MEDIA CENTER 730N (RER)
MEDIA CENTER 730N (RER)
Navigation User’s Manual
Navigation User’s Manual
USER AGREEMENT
NOTICE:
This device complies with Part 15 of the FCC Rules [and
with RSS-210 of Industry Canada].
Operation is subject to the following two conditions: this
device may not cause harmful interference, and this
device must accept any interference received, including
interference that may cause undesired operation.
NOTICE:
Changes or modifications made to this equipment not
expressly approved by the radio manufacturer may void
the FCC authorization to operate this equipment.
NOTICE:
This Class B digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe B est conforme à la
norme NMB-003 du Canada.
FCC Declaration
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause undesired operation.
Modifications not expressly approved by the radio
manufacturer could void the user’s authority to operate
the equipment.
following measures: - Increase the separation between
the equipment and receiver. - Consult the dealer or an
experienced radio technician for help.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the
Safety Information
Exposure to Radio Frequency Radiation
The radiated output power of the this internal wireless
radio is far below the FCC radio frequency exposure
limits. Nevertheless, the wireless radio shall be used in
such a manner that the radio is 20 cm or further from the
human body.
The internal wireless radio operates within guidelines
found in radio frequency safety standards and recommendations, which reflect the consensus of the scientific
community.
The radio manufacturer believes the internal wireless
radio is safe for use by consumers. The level of energy
emitted is far less than the electromagnetic energy emitted by wireless devices such as mobile phones. However,
the use of wireless radios may be restricted in some
situations or environments, such as aboard airplanes. If
you are unsure of restrictions, you are encouraged to ask
for authorization before turning on the wireless radio.
End User License Agreement NAVTEQ
PLEASE READ THIS END USER LICENSE AGREEMENT CAREFULLY BEFORE USING THE NAVTEQ
DATABASE
NOTICE TO THE USER
THIS IS A LICENSE AGREEMENT - AND NOT AN
AGREEMENT FOR SALE – BETWEEN YOU AND
NAVTEQ B.V. FOR YOUR COPY OF THE NAVTEQ
NAVIGABLE MAP DATABASE, INCLUDING ASSOCIATED COMPUTER SOFTWARE, MEDIA AND EXPLANATORY PRINTED DOCUMENTATION PUBLISHED BY NAVTEQ (JOINTLY ”THE DATABASE”). BY
USING THE DATABASE, YOU ACCEPT AND AGREE
TO ALL TERMS AND CONDITIONS OF THIS END
USER LICENSE AGREEMENT (”AGREEMENT”). IF
YOU DO NOT AGREE TO THE TERMS OF THIS
AGREEMENT, PROMPTLY RETURN THE DATABASE,
ALONG WITH ALL OTHER ACCOMPANYING ITEMS,
TO YOUR SUPPLIER FOR A REFUND.
OWNERSHIP
The Database and the copyrights and intellectual property or neighboring rights therein are owned by
NAVTEQ or its licensors. Ownership of the media on
which the Database is contained is retained by NAVTEQ
and/or your supplier until after you have paid in full any
amounts due to NAVTEQ and/or your supplier pursuant
to this Agreement or similar agreement(s) under which
goods are provided to you.
LICENSE GRANT
NAVTEQ grants you a non-exclusive license to use the
Database for your personal use or, if applicable, for use in
your business’ internal operations. This license does not
include the right to grant sublicenses.
LIMITATIONS ON USE
The Database is restricted for use in the specific system
for which it was created. Except to the extent explicitly
permitted by mandatory laws (e.g. national laws based
on the European Software Directive (91/250) and the
Database Directive (96/9)), you may not extract or reutilize substantial parts of the contents of the Database nor
reproduce, copy, modify, adapt, translate, disassemble,
decompile, reverse engineer any portion of the Database.
If you wish to obtain interoperability information as
meant in (the national laws based on) the European
Software Directive, you shall grant NAVTEQ reasonable
opportunity to provide said information on reasonable
terms, including costs, to be determined by NAVTEQ.
TRANSFER OF LICENSE
You may not transfer the Database to third parties, except
when installed in the system for which it was created or
when you do not retain any copy of the Database, and
provided that the transferee agrees to all terms and
conditions of this Agreement and confirms this in writing
to NAVTEQ. Multi-disc sets may only be transferred or
sold as a complete set as provided by NAVTEQ and not
as subset thereof.
LIMITED WARRANTY
NAVTEQ warrants that, subject to the warnings set out
below, for a period of 12 months after acquisition of your
copy of the Database, it will perform substantially in
accordance with NAVTEQ’s Criteria for Accuracy and
Completeness existing on the date you acquired the
Database; these criteria are available from NAVTEQ at
your request. If the Database does not perform in accordance with this limited warranty, NAVTEQ will use
reasonable efforts to repair or replace your nonconforming copy of the Database. If these efforts do not lead to
performance of the Database in accordance with the
warranties set out herein, you will have the option to
either receive a reasonable refund of the price you paid
for the Database or to rescind this Agreement. This shall
be NAVTEQ’s entire liability and your sole remedy
against NAVTEQ. Except as expressly provided in this
section, NAVTEQ does not warrant nor make any representations regarding the use of results of the use of the
Database in terms of its correctness, accuracy, reliability,
or otherwise. NAVTEQ does not warrant that the Database is or will be error free. No oral or written information or advice provided by NAVTEQ, your supplier or
any other person shall create a warranty or in any way
increase the scope of the limited warranty described
above. The limited warranty set forth in this Agreement
does not affect or prejudice any statutory legal rights that
you may have under the legal warranty against hidden
defects.
If you did not acquire the Database from NAVTEQ
directly, you may have statutory rights against the person
from whom you have acquired the Database in addition
to the rights granted by NAVTEQ hereunder according to
the law of your jurisdiction. The above warranty of
NAVTEQ shall not affect such statutory rights and you
may assert such rights in addition to the warranty rights
granted herein.
LIMITATION OF LIABILITY
The price of the Database does not include any consideration for assumption of risk of consequential, indirect
or unlimited direct damages which may arise in connection with your use of the Database. Accordingly, in no
event shall NAVTEQ be liable for any consequential or
indirect damages, including without limitation, loss of
revenue, data, or use, incurred by you or any third party
arising out of your use of the Database, whether in an
action in contract or tort or based on a warranty, even if
NAVTEQ has been advised of the possibility of such
damages. In any event NAVTEQ’s liability for direct
damages is limited to the price of your copy of the
Database.
THE LIMITED WARRANTY AND LIMITATION OF LIABILITY, SET FORTH IN THIS AGREEMENT, DO NOT
AFFECT OR PREJUDICE YOUR STATUTORY RIGHTS
WHERE YOU HAVE ACQUIRED THE DATABASE
OTHERWISE THAN IN THE COURSE OF A BUSINESS.
WARNINGS
The Database may contain inaccurate or incomplete
information due to the passage of time, changing circumstances, sources used and the nature of collecting comprehensive geographic data, any of which may lead to
incorrect results. The Database does not include or reflect
information on - inter alia - neighborhood safety; law
enforcement; emergency assistance; construction work;
road or lane closures; vehicle or speed restrictions; road
slope or grade; bridge height, weight or other limits; road
or traffic conditions; special events; traffic congestion; or
travel time.
GOVERNING LAW
This Agreement shall be governed by the laws of the
jurisdiction, in which you reside at the date of acquisition
of the Database. Should you at that moment reside
outside the European Union or Switzerland, the law of
the jurisdiction within the European Union or Switzerland where you acquired the Database shall apply. In all
other cases, or if the jurisdiction where you acquired the
Database cannot be defined, the laws of the Netherlands
shall apply. The courts competent at your place of
residence at the time you acquired the Database shall
have jurisdiction over any dispute arising out of, or
relating to this Agreement, without prejudice to
NAVTEQ’s right to bring claims at your then current
place of residence.
End-User License Agreement Gracenote
USE OF THIS PRODUCT IMPLIES ACCEPTANCE OF
THE TERMS BELOW.
Gracenote威 MusicID威 Terms of Use
This device contains software from Gracenote, Inc. of
Emeryville, California (“Gracenote”). The software from
Gracenote (the “Gracenote Software”) enables this application to do online disc identification and obtain musicrelated information, including name, artist, track, and
title information (“Gracenote Data”) from online servers
(“Gracenote Servers”) and to perform other functions.
You may use Gracenote Data only by means of the
intended End-User functions of this device.
You agree that you will use Gracenote Data, the
Gracenote Software, and Gracenote Servers for your own
personal noncommercial use only. You agree not to
assign, copy, transfer or transmit the Gracenote Software
or any Gracenote Data to any third party. YOU AGREE
NOT TO USE OR EXPLOIT GRACENOTE DATA, THE
GRACENOTE SOFTWARE, OR GRACENOTE SERVERS, EXCEPT AS EXPRESSLY PERMITTED HEREIN.
You agree that your non-exclusive license to use the
Gracenote Data, the Gracenote Software, and Gracenote
Servers will terminate if you violate these restrictions. If
your license terminates, you agree to cease any and all
use of the Gracenote Data, the Gracenote Software, and
Gracenote Servers. Gracenote reserves all rights in
Gracenote Data, the Gracenote Software, and the
Gracenote Servers, including all ownership rights. Under
no circumstances will Gracenote become liable for any
payment to you for any information that you provide.
You agree that Gracenote, Inc. may enforce its rights
under this Agreement against you directly in its own
name.
The Gracenote MusicID Service uses a unique identifier
to track queries for statistical purposes. The purpose of a
randomly assigned numeric identifier is to allow the
Gracenote MusicID service to count queries without
knowing anything about who you are. For more information, see the web page for the Gracenote Privacy
Policy for the Gracenote MusicID Service.
The Gracenote Software and each item of Gracenote Data
are licensed to you “AS IS.” Gracenote makes no representations or warranties, express or implied, regarding
the accuracy of any Gracenote Data from in the
Gracenote Servers. Gracenote reserves the right to delete
data from the Gracenote Servers or to change data
categories for any cause that Gracenote deems sufficient.
No warranty is made that the Gracenote Software or
Gracenote Servers are error-free or that functioning of
Gracenote Software or Gracenote Servers will be uninterrupted. Gracenote is not obligated to provide you with
new enhanced or additional data types or categories that
Gracenote may provide in the future and is free to
discontinue its online services at any time.
GRACENOTE DISCLAIMS ALL WARRANTIES EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED
TO, IMPLIED WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND
NON-INFRINGEMENT. GRACENOTE DOES NOT
WARRANT THE RESULTS THAT WILL BE OBTAINED
BY YOUR USE OF THE GRACE-NOTE SOFTWARE OR
ANY GRACENOTE SERVER. IN NO CASE WILL
GRACENOTE BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES OR FOR ANY LOST
PROFITS OR LOST REVENUES.
© Gracenote 2007 Version 2.2
CD and music-related data from Gracenote, Inc., copyright © 2000-2007 Gracenote. Gracenote Software, copyright © 2000-2007 Gracenote. This product and service
may practice one or more of the following U.S. Patents:
#5,987,525; #6,061,680; #6,154,773, #6,161,132, #6,230,192,
#6,230,207, #6,240,459, #6,330,593, and other patents issued or pending. Some services supplied under license
from Open Globe, Inc. for U.S. Patent: #6,304,523.
Gracenote and CDDB are registered trademarks of
Gracenote. The Gracenote logo and logotype, and the
⬙Powered by Gracenote⬙ logo are trademarks of
Gracenote.
CONTENTS
NAVIGATION
䡵 Safety Guidelines ....................... 4
䡵 Introduction ...........................6
▫ Warnings ............................ 6
▫ Safety References ...................... 6
▫ Intended Use ......................... 6
▫ System Care .......................... 6
䡵 General Handling ...................... 10
▫ User Interface Elements ................. 10
▫ Steering Wheel Mounted Controls
(If Equipped) ........................ 13
▫ Audio Settings ....................... 14
䡵 Getting Started ........................ 16
▫ Disclaimer For Navigation Radio .......... 16
▫ Change The Language .................. 16
▫ SetTheTime ........................ 17
▫ Store Radio Presets .................... 18
2 NAVIGATION
▫ Connect Bluetooth威 Phone ............... 19
䡵 Uconnect™ Multimedia (Remote Devices) ..... 71
▫ Set Default Country ................... 21
▫ Set Default State ...................... 21
▫ Enter Home Address ................... 22
▫ Change Home Address ................. 24
▫ Voice Command Tutorial ................ 26
▫ Uconnect™ Phone Tutorial .............. 26
䡵 Uconnect™ Multimedia (Radio) ............ 27
▫ Radio Mode ......................... 27
▫ Radio Settings ....................... 30
䡵 Uconnect™ Multimedia (Media) ............ 36
▫ Disc Mode .......................... 36
▫ Hard Disk Drive Mode (HDD) ............ 45
▫ iPod威 Mode (If Equipped) ............... 71
▫ Sirius Backseat TV™ (If Equipped) ......... 76
▫ Video Entertainment System (VES)™ ....... 77
▫ USB Connector ....................... 79
▫ AUX Mode ......................... 82
䡵 Voice Command ....................... 84
▫ Voice Command Operation .............. 84
䡵 Uconnect™ Phone ...................... 94
䡵 Uconnect™ GPS Navigation ............... 95
▫ General Notes ....................... 95
▫ Navigation Main Menu ................. 96
▫ Destination Input By POI ............... 99
▫ Route Guidance ..................... 125
NAVIGATION 3
▫ Software And Database Updates ......... 161
▫ Navigation Options ................... 133
▫ Navigation Default Settings ............. 138
▫ Map Viewer ........................ 140
▫ Stop Over ......................... 142
▫ Trip Planner ........................ 143
▫ Realtime Traffic By Sirius Satellite Radio .... 148
▫ Address Book ....................... 153
䡵 System Information .................... 161
▫ User Data Backup .................... 161
䡵 Troubleshooting ...................... 162
▫ Radio ............................ 162
▫ Disc .............................. 162
▫ HDD ............................. 162
▫ iPod ............................. 162
▫ Navigation ......................... 163
▫ Voice Command ..................... 163
䡵 Glossary Of Terms ..................... 164
4 NAVIGATION
SAFETY GUIDELINES
Ensure that all persons read this manual carefully before
using the navigation system. It contains instructions on
how to use the system in a safe and effective manner.
WARNING!
Please read and follow these safety precautions.
Failure to do so may result in injury or property
damage.
•
When using the navigation system to route you to an
emergency facility, contact the facility to verify its
location.
•
Not all emergency service locations are contained in
the database. Please use your own judgement and ask
for directions in such situations.
•
Glance at the screen only when necessary and safe to
do so. If prolonged viewing of the screen is necessary,
pull over at a safe location.
•
Road conditions and regulations take precedence over
information contained on the map display. Observe
actual traffic restrictions and circumstances when
driving.
•
Stop use immediately if a problem occurs. Failure to
do so may cause injury or damage to the product.
Return it to your authorized dealer to repair.
•
There may be situations where the navigation system
erroneously displays the vehicle’s location. Use your
own driving judgement in this situation, taking into
account current driving conditions. Please be aware
that in this situation the navigation system should
automatically correct the vehicle position within a few
minutes.
•
Make certain that the volume level of the system is set
to a level that still allows you to hear outside traffic
and emergency vehicles.
•
The map database is designed to provide you with
route suggestions and does not take into account the
relative safety of suggested route or factors that may
affect the time required to reach your destination. Use
your own personal judgement if the navigation system
is unable to provide you with an alternative route.
NAVIGATION 5
•
The law in some states prohibits the Front Seat DVD
Viewer. As a result, it may be disabled prior to delivery
to you. If you move to another state, you should
consult your dealer for the proper enable/disable
setting for your new state. Currently all states prohibit
front seat video viewers except for: Arkansas, Delaware, Georgia, Hawaii, Idaho, Iowa, Kentucky, Mississippi, Missouri, Montana, North Dakota and Ohio.
6 NAVIGATION
INTRODUCTION
Warnings
This manual contains WARNINGS against operating
procedures that could result in an accident or bodily
injury. If you do not read the entire manual you may miss
important information. Observe all WARNINGS!
The information given in this manual is subject to
change.
Safety References
Before operating this navigation system for the first time,
please read this manual carefully. Note the safety precautions described in this manual. If you have any questions,
please contact the vehicle manufacturer.
Intended Use
Generally recognized rules of navigation technology
were maintained during the development and manufacture of this navigation system. When using this product,
be aware of state-specific norms and guidelines.
Visit http://www.chrysler.com/en/owners/mygig/ for
updates, additional information, compatible phones, etc.
System Care
Software Update
Both navigation data and Gracenote威 data are software
updatable. Visit http://www.chrysler.com/en/owners/
mygig/ or contact your authorized dealer for the latest
available software.
Safe Usage of the Radio Navigation System
Read all instructions in this manual carefully before
using your radio system to ensure proper usage.
Your radio is a sophisticated electronic device. Do not let
young children use your radio unsupervised.
Permanent hearing loss may occur if you play your music
at the highest volume. Exercise caution when setting the
volume on your radio.
Driving is a complex activity that requires your full
attention. If you’re engaged in driving or any activity that
requires your full attention, we recommend that you not
use your radio navigation system.
NOTE: Many features of this radio are speed dependent. For your own safety it is not possible to use the
touch screen keyboard to enter a name (e.g., street name),
while the vehicle is in motion. Pull over at a safe location
to complete your task.
Keep drinks, rain, and other sources of moisture away
from your radio. Besides damage to your radio, moisture
can cause electric shocks with any electronic device.
NOTE: In a convertible vehicle, the system performance
may be compromised with roof top down.
Connections
Never force any connector into the ports of your radio.
Make sure your connectors are the correct shape and size
before you connect.
NAVIGATION 7
Any attached cable should be routed so that it will not
apply any pressure to the connection.
Do not use a USB device which will interfere with the
operation of opening the display.
Touch Screen
Do not touch the screen with any hard or sharp objects
which could scratch the touch screen surface (pen, USB
stick, jewelry, etc.)!
NOTE: It is possible to use a plastic stylus for press
screen enabled devices such as PDA and Pocket PCs.
Do not spray any liquid or caustic chemicals directly on
the screen. Use a clean and dry microfiber lens cleaning
cloth in order to clean the touch screen.
8 NAVIGATION
If necessary, use a lint-free cloth dampened with a
cleaning solution such as isopropyl alcohol or an isopropyl alcohol and water solution ratio of 50:50. Be sure to
follow solvent manufacturer’s precautions and
directions.
CD/DVD Drive
Do not insert any damaged, warped, scratched or dirty
CDs or DVDs into the CD/DVD player.
Discs that have been modified with an adhesive label
should not be used in the CD/DVD player.
Do not insert more than one CD/DVD at a time into the
drive slot.
Do not insert anything other than the supported CD/
DVD formats. See Disc Mode section for information on
supported CD/DVD formats.
GPS Navigation Antenna
The antenna for the navigation GPS system is mounted in
various locations (depending on the vehicle model)
within the dashboard. Do not place items on the dashboard around the GPS antenna location. Objects placed
within the line of sight of the antenna will decrease
performance. Do not place items directly on or above the
antenna.
Satellite Antenna
The antenna for the satellite radio and SIRIUS Backseat
TV™ is mounted on the roof of the vehicle. Do not place
items on the roof around the roof top antenna location.
Objects placed within the line of sight of the antenna will
cause decreased performance. Larger luggage items
should be placed as far from the antenna as possible. Do
not place items directly on or above the antenna.
Other Electronic Devices
You may bring other electronic devices into your vehicle
(e.g., PDA, iPod, laptop computer, etc.). Some of these
devices may cause electromagnetic interference with the
GPS. If a degradation in the navigation system is observed, turn the devices off, or keep them as far away
from the GPS antenna as possible.
NAVIGATION 9
10 NAVIGATION
GENERAL HANDLING
User Interface Elements
Power to operate the navigation radio is supplied
through the ignition switch, which must be in the ON,
ACC or in ACC Delay mode in order to operate the
navigation radio.
Soft-Keys
Soft-keys are accessible on the touch screen.
Hard-Keys
Hard-keys are on the left and right side of the radio
faceplate.
(1) OPEN/CLOSE
To open or close the display, press the OPEN CLOSE
hard-key (1).
After opening the display, it takes a few seconds to eject
a CD/DVD, if one was in the slot.
When inserting a disc, make sure the label is facing up.
The display will close automatically after inserting the
disc.
NOTE:
•
It may take several seconds to recognize the type of
inserted disc (CD, DVD, MP3, etc.).
•
If a CD or DVD will not eject from the player when the
OPEN/CLOSE hard-key is pressed, the user can perform the following eject override procedure:
NAVIGATION 11
(3) RADIO/MEDIA
Press the RADIO/MEDIA hard-key (3) to toggle between
RADIO and MEDIA mode.
1. Press the OPEN/CLOSE hard-key to open the display
door.
2. If the display door will not open when the hard-key is
pressed, manually open the display door by gently
pulling out on the bottom of the display door.
3. While the display door is open, simultaneously press
and release the SEEK UP, SEEK DOWN and NAV hardkeys.
4. The CD or DVD will eject from the player.
(2) SEEK UP/SEEK DOWN
Press the SEEK up and the SEEK down hard-key (2) to
seek through radio stations in AM, FM, or SAT bands.
Seek through tracks in CD or iPod威 modes or through
songs in the HDD playlist.
(4) ON/OFF VOLUME
It is possible to set the unit in standby mode during
driving by pressing the ON/OFF VOLUME rotary knob
(4).
NOTE: If the ignition is switched OFF with the radio in
standby mode, the radio memorizes the standby state
when the ignition is switched ON again. Press the (4)
ON/OFF VOLUME rotary knob to switch the radio ON.
The navigation software is always working when the
ignition is switched ON, even if the radio is in standby
mode. It is possible to eject the CD and to display the
time if the unit is switched off.
12 NAVIGATION
(5) Voice Command
Press the Voice Command hard-key (5)
and wait for the confirmation beep before you
say a voice command.
NOTE: Some vehicles may be equipped with a Voice
Command button on the steering wheel.
(6) Uconnect™ Phone
Press the Uconnect™ Phone
hard-key (6)
to either activate the Uconnect™ Phone system
or to cancel an active phone call.
NOTE:
•
If you are in one of the navigation menus (NAV Menu,
MAP display, etc.), you need to press the Uconnect™
Phone hard-key twice to end an active call.
•
Some vehicles may be equipped with a Uconnect™
Phone button on the steering wheel.
(7) MENU
Press the MENU hard-key (7) to access the system
settings menu.
NOTE: Press the MENU hard-key in an active mode in
order to change mode specific settings.
(8) NAV
Press the NAV hard-key (8) either to switch to the
navigation mode or to toggle between the navigation
menu and the map viewer menu.
(9) USB Connector
Connect a supported device into the USB connector (9) in
order to copy files to the internal hard disk drive.
NOTE: See USB connector section for information on
supported devices.
(10) AUX Connector
Connect an external audio device into the AUX Input (10)
(e.g., MP3 player, video-game), to play the device audio
through the car audio system.
Electronic Vehicle Information Center (EVIC)
Some vehicles feature an Electronic Vehicle Information
Center (EVIC) with driver-interactive display. The EVIC
is normally located in the instrument cluster or overhead.
It can display radio station frequencies, CD disc number,
satellite radio channel, and navigation system
information.
Steering Wheel Mounted Controls (If Equipped)
The remote sound system controls are located on the rear
surface of the steering wheel. Please refer to the vehicle
specific Owner’s Manual on the DVD for detailed information.
The following describes general steering wheel functionality:
NAVIGATION 13
1. The VOLUME rocker switch, located on the right,
controls the volume of the sound system. Pressing the top
of the rocker switch will increase the volume and pressing the bottom of the rocker switch will decrease the
volume.
2. The MODE ADVANCED button, located in the center
of the right rocker switch, changes the mode of the
navigation radio between the various modes available
(FM, AM, CD, DVD, SAT, TV, NAV etc.).
3. The FUNCTION SELECT button, located in the center
of the left rocker switch, advances the navigation radio to
the next preset, changes the current disc when in disc
mode, etc. The function is different depending upon
which mode is in use.
4. The SCROLL rocker switch, located on the left,
changes selections such as radio station, CD track, and
satellite radio channel, depending upon the current
mode.
14 NAVIGATION
The following describes the operation of the SCROLL
switch in each mode:
AM/FM/SAT Operation
Pressing the top of the rocker switch will seek up for the
next available station and pressing the bottom of the
rocker switch will seek down for the next available
station.
SIRIUS Backseat TV™ Operation
If equipped with a SIRIUS Backseat TV™, this control
will function the same way as in SIRIUS Satellite Radio
mode.
The Voice Command button (if equipped) will have the
same functionality as the Voice Command hard-key on
the radio faceplate.
HDD/Disc/iPod威 Operation
Pressing the top of the rocker switch will go to the next
track on the disc, and pressing the bottom of the rocker
switch will go to the beginning of the current track, or to
the beginning of the previous track, if it is within eight
seconds of the start of the current track.
Video Entertainment System™ Operation
If equipped with a remote video player, this control will
function the same way as in disc mode.
The Uconnect™ Phone button (if equipped) will have the
same functionality as the Uconnect™ Phone hard-key on
the radio faceplate.
Audio Settings
Volume
Use the ON/OFF VOLUME rotary knob (4) to adjust the
volume of the currently playing audio source. While you
adjust the volume, the name of the audio source and a
volume indicator are displayed in the lower left corner of
the display.
Audio Control Menu
Press the MENU hard-key (7) on the right side of the
radio. Then press the Audio Control soft-key to get to the
audio control menu.
Use either the arrow soft-keys or the cross-hair on the
screen to change Balance and Fade. The CENTER softkey resets the settings.
NAVIGATION 15
Press the Equalizer soft-key and use either the arrow
soft-keys or the sliders on the screen to adjust BASS,
MID, and/or TREBLE.
16 NAVIGATION
GETTING STARTED
NOTE: The ignition switch must be in the ON or ACC
position to operate the navigation radio.
If the unit is off, switch it on using the ON/OFF Volume
rotary knob.
Disclaimer for Navigation Radio
Before using the navigation radio read and accept the
disclaimer. The disclaimer will be activated after the
ignition is turned on.
Change the Language
The navigation radio will conform to the vehicle language set in the Electronic Vehicle Information Center
(EVIC), if equipped.
If you change the language in the navigation radio, the
system will change the language for all display information. Refer to your owner’s manual for more information.
To change the language with the navigation radio:
1. Press the MENU hard-key on the right side of the
radio.
2. Press the System Setup soft-key to get to the System
Setup menu.
NAVIGATION 17
3. Press the Language soft-key and select a language.
Set the Time
1. Press the Time Display soft-key in the lower left corner
of the screen.
The time is automatically set by the GPS system for the
time zone selected.
2. Press the Set Time Zone soft-key to change to the
desired time zone.
3. Press the Daylight Savings soft-key to switch Daylight
Savings on or off.
18 NAVIGATION
It is possible to set the time manually (ahead or behind
actual GPS time), by pressing the USER CLOCK soft-key.
Store Radio Presets
1. Press the Radio Media hard-key until AM FM SAT is
displayed in the upper left corner of the screen.
2. Select the radio band by touching either the AM, FM
or SAT soft-key.
3. Either press the SEEK up/down hard-keys, or touch
the SCAN soft-key, DIRECT TUNE soft-key, or the left
and right arrows to change the currently playing station.
NOTE: If the preset list is not displayed press the
PRESETS soft-key located in the bottom line of the screen.
4. Touch and hold one of the station preset soft-keys for
two seconds and you will see the highlighted soft-key
change from green to beige. You will also see the radio
station stored in the highlighted soft-key, and you will
hear a confirmation beep when the station is saved.
You can use the PAGE soft-keys to scroll through
the list of presets.
You can use the FULLSCREEN soft-key to toggle
between fullscreen and splitscreen mode. Long
preset names are displayed in fullscreen mode.
Connect Bluetooth姞 Phone
NAVIGATION 19
This menu lists all paired Bluetooth威 devices.
1. Press the MENU hard-key on the right side of the
radio.
2. Then touch the System Setup soft-key to get to the
System Setup menu.
3. Touch the Phone Pairing soft-key to access the
Bluetooth威 Devices menu.
4. Press the PAIR soft-key to start a new pairing.
5. You can use the BACK soft-key to switch to
the previous menu.
20 NAVIGATION
6. Enter any 4 Digit Security PIN and touch the PAIR
soft-key again.
7. The pairing procedure starts. Refer to the user’s
manual of your Bluetooth威 phone to complete the procedure.
8. You will then be asked to set a priority for the paired
phone. If there is more than one paired phone available,
the navigation radio will try to connect to the phone with
the highest priority setting.
NOTE: If the phone book download feature is supported by your cell phone, only the first 1000 contacts
will be automatically copied to the radio. Contacts will be
downloaded from your SIM card first and then copied
from your phones default phone book.
Set Default Country
NAVIGATION 21
Set Default State
1. Press the NAV hard-key on the right side of the radio.
2. Press the MENU hard-key.
3. Touch the NAV Settings soft-key.
4. Touch the Set Default Country soft-key to select your
default country.
1. Press the NAV hard-key on the right side of the radio.
2. Press the MENU hard-key.
3. Touch the NAV Settings soft-key.
4. Touch the Set Default State soft-key to choose your
default state.
22 NAVIGATION
Enter Home Address
1. Press the NAV hard-key on the right side of the radio.
If the radio does not display the NAV - Main Menu, press
the NAV hard-key again.
2. Touch the Guide Me Home soft-key to enter your
home address.
If no home address has been set, touch YES to access the
Enter Home Address menu.
3. Touch Street Address to enter your address.
4. Touch the soft-key with your state’s name and enter
your street name into the speller.
NOTE: Read more about destination input and the
predictive speller in the Navigation section of this
manual.
5. Once the street name has been input, touch continue to
confirm.
6. Enter the house number into the next screen. If more
than one city has this address, you will then need to
select your city from a list.
Once the address is entered completely, the system shows
a map of your home address area.
NAVIGATION 23
7. Touch the SAVE soft-key to confirm the address.
After you have entered your home address, the system
will start a route guidance to your home every time you
press the Guide Me Home soft-key.
24 NAVIGATION
Change Home Address
This procedure will allow you to change your Home
Address if one has already been entered.
1. Press the MENU hard-key.
2. Touch the My Files soft-key.
3. Touch the My Address Book soft-key.
4. Touch the Home soft-key.
NAVIGATION 25
5. Touch the Edit Contact soft-key.
6. Touch the Change Address soft-key.
7. Touch the soft-key with your state’s name and enter
your street name into the speller.
NOTE: If the State or Country needs to be changed,
touch the appropriate soft-key to edit the setting.
8. Once the street name has been input, touch continue to
confirm.
9. Enter the house number into the next screen. If more
than one city has this address, you will then need to
select your city from a list.
26 NAVIGATION
Once the address is entered completely, the system shows
a map of your home address area.
10. Touch the SAVE soft-key to confirm the address.
After you have changed your home address, the system
will start a route guidance to your home every time you
press the Guide Me Home soft-key.
Voice Command Tutorial
When you press the Voice Command hard-key, you will
hear a beep. The beep is your signal to give a command.
Say TUTORIAL to listen to a Voice Command tutorial.
Press any hard-key or touch the display to cancel the
tutorial.
Uconnect™ Phone Tutorial
When you press the Uconnect™ Phone hard-key, you
will hear a beep. The beep is your signal to give a
command. Say TUTORIAL to listen to a Uconnect™
Phone system tutorial.
Press any hard-key or touch the display to cancel the
tutorial.
Uconnect™ Multimedia (RADIO)
Radio Mode
Overview
The RER navigation radio is equipped with four different
tuners:
•
FM 87.7 MHz - 107.9 MHz (RBDS capable)
•
AM 530 kHz - 1710 kHz
•
SAT SIRIUS Satellite Radio (over 130 channels)
•
TV SIRIUS Backseat TV™
Toggle between the radio and the media menus by
pressing the RADIO/MEDIA hard-key. The different
tuner modes can be selected via the tabs in the radio
screen.
NAVIGATION 27
Satellite Radio Mode
In order to receive satellite radio, the vehicle needs to be
outside with a clear view to the sky. If the screen shows
Acquiring Signal, you might have to change the vehicle
position in order to receive a signal. In most cases, the
satellite radio does not receive a signal in underground
parking garages or tunnels.
28 NAVIGATION
Station Presets
There are 12 station presets available for storing the radio
stations in each tuner range.
Touch the arrows to the left and right of the DIRECT
TUNE soft-key to step manually through the frequency
or channel roster.
In order to store the desired station, touch and hold one
of the station preset soft-keys for two seconds and you
will see the highlighted soft-key change from green to
beige. You will also see the radio station stored in the
highlighted soft-key, and you will hear a confirmation
beep when the station is saved.
Change a Channel or Frequency
Press the SEEK up or the SEEK down hard-key to play
the next available station or channel.
Select DIRECT TUNE to enter a frequency or a channel
number, and confirm your selection by pressing the GO
soft-key.
Select the SCAN soft-key for a five second preview of
each listenable station in the frequency band. Touch the
SCAN soft-key again to stop the scan function and to
select a radio station.
RBDS (Radio Broadcast Data System)
This radio navigation system is capable of receiving
RBDS signals in the FM band. RBDS is a technology used
for transmitting textual information about the music
type, song and artist for FM band music. This information is shown on the display.
NOTE: Not all radio stations support RBDS.
The RBDS information is displayed below the frequency
reading of the currently playing radio station.
Radio Text Information
Select the INFO soft-key to display additional radio text
information in the right half of the screen.
NAVIGATION 29
Program Type (PTY) is only available in FM and SAT
mode. Radio stations are grouped according to their
program (e.g., Soft Rock, Rhythm & Blues, etc.).
Select the CLOSE INFO soft-key to hide additional radio
text information.
MUSIC TYPE (Program Type Filter)
Select MUSIC TYPE to enable and/or disable desired
program types. The SEEK and SCAN function will then
only display stations with matching program types.
RBDS (FM) Program Types
Adult Hits, Classic Rock, Classical, College, Country,
Information, Jazz, Language, News, Nostalgia, Oldies,
Personality, Public, Religious Music, Religious Talk,
Rhythm and Blues, Rock, Soft, Soft Rhythm and Blues,
Soft Rock, Sports, Talk, Top 40, Weather
SIRIUS Satellite Radio Program Types
Pop, Rock, Electronic/Dance, Hip-Hop, Rhythm and
Blues, Country, Christian, Jazz and Blues, Standards,
Classical, Latin, International, Talk, Political Talk, Comedy, Entertainment, Howard Stern, Martha Stewart, Family & Kids, Sports Talk & News, College, NFL, NBA,
30 NAVIGATION
NHL, More Sports, Soccer, NASCAR, Financial News, US
News, International News, Public Radio, Weather, Religion.
You can find the latest SIRIUS channel line up at
http://www.sirius.com.
Radio Settings
AM / FM MENU
There are no specific settings for this mode.
SAT MENU
While in SAT mode press the MENU hard-key to display
the SAT Menu.
Channel verses Preset List Selection
Select Presets List to display only user presets on the
right side of the SIRIUS Satellite Radio screen. Press
PRESETS/HIDE LIST in the SAT screen to turn the
presets list on or off.
Deselect Presets List to display all channels on the right
side of the SIRIUS Satellite Radio screen. Press SHOW
LIST/HIDE LIST in the SAT screen to turn the list on or
off.
Parental Lockout
Select Parental Lockout to enable and/or disable desired
channels. The SEEK and SCAN function will then only
display channels without parental lockout.
Re-Subscribe to SIRIUS Satellite Radio
New vehicle purchasers or lessees will receive a free
limited time subscription to SIRIUS Satellite Radio and
Realtime Traffic Service with your navigation radio.
Following expiration of the free services, it will be
necessary to access the information on the Subscription
Information screen in order to re-subscribe.
Touch the Subscription soft-key to access the Subscription Information screen.
NAVIGATION 31
Write down the SIRIUS ID numbers for your receiver. To
reactivate your service either call the number listed on
the screen or visit the provider online.
SAT Video Menu (if equipped)
While in TV mode press the MENU hard-key to display
the SAT-Video Menu.
Re-Subscribe to SIRIUS Backseat TV™
New vehicle purchasers or lessees will receive a free
limited time subscription to SIRIUS Backseat TV™ with
your radio. Following expiration of the free services, it
will be necessary to access the information on the Subscription Information screen in order to re-subscribe.
32 NAVIGATION
Touch the Subscription soft-key to access the Subscription Information screen.
Write down the SIRIUS ID numbers for your receiver. To
reactivate your service either call the number listed on
the screen or visit the provider online.
NOTE: SIRIUS Backseat TV™ is not available in
Canada, Hawaii or Alaska.
Display Settings
Press the MENU hard-key and touch the Display Settings
soft-key to access the Display Settings menu.
Select the Daytime Colors soft-key to switch to manual
daytime mode and to adjust the brightness of the display
using daytime colors.
Select the Nighttime Colors soft-key to switch to manual
nighttime mode and to adjust the brightness of the
display using nighttime colors.
Select the Auto Color soft-key to switch to automatic
daytime/nighttime mode and to control the brightness of
the display using the light switch of the vehicle.
Touch the DONE soft-key to save your settings and to
return to the AM/FM/SAT Menu.
Screen-saver
To activate the screen-saver press the MENU hard-key
and touch the Screen Saver soft-key.
Once the screen saver is active, press any hard-key or
touch the display to deactivate it.
NAVIGATION 33
Touch the Default View soft-key to enable the default
view mode, where the vehicle brand logo is displayed in
the right half of the screen.
View Settings
Press the MENU hard-key to display a radio menu.
Touch the Picture View soft-key to enable the picture
view mode, where a picture can be displayed on the right
half of the radio screen. Refer to the Hard Disk Drive
section of this manual for a detailed example.
34 NAVIGATION
Touch the Map View soft-key to enable the map view
mode.
In Map View mode the navigation map or turn-by-turn
navigation (as shown above) can be displayed on the
right half of the radio screen (see Navigation View
Settings for more information).
ParkView™ Rear Backup Camera (if equipped)
When equipped with ParkView™, the radio display
shows the rear view camera picture as soon as the shifter
is in the REVERSE position for vehicles with automatic
transmission. In vehicles with manual transmission the
REVERSE gear must be engaged.
Touch the Camera Setup button in the System Setup
menu to disable or enable ParkView™.
NAVIGATION 35
36 NAVIGATION
Uconnect™ Multimedia (MEDIA)
Disc Mode
Overview
The navigation radio is equipped with a CD/DVD
player.
Toggle between the media and the radio menus by
pressing the RADIO/MEDIA hard-key. The different
media modes can be selected via the tabs in the radio
screen.
Disc Requirements
CAUTION!
This disc player will accept a 4 3/4 in (12 cm) disc
only. The use of other sized discs may damage the
disc player mechanism.
The radio is capable of playing compact discs (CD),
recordable compact discs (CD+R and CD-R), rewritable
compact discs (CD+RW and CD-RW), recordable DVD-R,
DVD+R, DVD-RW, and DVD+RW compact discs.
Your radio will play the following formats:
MP3, WMA, CD Audio, DVD Audio, and DVD Video,
DVD-ROM, DVD Plus, DualDisc, SA-CD (CD Layer).
Do not insert anything other than the supported CD/
DVD formats.
SACD (SACD layer) VCD, SVCD, VCD format on DVD
and MPEG-4 are not supported.
A complete list of supported CD/DVD formats is available at http://www.chrysler.com/en/owners/mygig/.
Inserting a Disc
1. Press the OPEN/CLOSE hard-key once.
2. With the printed side upwards, insert the disc into the
disc slot of the radio. The radio pulls the disc in automatically and closes the flip screen. The radio selects the
appropriate mode after the disc is recognized, and starts
playing the first track. The display shows “Reading...”
during this process.
NAVIGATION 37
NOTE: A faulty CD is NOT automatically ejected. Use
only standard size discs. Discs that have been modified
with an adhesive label should not be used in the CD/
DVD player.
High definition content and media (e.g., HD-DVD, BluRay) is not supported.
If the user does not remove an ejected CD within
approximately 10 seconds, the CD will reload.
NOTE: On MP3 and WMA CDs with a large number of
songs, it may take several seconds to read, play, and
display information for all songs on the disc.
NOTE: Recording your own CD on a home computer at
a lower write speed will result in a more consistent
quality.
38 NAVIGATION
Removing a Disc
1. Press the OPEN/CLOSE hard-key.
2. The disc is ejected and can be removed.
NOTE: If the disc is not removed within approximately
10 seconds, the unit pulls it back into the slot (park
position). The disc may be ejected when the ignition is
OFF.
3. Press the OPEN/CLOSE hard-key to close the display.
The display will close automatically within 30 seconds
after the disc is removed.
Selecting Disc Mode
Toggle between the media and the radio menus by
pressing the RADIO/MEDIA hard-key. The disc mode
can be selected by touching the Disc tab soft-key.
NOTE: When a disc is inserted, the appropriate mode is
automatically selected once the disc is recognized.
Scan Search
Touch the SCAN soft-key.
The individual tracks of the disc will be played in
succession for eight seconds each.
Select the STOP SCAN soft-key to stop the scan function.
Next Track
Press the SEEK up hard-key. The next track on the disc is
played. Once the last track has been reached in the
forward direction, the unit will loop back to the first
track.
Previous Track
Pressing the SEEK down hard-key plays the previous
track. If the first track has been reached in the backward
direction, the unit will switch from the first track to the
last track. If a track has been playing for more than one
second when the SEEK down hard-key is pressed, the
unit will skip back to the beginning of the current track.
Fast Forward Track
Touch and hold the Fast Forward soft-key. The
audio will be heard at a reduced level while going
through the track in this mode. Stop the fast-forward by
releasing the Fast Forward soft-key.
Rewind Track
Touch and hold the Fast Reverse soft-key. The audio
will be heard at a reduced level while going
through the track in this mode. Stop the fast reverse by
releasing the Fast Reverse soft-key.
Displaying the Elapsed Title Time
The elapsed title time of the current playing track is
displayed in the left center of the screen.
Select Title from List
Select LIST to display a list of the titles of the currently
playing disc. Select the desired track you wish to play.
Select HIDE LIST to hide the list.
NAVIGATION 39
Disc Info
Select INFO to display title, artist, album and genre
information in the right half of the screen.
Select CLOSE INFO to close the information.
Gracenote威 Music Recognition Technology
This navigation radio is equipped with the Gracenote威
Music Recognition Service, with an embedded database
to look up album, song title, genre and artist information.
Data will be found for most Audio CDs (CDA discs).
Data will not be found for DVDs or data discs (those with
MP3 or WMA files).
40 NAVIGATION
Music recognition technology and related data are provided by Gracenote威. Gracenote威 is the industry standard in music recognition technology and related content
delivery. For more information visit www.gracenote.com.
NOTE: Visit http://www.chrysler.com/en/owners/
mygig/ for update information.
Copy Disc to Hard-Drive
Read about copying discs in the Hard Disk Drive section
of this manual.
Disc Menu
While in disc mode with audio disc inserted, press the
MENU hard-key to access the Disc Menu.
Select Random to play the titles on the disc in random
order. Select Random again to turn Random off.
Select Rpt. TRK to repeat the currently playing title.
Touch the Rpt. TRK soft-key again to stop the repeat
mode.
Select Repeat Folder to repeat all songs in the currently
playing folder (MP3/WMA disc only). Touch the Repeat
Folder soft-key again to stop the repeat mode.
Playing a MP3/WMA Disc
1. Press the OPEN/CLOSE hard-key once.
2. With the printed side upwards, insert the disc into the
disc slot of the radio. The radio pulls the disc in automatically and closes the flip screen. The radio selects the
appropriate mode after the disc is recognized, and starts
playing the first track. The display shows “Reading...”
during this process.
A MP3/WMA disc may contain audio files in a folder
structure. The folder, if any, is shown in the list view.
Touch the BROWSE soft-key if the list is not displayed.
NAVIGATION 41
3. Touch the soft-key with a folder symbol to open a
folder.
4. Touch the BACK soft-key to close a folder.
42 NAVIGATION
Playing a Video DVD
NOTE: Viewing a DVD video on the radio screen is not
available in all states/provinces, and the vehicle must be
stopped, and the shifter must be in the PARK position for
vehicles with automatic transmission. In vehicles with
manual transmission the parking brake must be engaged.
Insert a video DVD first.
The playback starts automatically after the DVD video is
recognized by the disc drive.
Touch the LIST soft-key to display a list of available
chapters or tracks. Touch a chapter or track soft-key in
the list to start playback from the selected section.
Touch the VIEW VIDEO soft-key to view the video on the
screen.
DVD Menu Controls
If you insert a DVD video disc that contains a top menu,
a menu may appear.
Touch the cursor arrow soft-keys to select the title you
want to view, then touch the ENTER soft-key to start
playback.
NAVIGATION 43
DVD Playback Controls
In video playback mode, touch anywhere on the screen to
show the DVD playback controls.
Touch the soft-key to move the controls to the right
part of the screen.
Touch the soft-key to close the DVD Menu Controls.
Touch the soft-key to pause playback.
Touch the soft-key to stop playback.
44 NAVIGATION
Touch the soft-key during playback to fast reverse
playback.
Touch the soft-key during playback to fast forward
playback.
Touch the NEXT soft-key to locate succeeding chapters or
tracks.
Touch the PREV soft-key to start playback from the
beginning of the current chapter or track. When you
press twice in quick succession, playback starts from the
beginning of the preceding chapter or track.
Touch the soft-key to move the controls to the right
part of the screen.
DVD Video Menu
While in disc mode with a DVD inserted, press the
MENU hard-key to access the DVD Video Menu.
Touch the soft-key to close the DVD MENU
Controls.
Touch the DVD Setup soft-key to access the DVD Setup
menu.
NAVIGATION 45
Disc Skipping
Skipping is typically caused by a damaged (scratched)
disc. This will result in a 10 second jump forward until
the damaged area is passed.
Temperature Protection
If the temperature of the disc reader during operation
becomes too high, a popup message will inform the user
of an over temperature situation. The unit switches to
radio mode until the disc reader temperature has
dropped to a normal level.
In the DVD Setup menu you may select Menu Language,
Audio Language, Subtitle, Camera Angle, Aspect Ratio,
and Brightness settings by pressing the corresponding
soft-key. Some of the soft-keys are disabled if the inserted
disc does not support the functionality.
Hard Disk Drive Mode (HDD)
The HDD mode gives you access to the audio files on the
internal hard disk drive. It functions similar to a CD
player, with the exception that the internal HDD can hold
more tracks. It can hold approximately 4,250 four-minute
CD-quality songs.
Before using the HDD mode, you will need to copy tracks
to the internal hard drive.
46 NAVIGATION
The files will be stored on the internal hard disk drive
and can be used in the HDD mode.
Copy Audio Disc to Hard-Drive
1. Insert a disc.
2. While in the DISC mode, press the MENU hard-key to
access the Settings Menu.
3. Touch the My Files soft-key.
4. Select My Music.
5. Touch the Import Music Files soft-key.
6. Touch the From DISC soft-key in the next screen to
copy music tracks of the inserted disc to the hard disk
drive.
During the copy process, the disc player cannot play
audio.
The copy progress is shown in the display.
NAVIGATION 47
It is possible to listen to radio modes during this process.
Copying time is greater than 5x the normal playback rate.
NOTE: When copying CD Audio to HDD, audio files
are converted from CD Audio to WMA. DVD-Audio
cannot be copied to the HDD.
Copy WMA/MP3 Files to Hard-Drive
You can copy MP3 and WMA formatted compressed
audio files from a disc or via USB (e.g., USB stick).
It is recommended to sort music files into folders.
48 NAVIGATION
Example:
Songs located in the root level (top level) of the disc or
USB device are saved in a playlist named Root_Level_
Songs.
Once the songs are copied, the playlist will be named by
the originating folder name.
For the example above the list on the HDD will show the
following:
Disc_Root_Level Songs (Playlist 1)
•
Song 1.mp3 (First song in Playlist 1)
•
Song 2.mp3 (Second song in Playlist 1)
•
Song 3.wma (Third song in Playlist 1)
My Playlist Folder 1 (Playlist 2)
•
Song 1.mp3 (First song in Playlist 2)
•
Song 2.mp3 (Second song in Playlist 2)
•
Song 3.mp3 (Third song in Playlist 2)
Copying Complete Disc
1. Insert a disc with MP3, WMA files.
NAVIGATION 49
During the copy process, the disc player cannot play
audio.
2. Refer to the Copy Audio Disc to Hard Drive
procedure.
The copy progress is shown in the display.
It is possible to listen to radio modes during this process.
50 NAVIGATION
Selective Song Copying from Disc
You can select specific songs on a WMA/MP3 disc using
the following procedure:
1. While in the DISC mode, press the MENU hard-key to
access the Settings menu.
2. Touch the My Files soft-key.
3. Select My Music. 4. Touch the Import Music Files soft-key.
5. Touch the From DISC soft-key in the next screen.
NAVIGATION 51
52 NAVIGATION
6. Select the folders or titles you would like to copy.
A red check mark indicates the selected songs and/or
folders. Touch the ALL soft-key to select all files and
folders at once.
7. Touch the DONE soft-key to start the copy process.
The copy process is shown on the display. It is possible to
listen to radio modes during this process.
If you unplug or eject the media before the copying
process is finished, the process will be interrupted. You
may restart the copying process by repeating the steps
above.
Copying from USB
1. Insert a USB device.
2. Select My Music.
NAVIGATION 53
3. Touch the Import Music Files soft-key.
4. Touch the From USB soft-key in the next screen.
54 NAVIGATION
5. Select the folders or titles you would like to copy.
A red check mark indicates the selected songs and/or
folders. Touch the ALL soft-key to select all files and
folders at once.
6. Touch the DONE soft-key to start the copy process.
Playing Audio Files from the Hard Disk Drive
You can play songs directly from the internal hard disk
drive.
1. Touch the BROWSE soft-key to select an available
category.
The navigation radio can sort the files by playlist, by song
name, by artist, by genre, by album, or from favorites.
2. For this example, touch the Playlists soft-key.
NAVIGATION 55
3. Touch a soft-key with the desired playlist name to play
a playlist.
Touch the PLAY ALL PLAYLISTS soft-key to play all
available playlists.
56 NAVIGATION
Next Track
Press the SEEK up hard-key. The next track of the current
playlist is played. Once the last track has been reached in
the forward direction, the unit will loop back to the first
track.
Rewind Track
Touch and hold the Fast Reverse soft-key. The audio
will be heard at a reduced level while going
through the track in this mode. Stop the fast reverse by
releasing the Fast Reverse soft-key.
Previous Track
Press the SEEK down hard-key. The previous track of the
current playlist is played. If the first track has been
reached in the backward direction, the unit will switch
from the first track to the last track. If a track has been
playing for more than 10 seconds when the SEEK down
hard-key is pressed, the unit will skip back to the
beginning of the current track.
Fast Forward Track
Touch and hold the Fast Forward soft-key. The
audio will be heard at a reduced level while going
through the track in this mode. Stop the fast forward by
releasing the Fast Forward soft-key.
Displaying the Elapsed Title Time
The elapsed title time of the current playing track is
displayed on the left side of the screen.
HDD Menu
While in HDD mode, press the MENU hard-key to access
the HDD Menu.
Random Playback
The random play function plays random tracks from the
hard disk drive. Touch the Random soft-key to switch the
random play function on or off.
A red check mark indicates the random play function is
active.
Repeat Track
The repeat track function repeats the currently played
track. Touch the Rpt. TRK soft-key to switch the repeat
track function on or off.
A red check mark indicates the repeat track function is
active.
List ABC...
The List ABC... function sorts the HDD songs and
categories in alphabetical order.
Favorite Playlists on the Hard Disk Drive
You may save links to favorite playlists in the Favorite
Playlists list.
NAVIGATION 57
1. While in HDD mode, touch the Browse soft-key to
access the Browse Categories menu.
58 NAVIGATION
2. Touch the Favorites soft-key to display a list of favorite
playlists.
3. Touch one of the ADD FAVORITE soft-keys.
NAVIGATION 59
4. Select the desired playlist. You may use the A to Z
soft-key to navigate faster through very long lists.
A link to the selected playlist is now saved in the Favorite
Playlists list.
NOTE: The link to the favorite playlist will be removed
after a playlist was removed from the My Playlists menu.
Refer to Editing Playlists on the Hard Disk Drive in this
manual.
60 NAVIGATION
You may now edit the list by touching the EDIT soft-key,
or exit the list by touching the EXIT soft-key.
Editing Playlists on the Hard Disk Drive
1. While in the HDD mode, press the MENU hard-key to
access the HDD Menu.
2. Touch the My Files soft-key.
3. Select My Music. 4. Touch the My Playlists soft-key.
NAVIGATION 61
62 NAVIGATION
5. Touch the EDIT soft-key (example: DISC_Root_Level_
Songs) of the playlist you would like to edit.
You can rename the selected playlist, delete songs from
the selected playlist, or delete the selected playlist.
6. Touch the Rename This Playlist soft-key.
NOTE: If you touch the Delete This Playlist soft-key, the
playlist and all songs contained in it will be permanently
deleted. Neither song nor playlist can be recovered.
NAVIGATION 63
7. Type in a new name for the playlist.
8. Touch the SAVE soft-key to confirm the name.
The playlist now has the new name.
9. Touch the Delete Songs From This Playlist soft-key.
NOTE: If you touch the Delete This Playlist soft-key, the
playlist and all songs contained in it will be permanently
deleted. Neither song nor playlist can be recovered.
64 NAVIGATION
10. Select the titles you would like to delete.
A red check mark indicates the selected songs.
11. Touch the DELETE soft-key to start the delete process.
NOTE: If you delete a song from the playlist, the song
cannot be recovered.
12. Touch the DONE soft-key when you are done editing
the playlist.
Deleting All Playlists from the Hard Disk Drive
1. Press the MENU hard-key on the right side of the
radio.
2. Touch the System Setup soft-key to access the System
Setup menu.
3. Touch the Manage HDD soft-key to access the Manage
HDD menu.
This menu displays the available space on the hard disk
drive and allows you to delete pictures, music files, and
address book entries.
Importing Pictures
It is possible to import display pictures to the internal
hard disk drive. The pictures can be displayed on the
right half of the radio screen.
NAVIGATION 65
WARNING!
It is not possible to copy pictures from a USB device
or CD while the vehicle is in motion.
66 NAVIGATION
In the default mode, the vehicle brand logo is displayed
in the right half of the screen. Press the Menu hard-key on
the right side of the radio to access one of the Setting
menus.
It is recommended to change the picture dimensions on a
PC or Digital Camera to 240 by 158 pixels before the
import.
NOTE: USB devices (e.g., camera memory USB adaptors, etc.) must comply with the MSD (Mass Storage
Device) standard. This USB terminal can provide power
to the inserted device. The device’s current limitation
must be less or equal to 500mA.
1. Touch the My Files soft-key to go to the Manage My
Files screen.
NAVIGATION 67
2. Insert either a CD or a USB device containing your
pictures.
3. Touch the My Pictures soft-key to get an overview of
the currently stored images.
The navigation radio can store eight user pictures.
4. Press one of the Add Picture soft-keys.
68 NAVIGATION
5. Select the type of media inserted. 6. Use the PAGE soft-keys to page through a list of
pictures and press the picture you would like to import.
NOTE: Files must be in the root directory (top level) of
the disc or USB device to be recognized.
NAVIGATION 69
7. Confirm your selection by touching the YES soft-key. The imported picture is now available in the Manage My
Pictures screen.
8. In order to display the imported picture in the radio
screen, touch the desired picture soft-key.
70 NAVIGATION
9. Select this picture by pressing the Picture View soft-
key. A check mark indicates the currently used picture.
Use the PREV or NEXT soft-key to step through the list of
available pictures.
Touch the DELETE soft-key to delete the picture from the
hard disk drive.
10. Press the MENU hard-key twice and then touch the
Picture View soft-key to enable the picture view.
The picture is now displayed on the right half of the
screen.
Uconnect™ Multimedia (REMOTE DEVICES)
iPod姞 Mode (If Equipped)
The iPod威 mode gives you access to the audio files on the
external iPod威. It functions as a remote control for the
currently connected iPod威 mobile digital device, and you
can play audio from the iPod威 device through the
vehicles speaker system.
Before using the iPod威 mode, you will need to connect
your iPod威 device to the iPod威 connector. (See UNIVERSAL CUSTOMER INTERFACE (UCI) section in the vehicles Owner’s Manual on the DVD for instructions.)
NOTE: The files will not be stored on the internal hard
disk drive and cannot be used in the HDD mode.
NOTE: It is recommended that you use the latest
available software for your iPod威 and iTunes.
See manufacturer website for updates http://
www.apple.com/support/ipod/
NAVIGATION 71
Playing Audio Files from the iPod威 Device
You can play songs directly from the iPod威 device.
Touch the LIST soft-key to display a list view.
Touch the soft-key with the desired list item to select and
play the item.
Touch the HIDE LIST soft-key to hide the list.
72 NAVIGATION
Touch the BROWSE soft-key to browse by categories.
Select an iPod威 Category
The radio can sort the files by playlists, by song names,
by artists, by composers, by genres, by albums, by
podcasts or by audio books.
Touch a soft-key with the desired artist’s name to play
songs from this artist.
Touch the PLAY ALL soft-key to play songs from all
available artists.
Touch the Artists soft-key for this example.
Touch the PAGE UP or PAGE DOWN soft-key to navigate through the list of artists.
List Jump
If you encounter a very long list, it may be helpful to
touch the A to Z soft-key to go to the List Jump menu.
NAVIGATION 73
Touch a soft-key with the desired artist’s name to play
songs from this artist.
For this example we entered the first letter of the desired
artist.
Touch the GO soft-key to jump to the desired artist.
Next Track
Press the SEEK up hard-key. The next track of the current
folder is played. Once the last track has been reached in
the forward direction, the unit will loop back to the first
track.
74 NAVIGATION
Previous Track
Press the SEEK down hard-key. The previous track of the
current folder is played. If the first track has been reached
in the backward direction, the unit will switch from the
first track to the last track. If a track has been playing for
more than 10 seconds when the SEEK down hard-key is
pressed, the unit will skip back to the beginning of the
current track.
Pause
Touch the PAUSE soft-key to pause the playback.
Play
Touch the PLAY soft-key to start the playback.
Displaying the Elapsed Title Time
The elapsed title time of the currently playing track is
displayed on the left side of the screen.
Fast Forward Track
Touch the Fast Forward soft-key. The audio will be
heard at a reduced level while going through the
track in this mode. Stop the fast forward by releasing the
Fast Forward soft-key.
Rewind Track
Touch the Fast Reverse soft-key. The audio will be
heard at a reduced level while going through the
track in this mode. Stop the fast reverse by releasing the
Fast Reverse soft-key.
Scan Search
Touch the SCAN soft-key.
The individual tracks will be played in succession for
eight seconds each.
Select the STOP SCAN soft-key to stop the scan function.
Track Info
Touch the INFO soft-key.
Information on the currently playing track, if available,
will be displayed on the right half of the screen.
NAVIGATION 75
If additional information is available, the NEXT soft-key
will be displayed. Touch the NEXT soft-key to show the
additional information.
iPod威 Menu
While in iPod威 mode, press the MENU hard-key to
access the iPod威 Menu.
Random Playback
The random playback function plays random tracks from
the iPod威 device. Touch the Random soft-key to switch
the random play function on or off.
A red check mark indicates the random play function is
active.
76 NAVIGATION
Repeat Track
The repeat track function repeats the currently played
track. Touch the Rpt. TRK soft-key to switch the repeat
track function on or off.
A red check mark indicates the repeat track function is
active.
SIRIUS Backseat TV™ (if equipped)
SIRIUS Backseat TV™ Mode
NOTE: SIRIUS Backseat TV™ is not available in
Canada, Hawaii or Alaska.
Press the RADIO/MEDIA hard-key repeatedly until AM
FM SAT TV is display at the top of the screen. Touch the
TV soft-key tab to access SIRIUS Backseat TV™.
In order to receive SIRIUS Backseat TV™ the vehicle
needs to be outside with a clear view to the sky. If the
screen shows Acquiring Signal, you might have to
change the vehicle position in order to receive a signal. In
most cases, the satellite radio does not receive a signal in
underground parking garages or tunnels.
Channel List
Select LIST to display a list of available video channels.
Select HIDE LIST to hide the video channel list.
View SIRIUS Backseat TV™ on the Radio Screen
NOTE: To view SIRIUS Backseat TV™ on the radio
screen, the vehicle must be stopped, and the shifter must
be in PARK for vehicles with automatic transmission. In
vehicles with manual transmission the parking brake
must be engaged.
In order to watch the desired SIRIUS Backseat TV™
channel, touch the VIEW VIDEO soft-key.
For vehicles equipped with VES™, refer to the VES™
section of the Uconnect™ User’s Manual on the DVD for
additional details.
Video Entertainment System (VES)™
The navigation radio can remotely control the VES™.
For vehicles equipped with VES™, refer to the VES™
section of the Uconnect™ User’s Manual on the DVD for
additional details.
NAVIGATION 77
Receiving Audio/Video from the VES™
You can play audio from the VES™ through the vehicle’s
speaker system. If you have a VES™ with a video player,
you can also see the video on the radios display if the
vehicle is parked.
78 NAVIGATION
The VES tab becomes available after the VES™ system is
turned on. Touch the VES MODES soft-key to select the
VES™ audio source.
Touch the soft-key with the desired source to play in the
vehicle cabin.
Availability of the DVD Player soft-key, the Rear AUX 1
soft-key, and the Rear AUX 2 is based on the type of
VES™ in the vehicle.
DVD Player is not available if there is no DVD player in
the VES™ or there is no DVD in the player.
A device must be plugged into the AUX jack of the VES™
to be available.
A disabled soft-key indicates an unavailable source.
Sending Audio/Video and controlling the VES™
The navigation radio can also control the VES™.
All sources are played through the VES™ headphones.
For vehicles equipped with VES™, refer to the VES™
section of the Uconnect™ User’s Manual on the DVD for
additional details.
USB Connector
It is possible to transfer audio files or pictures files to the
navigation radio. Files can be on a disc or on a USB
device (e.g., USB stick). The USB connector is covered by
a small cover which protects the connector from dust or
damage.
NOTE: USB devices (e.g., camera memory USB adaptors, etc.) must comply with the MSD (Mass Storage
Device) standard. This USB terminal can provide power
to the inserted device. The device’s current limitation
must be less or equal to 500mA.
The transfer speed for this USB connector is approximately two megabytes per second.
NAVIGATION 79
MP3 player devices cannot be controlled through the
USB connector. Some player devices save music files in
MP4 format, which cannot be played in this radio. Some
copy protected music (e.g., downloads from the internet)
cannot be played on this radio.
Compatible Devices
Please see your authorized dealer or visit http://
www.chrysler.com/en/owners/mygig/ for supported
devices.
NOTE: Some MP3 players do not allow songs to be
copied into other devices.
80 NAVIGATION
How to open the cover
1. Place finger under the pull arrow.
2. Pull forward.
NOTE: The flap is attached and should not be removed!
Do not pull the flap off of the frame. Do not use a tool
(e.g., screw driver, nail file, etc.) to open the flap, as this
could cause damage to the face of the radio.
How to Close the Cover
1. Using your thumb and index finger, grasp the flap.
Notice the hooks (1), which must first be inserted into the
frame.
NAVIGATION 81
2. Hook the top hooks (1) into the frame first.
82 NAVIGATION
3. Then push on the bottom of the flap to secure in place.
CAUTION!
Never force any connector into the ports of your
radio. Make sure your connectors are the identical
shape and size before you connect.
AUX Mode
The AUX connector allows you to connect the headset
output of an audio device (e.g., MP3 player) to the
navigation radio. The audio of the connected device will
then be played through the navigation radio sound
system.
NAVIGATION 83
The display will switch automatically to the AUX mode
when a 3.5 mm stereo mini-jack cable has been connected.
The radio screen will revert back to the last tuner mode
when the cable is unplugged.
To change radio modes while the cable is connected to
the unit, press the RADIO/MEDIA hard-key until the
AUX tab is displayed on the top of the screen. Touch the
AUX tab to return to the AUX mode.
Adjust the volume with the ON/OFF VOLUME rotary
knob, or with the volume of the attached device.
Connect a 3.5 mm stereo mini-jack cable as shown above
(not provided with the radio) to the AUX connector on
the navigation radio and to the earphone connector of
your audio device.
The control of the external device (e.g., selecting playlists,
play, fast forward, etc.) cannot be provided by the radio;
use the device controls instead.
NOTE: Inserting a mono jack will result in improper
audio playback.
84 NAVIGATION
VOICE COMMAND
Voice Command Operation
Voice Command allows you to control your AM and FM
radio, satellite radio, disc player, navigation system, hard
disk drive storage, and a memo recorder.
NOTE: Take care to speak into the Voice Command
system as calmly and normally as possible. The ability of
Voice Command to recognize user voice commands may
be negatively affected by rapid speaking or a raised voice
level.
WARNING!
Any voice commanded system should be used only
in safe driving conditions and all attention should be
kept on the roadway ahead. Failure to do so may
result in an accident causing serious injury or death.
When you press the Voice Command
hard-key, you will hear a beep. The beep is
your signal to give a command.
NOTE: If you do not say a command within a few
seconds, the system will present you with a list of
options.
If you ever wish to interrupt the system while it lists
options, press the Voice Command
hard-key, listen
for the beep, and say your command.
Pressing the Voice Command
hard-key while the
system is speaking is known as “barging in.” The system
will be interrupted and you can add or change commands. This will become helpful once you start to learn
the options.
NOTE: At any time you can say the words CANCEL,
REPEAT, HELP, or MAIN MENU.
These commands are universal and can be used from any
menu or screen.
All other commands can be used depending upon the
active application.
For example: If you are in the navigation menu and you
are listening to FM radio, you can speak commands from
the navigation menu or from the FM radio menu.
When using this system, you should speak clearly and at
a normal speaking volume.
The system will best recognize your speech if the windows are closed and the heater/air-conditioning fan is
set to low.
At any point, if the system does not recognize one of your
commands, you will be prompted to repeat it.
NAVIGATION 85
To hear the first available Menu, press the Voice
Command
hard-key and say HELP or MAIN
MENU.
Display Menu
In addition to audible help, the navigation radio is able to
display the most important available commands on the
screen.
86 NAVIGATION
Commands
The Voice Command understands two types of commands. Universal commands are available at all times.
Local commands are available if the supported radio
mode is active.
Changing the Volume
1. Start a dialogue by pressing the Voice Command
hard-key.
2. Say a command (e.g., HELP).
3. Use the ON/OFF VOLUME rotary knob to adjust the
volume to a comfortable level while the Voice Command
system is speaking.
Main Menu
Start a dialogue by pressing the Voice Command
hard-key.
You may say MAIN MENU to switch to the main menu.
•
In this mode you can say the following commands:
•
RADIO (to switch to the radio mode)
•
HARD DRIVE (to switch to the HDD mode)
•
DISC (to switch to the disc mode)
•
VES (to switch to the VES™ mode)
•
MEMO (to switch to the memo recorder)
•
NAVIGATION (to switch to the navigation mode)
•
SYSTEM SETUP (to display the system setup menu)
Radio Menu
You may say RADIO to switch to AM, FM, or SAT.
Say RADIO MENU.
•
In this mode you may say the following commands:
•
RADIO AM (to switch to the AM band)
•
RADIO FM (to switch to the FM band)
•
SATELLITE RADIO (to switch to the satellite radio)
NAVIGATION 87
•
NEXT STATION (to select the next station)
•
PREVIOUS STATION (to select the previous station)
Radio AM
To switch to the AM band say AM or RADIO AM.
In this mode you may say the following commands:
•
FREQUENCY (to change the frequency)
•
NEXT STATION (to select the next station)
•
PREVIOUS STATION (to select the previous station)
•
RADIO MENU (to switch to the radio menu)
•
MAIN MENU (to switch to the main menu)
Radio FM
To switch to the FM band say FM or RADIO FM.
In this mode you may say the following commands:
•
FREQUENCY (to change the frequency)
•
RADIO MENU (to switch to the radio menu)
•
MAIN MENU (to switch to the main menu)
Satellite Radio
To switch to satellite radio mode say SAT or SATELLITE
RADIO. In this mode you may say the following commands:
•
STATION (1-250) (to change the station)
•
NEXT STATION (to select the next station)
•
PREVIOUS STATION (to select the previous station)
•
LIST STATIONS (to hear a list of available stations)
•
SELECT NAME (to change to the station named)
•
RADIO MENU (to switch to the radio menu)
88 NAVIGATION
•
MAIN MENU (to switch to the main menu)
In this mode you may say the following commands:
SIRIUS Backseat TV™
To switch to SIRIUS Backseat TV™ mode say SATELLITE
VIDEO. In this mode you may say the following commands:
•
STATION (256-258) (to change the station)
•
NEXT STATION (to select the next station)
•
PREVIOUS STATION (to select the previous station)
•
LIST STATIONS (to hear a list of available stations)
•
SELECT NAME (to change to the station named)
•
RADIO MENU (to switch to the radio menu)
•
MAIN MENU (to switch to the main menu)
Disc
To switch to the disc mode say DISC.
•
TRACK (1-250) (to change the track)
•
NEXT TRACK (to play the next track)
•
PREVIOUS TRACK (to play the previous track)
•
MAIN MENU (to switch to the main menu)
Hard Drive
To switch to the HDD mode say HARD DRIVE.
In this mode you may say the following commands:
•
TRACK (1-250) (to change the track)
•
NEXT TRACK (to play the next track)
•
PREVIOUS TRACK (to play the previous track)
•
MAIN MENU (to switch to the main menu)
VES™
To switch to the VES™ mode sayVES.
In this mode you may say the following commands:
•
VES
•
VES REMOTE LOCK (to lock the VES™ remote)
Memo
To switch to the voice recorder mode say MEMO.
In this mode you may say the following commands:
•
NEW MEMO (to record a new memo)
During the recording you may press the Voice
Command
hard-key to stop recording. You
proceed by saying one of the following commands:
−
SAVE (to save the memo)
−
CONTINUE (to continue recording)
NAVIGATION 89
−
DELETE (to delete the recording)
•
PLAY MEMOS (to play previously recorded memos)
During the playback you may press the Voice
Command
hard-key to stop playing memos.
You proceed by saying one of the following commands:
−
REPEAT (to repeat a memo)
−
NEXT (to play the next memo)
−
PREVIOUS (to play the previous memo)
−
DELETE (to delete a memo)
•
DELETE ALL (to delete all memos)
NOTE: Keep in mind that you have to press the Voice
Command
hard-key first and wait for the beep,
before speaking the “barge in” commands.
Loading...
