Page 1
Stand foot
Mounting instructions Directions for use
STAND FOOT – STAND TUBE
Dr. Mach
Lamps and Engineering
Stand lamps:
Dr. Mach GmbH u. Co., Flossmannstrasse 28, D-85560 Ebersberg
Tel.: +49 (0)8092 2093 0, Fax +49 (0)8092 2093 50
Internet: www.dr-mach.com
Edition 01 03.02.2000 / Bak Page 1/11
, E-mail: [email protected]
Makrolux
Mach 115
Mach 120 / Mach 120F
Page 2
Stand foot
Dr. Mach
Lamps and Engineering
List of contents
1. Safety instructions ....................................................................................Page 3
2. Installation summary – stand lamps..........................................................Page 4
3. Overview table ..........................................................................................Page 5
Stand foot, stand tube, swivel arm
4. Mounting instructions................................................................................Page 6
4.1 Mounting the stand foot ......................................................................Page 6
5. Directions for use......................................................................................Page 7
5.1 Stand foot ...........................................................................................Page 7
5.2 Stand tube ..........................................................................................Page 7
5.3 Swivel arm ..........................................................................................Page 8
6. Cleaning....................................................................................................Page 8
7. Maintenance .............................................................................................Page 8
8. Data ..........................................................................................................Page 9
9. Disposal ....................................................................................................Page 9
10. Spare parts .............................................................................................Page 10
10.1 Stand foot .........................................................................................Page 10
10.2 Stand tube and swivel arm ...............................................................Page 11
Edition 01 03.02.2000 / Bak Page 2/11
Page 3
Stand foot
Dr. Mach
Lamps and Engineering
1. Safety instructions
The stand foot may not be connected to the mains until it has been fully assembled and installed.
The manufacturer is only responsible for operational safety of the stand foot when repairs and
modifications are carried out by his own staff or by persons who guarantee compliance with
the safety regulations.
The manufacturer is not responsible for damage to persons or property caused by incorrect or
improper use, or when used for incorrect purposes.
General information
These installation instructions must be kept on the lamp together with the relevant
All Dr. Mach stand lamps are supplied with all
installation and connection parts and components.
For packaging reasons, the five-foot stand is
supplied in dismantled state. The stand tube is
always assembled as a unit and only needs to be
attached to the foot with the lower fastening
screw.
operating instructions for consultation at any time.
The lamp is supplied with integrated connection
lead and earthed plug.
The socket to be used for the lamp must be installed according to the requirements stipulated
by the IEC or VDE 0107.
Please check that the earthed socket is available
within the working area of the lamp.
Edition 01 03.02.2000 / Bak Page 3/11
Page 4
Stand foot
2. Installation summary – stand lamps
Example: Lamp Mach 120
Dr. Mach
Lamps and Engineering
The stand is adjustable in heihgt and is to be mounted with the lamps Makrolux, Mach 115 and Mach
120/120F. The stand is not electrified.
Edition 01 03.02.2000 / Bak Page 4/11
Page 5
Stand foot
Data
Power
supply
Stand foot
Dr. Mach
Lamps and Engineering
3. Overview table
Stand foot – stand tube – swivel arm
Lamp type
Primary 230V AC (120V AC optional)
Secondary 24V
Transformer 20W 39W 40W
Number of
extension arms
Length of extension
arm
Roller ∅
Makrolux Mach 115 Mach 120/120F
5
310mm
50mm
Stand tube
Swivel arm +
lamp head
Length approx. 95cm – 145cm
Diameter 25mm
Extension yes
Cable connection no
Suitable for
article no.
Mounting
1100 1012 00
1101 1012 00
• Swivel arm and lamp head premounted
• Swivel arm to stand
1151 1012 00
1201 1012 00
1202 2012 00
Edition 01 03.02.2000 / Bak Page 5/11
Page 6
Stand foot
4. Mounting instructions
Extent of supply
• 1x 5-footed plastic central base
• 2x extension arms with blocking rollers
• 2x extension arms with electrically conductive rollers
• 1x extension arm with roller
• 1x cam catch plate
• 1x cheese head screw M8 with lock washer
• 1x stand tube
• Lamp head with arm
• Mounting instructions/Instructions for use – stand
• Instructions for use – lamp head
4.1 Mounting the stand
11
6
3 4
10
5
2
14
9
1
8
13 7
For mounting the stand proceed as follows:
• Place the central base 1 onto the stand tube
12
• Pre-mount the cam catch plate 3 (cams point
• Insert the other 4 extension arms 7-10 in the
Remark: Mount the two locking rollers 11 and
12, and the two electrically conductive rollers 13
and 14 as shown in the figure (not next to each
other).
• Tighten the catch plate with an Allen key SW6
Dr. Mach
Lamps and Engineering
∅25 2. The stiffness is to ensure a tight fit that
is free from any movement.
inwards), with the lock washer 4 and cheese
head screw M8 5, so that the extension arm 6
can still fit easily into the central base. Insert
the extension arm 6 into the central base from
above holding the cam catch plate 3 against
from the opposite side.
sequence shown in the left figure into the central base. The extension arms are held by the
cams of the cam catch plates.
(approx. 15Nm).
The cams of the catch plate must mate with the
drill holes of the extension arms so that every
extension arm is tightly fitted to both the central
base and stand tube.
The cams also prevent the extension arms from
being pulled out.
Edition 01 03.02.2000 / Bak Page 6/11
Page 7
Stand foot
A
Dr. Mach
Lamps and Engineering
5. Directions for use
A
S
15
5.1 Foot
The five-foot stand is equipped with two opposing
braked wheels A.
S
Set the brake by pressing the pedal S on the roller.
Unlock by lifting the pedal again.
5.2 Stand tube
The stand tube can be adjusted continuously in
height and fixed in the precisely required position,
needing only one hand.
The height is adjusted by lifting the slip button 15.
The position is automatically fixed on letting go.
As long as the slip button 15 is raised, the extension tube can be pulled off or inserted into the stand
tube.
Edition 01 03.02.2000 / Bak Page 7/11
Page 8
Stand foot
16
Dr. Mach
Lamps and Engineering
II.
I.
5.3 Swivel arm
The swivel arm with transformer as counterweight is
in balance, when the lamp is inserted in position.
Adjust the moving of the swivel arm with the adjusting
lever 16.
• The swivel arm doesn’t hold its set position:
Turn the adjusting lever clockwise as far as necessary (I.). You can fix the lamp in the required
position.
• The swivel arm moves sluggishly:
Turn the adjusting lever anti-clockwise (II.), until
you can move the swivel arm easy enough.
The adjusting lever can be brought into a suitable
position by pulling it out, without changing the adjusted clamping force.
6. Cleaning
Alc. ≤ 20 %
The surface of the stands can be easily kept clean
by simply wiping with a damp cloth. You can use
conventional cleaning agents.
In case of disinfection only use disinfectants with
less than 20% alcohol.
Remark: For cleaning the lamp head, the dispersion lenses and splinter protection disks,
see respective instructions for use of the lamp.
7. Maintenance
Caution!
The mains plug must be disconnected before performing any maintenance work.
The mounting journal M and the journal groove of
the lamp should be lightly greased with acid-free
grease when mounting the lamp and once in a
year.
M
Edition 01 03.02.2000 / Bak Page 8/11
Page 9
Stand foot
Dr. Mach
Lamps and Engineering
8. Data
Environmental conditions
Operation
Temperature +10°C +40°C
Relative atmospheric humidity 30% 75%
Air pressure 700 hPa 1060 hPa
Transport / storage
Temperature -10°C +50°C
Relative atmospheric humidity 20% 90%
Air pressure 700 hPa 1060 hPa
Min.
Min.
Max.
Max.
9. Disposal
The stands do not contain any danger goods.
The components of the stand should be properly disposed at the end of its shelf life.
Make sure that the materials are carefully separated.
The components of the stand should be disposed according to the contained materials.
Edition 01 03.02.2000 / Bak Page 9/11
Page 10
Stand foot
Dr. Mach
Lamps and Engineering
10. Spare parts
Item
01 1 Central base
02 1
03 1 Cam catch plate
04 1 Lock washer
05 1 Cheese head screw M5
06
07
08
09
10
11
12
13
14
15 1 Slip button Extension tube
16 1 Adjusting lever Swivel arm
Qty.
Stand tube ∅25mm
5 Extension arm length 300mm
2
Roller ∅50mm with brake
2
Roller ∅50mm electrically conductive
Name
EDVNO
10.1 Stand foot
Remarks
02
06
11
10
03 04 05
14
09
01
07
13
08
12
Edition 01 03.02.2000 / Bak Page 10/11
Page 11
Stand foot
10.2 Stand tube and swivel arm
1165
Dr. Mach
Lamps and Engineering
Edition 01 03.02.2000 / Bak Page 11/11
