Dukane 8946 User Manual
Liquid Crystal Projector
Models 8805 & 8946
USER'S MANUAL
Important Information
Safety Cautions
Precautions
Please read this manual carefully before using your Dukane 8805/
8946 Projector and keep the manual handy for future reference. Your
serial number is located on the right side of your projector. Record it
here:
CAUTION
To turn off main power, be sure to remove the plug from power
outlet.
The power outlet socket should be installed as near to the
equipment as possible, and should be easily accessible.
CAUTION
TO PREVENT SHOCK, DO NOT OPEN THE CABINET.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol warns the user that uninsulated voltage within the
unit may be sufficient to cause electrical shock. Therefore, it is
dangerous to make any kind of contact with any part inside of
the unit.
This symbol alerts the user that important information concerning the operation and maintenance of this unit has been
provided.
The information should be read carefully to avoid problems.
WARNING
TO PREVENT FIRE OR SHOCK, DO NOT EXPOSE THIS UNIT TO
RAIN OR MOISTURE.
DO NOT USE THIS UNIT’S GROUNDED PLUG WITH AN EXTENSION CORD OR IN AN OUTLET UNLESS ALL THE PRONGS CAN
BE FULLY INSERTED.
DO NOT OPEN THE CABINET. THERE ARE HIGH-VOLTAGE COMPONENTS INSIDE. ALL SERVICING MUST BE DONE BY QUALIFIED DUKANE SERVICE PERSONNEL.
DOC Compliance Notice
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
Acoustic Noise Information Ordinance-3. GSGV:
The sound pressure level is less than 70 dB (A) according
to ISO 3744 or ISO 7779.
This label is on the side of the remote control.
CAUTION
Do not look into the laser pointer while it is on and do not
point the laser beam at a person. Serious injury could result.
RF Interference
WARNING
The Federal Communications Commission does not allow any
modifications or changes to the unit EXCEPT those specified
by Dukane Corporation AV Division in this manual. Failure to comply with this government regulation could void your right to
operate this equipment. This equipment has been tested and
found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for
help.
In UK, a BS approved power cable with moulded plug has a Black (five
Amps) fuse installed for use with this equipment. If a power cable is not
supplied with this equipment please contact your supplier.
Important Safeguards
These safety instructions are to ensure the long life of your projector
and to prevent fire and shock. Please read them carefully and heed all
warnings.
Installation
1. For best results, use your projector in a darkened room.
2. Place the projector on a flat, level surface in a dry area away from
dust and moisture.
To avoid premature lamp failure, do not tilt the front of the projector
up or down by more than 75° from level. Tilting the front of the projector up or down from 15° to 75° might reduce lamp life by up to
25%.
3. Do not place your projector in direct sunlight, near heaters or heat
radiating appliances.
4. Exposure to direct sunlight, smoke or steam can harm internal components.
5. Handle your projector carefully. Dropping or jarring can damage internal components.
6. Do not place heavy objects on top of the projector.
7. If you wish to have the projector installed on the ceiling:
a. Do not attempt to install the projector yourself.
b. The projector must be installed by qualified technicians in order
to ensure proper operation and reduce the risk of bodily injury.
c. In addition, the ceiling must be strong enough to support the
projector and the installation must be in accordance with any
local building codes.
d. Please consult your dealer for more information.
WARNING TO CALIFORNIA RESIDENTS:
Handling the cables supplied with this product, will expose you to
lead, a chemical known to the State of California to cause birth defects or other reproductive harm. Wash hands after handling.
E-2
Fire and Shock Precautions
1. Ensure that there is sufficient ventilation and that vents are unobstructed to prevent the build-up of heat inside your projector. Allow
at least 4 inches (10 cm) of space between your projector and a
wall.
2. Prevent foreign objects such as paper clips and bits of paper from
falling into your projector.
Do not attempt to retrieve any objects that might fall into your projector. Do not insert any metal objects such as a wire or screwdriver
into your projector. If something should fall into your projector, disconnect it immediately and have the object removed by a qualified
Dukane service personnel.
3. Do not place any liquids on top of your projector.
4. Do not look into the lens while the projector is on. Serious damage
to your eyes could result.
5. Keep any items such as magnifying glass out of the light path of the
projector. The light being projected from the lens is extensive, therefore any kind of abnormal objects that can redirect light coming out
of the lens, can cause unpredictable outcome such as fire or injury
to the eyes.
6. Do not cover the lens with the supplied lens cap or equivalent while
the projector is on. Doing so can lead to melting of the cap and
possibly burning your hands due to the heat emitted from the light
output.
7. The projector is designed to operate on a power supply of 100-240
V 50/60 Hz AC. Ensure that your power supply fits this requirement
before attempting to use your projector.
8. Handle the power cable carefully and avoid excessive bending.
A damaged cord can cause electric shock or fire.
9. If the projector is not to be used for an extended period of time,
disconnect the plug from the power outlet.
10. Do not touch the power plug during a thunderstorm. Doing so can
cause electrical shock or fire.
• Allow a minimum of 90 seconds to elapse after turning off the projector. Then turn off the main power switch, disconnect the power
cable and allow 60 minutes to cool the projector before replacing
the lamp.
What's in the Box?
Make sure your box contains everything listed. If any pieces are missing, contact your dealer.
Please save the original box and packing materials if you ever need to
ship your 8805/8946 Projector.
Lens cap
PJ
ASPECT
FREEZE
HELP
3D REFORM
VOLUME
PO
INTER
PIC
M
AG
-M
NIFY
UTE
SLIDE
ZOOM
FOCUS
FO
LDER
SLIDE
LIST
Remote control
(7N900363)
Projector
OFF
VIDEO
A
U
T
O
POWER
A
D
J.
RGB
ON
VIEWER
LASER
SELECT
Batteries
Remote Control Cable
(7N520019)
String (24C05051) and
rivet (24C04531)
CAUTION
1. Do not try to touch the ventilation outlet on the front as it can become heated while the projector is turned on.
2. Do no use the tilt-foot for purposes other than originally intended.
Misuses such as gripping the tilt-foot or hanging on the wall can
cause damage to the projector.
3. Enable High-Speed Fan mode if you continue to use the projector
for consecutive days. (From the Advanced menu, select [Projector
Options] → [Setup] → [Page 4] → [High Speed Fan Mode].)
4. Do not unplug the power cable from the wall outlet under any one of
the following circumstances.
Doing so can cause damage to the projector:
* While the Hour Glass icon appears.
* While the message "Please wait a moment." appears. This mes-
sage will be displayed after the projector is turned off.
* While the cooling fans are running. (The cooling fans continue to
work for 90 seconds after the projector is turned off).
5. Do not eject the PC card or LAN card while its data is being accessed.
Doing so can damage your PC card or LAN card data.
6. Do not hold the lens part with your fingers. Doing so could pinch
fingers or hands causing injury.
Lamp Replacement
•To replace the lamp, follow all instructions provided on page E-55.
• Be sure to replace the lamp when the message "The lamp has
reached the end of its usable life. Please replace the lamp."
appears. If you continue to use the lamp after the lamp has reached
the end of its usable life, the lamp bulb may shatter, and pieces of
glass may be scattered in the lamp case. Do not touch them as the
pieces of glass may cause injury.
If this happens, contact your Dukane dealer for lamp replacement.
Power cable
(US: 7N080204)
(EU: 7N080008)
User's
Manual
Guide
For North America only
Registration card
Limited warranty
For Europe only
Guarantee policy
USB cable
(7N520013)
Quick
Connect
8805 only
USB mouse (7N960151)
RGB signal cable
(7N520032)
CD-ROM
Projector User Supportware
(7N950432)
E-3
TABLE OF CONTENTS
Important Information ..................................................... E-2
Safety Cautions ............................................................................................................... E-2
What's in the Box? .......................................................................................................... E-3
INTRODUCTION .............................................................. E-5
Introduction to the Projector ........................................................................................... E-5
Part Names of the Projector ............................................................................................ E-6
Attaching the lens cap ................................................................................................. E-6
Carrying the Projector ................................................................................................. E-6
Top Features ................................................................................................................ E-7
Terminal Panel Features ............................................................................................... E-8
Part Names of the Remote Control .............................................................................. E-9
Battery Installation ................................................................................................. E-11
Remote Control Precautions .................................................................................. E-11
Operating Range for Wireless Remote Control ...................................................... E-11
Using the Remote Control in Wired Operation ....................................................... E-11
INSTALLATION AND CONNECTIONS ....................................... E-12
Setting Up the Screen and the Projector ....................................................................... E-12
Selecting a Location .................................................................................................. E-12
Throw Distance and Screen Size ............................................................................... E-13
Making Connections ...................................................................................................... E-14
When Viewing a DVI Digital Signal ............................................................................ E-14
Connecting Your PC or Macintosh Computer ............................................................ E-14
To connect SCART output (RGB) ............................................................................... E-15
Connecting an External Monitor ................................................................................ E-15
Connecting Your DVD Player ..................................................................................... E-16
Connecting Your VCR or Laser Disc Player ............................................................... E-17
Connecting the Supplied Power Cable ....................................................................... E-17
PROJECTING AN IMAGE (BASIC OPERATION) ........................... E-18
Tur ning on the Projector ................................................................................................ E-18
Selecting a Source ......................................................................................................... E-19
Adjusting the Picture Size and Position ......................................................................... E-19
Correcting the Horizontal and Vertical Keystone Distortion (3D Reform) ...................... E-20
Optimizing RGB Picture Automatically .......................................................................... E-22
Tur ning Up or Down Volume ......................................................................................... E-22
Using the Laser Pointer ................................................................................................. E-22
Setting the function switch ............................................................................................ E-23
Tur ning off the Projector ............................................................................................... E-23
CONVENIENT FEATURES................................................... E-24
Using the Remote Mouse Function ............................................................................... E-24
Connecting to your computer for the remote mouse function ................................... E-24
When using the USB Port .......................................................................................... E-24
Switching operation mode between computer and projector ..................................... E-24
Auto 3D Reform ............................................................................................................ E-25
Tur ning Off the Image and Sound .................................................................................. E-27
Freezing a Picture .......................................................................................................... E-27
Using a Pointer .............................................................................................................. E-27
Enlarging and Moving a Picture ..................................................................................... E-27
Getting the On-line Help ................................................................................................ E-27
Using a USB Mouse ...................................................................................................... E-28
Using the USB HUB Function ........................................................................................ E-28
Changing Background Logo .......................................................................................... E-29
Making Freehand Drawings on a Projected Image (ChalkBoard) ................................... E-29
USB Memory Device or USB Memory Card Reader Support ......................................... E-29
USING THE VIEWER ........................................................ E-30
Making the Most out of the Viewer Function ................................................................. E-30
Operating the Viewer Function from the Projector (playback) ....................................... E-31
Projecting slides (Viewer) .......................................................................................... E-31
Auto Play Mode ......................................................................................................... E-32
Switching to Slides Directly from Other Input Modes ................................................ E-32
Viewing Digital Images .............................................................................................. E-32
Storing Images Displayed on the Projector on the PC card (Capture) ....................... E-32
Deleting Captured Images ......................................................................................... E-33
Using the PC Card Files Fucntion (PC Card Files) ...................................................... E-33
USING ON-SCREEN MENU ................................................. E-34
Basic Menu Operation ................................................................................................... E-34
Using the Menus ....................................................................................................... E-34
Customizing the Menu ............................................................................................... E-34
Menu tree ...................................................................................................................... E-35
Menu Elements ............................................................................................................. E-38
Entering Alphanumeric Characters by Using the Menu .............................................. E-39
Menu Descriptions & Functions .................................................................................... E-39
Source Select ............................................................................................................ E-39
RGB/Video/S-Video/DVI (DIGITAL)/Viewer/LAN/Entry List
Picture ....................................................................................................................... E-40
Sound ........................................................................................................................ E-40
Image Options ........................................................................................................... E-40
Selecting Aspect Ratio ........................................................................................... E-40
Masking Unwanted Area (Blanking) ....................................................................... E-41
Adjusting Position and Clock ................................................................................. E-41
Selecting Resolution .............................................................................................. E-41
Selecting Overscan Percentage .............................................................................. E-41
Selecting Video Filter Level .................................................................................... E-41
Selecting Noise Reduction Level ............................................................................ E-41
Signal Type ............................................................................................................ E-41
Picture Management .................................................................................................. E-41
User Adjust (when using User 1 to 4) .................................................................... E-41
Selecting Gamma Correction Mode ................................................................ E-42
Selecting Color Correction ............................................................................. E-42
Adjusting Color Temperature and White Balance ............................................ E-42
Selecting Base Setting .................................................................................... E-42
Projector Options ...................................................................................................... E-42
Using 3D Reform ................................................................................................... E-42
Cornerstone ................................................................................................... E-42
Keystone ........................................................................................................ E-42
Using Adapting Color Correction ........................................................................... E-43
Menu [Page1] ........................................................................................................ E-45
Selecting Menu Language/Selecting Menu Mode/Customizing the Menu/Select-
ing Projecting Pointer Icon & Mouse Icon/Selecting Menu Display Time
Menu [Page 2] ....................................................................................................... E-45
Turning On/Off Source Display / Turning On/Off Message / Selecting Menu Color
Setup [Page 1] ....................................................................................................... E-46
Selecting Projector Orientation/Selecting a Color or Logo for Background/Setting
RGB 1 or 2 for RGB OUT/Setting Closed Caption
Setup [Page 2] ....................................................................................................... E-46
Setting Viewer Options/Selecting Capture Options/Setting Mouse Button and Sen-
sitivity/Selecting Operation Mode
Setup [Page 3] ....................................................................................................... E-47
Selecting Signal Format [Signal Select]
Setup [Page 4] ....................................................................................................... E-47
Enabling Auto Adjust/Enabling Auto Start/Enabling Power Management/Enabling
Power Off Confirmation/Enabling Horizontal and Vertical Keystone Correction Save
/Enabling High Speed Fan Mode/Selecting Built-in Speakers/Enabling Idle Mode/
Resetting the Filter Usage Hours
Setup [Page 5] ....................................................................................................... E-48
Remote Sensor/S-Video Mode Select
Setup [Page 6] ....................................................................................................... E-48
Selecting Communication Speed/Selecting Default Source/Disabling the Cabinet
Buttons
Selecting Lamp Mode and Lamp Type ................................................................... E-48
Selecting Aspect Ratio and Position for Screen ..................................................... E-49
Selecting Auto Functions ....................................................................................... E-49
Setting LAN Mode ..................................................................................................... E-50
IP Address ............................................................................................................. E-50
Network Type ......................................................................................................... E-50
WEP ....................................................................................................................... E-51
Mail ........................................................................................................................ E-51
Status .................................................................................................................... E-52
Setting a Password .................................................................................................... E-52
Security ..................................................................................................................... E-53
Tools .......................................................................................................................... E-54
Using Sleep Timer/Using Capture/Using PC Card Files/Using ChalkBoard
Help ........................................................................................................................... E-54
Contents ................................................................................................................ E-54
Information ............................................................................................................ E-54
Returning to Factory Default ...................................................................................... E-54
MAINTENANCE ............................................................. E-55
Replacing the Lamp ...................................................................................................... E-55
Cleaning ........................................................................................................................ E-56
Cleaning or Replacing the Filter ................................................................................. E-56
Cleaning the Cabinet and the Lens ............................................................................. E-56
TROUBLESHOOTING ........................................................ E-57
Power Indicator ............................................................................................................. E-57
Status Indicator ............................................................................................................. E-57
Lamp Indicator .............................................................................................................. E-57
Common Problems & Solutions .................................................................................... E-58
SPECIFICATIONS ........................................................... E-60
APPENDIX ................................................................... E-62
Cabinet Dimensions ...................................................................................................... E-62
Pin Assignments of D-Sub RGB Input Connector .......................................................... E-62
Compatible Input Signal List ......................................................................................... E-63
PC Control Codes and Cable Connection ....................................................................... E-64
PC Control Connector (D-SUB 9P) ................................................................................ E-64
Using Software Keyboard .............................................................................................. E-64
Operation Using an HTTP Browser ................................................................................ E-65
TravelCare Guide ........................................................................................................... E-66
E-4
INTRODUCTION
Introduction to the Projector
This section introduces you to your new 8805/8946 Projector and
describes the features and controls.
Congratulations on Your Purchase of The 8946/
8805 Projector
The 8805/8946 is one of the very best projectors available today.
The 8805/8946 enables you to project precise images up to 500
inches across (measured diagonally) from your PC or Macintosh computer (desktop or notebook), VCR, DVD player, document camera, a
laser disc player or Viewer.
You can use the projector on a tabletop or cart, you can use the projector to project images from behind the screen, and the projector can be
permanently mounted on a ceiling*1. The remote control can be used
wirelessly.
*1Do not attempt to mount the projector on a ceiling yourself.
The projector must be installed by qualified technicians in order
to ensure proper operation and reduce the risk of bodily injury.
In addition, the ceiling must be strong enough to support the projector and the installation must be in accordance with any local
building codes. Please consult your dealer for more information.
Features you'll enjoy:
• 3D Reform enhanced keystone correction that allows not only horizontal and vertical access but diagonal adjustments.
2
• Wireless*
presentation delivery.
• Safety protect by Password and Security functions
Password and Security features prevent the projector from being used
by unauthorized individuals.
Password prevents unauthorized individuals from changing projector
settings or adjustments. Security offers complete protection by using
your PC card as a protect key so that the projector will not project a
signal without insertion of the registered PC card and unauthorized
use can be discouraged.
• Picture Management enables users to adjust individual color settings
to their preferences.
• Eco-mode extends lamp life and reduces total cost of ownership.
Standard lamp and optional longer life lamp
•Power zoom and power focus standard lens provide easy adjustment.
•Automatic lens focus provides extreme ease of use
•Automatic Wall Color Correction allows for quick adaptive color correction on textured or painted walls and in applications where the
display is other than screen material. With the built-in image sensor,
the projector adjusts the colors for screen sizes between 40" and
150" diagonally.
•Variable audio out control via projector
• The built-in Viewer allows you to start your presentation even when a
PC is not available at the site.
•A high-bright 300 watt DC lamp (240W Eco mode). (8946)
A high-bright 275 watt DC lamp (220W Eco mode). (8805)
• The Standby mode reduces standby power consumption significantly.
• The supplied wireless remote control that operates the projector from
any angle.
• The image can be projected between 25 and 500 inches (measured
diagonally).
• The "Capture" enables you to capture the current projected image.
• An image can be projected from in front or behind a screen, and the
projector can even be installed on the ceiling.
or wired networking access provides easy and effective
2
*
A wireless LAN card is required. The optional wireless LAN
card is available. (SWL-2100N-N
)
∗
• Exclusive Advanced AccuBlend intelligent pixel blending tech-
nology - an extremely accurate image compression technology - offers a crisp image with UXGA (1600⳯1200) resolution*
• Supports most IBM VGA, SVGA, XGA, SXGA/UXGA(with Advanced
AccuBlend)*
other RGB signals within a horizontal frequency range of 24 to 100
kHz and a vertical frequency range of 48 to 120 Hz. This includes
NTSC, PAL, PAL-N, PAL-M, PAL60, SECAM and NTSC4.43 standard video signals.
3
*
3
, Macintosh, component signal (YCbCr/ YPbPr) or any
A UXGA (1600⳯1200) and SXGA (1280⳯1024) image are displayed with Advanced AccuBlend.
3
.
NOTE: Composite video standards are as follows:
NTSC: U.S. TV standard for video in U.S. and Canada.
PAL: TV standard used in Western Europe.
PAL-N: TV standard used in Argentine, Paraguay and Uruguay.
PAL-M: TV standard used in Brazil.
PAL60: TV standard used for NTSC playback on PAL TVs.
SECAM: TV standard used in France and Eastern Europe.
NTSC4.43: TV standard used in Middle East countries.
• The supplied remote control can be used without a cable, and you
can even use the remote control to operate your PC's mouse wirelessly
from across the room with the built-in remote mouse function.
•You can control the projector with a PC using the PC Control port.
• USB port allows USB mouse operation*
4
The USB ports meet the USB1.1 specification.
*
• The contemporary cabinet design is light, compact, easy to carry,
and complements any office, boardroom or auditorium.
• Nine pointers are available for your presentation.
4
.
About this user's manual
The fastest way to get started is to take your time and do everything right the first time. Take a few minutes now to review
the user's manual. This may save you time later on. At the beginning of each section of the manual you'll find an overview. If
the section doesn't apply, you can skip it.
E-5
Part Names of the Projector
Controls (See page E-7)
Remote Sensor (See page E-11 and -48)
Built-in Security Slot ( )*
Ventilation (inlet)
Carrying Handle
Adjustable Tilt Foot Lever
(See page E-19)
Ventilation (outlet)
Heated air is exhausted from here
Adjustable Tilt Foot (See page E-19)
* This security slot supports the MicroSaver® Security System. MicroSaver® is a registered trademark of Kensington Microware Inc. The logo is
trademarked and owned by Kensington Microware Inc.
Lamp Cover (See page E-55)
Remote Sensor (See page E-11 and -48)
Image Sensor
For Auto Focus and Auto Wall Color
Correction. (See page E-49)
Lens
Adjustable Tilt Foot Lever
(See page E-19)
Adjustable Tilt Foot
(See page E-19)
Lens Cap
PC Card Slot 1
PC Card Slot 2
Filter Cover (inlet)
IO
D
U
A
N
I
I
V
/C
D
B
/Y
G
IO
D
U
Remote Sensor
(See page E-11 and -48)
A
N
I
2
B
G
R
IN
1
B
G
R
IO
D
U
A
R
O
L/MON
IO
D
U
A
N
I
O
E
D
I
V
S
Stereo Speaker (5W)
Main Power Switch
When you plug the supplied power cable into
an active wall outlet and turn on the Main
Power switch, the POWER indicator turns
orange and the projector is in standby mode.
(See page E-18)
Attaching the lens cap
To attach the lens cap to the bottom with the supplied string and rivet:
1. Thread the string through the
hole on the lens cap and then
tie a knot in the string.
2. Use the rivet to attach the
string to the bottom of the
projector.
Remote Sensor (See page E-11 and -48)
R
L
O
R
T
N
O
C
C
P
)
R
B
U
/H
E
S
U
O
O
(
N
M
O
B
S
/M
L
U
IO
D
U
A
V
H
T
U
O
b
IO
D
U
A
T
U
O
B
G
R
U
A
L/MONO
IO
D
U
A
N
I
O
E
D
I
V
AC IN
IO
D
R
PC Card Eject Button
1
2
E
T
O
EM
AC Input
Connect the supplied power cable's threepin plug here, and plug the other end into
an active wall outlet. (See page E-17)
Carrying the Projector
Always carry your projector by the handle.
Ensure that the power cable and any other cables connecting to video
sources are disconnected before moving the projector.
When moving the projector or when it is not in use, cover the lens with
the lens cap.
E-6
Top Features
11 10 9 8
5 6
4
3
2
1412 13
1. POWER Button (ON / STAND BY)( )
Use this button to turn the power on and off when the main power is
supplied and the projector is in standby mode.
NOTE: To turn on or off the projector, press and hold this button for a minimum of two seconds.
2. POWER Indicator
When this indicator is green, the projector is on; when this indicator
is orange, it is in standby or idle mode. See the Power Indicator section on page E-57 for more details.
3. STATUS Indicator
If this light blinks red rapidly, it indicates that an error has occurred,
the lamp cover is not attached properly or the projector has overheated. If this light remains orange, it indicates that you have pressed
a cabinet key while the Control Panel Key Lock is enabled. See the
Status Indicator section on page E-57 for more details.
4. LAMP Indicator
If this light blinks red rapidly, it's warning you that the lamp has reached
the end of its usable life. After this light appears, replace the lamp as
soon as possible (See page E-55). If this is lit green continually, it
indicates that the lamp mode is set to Eco. See the Lamp Indicator
section on page E-57 for more details.
5. SOURCE Button
Use this button to select a video source such as a PC, VCR, DVD
player, Viewer (PC card), or LAN.
Press and release this button quickly to display the Source List.
Each time this button is pressed for a minimum of ONE second, the
input source will change as follows:
RGB1 → RGB2 → Video → S-Video → DVI (DIGITAL) → Viewer → RGB1 → ...
If no input signal is present, the input will be skipped.
6. AUTO ADJUST Button
Use this button to adjust Position-H/V and Pixel Clock/Phase for an
optimal picture (See page E-22). Also press and hold this button for a
minimum of 2 seconds to enable the Auto Focus or Auto Wall Color
Correction function (See page E-49).
7. 3D REFORM Button
Press this button to enter 3D Reform mode to correct the keystone
(trapezoidal) distortion, and make the image square.
8. ZOOM Button (+/–)
Zoom the lens in and out.
9. FOCUS Button (+/–)
Adjust the lens focus.
10. MENU Button
Displays the menu.
17
11. SELECT (+) (–) / Volume Buttons
: Use these buttons to select the menu of the item you wish to
adjust. When no menus appear, these buttons work as a volume control.
: Use these buttons to change the level of a selected menu item.
A press of the button executes the selection. When the menus
or the Viewer tool bar is not displayed, these buttons can be
used to select a slide, or to move the cursor in Folder List or
Slide List.
When the pointer is displayed, these buttons move the pointer.
12. ENTER Button
Executes your menu selection and activates items selected from the
menu.
13. CANCEL Button
Press this button to exit "Menus". Press this button to return the adjustments to the last condition while you are in the adjustment or
setting menu.
14. PC CARD Access Indicator 1/2
Lights while accessing a PC card.
E-7
Terminal Panel Features
891013 12
3
2
1
5
1. RGB1 IN / Component Input Connector (Mini D-Sub 15 Pin)
Connect your computer or other analog RGB equipment such as IBM
compatible or Macintosh computers. Use the supplied RGB cable to
connect to your computer. This also serves as a component input
connector that allows you to connect a component video output of
component equipment such as a DVD player. This connector also
supports SCART output signal. See page E-15 for more details.
RGB1 AUDIO Input Mini Jack (Stereo Mini)
This is where you connect the audio output from your computer or
DVD player when connected to the RGB1 input. A commercially available audio cable is required.
2. RGB2 IN / Component Input Connectors (BNC)
Connect R,G,B,H (Horizontal sync) and V (Vertical sync) outputs of
external equipment.
If using a component with a combined sync (SYNC) output, connect
it to the H/V terminal.
When using luminance and color-difference signals of HDTV and DVD,
connect Pr/Cr to the R,Y to the G and Pb/Cb to the B input of the
projector.
NOTE: The RGB IN 2 does not support Plug & Play.
RGB2 AUDIO IN Mini Jack (Stereo Mini)
This is where you connect audio output from your computer or DVD
player connected to the RGB2 input. A commercially available audio
cable is required.
3. DVI IN Connector (24 pin)
This connector can be used to accept a digital signal output from a
computer or other sources with a DVI connector.
DVI AUDIO Input Mini Jack (Stereo Mini)
This is where you connect the audio output from your computer when
connected to the DVI input. A commercially available audio cable is
required.
4. RGB OUT Connector (Mini D-Sub 15 Pin)
You can use this connector to loop your computer image to an external monitor from the RGB 1 or 2 input source.
The RGB analog signal set on RGBOUT Terminal is output during
idle mode. See pages E-15 and -46.
RGB AUDIO OUT Mini Jack (Stereo Mini)
Connect an additional audio equipment here to listen to audio coming from your computer connected to RGB1, RGB2 or DVI input.
Note that there is no audio output from this jack during Standby and
Idle.
4
6
711
5. S-VIDEO IN Connector (Mini DIN 4 Pin)
Here is where you connect the S-Video input from an external source
like a VCR.
NOTE: S-Video provides more vivid color and higher resolution than the traditional composite video format.
S-VIDEO AUDIO Input Jacks R/L (RCA)
These are your left and right channel audio inputs for stereo sound
from an S-Video source.
6. VIDEO IN Connector (RCA)
Connect a VCR, DVD player, laser disc player, or document camera
here to project video.
VIDEO AUDIO Input Jacks R/L (RCA)
These are your left and right channel audio inputs for stereo sound
from a Video source.
7. AUDIO OUT Jacks R/L (RCA)
You can use this connector to output sound from the currently selected input source (RGB 1, RGB 2, DVI (DIGITAL), Video or S-Video).
Output sound level can be adjusted in accordance with the sound
level of the internal speaker.
8. USB Port (MOUSE/HUB) [Type A]
Connect a USB mouse. You can operate the menu or Viewer with the
USB mouse via this port.
•A USB-supported scanner or PC peripheral can be connected
to this port. (USB Hub Function)
9. USB Port (PC) [Type B]
Connect this port to the USB port (type A) of your PC using the supplied USB cable. You can operate your computer's mouse functions
from the remote control. This port also ser ves as a PC Control port
by using Dynamic Image Utility 2.0 included on the supplied CDROM.
10. REMOTE (Mini Jack)
Connect your remote control cable here for wired operation.
11. PC CONTROL Port (D-Sub 9 Pin)
Use this port to connect your PC to control your projector via a serial
cable. This enables you to use your PC and serial communication
protocol to control the projector. A commercially available RS232C
cross cable is required to use this port. You can also control the projector by using Dynamic Image Utility 2.0 included on the supplied
CD-ROM.
To do so you must first have Dynamic Image Utility 2.0 installed on
your PC. If you are writing your own program, typical PC control codes
are on page E-64.
12. PC CARD Slot 1/2
Insert a PC card, commercially available LAN card or optional
wireless LAN card here.
There are two slots: Slot 1 and Slot 2.
NOTE: A dummy card is inserted into each slot at the time of shipment. First
remove the dummy cards before use.
13. PC CARD Eject Button 1/2
Press to eject a PC card partially. Each slot has its own eject button:
1 and 2.
E-8
Part Names of the Remote Control
FR
P
E
NOTE: If you are using a Macintosh computer, you can click either the right-click
or left-click button to activate the mouse.
1. Infrared Transmitter
Direct the remote control toward
the remote sensor on the projector cabinet.
2. LASER Pointer
Beams a laser light when the LASER button is pressed.
LASER
ER
VIEW
RGB
ON
ER
POW
VIDEO
OFF
AUTO ADJ.
SELECT
J
P
3. Remote Jack
Connect your remote control
cable here for wired operation.
3
1
2
4
6
OFF
POWER
N
E
U
M
RGB VIEWER
VIDEO
AUTO ADJ.
ON
LASER
5
8
97
1110
12
SELECT
E
N
T
E
R
E
C
N
A
C
PJ
21
17
20
ASPECT
VOLUME MAGNIFY
HELP
FREEZE
POINTER
3D REFORM
PIC-MUTE
SLIDE
23
24
25
26
4. LED
Flashes when any button is pressed.
5. POWER ON Button
When the main power is on, you can use this button to turn your
projector on.
NOTE: To turn on the projector, press and hold the POWER ON button for a
minimum of two seconds.
6. POWER OFF Button
You can use this button to turn your projector off.
NOTE: To turn off the projector, press and hold the POWER OFF button for a
minimum of two seconds.
7. VIDEO Button
Press this button to toggle between Video and S-Video inputs.
8. RGB Button
Press this button to select RGB 1, RGB 2 or DVI (DIGITAL) inputs.
Each time this button is pressed, the input source will change as
follows:
RGB 1 → RGB 2 → DVI (DIGITAL) → RGB 1 → ...
ZOOM
FOCUS
FOLDER
SLIDE
LIST
13
1514
L
16
18
19
22
27
28
29
9. VIEWER Button
Press this button to select the Viewer source.
10. AUTO ADJ Button
Use this button to adjust an RGB source for an optimal picture. Also
press and hold this button for a minimum of 2 seconds to enable the
Auto Focus or Auto Wall Color Correction function. See page E-20 or
TE
U
IC-M
3D REFORM
E
-22.
Z
EE
11. LASER Button
Press and hold this button to activate the laser pointer. When lit, you
can use the laser to draw your audience's attention to a red dot that
you can place on any object.
12. MENU Button
Displays the menu for various settings and adjustments.
13. SELECT (Mouse) Button
When you are in the Computer mode, these buttons work as a computer mouse.
When you are in the Projector mode, which is indicated by lighting
the PJ button. See page E-24.
: Use these buttons to select the menu of the item you wish
to adjust.
: Use these buttons to change the level of a selected menu
item. A press of the button executes the selection.
When the pointer is displayed, these buttons move the pointer.
When the pointer is not displayed, these buttons are for adjust-
ing the image.
14. ENTER (Left Click) Button
When you are in the Computer mode, this button works as the mouse
left button. When this button is pressed and held for a minimum of 2
seconds, the drag mode is set. When you are in the Projector mode,
which is indicated by lighting the PJ button: Use this button to enter
your menu selection. It works the same way as the ENTER button on
the cabinet. See page E-7.
15. CANCEL (Right Click) Button
When you are in the Computer mode, this button works as the mouse
right button. When you are in the Projector mode, which is indicated
by lighting the PJ button: Press this button to exit the Menus. It works
the same way as the CANCEL button on the cabinet. See page E-7.
16. PJ Button
Press this button to switch the SELECT, CANCEL, and ENTER buttons between the Projector mode (lit red) and the Computer mode.
Press this button or any one of the POWER ON/OFF, MENU, ASPECT, 3D REFORM, HELP, POINTER, MAGNIFY, VIEWER, FOLDER
LIST or SLIDE LIST buttons to switch to the Projector mode and the
PJ button lights red. To switch back to the Computer mode, press the
PJ button again. See page E-24.
17. ASPECT Button
Press this button to display the Aspect Ratio select screen. See page
E-40.
18. FREEZE Button
This button will freeze a picture. Press again to resume motion.
19. 3D REFORM Button
Press this button to enter 3D Reform to correct the keystone (trapezoidal) distortion, and make the image square. See page E-20.
20. HELP Button
Provides the online help or the set information.
21. POINTER Button
Press this button to display one of the nine pointers; press again to
hide the pointer. You can move your pointer icon to the area you want
on the screen using the Select button. See page E-27.
E-9
4
6
OFF
POWER
N
E
U
M
RGB VIEWER
VIDEO
AUTO ADJ.
ON
LASER
5
8
97
1110
12
SELECT
E
N
T
E
R
E
C
N
A
C
PJ
21
17
20
ASPECT
VOLUME MAGNIFY
HELP
FREEZE
POINTER
3D REFORM
PIC-MUTE
SLIDE
23
24
25
26
22. PICTURE MUTE Button
This button turns off the image and sound for a short period of time.
Press again to restore the image and sound.
NOTE: When the menu is displayed, a press of this button mutes an image
and sound without turning off the menu.
23. VOLUME (+)(–) Button
Press (+) to increase the volume and (–) to decrease it.
24. MAGNIFY (+)(–) Button
Use this button to adjust the image size up to 400%. When the pointer
is displayed, the image is magnified about the center of the pointer.
When the image is magnified, the pointer is changed to the magnifying icon.
When the pointer is not displayed, the image is magnified about the
center of the screen. See page E-27.
25. ZOOM (+)(–) Button
Zoom the lens in and out.
26. FOCUS (+)(–) Button
Adjust the lens focus.
27. SLIDE (+)(–) Button
Press (+) to select the next folder or slide and (–) to select the previous folder or slide. See page E-31.
28. FOLDER LIST Button
Press this button to select Viewer source to display a list of folders
included in a PC card. See page E-31.
29. SLIDE LIST Button
Press this button to select Viewer source to display a list of slides
included in a PC card. See page E-31.
ZOOM
FOCUS
FOLDER
SLIDE
LIST
13
1514
L
16
18
19
22
27
28
29
NOTE: The default is the Computer mode, which allows you to use the SELECT,
CANCEL, and ENTER buttons as your computer mouse. When the POWER ON/
OFF, MENU, ASPECT, 3D REFORM, HELP, POINTER, MAGNIFY, VIEWER, FOLDER
LIST, or SLIDE LIST button is pressed, the PJ button lights red to indicate that
you are in the Projector mode. If no buttons are pressed within 60 seconds, the
light goes out and the Projector mode is canceled.
E-10
Battery Installation
1. Press firmly and slide the battery cover off.
Remote Control Precautions
• Handle the remote control carefully.
• If the remote control gets wet, wipe it dry immediately.
•Avoid excessive heat and humidity.
• If you will not be using the remote control for a long time, remove the
batteries.
• Do not place the batteries upside down.
• Do not use new and old batteries together, or use different types of
batteries together
2. Remove both old batteries and install new ones (AA). Ensure that
you have the batteries' polarity (+/-) aligned correctly.
3. Slip the cover back over the batteries until it snaps into place. Do not
mix different types of batteries or new and old batteries.
Note on Remote Control Operation:
If you press and hold the SELECT button while installing new
batteries, the remote control may fail to work properly.
Should this happen, remove the batteries and then install them again
without touching the SELECT button.
Operating Range for Wireless Remote Control
Remote sensor on the
projector cabinet
7m/22 feet
7m/22 feet
Remote control
Remote sensor on the
projector cabinet
• The infrared signal operates by line-of-sight up to a distance of about
22 feet/7 m and within a 60-degree angle of the remote sensor on the
projector cabinet.
• The projector will not respond if there are objects between the remote control and the sensor, or if strong light falls on the sensor.
Weak batteries will also prevent the remote control from properly
operating the projector.
Using the Remote Control in Wired Operation
Connect one end of the supplied remote cable to the REMOTE mini
jack and the other end to the remote jack on the remote control.
E-11
REMOTE
OFF
POWER
VIDEO
AUTO ADJ.
ASPECT
FREEZE
HELP
POINTER
VOLUME MAGNIFY
FOCUS
ZOOM
ON
RGB VIEWER
LASER
3D REFORM
PIC-MUTE
SLIDE
FOLDER
SLIDE
LIST
INSTALLATION AND CONNECTIONS
This section describes how to set up your projector and how to connect video and audio sources.
1
Your projector is simple to set up and use.
But before you get started, you must first:
Set up a screen and the projector.
z
x
Connect your computer or video equipment to the projector. See page
E-14 – 17.
c
Connect the supplied power cable. See
page E-17.
2
NOTE: Ensure that the power cable and any
other cables are disconnected before moving
the projector. When moving the projector or
when it is not in use, cover the lens with the
lens cap.
To the wall outlet.
3
Setting Up the Screen and the Projector
Selecting a Location
The further your projector is from the screen or wall, the larger the image. The minimum size the image can be is approximately 25" (0.64 m)
measured diagonally when the projector is roughly 39.4 inches (1.0 m) from the wall or screen. The largest the image can be is 500" (12.7 m) when
the projector is about 614.2 inches (15.6 m) from the wall or screen. Use the drawing below as a guide.
Screen size (Unit: cm/inch)
609.6(W)X457.2(H)/240(W)X180(H)
487.7(W)X365.8(H)/192(W)X144(H)
406.4(W)X304.8(H)/160(W)X120(H)
365.8(W)X274.3(H)/144(W)X108(H)
304.8(W)X228.6(H)/120(W)X90(H)
243.8(W)X182.9(H)/96(W)X72(H)
203.2(W)X152.4(H)/80(W)X60(H)
162.6(W)X121.9(H)/64(W)X48(H)
121.9(W)X91.4(H)/48(W)X36(H)
81.3(W)X61.0(H)/32(W)X24(H)
61.0(W)X45.7(H)/24(W)X18(H)
TELE: 50.8(W)X38.1(H)/20(W)X15(H)
Lens center
30"
25"
1.0
Screen Size
300"
240"
200"
180"
150"
120"
100"
80"
60"
40"
1.1
1.4
2.1
2.8
3.5
4.3
6.4
5.3
7.1
8.5
10.6
E-12
Distance (Unit: m)
Throw Distance and Screen Size
The following shows the proper relative positions of the projector and screen. Refer to the table to determine the position of installation.
Distance Chart
Screen Width
Screen Diagonal
Screen Height
Throw Angle (움)
Screen center
(B)
Lens Center
Throw Distance (C)
B = Vertical distance between lens center and screen center
C = Throw distance
α = Throw angle
NOTE: Distances may vary +/-5%.
Screen Bottom
Screen Size B C
Diagonal Width Height
Diagonal Width Height
10160
11430
12700
inch
inch
25
30
40
60
67
72
80
84
90
100
120
150
180
200
210
240
261
270
300
350
400
450
500
Screen Size B C
mm
635
762
1016
1524
1702
1829
2032
2134
2286
2540
3048
3810
4572
5080
5334
6096
6629
6858
7620
8890
10160
20
24
32
48
54
58
64
67
72
80
96
120
144
160
168
192
209
216
240
280
320
360
400
mm
508
610
813
1219
1361
1463
1626
1707
1829
2032
2438
3048
3658
4064
4267
4877
5304
5486
6096
7112
8128
9144
inch
15
18
24
36
40
43
48
50
54
60
72
90
108
120
126
144
157
162
180
210
240
270
300
mm
381
457
610
914
1021
1097
1219
1280
1372
1524
1829
2286
2743
3048
3200
3658
3978
4115
4572
5334
6096
6858
7620
inch
12.0
18.0
20.0
22.0
24.0
25.0
27.0
30.0
36.0
45.0
54.0
60.0
63.0
72.0
78.0
81.0
90.0
105.0
120.0
135.0
150.0
mm
191
229
305
457
511
549
610
640
686
762
914
1143
1372
1524
1600
1829
1989
2057
2286
2667
3048
3429
3810
8.0
9.0
Wide – Tele
inch
––– - 39.6
35.1 - 47.8
47.4 - 64.4
72.1 - 97.6
80.7 - 109.2
86.9 - 117.5
96.8 - 130.8
101.7 - 137.4
109.1 - 147.4
121.4 - 164.0
146.1 - 197.2
183.1 - 246.9
220.1 - 296.7
244.8 - 329.9
257.1 - 346.5
294.1 - 396.3
320.0 - 431.1
331.1 - 446.0
368.1 - 495.8
429.8 - 578.7
491.5 - –––
553.2 - –––
614.8 - –––
Wide – Tele
mm
––– - 1005
891 - 1215
1204 - 1636
1831 - 2479
2050 - 2774
2207 - 2985
2458 - 3322
2583 - 3490
2771 - 3743
3084 - 4165
3711 - 5007
4651 - 6272
5591 - 7536
6217 - 8379
6531 - 8800
7471 - 10064
8129 - 10949
8410 - 11328
9350 - 12593
10917 - 14700
12484 - –––
14050 - –––
15617 - –––
α
Wide – Tele
degree
––– - 10.7
14.4 - 10.7
14.2 - 10.5
14.0 - 10.4
14.0 - 10.4
14.0 - 10.4
13.9 - 10.4
13.9 - 10.4
13.9 - 10.4
13.9 - 10.4
13.8 - 10.3
13.8 - 10.3
13.8 - 10.3
13.8 - 10.3
13.8 - 10.3
13.8 - 10.3
13.7 - 10.3
13.7 - 10.3
13.7 - 10.3
13.7 - 10.3
13.7 - –––
13.7 - –––
13.7 - –––
α
Wide – Tele
degree
––– - 10.7
14.4 - 10.7
14.2 - 10.5
14.0 - 10.4
14.0 - 10.4
14.0 - 10.4
13.9 - 10.4
13.9 - 10.4
13.9 - 10.4
13.9 - 10.4
13.8 - 10.3
13.8 - 10.3
13.8 - 10.3
13.8 - 10.3
13.8 - 10.3
13.8 - 10.3
13.7 - 10.3
13.7 - 10.3
13.7 - 10.3
13.7 - 10.3
13.7 - –––
13.7 - –––
13.7 - –––
WARNING
* Installing your projector on the ceiling must be done by a quali-
fied technician. Contact your Dukane dealer for more information.
* Do not attempt to install the projector yourself.
•To avoid premature lamp failure, do not tilt the front of the projector
up or down by more than 75° from level. Tilting the front of the projector up or down from 15° to 75° might reduce lamp life by up to 25%.
• Only use your projector on a solid, level surface. If the projector falls
to the ground, you can be injured and the projector severely damaged.
• Do not use the projector where temperatures vary greatly. The projector must be used at temperatures between 32˚F (0˚C) and 95˚F
(35˚C).
• Do not expose the projector to moisture, dust, or smoke. This will
harm the screen image.
• Ensure that you have adequate ventilation around your projector so
heat can dissipate. Do not cover the vents on the side or the front of
the projector.
Reflecting the Image
Using a mirror to reflect your projector's image enables you to enjoy a
much larger image. Contact your Dukane dealer if you need a mirror. If
you're using a mirror and your image is inverted, use the MENU and
SELECT buttons on your projector cabinet or buttons on your remote control to correct the orientation. (See page E-46.)
E-13
Making Connections
NOTE: When using with a notebook PC, be sure to connect between the projector and the notebook PC before turning on the power to the notebook PC. In most
cases signal cannot be output from RGB output unless the notebook PC is turned on after connecting with the projector.
* If the screen goes blank while using your remote control, it may be the result of the computer's screen-saver or power management software.
* If you accidentally hit the POWER button on the remote control, wait 90 seconds and then press the POWER button again to resume.
When Viewing a DVI Digital Signal:
To project a DVI digital signal, be sure to connect the PC and the projector using a DVI-D signal cable (not supplied) before turning on your PC or
projector. Turn on the projector first and select DVI (DIGITAL) from the source menu before turning on your PC.
Failure to do so may not activate the digital output of the graphics card resulting in no picture being displayed. Should this happen, restart your PC.
Do not disconnect the DVI-D signal cable while the projector is running. If the signal cable has been disconnected and then re-connected, an image
may not be correctly displayed. Should this happen, restart your PC.
NOTE:
• Use the DVI-D cable compliant with DDWG (Digital Display Working Group) DVI (Digital Visual Interface) revision 1.0 standard. The DVI-D cable should be within
5 m (196") long.
• The DVI (DIGITAL) connector accepts VGA (640x480), SVGA (800x600), 1152x864, XGA (1024x768) and SXGA (1280x1024 @ up to 60Hz).
Connecting Your PC or Macintosh Computer
DVI IN
RGB 2 IN
RGB 1 IN
RGB signal cable (supplied)
To mini D-Sub 15-pin connector on the projector. It is recommended that you use a commercially available distribution
amplifier if connecting a signal
cable longer than the supplied
one.
PHONE
IBM VGA or Compatibles (Notebook type)
or Macintosh (Notebook type)
Connecting your PC or Macintosh computer to your projector will enable you to project your computer's screen image for an impressive presentation.
To connect to a PC or Macintosh, simply:
1. Turn off the power to your projector and computer.
2. Use the supplied signal cable to connect your PC or Macintosh to the
projector.
3. Turn on the projector and the computer.
4. If the projector goes blank after a period of inactivity, it may be caused
by a screen saver installed on the computer you've connected to the
projector.
DVI-D cable (not supplied)
Audio cable (not supplied)
IBM PC or Compatibles (Desktop type)
or Macintosh (Desktop type)
PHONE
NOTE: For older Macintosh,
use a commercially available
pin adapter (not supplied) to
connect to your Mac's video
port.
Connecting to RGB 2 IN connectors
Use a BNC⳯5 cable to connect your PC and the RGB 2 IN connectors
on your projector.
Connecting Your PC with a DVI Connector
Use a DVI-D signal cable (not supplied) to connect a DVI connector of
your PC to the projector.
NOTE: The 8805/8946 is not compatible with video decoded outputs of
Dukane 8805/8946
E-14
To connect SCART output (RGB)
Before connections: An exclusive SCART adapter (ADP-SC1) and a
commercially available SCART cable are required for this connection.
NOTE:
• Audio signal is not available for this connection.
• The RGB IN 2 connector does not support Plug & Play.
Video equipment
Projector
such as DVD player
RGB 1 IN
To RGB IN 1
Commercially available
Female
ADP-SC1
SCART cable
Connecting an External Monitor
RGB OUT
1. Turn off the power to the projector and your video equipment.
2. Use the ADP-SC1 SCART adapter and a commercially available SCART cable to connect the RGB 1 input of your projector and
a SCART output (RGB) of your video equipment.
3. Turn on the power to the projector and your video equipment.
4. Use the RGB 1 button on the remote control to select the RGB 1
input.
5. Press the MENU button on the remote control to display the menu.
6. From the Advanced menu, select [Projector Options]
→
[Setup]
→
[Page 3] → [Signal Select RGB1] → [Scart].
SCART is a standard European audio-visual connector for TVs, VCRs
and DVD players. It is also referred to as Euro-connector.
NOTE: The ADP-SC1 SCART adapter is obtainable from Dukane
Contact your Dukane.
PHONE
You can connect a separate, external monitor to your projector to simultaneously view on a monitor the RGB analog image you're projecting.
To do so:
1. Turn off the power to your projector, monitor and computer.
2. Use a 15-pin cable to connect your monitor to the RGB OUT (Mini DSub 15 pin) connector on your projector.
3. Turn on the projector, monitor and the computer.
LINE IN
NOTE:
• The RGB OUT connector outputs RGB signal during idle mode (See page E-
47). When the projector goes into idle mode, the image on an external monitor disappears for a moment. Note that the RGB OUT connector will not output RGB signal during Standby mode.
• When the projector is in the Idle mode, the image may not be correctly displayed while the cooling fans are running immediately after turning on or off
the power. Note that the RGB OUT connector will not output RGB signal during Standby mode.
• Daisy chain connection is not possible.
E-15
Connecting Your DVD Player
Optional 15-pin-to-RCA
(female)
⳯
3 cable (ADP-CV1)
RCA(female)-to-BNC(male)
adapter (not supplied)
⳯
Component video RCA
(not supplied)
3 cable
DVD player
RGB 2 IN
RGB 1 IN
AUDIO OUT
L
R
Component
YCbCr
Audio Equipment
AUDIO IN
LR
You can connect your projector to a DVD player with component output
or Video output. To do so, simply:
1. Turn off the power to your projector and DVD player.
2. If your DVD player has the component video (Y,Cb,Cr) output, use a
commercially available component video cable (RCAX3) and the optional 15-pin-to-RCA (female)
to the RGB IN1 or IN2 connector on the projector.
⳯
3 cable to connect your DVD player
Audio cable
(not supplied)
For a DVD player without component video (Y,Cb,Cr) output, use common RCA cables (not provided) to connect a composite VIDEO output of the DVD player to the Video Input of the projector.
3. Turn on the projector and DVD player.
NOTE: Refer to your DVD player's owner's manual for more information about
your DVD player's video output requirements,
E-16
Connecting Your VCR or Laser Disc Player
AC IN
R
G
B
2 IN
R
G
B
O
U
T
A
U
D
IO
A
U
D
IO
D
V
I IN
U
S
B
(
M
O
U
S
E
/H
U
B
)
R
E
M
O
TE
A
U
D
IO
A
U
D
IO
G
/Y
B
/C
b
H
V
R
G
B
1 IN
S
-
V
ID
E
O
IN
V
ID
E
O
IN
A
U
D
IO
A
U
D
IO
A
U
D
IO
L/MONO
R
L/MONO
R
A
U
D
IO
O
U
T
L
/M
O
N
O
R
P
C
C
O
N
T
R
O
L
1
2
S-VIDEO IN
S-video cable (not supplied)
VCR/ Laser disc player
AUDIO OUT
LR
VIDEO IN
VIDEO OUT
S-VIDEO OUT
Video cable (not supplied)
Audio equipment
AUDIO IN
Audio cable (not supplied)
LR
Use common RCA cables (not provided) to connect your VCR, laser
disc player or document camera to your projector.
To make these connections, simply:
1. Turn off the power to the projector and VCR, laser disc player or
document camera.
2. Connect one end of your RCA cable to the video output connector on
the back of your VCR or laser disc player, connect the other end to
the Video input on your projector. Use an audio cable (not supplied)
to connect the audio from your VCR or laser disc player to your audio
equipment (if your VCR or laser disc player has this capability). Be
careful to keep your right and left channel connections correct for
stereo sound.
3. Turn on the projector and the VCR or laser disc player.
Connecting the Supplied Power Cable
Connect the supplied power cable to the projector.
First connect the supplied power cable's three-pin plug to
the AC IN of the projector, and then connect the other
plug of the supplied power cable in the wall outlet.
NOTE: Refer to your VCR or laser disc player owner's manual for more information about your equipment's video output requirements.
NOTE: An image may not be displayed correctly when a Video or S-Video source
is played back in fast-forward or fast-rewind via a scan converter.
E-17
PROJECTING AN IMAGE (BASIC OPERATION)
This section describes how to turn on the projector and to project a
picture onto the screen.
Tur ning on the Projector
NOTE:
• When plugging in or unplugging the supplied power cable, make sure that the
main power switch is pushed to the off[O] position. Failure to do so may cause
damage to the projector.
• The projector has two power switches: main power switch and POWER button
(POWER ON and OFF on the remote control)
• The projector has a feature to prevent itself from being used by unauthorized
individuals. To use this feature, register your PC card as a protect key. See
"Security" in "Projector Options" on page E-53 for more details.
To turn on the main power to the projector, press the Main Power switch
to the ON position ( I ).
Before you turn on your projector, ensure that the computer or video
source is turned on and that your lens cap is removed.
Only after you press the ON/STAND BY button on the projector cabinet
or POWER ON button on the remote control for a minimum of 2 seconds will the power indicator turn to green and the projector become
ready to use.
2. Press the ENTER button to execute the selection.
N
E
U
M
SELECT
E
N
T
E
R
L
E
C
N
A
C
3. The Basic menu will be displayed in the language you have selected.
To close the menu, press the CANCEL button.
N
E
U
M
Note on Startup screen (Menu Language Select screen)
When you first turn on the projector, you will get the Startup screen. This
screen gives you the opportunity to select one of the seven menu languages: English, German, French, Italian, Spanish, Swedish and Japanese.
To select a menu language, follow these steps:
1. Use the SELECT or button to select one of the seven languages
for the menu.
N
E
U
M
SELECT
E
N
T
E
R
L
E
C
N
A
C
SELECT
E
N
T
E
R
L
E
C
N
A
C
After this has been done, you can proceed to the advanced menu operation.
If you want, you can select the menu language later. See "Language"
on page E-45.
NOTE: To turn the projector on by plugging in the power cable, first turn on the
Main Power switch to ON and use the menu and enable the "Auto Start" feature.
(See page E-47.) Immediately after turning on the projector, screen flicker may
occur. This is not a fault. Wait 3 to 5 minutes until the lamp lighting is stabilized.
When the Lamp mode is set to Eco, the Lamp indicator will light green.
If one of the following things happens, the projector will not turn on.
* If the internal temperature of the projector is too high, the projector
detects abnormal high temperature. In this condition the projector
will not turn on to protect the internal system. If this happens, wait for
the projector's internal components to cool down.
* When the lamp reaches its end of usable life, the projector will not
turn on. If this happens, replace the lamp.
* If the lamp fails to light, and if the STATUS indicator flashes on and
off in a cycle of six times, wait a full minute and then turn on the
power.
E-18
Selecting a Source
Selecting the computer or video source
Using the Remote Control
ON
OFF
POWER
RGB VIEWER
VIDEO
LASER
AUTO ADJ.
Press any one of the RGB, VIDEO or
VIEWER buttons.
ASPECT
3D REFORM
FREEZE
HELP
POINTER
PIC-MUTE
SLIDE
VOLUME MAGNIFY
FOLDER
ZOOM
FOCUS
SLIDE
LIST
NOTE: If no input signal is available, the projector will display a blue background
(factory preset).
Selecting from Source List
Source List
Adjusting the Picture Size and Position
Place your projector on a flat level surface and ensure that the projector
is square to the screen.
Lift the front edge of the projector to center the image vertically.
Move the projector left to center the image horizontally on the screen.
* If the projected image does not appear square to the screen then
use the 3D Reform feature for proper adjustment. See page E-20.
Press and quickly release the SOURCE button on the projector cabinet
to display the Source list. Each time the SOURCE button is pressed, the
input source will change as follows: "RGB1", "RGB2" (computer or DVD
with component output), "Video" (VCR, document camera, or laser disc
player), S-Video", "DVI (Digital)", "Viewer" (slides on a PC card), or "LAN"
(wired or wireless signal aired from a PC).
To display the selected source, press the ENTER button.
Detecting the Signal Automatically
Press and hold the SOURCE button for a minimum of 1 second, the
projector will search for the next available input source. Each time you
press and hold the SOURCE button, the input source will change as
follows:
→ RGB1 → RGB2 → Video → S-Video → DVI (Digital)→ Viewer
If no input signal is present, the input will be skipped. When the input
source you wish to project is displayed, release the button.
Press the ENTER button.
Adjust the Tilt Foot
1. Lift the front edge of the projector.
Adjustable Tilt Foot Lever
Adjustable Tilt Foot
Adjustable Tilt Foot Lever
2. Push up the Adjustable Tilt Foot Levers on the right and left sides of
the projector to extend the adjustable tilt feet (maximum height).
3. Push down the Adjustable Tilt Foot Levers.
4. Lower the front of the projector to the desired height (max. 44.5mm/
1.8”) and release the Adjustable Tilt Foot Lever to lock the Adjustable
tilt foot. There is approximately 10 degrees of up and down adjustment for the front of the projector.
WARNING: To avoid premature lamp failure, do not tilt the front of the
projector up or down by more than 15° from level.
E-19
CAUTION:
Do not use the tilt-foot for purposes other than originally intended.
Misuses such as gripping the tilt-foot or hanging on the wall can
cause damage to the projector.
Zoom
Use the ZOOM Button (+/-) to fine adjust the image size on the screen
You can use ZOOM +/- button to enlarge or reduce an image size within
a range of +/-15%.
Correcting the Horizontal and Vertical Keystone Distortion (3D Reform)
Use the 3D Reform feature to correct keystone (trapezoidal) distortion
to make the top or bottom and the left or right side of the screen longer
or shorter so that the projected image is rectangular.
In the following description, 3D Reform (Cornerstone) correction can be
done with the USB mouse or remote control, cabinet buttons.
When using the remote control or cabinet buttons:
1. Project an image so that the screen is smaller than the area of the
raster.
2. Pick up any one of the corners and align the corner of the screen
with the one of the image.
Projected image
Focus
Use the FOCUS Button (+/-) to obtain the best focus.
Using Auto Focus
Press and hold the AUTO ADJUST button on the cabinet or AUTO ADJ
button on the remote control for a minimum of 2 seconds. The focus
pattern will be displayed for a moment and then the best focus will be
automatically obtained.
NOTE: The Auto Functions have two options: Focus and Wall Color Correction.
When the AUTO ADJUST or AUTO ADJ button is pressed and held for a minimum of 2 seconds, either item can be executed. You can decide in advance
which item will be enabled at the time of execution.
From the Advanced menu, select [Projector Options] → [Auto Functions]. You
can turn on or off "Focus" and "Wall Color Correction". See page E-49.
NOTE: Just pressing quickly the AUTO ADJUST button on the cabinet or AUTO
ADJ button on the remote control will enable the Auto Adjust feature instead of
the Auto Focus feature.
NOTE:
Geometric Correction Tool
If you use a special shaped screen such as a cylindrical or spherical screen, a
downloadable program, Geometric Correction Tool is available.
This program (Geometric Correction Tool) enables the geometrical distortion
correction of an image when projected onto a special shaped screen with an
Dukane projector. Additionally, this program allows control of the projector via a
computer.
For additional information visit:
US : http://www.dukcorp.com/av
Screen
(The drawing shows the upper right corner.)
3. Press the 3D REFORM button on the remote control.
The CORNERSTONE adjustment screen is displayed.
NOTE: Press the 3D REFORM button to toggle between "Cornerstone" and "Keystone."
4. Use the SELECT
the direction you wish to move the projected image frame.
5. Press the ENTER button.
6. Use the SELECT
as shown on the example.
button to select one icon which points in
Screen
button to move the projected image frame
E-20
7. Press the ENTER button.
3. Press the 3D REFORM button on the remote control.
The Cornerstone adjustment screen is displayed.
The Cornerstone adjustment screen will disappear when you move
the USB mouse cursor.
4. Point to one of the remaining 3 corners and left-click on it.
Screen
Left-click on the corner.
8. Use the SELECT
button to select another icon which points
in the direction.
Screen
On the Cornerstone adjustment screen, select
“Exit” and then “OK”, or press the CANCEL button on the remote control.
The confirmation screen is displayed.
9. Press the SELECT
or button to highlight the [OK] and press the
ENTER button.
This completes the keystone correction.
Selecting “Cancel” will return to the adjustment screen without saving
changes (Step 3).
Selecting "Reset" will return to the factory default.
Selecting "Undo" will exit without saving changes.
When using the USB connected to the projector
Preparation: Connect the USB mouse to the projector. See page E-28.
1. Project an image so that the screen is smaller than the area of the
raster.
2. Pick up any one of the corners and align the corner of the screen
with the one of the image. (The drawing shows the upper right corner.)
Projected image
Screen
5. Do the above step 4 for the other two corners so that the projected
area becomes smaller than the screen.
Screen
Left-click on each corner.
6. To complete the procedure, right-click anywhere on the screen.
The confirmation screen is displayed.
7. Left-click on "OK".
This completes the Cornerstone adjustment.
*To return the Cornerstone adjustment to the default settings, left-
click on "Reset" in Step 7.
You can save your Cornerstone changes. The changes are saved when
you turn off the projector. To do so, select [Projector Options] → [Setup]
→ [Page 4]. Select the 3D Reform Save check box. This is not selected
at the time of shipment.
* There are limitations of shapes which can be corrected using the Cornerstone adjustment.
When adjusting the Cornerstone beyond these limits, you will get the
message "Out of adjustment range!" and no correction can be done.
Should this happen, do the Cornerstone adjustment again within the
allowable range.
* Due to limitations of accuracy within internal processes, there may be
some discrepancy of positions between the mouse cursor and corrected
shape or one corner and the other 3 corners.
NOTE: To return the 3D Reform correction setting values to the factory default,
press and hold the 3D REFORM button for a minimum of 2 seconds.
Screen
E-21
Loading...
