CHAPTER 1
DRAWMER DMS-1
M-Clock
MASTER CLOCK GENERATOR AND
MULTIPLE SAMPLE RATE CONVERTER
INTRODUCTION
In today's studio where increasing numbers of digital devices need to be interconnected, maintaining digital signal integrity can be a serious problem. The traditional professional solution has been to use an expensive master clock that drives all the digital equipment in the studio, but in most project studios there are often pieces of equipment that don't have wordclock inputs such as consumer CD players, MD recorders, DAT machines and budget computer soundcards.
The Drawmer M-Clock DMS-1 has been designed to be the heart of syncronisation in the digital audio studio, offering an extremely highly specified, multiple output master clock generator that also incorporates four further channels of sam- ple-rate-conversion (a total output of twenty four Grade 1 synchronization signals in the form of AES/EBU, SPDIF, optical Toslink and AES 11), all locked to the same master clock. The M-Clock generates seven Ultra Low Jitter sample rates - 44.1k, 48k, 88.2k, 96k, 176.4k and 192k as well as 256x Superclock, all stable to < 1ppm. If any equipment in the studio suffers jitter at its output the sample rate converters may be used to de-jitter and re-clock the signals before further transmission.
The advantages of combining wordclock with multiple channels of 'clock-locked' sample rate conversion are significant and often under-appreciated. With M-Clock, all your 'pro' and consumer digital equipment can run in the same system, locked to the same clock, with no worries about finding a suitable sync source. You'll no longer have to switch equipment between internal and external sync as you repatch - and the M-Clock helps to maintain optimum stereo imaging, lower noise and lower distortion. If you have multiple pieces of digital equipment in your studio, whether professional or a mixture of professional and consumer, the Drawmer M-Clock is the most effective upgrade you can make.
1 |
2 |
3 |
4 |
5 |
6 |
1 |
Front Panel Input: |
2 |
4x Status Locked Leds: |
3 |
4x Toslink Outputs: |
|
either 1x S/PDIF or 1x optical TOSLINK |
|
indicates a locked signal for each of the |
|
conveniently located on the front panel |
|
|
|
four inputs |
|
for easy access. |
4 |
Output Sample Rate: |
5 |
Output 5/6 sample rate x2: |
6 |
Superclock (256x) Output: |
|
the two switches set a sample rate of |
|
doubles the sample rate as set by 4 - |
|
provides Superclock to clock outputs 7 |
|
44.1k, 48k, 88.2k and 96k. |
|
upto 192k - for clock outputs 5 and 6. |
|
and 8. |
|
15 |
14 |
13 |
12 |
11 |
10 |
9 |
8 |
7 |
7 |
2x AES/EBU Inputs: |
|
|
8 |
1x S/PDIF Input: |
|
9 |
4x AES/EBU Outputs: |
|
10 |
4x SPDIF Outputs: |
|
|
11 |
2x AES 11 XLR Outputs: |
12 |
2x AES 11 SPDIF Outputs: |
||
outputs to the AES 11 standard (Also called DARS, Blank Frame).
outputs to the AES 11 standard. (Also called DARS, Blank Frame).
13 8x BNC Clock Outputs: |
14 5/6 x2 Clock Outputs: |
15 7/8 Superclock (256x) Output: |
the sample rate of 44.1k, 48k, 88.2k and
96k is set by switches 4 .
when switch 5 is set to double the output is twice the sample rate as set by switches 4 , upto 192k.
when switch 6 is in, connectors 7/8 provide Superclock (256x) output.
