Power Door Lock Relay: Description and Operation

(ISO)

The driver unlock relay is a International Standards Organization micro-relay. The terminal designations and functions are the same as aconventional ISO relay. However, the micro-relay terminal orientation (or footprint) is different, current capacity is lower, and the relay case dimensionsare smaller than those of the conventional ISO relay.

The driver unlock relay is a electromechanical device that switches battery current to the left front door power lock motor when the Remote KeylessEntry receiver within the high-line Central Timer Module grounds the relay coil.(RKE) (CTM)

The driver unlock relay is located in the relay and fuse block attached to the back of the junction block, under the left side of the instrument panel in thepassenger compartment. The driver unlock relay cannot be repaired and, if faulty or damaged, it must be replaced.

> Relays and Modules > Relays and Modules - Body and Frame > Power Door Lock Relay > Component Information > Locations > Page 9

Power Door Lock Relay: Service and Repair
REMOVAL

WARNING: ON VEHICLES EQUIPPED WITH AIRBAGS, REFER TO AIRBAGS AND SEAT BELTS/AIRBAGS BEFOREATTEMPTING ANY STEERING WHEEL, STEERING COLUMN, OR INSTRUMENT PANEL COMPONENT DIAGNOSIS ORSERVICE. FAILURE TO TAKE THE PROPER PRECAUTIONS COULD RESULT IN ACCIDENTAL AIRBAG DEPLOYMENT ANDPOSSIBLE PERSONAL INJURY.

1. Disconnect and isolate the battery negative cable.2. Remove the steering column opening cover and knee blocker from the instrument panel.

Relay And Fuse Block

3. Reach through the outboard side of the steering column opening in the instrument panel to access the relay and fuse block on the back of the
junction block.

4. Unplug the driver unlock relay from the relay and fuse block.5. Install the driver unlock relay by aligning the relay terminals with the cavities in the relay and fuse block and pushing the relay firmly into place.6. Connect the battery negative cable.7. Test the relay operation.8. Reverse the remaining removal procedures to complete the installation.

> Relays and Modules > Relays and Modules - Body and Frame > Trailer Towing Relay > Component Information > Locations

Trailer Towing Relay: Locations

> Relays and Modules > Relays and Modules - Body and Frame > Trailer Towing Relay > Component Information > Locations > Page 13

Durango 2WD V8-5.9L VIN Z LDC (2000)

Power Distribution Center

is located in the Power Distribution Center (PDC).Trailer Tow Relay

Power Distribution Center (PDC)

is located in the left front corner of the engine compartment, just behind the battery.Power Distribution Center (PDC)

> Relays and Modules > Relays and Modules - Body and Frame > Trailer Towing Relay > Component Information > Locations > Page 14

Trailer Towing Relay: Diagrams

Power Distribution Center

Trailer Tow Relay

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Controller Antilock Brake <--> [Electronic Brake Control Module] > Component Information > Specifications

Controller Antilock Brake: Specifications

Controller Mounting Screws 53 in.lb

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Controller Antilock Brake <--> [Electronic Brake Control Module] > Component Information > Locations > EBC 325

Controller Antilock Brake (CAB) EBC 325

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Controller Antilock Brake <--> [Electronic Brake Control Module] > Component Information > Locations > EBC 325 > Page 21

Controller Antilock Brake (CAB) EBC 2

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Controller Antilock Brake <--> [Electronic Brake Control Module] > Component Information > Locations > Page 22

Controller Antilock Brake: Diagrams

Controller Antilock Brake C1 Black 14 Way

C1 Black 14 Way

Controller Antilock Brake C2 Black 4 Way

C2 Black 4 Way

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Controller Antilock Brake <--> [Electronic Brake Control Module] > Component Information > Locations > Page 23

Controller Antilock Brake: Description and Operation

(VSS)

The controller antilock brake module is used to monitor wheel speeds and modulates (control) hydraulic pressure in each brake channel. The modulatedhydraulic pressure is used to prevent wheel lock up during braking. The CAB also provides a Vehicle Speed Signal to the powertrain controlmodule.

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Controller Antilock Brake <--> [Electronic Brake Control Module] > Component Information > Service and Repair > Four Wheel Antilock System

Controller Antilock Brake: Service and RepairFour Wheel Antilock System

NOTE:

If the CAB needs to be replaced, the rear axle type and tire revolutions per mile must be programmed into the new CAB. For axle type refer toTransmission and Drivetrain, Differential. For tire revolutions per mile refer to Steering and Suspension, Tires, Wheels and Alignment. To program theCAB refer to Testing and Inspection, Procedures, Diagnostic Information and Procedures.

REMOVAL

1. Disconnect battery negative cable.

2. Push the harness connector locks to release the locks, then remove the connectors from the CAB.

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Controller Antilock Brake <--> [Electronic Brake Control Module] > Component Information >

Service and Repair > Four Wheel Antilock System > Page 26

Durango 2WD V8-5.9L VIN Z LDC (2000)

3. Disconnect the pump motor connector.

4. Remove screws attaching CAB to the HCU).5. Remove the CAB.

INSTALLATION

1. Place the CAB onto the HCU.

Insure the CAB seal is in position before installation.NOTE:

4-4.7 Nm (36-42 inch lbs.).

2. Install the mounting screws and tighten to 3. Connect the pump motor harness.4. Connect the harnesses to the CAB and lock the connectors.5. Connect battery.

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Controller Antilock Brake <--> [Electronic Brake Control Module] > Component Information > Service and Repair > Four Wheel Antilock System >

Page 27

Controller Antilock Brake: Service and RepairRear Wheel Antilock System

NOTE:

If the CAB needs to be replaced, the rear axle type and tire revolutions per mile must be programmed into the new CAB. For axle type refer toTransmission and Drivetrain, Differential. For tire revolutions per mile refer to Steering and Suspension, Tires, Wheels and Alignment. To program theCAB refer to Testing and Inspection, Procedures, Diagnostic Information and Procedures.

REMOVAL

1. Push the CAB harness connector lock to release the lock and remove the connector from the controller.2. Remove the RWAL valve harness connector from the controller.3. Remove the controller mounting screws and remove the controller from the mounting bracket.

INSTALLATION

6 Nm (53 inch lbs.).

1. Position the controller on the bracket.2. Install the mounting screws and tighten to 3. Install the RWAL valve harness connector into the controller.4. Install the CAB harness connector into the controller and push down on the connector lock.

> Relays and Modules > Relays and Modules - Cooling System > Radiator Cooling Fan Motor Relay > Component Information > Locations

Radiator Cooling Fan Motor Relay: Locations

> Relays and Modules > Relays and Modules - Cooling System > Radiator Cooling Fan Motor Relay > Component Information > Locations > Page 32

Durango 2WD V8-5.9L VIN Z LDC (2000)

Power Distribution Center

is located in the Power Distribution Center (PDC).Radiator Fan Relay

Power Distribution Center (PDC)

is located in the left front corner of the engine compartment, just behind the battery.Power Distribution Center (PDC)

> Relays and Modules > Relays and Modules - Cooling System > Radiator Cooling Fan Motor Relay > Component Information > Locations > Page 33

Radiator Cooling Fan Motor Relay: Diagrams

Power Distribution Center

Radiator Fan Relay

> Relays and Modules > Relays and Modules - Cooling System > Radiator Cooling Fan Motor Relay > Component Information > Locations > Page 34

Radiator Cooling Fan Motor Relay: Description and Operation
RADIATOR COOLING FAN RELAY - PCM OUTPUT

(PDC)

The radiator cooling fan relay is a 5-pin, solenoid type, mini-relay. It is located in the Power Distribution Center . Refer to label on PDCcover for relay location.

(PCM)

The electric radiator cooling fan is controlled by the Powertrain Control Module through the radiator cooling fan relay. The PCM willactivate the relay after receiving inputs from the engine coolant temperature sensor and/or an air conditioning on/off signal.

Not Equipped With A/C: 103 C (217 F)

The relay is energized when coolant temperature is above approximately . It will then de-energizewhen coolant temperature drops to approximately . Refer to Cooling Systems for additional information.98 C (208 F)

Equipped With A/C:

In addition to using coolant temperatures to control cooling fan operation, the cooling fan will also be engaged when the airconditioning system has been activated. Refer to Heating and Air Conditioning for additional information.

> Relays and Modules > Relays and Modules - HVAC > Blower Motor Relay > Component Information > Locations

Blower Motor Relay: Locations

> Relays and Modules > Relays and Modules - HVAC > Blower Motor Relay > Component Information > Locations > Page 39

Durango 2WD V8-5.9L VIN Z LDC (2000)

Power Distribution Center

is located in the Power Distribution Center (PDC).Blower Motor Relay

Power Distribution Center (PDC)

is located in the left front corner of the engine compartment, just behind the battery.Power Distribution Center (PDC)

> Relays and Modules > Relays and Modules - HVAC > Blower Motor Relay > Component Information > Locations > Page 40

Blower Motor Relay: Diagrams

Power Distribution Center

Blower Motor Relay

> Relays and Modules > Relays and Modules - HVAC > Blower Motor Relay > Component Information > Locations > Page 41

Blower Motor Relay: Description and Operation
BLOWER MOTOR RELAY

(ISO)

The blower motor relay (also referred to as Voltage Reduction Relay or VRR) is an International Standards Organization -type relay. The relay isan electromechanical device that switches battery current from a fuse in the Power Distribution Center (PDC) directly to the blower motor. The relay isenergized when the relay coil is provided a voltage signal by the ignition switch. This arrangement reduces the amount of battery current that must flowthrough the ignition switch.

The blower motor relay control circuit is protected by a fuse located in the junction block. When the relay is de-energized, the blower motor receives nobattery current. The VRR is used to reduce blower speeds in Heat mode. In non-A/C modes, the relay is de-energized and switches the current flowthrough an added resistance in the resistor block. When an A/C mode is selected, the relay is energized and the normally open contact is used to bypassthe added resistor. The fuse is located in the small relay fuse block that is attached to the Junction Block. The relay is energized by grounding the coillow side with the HVAC switch in any A/C mode.

Blower Motor Relay (VRR) Location

The blower motor relay is mounted with a single screw directly to the instrument panel's structural plastic inside the glove box opening, next to theleft-side energy-absorbing bracket. Refer to the PDC label for blower motor relay identification and location.

The blower motor relay cannot be repaired and, if faulty or damaged, it must be replaced.(VRR)

> Relays and Modules > Relays and Modules - HVAC > Blower Motor Relay > Component Information > Locations > Page 42

Blower Motor Relay: Testing and Inspection
RELAY TEST

Blower Motor Relay

Blower Motor Relay (VRR) Location

The blower motor relay (Voltage Reduction Relay or VRR) is mounted with a single screw directly to the instrument panel's structural plastic inside theglove box opening, next to the left-side energy-absorbing bracket. Remove the blower motor relay to perform the following tests:

1. A relay in the de-energized position should have continuity between terminals 87A and 30, and no continuity between terminals 87 and 30. If OK,
go to Step 2. If not OK, replace the faulty relay.

> Relays and Modules > Relays and Modules - HVAC > Blower Motor Relay > Component Information > Locations > Page 43

Durango 2WD V8-5.9L VIN Z LDC (2000)

75 5 ohms

2. Resistance between terminals 85 and 86 (electromagnet) should be . If OK, go to Step 3. If not OK, replace the faulty relay.3. Connect a battery to terminals 85 and 86. There should now be continuity between terminals 30 and 87, and no continuity between terminals 87A

and 30. If OK, see Relay Circuit Test. If not OK, replace the faulty relay.

RELAY CIRCUIT TEST

1. The relay common feed terminal cavity (30) is connected to fused battery feed directly from a fuse in the Power Distribution Center (PDC), and
should be hot at all times. Check for battery voltage at the PDC cavity for relay terminal 30. If OK, go to Step 2. If not OK, repair the open circuitto the PDC fuse as required.

2. The relay normally closed terminal cavity (87A) is not used for this application. Go to Step 3.3. The relay normally open terminal cavity (87) is connected to the blower motor. When the relay is energized, terminal 87 is connected to terminal

30 and provides full battery current to the blower motor feed circuit. There should be continuity between the PDC cavity for terminal 87 and the blower motor relay output circuit cavity of the blower motor wire harness connector at all times. If OK, go to Step 4. If not OK, repair the opencircuit to the blower motor as required.

4. The coil battery terminal cavity (86) is connected to the ignition switch. When the ignition switch is placed in the ON position, fused ignition

switch output is directed from a fuse in the junction block to the relay electromagnetic coil to energize the relay. There should be battery voltage atthe PDC cavity for relay terminal 86 with the ignition switch in the ON position. If OK, go to Step 5. If not OK, repair the open circuit to thejunction block fuse as required.

5. The coil ground terminal cavity (85) is connected to ground. This terminal supplies the ground for the relay electromagnetic coil. There should be
continuity between the PDC cavity for relay terminal 85 and a good ground at all times. If not OK, repair the open circuit as required.

ADDITIONAL RELAY CIRCUIT TESTING

-

The relay common feed terminal cavity 30 is connected to the low side of the blower motor. When the blower switch is Off and the ignition is On,there should be battery voltage present on this circuit. When the ignition switch is On, the voltage at that point should vary based on blower switchposition.

-

2 volts

The normally closed contact cavity 87A is connected to the resistor block cavity 3. Check this circuit by turning the blower switch to High andcycling between Heat and A/C modes. The voltage in the Heat mode should be approximately . The blower switch must be in High blowerspeed position during this check.

­The normally open contact on cavity 87 is tied to both the resistor block cavity 6 and the HVAC blower switch cavity 6. Check for continuity onthis circuit.

­The coil B+ contact cavity 86 is connected to an ignition run start feed. Battery voltage should be present on this circuit when the ignition switch isin the Run position.

-

The coil ground (-) cavity 85 is connected to the HVAC switch cavity 2 as well as the JTEC and A/C high pressure switch. Battery voltage shouldbe present on this circuit when the ignition switch is in the Run position and a Heat mode is selected on the control head. When an A/C mode isselected, the voltage at this point should be less than .1 volt

­If the blower motor does not operate, or only operates in some modes, check for a faulty connection at the VRR, or defective blower motor relay(VRR).

> Relays and Modules > Relays and Modules - HVAC > Blower Motor Relay > Component Information > Locations > Page 44

Blower Motor Relay: Service and Repair

REMOVAL

Blower Motor Relay (VRR) Location

(Voltage Reduction Relay or VRR)

The blower motor relay is mounted with a single screw directly to the instrument panel's structural plastic insidethe glove box opening, next to the left-side energy-absorbing bracket.1. Disconnect and isolate the battery negative cable.2. Roll down the glove box as described in Instrument Panel. Refer to: "Instrument Panel, Gauges and Wiring indicators : Instrument Panel :

See: Instrument Panel, Gauges and Warning Indicators/Instrument Cluster / Carrier/Service and RepairService and Repair"

3. Using a short or screwdriver, remove the screw that secures the blower motor relay (VRR) to the steel clip in the instrument panel90 degree

plastic flange.

4. Maneuver the VRR into the glove box opening far enough for access, and disengage the wiring harness from the relay.5. Remove the relay through the glove box opening.

INSTALLATION

2.2 Nm (20 in. lbs.)

1. Position the relay into the instrument panel inside the glove box opening.2. Align the VRR with the connector and engage the wiring harness to the relay.3. Align the relay with the steel clip in the instrument panel, and insert and tighten the single screw to .4. Roll up the glove box Refer to: See:"Instrument Panel, Gauges and Wiring indicators : Instrument Panel : Service and Repair"

Instrument Panel, Gauges and Warning Indicators/Instrument Cluster / Carrier/Service and Repair

5. Reconnect the battery negative cable.

> Relays and Modules > Relays and Modules - HVAC > Compressor Clutch Relay > Component Information > Locations

Compressor Clutch Relay: Locations

> Relays and Modules > Relays and Modules - HVAC > Compressor Clutch Relay > Component Information > Locations > Page 48

Durango 2WD V8-5.9L VIN Z LDC (2000)

Power Distribution Center

is located in the Power Distribution Center (PDC).A/C Clutch Relay

Power Distribution Center (PDC)

is located in the left front corner of the engine compartment, just behind the battery.Power Distribution Center (PDC)

> Relays and Modules > Relays and Modules - HVAC > Compressor Clutch Relay > Component Information > Locations > Page 49

Compressor Clutch Relay: Diagrams

Power Distribution Center

A/C Compressor Clutch Relay

> Relays and Modules > Relays and Modules - HVAC > Compressor Clutch Relay > Component Information > Locations > Page 50

Compressor Clutch Relay: Description and Operation
COMPRESSOR CLUTCH RELAY

(ISO)

The compressor clutch relay is an International Standards Organization micro-relay. The terminal designations and functions are the same as aconventional ISO relay. However, the micro-relay terminal orientation (footprint) is different, the current capacity is lower and the relay case dimensionsare smaller than those of the conventional ISO relay.

(PCM)

The compressor clutch relay is an electromechanical device that switches battery current to the compressor clutch coil when the Powertrain ControlModule grounds the coil side of the relay. The PCM responds to inputs from the heater-A/C mode control switch, the electronic cycling clutchswitch, the low pressure cut-off switch, and the high pressure cut-off switch.

(PDC)

The compressor clutch relay is located in the Power Distribution Center in the engine compartment. Refer to the PDC label for relayidentification and location.
The compressor clutch relay cannot be repaired and, if faulty or damaged, it must be replaced.

> Relays and Modules > Relays and Modules - HVAC > Compressor Clutch Relay > Component Information > Locations > Page 51

Compressor Clutch Relay: Testing and Inspection
RELAY TEST

Compressor Clutch Relay

(PDC)

The compressor clutch relay is located in the Power Distribution Center . Refer to the PDC label for relay identification and location. Removethe relay from the PDC to perform the following tests:1. A relay in the de-energized position should have continuity between terminals 87A and 30, and no continuity between terminals 87 and 30. If OK,

go to Step 2. If not OK, replace the faulty relay.

75 5 ohms

2. Resistance between terminals 85 and 86 (electromagnet) should be . If OK, go to Step 3. If not OK, replace the faulty relay.3. Connect a battery to terminals 85 and 86. There should now be continuity between terminals 30 and 87, and no continuity between terminals 87A
and 30. If OK, see Relay Circuit Test. If not OK, replace the faulty relay.

RELAY CIRCUIT TEST

1. The relay common feed terminal cavity (30) is connected to fused battery feed. There should be battery voltage at the cavity for relay terminal 30
at all times. If OK, go to Step 2. If not OK, repair the open circuit to the fuse in the PDC as required.

2. The relay normally closed terminal (87A) is not used in this application. Go to Step 3.3. The relay normally open terminal cavity (87) is connected to the compressor clutch coil. There should be continuity between this cavity and the
A/C compressor clutch relay output circuit cavity of the compressor clutch coil wire harness connector. If OK, go to Step 4. If not OK, repair theopen circuit as required.

4. The relay coil battery terminal (86) is connected to the fused ignition switch output (run/start) circuit. There should be battery voltage at the cavity
for relay terminal 86 with the ignition switch in the ON position. If OK, go to Step 5. If not OK, repair the open circuit to the fuse in the junctionblock as required.

5. The coil ground terminal cavity (85) is switched to ground through the Powertrain Control Module . There should be continuity between(PCM)

this cavity and the A/C compressor clutch relay control circuit cavity of the PCM wire harness connector C (gray) at all times. If not OK, repair theopen circuit as required.

> Relays and Modules > Relays and Modules - HVAC > Compressor Clutch Relay > Component Information > Locations > Page 52

Compressor Clutch Relay: Service and Repair
REMOVAL AND INSTALLATION

1. Disconnect and isolate the battery negative cable.

Power Distribution Center

(PDC)

2. Remove the cover from the Power Distribution Center .3. Refer to the label on the PDC for compressor clutch relay identification and location.4. Unplug the compressor clutch relay from the PDC.5. Install the compressor clutch relay by aligning the relay terminals with the cavities in the PDC and pushing the relay firmly into place.6. Install the PDC cover.7. Connect the battery negative cable.8. Test the relay operation.

> Relays and Modules > Relays and Modules - Instrument Panel > Audible Warning Device Control Module > Component Information > Locations

Module Locations

> Relays and Modules > Relays and Modules - Instrument Panel > Audible Warning Device Control Module > Component Information > Diagrams > Diagram Information and Instructions

Audible Warning Device Control Module: Diagram Information and Instructions

How to Find System & Component Diagrams

Group Index Complete Body and Chassis Diagrams

When trying to find the diagram for a specific component or system, use the information under .See: Diagrams/Electrical Diagrams

Complete Body and Chassis Diagrams

GroupIndex

Whenever a reference exists to another sheet or figure, find the corresponding diagram in , using the . The reference number for the subsequent diagram will match a listed group shown.See: Diagrams/Electrical Diagrams

How to Use Wiring Diagrams

DaimlerChrysler Corporation wiring diagrams are designed to provide information regarding the vehicles wiring content. In order to effectively use thewiring diagrams to diagnose and repair DaimlerChrysler Corporation vehicles, it is important to understand all of their features and characteristics.

> Relays and Modules > Relays and Modules - Instrument Panel > Audible Warning Device Control Module > Component Information > Diagrams > Diagram Information

and Instructions > Page 59

Durango 2WD V8-5.9L VIN Z LDC (2000)

> Relays and Modules > Relays and Modules - Instrument Panel > Audible Warning Device Control Module > Component Information > Diagrams > Diagram Information

and Instructions > Page 60

Durango 2WD V8-5.9L VIN Z LDC (2000)

General Information (Part 1 of 2)

Diagrams are arranged such that the power (B+) side of the circuit is placed near the top of the page, and the ground (B-) side of the circuit is placednear the bottom of the page (Fig. 1).

> Relays and Modules > Relays and Modules - Instrument Panel > Audible Warning Device Control Module > Component Information > Diagrams > Diagram Information

and Instructions > Page 61

Durango 2WD V8-5.9L VIN Z LDC (2000)

General Information (Part 2 of 2)

All switches, components, and modules are shown in the at rest position with the doors closed and the key removed from the ignition (Fig. 2).

Components are shown two ways. A solid line around a component indicates that the component is complete. A dashed line around the componentindicates that the component is being shown is not complete. Incomplete components have a reference number to indicate the page where the componentis shown complete.

It is important to realize that no attempt is made on the diagrams to represent components and wiring as they appear on the vehicle. For example, a shortpiece of wire is treated the same as a long one. In addition, switches and other components are shown as simply as possible, with regard to function only.

Circuit Functions

Circuit Identification Code Chart

All circuits in the diagrams use an alpha/numeric code to identify the wire and its function. To identify which circuit code applies to a system, refer to theCircuit Identification Code Chart. This chart shows the main circuits only and does not show the secondary codes that may apply to some models.

Circuit Information

> Relays and Modules > Relays and Modules - Instrument Panel > Audible Warning Device Control Module > Component Information > Diagrams > Diagram Information

and Instructions > Page 62

Durango 2WD V8-5.9L VIN Z LDC (2000)

Wire Code Identification

Wire Color Code Chart

> Relays and Modules > Relays and Modules - Instrument Panel > Audible Warning Device Control Module > Component Information > Diagrams > Diagram Information

and Instructions > Page 63

Durango 2WD V8-5.9L VIN Z LDC (2000)

Each wire shown in the diagrams contains a code which identifies the main circuit, part of the main circuit, gauge of wire, and color.

Connector, Ground and Splice Information

CAUTION:

Not all connectors are serviced. Some connectors are serviced only with a harness. A typical example might be the Supplemental RestraintSystem connectors. Always check parts availability before attempting a repair.

IDENTIFICATION

Connectors, grounds, and splices are identified as follows:-

In-line connectors located in the engine compartment are series numbersC100

-

In-line connectors located in the Instrument Panel area are series numbers.C200

-

In-line connectors located in the body are series numbers.C300

-

Jumper harness connectors are series numbers.C400

-

Grounds and ground connectors are identified with a "" and follow the same series numbering as the in-line connectors.G

-

Splices are identified with an "" and follow the same series numbering as the in-line connectors.S

­Component connectors are identified by the component name instead of a number. Multiple connectors on a component use a C1, C2, etc.identifier.

Electrostatic Discharge (ESD) Sensitive Devices

Electrostatic Discharge Symbol

All ESD sensitive components are solid state and a symbol is used to indicate this. When handling any component with this symbol comply with thefollowing procedures to reduce the possibility of electrostatic charge build up on the body and inadvertent discharge into the component. If it is notknown whether the part is ESD sensitive, assume that it is.

1. Always touch a known good ground before handling the part. This should be repeated while handling the part and more frequently after sliding
across a seat, sitting down from a standing position, or walking a distance.

2. Avoid touching electrical terminals of the part, unless instructed to do so by a written procedure.3. When using a voltmeter, be sure to connect the ground lead first.4. Do not remove the part from its protective packing until it is time to install the part.5. Before removing the part from its package, ground the package to a known good ground on the vehicle.

Notes, Cautions and Warnings

Additional important information is presented in three ways: Notes, Cautions, and Warnings.

NOTES

are used to help describe how switches or components operate to complete a particular circuit. They are also used to indicate differentconditions that may appear on the vehicle. For example, an up-to and after condition.

are used to indicate information that could prevent making an error that may damage the vehicle.CAUTIONS

WARNINGS

provide information to prevent personal injury and vehicle damage. Below is a list of general warnings that should be followed any time avehicle is being serviced.

WARNING:

- ALWAYS WEAR SAFETY GLASSES FOR EYE PROTECTION.

- USE SAFETY STANDS ANYTIME A PROCEDURE REQUIRES BEING UNDER A VEHICLE.

­BE SURE THAT THE IGNITION SWITCH ALWAYS IS IN THE OFF POSITION, UNLESS THE PROCEDURE REQUIRES IT TOBE ON.

> Relays and Modules > Relays and Modules - Instrument Panel > Audible Warning Device Control Module > Component Information > Diagrams > Diagram Information

and Instructions > Page 64

Durango 2WD V8-5.9L VIN Z LDC (2000)

­SET THE PARKING BRAKE WHEN WORKING ON ANY VEHICLE. AN AUTOMATIC TRANSMISSION SHOULD BE IN PARK.A MANUAL TRANSMISSION SHOULD BE IN NEUTRAL.

- OPERATE THE ENGINE ONLY IN A WELL-VENTILATED AREA.

- KEEP AWAY FROM MOVING PARTS WHEN THE ENGINE IS RUNNING, ESPECIALLY THE FAN AND BELTS.

­TO PREVENT SERIOUS BURNS, AVOID CONTACT WITH HOT PARTS SUCH AS THE RADIATOR, EXHAUST MANIFOLD(S),TAIL PIPE, CATALYTIC CONVERTER, AND MUFFLER.

­DO NOT ALLOW FLAME OR SPARKS NEAR THE BATTERY. GASES ARE ALWAYS PRESENT IN AND AROUND THEBATTERY.

- ALWAYS REMOVE RINGS, WATCHES, LOOSE HANGING JEWELRY, AND LOOSE CLOTHING.

Symbols

> Relays and Modules > Relays and Modules - Instrument Panel > Audible Warning Device Control Module > Component Information > Diagrams > Diagram Information

and Instructions > Page 65

Durango 2WD V8-5.9L VIN Z LDC (2000)

Wiring Diagram Symbols

International symbols are used throughout the wiring diagrams. These symbols are consistent with those being used around the world (Fig. 3).

Take Outs

The abbreviation is used in the component location section to indicate a point in which the wiring harness branches out to a component.T/O

Terminology

This is a list of terms and definitions used in the wiring diagrams.

LHD ............................................................................................................................................................................................... Left Hand Drive VehiclesRHD ............................................................................................................................................................................................. Right Hand Drive VehiclesATX ................................................................................................................................................................. Automatic Transmissions-Front Wheel DriveMTX ..................................................................................................................................................................... Manual Transmissions-Front Wheel DriveAT ..................................................................................................................................................................... Automatic Transmissions-Rear Wheel DriveMT ........................................................................................................................................................................ Manual Transmissions-Rear Wheel DriveSOHC ..................................................................................................................................................................................... Single Over Head Cam EngineDOHC ................................................................................................................................................................................... Double Over Head Cam EngineBUX ............................................................................................................................................................................................................. Built-Up-ExportBuilt-Up-Export .................................................................................................................. Vehicles Built For Sale In Markets Other Than North America Except Built-Up-Export ........................................................................................................................................ Vehicles Built For Sale In North America

Section Identification and Information

Section Identification

The wiring diagrams are grouped into individual sections. If a component is most likely found in a particular group, it will be shown complete (all wires,connectors, and pins) within that group. For example, the Auto Shutdown Relay is most likely to be found in Group 30, so it is shown there complete. Itcan, however, be shown partially in another group if it contains some associated wiring.

Connector and Terminal Replacement
CONNECTOR AND TERMINAL REPLACEMENT

1. Disconnect battery.2. Disconnect the connector (that is to be repaired) from its mating half/component.3. Cut off the existing wire connector directly behind the insulator. Remove of tape from the harness.6 inches

> Relays and Modules > Relays and Modules - Instrument Panel > Audible Warning Device Control Module > Component Information > Diagrams > Diagram Information

and Instructions > Page 66

Durango 2WD V8-5.9L VIN Z LDC (2000)

Stagger Cutting Wires

1/2 inch

1 inch

4. Stagger cut all wires on the harness side at intervals.5. Remove of insulation from each wire on the harness side.6. Stagger cut the matching wires on the repair connector assembly in the opposite order as was done on the harness side of the repair. Allow extra
length for soldered connections. Check that the overall length is the same as the original.

1 inch

7. Remove of insulation from each wire.8. Place a piece of heat shrink tubing over one side of the wire. Be sure the tubing will be long enough to cover and seal the entire repair area.9. Spread the strands of the wire apart on each part of the exposed wires.

10. Push the two ends of wire together until the strands of wire are close to the Insulation.11. Twist the wires together.12. Solder the connection together using rosin core type solder only. Do not use acid core solder.13. Center the heat shrink tubing over the joint and heat using a heat gun. Heat the joint until the tubing is tightly sealed and sealant comes out of both
ends of the tubing

1-1/2 inches 2 inches

14. Repeat steps 8 through 13 for each wire.15. Re-tape the wire harness starting behind the connector and past the repair.16. Re-connect the repaired connector.17. Connect the battery, and test all affected systems.

Connector Replacement
CONNECTOR REPLACEMENT

1. Disconnect battery.2. Disconnect the connector that is to be repaired from its mating half/component

> Relays and Modules > Relays and Modules - Instrument Panel > Audible Warning Device Control Module > Component Information > Diagrams > Diagram Information

and Instructions > Page 67

Durango 2WD V8-5.9L VIN Z LDC (2000)

Connector Locking Wedge

3. Remove the connector locking wedge, if required.

Terminal Removal

Terminal Removal Using Special Tool

4. Position the connector locking finger away from the terminal using the proper pick from special tool kit 6680. Pull on the wire to remove the
terminal from the connector.

5. Reset the terminal locking tang, if it has one.6. Insert the removed wire in the same cavity on the repair connector.7. Repeat steps four through six for each wire in the connector, being sure that all wires are inserted into the proper cavities. For additional connector
pinout identification, refer to the wiring diagrams.

8. Insert the connector locking wedge into the repaired connector, if required.9. Connect connector to its mating half/component.

> Relays and Modules > Relays and Modules - Instrument Panel > Audible Warning Device Control Module > Component Information > Diagrams > Diagram Information

and Instructions > Page 68

Durango 2WD V8-5.9L VIN Z LDC (2000)

10. Connect battery and test all affected systems.

Diode Replacement
REMOVAL

1. Disconnect the battery.2. Locate the diode in the harness, and remove the protective covering.

Diode Identification

3. Remove the diode from the harness, pay attention to the current flow direction.

INSTALLATION

1. Remove the insulation from the wires in the harness. Only remove enough insulation to solder in the new diode.2. Install the new diode in the harness, making sure current flow is correct. If necessary, refer to the appropriate wiring diagram for current flow (Fig.

13).

3. Solder the connection together using rosin core type solder only Do not use acid core solder.4. Tape the diode to the harness using electrical tape. Make sure the diode is completely sealed from the elements.5. Re-connect the battery and test affected systems.

Terminal Replacement
REMOVAL

1. Disconnect battery.2. Disconnect the connector being repaired from its mating half/component.

> Relays and Modules > Relays and Modules - Instrument Panel > Audible Warning Device Control Module > Component Information > Diagrams > Diagram Information

and Instructions > Page 69

Durango 2WD V8-5.9L VIN Z LDC (2000)

Fig.16 Connector Locking Wedge Tab (Typical)

3. Remove the connector locking wedge, if required (Fig. 16).

Fig.17 Terminal Removal

Fig.18 Terminal Removal Using Special Tool

4. Position the connector locking finger away from the terminal using the proper pick from special tool kit . Pull on the wire to remove the6680

terminal from the connector (Fig. 17) (Fig. 18).

5. Cut the wire 6 inches from the back of the connector.6. Remove of insulation from the wire on the harness side.1 inch

INSTALLATION

one-half (1/2) inch

1. Select a wire from the terminal repair assembly that best matches the color wire being repaired.2. Cut the repair wire to the proper length and remove of insulation.3. Splice the repair wire to the wire harness

> Relays and Modules > Relays and Modules - Instrument Panel > Audible Warning Device Control Module > Component Information > Diagrams > Diagram Information

and Instructions > Page 70

Durango 2WD V8-5.9L VIN Z LDC (2000)

a. Place a piece of heat shrink tubing over one side of the wire. Make sure the tubing will be long enough to cover and seal the entire repair area.b. Spread the strands of the wire apart on each part of the exposed wires.c. Push the two ends of wire together until the strands of wire are close to the insulation.d. Twist the wires together.e. Solder the connection together using rosin core type solder only. Do not use acid core solder.f.

Center the heat shrink tubing over the joint and heat using a heat gun. Heat the joint until the tubing is tightly sealed and sealant comes out ofboth ends of the tubing.

1-1/2 inches 2 inches

4. Insert the repaired wire into the connector.5. Install the connector locking wedge, if required, and reconnect the connector to its mating half/component.6. Re-tape the wire harness starting at behind the connector and past the repair.7. Connect battery and test all affected systems.

Terminal/Connector Repair-Augat Connectors
REMOVAL

1. Disconnect battery.2. Disconnect the connector from its mating half/component.

Fig.8 Augat Connector Repair

3. Push down on the yellow connector locking tab to release the terminals (Fig. 8).

Fig.9 Using Special Tool 6932

6932

4. Using special tool , push the terminal to remove it from the connector (Fig. 9).5. Repair or replace the terminal as necessary.

INSTALLATION

> Relays and Modules > Relays and Modules - Instrument Panel > Audible Warning Device Control Module > Component Information > Diagrams > Diagram Information

and Instructions > Page 71

Durango 2WD V8-5.9L VIN Z LDC (2000)

1. Reset the terminal locking tang.2. Insert the removed wire in the same cavity on the repair connector.3. Repeat steps for each wire in the connector, being sure that all wires are inserted into the proper cavities. For additional connector pin-out
identification, refer to the wiring diagrams.

4. When the connector is re-assembled, the locking tab must be placed in the locked position to prevent terminal push out.5. Connect connector to its mating half/component.6. Connect battery and test all affected systems.

Terminal/Connector Repair-Molex Connectors
REMOVAL

1. Disconnect battery2. Disconnect the connector from its mating half/component.

Fig.10 Molex Connector Repair

3. Insert special tool into the terminal end of the connector (Fig. 10).6742

Fig.11 Using Special Tool 6742

6742

4. Using special tool , release the locking fingers on the terminal (Fig. 11).5. Pull on the wire to remove it from the connector.6. Repair or replace the terminal as necessary.

INSTALLATION

1. Reset the terminal locking tang.2. Insert the removed wire in the same cavity on the repair connector.3. Repeat steps for each wire in the connector, being sure that all wires are inserted into the proper cavities. For additional connector pin-out

> Relays and Modules > Relays and Modules - Instrument Panel > Audible Warning Device Control Module > Component Information > Diagrams > Diagram Information

and Instructions > Page 72

Durango 2WD V8-5.9L VIN Z LDC (2000)

identification, refer to the wiring diagrams.

4. Connect connector to its mating half/component.5. Connect battery and test all affected systems.

Terminal/Connector Repair-Thomas and Betts Connectors
REMOVAL

1. Disconnect battery.2. Disconnect the connector from its mating half/component.

Fig.12 Thomas And Betts Connector Lock Release Tabs

3. Push in the two lock tabs on the side of the connector (Fig. 12).

Fig.13 Removing Wire Terminal

6934
6934

4. Insert the probe end of special tool into the back of the connector cavity (Fig. 13).5. Grasp the wire and tool , then slowly remove the wire and terminal from the connector.6. Repair or replace the terminal as necessary.

INSTALLATION

> Relays and Modules > Relays and Modules - Instrument Panel > Audible Warning Device Control Module > Component Information > Diagrams > Diagram Information

and Instructions > Page 73

Durango 2WD V8-5.9L VIN Z LDC (2000)

1. Reset the terminal locking tang.2. Insert the removed wire in the same cavity on the repair connector.3. Repeat steps for each wire in the connector, being sure that all wires are fully seated into the proper cavities. For additional connector pin-out

identification, refer to the wiring diagrams.

Fig.14 Single Lock Tab

4. Push in the single lock tab on the side of the connector (Fig. 14).5. Connect connector to its mating half/component.6. Connect battery and test all affected systems.

Wiring Repair

When replacing or repairing a wire, it is important that the correct gauge be used as shown. The wires must also be held securely in place to preventdamage to the insulation.

1 inch

1. Disconnect battery negative cable.2. Remove of insulation from each end of the wire.3. Place a piece of heat shrink tubing over one side of the wire. Make sure the tubing will be long enough to cover and seal the entire repair area.

> Relays and Modules > Relays and Modules - Instrument Panel > Audible Warning Device Control Module > Component Information > Diagrams > Diagram Information

and Instructions > Page 74

Durango 2WD V8-5.9L VIN Z LDC (2000)

Wire Repair

4. Spread the strands of the wire apart on each part of the exposed wire (Example 1).5. Push the two ends of wire together until the strands of wire are close to the insulation (Example 2).6. Twist the wires together (Example 3).7. Solder the connection together using rosin core type solder only. 8. Center the heat shrink tubing over the joint, and heat using a heat gun. Heat the joint until the tubing is tightly sealed and sealant comes out of bothDo not use acid core solder.

ends of the tubing.

9. Secure the wire to the existing ones to prevent chafing or damage to the insulation.

10. Connect battery and test all affected systems.

Special Tools

Probing Tool Package 6807

Terminal Pick 6680

Terminal Removing Tool 6932
