1909R1909
C136C136
Q1902Q1902
R1904R1904
Q1901Q1901
R1903R1903
IC1901IC1901
L1901L1901
R115R115
JC37JC37
C511C511
R102R102
GF502GF502
SW501SW501
REDEREDE
FS502FS502
TF501TF501
D508D508
D511D511
JC56JC56
D510D510
R204R204
C514C514
D1901D1901
D509D509
C210C210
R203R203
C209C209
R530R530
R531R531
R428R428
C412C412
C413C413
CN401CN401
R422R422
R424R424
R421R421
R423R423
R429R429
J2J2
IC503IC503
R211R211
R509R509
Q501Q501
C507C507
D507D507
C508C508
C509C509
J1J1
C506C506
- ITEM DE SEGURANCA - ESTES COMPONENTES SO PODEM SER SUBSTITUIDOS POR - ITEM DE SEGURANCA - ESTES COMPONENTES SO PODEM SER SUBSTITUIDOS POR
ORIGINAIS DE FABRICAORIGINAIS DE FABRICA
GNDGNDGNDGND
(+L)(+L)(+R) (+R)
X-INX-IN X-OUTX-OUT VDDVDD
ININ
MPXMPX
OUTOUT
DETDET
LOW CUTLOW CUT
AMAM AGCAGC PDPD A-INA-IN A-OUTA-OUT BO1BO1 BO2BO2
OSCOSC
AMAM
OSCOSC
FMFM Vcc2Vcc2
RF OUTRF OUT
FMFM GND2GND2
RF INRF IN
FMFM
DODO CLCL DIDI CECE VSSVSS R-OUTR-OUT L-OUTL-OUT DETDET
FMFM
P-COMPP-COMP P-DETP-DET IF INIF IN
FMFM
IF INIF IN
AMAM
Vcc1Vcc1 IF INIF IN
AMAM
GND1GND1 MIXMIX
FMFM
REGREG RF INRF IN
AMAM
363635353434333332323131303029292828272726262525242423232222212120201919
1818 1717 1616 1515 1414 1313 1212 1111 1010 99 88 77 66 55 44 33 22 11
1111
1212
99
77
1010
8833
55
66
44
22
11
Rin_1Rin_1LoutLout
RoutRout
Lin_3Lin_3
Lin_4Lin_4
Loud_LLoud_L
Rin_2Rin_2
Rin_3Rin_3
Rin_4Rin_4
Loud_RLoud_R
RinRin
Treble_RTreble_R
Treble_LTreble_L
AgndAgnd
VddVddRefRef
CLKCLK
DATADATA
DgndDgnd
Out_LOut_L
Out_ROut_R
Bout_RBout_R
Bin_RBin_R
Bout_LBout_L
Bin_LBin_L
LinLin
Lin_1Lin_1
Lin_2Lin_2
& Gain Control& Gain Control
Input SelectorInput Selector
LoudnessLoudness Volume &Volume &
& Gain Control& Gain Control
Input SelectorInput Selector
PT2314PT2314
BassBass BassBass
MuteMute
AttAttAttAtt
MuteMute
LoudnessLoudness Volume &Volume &
TrebleTreble
TrebleTreble
SupplySupply
LatchesLatches
Decoder &Decoder &
Serial BusSerial Bus
44 33
22 11
33
22
11
1.00.52318.031.00.52318.03
MCP-314 /MD-K400 /DMD-K400MCP-314 /MD-K400 /DMD-K400
OU 7805 + D510,511OU 7805 + D510,511
PARA CD PHONIC USA-SE R417 e R418 12KPARA CD PHONIC USA-SE R417 e R418 12K
PARA CD 10/3 USA-SE R417 e R418 47K PARA CD 10/3 USA-SE R417 e R418 47K
USAR KIA 7806USAR KIA 7806
PARA MD-K400"B"PARA MD-K400"B"
GNDGND AUXAUX
RR
LL
33
22
11
A_GNDA_GND
ROBERTOROBERTO
THIAGOTHIAGO
THIAGOTHIAGO
99
88
77
66
1212
1111
1010
22/07/0322/07/03
22/07/0322/07/03
24/07/0324/07/03
0V -> Stby on0V -> Stby on
+5V -> Stby off+5V -> Stby off
10V10VA_GNDA_GND
**
GND2GND2
GND2GND2
GND2GND2
GND2GND2
GND2GND2
GND2GND2
GND2GND2 GND2GND2
ELIMINAR JUMPERS JC35.JC37ELIMINAR JUMPERS JC35.JC37
1.52.10269.991.52.10269.99
1313
4V / 0,2A4V / 0,2A
30V / 0,05A30V / 0,05A
11V/0,8A11V/0,8A
27V/1A27V/1A
120120
2020
100100
* = fixado ao dissipador* = fixado ao dissipador
5V-ON5V-ON
0V-OFF0V-OFF
**
CIRCUITO USADO PARA DECK APEX 1.52.10269.99CIRCUITO USADO PARA DECK APEX 1.52.10269.99
PARA MONTAGEM DO DECK APEXPARA MONTAGEM DO DECK APEX
CICUITO OPCIONAL USADOCICUITO OPCIONAL USADO
22
11
AC INAC IN
MM
GND2GND2
22
11
LATERAL PCB ELECTRIC SCHEMATICLATERAL PCB ELECTRIC SCHEMATIC
ESQUEMA ELETRICO PCI LATERALESQUEMA ELETRICO PCI LATERAL
998877
6611554433
22
99
88
66
55
44
33
22
11
77
1111
1010
CN701/CCN701/C
DO CDDO CD
ALIMENTACAOALIMENTACAO
**
**
+5V+5V
+5V+5V
+5V+5V
+5V+5V
+5V+5V
+5V+5V
+5V+5V
+5V+5V
+5V+5V+5V+5V
GNDGND CDCD
RR
LL
33
22
11
A_GNDA_GND
D_GNDD_GND
A_GNDA_GNDA_GNDA_GND
A_GNDA_GND
A_GNDA_GNDA_GNDA_GND
A_GNDA_GND
A_GNDA_GND
A_GNDA_GND
A_GNDA_GND
++
++
++
++
++
++
++
++
++
++
++ ++
++ ++
++
++
++
++
++
++
++
++
++
28282727262625252424232322222121202019191818171716161515
1414 1313 11111212 1010 99 88 77 66 55 44 33 22 11
++
++
++
++
++
++
++
++++
++
++
++
++
++
++
++
++
++
++
++
++
++ ++
++
++
++
++
VERIF.VERIF.
A1A1
mmmmememdimensoesdimensoes
PROJECAOPROJECAO
DISCRIMINACAODISCRIMINACAO DATADATAVISTOVISTO
COD.COD.
N.N.TOL.TOL.TOL.TOL.
MOD.MOD.
ACAB.ACAB.
ESC.ESC.
MAT.MAT.DATADATA
PROJ.PROJ.
DES.DES.
NOMENOME
P.A.P.A.ALT.ALT.
TITLE:TITLE:
TITULO:TITULO:
BiasBias
SCLSCL
SCLSCL
CDM_POSCDM_POS
CAR+CAR+
CAR+CAR+
CAR+CAR+
CAR+CAR+
3V33V3
3V33V3
3V33V3
3V33V3
3V33V3
MONMON
F-F-
F-F-
F+F+
F+F+
1V81V8
EE
EE
AA
AA
BB
BB
RESETRESET
RESETRESET
RESETRESET
RESETRESET RESETRESET
TRAY-TRAY-
TRAY-TRAY- TRAY-TRAY-
CAR-CAR-
CAR-CAR-
CAR-CAR-
CAR-CAR-
STATUSSTATUS
SDASDA
SDASDA
T-T-
T-T-
CCCC
T+T+
T+T+
DD
DD
LDLDLDLD
FF
FF
TRAY+TRAY+
TRAY+TRAY+ TRAY+TRAY+
+6V+6V
+6V+6V
+6V+6V
+6V+6V
+6V+6V
R_OUTR_OUT
GNDGND
GNDGND
CAR_POSCAR_POS
L_OUTL_OUT
TRAY_SWTRAY_SW
TRAY_SWTRAY_SW
HOME_SWHOME_SW
A_GND2A_GND2
3V33V3
1V81V8
SAA7824SAA7824
100n100n
BC817/25BC817/25
3n33n3
OPC.OPC.
100uF/10V100uF/10V
1uF/10V1uF/10V
33p33p33p33p
BC817/25BC817/25
22n22n
22uF/50V22uF/50V
100n100n
4K74K7
47n47n
2n22n2
10R10R
47uF/25V47uF/25V
BC807/25BC807/25
1K51K5
BC807/25BC807/25 BC807/25BC807/25
BC817/25BC817/25
BC807/25BC807/25
100n100n
100n100n
4K74K7
120K120K
4K74K7
10R10R
3n33n3
3n33n3
0R0R
10n10n
220uF/10V220uF/10V
1uF/10V1uF/10V
0,47uF/100V0,47uF/100V
100n100n
220uF/10V220uF/10V
BC337/25BC337/25
47uF/25V47uF/25V
47uF/25V47uF/25V
BC337/25BC337/25
OPC.OPC.
TZA1048TZA1048
OPC.OPC.
CLOSECLOSE
OPENOPEN
24K24K
10K10K
2n22n2
2n22n2
33K33K
330p330p
0R0R
10n10n
4K74K7
4K74K7
4K74K7
4K74K7
4K74K7
0R0R
100n100n
100n100n
3n33n3
OPC.OPC.
100uF/10V100uF/10V
CLOSECLOSE
OPENOPEN
CLOSECLOSE
OPENOPEN
BC817/25BC817/25
22n22n
22uF/50V22uF/50V 22uF/50V22uF/50V 22uF/50V22uF/50V
CLOSECLOSE
OPENOPEN
10K10K
1K1K
1K1K
BC337/25BC337/25
4K74K7
1K1K
1K1K
22n22n
10K10K
1K51K5
47uF/25V47uF/25V
100n100n
1K51K5
100n100n
1K51K51K51K5
100n100n
8,4672MHz8,4672MHz
OPC.OPC.
1K51K5
100R100R
4K74K7
2n22n2
10K10K
SK-107SK-107
1N41481N4148
SK-107SK-107
OPC.OPC.
10R10R
BC856BBC856B
120K120K
BC856BBC856B
220uH220uH
4K74K7
10R10R
47uF/25V47uF/25V
47n47n
1R1R
47uF/25V47uF/25V
47uF/25V47uF/25V
100n100n
470uF/10V470uF/10V
100R100R
1.00.52284.011.00.52284.01
P/ USO CD 3 DISCOSP/ USO CD 3 DISCOS
P/ USO CD 3 DISCOSP/ USO CD 3 DISCOS
P/ USO CD 3 DISCOSP/ USO CD 3 DISCOS
usado para CD 3 DISCOS usado para CD 3 DISCOS
P/ USO CD TOPOP/ USO CD TOPO
44
33
22
11
M704M704
M703M703
SP1SP1
TR1TR1
SP2SP2
TR2TR2
19/11/0319/11/03
19/11/0319/11/03
PHONIC CD 3 e 1 discoPHONIC CD 3 e 1 disco
ESQUEMA ELETRICO PCI CD 3 e 1 discoESQUEMA ELETRICO PCI CD 3 e 1 disco
PHONIC P/ PICK-UP DA-12PHONIC P/ PICK-UP DA-12
04/08/0304/08/03
MM
MM
1616
1515
1414
1313
1212
1111
1010
99
88
77
66
55
44
33
22
11
THIAGOTHIAGO
THIAGOTHIAGO
ROBERTOROBERTO
IC701IC701
C715C715
Q708Q708
C709C709
J3J3
C731C731
C713C713
C703C703C704C704
Q705Q705
C702C702
C744C744
C706C706
R715R715
C701C701
C721C721
R712R712
C732C732
Q712Q712
R729R729
Q710Q710 Q709Q709
Q707Q707
Q711Q711
C719C719
C718C718
R716R716
R718R718
R708R708
R702R702
C710C710
C711C711
J2J2
C716C716
C738C738
CN704CN704
C712C712
C735C735
C725C725
C734C734
Q701Q701
C740C740
C733C733
Q702Q702
R707R707
IC702IC702
R706R706
SW702SW702
R701R701
R714R714
C723C723
C722C722
R709R709
C724C724
J701J701
C717C717
R705R705
R703R703
R724R724
R723R723
R710R710
J1J1
C705C705
C707C707
C708C708
J4J4
C730C730
CN705CN705
SW703SW703
SW704SW704
CN702CN702
CN702CN702
Q706Q706
C727C727
C743C743 C742C742 C741C741
SW701SW701
R713R713
R722R722
R720R720
Q703Q703
R711R711
R719R719
R721R721
C726C726
R732R732
R725R725
C739C739
C750C750
R727R727
C728C728
R726R726R728R728
C729C729
X701X701
J703J703
R730R730
CN703CN703
CN701CN701
R731R731
R735R735
C720C720
R733R733
D702D702
D701D701
D703D703
J704J704
R738R738
Q713Q713
R717R717
Q714Q714
L701L701
R734R734
R737R737
C747C747
C749C749
R736R736
C746C746
C745C745
C748C748
C736C736
R739R739
VAI PARA PICK-UPVAI PARA PICK-UP
LASERLASER
TEST4TEST4
TEST3TEST3
TEST2TEST2
TEST1TEST1
V5V5
V4V4
V3V3
V2V2
V1V1
VDDD3VDDD3
VSSD3VSSD3
MOTO2MOTO2
MOTO1MOTO1
SLSL
FOFO
RARA
VDDD2VDDD2
DOBMDOBM
VSSD2VSSD2
8080 7979 7878 7777 7676 7575 7474 7373 7272 7171 7070 6969 6868 6767 6666 6565 6464 6363 6262 6161
STATUSSTATUS
SLIDSLID
RABRAB
SCLSCL
6060
5959
5858
5757
5656
5555
5454
5353
5252
SDASDA
RESETRESET
CLK12CLK12
CLK16CLK16
SCLKSCLK
WCLKWCLK
DATADATA
EFEF
SCLISCLI
SDDSDD
VDDD1VDDD1
5151
5050
4949
4848
4747
4646
4545
4444
4343
4242
4141
RKILLRKILL
VSSD1VSSD1
CFLAGCFLAG
CDT_CLKCDT_CLK
CDT_DATACDT_DATA
CDT_RDYCDT_RDY
LKILLLKILL
BUF_GNDBUF_GND
BUF_IN_LBUF_IN_L
BUF_OUT_LBUF_OUT_L
BUF_OUT_RBUF_OUT_R
BUF_IN_RBUF_IN_R
BUF_VPOSBUF_VPOS
DAC_VPOSDAC_VPOS
DAC_LPDAC_LP
DAC_LNDAC_LN
DAC_VREFDAC_VREF
DAC_RNDAC_RN
DAC_RPDAC_RP
KDAC_GNDKDAC_GND
40403939383837373636353534343333323231313030292928282727262625252424232322222121
VSSA3VSSA3
OSCINOSCIN
OSCOUTOSCOUT
2020
1919
1818
1717
VSSA2VSSA2
VDDA2VDDA2
CSLICECSLICE
R2R2
R1R1
D4D4
D3D3
D2D2
D1D1
VREF_OUTVREF_OUT
VDDA1VDDA1
IREFIREF
VSSA1VSSA1
SENSESENSE
MONITORMONITOR
EXTFILTEREXTFILTER
POWERPOWER
1313
1212
1111
1010
99
88
77
66
55
44
33
22
11
SBSYSBSY
SFSYSFSY
SUBSUB
RCKRCK
WCLIWCLI
1414
1515
1616
SLSL
VBiasVBias
GNDGND
V1.65DutV1.65Dut
Vo toVo to
MOTI1MOTI1
MOTI2MOTI2
MOTO-MOTO-
MOTO+MOTO+
GNDGND
SLO-SLO-
SLO+SLO+
VCCVCC
99
88
2020
1919
1818
1717
1616
1515
2121
3030
EARTHEARTH
1414
1313
1212
1111
1010
2929
77
66
55
44
33
22
2222
2323
2424
2525
2626
2727
2828
FODFOD
RADRAD
MUTEMUTE
V1.8FBV1.8FB
V1.8OutV1.8Out
V3.3FBV3.3FB
V3.30utV3.30ut
VCCVCC
VCCVCC
RADO+RADO+
FOCO-FOCO-
GNDGND
FOCO+FOCO+
RADO-RADO-
VCCVCC
77
66
55
44
33
22
11
PICK-UP SANSUNGPICK-UP SANSUNG
EE
VCVC
VCCVCC
DD
AA
BB
CC
FF
GNDGND
LDLD
VRVR
PDPD
PSC(+)PSC(+)
TRK(-)TRK(-)
TRK(+)TRK(+)
PSC(-)PSC(-)
GND1GND1GNDGND
DGNDDGNDGND1GND1
GND1GND1A_GND1A_GND1
A_GND2A_GND2
DGNDDGND
GNDGND GNDGND
GNDGND
GNDGND
GNDGND
A_GND2A_GND2
opc. nao montar para uso do CD TOPOopc. nao montar para uso do CD TOPO
USAR CN703 2 VIAS (1 e 2)USAR CN703 2 VIAS (1 e 2)
PARA USO CD 3 DISCOSPARA USO CD 3 DISCOS
USAR CN701 13 VIASUSAR CN701 13 VIAS
PARA USO CD 3 DISCOSPARA USO CD 3 DISCOS
USAR CN701 10 VIAS (1 AO 10)USAR CN701 10 VIAS (1 AO 10)
GNDGND
GNDGND
+6V+6V
+6V+6V
USAR CN703 6 VIASUSAR CN703 6 VIAS
PARA USO DE CD TOPOPARA USO DE CD TOPO
PARA USO DE CD TOPOPARA USO DE CD TOPO
TRAY_SWTRAY_SW
A_GND2A_GND2
A_GND2A_GND2
A_GND2A_GND2
----++
++
1313
1212
1111
1010
99
88
77
66
44
33
22
11
55
DGNDDGND
CAR_POSCAR_POS
CDM_POSCDM_POS
66
55
44
33
22
11
D_GNDD_GND
TRAYTRAY
CARCAR
M702M702
M701M701
MM
MM
A_GND1A_GND1
A_GND1A_GND1
A_GND1A_GND1
A_GND1A_GND1 A_GND1A_GND1
A_GND1A_GND1
A_GND1A_GND1A_GND1A_GND1
A_GND1A_GND1
A_GND2A_GND2 D_GNDD_GND
3V33V3
3V33V3
GND1GND1 GND1GND1
GND1GND1GND1GND1 GND1GND1
GND1GND1
GND1GND1
GND1GND1
GND1GND1
3V33V3
3V33V3
++
++
++
++
++
++
++
++
++
++ ++ ++
++
++
++
++
++
TITULO:TITULO:
VERIF.VERIF.
A2A2
mmmmememdimensoesdimensoes
PROJECAOPROJECAO
DISCRIMINACAODISCRIMINACAO DATADATAVISTOVISTO
COD.COD.
N.N.TOL.TOL.TOL.TOL.
MOD.MOD.
ACAB.ACAB.
ESC.ESC.
MAT.MAT.DATADATA
PROJ.PROJ.
DES.DES.
NOMENOME
P.A.P.A.ALT.ALT.
REC_SWREC_SW
+12V+12V
L_OUTL_OUT
R_OUTR_OUT
GNDGND
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
M_PM_P
RECREC
RECREC
PB_1/2PB_1/2
PB_1/2PB_1/2
M_RPM_RP
R_RECR_REC
L_RECL_REC
+9VA+9VA
+9VA+9VA
+9VA+9VA
+9VA+9VA
+9VA+9VA
+9VA+9VA
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC
1/2VCC1/2VCC1/2VCC1/2VCC
--
--
++
++
45584558
88 77 66 55
44332211
--
--
++
++
45584558
88 77 66 55
44332211
--
--
++
++
45584558
88 77 66 55
44332211
2n22n2 2n22n2
BC856BBC856B
6n86n8
82p82p
100n100n
2n72n7
1n1n
100n100n
22K22K
6n86n8
220uF/10V220uF/10V
22K22K
470R470R 470R470R
12n12n
100n100n
2K22K2
18K18K 2K22K2
56K56K18K18K
1K1K
1K21K2
8K28K2
10K10K
BC846BBC846B
10K10K
BC846BBC846B
1K1K
12n12n
6K86K8
1K1K
8K28K2
12n12n
680R680R
56K56K
6K86K8
1K21K2
1K1K
82p82p
2K22K2
680R680R
470p470p
1n1n
100K100K 100K100K
1uF/100V1uF/100V
1K1K
1K1K
10R10R
22n22n
BC846BBC846B
22K22K
39R39R
47K47K
47K47K
opc.opc.
OPC.OPC.
47R47R
BC846BBC846B
10K10K
47K47K
22K22K
BC846BBC846B
47K47K
10R10R
10K10K
OSC.BIASOSC.BIAS
BC846BBC846B
BC846BBC846B
18K18K
18K18K
2n72n7
10n10n
2n72n7
opc.opc.
2K22K2
opc.opc.
OPC.OPC.
3n33n3
470p470p
100n100n
BC856BBC856B
BC846BBC846B
BC856BBC856B
22n22n
1K1K
BC817/25BC817/25
BC856BBC856B
BC856BBC856B
330K330K
47K47K
BC856BBC856B
4K74K7
1K21K2
39R39R
18K18K
47R47R
8n28n2
100uF/16V100uF/16V
330K330K
8n28n2
18K18K
390K390K
4K74K7
47K47K 47K47K
1K21K2
330K330K
OPC.OPC.
8n28n2
1K21K2
390K390K
390K390K
18K18K18K18K
47R47R
39R39R
1R1R
47R47R
100uF/16V100uF/16V
8n28n2
39R39R
47K47K
OPC.OPC.
100uF/16V100uF/16V
BC856BBC856B
10K10K
47K47K
47K47K
8R28R2
10n10n
10K10K
470R470R
10K10K
10K10K
1uF/100V1uF/100V
330K330K
1K21K2
390K390K
470R470R
1n81n8
100uF/16V100uF/16V
1n81n8
1n81n8
1n81n8
IC903IC903
IC902IC902
IC901IC901
JG01JG01
C923C923 C922C922
Q907Q907
C927C927
C929C929
C953C953
C943C943
C916C916
R971R971
C926C926
C934C934
R970R970
R966R966 R967R967
C925C925
C954C954
R972R972
R969R969 R973R973
R990R990R968R968
R986R986
R988R988
R993R993
R975R975
Q915Q915
R974R974
Q916Q916
R987R987
R981R981
R983R983
R992R992
C924C924
R985R985
R991R991
R980R980
R989R989
R982R982
C928C928
R976R976
R984R984
C930C930
C915C915
R962R962 R961R961
C920C920
R960R960
R959R959
R916R916
C907C907
Q906Q906
R942R942
R911R911
R954R954
R943R943
C951C951
R944R944
R914R914
Q914Q914
R963R963
R964R964
R965R965
Q911Q911
R977R977
R915R915
R923R923
T903T903
Q903Q903
Q904Q904
R937R937
R936R936
C944C944
C941C941
C942C942
C940C940
R979R979
C932C932
R945R945
C933C933
C931C931
C917C917
Q909Q909
Q908Q908
Q910Q910
C945C945
R939R939
Q905Q905
Q902Q902
Q901Q901
R925R925
R978R978
Q912Q912
R907R907
R904R904
R912R912
R906R906
R913R913
C903C903
C906C906
R901R901
C904C904
R905R905
R909R909
R908R908
R948R948 R949R949
R926R926
R924R924
C913C913
C911C911
R927R927
R930R930
R931R931
R929R929R928R928
R935R935
R941R941
R940R940
R932R932
C918C918
C910C910
R933R933
R947R947
C912C912
C919C919
Q913Q913
R994R994
R920R920
R946R946
R934R934
C914C914
R921R921
R917R917
R919R919
R922R922
C921C921
CN907CN907
CN908CN908
CN903CN903
R902R902
R903R903
CN901CN901
R910R910
CN901CN901
R918R918
C901C901
C905C905
CAB_APGCAB_APG
CAB.PLAYCAB.PLAY
CAB.R/PCAB.R/P
C908C908
C902C902
C909C909
PLAYPLAYREC/PLAYREC/PLAY
665544332211
RECREC
(-)(-)
(+)(+)
(-)(-)
(+)(+)
(-)(-)
(+)(+)
AND CONJUNCT DECK LOGICIAN (1.02.52251.55)AND CONJUNCT DECK LOGICIAN ( 1.02.52251.55)
CJT. DECK LOGICO (1.02.52251.55)CJT. DECK LOGICO (1.02.52251.55)
17/09/0217/09/02C901.902.908.909 ERA 1nC901.902.908.909 ERA 1nCC
BB C901.902.908.909 ERA 2n7/ ELIMINAR C912.913 68n E R944.945 68RC901.902.908.909 ERA 2n7/ ELIMINAR C912.913 68n E R944.945 68R 21/05/0221/05/02
RELATIVE FOR THE CONJUNCT DECK MOUNTED (1.02.52172.82)RELATIVE FOR THE CONJUNCT DECK MOUNTED (1.02.52172.82)
REFERENTE AO CJT. DECK MONT (1.02.52172.82)EREFERENTE AO CJT. DECK MONT (1.02.52172.82)E
AA THIAGOTHIAGO
THIAGOTHIAGO
THIAGOTHIAGO
20/09/0120/09/01ALTERADO CODIGO CJT. DECK MONT DE 1.02.52172.81 PARA 1.02.52172.82ALTERADO CODIGO CJT. DECK MONT DE 1.02.52172.81 PARA 1.02.52172.82
OPC. PARA CJT. DECK LOGICO 1.02.52202.45OPC. PARA CJT. DECK LOGICO 1.02.52202.45
1.00.52172.151.00.52172.15
DOUBLE DECK PCB ELECTRIC SCHEMATICDOUBLE DECK PCB ELECTRIC SCHEMATIC
DECK duploDECK duplo
ESQUEMA ELETRICO PCI DECK DUPLOESQUEMA ELETRICO PCI DECK DUPLO
01/08/0101/08/01
01/08/0101/08/01
01/08/0101/08/01
THIAGOTHIAGO
THIAGOTHIAGO
ROBERTOROBERTO
99
88
77
66
55
44
33
22
11
CN905CN905
CN904CN904
PCIPCI
GND DOGND DO
TP7TP7
TP8TP8
TP11TP11
TP10TP10
TP12TP12TP9TP9
22
11
33
44
AO MICROAO MICRO
ESTAO JUNTOESTAO JUNTO
DE PULL-UPDE PULL-UP
RESISTORESRESISTORES
1111
1010
+9V+9V
5V-R/P5V-R/P
0V-PLAY0V-PLAY
22
11
RRLL33
22
11
plasticoplastico
Verase=0,035VVerase=0,035V
Ierase=35mAIerase=35mA
f=59.068Hzf=59.068Hz
S-201S-201
S-201S-201
E-621MLE-621ML
Ibias=400uAIbias=400uA
Vbias=0,004VVbias=0,004V
Vrec=0,00035VVrec=0,00035V
Irec=35uAIrec=35uA
CN902CN902
TP2TP2
TP3TP3
TP6TP6TP5TP5
TP4TP4
TP1TP1
66
4433
11
ERASEERASE
5522
HEADHEAD
HEADHEAD
PLAYPLAY
REC/PLAYREC/PLAY
HEADHEAD
P/R_SWP/R_SW
M_PM_P
M_RPM_RP
0V-ON0V-ON
5V-OFF5V-OFF
0V-ON0V-ON
5V-OFF5V-OFF
0V-REC0V-REC
5V-PLAY5V-PLAY
++
++
++
++
++
++ ++
++
++
VERIF.VERIF.
TITLE:TITLE:
TITULO:TITULO:
A2A2
mmmmememdimensoesdimensoes
PROJECAOPROJECAO
DISCRIMINACAODISCRIMINACAO DATADATAVISTOVISTO
COD.COD.
N.N.TOL.TOL.TOL.TOL.
MOD.MOD.
ACAB.ACAB.
ESC.ESC.
MAT.MAT.DATADATA
PROJ.PROJ.
DES.DES.
NOMENOME
P.A.P.A.AL T.ALT.
POWERPOWER MUTEMUTE CDCD TAPETAPE
DOWNDOWNVOL+VOL+TUNERTUNER
CST3.456MGWCST3.456MGW
47uF/16V47uF/16V
1/DISC11/DISC1VOL-VOL-UPUP
5/DEMO/DIMMER5/DEMO/DIMMER4/MEMO4/MEMO3/DISC33/DISC32/DISC22/DISC2
9/CLOCK9/CLOCK8/SLEEP8/SLEEP
OPEN/PROGOPEN/PROG STOP/SHUFFLESTOP/SHUFFLE PLAY-PAUSE/SCANPLAY-PAUSE/SCAN
opc.opc.
opc.opc.
1R81R8
BC817/25BC817/25
330330
7/TIMER7/TIMER6/MODE6/MODE
DISPLAY/REPEATDISPLAY/REPEAT
opc.opc.
O/EQUALO/EQUALHI_BASSHI_BASS
SHIFTSHIFT
AUXAUX
RC1RC1
C1C1
LD1LD1
C4C4
C3C3
R1R1
Q1Q1
R2R2
C2C2
CONTROLE REMOTOCONTROLE REMOTO
1.00.52300.051.00.52300.05
11/09/0311/09/03
09/09/0309/09/03
09/09/0309/09/03
ROBERTOROBERTO
THIAGOTHIAGO
THIAGOTHIAGO
CONTROL PCB ELECTRIC SCHEMATICCONTROL PCB ELECTRIC SCHEMATIC
ESQUEMA ELETRICO PCI CONTROLE REMOTOESQUEMA ELETRICO PCI CONTROLE REMOTO
Fportadora : 36 kHzFportadora : 36 kHz
Fosc : 3,456 MHzFosc : 3,456 MHz
uPD64GS-492uPD64GS-492
IC1IC1
2 x 1,5V (tipo AA)2 x 1,5V (tipo AA)
VERIF.VERIF.
TITLE:TITLE:
KI0KI0
KI1KI1
KI2KI2
KI3KI3
KI/00KI/00
KI/01KI/01
KI/02KI/02
KI/03KI/03
KI/04KI/04
KI/05KI/05
RESETRESET
VSSVSS
XINXIN
XOUTXOUT
VDDVDD
REMREM
S1/LEDS1/LED
SDSD
KI/07KI/07
KI/06KI/06 2020
1919
1818
1717
1616
1515
1414
1313
1212
11111010
99
88
77
11
22
33
44
55
66
mmmmememdimensoesdimensoes
PROJECAOPROJECAO
DISCRIMINACAODISCRIMINACAO
TITULO:TITULO:
DATADATAVISTOVISTO
COD.COD.
N.N.TOL.TOL.TOL.TOL.
MOD.MOD.
ACAB.ACAB.
ESC.ESC.
MAT.MAT.DATADATA
PROJ.PROJ.
DES.DES.
NOMENOME
P.A.P.A.ALT.ALT.
TÍTULOTÍTULO
PROJEÇÃOPROJEÇÃO
dimensões em mmdimensões em mm
MAIN PCBMAIN PCB
NOME NOME
DATA DATA MAT.MAT.
APROV. APROV.
15/08/00 15/08/00
MOD. MOD.
N.º N.º
MD-K400MD-K400
TÍTULOTÍTULO
PROJEÇÃOPROJEÇÃO
dimensões em mmdimensões em mm
MAIN PCBMAIN PCB
NOME NOME
DATA DATA MAT.MAT.
APROV. APROV.
15/08/00 15/08/00
MOD. MOD.
N.º N.º
MD-K400MD-K400
IR801
321
SW801
DISC1
SW802
DISC2
SW803
DISC3
SW804
SKIP-RW
SW805
SKIP-FF
SW806
PL/PS
SW807
STOP
SW808
EQUAL
SW809
SURR
SW810
CD
SW811
TAPE
SW812
TUNER
SW813
REC
SW815
OP/CLOSE
SW814
POWER
E801
3 2 1
CNTP9
CN101
JE13
JE12
JE11
JE14
JE08
JE07
JE06
JE15
JE05
JE10
JE04
JE09
JE02
JE01
JE03
JC23
JC19
JC20
JC36
JC39
JC38
JC34
JC42
JC43
JC41
JC40
JC30
JC32
JC12
JC13
JC14
JC09
JC08
JC22
JC02
JC26
JC01
JC44
JC03
JC04
JC05
JC06
JC07
JC15
JC16
JC21
JC25
JC33
JC31
JC18
JC17
JC10
JC11
JC35
OPC
JC37
OPC
JC24JC27
JC28
JC45
JC29
C505
FS502
T-1A-L
FS501
T-500mA-L
FS503
D502
D504
D501
D503
D202
D204
D203
D205
D1902
D1903
D803
D802
D801
D505
D1901
D508
D509
D515
C503
C501
C502
C504
C216
C218
C217
C215
C510
JG05
JG04
JG10
JG11
JG12
JG13
JG14
JG06
JG01
JG02
JG03
JG07
JG08
JG09
TF501
5
1
13
10
8
6
SW501
220V
110V
JE33
JE26
JE25
JE32
JE27
JE31
JE38
JE39
JE28
JE30
JE37
JE40
JE36
JE41
JE29
C213
IC201
6
12 1
C210
C209
C508
C509
C521
C522
C207
C208
CN201
G
G
L
R
JA09
JA08
JA12
JA11
JA04
JA05
JB17
JA02
JA01
JA13
JA14
JA06
JA03
C205
C212
C206
C201
C305
C202
C211
C408
C409
C113
C115
C118
C121
C123
C125
C126
C127
C131
C602
C603
C601
C630
C407
C420
C406
C418
C419
C410
C401
C421
C422
C425
C411
C424
C803
C802
JB13
JB12
JB14
JB07
JB11
JB03
JB01
JB16
JB04
JB05
JB06
JB08
JB02
JB15
JE23
JD25
JD67
JD23
JD14
JD13
JD29
JD22
JD30
JD21
JD31
JD32
JD20
JD38
JD19
JD26
JD24
JD18
JD17
JD33
JD16
JD15
JD34
JD35
JD36
JD27
JD28
JD37
JD39
JE34
JE35
JD46
JD44
JD43
JD42
JD41
JD40
JD47
JD45
JD12
JD11
JD01
JD10
JD09
JD08
JD03
JD02
JD04
JD05
JD06
JD07
JD66
JH02
JH01
JK03
JK02
JK05
JK01
JI02
JI01
Q501
Q602
Q601
Q1910
Q1909
Q502
Q1913
Q1904
Q1903
Q1902
Q1901
D104
D105
D601
D450
D507
D506
C417C416
C402
C403
C404
C415
C405
C414
CF102
SFU450B
IC101
CF103
SFE10.7
D103
K A
D102
K A
L101
RF-FM
L102
OSC-FM
CF104
CDA10.7
T101
OSC-AM
6
4 3
1
T104
FI-AM
6
4 3
1
X101
X601
CF101
T102
65
43
21
33
11
44
34
23
22121
CN602
/TRAY-
/TRAY+
P/CN701-CD
STATUS
SCL
SDA
CDRW/GND
RST-CD
CAR-
CAR+
CAR-POS
CDM-POS
1
9
CN402
LGR
CD
CN507
+5VBG+5VB
CD
CN601
L-OUT
R-OUT
R-REC
L-REC
RECSW
PB1/2
REC
+9V
GND
P/CN901-DECK
28 25 20 15
141051
CABO-REDE
D805
TAPE
D806
TUNER
CN1901
ANO-A
SEN-A
GND
SOL-A
REC-SW
5 1
CN1902
SEN-B
ANO-B
GND
SOL-B
4 1
CN1903
ANO-A
SEN-A
RECSW
GND
SOL-A
M-SWA
6
1
CN1904
SEN-B
ANO-B
GND
SOL-B
M-SWB
6
1
JF01
39
26
14
52
40
27
13
1
VFD801
1
31
L801
L1901
IC503
41
C1902
C511
C518 C513
C512
R501
R530
R531
R1928
CN906
MOTOR
- +
IC1901
VR1901
VR1901
IC501
E
C S
IC502
S
C
E
JG15
JE22
JE21
JE20
JE16
JE17
JE18
JE19
C514
JE24
JD69
JD68
CN401
C413
C412
JC46
D807
CD
JE42
IRIR
GND-MGND-M
GNDGND
GND
GND GND
GND
GND2 GND2
FILB FILB
FILAFILA
+12V +12V
E1B E1B
-VFD-VFD
MOSIMOSI
STBSTB
CLKCLK
M-SWB M-SWB
M-SWA M-SWA
SOL-PLSOL-PL
E1A E1A
SOL-RPSOL-RP
REC-SWREC-SW
MISO MISO
+5V+5V
+5V
+5V+5V
+5V
1.10.52280.02
1.10.52280.02
1.10.52280.02
MDK400
MDK400
MDK400
PCI CONJUNTO
PCI CONJUNTO
FM
GND
8
5
41
MDK400
PCI CONJUNTO
RADIO
VOLUME
PCI CONJUNTO
TÍTULO:
PROJEÇÃO
dimensões em mm
CD PCB
NOME
DATA MAT.
APRO.
15/08/00
N.º
PROJ.
DES.
15/08/00
ACAB.
ESC.
MOD.
TOL.
15/08/00
MD-K400
Q701
C
E
SW704
CN702
1
2
16
15
CN704
1
4
CN703
R732
CN701
R733
D703
D702
D701
M703
IC702
1
28
15
14
M704
C735
Q714
E
C
B
Q713
E
C
B
R734
R735
J704
OPC
J703
OPC
C740
C739
J701
J702
R731
Q712
E
C
B
Q711
E
C
B
Q710
E
C
B
Q709
E
C
B
Q708
E
C
B
Q707
E
C
B
Q706
E
C
B
Q705
E
C
B
C741
Q703
C
E
Q702
C
E
J1
J3
OPC
C744
C743
C742
C738
C734
C733
C732
C731
C730
C729
C728
C727
C726
C725
C724
C723
C722
C721
C720
C719
C718
C717
C716
C715
C714
C713
C712
C711
C710
C709
C708
C707
C706
C705
C704
C703
C702
C701
R730
R729
R728
R727
R726
R725
R724
R723
R722
R721
R720
R719
R718
R717
R716
R715
R714
R713
R712
R711
R710
R709
R708
R707
R706
R705
R704
R703
R702
R701
IC701
80
61
60
41
40
21
20
1
J4
OPC
C736
J2
52284.03
6V
13
1
GND
TRAYSW
CDMPOS
CARPOS
CAR+
CAR-
RESET
SDA
SCL
STATUS
R
G
L
GND
TRAY-
TRAY+
CAR-
CAR+
CDMPOS
GND
CARPOS
TRAYSW
TÍTULO:
PROJEÇÃO
dimensões em mm
CD PCB
NOME
DATA MAT.
APRO.
15/08/00
N.º
PROJ.
DES.
15/08/00
ACAB.
ESC.
MOD.
TOL.
15/08/00
MD-K400
Q701
C
B
E
SW704
CN702
1 15
2581116
CN704
CDMPOS
GND
CARPOS
TRAYSW
CN703
CN701
D703
D702
D701
IC702
17814
15 21 22 28
C735
C740
C739
X701
C741
Q703
C
B
E
Q702
C
B
E
C744
C743
C742
C738
C734
C733
C732
C731
C730
C736
52284.03
6V
13
CDMPOS
CARPOS
CAR+
CAR-
RESET
SDA
SCL
STATUS
R
G
L
GND
1
6
GND
TRAYSW
4
1
1 CAR+
CAR-
TRAY+
TRAY-
TÍTULO:
PROJEÇÃO
dimensões em mm
DECK PCB
NOME
DATA MAT.
APRO.
15/08/00
N.º
PROJ.
DES.
15/08/00
ACAB.
ESC.
MOD.
TOL.
15/08/00
MD-K400
TÍTULO:
PROJEÇÃO
dimensões em mm
DECK PCB
NOME
DATA MAT.
APRO.
15/08/00
N.º
PROJ.
DES.
15/08/00
ACAB.
ESC.
MOD.
TOL.
15/08/00
MD-K400
T903
1 3
46
JI05
CN901
L-OUT
R-OUT
R-REC
L-REC
M-P
M-RP
RECSW
PB1/2
REC
+9V
GND
P/CN601-LAT
CN903
MP
MRP
RECSW
G
G
G
JA11
C920
IC901
8 5
41
IC903
85
4 1
IC902
8 5
41
C905
C918
C921
JA04
JC04
JA03
JD01
C933
C951
C919
JC03
JC02
JB01
JC11
JB05
JA10
JC05
JA05
JC07
JC10
JC08
JD02
JC01
JG01
JD03
JA07
JD04
JA09
JI01
JI02
JA06
JC13
JI04
JI03
JB04
C934
JA08
JC12
JC06
CN904
JA01
JF01
JA02
C906
JA12
1.10.52251.03
PCI DECK LOGICO
CN902
CN905
PCI DECK
VCC1/2 GND
TÍTULO:
PROJEÇÃO
dimensões em mm
REMOTE CONTROL PCB
NOME
DATA MAT.
APRO.
15/08/00
N.º
PROJ.
DES.
15/08/00
ACAB.
ESC.
MOD.
TOL.
15/08/00
MD-K400
JV03
JA02
JV01
JA01
C3
Q1
ECB
C4
R2
IC1
1
10
11 20
JV02
R1
C2
TÍTULO:
PROJEÇÃO
dimensões em mm
REMOTE CONTROL PCB
NOME
DATA MAT.
APRO.
15/08/00
N.º
PROJ.
DES.
15/08/00
ACAB.
ESC.
MOD.
TOL.
15/08/00
MD-K400
CLOCKSLEEPTIMER
MEMO DEMO MODE
DISC3
DISC2
DISC1
SURROU
TUNER
MUTE
AUXTAPECD
POWER
EQUAL
PL/PS
SHIFT
DISPLAY STOP
LD1
LOUD
DISC
RC1
C1
52181.03
01 02
03 04 05 06
07
08
10
09
11/so
12 13
14
15
16 17
18 19 20
21 22 23
24 25 26 27
C.REMOTO
UP
DW
V0L-
VOL+
+-
TITULO: CODIGO:
MODELO:
DESENHO N: FOLHA
02A4
ESPECIFICACAO
TECNICA
ESPECIFICACOES GERAIS/ GENERAL SPECIFICATIONS
ITEM DESCRICAO DO TESTE UNID.
ESPECIFICACAO
NOMINAL
1
2
IMPEDANCIA
8.0
3
4
5
CURVA DE IMPEDANCIA
POTENCIA NOMINAL
POTENCIA MAXIMA APLICAVEL
Hz
60 Hz / 10
W10
W15
6
7
8
9
SENSIBILIDADE
dB/W/m
85
ITEM TEST DESCRIPTION
IMPEDANCE
IMPEDANCE CURVE
POWER RATING
UNIT.
SPECIFICATION
MAXIMUN APPLICABLE POWER
SENSIBILITY
ESQUEMA ELETRICO
CL-K400MD
1.58.42234.01
MODELO
IMPED.
RESSON.
COR CONE
PROTETOR
DIAMETRO
SISTEMA
WOOFER MODELO
MIDRANGE MODELO
TWEETER MODELO
RESPOSTA DE FREQUENCIA
FREQUENCY
FREQUENCIA DE CORTE
CUT FREQUENCY
ATUACAO DO DIVISOR DE FREQUENCIA
Hz
Hz
dB/oitava
(+) (-)
ENTRADA
COD: 1.51.09560.43
AF 412WFPS/60D-DF
(-)
WOOFER
(+)
8 OHMS
120 Hz
PRETO
DIFUSOR
4 1/2"
BASS-REFLEX / 1 VIA / 1 ALTO-FALANTE
20 ~ 18000
~
~
120 Hz / 15
PESO 1,60 Kg
10
15%
15%
TITULO: CODIGO:
MODELO:
DESENHO N: FOLHA
01A3
ESPECIFICACAO
CL-K400MD
TECNICA
ESPECIFICACOES MECANICAS/MECHANICAL SPECIFICATIONS
1.58.42234.01
PAINEL FRONTAL
DE BORRACHA
APLICAR ADESIVO
TELA P/ A.FALANTE
654321
A
B
C
D D
C
B
A
123456
CJTO. CABO PAR. 22AWG VM/PT
ETIQUETA DE IMPEDANCIA
CINTA P/ CX. ACÚSTICA
No. VAGOS:
87654321
A
C
D
B
E
12345678
F F
E
D
C
B
A
ESPECIFICACAO
TECNICA
TITULO:
CL-K400MD
1.58.42234.01
MODELO:
CODIGO:
A4
DESENHO N:03FOLHA
ALTO FALANTE 412WFPS/60D-DF
DESCRICAO
CINTA P/ CAIXA ACÚSTICA
CJ. CABO PAR./POL. 22AWG PT/VM C=1500mm TER
PAR. AA. PAN. PH. PP1 3.5x16 ZNP
PAINEL FRONTAL
1.51.09560.41
9
1.58.42180.01
7 8
3
5
1.58.42150.06
1.64.45065.00
4 6 2
1
CODIGONo.
-
1
ACO
1
4
1
-
MADEIRA
PS-AI
1
1
1
MATERIAL QTD
PECA
PECA
PECA
UNIDADE
9
TELA P/ FALANTE
ETIQUETA DE IMPEDANCIA
1.60.00055.27
1.58.42150.05
1
3
5
7
8
2
PECA
PECA
PECA
PECA
1.06.52242.10
1
PECA
EPDM
-
4
1
PECA
10 11
BAFLE DE MADEIRA
TAMPA TRASEIRA
MADEIRA
MADEIRA
6
1.58.42150.07
1.58.42153.04
10
VEDAÇÃO P/ FRONTAL
1.58.42088.13
PS-AI
11
1.67.72411.13
LOGOTIPO DURABRAND
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
