Introduction

The LCD5500 Security Station provides easy to understand English language information about the
status of your security system and makes daily operation simple by prompting the user through each

operation.

The LCD5500 eliminates the need to memorize key sequences to perform system functions but, you
must memorize your Master Security Code and any additional Security Codes you have programmed

into the system.

The keypad sounding device provides audible feedback each time a key is pressed and with unique
audible sequences it signals troubles and the correct or incorrect entry of information,

About Your Security System

Your DSC security equipment has been designed to give you the greatest possible flexibility and
convenience. The LCD5500 Security Station will guide you through each operation with English

language prompts. Read this manual carefully and have your installer instruct you on system
operation and on which features have been implemented on your system. All users of this system
should be equally instructed in its use. Fill out the SYSTEM INFORMATION page and store this
manual in a safe place for future reference.

Fire Detection

This equipment is capable of monitoring fire detection devices such as smoke detectors and

providing a warning alarm if a fire condition is detected. Good fire detection depends on having

adequate numbers of fire detectors placed in appropriate locations. This equipment should be

#72,

installed in accordance with N.F.P.A. standard

MA 02269). Carefully review the Family Escape Planning guidelines in this manual.

Note: Your Installer must enable the fire detection portion of this equipment before it becomes functional.

chapter 2 (N.F.P.A. Batterymarch Park,

Quincey

IMPORTANT NOTE

A

security system cannot prevent emergencies. It Is only intended to alert you and, If

Included, a monitoring statlon of an emergency situation. Security systems are generally very

_

reliable but they may not work under all
security practices or life and property Insurance. Your security system should be Installed
and serviced by qualified security professionals who should Instruct you on the level of
protection that has been provided and on system operatlon.

The system has been listed for commercial burglary, residential fire and Grade A residential burglary
applications by Underwriters Laboratories.

Testing

To insure that your system continues to function as intended, it is important that you test the system
weekly. See the testing procedure elsewhere in this manual. If your system does not function

properly, call your installing company for service.

conditions

and they are not a substitute for prudent

1

Monitoring

This system is capable of transmitting alarms, troubles, and emergency information over telephone
lines to a monitoring station. If you inadvertently initiate an alarm, immediately call the monitoring
station to prevent an unnecessary response.

Note: The

monitoring function must be enabled by the installer before it becomes functional.

General System Operation

Your security system is made up of a DSC control panel, one or more LCD5500 security stations and
various detectors and sensors. The DSC control panel will be mounted out of the way in a utility room
or basement. The metal cabinet contains the system electronics, fuses and stand-by battery. There
is normally no reason for anyone but the installer or service person to have access to the control
panel. The LCD5500 keypads have an audible indicator, an alphanumeric LCD, (Liquid Crystal
Display), and command entry keys. The keypad is used to send commands to the system and to
display the current system status. The security station(s) will be mounted in convenient locations
inside the protected premises close to the exit-entry doors.

The security system has several zones or areas of protection and each of these zones will have one
or more detection sensors connected to it (motion detectors, glassbreak detectors, door contacts or
shock sensors). When a sensor is in alarm, the zone in alarm will be displayed on the LCD5500
security station,

Trouble and Armed LED Displays

The LCD5500 has a yellow LED on the right side of the keypad which represents the trouble status of
the panel. There is a red LED in the middle which represents the armed status of the panel. There is
a green LED on the left side which represents the ready status of the panel.

Master Code

The four digit Master Code is used for arming and disarming the security system, programming
additional security codes and changing other features. The Master Code will be supplied to you by
your installer. If enabled by your installer, the Master Code can be changed at any time. (See

Programming Security Codes section.)

2

System Information

This system includes:

Control Panel model

Security Station(s) model
Remote keypad(s) model

Master Security Code: 40

There are

Additional Security Codes

01

02

03

04

05

06

07

08

There are

Zone

1
2
3
4
5
6
7
8
9
10

LCD5500

codes available on this system.

09
10
11
12
13
14
15
16

active zones on this system.

17
18
19
20
21
22 30
23
24

Protected Area

25
26
27
28
29

31
32

Zone Type

3

Zone

11
12
13
14
15
16
17
18

19
20
21
22
23
24
25
26
27
28
29
30
31
32

FIRE

Protected Area Zone Type

4

A

I

Monitoring Station Information

Account #

Installer Information

Company

4

Keypad Fire Zone
Keypad Auxiliary Zone
Keypad Panic Zone

Telephone #

Telephone #
