Dometic CFX28, CFX35W, CFX40W, CFX50W, CFX65W operation manual

...

COOLING BOXES

COOLFREEZE

CFX28, CFX35W, CFX40W, CFX50W, CFX65W, CFX65DZ, CFX100W

Compressor Cooler

Operating manual . . . . . . . . . . . . . . . . . . . . . 6

Kompressor-Kühlbox

Bedienungsanleitung . . . . . . . . . . . . . . . . .30

Glacière à compression

Notice d’utilisation . . . . . . . . . . . . . . . . . . .55

Nevera por compresor

Instrucciones de uso . . . . . . . . . . . . . . . . . .80

Geleira com compressor

Manual de instruções . . . . . . . . . . . . . . . . 105

Frigorifero a compressore

Istruzioni per l’uso . . . . . . . . . . . . . . . . . . .130

Compressorkoelbox

Gebruiksaanwijzing. . . . . . . . . . . . . . . . . .155

Kompressor-køleboks

Betjeningsvejledning . . . . . . . . . . . . . . . .180

Kylbox med kompressor

Bruksanvisning . . . . . . . . . . . . . . . . . . . . .204

Kjøleboks med kompressor

Bruksanvisning . . . . . . . . . . . . . . . . . . . . .227

Kompressori-kylmälaatikko

Käyttöohje . . . . . . . . . . . . . . . . . . . . . . . . .250

Компрессорный холодильник

Инструкция по эксплуатации . . . . . . . . . 273

Przenośna lodówka kompresorowa

Instrukcja obsługi . . . . . . . . . . . . . . . . . . . 298

Chladiaci box s kompresorom

Návod na obsluhu. . . . . . . . . . . . . . . . . . . 323

Kompresorový chladicí box

Návod k obsluze . . . . . . . . . . . . . . . . . . . . 347

Kompresszor hűtőláda

Használati utasítás. . . . . . . . . . . . . . . . . . . 371

SET

–

CFX28, CFX35W, CFX40W CFX50W, CFX65W, CFX65DZ

CFX100W

CFX28 – CFX100W

–

SET

CFX28 – CFX100W

SET

–

1 3 4 5 6 72

EMERGENCY

OVERRIDE

NORMAL

USE

100-240V~AC

12/24V DC

2 3 4 51

CFX28 – CFX100W

SET

–

SET

–

CFX50W, CFX65W, CFX65 DZ, CFX 100W

CFX100W

CFX28 – CFX100W

CFX50W, CFX65W

CFX65DZ

1 2 3

–

SET

CFX28 – CFX100W

Please read this operating manual carefully before starting the device. Keep it in a safe place for future reference. If the device is passed on to another person, this operating manual must be handed over to the user along with it.

The manufacturer cannot be held liable for damage resulting from improper usage or incorrect operation.

Contents

1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

2.1 General safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

3 Scope of delivery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

3 Scope of delivery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

4 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

5 Intended use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

6 Function description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

6.1 Scope of functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

6.2 Operating and display elements . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

7Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

7.1 Before initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

7.2 Energy saving tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

7.3 Connecting the cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

7.4 Using the battery monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

7.5 Using the cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

7.6 Setting the temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

7.7 Enabling WiFi signal for optional app (all except CFX28 and

CFX65DZ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

7.8 Set brightness of display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

7.9 Using the emergency switch (where fitted) . . . . . . . . . . . . . . . . . . . .21

7.10 USB port for power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

7.11 Switching off the cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

7.12 Defrosting the cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

7.13 Replacing the device fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

7.14 Replacing the plug fuse (12/24 V) . . . . . . . . . . . . . . . . . . . . . . . . . . 23

7.15 Replacing the light PCB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

CFX28 – CFX100W Explanation of symbols

8 Cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

9Guarantee. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

10 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

11 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

12 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

1 Explanation of symbols

WARNING!

! !

Safety instruction: Failure to observe this instruction can cause fatal or serious injury.

CAUTION! Safety instruction: Failure to observe this instruction can lead to injury.

NOTICE!

Failure to observe this instruction can cause material damage and impair the function of the product.

NOTE

Supplementary information for operating the product.

Safety instructions CFX28 – CFX100W

2 Safety instructions

2.1 General safety

WARNING!

• Do not operate the device if it is visibly damaged.

• If this device's power cable is damaged, it must be replaced by the

manufacturer, customer service or a similarly qualified person in order to prevent safety hazards.

• This device may only be repaired by qualified personnel. Improper repairs can lead to considerable hazards.

• This device can be used by children aged 8 years or over, as well as by persons with diminished physical, sensory or mental capacities or a lack of experience and/or knowledge, providing they are supervised or have been taught how to use the device safely and are aware of the resulting risks.

• Cleaning and user maintenance must not be carried out by children without supervision.

• Children must not play with the device.

• Children must be supervised to ensure that they do not play with the

device.

• Always keep and use the device out of the reach of children under the age of 8 years.

• Do not store any explosive substances such as spray cans with a flammable propellant in the device.

CAUTION!

• Disconnect the device from the power supply – before each cleaning and maintenance – after every use

• Food may only be stored in its original packaging or in suitable containers.

NOTICE!

• Check that the voltage specification on the type plate corresponds to that of the energy supply.

CFX28 – CFX100W Safety instructions

• Only connect the device as follows: – With the DC cable to a DC plug socket in the vehicle (e. g.

cigarette lighter)

– Or with the AC connection cable to the AC mains supply

• Never pull the plug out of the socket by the cable.

• If the cooler is connected to the DC socket: Disconnect the cooler and

other power consuming devices from the battery before connecting the quick charging device.

• If the cooler is connected to the DC socket: Disconnect the cooler or switch it off when you turn off the engine. Otherwise you may discharge the battery.

• The cooling device is not suitable for transporting caustic materials or materials containing solvents.

• The cooling device contains inflammable cyclopentane in the insulation. The gases in the insulation material require special disposal procedures. Deliver the device at the end of its life-cycle to an appropriate recycling.

2.2 Operating the device safely

CAUTION!

• Before starting the device, ensure that the power supply line and the

plug are dry.

NOTICE!

• Do not use electrical devices inside the cooler unless they are recommended by the manufacturer for the purpose.

• Do not place the device near naked flames or other heat sources (heaters, direct sunlight, gas ovens etc.).

• Danger of overheating!

Ensure at all times that there is sufficient ventilation so that the heat that arises during operation does not build up. Make sure that the device is sufficiently far away from walls and other objects so that the air can circulate.

• Ensure that the ventilation openings are not covered.

• Do not fill the inner container with ice or fluid.

• Never immerse the device in water.

• Protect the device and the cable against heat and moisture.

Scope of delivery CFX28 – CFX100W

3Scope of delivery

The scope of delivery is shown in fig. 1, page 2.

Item Quantity Description

1 1 Cooler

2 1 Connection cable for 12/24 Vg connection

– 1 Operating manual

Connection cable for 100 – 240 V

connection

4Accessories

Available as accessory (not included in scope of delivery):

Designation Ref. no. Model

Universal fixing kit (belt system) CFX-UFK 9108300002 suits all models

Quick release fixing kit CFX-QFK 9600000166 CFX28 only

Wireless display CFX-WD 9600000164 suits CFX28,

CFX65DZ and older models without WIFI app function

Visit the Dometic website (see back page) for information about a WiFi app with control-, display- and alarm functions (all except CFX28 and CFX65DZ). Note that the app may not be available in your country.

CFX28 – CFX100W Intended use

5 Intended use

The cooler is suitable for cooling and freezing foods. The device is also suitable for use on boats.

The device is designed to be operated from a 12 V supply socket of a vehicle (e. g. cigarette lighter), boat or caravan as well as from a 100 – 240 V AC mains.

The cooling device is intended to be used in household and similar applications such as

• staff kitchen areas in shops, offices and other working environments

• farm houses

• clients in hotels, motels and other residential type environments

• bed and breakfast type environments

• catering and similar non-retail applications

CAUTION! Health hazard!

Please check if the cooling capacity of the device is suitable for storing the food or medicine you wish to cool.

g or 24 Vg on-board

Function description CFX28 – CFX100W

6 Function description

The cooler can chill products, keep them cool as well as freeze them. A low maintenance refrigerant circuit with compressor provides the cooling. The generous insulation and powerful compressor ensure efficient and fast cooling.

The cooler is portable. The cooler can withstand a heel (inclination) of 30°, for example when used on

boats.

6.1 Scope of functions

• Power supply with priority circuit for connecting to the AC mains

• Three-level battery monitor to protect the vehicle battery

• Display with temperature gauge in °C and °F

switches off automatically at low battery voltage

• Temperature setting: With two buttons in steps of 1 °C (2 °F)

• Integrated WiFi transmitter hence controllable using an app (all except CFX 28

and CFX65DZ)

• Foldable carrying handles

• USB port for power supply

• Emergency switch (where fitted)

• Removable wire basket

CFX28 – CFX100W Function description

6.2 Operating and display elements

Latch for lid: fig. 2 1, page 2

Operating panel (fig. 3, page 3)

Item Description Explanation

1ON

OFF

POWER

3 ERROR LED flashes red: Device is switched on but not ready

4 SET Selects the input mode

5 – Display, shows the information

6 DOWN – Press once to decrease the value

7 UP + Press once to increase the value

“P”

Switches the cooler on or off when the button is pressed for between one and two seconds

Status indication

LED lights up green: Compressor is on

LED lights up orange: Compressor is off

LED flashes orange: display switched off automatically due

to low battery voltage

for operation

– Temperature setting – Celsius or Fahrenheit display – Set battery monitor – Set brightness of display – Switch WiFi on or off (all except CFX28 and CFX65DZ)

Connection sockets (fig. 4, page 3)

Item Description

1 Connection socket AC voltage supply

2 Fuse holder

3 Emergency switch (when fitted)

4 USB port for power supply

5 Connection socket DC voltage supply

Operation CFX28 – CFX100W

7Operation

7.1 Before initial use

NOTE

Reversing the lid opening direction (CFX50W, CFX65W, CFX65DZ)

Th e lid hinges can be moved t o th e oppos ite si de if yo u wa nt to ope n the lid f rom the opposite direction. To do this, proceed as follows:

➤ Open the lid and remove it (fig. 5 A, page 4). ➤ Remove 3 screws per hinge (fig. 5 B, page 4) and take off hinges. ➤ Remove plastic covers from new hinge positions with a small screwdriver and

re-fit to old hinge positions.

➤ Re-fit hinges in new positions. ➤ Insert the lid in the hinges on the opposite side (fig. 5 C, page 4) (CFX50W,

CFX65W, CFX65DZ only).

Before starting your new cooler for the first time, you should clean it inside and outside with a damp cloth for hygienic reasons (please also refer to the chapter “Cleaning and maintenance” on page 24).

Additionally the centre hinge has to be changed (CFX100W only):

➤ Remove two plastic covers from the centre hinge (fig. 6 A, page 4). ➤ Remove four screws from the centre hinge (fig. 6 B, page 4) and take off the

hinge.

➤ Remove the plastic cover from new centre hinge position with a small screw-

driver and re-fit to old hinge position (fig. 6 C, page 4).

➤ Re-fit centre hinge in new position. ➤ Insert the lids in the hinges on the opposite side (fig. 6 D, page 4).

CFX28 – CFX100W Operation

Selecting the temperature units

Temperature display units can be switched between Celsius and Fahrenheit as follows:

➤ Switch on the cooler. ➤ Press the “SET” button (fig. 3 4, page 3) twice. ➤ Use the “UP +” (fig. 3 7, page 3) or “DOWN –” (fig. 3 6, page 3) buttons to

select Celsius or Fahrenheit.

✓ The selected temperature units then appear in the display for a few seconds. The

display flashes several times before it returns to the current temperature.

7.2 Energy saving tips

• Choose a well ventilated installation location which is protected against direct sunlight.

• Allow warm food to cool down first before placing it in the cooling device to keep cool.

• Do not open the cooling device more often than necessary.

• Do not leave the cooling device open for longer than necessary.

• Defrost the cooler once a layer of ice forms.

• Avoid unnecessarily low temperatures.

7.3 Connecting the cooler

Connecting to a battery (Vehicle or boat)

The cooler can be operated with 12 V or 24 V

NOTICE! Danger of damage!

For safety reasons the cooler is equipped with an electronic system to prevent polarity reversal. This protects the cooler against short-circuiting when connecting to a battery.

➤ Plug the 12/24 V connection cable (fig. 1 2, page 2) into the device

DC voltage socket and also into a 12 V or 24 V cigarette lighter socket.

Disconnect the cooler and other consumer units from the battery before you connect the battery to a quick charging device. Overvoltage can damage the electronics of the device.

Operation CFX28 – CFX100W

Connecting to a 100 – 240 V AC mains (E.g. in the home or office)

DANGER! Danger of electrocution!

The coolers have an integrated multi-voltage power supply with priority circuit for connecting to an AC voltage source of 100 switches the cooler to mains operation, if the device is connected to a 100 AC mains, even if the 12/24 V connection cable is still attached.

• Never handle plugs and switches with wet hands or if you are standing on a wet surface.

• If you are operating your cooler on board a boat from a mains connection of 100 circuit breaker between the 100 Seek advice from a trained technician.

– 240 Vw, you must install a residual current

– 240 V

– 240 V. The priority circuit automatically

mains and the cooler.

– 240 V

➤ Plug the 100

AC voltage socket and connect it to the 100

– 240 V connection cable (fig. 1 3, page 2) into the device

– 240 V AC voltage mains.

7.4 Using the battery monitor

The device is equipped with a multi-level battery monitor that protects your vehicle battery against excessive discharging when the device is connected to the on-board 12/24 V supply.

If the cooler is operated when the vehicle ignition is switched off, the cooler switches off automatically as soon as the supply voltage falls below a set level. The cooler will switch back on once the battery has been recharged to the restart voltage level.

NOTICE! Danger of damage!

When switched off by the battery monitor, the battery will no longer be fully charged. Avoid starting repeatedly or operating current consumers without longer charging phases. Ensure that the battery is recharged.

CFX28 – CFX100W Operation

In “HIGH” mode, the battery monitor responds faster than at the levels “LOW” and “MED” (see the following table).

Battery monitor mode LOW MED HIGH

Switch-off voltage at 12 V

Restart-voltage at 12 V

Switch-off voltage at 24 V

Restart voltage at 24 V

The battery monitor mode can be selected as follows:

➤ Switch on the cooler. ➤ Press the “SET” button (fig. 3 4, page 3) three times. ➤ Use the “UP +” (fig. 3 7, page 3) or “DOWN –” (fig. 3 6, page 3) buttons to

select the battery monitor mode.

✓ Display will be as follows:

Lo (LOW), Ȇd (MED), Hi (HIGH)

✓ The selected mode then appears in the display for a few seconds. The display

flashes several times before it returns to the current temperature.

10.1 V 11.4 V 11.8 V

11.1 V 12.2 V 12.6 V

21.5 V 24.1 V 24.6 V

23.0 V 25.3 V 26.2 V

NOTE

When the cooler is supplied by the starter battery, select the battery monitor mode “HIGH”. If the cooler is connected to a supply battery, the battery monitor mode “LOW” will suffice.

Operation CFX28 – CFX100W

7.5 Using the cooler

NOTICE! Danger of overheating!

➤ Place the cooler on a firm foundation.

Make sure that the ventilation slots are not covered and that the heated air can dissipate.

➤ Connect the cooler, see chapter “Connecting the cooler” on page 15.

➤ Press the “ON/OFF” button (fig. 3 1, page 3) for between one and two

seconds.

Ensure at all times that there is sufficient ventilation so that the heat that generated during operation can dissipate. Ensure that the ventilation slots are not covered. Make sure that the device is sufficiently far away from walls and other objects so that the air can circulate.

NOTE

Place the cooler as shown (fig. 1, page 2). If you operate the box in a different orientation it can be damaged.

NOTICE! Danger from excessively low temperature!

Ensure that the only those objects are placed in the cooler that are intended to be cooled at the selected temperature.

✓ The LED “P” lights up (fig. 3 2, page 3). ✓ The display (fig. 3 5, page 3) switches on and shows the current cooling

temperature.

CAUTION! Health hazard!

CFX65DZ:

If the temperature in the freezer compartment (fig. 8 1, page 5) is very low (–22 °C), the temperature range in the cooling department (fig. 8 2, page 5) can be below freezing as well.

CFX28 – CFX100W Operation

NOTE

✓ The cooler starts cooling the interior.

Latching the cooler lid

➤ Close the lid. ➤ Press the latch (fig. 2 1, page 2) down, until it latches in place audibly.

Displayed temperature

• CFX28, CFX35W, CFX40W, CFX50W, CFX65W, CFX100W:

The temperature displayed is that of the large interior compartment (e.g. CFX50W, CFX65W: fig. 7 1, page 5).

• CFX65DZ:

– With fridge/freezer divider in: The temperature displayed is that

of the freezer compartment (fig. 8 1, page 5).

– With fridge/freezer divider out: The actual compartment

temperature will be considerably warmer than the displayed temperature

NOTE

When operating with the battery, the display switches off automatically if the battery voltage is low. The LED “P” flashes orange.

7.6 Setting the temperature

➤ Press the “SET” button (fig. 3 4, page 3) once. ➤ Use the “UP +” (fig. 3 7, page 3) and “DOWN –” (fig. 3 6, page 3) buttons to

select the cooling temperature.

✓ The cooling temperature appears in the display for a few seconds. The display

flashes several times and then the current temperature is displayed again.

Operation CFX28 – CFX100W

7.7 Enabling WiFi signal for optional app (all except CFX28 and CFX65DZ)

The cooler can be controlled via WiFi using an app that you can install on a compatible device. The app has control, display and alarm functions.

For further information go to the Dometic website for your country (see back page). Note that the app may not be available in your country.

The WiFi name of the compressor cooler begins with“CFX”. The preset password is “00000000”. You can change the WiFi name and password individually.

Switching the WiFi signal on or off

➤ Press the “SET” button (fig. 3 4, page 3) five times. ➤ Use the “UP +” (fig. 3 7, page 3) and “DOWN–” (fig. 3 6, page 3) buttons to

switch the WiFi signal on or off.

✓ The desired setting appears in the display for a few seconds. The display flashes

several times and then the current temperature is displayed again.

NOTE

• The default setting for the WiFi transmitter is off. For first time use and

whenever power to the device is interrupted, switch on the WiFi transmitter to use the app.

• The WiFi transmitter uses a small amount of power. For optimal energy performance switch the WiFi transmitter off if it is not being used.

Resetting the WiFi to factory settings

In case you have personalized the WiFi settings of your cooling device using the WiFi app and forgotten your password, you can reset to the factory settings as follows:

➤ Press the “SET” button (fig. 3 4, page 3) five times. ➤ Hold the “UP +” (fig. 3 7, page 3) button for at least five seconds. ✓ In both displays “rES” will blink several times before returning to the previous dis-

play. ✓ The WiFi settings have been reset to factory settings. For additional information visit the Dometic website from which you downloaded

the app.

CFX28 – CFX100W Operation

7.8 Set brightness of display

The display brightness can be dimmed for low ambient light conditions. To set the dimming level of the display proceed as follows:

➤ Switch on the cooler. ➤ Press the “SET” button (fig. 3 4, page 3) four times. ➤ Use the “UP +” (fig. 3 7, page 3) or “DOWN –” (fig. 3 6, page 3) buttons to

set the brightness of the display. ✓ Display will be as follows:

d0 (default), d1 (medium), d2 (dark) ✓ The display shows the set mode for some seconds. The display flashes several

times before it returns to the current brightness.

NOTE

7.9 Using the emergency switch (where fitted)

The emergency switch (fig. 4 3, page 3) is located below the control panel on all models except CFX28 where it is located above the power inlet sockets. For normal operation the switch is in the “NORMAL USE” position.

• The factory setting of brightness of the display is d0 (default).

• If a fault occurs, the brightness automatically is d0 (default). After

troubleshooting the set brightness is reactivated.

➤ If an electronic control failure occurs, slide the switch to “EMERGENCY

OVERRIDE” position

NOTE

7.10 USB port for power supply

USB port allows you to charge small devices like mobile phones and mp3-players. To use your cooling box with any USB devices, simply connect a USB cable (not

included) to your device.

If the switch is in the “EMERGENCY OVERRIDE” position, the cooler runs with full cooling capacity and may freeze.

NOTE

Ensure that any small device connected to the USB port is compatible with 5 V/500 mA operation.

Operation CFX28 – CFX100W

7.11 Switching off the cooler

➤ Empty the cooler. ➤ Switch the cooler off. ➤ Pull out the connection cable.

If you do not want to use the cooler for a longer period of time: ➤ Leave the cover slightly open. This prevents odour build-up.

7.12 Defrosting the cooler

Humidity can form frost in the interior of the cooling device or on the evaporator. This reduces the cooling capacity. Defrost the device in good time to avoid this.

NOTICE! Danger of damage!

To defrost the cooler, proceed as follows: ➤ Take out the contents of the cooling device.

Never use hard or pointed tools to remove ice or to loosen objects which have frozen in place.

➤ If necessary, place them in another cooling device to keep them cool. ➤ Switch off the device. ➤ Leave the lid open. ➤ Wipe off the defrosted water.

7.13 Replacing the device fuse

DANGER! Danger of electrocution!

➤ Disconnect the power supply to the device. ➤ Pull off the connection cable. ➤ Pry out the fuse insert (fig. 4 2, page 3) with a screwdriver. ➤ Replace the defective glass fuse with a new one that has the same rating (4 A,

250 V).

Disconnect the power supply and the connection cable before you replace the device fuse.

CFX28 – CFX100W Operation

➤ Press the fuse insert back into the housing. ➤ Reconnect the power supply to the device.

7.14 Replacing the plug fuse (12/24 V)

➤ Unscrew the contact pin housing (fig. 9 3, page 5) from the plug (fig. 9 1,

page 5). ➤ Replace the defective fuse (fig. 9 2, page 5) with a new fuse that has the same

rating (3AG, 15 A). ➤ Re-assemble the plug in reverse order.

7.15 Replacing the light PCB

➤ Disconnect the power supply to the device. ➤ Pry out the transparent cover with a screwdriver (fig. 0 1, page 5). ➤ Unscrew the PCB mounting screws (fig. 0 2, page 5). ➤ Pull out the plug from the PCB (fig. 0 3, page 5). ➤ Replace the defective light PCB with a new one. ➤ Fit new PCB using reverse of removal instructions. ➤ Press the transparent cover back into the housing. ➤ Reconnect the power supply to the device.

Cleaning and maintenance CFX28 – CFX100W

8 Cleaning and maintenance

WARNING!

➤ Occasionally clean the device interior and exterior with a damp cloth. ➤ Make sure that the air inlet and outlet vents on the device are free of any dust and

dirt, so that heat can be released and the device is not damaged.

Always disconnect the device from the power supply before you clean and service it.

NOTICE! Risk of damage

• Never clean the cooler under running water or in dish water.

• Do not use abrasive cleaning agents or hard objects during cleaning

as these can damage the cooler.

9Guarantee

The statutory warranty period applies. If the product is defective, please contact the manufacturer's branch in your country (see the back of the instruction manual for the addresses) or your retailer.

For repair and guarantee processing, please include the following documents when you send in the device:

• A copy of the receipt with purchasing date

• A reason for the claim or description of the fault

CFX28 – CFX100W Troubleshooting

10 Troubleshooting

Fault Possible cause Suggested remedy

Device does not function, LED does not glow.

The device does not cool (plug is inserted, “POWER” LED is lit).

The device does not cool (plug is inserted, “POWER” LED flashes orange, display is switched off).

When operating from the 12/24 V socket (cigarette lighter):

The ignition is on and the device is not working and the LED is not lit.

Pull the plug out of the socket and make the following checks.

The display shows an error message (e.g. “Err1”) and the appliance does not cool.

There is no voltage present in the 12/24 V socket (cigarette lighter) in your vehicle.

No voltage present in the AC voltage socket.

The device fuse is defective.

The integrated mains adapter is defective.

Defective compressor. This can only be repaired by an

Battery voltage is too low.

The cigarette lighter socket is dirty. This results in a poor electrical contact.

The fuse of the 12/24 V plug has blown.

The vehicle fuse has blown.

The appliance has switched off due to an internal fault.

The ignition must be switched on in most vehicles to apply current to the cigarette lighter.

Try using another plug socket.

Replace the device fuse, see chapter “Replacing the device fuse” on page 22.

This can only be repaired by an authorised repair centre.

authorised customer services unit.

Test the battery and charge it as needed.

If the plug of your cooler becomes very warm in the cigarette lighter socket, either the lighter socket must be cleaned or the plug has not been assembled correctly.

Replace the fuse (15 A) in the 12/24 V plug, see chapter “Replacing the plug fuse (12/24 V)” on page 23.

Replace the vehicle’s 12/24 V socket fuse (usually 15 A). Please refer to your vehicle’s operating manual.

This can only be repaired by an authorised repair centre.

Disposal CFX28 – CFX100W

11 Disposal

➤ Place the packaging material in the appropriate recycling waste bins wherever

possible.

If you wish to finally dispose of the product, ask your local recycling centre or specialist dealer for details about how to do this in accordance with the

applicable disposal regulations.

12 Technical data

CFX28 CFX35W CFX40W

Ref. no.: 9600000468

9600000469

Connection voltage: 12/24 Vg and 100 – 240 Vw

Rated current: 12 Vg: 6,5 A

24 Vg: 3,2 A

100 Vw: 0,75 A

240 Vw: 0,32 A

Cooling capacity: +10 °C to –22 °C (+50 °F to –8 °F)

Category: 1

Energy efficiency class: A++

Energy consumption: 61 kWh/annum 62 kWh/annum 64 kWh/annum

Gross volume: 28 l 34.5 l 41 l

Storage volume: 26 l 32 l 38 l

Climate class: N, T

Ambient temperature: +16 °C to +43 °C

Noise emission: 34 dB(A) 42 dB(A)

USB: 5 Vg, 500 mA

Refrigerant quantity: 38 g 33 g 38 g

equivalent: 0.054 t 0.047 t 0.054 t

Global warming potential (GWP):

9600000470 9600000471

100 Vw: 0,86 A 240 Vw: 0,42 A

1430

9600000472 9600000473

12 Vg: 7,0 A

24 Vg: 3,2 A

CFX28 – CFX100W Technical data

CFX28 CFX35W CFX40W

Dimensions (WxHxD) inmm (including handles):

Weight: 13 kg 17.5 kg 18.5 kg

342 x 425 x 620 398 x 411 x 692 398 x 461 x 692

CFX50W CFX65W CFX65DZ

Ref. no.: 9600000474

9600000475

Connection voltage:

Rated current: 12 Vg: 7,8 A

Cooling capacity: +10 °C to –22 °C (+50 °F to –8 °F)

Category: 1

Energy efficiency class: A++ A+

Energy consumption: 66 kWh/annum 69 kWh/annum 115 kWh/annum

Gross volume: 50 l 65 l with divider: 61 l

Storage volume: 46l 60l 53l

Climate class: N, T

Ambient temperature: +16 °C to +43 °C

Noise emission: 42 dB(A)

USB: 5 Vg, 500 mA

Refrigerant quantity: 43 g 57 g 31 g

equivalent: 0.062 t 0.082 t 0.044 t

Global warming potential (GWP):

Dimensions (WxHxD) inmm (including handles):

Weight: 20.4 kg 22.3 kg 23.2 kg

24 Vg: 3,6 A

100 Vw: 0,95 A 240 Vw: 0,46 A

725 x 471 x 455 725 x 561 x 455 725 x 561 x 455

9600000476 9600000477

12/24 Vg and 100 – 240 Vw

12 Vg: 8,2 A 24 Vg: 3,8 A

100 Vw: 1,0 A

240 Vw: 0,48 A

1430

9600000478 9600000479

12 Vg: 5,5 A 24 Vg: 2,6 A

100 Vw: 0,75 A 240 Vw: 0,37 A

without divider: 65 l

Technical data CFX28 – CFX100W

CFX100W

Ref. no.: 9600000536

9600000650

Connection voltage:

Rated current: 12 Vg: 10,5 A

Cooling capacity: +10 °C to –22 °C (+50 °F to –8 °F)

Category: 1

Energy efficiency class: A+

Energy consumption: 98 kWh/annum

Gross volume: 100 l

Storage volume: 88 l

Climate class: N, T

Ambient temperature: +16 °C to +43 °C

Noise emission: 37 dB(A)

USB: 5 Vg, 500 mA

Refrigerant quantity: 64 g

equivalent: 0.092 t

Global warming potential (GWP):

Dimensions (WxHxD) inmm (including handles):

Weight: 32 kg

12/24 Vg and 100 – 240 Vw

24 Vg: 5,0 A

100 Vw: 1,25 A 240 Vw: 0,48 A

1430

957 x 472 x 530

NOTE

If the ambient temperature is above +32 °C (+90 °F), the minimum temperature cannot be attained.

CFX28 – CFX100W Technical data

Test/certificates:

The coolant circuit contains R134a. Contains fluorinated greenhouse gases Hermetically sealed equipment

CFX28 – CFX100W

Bitte lesen Sie diese Anleitung vor der Inbetriebnahme sorgfältig durch und bewahren Sie sie auf. Geben Sie sie im Falle einer Weitergabe des Kühlgerätes an den Nutzer weiter.

Der Hersteller haftet nicht für Schäden, die durch nicht bestimmungsgemäßen Gebrauch oder falsche Bedienung verursacht werden.

Inhaltsverzeichnis

1 Erklärung der Symbole . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

2 Sicherheitshinweise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

2.1 Allgemeine Sicherheit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

2.2 Sicherheit beim Betrieb des Kühlgerätes . . . . . . . . . . . . . . . . . . . . . 33

3Lieferumfang . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

4Zubehör. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

5 Bestimmungsgemäßer Gebrauch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

6 Funktionsbeschreibung. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

6.1 Funktionsumfang. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

6.2 Bedien- und Anzeigeelemente. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

7Bedienung. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

7.1 Vor dem ersten Gebrauch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

7.2 Tipps zum Energiesparen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

7.3 Kühlbox anschließen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

7.4 Batteriewächter verwenden . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

7.5 Kühlbox benutzen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

7.6 Temperatur einstellen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

7.7 WLAN-Signal für optionale App aktivieren (alle außer CFX28 und

CFX65DZ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

7.8 Helligkeit des Displays einstellen . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

7.9 Notschalter verwenden (falls vorhanden) . . . . . . . . . . . . . . . . . . . . 45

7.10 USB-Anschluss für Spannungsversorgung. . . . . . . . . . . . . . . . . . . . 46

7.11 Kühlbox ausschalten . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

7.12 Kühlbox abtauen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

7.13 Gerätesicherung austauschen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

7.14 Steckersicherung (12/24 V) austauschen . . . . . . . . . . . . . . . . . . . . 47

7.15 Lichtleiterplatte wechseln . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

8 Reinigung und Pflege. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

+ 366 hidden pages
