Page 1

2016

DART

USER GUIDE

Page 2

The driver’s primary responsibility is the safe operation of the vehicle. Driving while distracted can result in loss of vehicle control, resulting in a collision and personal injury. FCA US LLC strongly recommends that the driver use extreme caution when using any device or feature that may take their attention off the road. Use of any electrical devices, such as cellular telephones, computers, portable radios, vehicle navigation or other devices, by the driver while

the vehicle is moving is dangerous and could lead to a serious collision. Texting while driving is also dangerous and should never be done while the vehicle is moving. If you find yourself unable to devote your full attention to vehicle operation, pull off the road to a safe location and stop your vehicle. Some states or provinces prohibit the use of cellular telephones or texting while driving. It is always the driver’s responsibility to comply with all local laws.

IMPORTANT

This User Guide is intended to familiarize you with the important features of your vehicle. The DVD enclosed contains your Owner’s Manual, Navigation/Uconnect Manuals, Warranty Booklets, Tire Warranty and Roadside Assistance (new vehicles purchased in the U.S.) or Roadside Assistance (new vehicles purchased in Canada) in electronic format. We hope you find it useful. Replacement DVD kits may be purchased by visiting www.techauthority.com.

This guide has been prepared to help you get quickly acquainted with your new Dodge and to provide a convenient reference source for common questions. However, it is not a substitute for your Owner’s Manual.

For complete operational instructions, maintenance procedures and important safety messages, please consult your Owner’s Manual, Navigation/ Uconnect Manuals and other Warning Labels in your vehicle.

Not all features shown in this guide may apply to your vehicle. For additional information on accessories to help personalize your vehicle, visit www.mopar.com (U.S.), www.mopar.ca (Canada) or your local Dodge dealer.

Drunken driving is one of the most frequent causes of accidents. Your driving ability can be seriously impaired with blood alcohol levels far below the legal minimum. If you are drinking, don’t drive. Ride with a designated non-drinking driver, call a cab, a friend, or use public transportation.

Driving after drinking can lead to an accident. Your perceptions are less sharp, your reflexes are slower, and your judgment is impaired when you have been drinking. Never drink and then drive.

If you are the rst registered retail owner of your vehicle, you may obtain a complimentary printed copy of the Owner’s Manual, Navigation/Uconnect Manuals or Warranty Booklet by calling 1-800-423-6343 (U.S.) or 1-800-387-1143 (Canada) or by contacting your dealer.

Page 3

TABLE OF CONTENTS

INTRODUCTION/WELCOME

WELCOME FROM FCA US LLC .......2

CONTROLS AT A GLANCE

DRIVER COCKPIT ...............4

INSTRUMENT CLUSTER ...........6

GETTING STARTED

KEYFOB ....................8

REMOTESTART ................9

KEYLESS ENTER-N-GO ...........10

VEHICLE SECURITY ALARM ........14

SEAT BELT SYSTEMS ............16

SUPPLEMENTAL RESTRAINT SYSTEM

(SRS) — AIR BAGS .............17

CHILD RESTRAINTS ............24

HEAD RESTRAINTS .............28

FRONT SEATS ................30

REAR SEAT ..................32

HEATEDSEATS ...............33

HEATED STEERING WHEEL —

IF EQUIPPED .................34

TILT/TELESCOPING STEERING

COLUMN ...................35

OPERATING YOUR VEHICLE

ENGINE BREAK-IN

RECOMMENDATIONS ............36

TURN SIGNAL/WIPER/WASHER/HIGH

BEAM LEVER .................37

HEADLIGHT SWITCH ............39

ELECTRONIC SPEED CONTROL —

IF EQUIPPED .................40

MANUAL CLIMATE CONTROLS .......44

UCONNECT 8.4 MANUAL CLIMATE

CONTROLS ..................45

UCONNECT 8.4 AUTOMATIC CLIMATE

CONTROLS ..................47

BLIND SPOT MONITORING .........49

PARKVIEW REAR BACK UP CAMERA —

IF EQUIPPED .................49

POWER SUNROOF — IF EQUIPPED . . . 51 MANUAL TRANSMISSION —

IF EQUIPPED .................53

SIX-SPEED AUTOMATIC TRANSMISSION . . . 54

ELECTRONICS

YOUR VEHICLE'S SOUND SYSTEM ....56

UCONNECT 200 ...............58

UCONNECT 8.4 & 8.4N ...........68

STEERING WHEEL AUDIO CONTROLS . . 96 ELECTRONIC VEHICLE INFORMATION

CENTER (EVIC) — ST ANDARD

(2 BUTTON) ..................97

DRIVER INFORMATION DISPLA Y (DID) —

PREMIUM (4 BUTTON) ...........98

UCONNECT 8.4 CUSTOMER

PROGRAMMABLE FEATURES ......101

UNIVERSAL GARAGE DOOR OPENER

(HomeLink) .................102

POWER OUTLET ..............105

UTILITY

TRAILER TOWING WEIGHTS (MAXIMUM

TRAILER WEIGHT RATINGS) .......106

RECREATIONAL TOWING (BEHIND

MOTORHOME, ETC.) ............107

WHAT TO DO IN EMERGENCIES

ROADSIDE ASSISTANCE ..........108

INSTRUMENT CLUSTER WARNING

LIGHTS ...................108

INSTRUMENT CLUSTER INDICATOR

LIGHTS ...................114

IF YOUR ENGINE OVERHEATS ......115

JACKING AND TIRE CHANGING .....116

TIRE SERVICE KIT .............124

JUMP-STARTING PROCEDURES .....130

SHIFT LEVER OVERRIDE .........133

TOWING A DISABLED VEHICLE .....134

FREEING A STUCK VEHICLE .......134

ENHANCED ACCIDENT RESPONSE

SYSTEM (EARS) ...............136

EVENT DATA RECORDER (EDR) .....136

MAINTAINING YOUR VEHICLE

TO OPEN AND CLOSE THE HOOD ....137

ENGINE COMPARTMENT — 1.4L

TURBO ....................138

ENGINE COMPARTMENT — 2.0L ....140

ENGINE COMPARTMENT — 2.4L ....142

FLUID CAPACITIES .............144

FLUIDS, LUBRICANTS, AND

GENUINE PARTS ..............144

MAINTENANCE PROCEDURES ......146

MAINTENANCE SCHEDULE .......146

FUSES ....................151

TIRES — GENERAL INFORMATION . . . 154

REPLACEMENT BULBS ..........157

CONSUMER ASSISTANCE

FCA US LLC CUSTOMER CENTER ....158

FCA CANADA INC. CUSTOMER CENTER ASSISTANCE FOR THE HEARING

IMPAIRED ..................158

PUBLICATIONS ORDERING ........158

REPORTING SAFETY DEFECTS IN THE

UNITED STATES ..............159

Uconnect CUSTOMER CENTER ......159

. . 158

MOPAR® ACCESSORIES

AUTHENTIC ACCESSORIES BY MOP AR

. . 160

FREQUENTLY ASKED QUESTIONS

FAQ’s .....................162

INDEX

.....................164

Page 4

INTRODUCTION/WELCOME

WELCOME FROM FCA US LLC

Congratulations on selecting your new FCA US LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essentials that are traditional to our vehicles.

Your new FCA US LLC vehicle has characteristics to enhance the driver's control under some driving conditions. These are to assist the driver and are never a substitute for attentive driving. They can never take the driver's place. Always drive carefully.

Your new vehicle has many features for the comfort and convenience of you and your passengers. Some of these should not be used when driving because they take your eyes from the road or your attention from driving. Never text while driving or take your eyes more than momentarily off the road.

This guide illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This guide may also include a description of features and equipment that are no longer available or were not ordered on this vehicle. Please disregard any features and equipment described in this guide that are not available on this vehicle. FCA US LLC reserves the right to make changes in design and specifications and/or make additions to or improvements to its products without imposing any obligation upon itself to install them on products previously manufactured.

This User Guide has been prepared to help you quickly become acquainted with the important features of your vehicle. It contains most things you will need to operate and maintain the vehicle, including emergency information.

The DVD includes a computer application containing detailed owner's information which can be viewed on a personal computer or Mac computer. The multimedia DVD also includes videos which can be played on any standard DVD player (including the Uconnect Touchscreen Radios if equipped with DVD player capabilities). Additional DVD operational information is located on the back of the DVD sleeve.

For complete owner information, refer to your Owner's Manual on the DVD in the owner’s kit provided at the time of new vehicle purchase. For your convenience, the information

contained on the DVD may also be printed and saved for future reference.

FCA US LLC is committed to protecting our environment and natural resources. By converting from paper to electronic delivery for the majority of the user information for your vehicle, together we greatly reduce the demand for tree-based products and lessen the stress on our environment.

Page 5

INTRODUCTION/WELCOME

VEHICLES SOLD IN CANADA

With respect to any vehicles sold in Canada, the name FCA US LLC shall be deemed to be deleted and the name FCA Canada Inc. used in substitution (excluding legal lines).

WARNING!

• Pedals that cannot move freely can cause loss of vehicle control and increase the risk of serious personal injury.

• Always make sure that objects cannot fall into the driver foot well while the vehicle is moving. Objects can become trapped under the brake pedal and accelerator pedal causing a loss of vehicle control.

• Failure to properly follow floor mat installation or mounting can cause interference with the brake pedal and accelerator pedal operation causing loss of control of the vehicle.

• Never leave children alone in a vehicle, or with access to an unlocked vehicle. Allowing children to be in a vehicle unattended is dangerous for a number of reasons. A child or others could be seriously or fatally injured. Children should be warned not to touch the parking brake, brake pedal or the transmission gear selector.

• Do not leave the Key Fob in or near the vehicle, or in a location accessible to children, and do not leave the ignition of a vehicle equipped with Keyless Enter-N-Go in the ACC or ON/RUN mode. A child could operate power windows, other controls, or move the vehicle.

• Never use the “PARK” position as a substitute for the parking brake. Always apply the parking brake fully when parked to guard against vehicle movement and possible injury or damage.

• Refer to your Owner's Manual on the DVD for further details.

USE OF AFTERMARKET PRODUCTS (ELECTRONICS)

The use of aftermarket devices including cell phones, MP3 players, GPS systems, or chargers may affect the performance of on-board wireless features including Keyless Enter-N-Go and Remote Start range. If you are experiencing difficulties with any of your wireless features, try disconnecting your aftermarket devices to see if the situation improves. If your symptoms persist, please see an authorized dealer.

When it comes to service, remember that your authorized dealer knows your vehicle best, has factory-trained technicians and genuine MOPAR parts, and cares about your satisfaction.

Page 6

CONTROLS AT A GLANCE

DRIVER COCKPIT

1. Headlight Switch pg. 39

2. Electronic Vehicle Information Center (EVIC) Control/Driver Information Display (DID) pg. 6

3. T urn Signal/Wiper/W asher/High Beam Lever pg. 37

4. Instrument Cluster pg. 6

5. Electronic Vehicle Information Center (EVIC)/Driver Information Display (DID) pg. 6

6. Fuel Door Locator pg. 6

7. Speed Control pg. 40

8. Ignition Switch pg. 12

9. Audio System pg. 56

Page 7

CONTROLS AT A GLANCE

10. Glove/Storage Compartment

11. Hazard Warning Light

12. Climate Control pg. 44

13. Shifter

14. Power Outlet pg. 105

15. Power Mirrors

16. Power Windows

17. Power Locks

Page 8

CONTROLS AT A GLANCE

INSTRUMENT CLUSTER

1. T achometer

2. Selectable Information Area — If Equipped

3. Electronic Vehicle Information Center (EVIC)/ Driver Information Display (DID)

4. Speedometer

(See page 108 for Instrument Cluster Warning Lights.)

Page 9

CONTROLS AT A GLANCE

5. Gear Position Display

6. Fuel Gauge

7. Fuel Door Location

(See page 114 for Instrument Cluster Indicator Lights.)

Page 10

GETTING STARTED

KEY FOB

Locking And Unlocking The Doors

Push and release the LOCK button on the RKE transmitter to lock all doors. The turn signal lights will flash, and the horn will chirp to acknowledge the signal.

Push and release the UNLOCK on the RKE transmitter once to unlock the driver's door or twice within five seconds to unlock all doors. The turn signal lights will flash to acknowledge the unlock signal. The illuminated entry system will also turn on.

1st Press Of Key Fob Unlocks

This feature lets you program the system to unlock either the driver's door or all doors on the first push of the UNLOCK button on the RKE transmitter. To change the current setting, refer to your “Uconnect Settings” in “Understanding Your Instrument Panel” in your Owner's Manual on the DVD for further information.

button

Opening The Trunk

Push the Trunk Release button on the transmitter two times within five seconds to open the trunk.

Key Fob

1 — Decklid 2 — Unlock 3 — Lock 4 — Remote Start 5 — Panic

Panic Alarm

1. Push the PANIC button once to turn the Panic Alarm on.

2. Wait approximately three seconds and push the button a second time to turn the Panic Alarm off.

Key Fob

1 — Decklid 2 — Lock 3 — Unlock 4 — Remote Start 5 — Emergency Key

Page 11

GETTING STARTED

Emergency Key

Should the battery in the vehicle or the Key Fob transmitter go dead, there is an emergency key located in the Key Fob. T o remove the emergency key, slide the button at the back of the Key Fob sideways with your thumb and then pull the key out with your other hand.

The emergency key is also used to lock the glove compartment.

WARNING!

REMOTE START

• Push the REMOTE ST AR T button

• Pushing the REMOTE ST AR T button a third time shuts the engine off.

• To drive the vehicle, push the UNLOCK button and cycle the ignition to the ON/RUN position.

With remote start, the engine will only run for 15 minutes (timeout) unless the ignition is cycled to the ON/RUN position.

The vehicle must be cycled to the ON/RUN position after two consecutive timeouts.

• Do not start or run an engine in a closed garage or confined area. Exhaust gas contains Carbon Monoxide (CO) which is odorless and colorless. Carbon Monoxide is poisonous and can cause you or others to be severely injured or killed when inhaled.

• Keep Key Fob transmitters away from children. Operation of the Remote Start System, windows, door locks or other controls could cause you and others to be severely injured or killed.

on the Key Fob twice within five seconds.

WARNING!

Page 12

GETTING STARTED

KEYLESS ENTER-N-GO

The Keyless Enter -N-Go system is an enhancement to the vehicle's Key Fob. This feature allows you to lock and unlock the vehicle's door(s) and trunk without having to push the Key Fob lock or unlock buttons, as well as starting and stopping the vehicle with the push of a button.

To Unlock From The Driver Or Passenger Side

With a valid Keyless Enter-N-Go Key Fob located outside the vehicle and within 5 ft (1.5m) of the driver or passenger side door handle, grab either front door handle to unlock the door automatically.

To Lock The Vehicle

Both front door handles have buttons located on the outside of the handle. With one of the vehicle's Keyless Enter-N-Go Key Fobs located outside the vehicle and within 5 ft (1.5 m) of the driver's or passenger front door handle, push the door handle button to lock all four doors and trunk.

Grab The Door Handle To Unlock

DO NOT grab the door handle when pushing the door handle button. This could unlock the door(s).

Push The Door Handle To Lock

Do NOT Grab The Handle When Locking

Page 13

GETTING STARTED

NOTE:

• If “Unlock All Doors 1st Press” is programmed all doors will unlock when you grab hold of the front driver's door handle. To select between “Unlock Driver Door 1st Press” and “Unlock All Doors 1st Press”, refer to the “Electronic Vehicle Information Center (EVIC)” or “Driver Information Display (DID)” in your vehicle's Owner's Manual on the DVD or “Programmable Features” in this guide for further information.

• If “Unlock All Doors 1st Press” is programmed all doors and trunk will unlock when you push the trunk button. If “Unlock Driver Door 1st Press” is programmed only the trunk will unlock when you push the trunk button. T o select between “Unlock Driver Door 1st Press” and “Unlock All Doors 1st Press”, refer to the “Electronic Vehicle Information Center (EVIC)” or “Driver Information Display (DID)” in your vehicle's Owner's Manual on the DVD or “Programmable Features” in this guide for further information.

• If a Key Fob is detected in the vehicle when locking the vehicle using the power door lock switch, the doors and trunk will unlock and the horn will chirp three times. On the third attempt, your Key Fob can be locked inside the vehicle.

• After pushing the Keyless Enter-N-Go LOCK button, you must wait two seconds before you can lock or unlock the vehicle using the door handle. This is done to allow you to check if the vehicle is locked by pulling the door handle, without the vehicle reacting and unlocking.

• If a Keyless Enter-N-Go door handle has not been used for 72 hours, the Keyless Enter-N-Go feature for that handle may time out. Pulling the deactivated front door handle will reactivate the door handle's Keyless Enter-N-Go feature.

To Enter The Trunk

With a valid Keyless Enter-N-Go Key Fob located outside the vehicle and within 5ft (1.5 m) of the deck lid, push the button on the right side of the light bar which is located on the deck lid above the license plate.

NOTE:

Refer to “Keyless Enter-N-Go” in “Things To Know Before Starting Your Vehicle” in your Owner's Manual on the DVD for further information.

Trunk Unlock Button

Page 14

GETTING STARTED

Engine Starting/Stopping

Starting

1. With a valid Keyless Enter-N-Go Key Fob inside the vehicle.

2. Place the shift lever in PARK or NEUTRAL.

3. While pushing the brake pedal, push the ENGINE START/STOP button once. If the engine fails to start, the starter will disengage automatically after 10 seconds.

4. T o stop the cranking of the engine prior to the engine starting, push the button again.

NOTE:

In case the ignition switch does not change with the push of a button, the RKE transmitter (Key Fob) may have a low or dead battery . In this situation a back up method can be used to operate the ignition switch. Put the nose side of the Key Fob against the ENGINE START/STOP button and push to operate the ignition switch.

Engine START/STOP Button

Stopping

1. Bring the vehicle to a complete stop.

2. Shift the transmission to P ARK (P).

3. Push the ENGINE START/STOP button once. The ignition switch will return to the OFF position.

NOTE:

If the transmission is not in PARK and the vehicle is in motion, the ENGINE START/STOP button must be held for two seconds with the vehicle speed above 5 mph (8 km/h) before the engine will shut off.

Page 15

GETTING STARTED

Accessory Positions With Engine Off

NOTE:

The following functions are with the driver’s foot OFF the brake pedal (transmission in PARK or NEUTRAL position).

Starting With The Ignition Switch In The OFF Position:

• Push the ENGINE START/STOP button once to change the ignition switch to the ACC position.

• Push the ENGINE START/STOP button a second time to change the ignition switch to the ON/RUN position.

• Push the ENGINE ST AR T/STOP button a third time to return the ignition switch to the OFF position.

NOTE:

If the ignition switch is left in the ACC or ON/RUN (engine not running) position and the transmission is in PARK, the system will automatically time out after 30 minutes of inactivity and the ignition will switch to the OFF position.

Ignition Positions

Page 16

GETTING STARTED

VEHICLE SECURITY ALARM

The Vehicle Security Alarm monitors the vehicle doors for unauthorized entry and the ignition for unauthorized operation. While the Vehicle Security Alarm is armed, interior switches for door locks and decklid release are disabled. If something triggers the alarm, the Vehicle Security Alarm will provide the following audible and visible signals: the horn will pulse, the park lamps and/or turn signals will flash, and the V ehicle Security Light in the instrument cluster will flash.

To Arm The System

Vehicles Not Equipped With Keyless Enter-N-Go

Remove the key from the ignition switch and either push a power door LOCK switch while the driver or passenger door is open or push the LOCK button on the Remote Keyless Entry (RKE) transmitter. After the last door is closed, or if all doors are closed, the Vehicle Security Alarm will arm itself in about 16 seconds. During that time, the Vehicle Security Light will flash. If it does not illuminate, the Vehicle Security Alarm is not arming. In addition, if you open a door during the arming period, the Vehicle Security Alarm will cancel the arming process. If you wish to rearm the Vehicle Security Alarm after closing the door, you must repeat one of the previously-described arming sequences.

You may also disarm the ultrasonic intrusion sensor during the 16 second arming period by pushing the lock button three times with a delay of no more than five seconds between key pushes. The horn will pulse twice to acknowledge that the ultrasonic intrusion sensor has been disabled.

NOTE:

• The driver’s door key cylinder and the trunk button on the RKE transmitter cannot arm or disarm the Vehicle Security Alarm.

• The Vehicle Security Alarm remains armed during trunk entry. Pushing the TRUNK button will not disarm the Vehicle Security Alarm. If someone enters the vehicle through the trunk, and opens any door, the alarm will sound.

• When the Vehicle Security Alarm is armed, the interior power door lock switches will not unlock the doors.

• The ultrasonic intrusion sensor may be inadvertently activated by a child, pet or shifting package left within the vehicle after the Vehicle Security Alarm is armed.

Vehicles Equipped With Keyless Enter-N-Go

Push the Keyless Enter-N-Go START/STOP button until the EVIC/DID indicates that the vehicle ignition is “OFF” (refer to “Starting Procedures” in “Starting And Operating” in your Owner's Manual on the DVD for further information). Then either push the power door LOCK switch while the driver or passenger door is open, push the Remote Keyless Entry (RKE) transmitter LOCK button or push the Passive Entry Door Handle LOCK button (refer to “Keyless Enter-N-Go” in “Things To Know Before Starting Your Vehicle” in your Owner's Manual on the DVD for further information).

Page 17

GETTING STARTED

To Disarm The System

The Vehicle Security Alarm is designed to protect your vehicle; however, you can create conditions where the Vehicle Security Alarm will give you a false alarm. If one of the previously-described arming sequences has occurred, the V ehicle Security Alarm will arm regardless of whether you are in the vehicle or not. If you remain in the vehicle and open a door, the alarm will sound. If this occurs, disarm the Vehicle Security Alarm.

If the V ehicle Security Alarm is armed and the battery becomes disconnected the Vehicle Security Alarm will remain armed when the battery is reconnected. The exterior lights will flash, and the horn will sound. If this occurs, disarm the Vehicle Security Alarm.

Vehicles Not Equipped With Keyless Enter-N-Go

Either push the UNLOCK button on the RKE transmitter or insert a valid ignition key into the ignition switch and turn the key to the ON/RUN position.

NOTE:

• The driver's door key cylinder and the trunk button on the RKE transmitter cannot arm or disarm the Vehicle Security Alarm.

• When the Vehicle Security Alarm is armed, the interior power door lock switches will not unlock the doors.

Vehicles Equipped With Keyless Enter-N-Go

Either push the UNLOCK button on the RKE transmitter or grasp the Passive Entry Unlock Door Handle (refer to “Keyless Enter-N-Go” in “Things To Know Before Starting Your Vehicle” in your Owner's Manual on the DVD for further information), push the Keyless Enter-N-Go START/STOP button (requires at least one valid Key Fob in the vehicle), or insert a valid Key Fob into the ignition switch (if the STAR T/STOP button is removed) and rotate it to the ON/RUN position.

Tamper Alert

If something has triggered the Vehicle Security Alarm in your absence, the horn will sound three times and the exterior lights will blink three times when you disarm the Vehicle Security Alarm. Check the vehicle for tampering.

Page 18

GETTING STARTED

SEAT BELT SYSTEMS

Lap/Shoulder Belts

• All seating positions in your vehicle are equipped with lap/shoulder belts.

• Be sure everyone in your vehicle is in a seat and using a seat belt properly.

• Position the lap belt so that it is snug and lies low across your hips, below your abdomen. To remove slack in the lap belt portion, pull up on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt. A snug seat belt reduces the risk of sliding under the seat belt in a collision.

• Position the shoulder belt across the shoulder and chest with minimal, if any slack so that it is comfortable and not resting on your neck. The retractor will withdraw any slack in the shoulder belt.

Seat Belt Pretensioner

• The front seat belt system is equipped with pretensioning devices that are designed to remove slack from the seat belt in the event of a collision.

• A deployed pretensioner or a deployed air bag must be replaced immediately .

WARNING!

• In a collision, you and your passengers can suffer much greater injuries if you are not properly buckled up. You can strike the interior of your vehicle or other passengers, or you can be thrown out of the vehicle. Always be sure you and others in your vehicle are buckled up properly.

• A shoulder belt placed behind you will not protect you from injury during a collision. You are more likely to hit your head in a collision if you do not wear your shoulder belt. The lap and shoulder belt are meant to be used together.

• A seat belt that is too loose will not protect you properly. In a sudden stop, you could move too far forward, increasing the possibility of injury. Wear your seat belt snugly.

• A frayed or torn seat belt could rip apart in a collision and leave you with no protection. Inspect the seat belt system periodically, checking for cuts, frays, or loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system. Seat belt assemblies must be replaced after a collision.

Page 19

GETTING STARTED

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) — AIR BAGS

Air Bag System Components

Your vehicle may be equipped with the following air bag system components:

• Occupant Restraint Controller (ORC)

• Air Bag Warning Light

• Steering Wheel and Column

• Instrument Panel

• Knee Impact Bolsters

• Advanced Front Air Bags

• Supplemental Side Air Bags

• Supplemental Knee Air Bags

• Front and Side Impact Sensors

• Seat Belt Pretenioners

• Seat Belt Buckle Switch

• Seat Track Position Sensors

• Occupant Classification System

Advanced Front Air Bags

• This vehicle has Advanced Front Air Bags for both the driver and front passenger as a supplement to the seat belt restraint systems. The Advanced Front Air Bags will not deploy in every type of collision.

• Advanced Front Air Bags are designed to provide additional protection by supplementing the seat belts. Advanced Front Air Bags are not expected to reduce the risk of injury in rear, side, or rollover collisions.

• The Advanced Front Air Bags will not deploy in all frontal collisions, including some that may produce substantial vehicle damage — for example, some pole collisions, truck underrides, and angle offset collisions.

• On the other hand, depending on the type and location of impact, Advanced Front Air Bags may deploy in crashes with little vehicle front-end damage but that produce a severe initial deceleration.

•

Because air bag sensors measure vehicle deceleration over time, vehicle speed and damage

by themselves are not good indicators of whether or not an air bag should have deployed.

• Seat belts are necessary for your protection in all collisions, and also are needed to help keep you in position, away from an inflating air bag.

• After any collision, the vehicle should be taken to an authorized dealer immediately.

• Do not drive your vehicle after the air bags have deployed. If you are involved in another collision, the air bags will not be in place to protect you.

• If it is necessary to modify the air bag system for persons with disabilities, contact your authorized dealer.

• Refer to the Owner's Manual on the DVD for further details regarding the Supplemental Restraint System (SRS).

Page 20

GETTING STARTED

Occupant Classification System

This vehicle is equipped with a right front passenger Occupant Classification System (“OCS”) that is designed to provide Passenger Advanced Front Air Bag output appropriate to the occupant’s seated weight input, as determined by the OCS.

The Occupant Classification System (OCS) consists of the following:

• Occupant Restraint Controller (ORC)

• Occupant Classification Module (OCM) and Sensor located in the front passenger seat

• Air Bag Warning Light

The OCS will NOT prevent deployment of the Passenger Advanced Front Air Bag. The OCS may reduce the inflation rate of the Passenger Advanced Front Air Bag if the OCS estimates that:

• The front passenger seat is unoccupied or has very light objects on it; or

• The front passenger seat is occupied by a small passenger, including a child; or

• The front passenger seat is occupied by a rear-facing child restraint; or

• The front passenger is not properly seated or his or her weight is taken off of the seat for a period of time.

Front Passenger Seat Occupant Status Front Passenger Air Bag Output

Rear-facing child restraint Reduced-power deployment Child, including a child in a forward-facing

child restraint or booster seat*

Properly seated adult

Unoccupied seat Reduced-power deployment

* It is possible for a child to be classified as an adult, allowing a full-power Passenger Advanced Front Air Bag deployment. Never allow children to ride in the front passenger seat and never install a child restraint system, including a rear -facing child restraint, in the front passenger seat.

The OCS determines the front passenger’s most probable classification.

The OCS estimates the seated weight on the front passenger seat and where that weight is located. The OCS communicates the classification status to the ORC. The ORC uses the classification to determine whether the Passenger Advanced Front Air Bag inflation rate should be adjusted. In order for the OCS to operate as designed, it is important for the front passenger to be seated properly and properly wearing the seat belt. Properly seated passengers are:

Full-power deployment OR reducedpower deployment

• Sitting upright

• Facing forward

Page 21

GETTING STARTED

• Sitting in the center of the seat with their feet comfortably on or near the floor

• Sitting with their back against the seatback and the seatback in an upright position

Seated Properly

Lighter Weight Passengers (Including Small Adults)

When a lighter weight passenger, including a small adult, occupies the front passenger seat, the OCS may reduce the inflation rate of the Passenger Advanced Front Air Bag. This does not mean that the OCS is working improperly .

Do not decrease OR increase the front passenger’s seated weight on the front passenger seat

The front passenger’s seated weight must be properly positioned on the front passenger seat. Failure to do so may result in serious injury or death. The OCS determines the most probable classification of the occupant that it detects. The OCS will detect the front passenger’s decreased or increased seated weight, which may result in an adjusted inflation rate of the Passenger Advanced Front Air Bag in a collision. This does not mean that the OCS is working improperly. Decreasing the front passenger’s seated weight on the front passenger seat may result in a reduced-power deployment of the Passenger Advanced Front Air Bag. Increasing the front passenger’s seated weight on the front passenger seat may result in a full-power deployment of the Passenger Advanced Front Air Bag. Examples of improper front passenger seating include:

• The front passenger’s weight is transferred to another part of the vehicle (like the door, arm rest or instrument panel).

• The front passenger leans forward, sideways, or turns to face the rear of the vehicle.

• The front passenger’s seatback is not in the full upright position.

• The front passenger carries or holds an object while seated (e.g., backpack, box, etc.).

• Objects are lodged under the front passenger seat.

• Objects are lodged between the front passenger seat and center console.

• Accessories that may change the seated weight on the front passenger seat are attached to the front passenger seat.

• Anything that may decrease or increase the front passenger’ s seated weight.

Page 22

GETTING STARTED

The OCS determines the front passenger’s most probable classification. If an occupant in the front passenger seat is seated improperly, the occupant may provide an output signal to the OCS that is different from the occupant’s properly seated weight input, for example:

The Air Bag Warning Light in the instrument panel OCS is unable to classify the front passenger seat status. A malfunction in the OCS may affect the operation of the air bag system.

will turn on whenever the

If the Air Bag Warning Light come on, or stays on after you start the vehicle, or it comes on as you drive, take the vehicle to an authorized dealer for service immediately .

The passenger seat assembly contains critical OCS components that may affect the Passenger Advanced Front Air Bag inflation. In order for the OCS to properly classify the seated weight of a front seat passenger, the OCS components must function as designed.

Do not make any modifications to the front passenger seat components, assembly, or to the seat cover. If the seat, trim cover, or cushion needs service for any reason, take the vehicle to your authorized dealer. Only FCA US LLC approved seat accessories may be used.

does not

Not Seated Properly

Page 23

GETTING STARTED

The following requirements must be strictly followed:

• Do not modify the front passenger seat assembly or components in any way.

Do not use prior or future model year seat covers or cushions not designated by FCA US LLC

• for the specific model being repaired. Always use the correct seat cover and cushion specified for the vehicle.

•

Do not replace the seat cover or cushion with an aftermarket seat cover or cushion.

• Do not add a secondary seat cover or mat.

• At no time should any Supplemental Restraint System (SRS) component or SRS related component or fastener be modified or replaced with any part except those which are approved by FCA US LLC.

Supplemental Knee Air Bags

This vehicle is equipped with a Supplemental Driver Knee Air Bag mounted in the instrument panel below the steering column and a Supplemental Passenger Knee Air Bag mounted in the instrument panel below the glove compartment. The Supplemental Knee Air Bags provide enhanced protection during a frontal impact by working together with the seat belts, pretensioners, and Advanced Front Air Bags.

Supplemental Side Air Bags

• This vehicle is equipped with Supplemental Seat-Mounted Side Air Bags (SABs) located in the outboard side of the front and rear (in vehicles equipped with outboard rear seat SABs) seats. The SABs are marked with a SRS AIRBAG or AIRBAG label sewn into the outboard side of the seats.

• This vehicle is equipped with Supplemental Side Air Bag Inflatable Curtains (SABICs) located above the side windows. The trim covering the SABICs is labeled SRS AIRBAG or AIRBAG. The SABICs may help reduce the risk of partial or complete ejection of vehicle occupants through side windows in certain side impact events.

• The SABICs and SABs (“Side Air Bags”) are designed to activate in certain side impacts. The Occupant Restraint Controller (“ORC”) determines whether the deployment of the Side Air Bags in a particular impact event is appropriate, based on the severity and type of collision. Vehicle damage by itself is not a good indicator of whether or not Side Air Bags should have deployed.

Page 24

GETTING STARTED

WARNING!

• Side Air Bags need room to inflate. Do not lean against the door or window. Sit upright in the center of the seat.

• Being too close to the Side Air Bags during deployment could cause you to be severely injured or killed.

• Relying on the Side Air Bags alone could lead to more severe injuries in a collision. The Side Air Bags work with your seat belt to restrain you properly . In some collisions, Side Air Bags won’t deploy at all. Always wear your seat belt even though you have Side Air Bags.

•

This vehicle is equipped with left and right Supplemental Side Air Bag Inflatable Curtains (SABICs). Do not stack luggage or other cargo up high enough to block the deployment of the SABICs. The trim covering above the side windows where the SABIC and its deployment path are located should remain free from any obstructions.

• This vehicle is equipped with SABICs. In order for the SABICs to work as intended, do not install any accessory items in your vehicle which could alter the roof. Do not add an aftermarket sunroof to your vehicle. Do not add roof racks that require permanent attachments (bolts or screws) for installation on the vehicle roof. Do not drill into the roof of the vehicle for any reason.

• Do not use accessory seat covers or place objects between you and the Side Air Bags; the performance could be adversely affected and/or objects could be pushed into you, causing serious injury.

Enhanced Accident Response System

In the event of an impact, if the communication network remains intact, and the power remains intact, depending on the nature of the event, the ORC will determine whether to have the Enhanced Accident Response System perform the following functions:

• Cut off fuel to the engine.

• Flash hazard lights as long as the battery has power or until the hazard light button is pushed. The hazard lights can be deactivated by pushing the hazard light button.

• Turn on the interior lights, which remain on as long as the battery has power .

• Unlock the power door locks.

Enhanced Accident Response System Reset Procedure

In order to reset the Enhanced Accident Response System functions after an event, the ignition switch must be changed from ignition ST AR T or ON/RUN to ignition OFF . Carefully check the vehicle for fuel leaks in the engine compartment and on the ground near the engine compartment and fuel tank before resetting the system and starting the engine.

Air Bag Warning Light

• The air bags must be ready to inflate for your protection in a collision. The Occupant Restraint Controller (ORC) monitors the internal circuits and interconnecting wiring associated with air bag system electrical components.

Page 25

GETTING STARTED

•

The ORC monitors the readiness of the electronic parts of the air bag system whenever the ignition switch is in the START or ON/RUN position. If the ignition switch is in the OFF position or in the ACC position, the air bag system is not on and the air bags will not inflate.

• The ORC turns on the Air Bag W arning Light in the instrument panel for approximately four to eight seconds for a self-check when the ignition switch is first turned to the ON/RUN position. After the self-check, the Air Bag Warning Light will turn off. If the ORC detects a malfunction in any part of the system, it turns on the Air Bag Warning Light, either momentarily or continuously. A single chime will sound to alert you if the light comes on again after initial startup.

• If the Air Bag Warning Light in the instrument panel is not on during the four to eight seconds when the ignition switch is first turned to the ON/RUN position, stays on, or turns on while driving, have the vehicle serviced by an authorized service center immediately .

NOTE:

If the speedometer, tachometer, or any engine related gauges are not working, the Occupant Restraint Controller (ORC) may also be disabled. In this condition the air bags may not be ready to inflate for your protection. Have an authorized dealer service the air bag system immediately.

Event Data Recorder (EDR)

This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed. The EDR is designed to record data related to vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less. The EDR in this vehicle is designed to record such data as:

• How various systems in your vehicle were operating;

• Whether or not the driver and passenger safety belts were buckled/fastened;

• How far (if at all) the driver was depressing the accelerator and/or brake pedal; and,

• How fast the vehicle was traveling.

These data can help provide a better understanding of the circumstances in which crashes and injuries occur.

NOTE:

EDR data are recorded by your vehicle only if a non-trivial crash situation occurs; no data are recorded by the EDR under normal driving conditions and no personal data (e.g., name, gender, age, and crash location) are recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation.

To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have the special equipment, can read the information if they have access to the vehicle or the EDR.

Page 26

GETTING STARTED

CHILD RESTRAINTS

Children 12 years or younger should ride properly buckled up in a rear seat, if available. According to crash statistics, children are safer when properly restrained in the rear seats rather than in the front.

Every state in the United States and all Canadian provinces require that small children ride in proper restraint systems. This is the law , and you can be prosecuted for ignoring it.

NOTE:

• For additional information, refer to www.Seatcheck.org or call 1-866-SEATCHECK (1-866-732-8243 ).

• Canadian residents should refer to Transport Canada’s website for additional information: http://www.tc.gc.ca/eng/motorvehiclesafety/safedrivers-childsafety-index-53.htm

LATCH – Lower Anchors And Tethers For CHildren

Your vehicle is equipped with the child restraint anchorage system called LA TCH, which stands for Lower Anchors and T ethers for CHildren.

The rear outboard seating positions have lower anchors and top tether anchors. The rear center seating position has a top tether anchor only.

LATCH Weight Limit

You may use the LA TCH anchorage system until the combined weight of the child and the child restraint is 65 lbs (29.5 kg). Use the seat belt and tether anchor instead of the LATCH system once the combined weight is more than 65 lbs (29.5 kg).

Lower Anchors

Locating LATCH Anchorages

The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seatback, below the anchorage symbols on the seatback. They are just visible when you lean into the rear seat to install the child restraint. You will easily feel them if you run your finger along the gap between the seatback and seat cushion.

Page 27

GETTING STARTED

Locating Tether Anchorages

In addition, there are tether strap anchorages behind each rear seating position located in the panel between the rear seatback and the rear window. These tether strap anchorages are under a plastic cover with the tether anchorage symbol on it.

Center Seat LATCH

Do not install child restraints with rigid lower attachments in the center seating position. Only install this type of child restraint in the outboard seating positions. Child restraints with flexible, webbing mounted lower attachments can be installed in any rear seating position. In the center position, the inner anchorages are 17 inches (440 mm) apart.

Tether Anchorages

Installing The Child Restraint Using The LATCH Lower Anchors

NOTE:

Never “share” a LA TCH anchorage with two or more child restraints.

1. Loosen the adjusters on the lower straps and on the tether strap of the child seat so that

you can more easily attach the hooks or connectors to the vehicle anchorages.

2. Attach the lower hooks or connectors of the child restraint to the lower anchorages in

the selected seating position.

3. If the child restraint has a tether strap, connect it to the top tether anchorage. See

below for directions to attach a tether anchor.

4. T ighten all of the straps as you push the child restraint rearward and downward into the

seat. Remove slack in the straps according to the child restraint manufacturer’s instructions.

5. T est that the child restraint is installed tightly by pulling back and forth on the child

seat at the belt path. It should not move more than 1 inch (25.4 mm) in any direction.

Installing The Child Restraint Using The Vehicle Seat Belts

The seat belts in the passenger seating positions are equipped with a Switchable Automatic Locking Retractor (ALR) that is designed to keep the lap portion of the seat belt tight around the child restraint. Any seat belt system will loosen with time, so check the belt occasionally, and pull it tight if necessary.

Page 28

GETTING STARTED

Tether Anchorage Weight Limit

Always use the tether anchor when using the seat belt to install a forward facing child restraint, up to the recommended weight limit of the child restraint.

To Install A Child Seat Using An ALR:

1. Pull enough of the seat belt webbing from the retractor to pass it through the belt path of the child restraint. Do not twist the belt webbing in the belt path.

2. Slide the latch plate into the buckle until you hear a “click.”

3. Pull on the webbing to make the lap portion tight against the child seat.

4. T o lock the seat belt, pull down on the shoulder part of the belt until you have pulled all the seat belt webbing out of the retractor. Then, allow the webbing to retract back into the retractor. As the webbing retracts, you will hear a clicking sound. This means the seat belt is now in the Automatic Locking mode.

5. T ry to pull the webbing out of the retractor. If it is locked, you should not be able to pull out any webbing. If the retractor is not locked, repeat the last step.

6. Finally, pull up on any extra webbing to tighten the lap portion around the child restraint while you push the child restraint rearward and downward into the vehicle seat.

7. If the child restraint has a top tether strap and the seating position has a top tether anchorage, connect the tether strap to the anchorage and tighten the tether strap. See below for directions to attach a tether anchor.

8. T est that the child restraint is installed tightly by pulling back and forth on the child seat at the belt path. It should not move more than 1 inch (25.4 mm) in any direction.

Installing The Top Tether Strap (With Either Lower Anchors Or Vehicle Seat Belt):

When installing a forward-facing child restraint, always secure the top tether strap, up to the tether anchor weight limit, whether the child restraint is installed with the lower anchors or the vehicle seat belt.

Tether Strap Installation

1. Rotate or lift the cover to access the anchor directly behind the seat where you are placing the child restraint.

2. Route the tether strap to provide the most direct path for the strap between the anchor and the child seat.

3. If your vehicle is equipped with adjustable rear head restraints, raise the head restraint, and where possible, route the tether strap under the head restraint and between the two posts. If not possible, lower the head restraint and pass the tether strap around the outboard side of the head restraint.

Page 29

GETTING STARTED

4. Attach the tether strap hook of the child restraint to the top tether anchorage and remove slack in the tether strap according to the child restraint manufacturer’s instructions.

Tether Strap Mounting

1 — Cover 3 — Attaching Strap A — Tether Strap Hook B — Tether Anchor

WARNING!

• In a collision, an unrestrained child, even a tiny baby , can become a projectile inside the vehicle. The force required to hold even an infant on your lap could become so great that you could not hold the child, no matter how strong you are. The child and others could be severely injured or killed. Any child riding in your vehicle should be in a proper restraint for the child's size.

• Never place a rear-facing child restraint in front of an air bag. A deploying Passenger Advanced Front Air Bag can cause death or serious injury to a child 12 years or younger, including a child in a rear-facing child restraint.

• Only use a rear-facing child restraint in a vehicle with a rear seat.

• Improper installation of a child restraint to the LA TCH anchorages can lead to failure of an infant or child restraint. The child could be severely injured or killed. Follow the manufacturer’s directions exactly when installing an infant or child restraint.

• An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child. Use only the anchor positions directly behind the child seat to secure a child restraint top tether strap.

• If your vehicle is equipped with a split rear seat, make sure the tether strap does not slip into the opening between the seatbacks as you remove slack in the strap.

Page 30

GETTING STARTED

HEAD RESTRAINTS

Head restraints are designed to reduce the risk of injury by restricting head movement in the event of a rear impact. Head restraints should be adjusted so that the top of the head restraint is located above the top of your ear.

WARNING!

The head restraints for all occupants must be properly installed and adjusted prior to operating the vehicle or occupying a seat. Head restraints should never be adjusted while the vehicle is in motion. Driving a vehicle with the head restraints improperly adjusted or removed could cause serious injury or death in the event of a collision.

Reactive Head Restraints — Front Seats

The front driver and passenger seats are equipped with Reactive Head Restraints (RHR). In the event of a rear impact the RHRs will automatically extend forward minimizing the gap between the back of the occupant’s head and the RHR.

The RHRs will automatically return to their normal position following a rear impact. If the RHRs do not return to their normal position see your authorized dealer immediately.

To raise the head restraint, pull upward on the head restraint. T o lower the head restraint, push the adjustment button, located at the base of the head restraint, and push downward on the head restraint.

NOTE:

To remove the head restraint, raise it as far as it can go then push the release button and the adjustment button at the base of each post while pulling the head restraint up. Seatback angle may need to be adjusted to fully remove the head restraint. T o reinstall the head restraint, put the head restraint posts into the holes and push downward. Then adjust the head restraint to the appropriate height.

WARNING!

• A loose head restraint thrown forward in a collision or hard stop could cause serious injury or death to occupants of the vehicle. Always securely stow removed head restraints in a location outside the occupant compartment.

• ALL the head restraints MUST be reinstalled in the vehicle to properly protect the occupants. Follow the re-installation instructions above prior to operating the vehicle or occupying a seat.

• Do not place items over the top of the Reactive Head Restraint, such as coats, seat covers or portable DVD players. These items may interfere with the operation of the Reactive Head Restraint in the event of a collision and could result in serious injury or death.

Page 31

GETTING STARTED

Rear Head Restraints

The rear outboard head restraints have three positions UP , MID and DOWN. The center head restraint has only two positions, UP and DOWN. When the center seat is being occupied the head restraint should be in the raised position. When there are no occupants in the center seat the head restraint can be lowered for maximum visibility for the driver.

NOTE:

To remove the head restraint, raise it as far as it can go then push the release button and the adjustment button at the base of each post while pulling the head restraint up. Seatback needs to be folded forward to fully remove the head restraint. To reinstall the head restraint, put the head restraint posts into the holes and push downward. Then adjust the head restraint to the appropriate height.

WARNING!

• ALL the head restraints MUST be reinstalled in the vehicle to properly protect the occupants. Follow the re-installation instructions above prior to operating the vehicle or occupying a seat.

Page 32

GETTING STARTED

FRONT SEATS

Power Seats — If Equipped

Some models may be equipped with a power driver's seat. The power seat switch is located on the outboard side of the seat near the floor. Use the switch to move the seat up, down, forward or rearward.

Adjusting The Seat Forward Or Rearward

The seat can be adjusted both forward and rearward. Push the seat switch forward or rearward. The seat will move in the direction of the switch. Release the switch when the desired position has been reached.

Adjusting The Seat Up Or Down

The height of the seats can be adjusted up or down. Pull upward or push downward on the seat switch. The seat will move in the direction of the switch. Release the switch when the desired position is reached.

Reclining The Seatback Forward Or Rearward

The seatback can be reclined both forward and rearward. Push the seat recliner switch forward or rearward. The seatback will move in the direction of the switch. Release the switch when the desired position has been reached.

1 — Power Seat Switch 2 — Recline Switch 3 — Power Lumbar Switch

Power Seat Switches

WARNING!

Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt, which could result in serious injury or death.

Power Lumbar — If Equipped

Vehicles equipped with power driver or passenger seats may be equipped with power lumbar. The power lumbar switch is located on the outboard side of the power seat. Push the switch forward or rearward to increase or decrease the lumbar support. Push the switch upward or downward to raise or lower the lumbar support.

Page 33

GETTING STARTED

Manual Front Seat Forward/Rearward Adjustment

On models equipped with manual seats, the adjusting bar is located at the front of the seats, near the floor.

While sitting in the seat, lift up on the bar and move the seat forward or rearward. Release the bar once you have reached the desired position. Then, using body pressure, move forward and rearward on the seat to be sure that the seat adjusters have latched.

Manual Seat Adjustment

1 — Forward/Rearward Adjusting Bar 2 — Height Adjustment 3 — Recliner Lever

WARNING!

• Adjusting a seat while driving may be dangerous. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death.

• Seats should be adjusted before fastening the seat belts and while the vehicle is parked. Serious injury or death could result from a poorly adjusted seat belt.

Manual Front Seat Recline Adjustment

To adjust the seatback, lift the lever located on the outboard side of the seat, lean back to the desired position and release the lever . To return the seatback, lift the lever, lean forward and release the lever.

WARNING!

Manual Seat Height Adjustment — If Equipped

The driver’ s seat height can be raised or lowered by using a lever, located on the outboard side of the seat. Pull upward on the lever to raise the seat height or push downward on the lever to lower the seat height.

Page 34

GETTING STARTED

REAR SEAT

Folding Rear Seat

The rear seatbacks can be folded forward to provide an additional storage area. To fold the rear seatback, pull on the loops located on the upper seatback.

NOTE:

The upper seatback loops can be tucked away when not in use.

After releasing the seatback, it can be folded forward.

When the seatback is folded to the upright position, make sure it is latched by strongly pulling on the top of the seatback above the seat strap.

Seatback Loops Locations

WARNING!

• Be certain that the seatback is securely locked into position. If the seatback is not securely locked into position, the seat will not provide the proper stability for child seats and/or passengers. An improperly latched seat could cause serious injury .

• The cargo area in the rear of the vehicle (with the rear seatbacks in the locked-up or folded down position) should not be used as a play area by children when the vehicle is in motion. They could be seriously injured in a collision. Children should be seated and using the proper restraint system.

Page 35

GETTING STARTED

HEATED SEATS

Front Heated Seats

The front heated seats control buttons are located within the Uconnect system. You can gain access to the control buttons through the climate screen or the controls screen.

• Press the heated seat button

If the HI-level setting is selected, the system will automatically switch to LO-level after approximately 60 minutes of continuous operation. At that time, the display will change from HI to LO, indicating the change. The LO-level setting will turn OFF automatically after approximately 45 minutes.

NOTE:

The engine must be running for the heated seats to operate.

Vehicles Equipped With Remote Start

On models that are equipped with remote start, the heated seats can be programed to come on during a remote start.

This feature can be programmed through the Uconnect system. Refer to “Uconnect Settings” in “Understanding Your Instrument Panel” in the Owner’s Manual on the DVD for further information.

once to turn the HI setting ON.

a second time to turn the LO setting ON.

a third time to turn the heating elements OFF.

WARNING!

• Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion or other physical condition must exercise care when using the seat heater. It may cause burns even at low temperatures, especially if used for long periods of time.

• Do not place anything on the seat or seatback that insulates against heat, such as a blanket or cushion. This may cause the seat heater to overheat. Sitting in a seat that has been overheated could cause serious burns due to the increased surface temperature of the seat.

Page 36

GETTING STARTED

HEATED STEERING WHEEL — IF EQUIPPED

The steering wheel contains a heating element that helps warm your hands in cold weather. The heated steering wheel has only one temperature setting. Once the heated steering wheel has been turned on it can operate for up to 165 minutes before automatically shutting off. The heated steering wheel can shut off early or may not turn on when the steering wheel is already warm.

The heated steering wheel control button is located within the Uconnect system. You can gain access to the control button through the climate screen or the controls screen.

• Press the heated steering wheel button

• Press the heated steering wheel button OFF.

NOTE:

The engine must be running for the heated steering wheel to operate.

Vehicles Equipped With Remote Start

On models that are equipped with remote start, the heated steering wheel can be programmed to come on during a remote start through the Uconnect system. Refer to “Uconnect Settings” in “Understanding Your Instrument Panel” in the Owner’s Manual on the DVD for further information.

once to turn the heating element ON.

a second time to turn the heating element

WARNING!

• Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion, or other physical conditions must exercise care when using the steering wheel heater. It may cause burns even at low temperatures, especially if used for long periods.

• Do not place anything on the steering wheel that insulates against heat, such as a blanket or steering wheel covers of any type and material. This may cause the steering wheel heater to overheat.

Page 37

GETTING STARTED

TILT/TELESCOPING STEERING COLUMN

This feature allows you to tilt the steering column upward or downward. It also allows you to lengthen or shorten the steering column. The tilt/telescoping control handle is located below the steering wheel at the end of the steering column.

To unlock the steering column, push the control handle down. T o tilt the steering column, move the steering wheel upward or downward as desired. To lengthen or shorten the steering column, pull the steering wheel outward or push it inward as desired. To lock the steering column in position, push the control handle up until fully engaged.

Tilt/Telescoping Control Lever

WARNING!

Do not adjust the steering column while driving. Adjusting the steering column while driving or driving with the steering column unlocked, could cause the driver to lose control of the vehicle. Failure to follow this warning may result in serious injury or death.

Page 38

OPERATING YOUR VEHICLE

ENGINE BREAK-IN RECOMMENDATIONS

A long break-in period is not required for the engine and drivetrain (transmission and axle) in your vehicle.

Drive moderately during the first 300 miles (500 km). After the initial 60 miles (100 km), speeds up to 50 or 55 mph (80 or 90 km/h) are desirable.

While cruising, brief full-throttle acceleration within the limits of local traffic laws contributes to a good break-in. Wide-open throttle acceleration in low gear can be detrimental and should be avoided.

The engine oil installed in the engine at the factory is a high-quality energy conserving type lubricant. Oil changes should be consistent with anticipated climate conditions under which vehicle operations will occur. Refer to “Maintaining Your Vehicle,” for the recommended viscosity and quality grades.

NOTE:

A new engine may consume some oil during its first few thousand miles (kilometers) of operation. This should be considered a normal part of the break-in and not interpreted as an indication of an engine problem or malfunction.

CAUTION!

Never use Non-Detergent Oil or Straight Mineral Oil in the engine or damage may result.

Page 39

OPERATING YOUR VEHICLE

TURN SIGNAL/WIPER/WASHER/HIGH BEAM LEVER

Multifunction Lever

1 — Push For Washer 2 — Rotate Downward For Mist 3 — Push Lever For High Beams

Turn Signal/Lane Change Assist

Tap the lever up or down once and the turn signal (right or left) will flash three times and automatically turn off.

Front Wipers

Intermittent, Low And High Operation

Rotate the end of the lever to the first detent position for one of four intermittent settings, the second detent for low wiper operation and the third detent for high wiper operation.

Mist

Rotate the end of the lever rearward when a single wipe is desired.

NOTE:

The mist feature does not activate the washer pump; therefore, no washer fluid will be sprayed on the windshield. The wash function must be activated in order to spray the windshield with washer fluid.

Page 40

OPERATING YOUR VEHICLE

Washer Operation

Push the end of the lever inward and hold for as long as spray is desired.

Rain Sensing Wipers

This feature senses moisture on the vehicle's windshield and automatically activates the wipers for the driver when the switch is in the intermittent position. Rotate the end of the lever to one of four settings to activate this feature and adjust sensitivity.

Rain Sensing can be turned on and off using the Uconnect System, refer to the Owner's Manual on the DVD for further details.

High Beam Operation

Push the lever forward to activate the high beams. Pull the lever toward you for flash to pass.

NOTE:

For safe driving, turn off the high beams when oncoming traffic is present to prevent headlight glare and as a courtesy to other motorists.

Page 41

OPERATING YOUR VEHICLE

HEADLIGHT SWITCH

Automatic Headlights/Parking Lights/Headlights

Rotate the headlight switch, located on the instrument panel to the left of the steering wheel, to the first detent for parking lights headlights

With the parking lights or low beam headlights on, push the headlight switch once for fog lights.

Rotate the headlight switch to AUTO for AUTO headlights if equipped with this feature.

and to the second detent for

When set to AUTO, the system automatically turns the headlights on or off based on ambient light levels.

Fog Lights — If Equipped

Turn the headlights or parking lights on and push the headlight switch once to turn the fog lights on.

Push the switch a second time to turn the fog lights off. Fog lights will not operate when high beams are on.

A fog light symbol will illuminate in the cluster to indicate the fog lights are on.

Headlight Switch Premium Model

1 — Auto-If Equipped 2 — Rotate Headlight Switch 3 — Rotate Dimmer 4 — Rotate Ambient Light ControlIf Equipped

Instrument Panel Dimmer

• Rotate the dimmer control to the extreme bottom position to fully dim the instrument panel lights and prevent the interior lights from illuminating when a door is opened.

• Rotate the dimmer control up to increase the brightness of the instrument panel when the parking lights or headlights are on.

• Rotate the dimmer control up to the next detent position to fully brighten the odometer and radio when the parking lights or headlights are on.

• Rotate the dimmer control up to the last detent position to turn on the interior lighting.

If your vehicle is equipped with a touchscreen, the dimming is programmable through the Uconnect system. Refer to “Uconnect Settings ” in “Understanding Your Instrument Panel” in the Owner's Manual on the DVD for further details.

Ambient Light Control

Rotate the right dimmer control upward or downward to increase or decrease the brightness of the instrument bezel ambient lighting (if equipped), of the door handle lights and of the door map pocket lights.

Page 42

OPERATING YOUR VEHICLE

ELECTRONIC SPEED CONTROL — IF EQUIPPED

When engaged, the Electronic Speed Control takes over accelerator operations at speeds greater than 25 mph (40 km/h).

The Electronic Speed Control buttons are located on the right side of the steering wheel.

NOTE:

In order to ensure proper operation, the Electronic Speed Control system has been designed to shut down if multiple Speed Control functions are operated at the same time. If this occurs, the Electronic Speed Control system can be reactivated by pushing the Electronic Speed Control ON/OFF button and resetting the desired vehicle set speed.

To Activate

Push the ON/OFF button to activate the Electronic Speed Control. The Cruise Indicator Light in the Electronic Vehicle Information Center (EVIC) or Driver Information Display (DID) will illuminate. T o turn the system off, push the ON/OFF button a second time. The Cruise Indicator Light will turn off. The system should be turned off when not in use.

Electronic Speed Control Switches

1 — Push CANCEL 2 — Push ON/OFF 3 — Push Resume/Accel 4 — Push Set/Decel

WARNING!

Leaving the Electronic Speed Control system on when not in use is dangerous. You could accidentally set the system or cause it to go faster than you want. Y ou could lose control and have an accident. Always leave the system OFF when you are not using it.

Page 43

OPERATING YOUR VEHICLE

To Set A Desired Speed

Turn the Electronic Speed Control ON.

NOTE:

The vehicle should be traveling at a steady speed and on level ground before pushing the SET button.

When the vehicle has reached the desired speed, push the SET (-) button and release. Release the accelerator and the vehicle will operate at the selected speed.

NOTE:

After pushing the SET button “Cruise Control Set” message is displayed for five seconds or until another switch is pushed.

For Premium Clusters Only

• When set to analog mode: The red outer line on the speedometer changes from red to white to identify set speed.

To Deactivate

A soft tap on the brake pedal, pushing the CANCEL button, or normal brake pressure while slowing the vehicle will deactivate Electronic Speed Control without erasing the set speed memory . Pushing the ON/OFF button or turning the ignition switch OFF erases the set speed memory.

NOTE:

After pushing the OFF button a “Cruise Control Off” message is displayed for five seconds or until another switch is pushed.

For Premium Clusters Only

• When set to analog mode: The white outer line on the speedometer returns to red.

To Resume Speed

To resume a previously set speed, push the RES (+) button and release. Resume can be used at any speed above 20 mph (32 km/h).

Page 44

OPERATING YOUR VEHICLE

To Vary The Speed Setting

To Increase Speed

When the Electronic Speed Control is set, you can increase speed by pushing the RES (+) button.

The drivers preferred units can be selected through the instrument panel settings if equipped. Refer to “Understanding Your Instrument Panel” in the Owner’ s Manual on the DVD for more information. The speed increment shown is dependant on the chosen speed unit of U.S. (mph) or Metric (km/h):

U.S. Speed (mph)

• Pushing the RES (+) button once will result in a 1 mph increase in set speed. Each subsequent tap of the button results in an increase of 1 mph.

• If the button is continually pushed, the set speed will continue to increase until the button is released, then the new set speed will be established.

Metric Speed (km/h)

• Pushing the RES (+) button once will result in a 1 km/h increase in set speed. Each subsequent tap of the button results in an increase of 1 km/h.

• If the button is continually pushed, the set speed will continue to increase until the button is released, then the new set speed will be established.

To Decrease Speed

When the Electronic Speed Control is set, you can decrease speed by pushing the SET (-) button.

The drivers preferred units can be selected through the instrument panel settings if equipped. Refer to “Understanding Your Instrument Panel” in the Owner’ s Manual on the DVD for more information. The speed decrement shown is dependant on the chosen speed unit of U.S. (mph) or Metric (km/h):

U.S. Speed (mph)

• Pushing the SET (-) button once will result in a 1 mph decrease in set speed. Each subsequent tap of the button results in a decrease of 1 mph.

• If the button is continually pushed, the set speed will continue to decrease until the button is released, then the new set speed will be established.

Page 45

OPERATING YOUR VEHICLE

Metric Speed (km/h)

• Pushing the SET (-) button once will result in a 1 km/h decrease in set speed. Each subsequent tap of the button results in a decrease of 1 km/h.

• If the button is continually pushed, the set speed will continue to decrease until the button is released, then the new set speed will be established.

To Accelerate For Passing

Press the accelerator as you would normally. When the pedal is released, the vehicle will return to the set speed.

Using Electronic Speed Control On Hills

The transmission may downshift on hills to maintain the vehicle set speed.

NOTE:

The Electronic Speed Control system maintains speed up and down hills. A slight speed change on moderate hills is normal.

On steep hills, a greater speed loss or gain may occur so it may be preferable to drive without Electronic Speed Control.

WARNING!

Electronic Speed Control can be dangerous where the system cannot maintain a constant speed. Your vehicle could go too fast for the conditions, and you could lose control and have an accident. Do not use Electronic Speed Control in heavy traffic or on roads that are winding, icy, snow-covered or slippery.

Page 46

OPERATING YOUR VEHICLE

MANUAL CLIMATE CONTROLS

Manual Climate Controls

1 — Rotate Blower Control 2 — Push Air Recirculation Button 3 — Rotate T emperature Control

4 — Push A/C Button 5 — Rotate Mode Control 6 — Push Rear Defroster Button

Air Recirculation

Use Recirculation for maximum A/C operation.

For window defogging, turn the Recirculation button off.

Recirculation is allowed in floor and defrost/floor (mix modes) for approximately five minutes.

Heated Mirrors — If Equipped

The mirrors are heated to melt frost or ice. This feature is activated whenever you turn on the rear window defroster.

Page 47

OPERATING YOUR VEHICLE

UCONNECT 8.4 MANUAL CLIMATE CONTROLS

Uconnect 8.4 Manual Climate Controls

1 — MAX A/C Button 2 — A/C Button 3 — Air Recirculation Button 4 — Mode Adjustment Buttons 5 — Front Defroster Button

6 — Rear Defroster Button 7 — Blower Control Up/Down Buttons 8 — OFF Button 9 — Temperature Controls Up/Down

Page 48

OPERATING YOUR VEHICLE

Climate Control Knobs

1 — Temperature Controls Up/Down 2 — A/C Button 3 — Air Recirculation Button 4 — Rotate Blower Control

For your convenience the climate controls can be operated by using the buttons located on the touchscreen or the climate control knobs below the Uconnect touchscreen.

5 — OFF Button 6 — Front Defroster Button 7 — Rear Defroster Button

Air Recirculation

Use Recirculation for maximum A/C operation.

For window defogging, turn the Recirculation button off.

Recirculated air is not allowed in Defrost modes. If the Recirculation button is pushed while in this mode, the LED indicator will flash several times then go out. Recirculation will be disabled automatically if this mode is selected.

Heated Mirrors — If Equipped

The mirrors are heated to melt frost or ice. This feature is activated whenever you turn on the rear window defroster.

Page 49

OPERATING YOUR VEHICLE

UCONNECT 8.4 AUTOMATIC CLIMATE CONTROLS

Uconnect 8.4 Automatic Climate Controls

1 — MAX A/C Button 2 — A/C Button 3 — Air Recirculation Button 4 — Mode Control Buttons 5 — AUTO Button 6 — Front Defroster Button

7 — Rear Defroster Button 8 — Passenger T emperature Control 9 — SYNC Button 10 — Blower Control Up/Down Buttons 11 — Off Button 12 — Driver T emperature Control

Page 50

OPERATING YOUR VEHICLE

Climate Control Knobs

1 — AUTO Button 2 — Driver T emperature Up 3 — Passenger T emperature Up 4 — A/C Button 5 — Air Recirculation Button 6 — Driver T emperature Down

For your convenience the climate controls can be operated by using the buttons located on the touchscreen or the climate control knobs below the Uconnect touchscreen.

7 — Rotate Blower Control 8 — OFF Button 9 — Passenger T emperature down 10 — Front Defroster Button 11 — Rear Defroster Button

Automatic Operation — If Equipped

• Push the AUTO button or press the “AUTO” button on the touchscreen.

Select the desired temperature by pressing the Temperature Controls for the driver or

• passenger.

• The system will maintain the set temperature automatically.

SYNC Temperature Button — If Equipped

Press the SYNC button on the touchscreen once to control driver and passenger temperatures simultaneously.

Press the SYNC button on the touchscreen a second time to control the temperatures individually .

Page 51

OPERATING YOUR VEHICLE

Air Recirculation

Use Recirculation for maximum A/C operation.

For window defogging, turn the Recirculation button off.

If the Recirculation button is pushed while in the AUTO mode, the indicator light may flash three times to indicate the cabin air is being controlled automatically.

Heated Mirrors — If Equipped

The mirrors are heated to melt frost or ice. This feature is activated whenever you turn on the rear window defroster.

BLIND SPOT MONITORING

The Blind Spot Monitoring (BSM) system uses two radar-based sensors, located inside the rear bumper fascia, to detect Highway licensable vehicles (automobiles, trucks, motorcycles etc.) that enter the blind spot zones from the rear/front/side of the vehicle.

The Blind Spot Monitoring (BSM) system warning light, located in the outside mirrors, will illuminate if a vehicle moves into a blind spot zone.

The BSM system can also be configured to sound an audible (chime) alert and mute the radio to notify you of objects that have entered the detection zones.

Refer to “Blind Spot Monitoring” in “Understanding The Features Of Your Vehicle” in your Owner's Manual on the DVD for further details.

PARKVIEW REAR BACK UP CAMERA — IF EQUIPPED

Your vehicle may be equipped with the ParkView Rear Back Up Camera that allows you to see an on-screen image of the rear surroundings of your vehicle whenever the shift lever is put into REVERSE. The image will be displayed in the touchscreen display along with a caution note to “check entire surroundings” across the top of the screen. After five seconds this note will disappear . The ParkView camera is located on the rear of the vehicle above the rear License plate.

When the vehicle is shifted out of REVERSE, the rear camera mode is exited and the last selected touchscreen appears again.

If your vehicle is equipped with the Camera Delay feature and it is turned On, the rear camera image will be displayed for up to 10 seconds when the vehicle is shifted out of REVERSE unless the forward vehicle speed exceeds 8 mph (13 km/h), the transmission is shifted into "PARK" or the vehicle's ignition is cycled to the OFF position.

Fixed guide lines are overlaid on the image to illustrate the width of the vehicle.

Page 52

OPERATING YOUR VEHICLE

NOTE:

The ParkView Rear Back Up Camera has programmable modes of operation that may be selected through the Uconnect System. Refer to “Uconnect Settings” in “Understanding Your Instrument Panel” for further information.

Different colored zones indicate the distance to the rear of the vehicle.

The following table shows the approximate distances for each zone:

Zone Distance to the rear of the vehicle

Red 0-1ft(0-30cm)

Yellow 1ft-3ft(30cm-1m)

Green 3 ft or greater (1 m or greater)

WARNING!

Drivers must be careful when backing up even when using the ParkView Rear Back Up Camera. Always check carefully behind your vehicle, and be sure to check for pedestrians, animals, other vehicles, obstructions, or blind spots before backing up. You are responsible for the safety of your surroundings and must continue to pay attention while backing up. Failure to do so can result in serious injury or death.

CAUTION!

• T o avoid vehicle damage, ParkView should only be used as a parking aid. The ParkView camera is unable to view every obstacle or object in your drive path.

• T o avoid vehicle damage, the vehicle must be driven slowly when using ParkView to be able to stop in time when an obstacle is seen. It is recommended that the driver look frequently over his/her shoulder when using ParkView.

NOTE:

If snow , ice, mud, or any foreign substance builds up on the camera lens, clean the lens, rinse with water, and dry with a soft cloth. Do not cover the lens.

Page 53

OPERATING YOUR VEHICLE

POWER SUNROOF — IF EQUIPPED

The power sunroof switch is located between the sun visors on the overhead console.

Sunroof Switches

1 — Opening Sunroof 2 — Venting Sunroof 3 — Closing Sunroof

WARNING!

• Never leave children unattended in a vehicle, or with access to an unlocked vehicle. Never leave the Key Fob in or near the vehicle, or in a location accessible to children. Do not leave the ignition of a vehicle equipped with Keyless Enter-N-Go in the ACC or ON/RUN mode. Occupants, particularly unattended children, can become entrapped by the power sunroof while operating the power sunroof switch. Such entrapment may result in serious injury or death.

• In a collision, there is a greater risk of being thrown from a vehicle with an open sunroof. You could also be seriously injured or killed. Always fasten your seat belt properly and make sure all passengers are also properly secured.

•

Do not allow small children to operate the sunroof. Never allow your fingers, other body parts, or any object, to project through the sunroof opening. Injury may result.

Page 54

OPERATING YOUR VEHICLE

Opening Sunroof — Express

Push the switch rearward and release it within one-half second. The sunroof and sunshade will open automatically from any position. The sunroof and sunshade will open fully and stop automatically . This is called “Express Open.” During Express Open operation, any movement of the sunroof switch will stop the sunroof.

Opening Sunroof — Manual Mode

To open the sunroof, push and hold the switch rearward to full open. Any release of the switch will stop the movement. The sunroof and sunshade will remain in a partially opened condition until the switch is pushed and held rearward again.

Closing Sunroof — Express

Push the switch forward and release it within one-half second and the sunroof will close automatically from any position. The sunroof will close fully and stop automatically . This is called “Express Close.” During Express Close operation, any movement of the switch will stop the sunroof.

Closing Sunroof — Manual Mode

To close the sunroof, push and hold the switch in the forward position. Any release of the switch will stop the movement and the sunroof will remain in a partially closed condition until the switch is pushed and held forward again.

Pinch Protect Feature

This feature will detect an obstruction in the opening of the sunroof during Express Close operation. If an obstruction in the path of the sunroof is detected, the sunroof will automatically retract. Remove the obstruction if this occurs. Next, push the switch forward and release to Express Close.

NOTE:

If three consecutive sunroof close attempts result in Pinch Protect reversals, the fourth close attempt will be a Manual Close movement with Pinch Protect disabled.

Pinch Protect Override

If a known obstruction (ice, debris, etc.) prevents closing the sunroof, attempt to remove the obstruction and then push and hold the switch forward until the sunroof fully closes.

NOTE:

Pinch protection is disabled while the switch is pushed.

Page 55

OPERATING YOUR VEHICLE

Venting Sunroof — Express

Push and release the Vent button within one half second and the sunroof will open to the vent position. This is called “Express V ent” and it will occur regardless of sunroof position. During Express Vent operation, any movement of the switch will stop the sunroof.

Sunshade Operation

The sunshade can be opened manually. However, the sunshade will open automatically as the sunroof opens.

NOTE:

The sunshade cannot be closed if the sunroof is open.

Wind Buffeting

Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down, or the sunroof (if equipped) in certain open or partially open positions. This is a normal occurrence and can be minimized. If the buffeting occurs with the rear windows open, open the front and rear windows together to minimize the buffeting. If the buffeting occurs with the sunroof open, adjust the sunroof opening to minimize the buffeting or open any window.

Sunroof Maintenance

Use only a nonabrasive cleaner and a soft cloth to clean the glass panel.

MANUAL TRANSMISSION — IF EQUIPPED

Be sure the transmission is in first gear, not third, when starting from a standing position. Damage to the clutch can result from starting in third gear.

Never drive with your foot resting on the clutch pedal, and never try to hold the vehicle on a hill with the clutch pedal partially engaged. This will cause abnormal wear on the clutch.

Shifting Into Reverse

To shift into Reverse pull up on the lockout ring (located under the shift knob) and shift the transmission into Reverse.

NOTE:

• Never shift into REVERSE until the vehicle has come to a complete stop.

• During cold weather, until the transmission lubricant is warm, you may experience slightly higher shift efforts. This is normal and not harmful to the transmission.

Page 56

OPERATING YOUR VEHICLE

SIX-SPEED AUTOMATIC TRANSMISSION

This vehicle may be equipped with a fuel efficient Dual-Dry Clutch, Six Speed Automatic Transmission. This transmission offers a sportier driving experience with faster AutoStick shifting.

During low-speed driving conditions in first gear, vehicle momentum changes may feel exaggerated in response to changes in accelerator pedal position. This behavior is normal and is similar to vehicles equipped with a manual transmission.

NOTE:

• Very aggressive driving may result in some clutch odor similar to a manual transmission. An active warning message will display in the Instrument Cluster if cool down actions are needed.

• The first few shifts on a new vehicle may be somewhat abrupt. This is a normal condition, and precision shifts will develop within a few hundred miles (kilometers).

• At low speeds you may hear mechanical noises similar to a manual transmission as the transmission changes gears. These noises are normal and will not damage the transmission.

• Before and after the engine is started, you may hear a hydraulic pump for a short period of time. This noise is normal and will not damage the transmission.

Shifting The Transmission

The transmission shift lever position (PRND) is displayed both on the shift lever and in the Electronic Vehicle Information Center (EVIC).

To drive, depress the brake pedal, push the button on the front of the shift lever and move the shift lever from PARK or NEUTRAL to the DRIVE position.

Manual shifts can also be made using the AutoStick shift control.

This transmission is programmed to prevent shifting from Reverse to DRIVE or DRIVE to REVERSE, if vehicle speed is above 6 mph (10 km/h). This safety feature helps protect your transmission from damage.

NOTE:

• When stopped on an incline, it is recommended that you always hold the vehicle in place using the brakes. On steep inclines, Hill Start Assist (HSA) will temporarily hold the vehicle in position when the brake pedal is released. If the accelerator pedal is not applied after a short time, the vehicle will roll back. Either reapply the brake (to hold the vehicle) or press the accelerator to climb the hill.

• During acceleration, gear changes will feel smooth compared to a vehicle with a traditional manual transmission. This is a benefit of the dual clutch design that avoids power loss during up-shifts.

Page 57

OPERATING YOUR VEHICLE

Instrument Cluster Messages

Messages will be displayed in the instrument cluster (if equipped with an EVIC/DID) to alert the driver when certain conditions occur. These messages are described below.

MESSAGE DESCRIPTION

GEAR NOT AV AILABLE In AutoStick mode, the gear selected by the driver is

not available due to a fault condition. See your autho-

rized dealer for diagnosis and service.

SHIFT NOT ALLOWED

SHIFT TO NEUTRAL

THENDorR

AUTOSTICK NOT AV AILABLE

AUTOMATIC MODE NOT

AVAILABLE

REDUCE GEAR CHANGES The transmission pump is overheating. In AutoStick

TRANS. GETTING HOT PRESS

BRAKE

TRANS. HOT STOP SAFELY

SHIFT TO P

SERVICE TRANSMISSION A transmission fault has been detected. See your

SERVICE SHIFTER A shift lever fault has been detected. See your

ENGAGE PARK BRAKE The sensor that monitors PARK engagement is not

The gear position requested by the driver is currently blocked. This occurs if NEUTRAL is requested while

moving, if REVERSE is requested while moving (at 6 mph

[10 km/h] or faster), if DRIVE is requested while moving

backwards (at 6 mph [10 km/h] or faster), or if 3rd gear

or higher is requested at a stop. Make sure the vehicle is

stopped before engaging DRIVE or REVERSE.

The transmission has shifted itself into NEUTRAL (due to

a fault condition, or overheat due to excessive idling when

stopped in DRIVE with the brakes released), but the shift lever remains in gear. Shift into NEUTRAL and then back

into gear for continued driving. If the transmission will not

reengage, see your authorized dealer.

AutoStick mode is unavailable due to a shift lever fault.

See your authorized dealer for diagnosis and service.

The transmission is unable to shift itself automati-

cally , due to a fault condition. Use the AutoStick

mode to shift the transmission manually. See your

authorized dealer for diagnosis and service.

mode, try to drive in one specific gear as much as

possible, avoiding frequent gear changes. In DRIVE,

the transmission will automatically modify its shift

schedule to reduce the number of shifts.

The transmission driving clutch is overheating, usually

due to repeated launches in stop-and-go traffic. Pull

over and allow the transmission to cool in NEUTRAL

until “TRANS. COOL READY TO DRIVE” is displayed.

The transmission driving clutch has overheated.

Pull over, shift the transmission into PARK, and allow

the vehicle to cool until “TRANS. COOL READY

TO DRIVE” is displayed.

authorized dealer for diagnosis and service.

functioning properly . Engage the parking brake to en-

sure that the vehicle will not roll when in PARK.

Refer to your Owner's Manual on the DVD for further details.

Page 58

ELECTRONICS

YOUR VEHICLE'S SOUND SYSTEM

1. Uconnect Voice Command Button pg. 93

2. Uconnect Phone Button pg. 87

3. Steering Wheel Audio Controls (Left) pg. 96

4. Steering Wheel Audio Controls (Right) pg. 96

Page 59

ELECTRONICS

5. Volume Knob/Audio Mute Button

6. Uconnect 8.4 Radio pg. 68

7. T une/Scroll Knob/Browse/Enter Button

8. Media Hub: Audio Jack, USB Port, and CD Slot (located inside front console) pg. 76

Page 60

ELECTRONICS

UCONNECT 200

Uconnect 200

1 — Station Presets (Buttons 1–5) 2 — Radio Mode Button 3 — Time Function Button 4 — Player Mode Button 5 — Info Options Button 6 — A, B or C, Presets Buttons 7 — Play/Pause/Mute Button 8 — Eject CD Button

NOTE:

Your radio may not be equipped with the Uconnect Voice Command and Uconnect Phone

• features. To determine if your radio has these features, locate and push the Uconnect Voice Command

• Your radio has many features that add to the comfort and convenience of you and your passengers. Some of these radio features should not be used when driving because they take your eyes from the road or your attention from driving.

and Uconnect Phone buttons on the steering wheel.

9 — Seek Up Button 10 — ON/OFF — Volume/Mute 11 — ENTER/BROWSE — Tune/Scroll 12 — Seek Down Button 13 — Audio Settings Button 14 — Menu Options Button 15 — Back Function Button

Page 61

ELECTRONICS

Anti-Theft Protection

This radio will not operate in any vehicle other than the vehicle in which it was delivered. The radio display will prompt you to enter an anti-theft code and the radio will not function, if this radio is transferred to another vehicle. You must contact your authorized dealer to get the anti-theft code to unlock the radio.

Clock Setting

1. Push and hold the TIME button until the hours are highlighted.

2. Adjust the hours by turning the right side TUNE/SCROLL control knob.

3. After adjusting the hours, push the right side ENTER/BROWSE control knob to set the minutes. The minutes will highlight.

4. Adjust the minutes using the right side TUNE/SCROLL control knob.

5. T o exit, push the TIME button or push the BACK button to return to the previous menu.

NOTE:

Time format has the options of 12HR or 24HR. Selecting one of these options will change the way the clock is displayed.

Equalizer, Balance And Fade

To set the Bass, Mid Range, Treble, Balance or Fade settings push the AUDIO button to access the Audio sub-menu.

The Audio sub-menu can also be reached by pushing the MENU button until AUDIO appears in the display. Push the ENTER/BROWSE button to select the AUDIO menu and use the TUNE/SCROLL knob to highlight select Bass, Mid Range, T reble, Balance or Fade. Once the desired selection is highlighted, push the ENTER/BROWSE button to select the item and use the TUNE/SCROLL knob to adjust the setting.

Radio Operation

RADIO Button

Push the button to select either AM, FM or SiriusXM mode.

Seek Up/Down Buttons

Push the up or down button to seek through radio stations in AM, FM, or SXM bands.

Hold either button to bypass stations without stopping.

Buttons 1 - 5

These buttons tune the radio to the stations that you commit to pushbutton memory AM (A, B, C), FM (A, B, C) and SXM (A, B, C) — 15 AM, 15 FM and 15 SXM stations.

Page 62

ELECTRONICS

Store Radio Presets Manually

To store a radio preset manually, follow the steps below:

1. T une to the desired station.

2. Push and hold the button (1–5) you wish to lock onto this station for three seconds.

You may add a second or third station to each pushbutton by repeating the above procedure with this exception: Push the “A–B–C” button to select the A, B or C mode. Each button can be set for up to three stations in both AM and FM. This allows a total of 15 AM, 15 FM and 15 SXM stations to be stored into push-button memory .

INFO Button

Push the INFO button for an RDS station (one with call letters displayed). The radio will return a Radio T ext message broadcast from an FM station (FM mode only).

PLAYER Button

Pushing the “Player” button will allow you to switch from AM/FM/SXM modes to Player mode (AUX/CD/Bluetooth Steaming (BT)/USB).

MENU Button

Pushing the MENU button allows you to scroll between the setting sub-menus. Once the desired sub-menu setting is highlighted push the TUNE/SCROLL knob to select the setting. The following items are selectable:

Radio Mode

• Audio — Selecting the Audio sub-menu will allow you to adjust the Bass, Mid Range,

Treble, Balance or Fade, just like pushing the AUDIO hard control. If the BACK button is pushed the radio will return to the Main Menu.

• Clock — Selecting Clock will allow you to set the clock. Adjust the hours by turning the

TUNE/SCROLL control knob. After adjusting the hours, push the ENTER/BROWSE button to set the minutes. The minutes will highlight. Adjust the minutes using the right side TUNE/SCROLL control knob. Press the ENTER/BROWSE button to save time change.

Player Mode

• Player Browse — Selecting Player Browse will go to the appropriate browse menu

depending on the device currently playing (will function the same as pushing the browse button while in that mode). This will only appear in the menu if the device currently playing can support these features.

• Shuffle (SHFL) — This function shuffles (randomizes the order of the files). This will

only appear in the menu if the device currently playing can support these features.

Page 63

ELECTRONICS

• Repeat (RPT) — When Repeat is activated, the currently playing song will begin again

when it ends. It will continue to cycle through the same song until repeat is turned Off. Repeat will be turned off once one for the following conditions are met: 1) The source is ejected 2) A different track list within that source is initiated 3) The REPEAT button is toggled OFF. This will only appear in the menu if the device currently playing can support these features.

• Audio — Selecting the Audio sub-menu will allow you to adjust the Bass, Mid Range,

Treble, Balance or Fade, just like pushing the AUDIO hard control. If the BACK button is pushed the radio will return to the Main Menu.

• Clock — Selecting Clock will allow you to set the clock. Adjust the hours by turning the

right-side TUNE/SCROLL control knob. After adjusting the hours, push the ENTER/ BROWSE button to set the minutes. The minutes will highlight. Adjust the minutes using the right side TUNE/SCROLL control knob. Push the ENTER/BROWSE button to save time change.

System Info

Selecting System Info will display the software version, serial number and SIRIUS ID.

SiriusXM Satellite Radio

SiriusXM Satellite Radio gives you over 130 channels, including 100% commercial-free music from nearly every genre, plus all your favorite sports, news, talk and entertainment channels–all with crystal clear, coast-to-coast coverage, all in one place and all at your fingertips.

To access SiriusXM Satellite Radio, push the RADIO button.

• If you decide to continue your service at the end of your trial subscription, the plan you

choose will automatically renew and bill at then-current rates until you call SiriusXM at 1-866-635-2349 to cancel. Canadian residents call 1-888-539-7474. See

SiriusXM Customer Agreement for complete terms at www.siriusxm.com. For Canadian residents www.siriusxm.ca. All fees and programming subject to change. Our satellite service is available only to those at least 18 and older in the 48 contiguous USA and D.C. Our Sirius satellite service is also available in PR (with coverage limitations). Our Internet radio service is available throughout our satellite service area and in AK and HI. © 2015 Sirius XM Radio Inc. Sirius, XM and all related marks and logos are trademarks of Sirius XM Radio Inc.

CD/DISC Operation — If Equipped

This radio is capable of playing compact discs (CD), recordable compact discs (CD-R), re writable compact discs (CD-RW), compact discs with MP3 tracks and multi session compact discs with CD, MP3 and WMA tracks.

Seek Up/Down Buttons

• Push to seek through CD tracks.

• Hold either button to bypass tracks without stopping.

Page 64

ELECTRONICS

Audio Jack Operation

The Audio Jack allows a portable device, such as an MP3 player or an iPod to be plugged into the center console and utilize the vehicle’s audio system, using a 3.5 mm stereo audio cable, to amplify the source and play through the vehicle speakers.

Pushing the PLA YER button will change the mode to auxiliary device if the Audio Jack is connected, allowing the music from your portable device to play through the vehicle's speakers.

The functions of the portable device are controlled using the device buttons. The volume may be controlled using the radio or portable device.

USB Port

Connect your iPod/MP3 or compatible device using a USB cable into the USB Port. USB Memory sticks with audio files can also be used. Then, audio from the device can be played on the vehicles sound system while providing metadata (artist, track title, album, etc.) information on the radio display .

1 — USB Port and AUX Jack 2 — Audio Cable Access

USB/Audio Jack

Pushing the PLAYER button will change the device mode between connected auxiliary devices.

When connected, the MP3 Player/compatible USB device can be controlled using the radio or Steering Wheel Audio Controls or Voice Commands to play, skip to the next or previous track, browse, and list the contents.

The MP3/WMA Player battery charges when plugged into the USB port (if supported by the specific device).

To route the audio cable out of the center console, use the access cut out on the right side of the console.

NOTE:

• Your vehicle cannot be equipped with the USB Port without having the available Uconnect Voice Command feature.

• When connecting your MP3/WMA Player device for the first time, the system may take several minutes to read your music, depending on the number of files. For example, the system will take approximately five minutes for every 1,000 songs loaded on the device. However, music on the device will play while reading continues in the background. Also during the reading process, the Shuffle and Browse functions will be

Page 65

ELECTRONICS

disabled. This process is needed to ensure the full use of your MP3/WMA Player features and only happens the first time it is connected. After the first time, the reading process of your iPod will take considerably less time unless changes are made or new songs are added to the playlist.

• The USB port supports certain Mini, Classic, Nano, T ouch, and iPhone devices. The USB port also supports playing music from compatible external USB Mass Storage Class memory devices. Some iPod software versions may not fully support the USB port features. Please visit Apple’s website for iPod software updates.

Uconnect Phone — Bluetooth Hands Free Calling — If Equipped

The Uconnect Phone is a voice-activated, hands-free, in-vehicle communications system with Voice Command Capability (see Voice Command section).

The Uconnect Phone allows you to dial a phone number with your mobile phone using simple voice commands.

Refer to your vehicle Owner's Manual on the DVD for further details.

NOTE:

•

The Uconnect Phone requires a mobile phone equipped with the Bluetooth Hands-Free

Profile, Version 1.0 or higher. For Uconnect customer support, call 1-877-855-8400 or

UconnectPhone.com. Canadian Residents: call 1-800-465–2001 (English) or

visit 1-800-387-9983 (French) or visit UconnectPhone.com.

• Prior to starting the pairing procedure, ensure all additional Bluetooth devices or phones within the vehicle have their Bluetooth disabled.

Phone Pairing

To use the Uconnect Phone feature, you must first pair your Bluetooth phone with the Uconnect system.

Start Pairing Procedure

1. Push the “Phone” button to begin.

2. Wait for the “ready” prompt and BEEP.

3. After the BEEP, say “Setup Phone Pairing”.

4. After the BEEP, say “Pair a Phone”.

5. Follow the audible prompts.

6. You will then be asked if paired device should be set to favorite.

Device

Uconnect Phone will say “Start pairing procedure on device.”

Search for available devices on your Bluetooth enabled mobile phone. This is usually within Settings or Options under “Bluetooth.” See your mobile phone’s manual for details.

Page 66

ELECTRONICS

NOTE:

For assistance in pairing your phone, contact Uconnect customer support at 1-877-855-8400 or visit Canadian Residents: call 1-800-465-2001 (English) or 1-800-387-9983 (French) or visit UconnectPhone.com.

When your phone finds the system, select “Uconnect” as the paired device.

Complete The Pairing Procedure

When prompted on the phone, enter the 4-digit PIN number shown on the radio display.

If your phone asks you to accept a connection request from Uconnect, select “Yes”. If available, check the box telling it not to ask again – that way your phone will automatically connect each time you start the vehicle.

Phonebook Download — Automatic Phonebook Transfer From Mobile Phone

If equipped and specifically supported by your phone, Uconnect Phone automatically downloads names (text names) and number entries from your mobile phone’ s phonebook. Specific Bluetooth Phones with Phone Book Access Profile may support this feature. See UconnectPhone.com for supported phones.

UconnectPhone.com for phone compatibility, pairing instructions and details.

Automatic download and update, if supported, begins as soon as the Bluetooth wireless phone connection is made to the Uconnect Phone, for example, after you start the vehicle.

NOTE:

You may be asked for permission to initiate the phonebook download.

• A maximum of 1,000 entries per phone will be downloaded and updated every time a phone is connected to the Uconnect Phone.

• Depending on the maximum number of entries downloaded, there may be a short delay before the latest downloaded names can be used. Until then, if available, the previously downloaded phonebook is available for use.

• Only the phonebook of the currently connected mobile phone is accessible.

• Only the mobile phone’ s phonebook is downloaded. SIM card phonebook is not part of the Mobile phonebook.

• This downloaded phonebook cannot be edited or deleted on the Uconnect Phone. These can only be edited on the mobile phone. The changes are transferred and updated to Uconnect Phone on the next phone connection.

Making A Phone Call

• Push the “Phone” button .

• After the BEEP, say “dial” (or “call” a name).

Receiving A Call — Accept (And End)

•

When an incoming call rings/is announced on Uconnect, push the “Phone” button .

• To end a call, push the “Phone” button .

Page 67

ELECTRONICS

Mute (Or Unmute) Microphone During Call

• During a call, push the “Voice Command” button .

• After the BEEP, say “mute” (or “mute off”).

Transfer Ongoing Call Between Handset And Vehicle

• During a call, push the “Voice Command” button .

• After the BEEP, say “transfer call”.

Changing The Volume

• Start a dialogue by pushing the “Phone” button , then adjust the volume during a normal call.

• Use the radio ON/OFF VOLUME rotary knob to adjust the volume to a comfortable level while the Uconnect system is speaking. Please note the volume setting for Uconnect is different than the audio system.

Uconnect Voice Command

The Uconnect Voice Command system allows you to control your AM, FM radio, satellite radio, disc player, Uconnect Phone and supported portable media devices.

When you push the “Voice Command” button will hear a beep. The beep is your signal to give a command. If you do not say a command within a few seconds, the system will present you with a list of options. If you ever wish to interrupt the system while it lists options, push the “Voice Command” button listen for the BEEP, and say your command.

located on the steering wheel, you

Voice Command Operation

Start a dialogue by pushing the “Voice Command” button , you will hear a beep. The beep is your signal to give a command. Below are a list of voice commands for each of the different modes.

Page 68

ELECTRONICS

Common Voice Commands (Examples)

While In: Voice Command Example:

“Radio AM” (to switch to the radio mode) “Radio FM” (to switch to the radio mode) “Satellite Radio” (to switch to the radio mode)

Main Menu

Radio AM, Radio FM Modes

SiriusXM Satellite Radio Mode

Disc Mode

USB Mode

Bluetooth Streaming (BT) Mode

“Disc” (to switch to the disc mode) “USB” (to switch to the USB mode) “Bluetooth Streaming” (to switch to the Bluetooth mode) “Memo” (to switch to the memo recorder) “System Setup” (to switch to system setup)

“Frequency” (to change the frequency) “Next Station” (to select the next station) “Previous Station” (to select the previous station) “Radio Menu” (to switch to the radio menu) “Main Menu” (to switch to the main menu)

“Channel Number” (to change the channel by its spoken number) “Next Channel” (to select the next channel) “Previous Channel” (to select the previous channel) “List Channel” (to hear a list of available channels) “Channel Name” (to change the channel by its spoken name) “Radio Menu” (to switch to the radio menu) “Main Menu” (to switch to the main menu)

“Track” (#) (to change the track) “Next T rack” (to play the next track) “Previous T rack” (to play the previous track) “Main Menu” (to switch to the main menu)

“Next T rack” (to play the next track) “Previous T rack” (to play the previous track) “Play” (to play a Artist Name, Playlist Name, Album Name, Track Name, etc.) “List” (to List a Artist, Playlist, Album, Track, etc.)

“Next T rack” (to play the next track) “Previous T rack” (to play the previous track)

Page 69

ELECTRONICS

While In: Voice Command Example:

To switch to the voice recorder mode, say “Memo”. The following are common voice commands for this mode: “New Memo” (to record a new memo) — During the recording, you may push the Voice Command button

to stop recording. You proceed by

saying one of the following commands:

•

“Save” (to save the memo)

• “Continue” (to continue recording)

Memo Mode

• “Delete” (to delete the recording)

• “Play Memos” (to play previously recorded memos) — During the playback you may push the Voice Command button

to stop playing memos. You proceed by saying one of the following commands:

• “Repeat” (to repeat a memo)

• “Next” (to play the next memo)

• “Previous” (to play the previous memo)

• “Delete” (to delete a memo)

• “Delete All” (to delete all memos)

NOTE:

Refer to your vehicle Owner's Manual on the DVD for further details on Voice Command.

Voice Text Reply

If equipped with Uconnect Voice Command, your radio may be able to play incoming Voice Text Reply messages (text messages) through the vehicle's sound system.

It also allows you to respond by selecting from various pre-defined phrases.

Not all phones are compatible with this feature. Refer to the phone compatibility list at UconnectPhone.com. Connected mobile phones must be Bluetooth-compatible, and paired with your radio.

Push the “Voice Command” button

and after the BEEP, say “SMS” to get started.

NOTE:

To access the tutorial, push the “Voice Command” button

. After the BEEP, say “tutorial.” Push any button on the faceplate or button on the touchscreen to cancel the tutorial.

Page 70

ELECTRONICS

WARNING!

• Any voice commanded system should be used only in safe driving conditions following applicable laws regarding phone use. Your attention should be focused on safely operating the vehicle. Failure to do so may result in a collision causing you and others to be severely injured or killed.

• In an emergency , to use Uconnect Phone, your mobile phone must be:

• turned on

• paired to Uconnect Phone

• have network coverage

UCONNECT 8.4 & 8.4N

NOTE:

• Uconnect models 8.4 and 8.4N have an 8.4 inch touch screen.

• Model 8.4N has all Model 8.4 features, plus Garmin Navigation and SiriusXM T ravel Link (5-year trial subscription included).

• Model 8.4N is identified by the unique Nav button on the main screen menu bar, and the presence of T ravel Link within the More menu.

Uconnect 8.4N

Page 71

Uconnect 8.4 & 8.4N AT A GLANCE

ELECTRONICS

Uconnect 8.4N

1 — Status Bar 2 — Small Navigation Map (8.4N) 3 — More Settings Button 4 — Uconnect Phone Button 5 — Garmin Navigation Button (8.4N)

6 — Climate Control Button 7 — Controls Button 8 — Player Button 9 — Radio Button

Page 72

ELECTRONICS

Anti-Theft Protection

Displaying The Time

If the time is not currently displayed on the radio or player main page, press the “More” button on the touchscreen and then press the “Settings” button on the touchscreen. In the Settings list, press the “Clock” button on the touchscreen then press the check box next to Show T ime in Status Bar.

Setting The Time

Model 8.4N synchronizes time automatically via GPS, so should not require any time adjustment. If you do need to set the time manually , follow the instructions below for Model 8.4.

For Model 8.4, turn the unit on, then press the “Time Display” at the top of the screen. Press “Yes.”

If the time is not displayed at the top of the screen, press the “More” button on the touchscreen and then the “Settings” button on the touchscreen. In the Settings screen, press the “Clock” button on the touchscreen, then check or uncheck this option.

Press “+” or “–” next to Set Time Hours and Set Time Minutes to adjust the time.

If these features are not available, uncheck the Sync with GPS box.

Press “X” to save your settings and exit out of the Clock Setting screen.

Audio Settings

Press the “Audio” button on the touchscreen to activate the Audio settings screen to adjust Balance\Fade, Equalizer and Speed Adjusted Volume.

You can return to the Radio screen by touching the “X” located at the top right.

Balance/Fade

Press the “Balance/Fade” button on the touchscreen to Balance audio between the front speakers or fade the audio between the rear and front speakers.

Touching the “Front,” “Rear,” “Left” or “Right” buttons on the touchscreen or press and drag the red Speaker Icon to adjust the Balance/Fade.

Page 73

ELECTRONICS

Equalizer

Press the “Equalizer” button on the touchscreen to activate the Equalizer screen.

Press the “+” or “–” buttons on the touchscreen, or by touching and dragging over the level bar for each of the equalizer bands. The level value, which spans between ±9, is displayed at the bottom of each of the Bands.

Speed Adjusted Volume

Press the “Speed Adjusted Volume” button on the touchscreen to activate the Speed Adjusted Volume screen. The Speed Adjusted Volume is adjusted by touching the “+” and “–” buttons or by touching and dragging over the level bar. This alters the automatic adjustment of the audio volume with variation to vehicle speed.

Remote CD/Disc Player — If Equipped

The CD/Disc Player is located inside the center console.

With the printed side facing the rear of the vehicle, insert the disc into the disc slot inside the center console. The radio pulls the disc in automatically . The radio selects the appropriate mode after the disc is recognized, and starts playing the first track.

Remote CD/Disc Player

1 — USB Port 2 — Power Outlet 3 — Audio/AUX Jack 4 — CD/Disc Slot

Page 74

ELECTRONICS

Radio Operation

Uconnect 8.4 Radio

1 — Radio Station Presets 2 — Toggle Presets 1–6 and 7–12 3 — Audio Settings Button 4 — Seek Up Button

To access the Radio mode, press the “Radio” button at the lower left of the touchscreen.

5 — Direct T une To A Radio Station 6 — Seek Down Button 7 — Browse And Manage Stations 8 — Radio Band Buttons

Selecting Radio Stations

Press the desired radio band (AM, FM or SA T) button on the touchscreen.

Seek Up/Seek Down

Press the “Seek” arrow up or down buttons on the touchscreen for less than two seconds to seek through radio stations.

Press and hold either “arrow” button on the touchscreen for more than two seconds to bypass stations without stopping. Once the “arrow” button on the touchscreen is released, the radio will stop at the next available frequency .

Direct Tune

Tune directly to a radio station by pressing the “T une” button on the screen, and entering the desired station number.

Page 75

ELECTRONICS

Store Radio Presets

Your radio can store 12 total preset stations. They are shown at the top of your screen. To see all 12 stations, press the arrow button at the top right of the touchscreen to toggle between the six presets.

To store a radio preset manually, follow the steps below:

1. T une to the desired station.

2. Press and hold the desired numbered button on the touchscreen for more than two seconds or until the preset button becomes highlighted red and you hear a confirmation beep.

SiriusXM SATELLITE RADIO

SiriusXM Satellite Radio gives you over 130 channels, including 100% commercialfree music from nearly every genre, plus all your favorite sports, news, talk and entertainment channels – all with crystal clear, coast-to-coast coverage, all in one place and all at your fingertips.

To access SiriusXM Satellite Radio, press the “SAT” button on the main Radio touchscreen.

There are Voice Commands available while in this mode. Refer to the Uconnect Voice Command section in this guide.

The following describes features that are available when in SiriusXM Satellite Radio mode.

SiriusXM Satellite Radio

Selecting SiriusXM Satellite Channels

Seek Up/Seek Down

Press the “Seek” arrow buttons on the touchscreen for less than two seconds to seek through channels in SA T mode.

Press and hold either “arrow” button on the touchscreen for more than two seconds to bypass channels without stopping. The radio will stop at the next listenable channel once the “arrow” button on the touchscreen is released.

Direct Tune

Tune directly to a SAT channel by pressing the “Tune” button on the screen, and entering the desired station number.

Page 76

ELECTRONICS

Jump

Automatically tells you when Traffic & Weather for a favorite city is available, and gives you the option to switch to that channel. Press “Jump” to activate the feature. After listening to T raffic and Weather , press “Jump” again to return to the previous channel.

Fav

Activates the favorites menu. You can add up to 50 favorite artists or songs. Just press “Add Fav Artist” or “Add Fav Song” while the song is playing. Y ou will then be alerted any time one of these songs, or works by these artists, is playing on other SiriusXM channels.

SiriusXM Parental Controls

You can skip or hide certain channels from view if you do not want access to them. Press the “More” button on the touchscreen, then the “Settings” button on the touchscreen, next press the “SIRIUS Setup” button on the touchscreen, then select “Channel Skip.” Press the box, check-mark, next to the channel you want skipped. They will not show up in normal usage.

SiriusXM also offers the option to permanently block selected channels. Call (1-888-601-6297 for U.S. customers, 1-877-438-9677 for Canadian customers) and request the Family Package.

Browse

Lets you browse the SiriusXM channel listing, Favorites, Genres, Game Zone, and Weather channels. Jump setting, and also provides the SiriusXM channel list. Browse contains many sub-menus.

Browse Sub-Menu

All Shows the channel listing. Genre Provides a list of all genres, and lets you jump to a channel within the

Presets Lets you scroll the list of Preset satellite channels. Touch the channel, or

Favorites Lets you manage artists and songs in the Favorites list and configure Alert

Game Zone Provides alerts when your favorite sports teams are starting a game which

Jump Lets you select your favorite cities for Traffic & Weather information, which

Sub-Menu Description

selected genre.

press Enter on the T une knob, to go to that channel. Touch the trash can icon to delete a preset. Your presets are also shown at the top of the main Satellite Radio screen.

Settings to let you know when favorite songs or artists are playing on other channels). Also, view a list of channels airing any of your Favorites.

is being aired on other SiriusXM channels, or when their game score is announced. You can select and manage your Teams list here, and configure alerts.

is used by the Jump feature on the main satellite radio screen.

Page 77

ELECTRONICS

Replay

Lets you replay up to 44 minutes of the content on the current SiriusXM channel.

NOTE:

• You must be actively listening to the same station consistently for 44 minutes without

changing stations.

• If you change to a different channel, you will lose the saved content.

Replay Option Option Description

Play/Pause Touch to Pause content playback. Touch Pause/Play again to resume

playback.

Rewind/RW Rewinds the channel content in steps of five seconds. Touch and hold to

rewind continuously , then release to begin playing content at that point.

Fast Forward/FW

Replay T ime Displays the amount of time in the upper center of the screen by which

Live Resumes playback of Live content at any time while replaying rewound

Forwards the content, and works similarly to Rewind/RW. However, Fast Forward/FW can only be used when content has been previously rewound.

your content lags the Live channel.

content.

Page 78

ELECTRONICS

MP3 Player/USB/CD/Audio Jack/Bluetooth Operation

MP3 Player/USB/CD/Audio Jack/Bluetooth Touchscreen

1 — Music Source Button 4 — Info Button 2 — Repeat T rack Button 5 — Music T rack Button 3 — Shuffle Button 6 — Browse Button

Selecting The Source

The MP3 Player/USB, CD, Audio Jack, or Bluetooth source is accessed by pressing the “Player” button on the touchscreeen to enter the Player main screen, then press the “Source” button on the touchscreen and choose between Disc, Aux, MP3 Player or Bluetooth.

NOTE:

Uconnect will automatically switch to the appropriate mode when something is first connected or inserted into the system.

Source Selection

Page 79

USB Port

• Connect your MP3 Player or compatible

device using a USB cable into the USB Port. USB Memory sticks with audio files can also be used. Then, audio from the device can be played on the vehicles sound system while providing metadata (artist, track title, album, etc.) information on the radio display.

• When connected, the MP3 Player/

compatible USB device can be controlled using the radio or Steering Wheel Audio Controls to play, skip to the next or previous track, browse, and list the contents.

ELECTRONICS

• The MP3 Player battery charges when

plugged into the USB port (if supported by the specific device).

• To route the audio cable out of the center

console, use the access cut out on the right side of the console.

NOTE:

When connecting your MP3 Player device for the first time, the system may take several minutes to read your music, depending on the number of files. For example, the system will take approximately five minutes for every 1,000 songs loaded on the device. Also during the reading process, the Shuffle and Browse functions will be disabled. This process is needed to ensure the full use of your MP3 Player features and only happens the first time it is connected. After the first time, the reading process of your MP3 Player will take considerably less time unless changes are made or new songs are added to the playlist.

USB Port

1 — USB Port 2 — Power Outlet 3 — Audio/AUX Jack 4 — CD/Disc Slot

USB/MP3/Audio Cable Access

• The USB port supports certain Mini, Classic, Nano, T ouch, and iPhone devices. The

USB port also supports playing music from compatible external USB Mass Storage Class memory devices. Some iPod software versions may not fully support the USB port features. Please visit Apple’s website for iPod software updates.

Page 80

ELECTRONICS

Audio Jack

The Audio Jack allows a portable device, such as an MP3 player or an iPod to be plugged into the radio and utilize the vehicle’s sound system, using a standard 3.5 mm audio cable, to amplify the source and play through the vehicle speakers.

Press the “Player” button on the touchscreen on the then choose AUX source will change the mode to auxiliary device if the Audio Jack is connected, allowing the music from your portable device to be heard through the vehicle's speakers.

The functions of the portable device are controlled using the device controls. The volume may be controlled using the radio or portable device.

To route the audio cable out of the center console, use the access cut out on the right side of the console.

Remote CD/Disc Player — If Equipped

The CD/Disc Player is located inside the center console.

With the printed side facing the rear of the car, lift up the protective door and insert the disc into the disc slot. The radio pulls the disc in automatically. The radio selects the appropriate mode after the disc is recognized, and starts playing the first track.

The CD/Disc can also be selected by pressing the “Player” button on the touchscreen, then press the “Source” button on the touchscreen and then press the “Disc” button on the touchscreen.

NOTE:

• Depending on the CD/Disc being used, you will only be able to browse by folder.

• There are Voice Commands available while in this mode. Refer to the Uconnect Voice Command section in this guide.

Page 81

ELECTRONICS

Bluetooth® Streaming Audio

• If equipped with Uconnect®Voice Command, your Bluetooth-equipped MP3 Player devices, cell phones or other media players, may also be able to stream music to your vehicle's sound system. Your connected device must be Bluetooth-compatible, and

paired with your Uconnect www.UconnectPhone.com for pairing instructions). You can access the music from

your connected Bluetooth mode.

device by touching the Source soft-key while in Player

Garmin Navigation (8.4N Only)

Uconnect 8.4N integrates Garmin’s consumer-friendly navigation into your vehicle. Garmin Navigation includes Lane Assist and Junction View , Speed Limit information, and a database with over six million points of interest.

• Press the “Nav” button on the touchscreen in the menu bar to access the Navigation system.

Changing The Navigation Voice Prompt Volume

system (see Uconnect®Phone section or

1. Program a destination.

2. While traveling on your route, press the upper left area of the map screen where your

next turn is displayed.

3. The Navigation system will then repeat the distance to your next turn.

4. While the Navigation system is speaking, use the ON/OFF VOLUME rotary knob to

adjust the volume to a comfortable level. Please note the volume setting for Navigation Voice Prompt is different than the audio system.

Page 82

ELECTRONICS

Main Navigation Menu

Main Navigation Menu Touchscreen

1 — Where T o? Button 2 — View Map Button 3 — Settings Button

Acquiring Satellites

The GPS Satellite strength bars indicate the strength of your satellite reception.

Acquiring satellite signals can take a few minutes. When at least one of the bars is green, your device has acquired satellite signals. If no signal is found the Navigation system still can operate with internal gyro direction & location based on data provided by the vehicle.

Sensor Assisted GPS technology uses the speed sensors attached to your vehicle’s drivetrain and a gyroscope to supplement the existing GPS data. The combined data provides accurate positioning for your vehicle in tunnels, indoor parking garages, urban canyons, and any other area where GPS signals can become obstructed.

4 — Tools Button 5 — Detour Button 6 — Stop Button

Page 83

Finding Points Of Interest

1. From the main Navigation menu press

the “Where To?” button on the touchscreen, then press “Points of Interest.”

2. Select a Category and then a subcat-

egory , if necessary .

3. Select your destination and press “Go.”

Finding A Place By Spelling The Name

1. From the Main Navigation Menu press

the “Where To?” button on the touchscreen, press “Points of Interest”, then press “Spell Name.”

2. Enter the name of your destination.

3. Press “Done.”

ELECTRONICS

Finding Points Of Interest

4. Select your destination and press “Go.”

Entering A Destination Address

1. From the main Navigation menu press the “Where To?” button on the touchscreen,

then press “Address.”

2. Follow the on-screen prompts to enter the address and press “Go.”

Searching Near Another Location

1. From the main Navigation menu press the “Where To?” button on the touchscreen,

press a destination, then press “Near.”

2. Select an option from the available choices.

Setting Or Changing Your Home Location

1. Press the “NAV” button on the touchscreen in the menu bar to access the Navigation

system and the Main Navigation menu.

2. Press the “Where To?” button on the touchscreen, then press “Go Home.”

3. You may enter your address directly, use your current location as your home address,

or choose from recently found locations.

4. T o edit your Home location (or other saved locations), press the “Where To?” button on

the touchscreen from the Main Navigation menu, press “Favorites,” then press the location you want to edit. After selecting a location to edit, press “Press for More,” then “Edit.”

Page 84

ELECTRONICS

Go Home

A Home location must be saved in the system. From the Main Navigation menu press the “Where T o?” button on the touchscreen, then press “Go Home.”

Searching By Phone Number

1. From the main Navigation menu press the “Where To?” button on the touchscreen, press the “down” arrow to display the secondary selections, then press “Phone Number.”

2. Enter the desired Phone Number and follow the prompts.

Searching By Phone Number

Secondary Search Selections

From the main Navigation menu press the “Where T o?” button on the touchscreen, then press the “down” arrow to display the secondary search selections.

Selection Selection Description

Extras Visit http://www.garmin.com/us/extras to add

more content to your device with purchasable and free downloads.

Cities Select a City within the current state to route

to that specific City Center.

Routes Let’s you create and save your own routes with

your own destinations or points of interests.

Browse Maps Let’s you browse and select destinations from

the Map.

Coordinates Enter destination using its Geographical co-

ordinates instead of an address.

Page 85

Following Your Route

ELECTRONICS

Following Your Route

1 — Distance T o Next Turn 2 — Current Location 3 — Zoom In Button 4 — Zoom Out Button 5 — Current Speed

Your route is marked with a magenta line on the map. If you depart from the original route, your route is recalculated. A speed limit icon could appear as you travel on major roadways.

Lane Assist helps you decide which lane to be in at upcoming junctions.

Junction View gives you an expanded view as junctions approach.

6 — Press And Drag Map 7 — Your Location On The Map 8 — Estimated T ime Arrival 9 — Return Button

Page 86

ELECTRONICS

Adding A Via Point

To add a via point you must be navigating a route.

1. Press the “back” arrow to return to the Main Navigation menu.

2. Press the “Where To?” button on the touchscreen, then search for a destination. Select the desired destination to add from the search results.

3. Press “Go,” then press “Add as a Via Point.”

Taking A Detour

To take a detour you must be navigating a route.

• Press “Detour.”

NOTE:

If the route you are currently taking is the only reasonable option, the device might not calculate a detour.

Traffic

When you are receiving traffic information, a traffic icon appears on the map.

The traffic icon changes color to indicate the severity of the traffic conditions on your route or on the road you are currently traveling.

Traffic Icon

Color Description Meaning

Green Low severity Traffic is flowing normally Yellow Medium severity Traffic is slightly congested Red High severity Traffic is heavily congested or

stopped

Gray No data Traffic data has not updated

Page 87

Manually Avoid Traffic On Your Route

1. While navigating a route, press the traffic icon.

2. Press “Traffic On Route.”

3. If necessary, press the arrows to view other traffic delays on your route.

4. Press the desired delay and press “Avoid.”

View The Traffic Map

ELECTRONICS

The traffic map shows color-coded traffic flow and delays on nearby roads.

1. From the map, press the “traffic icon.”

2. Press “Traffic Map” to view the traffic incidents on a map.

Search For Traffic Delays

1. From the map, press the “traffic icon.”

2. Press “T raffic Search” to view a list of traffic delays.

3. Press an item in the list to view delays on the road.

4. If there is more than one delay, press the “arrows” to view additional delays.

Traffic Touchscreen

Traffic Search

Page 88

ELECTRONICS

SiriusXM TRAVEL LINK (8.4N ONLY)

SiriusXM Travel Link brings a wealth of useful information into your vehicle and right to your fingertips.

To access Travel Link, press the “More” button on the touchscreen, then the “Travel Link” button on the touchscreen.

• SiriusXM T ravel Link requires a subscription, sold separately after the 5 year trial subscription included with your vehicle purchase.

• SiriusXM Travel Link is only available in the United States.

1 – Fuel Prices

2 – Movie Listings

3 – Sports Scores 4 – SIRIUS 5 – My Favorites

6 – Weather

View detailed price information for fuel stations near your current location.

View information on movies that are playing at theaters near your current location.

View scores and upcoming events for all major sports. View subscription information. View and store your favorite location, theater and sport teams for

quick access. View detailed weather conditions, forecasts and ski/snowboarding

conditions at local resorts.

Page 89

ELECTRONICS

Uconnect Phone (Bluetooth HANDS FREE CALLING)

If the Uconnect Phone Button exists on your steering wheel, then you have the Uconnect Phone features.

The Uconnect Phone is a voice-activated, hands-free, in-vehicle communications system with Voice Command Capability (see Voice Command section).

The Uconnect Phone allows you to dial a phone number stored in your mobile phone by using simple voice commands or using buttons on the touchscreen.

Refer to the “Understand The Features Of Your Vehicle” section of your vehicle's Owner's Manual on the DVD for further details.

NOTE:

The Uconnect Phone requires a mobile phone equipped with the Bluetooth Hands-Free Profile, Version 1.0 or higher. For Uconnect customer support, call 1-877-855-8400 or visit UconnectPhone.com. Canadian Residents: call 1-800-465-2001 (English) or 1-800-387-9983 (French) or visit UconnectPhone.com.

Pairing A Phone

To use the Uconnect Phone feature, you must first pair your Bluetooth phone with the Uconnect system.

NOTE:

For Voice Command enabled phone pairing, refer to your vehicles Owner's Manual for details.

Start Pairing Procedure On The Radio

Press the “Phone” button on the touchscreen and then the “Settings” button on the touchscreen. Next, press “Add Device.”

Uconnect Phone will display an “In progress” screen while the system is connecting.

Phone Pairing

Page 90

ELECTRONICS

Start Pairing Procedure On Mobile Phone

Search for available devices on your Bluetooth enabled mobile phone. This is usually within Settings or Options under “Bluetooth.” See your mobile phone’s manual for details.

NOTE:

For assistance in pairing your phone, contact Uconnect customer support at 1-877-855-8400 or visit 1-800-387-9983 (French) or visit UconnectPhone.com.

Complete The Pairing Procedure

When prompted on the phone, enter the 4-digit PIN number shown on the Uconnect Screen.

If your phone asks you to accept a connection request from Uconnect, select “Yes.” If available, check the box telling it not to ask again – that way your phone will automatically connect each time you start the vehicle.

UconnectPhone.com. Canadian Residents: call 1-800-465-2001 (English) or

Select The Mobile Phone's Priority Level

When the pairing process has successfully completed, the system will prompt you to choose whether or not this is your favorite phone. Selecting “Yes” will make this phone the highest priority. This phone will take precedence over other paired phones within range. Only one phone can be connected at a time.

You are now ready to make hands-free calls. Press the “Uconnect Phone” button on your steering wheel to begin.

Bluetooth Pairing Device Name And PIN

1 — Vehicle Device Name — Uconnect 2 — Uconnect Bluetooth Pairing PIN Number

Page 91

Phone Menu Screen

ELECTRONICS

Uconnect Phone Menu Touchscreen

1 — Favorite Phonebook Entries 2 — Phone Battery Level 3 — Current Phone 4 — Phone Signal Strength 5 — Mute Microphone 6 — Transfer Radio/Phone 7 — Conference Call 8 — Manage Paired Mobile Phones

9 — SMS (T ext Messaging) 10 — Direct Dial 11 — Recent Call List 12 — Browse Phone Book Entries (Contains 911) 13 — End Call 14 — Call/Redial Last Number

Making A Phone Call

Push the “Uconnect Phone” button

After the BEEP, say “dial” then the number. Or, (After the BEEP) say “call” then the name as listed in your phone; see Phonebook below.

NOTE:

You can also initiate a call by using the touchscreen on the Phone main screen.

on the steering wheel.

Page 92

ELECTRONICS

Receiving A Call — Accept (And End)

When an incoming call rings/is announced on Uconnect, push the “Phone” button .

To end a call, push the Phone button

Mute (Or Unmute) Microphone During Call

During a call, press the “Mute” button on the Phone main touchscreen to mute and unmute the call.

Transfer Ongoing Call Between Handset And Vehicle

During an on-going call, press the “Transfer” button on the touchscreen to transfer an on-going call between handset and vehicle.

Common Phone Commands (Examples)

“Call John Smith” “Show Missed Calls” “Call John Smith mobile” “Show Recent Calls” “Dial 1 248 555 12XX” “Show My Contacts” “Call Emergency” “Redial” “Call T owing Assistance” “Call Back” “Redial” “Send 1234#” (only available while call is

active)

“Search for John Smith”

Phonebook

Uconnect radios will automatically download your contact list from your paired phone, if this feature is supported by your phone. Entries are updated each time that the phone is paired. If your contact list entries do not appear, check the settings on your phone. Some phones require you to enable this feature manually .

Your phonebook can be browsed on your radio screen, but editing can only be done on your phone. To browse, press the Phone button on the touchscreen, then the Phonebook button on the touchscreen.

Favorite phonebook entries can be saved as Favorites for quicker access. Favorites are shown at the top of your main phone screen.

Phonebook

Page 93

ELECTRONICS

Voice Command Tips

The Phone button is for placing calls, or responding to texts, or Phone controls.

The V oice Command modes, (FM, SATELLITE), or T uning to stations (95.5 or “Symphony Hall”).

Take care to speak into the Voice Command System as calmly and normally as possible. The ability of Voice Command to recognize user voice commands may be negatively affected by rapid speaking or a raised voice level.

Use longer names that are less easily mistaken for others. For examples, say “Call John Doe” instead of “Call John”.

You can “chain” commands together for faster results. Say “Call John Doe, mobile”, for example.

You can interrupt while the system is talking to you, enabling you to say your response without waiting. Just push the

button is for controlling Media, such as changing broadcast

button on the steering wheel to say your command.

Changing The Volume

Start a dialogue by pushing the “Phone” button , then say a command for example

- “Help”.

Use the radio ON/OFF VOLUME rotary knob to adjust the volume to a comfortable level while the Uconnect system is speaking. Please note the volume setting for Uconnect is different than the audio system.

NOTE:

To access help, push the “Uconnect Phone” “help.” T ouch the display or push either cancel the help session.

button on the steering wheel and say

or button and say “cancel” to

Voice Text Reply

Uconnect Phone can read or send new text messages on your mobile phone.

Your mobile phone must support Voice T ext Reply over Bluetooth in order to use this feature. If the Uconnect Phone determines your phone is not compatible with Voice Text Reply messaging over Bluetooth the “Messaging” button will be greyed out and the feature will not be available for use.

For mobile phone compatibility and pairing instructions, please visit

UconnectPhone.com.

Page 94

ELECTRONICS

Read Messages:

If you receive a new text message while your phone is connected to Uconnect Phone, an announcement will be made to notify you that you have a new text message. Once a message is received and viewed or listened to, you will have the following options:

• Send a Reply

• Forward

• Call

Send Messages Using Buttons On The Touchscreen:

With the vehicle in Park, you can send messages using Uconnect Phone. T o send a new message:

1. Press the “Phone” button on the touchscreen.

2. Press the “Messaging” button on the touchscreen then “New Message.”

3. Press one of the 18 preset messages and the person you wish to send the message to.

4. If multiple numbers are available for the contact select which number you would like

to have the message sent.

5. Press “Send” or “Cancel.”

Send Messages Using Voice Commands:

1. Push the “Uconnect Phone”

2. After the “Listening” prompt and the following beep, say “Send message to John

Smith mobile.”

3. After the system prompts you for what message you want to send, say the message you

wish to send or say “List.” There are 18 preset messages.

While the list of defined messages are being read, you can interrupt the system by pushing the

After the system confirms that you want to send your message to John Smith, your message will be sent.

button and saying the message you want to send.

button.

Page 95

ELECTRONICS

List Of Preset Messages

Yes. I will be <number> minutes late. No. See you in <number> minutes. Okay . Stuck in traffic. I can't talk right now. Start without me. Call me. Where are you? I'll call you later. Are you there yet? I'm on my way. I need directions. Thanks. I'm lost. I'll be late. See you later.

Uconnect Voice Command

If the Uconnect Voice Command button exists on your steering wheel, then you have the Voice Command feature.

The Voice Command feature lets you keep your hands on the steering wheel, and your eyes on the road.

When you push the “Voice Command” button steering wheel, you will hear a beep. The beep is your signal to give a command. If you do not know what commands to say, you can say “help” and the system will provide options to you. If you ever wish to interrupt the system while it lists options, push the “Voice Command” button

, listen for the BEEP, and say your command.

located on the radio faceplate or

Changing The Volume

Start a dialogue by pushing the “Phone” button “Help”.

NOTE:

To access help, push the “Uconnect Phone” “help.” T ouch the display or push either cancel the help session.

, then say a command for example -

button on the steering wheel and say

or button and say “cancel” to

Page 96

ELECTRONICS

Common Voice Commands (Examples)

While In: Voice Command Example:

“FM”

Switch Modes

Radio (FM, AM)

Player

Sirius XM Satellite Radio

Sirius Travel Link

“Satellite” “AM” “Change Source to my MP3 Player”

“95.5” “95.5 FM” “Go to preset 5”

“Play Album 'Greatest Hits” “Play Artist 'Scott Joplin” “Play Genre 'Rock” “Play Song 'Maple Leaf Rag”

“39” “Foxxhole”

“Show fuel prices” “Show movie listings” “Show current weather” “Show extended weather” “Show T ravel Link favorites” “Show NFL headlines” “Show NBA rankings” “Show NFL schedules” “Show NBA scores”

NOTE:

For the shortened Sirius XM Satellite Radio mode commands to be recognized you must be in that mode. For example, if you are in Sirius XM Satellite Radio mode you can say “39”, but if you are not in Sirius XM mode, you would need to say “Tune to Satellite Channel 39.”

Common Navigation Voice Commands

To access the navigation voice commands, push the Uconnect Voice Command

button while in any mode and say “Navigation.”

Once in the Navigation feature, you can simply Say What You See on the touchscreen to give a navigation voice command.

Locating an address can be given as a one shot entry. For example, after saying “Find Address” and the system is ready, you can say the entire address in one command, “1234 1st Street, Any T own, Michigan.” If you are searching for a particular address or Point Of Interest, the available voice commands depend on what is displayed on the touchscreen.

Page 97

ELECTRONICS

When the Voice Command system is ready to be given a command, a green indicator is visible in the right corner of the touchscreen.

The following chart lists the navigation voice commands that may be available.

Navigation Voice Commands:

“Where T o?” (Main Menu command)

“View Map” (Main Menu command)

“Repeat guidance”

“Cancel Route”

“Detour” (During a Route Guidance)

“Where Am I?” “Find Address”

“Go Home”

“Find Place by Category”

“Find Place by Name”

“Find Recently Found”

“Find Favorite”

“Find City”

“Find Nearest Restaurant”

“Find Nearest Fuel”

“Find Nearest T ransit”

“Find Nearest Lodging”

“Find Nearest Shopping”

“Find Nearest Bank”

“Find Nearest Parking”

“Find Nearest Entertainment”

“Find Nearest Recreation”

“Find Nearest Attractions”

“Find Nearest Hospitals”

“Find Nearest Community”

“Find Nearest Auto Services”

“Find Nearest Airport”

“Find Nearest Police Stations”

“Find Nearest Fire Stations” “Find Nearest Auto Dealers”

WARNING!

• In an emergency , to use Uconnect Phone, your mobile phone must be:

• turned on

• paired to Uconnect Phone

• have network coverage

Page 98

ELECTRONICS

STEERING WHEEL AUDIO CONTROLS

The steering wheel audio controls are located on the rear surface of the steering wheel.

Right Switch

• Push the switch up or down to increase or decrease the volume.

• Push the button in the center to change modes AM/FM/CD/SXM.

Left Switch

• Push the switch up or down to search for the next listenable station or select the next or previous CD track.

• Push the button in the center to select the next preset station (radio) or to change CDs if equipped with a CD Changer.

Steering Wheel Audio Controls

Page 99

ELECTRONICS

ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) — STANDARD (2 BUTTON)

The EVIC features a driver interactive display that is located in the instrument cluster. Pushing the controls on the left side of the steering wheel allows the driver to select vehicle information/personal settings. For additional information, refer to “Programmable Features” in this section.

• Push the UP

upward through the main menus.

• Push the RIGHT

cess the submenu screens of a main menu item. Push and hold the RIGHT arrow button for two seconds to reset displayed/selected features that can be reset.

arrow button to scroll

arrow button to ac-

Two Button EVIC Controls

Programmable Features

The EVIC can be used to select the following vehicle information/personal settings. T o step to each main menu feature, push the UP last item in the list will cause the first item in the feature list to be displayed. The following features are in the Main menu:

• Odometer • Oil Life

• Digital Speedometer • T ire Pressure Monitor

• T rip Meter • Stored Messages

• Fuel Economy • Settings

NOTE:

For features in the EVIC that can be reset (Average Fuel Economy), the EVIC prompts a reset with a RIGHT arrow button graphic and the word RESET next to it.

button once for each step. A step from the

Page 100

ELECTRONICS

DRIVER INFORMATION DISPLAY (DID) — PREMIUM (4 BUTTON)

The DID features a driver interactive display that is located in the instrument cluster. Pushing the controls on the left side of the steering wheel allows the driver to select vehicle information and Personal Settings. For additional information, refer to “Programmable Features” in this guide.

• Push the UP through the main menus (Fuel Economy, Vehicle Info, Tire PSI, Cruise, Messages, Trip Info, Vehicle Speed and T urn Menu Off) and sub menus.

• Push the DOWN downward through the main menus and sub menus.

• Push the RIGHT setting in the setup menu. Push and hold the RIGHT features

• Push the LEFT

button to scroll upward

button to scroll

Four Button DID Controls

button for access to main menus, sub menus or to select a personal

button for two seconds to reset

button to scroll back to a previous menu or sub menu.

Compass Calibration

This compass is self-calibrating, which eliminates the need to set the compass manually. When the vehicle is new, the compass may appear erratic and the DID will display “CAL” until the compass is calibrated.

You may also calibrate the compass by completing one or more 360 degree turns (in an area free from large metal or metallic objects) until the “CAL” message displayed in the DID turns off. The compass will now function normally .

Programmable Features

• The DID can be used to view or change the following settings. Push the UP or DOWN

through the settings using the UP or DOWN buttons. Push the RIGHT change the setting. Push the LEFT sub menu.

• Radio Info • T rip Info

• Fuel Economy Info • T ire Pressure

• Cruise Control Info • Vehicle Info

• Digital Vehicle Speed • Stored Warning Messages

• Analog Vehicle Speed • T urn Menu OFF

button until System Setup displays, then push the RIGHT button. Scroll

button to

button to scroll back to a previous menu or
