D Link WA127A1 User Manual

150N Wireless LAN USB Adapter

User Manual

Version: 1.0

(September, 2008)

Copyright ©2008/2009 by this company. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of this company.

This company makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular purpose. Any software described in this manual is sold or licensed "as is". Should the programs prove defective following their purchase, the buyer (and not this company, its distributor, or its dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential damages resulting from any defect in the software. Further, this company reserves the right to revise this publication and to make changes from time to time in the contents thereof without obligation to notify any person of such revision or changes.

Federal Communication Commission

Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4. Consult the dealer or an experienced radio technician for help.

FCC Caution

This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Any changes or modifications not expressly approved by the party responsible for compliance could void the authority to operate equipment.

Federal Communication Commission (FCC) Radiation Exposure Statement

This EUT is compliance with SAR for general population/uncontrolled exposure limits in ANSI/IEEE C95.1-1999 and had been tested in accordance with the measurement methods and procedures specified in OET Bulletin 65 Supplement C.

The equipment version marketed in US is restricted to usage of the channels 1-11 only.

R&TTE Compliance Statement

This equipment complies with all the requirements of DIRECTIVE 1999/5/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of March 9, 1999 on radio equipment and telecommunication terminal Equipment and the mutual recognition of their conformity (R&TTE) The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment and Satellite Earth Station Equipment) As of April 8, 2000.

Safety

This equipment is designed with the utmost care for the safety of those who install and use it. However, special attention must be paid to the dangers of electric shock and static electricity when working with electrical equipment. All guidelines of this and of the computer manufacture must therefore be allowed at all times to ensure the safe use of the equipment.

EU Countries Intended for Use

The ETSI version of this device is intended for home and office use in Austria, Belgium, Denmark, Finland, France, Germany, Greece, Ireland, Italy, Luxembourg, the Netherlands, Portugal, Spain, Sweden, and the United Kingdom.

The ETSI version of this device is also authorized for use in EFTA member states: Iceland, Liechtenstein, Norway, and Switzerland.

EU Countries Not intended for use

None.

C A T A L O G

CHAPTER I: Product Information .............................................................1

1-1 Introduction and safety information................................................................1

1-2 Safety Information...........................................................................................2

1-3 System Requirements......................................................................................3

1-4 Package Contents.............................................................................................4

1-5 Familiar with your new wireless network card ...............................................5

CHAPTER II: Driver Installation and Configuration...............................6

2-1 Network Card Installation ...............................................................................6

2-2 Connect to Wireless Access Point .................................................................13

2-2-1 Using Ralink Utility...........................................................................14

2-2-1-1 Scan for Other Wireless Devices ............................................16

2-2-1-2 Connect to an Access Point.....................................................21

2-2-1-3 Add an Access Point to Profile................................................25

2-2-2 Using Windows Zero Configuration ..................................................33

2-3 Profile Management ......................................................................................37

2-3-1 Add a profile.......................................................................................38

2-3-2 Edit an existing profile.......................................................................39

2-3-3 Delete an existing profile ...................................................................40

2-3-4 Activate a profile................................................................................41

2-4 Advanced Settings .........................................................................................42

2-5 View Network Statistics ................................................................................45

2-6 WMM Setting................................................................................................46

2-7 WPS Configuration........................................................................................48

2-7-1 WPS Setup - PBC (Push-Button Configuration)................................49

2-7-2 WPS Setup - PIN................................................................................52

2-8 Radio On/Off.................................................................................................54

2-9 About .............................................................................................................55

2-10 On-line Help................................................................................................56

CHAPTER III: Soft-AP Function..............................................................57

3-1 Switch to AP Mode and Basic Configuration................................................57

3-2 Security Setting..............................................................................................62

3-3 Access Control...............................................................................................65

3-4 Connection Table...........................................................................................67

3-5 Event Log ......................................................................................................69

3-6 Statistics.........................................................................................................70

3-7 About .............................................................................................................71

CHAPTER IV: Appendix............................................................................ 72

4-1 Specification..................................................................................................72

4-2 Troubleshooting.............................................................................................73

4-3 Glossary.........................................................................................................75

CHAPTER I: Product Information

1-1 Introduction and safety information

Thank you for purchasing this high-speed wireless network card! Excepting common wireless standards 802.11b/g, this wireless network card is also able to access 802.11n wireless networks - data transfer rate is 150Mbps, and that’s three times faster than 802.11g wireless network!

The network card is integrated with high gain antenna. Due to the design, the network card can perform very well at dead spot and also enhance the wireless coverage.

With easy-to-install USB 2.0 interface - a very common expansion port of computers - plug this wireless network card into any empty USB port of your computer, just t hat simple!

Other features of this wireless network card including:

 High-efficiency antenna expands the scope of your wireless

network.

 High-speed data transfer rate - Up to 150Mbps.  WMM function: control the bandwidth required for different

applications.

 Work with 802.11b/g/Draft-N wireless networks.  Supports major encryption methods like WEP, WPA, and WPA2

encryption.  WPS configuration - You don’t need an experienced computer

technician to help you to get connected. Utilizing the software

program of the card, you can get your computer connected by

pushing a button or entering an 8-digit code. Pressing the button

on the network card, the WPS connection can be activated as

well.  USB 2.0 interface - you can get it installed on your computer in

just few seconds!

1-2 Safety Information

In order to keep the safety of users and your properties, please follow the following safety instructions:

1. This USB wireless network card is designed for indoor use only. DO NOT expose this network card to direct sun light, rain, or snow.

2. DO NOT put this network card at or near hot or humid places, like kitchen or bathroom. Also, do not left this wireless network card in the car in summer.

3. This network card is small enough to put in a child’s mouth, and it could cause serious injury or could be fatal. If they throw the network card, the card will be damaged. PLEASE KEEP THIS NETWORK CARD OUT THE REACH OF CHILDREN!

4. This network card will become hot when being used for long time (This is normal and is not a malfunction). DO NOT put the network card on a paper, cloth, or other flammable objects after the network card has been used for a long time.

5. There’s no user-serviceable part inside the network card. If you found that the network card is not working properly, please contact your dealer of purchase and ask for help. DO NOT disassemble the network card by your self, warranty will be void.

6. If the network card falls into water, DO NOT USE IT AGAIN BEFORE YOU SEND THE CARD TO THE DEALER OF PURCHASE FOR INSPECTION.

7. If you smell something strange or even see some smoke coming out from the network card, switch the computer off immediately, and call dealer of purchase for help.

1-3 System Requirements

 An empty USB 2.0 port (May not be able work with USB 1.1 port,

and performance will be greatly reduced)

 Windows 2000, XP, or Vista operating system  CD-ROM drive  At least 100MB of available disk space

1-4 Package Contents

Before you starting to use this wireless network card, please check if there’s anything missing in the package, and contact your dealer of purchase to claim for missing items:

□ USB wireless network card (1 pcs) ……………………………… 1 □ Protection Cap (1 pcs) …………………………………………… 2 □ Quick installation guide (1 pcs) …………………………………. 3 □ Driver/Utility/User manual CD-ROM (1pcs) …..……………… 4

4 1

1-5 Familiar with your new wireless network card

1. USB Connector

2. Connector Cap (To protect USB connector when not in use)

3. Link/Activity LED

4. WPS Button

LED Name Light Status Description Radio Off Off Wireless LAN function is disabled.

Off No link to wireless AP or Router Radio On

(No Link)

Flashing Transmitting management information.

(Link to AP or Router)

On Link to wireless AP or Router Radio On

Transmitting data or management

Flashing

information.

CHAPTER II: Driver Installation and Configuration

2-1 Network Card Installation

Please follow the following instructions to install your new wireless network card:

1. Insert the USB wireless network card into an empty USB 2.0 port of

your computer when computer is switched on. Never use force to insert the card, if you feel it’s stuck, flip the card over and try again.

2. The following message will appear on your computer, click ‘cancel’.

3. Insert device driver CDROM into the CD/DVD ROM drive of your

computer, and execute ‘Setup.exe’ program. Please read the end user license agreement and click ‘I accept the terms of the license agreement’ then click ‘Next’ button, to accept license agreement.

4. It is recommend installing driver and utility if the network card is

installing the first time. If you want to update the driver only, choose ’Install driver only’. Click ‘Next’ to continue.

5. You can choose the configuration tool used to configure the wireless

network card here. It’s recommended to select ‘Ralink Configuration Tool’, which provides fully access to all functions of this wireless network card. If you prefer to use the wireless configuration tool provided by Windows XP or Vista, please select ‘Microsoft Zero Configuration Tool’ then click ‘Next’.

6. Now you’ll see the following message, please click ‘Install’ to start

utility installation. If you see ‘Found New Hardware’ message again,

please ignore it and wait.

7. Please wait while the install procedure is running. When you see this

message, please click ‘Finish’ to complete the driver installation process.

8. After installation is complete, wireless configuration utility will be

shown in the desktop of your computer automatically. You will also see an icon at the lower-right corner of your windows system. If you put the mouse cursor on the icon, the status of wireless card will be displayed as a popup balloon.

HERE!

When you want to configure your wireless connection, please right click on this icon, and a popup menu will appear. You can click ‘Launch Config Utility’ to start configuration program.

If you want to close the configuration utility, please click ‘Exit’.

Please note that if you stopped config utility by ‘Exit’ function, you’ll not be able to maintain the wireless link to the access point you wish to use. In this case, you can start config utility again by clicking ‘Ralink Wireless Utility’ icon from ‘Start’ -> ‘All Programs’ -> ‘Ralink Wireless’, as shown below.

2-2 Connect to Wireless Access Point

After the driver is correctly installed, it will try to connect to any unencrypted wireless access point automatically. If you want to connect to a specific wireless access point, or the access point you wish to connect uses encryption, you have to configure the wireless network card and input required parameters, to get connected to the wireless access point you wish to connect.

NOTE: In Vista, the network card will not connect to any unencrypted wireless access point automatically.

The current status of wireless connection will be displayed by Ralink configuration utility icon:

Wireless connection is established, good signal reception.

Wireless connection is established, normal signal reception.

Wireless connection is established, weak signal reception.

Connection is not established yet.

Wireless network card is not detected.

There are two ways you can configure your wireless network card to connect to wireless access point: using the Ralink configuration utility and using built-in windows zero configuration utility.

2-2-1 Using Ralink Utility

Please follow the following instructions to use Ralink configuration utility to connect to wireless access point.

1. Right-click the Ralink configuration utility icon located at lower-right

corner of computer desktop and then clicks ‘Launch Config Utility’.

Ralink setup utility (RaUI) will launch, and begin to scan for all wireless access points automatically.

RaUI consists two parts: Menu and setup area. You can select a setup function (Profile, Network, etc.) from menu, and corresponding setup items will be displayed at setup area.

Setup Area

More / Less button

Some function includes more information, and can not be fitted in setup area. In this case, you can click ‘More / less’ button to expand the setup utility window, to display more information:

You can click ‘More / Less’ button again, and setup utility window will resume to its original size.

Tip: If a setup item requires more information to complete the setup procedure, the setup utility window will expand automatically.

2-2-1-1 Scan for Other Wireless Devices

There are two kinds of wireless connection mode: Infrastructure and Ad-Hoc. Infrastructure mode is used by wireless access points, which is able to establish wireless connection for you and other wireless / wired network clients.

Ad-Hoc mode is also know as ‘point-to-point’ mode, and in this mode, wireless devices such as computer or PDA will not be capable to establish wireless connection with more than one wireless device, and is suitable for establishing a one-to-one wireless connection between two wireless devices.

Before you can connect to any wireless access point or device by infrastructure or Ad-Hoc mode, there two things you must know:

a. Wireless device’s ‘SSID’ (Service Set IDentifier, someone will call

it ‘access point’s name’).

You can scan for the SSID of other wireless devices nearby, but if the SSID of the wireless device you wish to connect is hidden, you must know exact SSID before you can establish connection with it.

b. If the wireless device you wish to connect uses encryption, you

must know its encryption key.

Please launch Ralink setup utility and it will scan for wireless access points near by:

Scan results will be displayed here, please check if the wireless device (access point or another computer) with the SSID you wish to connect is shown here.

Scan result includes 6 types of information, they are:

A B C D E

A The SSID (Service Set Identifier) of wireless device. If nothing is displayed here, it means the SSID of this wireless device is hidden.

If a

symbol appears in front of the name of wireless device, means

you’ve established connected with that wireless device.

B The type of this wireless device and the channel number of this wireless device.

Means this wireless device is an access point

Means this wireless device is a computer (Ad-Hoc mode,

point-to-point connection)

C The wireless standard supported by this access point is displayed here.

‘n’ for 802.11n WPS icon access point uses encryption, a key icon

, ‘g; for 802.11g , and ‘b’ for 802.11b .

will appear when the access point supports WPS. If the

will appear.

Note: When the access point supports WPS and WPS icon

appeared, you will not see the key icon

here even through the

access point uses encryption.

D Shows the signal strength of access point by percentage.

E Shows the bar graph of the signal strength.

If you can not see the access point you wish to connect here, please click ‘Rescan’ button to scan for access point again, until the one you preferred is displayed. You may have to click ‘Rescan’ for more than two times before you can see the access point you wish to use here.

If you still can not see the access point you wish to use after clicking ‘Rescan’ for more than five times, please move your computer closer to the location where the wireless access point is, or see instructions in Chapter 4-2 ‘Troubleshoot ing’.

If you wish to see detailed information for a specific access point, please double-click on it, and you’ll be provided with its detailed information.

There are 4 types of technical information:

General: Displays basic information about this access point, such as SSID, MAC Address, authentication / encryption type, channel etc.

WPS: If this access point supports WPS (Wi-Fi Protected Setup), related information will be displayed here.

CCX: If this access point supports CCX (Cisco Compatible eXtension), related information will be displayed here.

802.11n: If this access point complies with 802.11n draft, related information will be displayed here.

And here are descriptions of every setup item in setup area:

Item Name Description

Sorted by >> You can decide how to sort all listed access point

by ‘SSID’, ‘Channel’, or ‘Signal’ (signal strength).

Show dBm Check this box to show the signal strength of

access point, instead of percentage.

Rescan Click this button to rescan access points. You can

click this button for several times, if the access point you wish to use does not show in the list.

Add to Profile You can store a specific access point to profile, so

you can link to that access point directly next time, without inputting authentication key again.

To add an access point to profile, you have to select an access point from the list first, then click ‘Add to Profile’ button. Detailed instructions will be given below.

Connect Connect to a selected access point. You have to

select an access point from the list first and then click ‘Connect’ to connect to the selected access point.

2-2-1-2 Connect to an Access Point

If the wireless access point you wish to connect is found, you can establish connection with it by clicking ‘Connect’ button. Instructions will be given as follow:

1. Click the wireless access point or network device you wish to connect,

it will be highlighted, then click ‘Connect’.

If the access point you selected does not use encryption, you’ll be connected to this wireless access point within one minute. If the access point you selected uses encryption, please proceed to step 3.

2. If the wireless access point does not have SSID, you’ll be prompted to

input it now. Please ask the owner of wireless access point for the exact SSID and input it here, then click ‘OK’ when ready. If the SSID you provided here is wrong, you’ll not be able to connect to this access point.

3. If the wireless access point uses encryption, you will be prompted to

input its WEP key or WPA preshared key.

4. Please ask the owner of the wireless access point you want to connect,

and input the correct key here and then click ‘OK’. By checking ‘Show Password’ box, the encryption key you inputted here will be displayed.

If the value you inputted here is wrong, you will not be able to connect to this wireless access point.

Authentication type will be selected by the authentication type of the access point automatically, please don’t change it.

However, if you’re connecting to an access point uses 802.1x authentication, you have to check ‘802.1x’ box and input related information. Instructions for 802.1x authentication will be given later.

5. If the wireless access point is successfully connected, you’ll see a

symbol appears in front of the name of wireless device.

You can put the mouse cursor over the Ralink configuration utility icon, and the brief information about link status and signal strength of current wireless connection will be shown as a popup balloon.

You can also click More / Less button ( ) to see detailed information of connected access point:

2-2-1-3 Add an Access Point to Profile

If you will connect to some specific wireless access point frequently, you can add their information to the profile. Just like the telephone directory, the profile saves all information of access points, and you can recall them anytime you wish to establish connection.

You can add a found access point to profile, or input all information of an access point by yourself.

To add a found access point to profile, please select a found access point first (to make it highlighted), then click ‘Add to Profile’ button; to input the information of access point by yourself, please go to ‘Profile’ menu and click ‘Add’ button.

The setup utility will expand:

Here are descriptions of every setup item:

Item Name Description

Profile Name You can give this profile a name. Every profile

needs a unique name.

SSID Please input the SSID of this access point. If you

selected an access point from the list, and its SSID is not hidden, the SSID will be filled automatically; however, you can modify the SSID by yourself.

Network Type Please select the network type: Ad hoc or

Infrastructure. If you’re connecting to an access point, please select ‘Infrastructure’; for point-to-point wireless connection (i.e. connecting to another computer using Ad Hoc mode), please select Ad hoc here.

If you selected an access point from the list above, please keep this field unchanged.

Tx Power You can select the wireless output power here. If

you’re not too far from access point (good signal reception), you can select a lower output power to save energy; for a distant access point, you can select a higher output power.

It’s suggested to select ‘Auto’ to let setup utility

decide the best output power for you.

Preamble Select the preamble for Ad hoc mode here.

Available options are ‘Auto’ and ‘Long’.

It’s suggested to select ‘Auto’ to let setup utility decide the preamble for you.

Channel You can select the radio channel number for

AdHoc mode here.

Power Save Mode Please select CAM (constantly awake mode, keep

wireless radio activity even when not transferring data), or PSM (Power saving mode, switches radio off when not transferring data).

It’s recommended to choose ‘PSM’ if you’re using this network card with notebook computer to help the battery live longer.

RTS Threshold Check this box to set the RTS threshold by

yourself. You can drag the slider to set the threshold value, or input the value in the box located at right.

It’s recommended to keep this value untouched

unless you know the effect of changing this value. Fragment Threshold

Check this box to set the packet fragment

threshold by yourself. You can drag the slider to

set the threshold value, or input the value in the

box located at right.

It’s recommended to keep this value untouched

unless you know the effect of changing this value.

To set authentication / encryption information for the access point. Please click ‘Auth. \ Encry.’ tab:

Here are descriptions of every setup item:

Item Name Description

Authentication Select the authentication type of the wireless access point or

wireless device you wish to connect. When you’re adding a profile from an existing access point or wireless device, authentication type will be selected automatically, and please do not change it.

If you select ‘LEAP’, you’ll be prompted to input LEAD specific settings:

Please input LEAP identity, password, domain name, and select encryption type. You can check ‘Show Password’ box so the password you inputted will be displayed as you type, but not replace by asterisk.

Encryption Select the encryption type of the wireless access point or

wireless device you wish to connect. When you’re adding a

profile from an existing access point or wireless device, the encryption type will be selected automatically, and please do

not modify it. WPA Preshared Key

Input WPA preshared key here. If encryption is not enabled,

or you select ‘WEP’ as encryption type, this field will be

disabled and grayed out. WEP Key You can select key type (Hexadecimal or ASCII) and input

WEP key here. If encryption is not enabled, or you select

‘WPA’ as encryption type, this field will be disabled and

grayed out. You can set up to 4 WEP keys here.

There are two types of WEP key: Hexadecimal and ASCII.

For Hexadecimal key, you can input number 0-9 and alphabet

a-f; for example, ‘001122aabbcc’; For ASCII key, you can

input number 0-9 and alphabet a-z; for example,

mywepkey12345.

The length of WEP key depends on the type of WEP key you

selected. You can input 10 or 26 hexadecimal characters and

5 or 13 ASCII characters as WEP key. Show Password

Check this box and all passphrases or security keys you

inputted will be displayed as you type, but not replace your

input with asterisk. Use 802.1x If the access point you wish to connect requires 802.1x

authentication, please click on ‘Use 802.1x’ box, then click

‘802.1X’ tab to set 802.1x parameters.

To set 802.1x authentication for the access point. Please click ‘802.1X’ tab:

Here are descriptions of every setup item:

Item Name Description

EAP Method Select 802.1x EAP method from dropdown menu. Please ask

the administrator of the access point you wish to connect to

select a correct EAP method. Tunnel Authentication

Select 802.1x tunnel authentication type from dropdown

menu. Please ask the administrator of the access point you

wish to connect to select a correct tunnel authentication

method. This pull down menu is only available when

authentication type you use is 'PEAP', ‘TLS / Smart Card', or

'TTLS'.

When you use 'EAP-FAST' as authentication type, the

protocol setting is always 'Generic Token Card' and can not

be changed. You also need to select ‘Soft Token’ or ‘Static

Password’ as password in ‘ID \ Password’ setting.

’EAP Fast’ authentication type also have a sub-menu to set

EAP fast-specific parameters:

If you need to use protected authentication credential, check

‘Use protected authentication credential’ box, and click

‘Import’ to load .pac credential file; to remove a loaded

credential file, click ‘Remove’. Session Resumption

ID \ Password tab

Client Certification tab

Server Certification tab

You can enable or disable session resumption here. If you

don’t know if you should enable session resumption or not,

please ask your 802.1x authentication administrator.

Input 802.1x username (ID) and password and other

information if it is required here. Click ‘Show Password’ to

show the password you typed.

Use this tab to select a local certificate from dropdown menu.

If the access point you wish to connect required a specific

client certificate, the certificate must be installed on your

computer, and you can select the certificate here.

Use this tab to use server-based certification. Please select a

CA (Certificate Authority) from dropdown menu. If

intermediate certificates are allowed, please select ‘Allow

intermediate certificates’. Also, if you need to specify CA

server’s name, you can specify it in ‘Server name’ field. You

can select ‘Server name must match’, so the CA server’s

name must be the same with the value you set in ‘Server

name’ field; If only the domain name part of full server name

must the same with the value you set in ‘Server name’ field,

select ‘Domain name must end in specified name’.

After you complete all information related to the access point, click ‘OK’ to save the profile, or click ‘cancel’ to cancel adding a new profile.

If the profile is created, you will see the information in the Profile List.

2-2-2 Using Windows Zero Configuration

Windows XP and Vista has a built-in wireless network configuration utility, called as ‘Windows Zero Configuration’ (WZC). You can also use WZC to configure your wireless network parameter:

1. Right-click Ralink configuration utility icon and select ‘Use Zero

Configuration as Configuration utility’.

2. Right click Windows Zero Configuration icon and select ‘View

Available Wireless Networks’. If you can not find the icon, please follow the procedures from step 3 to step 5.

HERE!

3. Click ‘Start’ button (should be located at the bottom-left corner of

windows desktop), click ‘Control Panel’, then click ‘Network and Internet Connections’ in Control Panel.

4. Click ‘Network Connections’.

5. Right-click ‘Wireless Network Connection’ (it may have a number as

suffix if you have more than one wireless network card, please make sure you right-click the ‘Ralink 802.11n Wireless LAN Card), then select ‘View Available Wireless Networks’.

6. All wireless access points in proximity will be displayed here. If the

access point you want to use is not displayed here, please try to move your computer closer to the access point, or you can click ‘Refresh network list’ to rescan access points. Click the access point you want to use if it’s shown, then click ‘Connect’.

7. If the access point is protected by encryption, you have to input its

security key or passphrase here. It must match the encryption setting on the access point.

If the access point you selected does not use encryption, you’ll not be prompted for security key or passphrase.

8. If you can see ‘Connected’ message, the connection between your

computer and wireless access point is successfully established.

2-3 Profile Management

If you need to connect to different wireless access points at different time, like of access point of your home, office, cybercafe, or public wireless service, you can store the connection parameters (encryption, passphrase, security etc, etc.) as a profile for every access point, so you don’t have to input these parameters every time when you want to connect to a specific wireless access point. To manage profiles, right-click the Ralink configuration utility icon located at lower-right corner of computer desktop, then click ‘Launch Config Utility’.

Click the ‘Profile’ menu. All profiles will be listed in ‘Profile List’, and you can select a profile from the list, all information about selected profile will be listed.

2-3-1 Add a profile

If you want to click new profile, click ‘Profile’ menu, then click ‘Add’ button. You’ll be prompted to input detailed information of access point, as described in Section 2-2-1-3.

2-3-2 Edit an existing profile

If you have added a profile before, and you wish to change the content of the profile, you can use this function. Please select a profile from the list first, then click ‘Edit’ button. You’ll be provided with the contents of selected profile, and you can edit them. Click ‘OK’ to save changes, or click ‘Cancel’ to discard changes.

2-3-3 Delete an existing profile

If you no longer need a profile, you can delete it. Select the profile you wish to delete from the list, and click ‘Delete’ button to delete it.

2-3-4 Activate a profile

When you want to connect to a specific wireless device in the profile list, you can select it and click ‘Activate’ button, to establish connection with it.

When you selected a profile and click ‘Activate’ button to activate the profile, a

icon will be displayed in front of the profile to show that the connection is failed; When the connection is successfully established, a icon will be displayed.

2-4 Advanced Settings

This wireless network card provides several advanced settings for experienced wireless users. You can change these settings to increase data transfer performance, or change operation mode.

Please follow the following instructions to set advanced wireless settings:

1. Right-click the Ralink configuration utility icon located at lower-right

corner of computer desktop and then click ‘Launch Config Utility’.

2. Click ‘Advanced’ menu, and the following settings will appear:

Here are descriptions of every setup item:

Item Name Description

Wireless mode Display the wireless operation mode of the

network card.

Enable Tx Burst Check this box to accelerate the data transmit rate.

It may not work with all wireless access point and

wireless devices. Enable TCP Window Size

Check this box and the configuration utility will

adjust TCP window size automatically to get

better performance. It should be safe for most of

wireless environments, but if you found some

problem on data transfer, uncheck this box. Fast Roaming Check this box and you can control the threshold

that the wireless network card should switch to

another wireless access point with better signal

quality. Only adjust value when you understand

what it means and you need to roam between

multiple access points. Show Authentication Status Dialog

When your computer is being authenticated by

wireless authentication server, a dialog window

with the process of authentication will appear.

This function is helpful to find out the problem

when you can not be authenticated, and you can

provide this information to authentication server’s

administrator for debugging purpose. Enable CCX Enable Cisco Compatible eXtensions. CCX is a

wireless feature developed by Cisco used to

improve the wireless performance with CCX

compatible wireless devices. Check this box if you

need to connect to CCX-compatible wireless

devices. When you enabled CCX, the following

setup items will become available:

Turn on CCKM: Check this box to enable CCKM

(Cisco Centralized Key Management), which

enables wireless clients to roam between

CCKM-enabled access points in very short time.

Enable Radio Measurements: When you’re

connecting to CCX-compatible access point,

check this box to enable radio measurement

function to improve wireless connectivity.

Non-Serving Channel Measurements Limit: When

you’re connecting to CCX-compatible access

point, check this box to enable measurement on

unused radio channels to improve wireless

connectivity.

After you finish the settings, click ‘Apply’ to apply new settings.

2-5 V iew Network Statistics

The configuration utility provides information about network statistics and link status. If you want to know how your wireless network card works, you can use these functions to get detailed information about the wireless connection you’re using.

Please follow the following instructions to check network statistics:

1. Right-click the Ralink configuration utility icon located at lower-right

corner of computer desktop and then click ‘Launch Config Utility’.

2. Click ‘Statistics’ menu and the statistics of wireless connection will be

displayed:

All connection-related statistics is displayed here. You can click ‘Transmit’ or ‘Receive’ tab, to view the statistics of transmitted or received packets. You can also click ‘Reset Counter’ button, to reset the statistics of all items back to 0.

2-6 WMM Setting

This wireless network card provides WMM (Wi-Fi Multimedia) function, which can improve the performance of certain network applications, like audio/video streaming, network telephony (VoIP), and others. When you enable the WMM function of this network card, you can define the priority of different kinds of data, to give higher priority to applications which require instant responding. Therefore you can improve the performance of such network applications.

Please follow the following instructions to set advanced wireless settings:

1. Right-click the Ralink configuration utility icon located at lower-right

corner of computer desktop and then click ‘Launch Config Utility’.

2. Click ‘WMM’ menu, and the following settings will appear:

In ‘WMM Setup Status’ block, current WMM settings will be displayed. And here are descriptions of every setup item:

Item Name Description

WMM Enable Check this box to enable WMM function. Please

click ‘Apply’ button on the right of this check box

after you check or uncheck this box, so

corresponding settings in this window will be

activated or deactivated respectively. WMM - Power Save Enable

Direct Link Setup Enable

Check this box to enable WMM power saving

mode to save energy, and let your computer’s

battery live longer.

You also have to select WMM power save modes

here:

AC_BE: Best Performance

AC_BK: Worst Performance

AC_VI: Video data has priority

AC_VO: Voice data has priority

If you have another WMM-enabled wireless

device, you can enter its MAC address here, then

click ‘Apply’ button, and this network card will

establish a direct link to the wireless device you

specified here.

You also have to specify the timeout value of this

directly-linked wireless device. Valid values are

from 1 to 65535 (seconds), and input ‘0’ for

infinity.

If you want to remove a specific wireless device

from direct link table, select the device and click

this button to remove it.

2-7 WPS Configuration

Wi-Fi Protected Setup (WPS) is the latest wireless network technology which makes wireless network setup become very simple. If you have WPS-enabled wireless access point, and you want to establish a secure connection to it, you don’t have to configure the wireless access point and setup data encryption by yourself. All you have to do is to go to the WPS setup page of this wireless card, click a button, and then press a specific button or enter a set of 8-digit code on the wireless access point you wish to establish a secure connection - just three simple steps!

For older wireless access points, it’s possible to perform a firmware upgrade to become a WPS-enabled access point. Since they may not have a hardware button to press for WPS setup, you can use an alternative WPS setup method - input the pin code. Every WPS-compatible wireless network card support pin code configuration method; you can just input the code to wireless access point, and the wireless access point and wireless network card will do the rest for you.

This wireless network card is compatible with WPS. To use this function, the wireless access point you wish to connect to must support WPS function too. Now, please follow the following instructions to establish secure connection between WPS-enabled wireless access point and your wireless network card.

2-7-1 WPS Setup - PBC (Push-Button Configuration)

1. Right-click the Ralink configuration utility icon located at lower-right

corner of computer desktop and then click ‘Launch Config Utility’.

2. Click ‘WPS’ menu, and the following settings will appear.

3. Set ‘Config Mode’ to ‘Enrollee’, and then push the ‘WPS’ button on

your wireless access point (the button used to activate WPS standby mode may have another name), or use other way to start WPS PBC standby mode as the instruction given by your wireless access point’s user manual.

You can also set ‘Config Mode’ to ‘Registrar’. In this mode, this wireless network card will wait for other WPS-enabled access points to send WPS pairing requests. Please refer to the instruction given by your wireless access point’s user manual to understand how to send WPS requests.

4. Before you start to establish the wireless connection by using WPS,

you can click ‘Rescan’ button to search for WPS-enabled access points near you again, to make sure the WPS function of your access point is activated.

All access points with WPS function enabled will be displayed here. Please make sure the access point you wish to connect is displayed. If not, please click ‘Rescan’ few more times. You can also click ‘Information’ button to see the detailed information about selected access point.

5. Start PBC pairing procedure at access point side (please refer to the

instruction given by your access point’s manufacturer), then click ‘PBC’ button in wireless configuration utility to start to establish wireless connection by WPS. Please be patient (This may require several seconds to one minute to complete). When you see ‘WPS status is connected successfully’ message, means the connection between this wireless network card and access point is successfully established by WPS, and the information about access point you connected to will be displayed.

6. You can click ‘Detail’ button to see detailed information of connected

access point. If you wish to save this connection as a profile, you can click ‘Export Profile’ button, and this connection will be saved. You can find this connection in ‘Profile’ tab in a later time.

7. Sometime WPS may fail (In the following picture, WPS pairing is

failed because no WPS-enabled access point is found):

You can click ‘PBC’ button few more times to try again. When an access point is connected, you can click ‘Disconnect’ to disconnect your wireless network card from a connected access point, or select another WPS-enabled wireless access point, then click ‘Connect’ to establish connection to selected access point, if there are more than one WPS-enabled access point found. You can also click ‘Rotate’ button, and next access point on the list will be selected to establish connection.

If you want to delete a found access point from the list, select it and click ‘Delete’ button.

2-7-2 WPS Setup - PIN

If the wireless access point you wish to connect supports PIN, please follow the following instructions to establish connection to it:

1. Right-click the Ralink configuration utility icon located at lower-right

corner of computer desktop and then click ‘Launch Config Utility’.

2. Click ‘WPS Configuration’ menu, and the following settings will

appear.

3. The PIN code of your wireless network card is an eight-digit number

located at the upper-right position of configuration utility. Remember it, and input the number to your wireless access point as the WPS PIN code (Please refer to the user manual of your wireless access point for instructions about how to do this).

NOTE: If you experienced problem with the pin code provided here, you can click ‘Renew’ to get a new pin code.

4. Click ‘PIN’ button now, and wait for few seconds to one minute. If a

wireless access point with correct PIN code is found, you’ll be connected to that access point.

5. You may have to click ‘PIN’ for few more times to try again. If you

still can not connect to access point by this way, please make sure the PIN code you provided to access point is correct.

There are also some options available for WPS configuration:

WPS associate IE: Check this box to send the association request with WPS IE during WPS setup. This is optional and you can use default value if you don’t know what will be affected.

WPS probe IE: Check this box to send the WPS probe request with WPS IE during WPS setup. This is optional and you can use default value if you don’t know what will be affected.

Auto: When in PIN mode, wireless access point to be connected will be selected automatically if this box is checked.

2-8 Radio On/Off

You can switch the wireless radio transceiver on and off by the utility, so if you want to disable wireless network function, you don’t have to remove the network card physically.

1. Right-click the Ralink configuration utility icon located at lower-right

corner of computer desktop and then click ‘Launch Config Utility’.

2. To switch wireless radio on/off, please click ‘Radio On/Off’ button.

Wireless radio is on (Green)

Wireless radio is off (Red)

2-9 About

The ‘About’ tab provides you the information about version number of the configuration utility, driver, and other important information about your wireless network card.

Please follow the following instructions to see these information:

1. Right-click the Ralink configuration utility icon located at lower-right

corner of computer desktop and then click ‘Launch Config Utility’.

2. Click ‘About’ tab, and the following information will appear.

2-10 On-line Help

If you need to know the directions of how to use specific function in the utility, please click ‘Help’ button. On-line help documents will be presented in Windows help format.

Click this button to view on-line help documents.

CHAPTER III: Soft-AP Function

Excepting become a wireless client of other wireless access points, this wireless card can act as a wireless service provider also! You can switch this wireless card’s operating mode to ‘AP’ mode to simulate the function of a real wireless access point by software, and all other computers and wireless devices can connect to your computer wirelessly, even share the internet connection you have!

Please follow the instructions in following chapters to use the AP function of your wireless card.

3-1 Switch to AP Mode and Basic Configuration

The operating mode of the wireless card is ‘Station Mode’ (becoming a client of other wireless access points) by default. If you want to switch to AP mode, please right-click Ralink utility icon, and select ‘Switch to AP Mode’.

After you select ‘Switch to AP Mode’, the Ralink utility icon will be changed to:

Which indicated the wireless card is operating in AP mode now. If you want to switch the wireless card back to station mode (become a client of other wireless access points), click ‘Switch to Station Mode’.

A configuration window will appear after you switch the operation mode to ‘AP’, which asks you to assign an existing network card with internet connection.

If your computer has another network card which is connected to Internet, please select it from ‘Name’ dropdown menu, and click ‘Enable ICS’; if your computer does not have another network card with Internet connection, please click ‘Not enable ICS’.

After you click ‘Enable ICS’ or ‘Not enable ICS’, you’ll see the basic configuration menu of the AP function.

Here are descriptions of every setup item:

Item Name Description

SSID Please input the SSID (the name used to identify

this wireless access point) here. Up to 32

numerical characters can be accepted here,

excepting space. Channel Please select the wireless channel you wish to use.

The number of channels available here will vary

depends on the setting of ‘Country Region Code’. Wireless Mode Select the operation mode of the access point here. Use Mac Address Click this button to use the MAC address of the

wireless card as SSID. A prefix ‘AP’ will be added

automatically. Security Setting Set the security options (wireless data encryption).

Please refer to chapter 3-2 ‘Security Settings’ for

details. Country Region Code

Please select the country code of the country or

region you live. Available options are 0-7, which

will affect the available wireless channels you can

use:

0: FCC (US, Canada, and other countries uses

FCC radio communication standards)

1: ETSI (Europe)

2: SPAIN

3: FRANCE

4: MKK

5: MKKI (TELEC)

6: ISERAL (Channel 3 to 9)

7: ISERAL (Channel 5 to 13)

Please note that only change the country code if

you are in different country. For example:

when operating this product in US, only

channels 1~11 can be operated. Selection of

other channels is not permitted under FCC

regulations.

No forwarding among wireless

Check this box and wireless clients will not be

able to share data with each other. clients Hide SSID Check this box and the SSID will not be

broadcasted to the public. Your wireless clients

must know the exact SSID to be able to connect to

your computer. This option is useful to enhance

security level. Allow BW 40 MHz Check this box to allow BW 40MHz capability. Tx BURST Check this box to accelerate the data transmit rate.

It may not work with all wireless access point and

wireless devices.

Beacon(ms) You can define the time interval that a beacon

signal should be send. Default value is 100. Do

not modify this value unless you know what will

be affected. TX Power You can select the wireless output power here.

Please select a proper output power setting

according to your actual needs. You may not need

100% of output power if other wireless clients are

not far from you. Idle Time Select the idle time for the wireless access point.

Default value is 300. Do not modify this value

unless you know what will be affected.

To save changes, click ‘Apply button. Or you can click ‘Default’ to reset all values to factory default value.

3-2 Security Setting

This wireless card supports wireless encryption in AP mode, which will encrypt the data being transferred over the air to enhance data security level. It’s recommended to enable data encryption unless you wish to open your computer (and its internet connection) to the public.

When you click ‘Security Setting’ in the utility, the following window will appear:

Here are descriptions of every setup item:

Item Name Description

Authentication Type

Please select a wireless authentication type you

wish to use. Available options are ‘Open’,

‘Shared’, WPA-PSK’, ‘WPA2-PSK’, and

‘WPA-PSK / WPA2-PSK’. If you want to disable

wireless data encryption, you must select ‘Open’. Encryption Type Please select an encryption mode. The available

options in this setting item will vary depending on

the authentication type you select. If you select

‘Not Use’, data will not be encrypted and people

with some networking knowledge will be able to

read the data you transfer with proper tool. WPA Pre-shared Key

Please input the WPA pre-shared key here. Only

clients with the same pre-shared key you inputted

here will be able to connect to your computer.

This setting is only available when you select one

of WPA encryptions. Group Rekey

You can specify the time interval to re-issue the Interval

key to your wireless clients here. You can click the

button ’10 seconds’ or ‘Kpackets’ to change the

unit of time interval. (every 10 seconds or a

thousand data packets times the value you

specified in ‘Group Rekey Interval’ field). Wep Key Please input the WEP encryption key here when

you select ‘WEP’ as encryption type. There are 2

types of WEP key: Hex (number 0 to 9, and ASCII

characters A to F) and ASCII (all alphanumerical

characters plus symbols). Please select the type of

WEP key first, and then input the WEP key

according to the type of WEP key you selected.

If you want to use WEP 64 bits encryption, please

input 10 characters if you select HEX, or input 5

characters if you select ASCII. If you want to use

WEP 128bits encryption, please input 26

characters if you select HEX, or input 13

characters if you select ASCII. 128 bits encryption

is safer then 64 bits, but the data transfer speed

will be slightly reduced. Show Password Check this box and the WPA pre-shared key or

WEP key you inputted will be shown, but not

replaced by asterisk (*).

When you finish with setting and want to save changes, click ‘OK’ button, or click ‘Cancel’ button to discard all changes you made.

3-3 Access Control

If you’re not going to open your computer and wireless resources to the public, you can use MAC address filtering function to enforce your access control policy, so only wireless clients with MAC address you defined by this function can be connected to your software access point.

Here are descriptions of every setup item:

Item Name Description

Access Policy Select the policy type of your access rule.

Disable: Allow any wireless client with proper

authentication settings to connect to this access

point.

Allow All: Only allow wireless clients with MAC

address listed here to connect to this access point.

Reject All: Reject wireless clients with MAC

address listed here to be connected to this access

point. MAC address Input the MAC address of the wireless client you

wish to allow or reject here. No colon (:) or

hyphen (-) required. Add Add the MAC address you inputted in ‘MAC

address’ field to the list. Delete Please select a MAC address from the list, then

click ‘Delete’ button to remove it. Remove All Delete all MAC addresses in the list.

When you finish with setting and want to save changes, click ‘Apply’ button.

3-4 Connection Table

If you want to see the list of all wireless clients connected to this access point, please select ‘Mac Table’ tab from the utility.

Here are descriptions of every field:

Item Name Description

MAC Address Displays the MAC address of this wireless client. AID The serial number of this wireless connection. Power Saving Mode

Displays the capability of power-saving function

of this wireless client. Status Displays additional information of this wireless

Connection, like current wireless operating mode

and data transfer rate.

3-5 Event Log

This software access point will log all wireless-related activities as a log. Click ‘Event Log’ tab, and the event log will be displayed.

You can click ‘Clear’ to remove all entries in the log.

3-6 Statistics

If you want to know detailed information about how your software access point works, click ‘Statistics’ tab, and the event log will be displayed.

You can click ‘RESET COUNTERS’ button to reset all counters to zero.

3-7 About

The ‘About’ tab provides you the information about version number of the configuration utility, driver, and other important information about your wireless access point.

CHAPTER IV: Appendix

4-1 Specification

Standards: IEEE 802.11b/g Interface: USB 2.0 (USB 1.1 Compatible) Frequency Band: 2.4000 ~ 2.4835GHz (Industrial Scientific Medical Band) Data Rate: 11b: 1/2/5.5/11Mbps

11g: 6/9/12/24/36/48/54Mbps 11n (20MHz): MCS0-7 (up to 72Mbps) 11n (40MHz): MCS0-7 (up to 150Mbps)

Securities: WEP 64/128, WPA, WPA2

Cisco CCX Support Antenna: Integrated with 3dBi Dipole Antenna Drivers: Windows 2000/XP/Vista LED: Link/Activity Dimension: 15(H) x 15(W) x 155(D) mm Temperature: 32~104°F (0 ~ 40°C) Humidity: 10-95% (NonCondensing) Certification: FCC, CE

4-2 Troubleshooting

If you encounter any problem when you’re using this wireless network card, don’t panic! Before you call your dealer of purchase for help, please check this troubleshooting table, the solution of your problem could be very simple, and you can solve the problem by yourself!

Scenario Solution I can’t find any wireless access point / wireless device in ‘Site Survey’ function.

1. Click ‘Rescan’ for few more times and

see if you can find any wireless access point or wireless device.

2. Please move closer to any known

wireless access point.

3. ‘Ad hoc’ function must be enabled for

the wireless device you wish to establish a direct wireless link.

4. Please adjust the position of network

card (you may have to move your computer if you’re using a notebook computer) and click ‘Rescan’ button for few more times. If you can find the wireless access point or wireless device you want to connect by doing this, try to move closer to the place where the wireless access point or wireless device

Nothing happens when I click ‘Launch Config Utility’

I can not establish connection with a certain

is located.

1. Please make sure the wireless network

card is inserted into your computer’s USB port. If the Ralink configuration utility’s icon is black, the network card is not detected by your computer.

2. Reboot the computer and try again.

3. Remove the card and insert it into

another USB port.

4. Remove the driver and re-install.

5. Contact the dealer of purchase for help.

1. Click ‘Connect’ for few more times.

2. If the SSID of access point you wish to

wireless access point connect is hidden (nothing displayed in

‘SSID’ field in ‘Site Survey’ function), you have to input correct SSID of the access point you wish to connect. Please contact the owner of access point to ask for correct SSID.

3. You have to input correct security key to connect an access point with encryption. Please contact the owner of access point to ask for correct security key.

4. The access point you wish to connect only allows network cards with specific MAC address to establish connection. Please go to ‘About’ tab and write the value of ‘Phy_Addess’ down, then

The network is slow / having problem when transferring large files

present this value to the owner of access point so he / she can add the MAC address of your network card to his / her access point’s list.

1. Move closer to the place where access

point is located.

2. Disable ‘Tx Burst’ in ‘Advanced’ tab.

3. Enable ‘WMM’ in ‘WMM’ tab if you

need to use multimedia / telephony related applications.

4. Disable ‘WMM – Power Save Enable’ in

‘WMM’ tab.

5. There could be too much people using

the same radio channel. Ask the owner of the access point to change the channel number.

Please try one or more solutions listed above.

4-3 Glossary

1. What is the IEEE 802.11g standard?

802.11g is the new IEEE standard for high-speed wireless LAN communications that provides for up to 54 Mbps data rate in the 2.4 GHz band. 802.11g is quickly becoming the next mainstream wireless LAN technology for the home, office and public networks.

802.11g defines the use of the same OFDM modulation technique specified in IEEE 802.11a for the 5 GHz frequency band and applies it in the same 2.4 GHz frequency band as IEEE 802.11b. The

802.11g standard requires backward compatibility with 802.11b. The standard specifically calls for:

A. A new physical layer for the 802.11 Medium Access Control

(MAC) in the 2.4 GHz frequency band, known as the extended rate PHY (ERP). The ERP adds OFDM as a mandatory new coding scheme for 6, 12 and 24 Mbps (mandatory speeds), and 18, 36, 48 and 54 Mbps (optional speeds). The ERP includes the modulation schemes found in 802.11b including CCK for 11 and

5.5 Mbps and Barker code modulation for 2 and 1 Mbps.

B. A protection mechanism called RTS/CTS that governs how

802.11g devices and 802.11b devices interoperate.

2. What is the IEEE 802.11b standard?

The IEEE 802.11b Wireless LAN standard subcommittee, which formulates the standard for the industry. The objective is to enable wireless LAN hardware from different manufactures to communicate.

3. What does IEEE 802.11 feature support?

The product supports the following IEEE 802.11 functions:

z CSMA/CA plus Acknowledge Protocol z Multi-Channel Roaming z Automatic Rate Selection z RTS/CTS Feature z Fragmentation z Power Management

4. What is Ad-hoc?

An Ad-hoc integrated wireless LAN is a group of computers, each has a Wireless LAN card, Connected as an independent wireless LAN. Ad hoc wireless LAN is applicable at a departmental scale for a branch or SOHO operation.

5. What is Infrastructure?

An integrated wireless and wireless and wired LAN is called an Infrastructure configuration. Infrastructure is applicable to enterprise scale for wireless access to central database, or wireless application for mobile workers.

6. What is BSS ID?

A specific Ad hoc LAN is called a Basic Service Set (BSS). Computers in a BSS must be configured with the same BSS ID.

7. What is WEP?

WEP is Wired Equivalent Privacy, a data privacy mechanism based on a 40 bit shared key algorithm, as described in the IEEE 802 .11 standard.

8. What is TKIP?

TKIP is a quick-fix method to quickly overcome the inherent weaknesses in WEP security, especially the reuse of encryption keys. TKIP is involved in the IEEE 802.11i WLAN security standard, and the specification might be officially released by early 2003.

9. What is AES?

AES (Advanced Encryption Standard), a chip-based security, has been developed to ensure the highest degree of security and authenticity for digital information, wherever and however communicated or stored, while making more efficient use of hardware and/or software than previous encryption standards. It is also included in IEEE 802.11i standard. Compare with AES, TKIP is a temporary protocol for replacing WEP security until manufacturers implement AES at the hardware level.

10. Can Wireless products support printer sharing?

Wireless products perform the same function as LAN products. Therefore, Wireless products can work with Netware, Windows 2000, or other LAN operating systems to support printer or file sharing.

11. Would the information be intercepted while transmitting on air?

WLAN features two-fold protection in security. On the hardware side, as with Direct Sequence Spread Spectrum technology, it has the inherent security feature of scrambling. On the software side, WLAN series offer the encryption function (WEP) to enhance security and Access Control. Users can set it up depending upon their needs.

12. What is DSSS? What is FHSS? And what ar e their differences?

Frequency-hopping spread-spectrum (FHSS) uses a narrowband carrier that changes frequency in a pattern that is known to both transmitter and receiver. Properly synchronized, the net effect is to maintain a single logical channel. To an unintended receiver , FHSS appears to be short-duration impulse noise. Direct-sequence spread-spectrum (DSSS) generates a redundant bit pattern for each bit to be transmitted. This bit pattern is called a chip (or chipping code). The longer the chip is, the greater the probability that the original data can be recovered. Even if one or more bits in the chip are damaged during transmission, statistical techniques embedded in the radio can recover the original data without-the need for retransmission. To an unintended receiver, DSSS appears as low power wideband noise and is rejected (ignored) by most narrowband receivers.

13. What is Spread Spectrum?

Spread Spectrum technology is a wideband radio frequency technique developed by the military for use in reliable, secure, mission-critical communication systems. It is designed to trade off bandwidth efficiency for reliability, integrity , and security. In other words, more bandwidth is consumed than in the case of narrowband transmission, but the trade off produces a signal that is, in effect, louder and thus easier to detect, provided that the receiver knows the parameters of the spread-spectrum signal being broadcast. If a receiver is not tuned to the right frequency, a spread –spectrum signal looks like background noise. There are two main alternatives, Direct Sequence Spread Spectrum (DSSS) and Frequency Hopping Spread Spectrum (FHSS).

14. What is WMM?

Wi-Fi Multimedia (WMM), a group of features for wireless networks that improve the user experience for audio, video and voice applications. WMM is based on a subset of the IEEE 802.11e WLAN QoS draft standard. WMM adds prioritized capabilities to Wi-Fi networks and optimizes their performance when multiple concurring applications, each with different latency and throughput requirements, compete for network resources. By using WMM, end-user satisfaction is maintained in a wider variety of environments and traffic conditions. WMM makes it possible for home network users and enterprise network managers to decide which data streams are most important and assign them a higher traffic priority.

15. What is WMM Power Save?

WMM Power Save is a set of features for Wi-Fi networks that increase the efficiency and flexibility of data transmission in order to conserve power. WMM Power Save has been optimized for mobile devices running latency-sensitive applications such as voice, audio, or video, but can benefit any Wi-Fi device. WMM Power Save uses mechanisms included in the IEEE 802.11e standard and is an enhancement of IEEE 802.11 legacy power save. With WMM Power Save, the same amount of data can be transmitted in a shorter time while allowing the Wi-Fi device to remain longer in a low-power “dozing” state.

16. What is GI?

GI stands for Guard Interval. It’s a measure to protect wireless devices from cross- interference. If there are two wireless devices using the same or near channel, and they are close enough, radio interference will occur and reduce the radio resource usability.

17. What is STBC?

STBC stands for Space-Time Block Coding, which is a technique used to transfer multiple copies of data by multiple antenna, to improve data transfer performance. By using multiple antennas, not only data transfer rate is improved, but also the wireless stability.

18. What is WPS?

WPS stands for Wi-Fi Protected Setup. It provides a simple way to establish unencrypted or encrypted connections between wireless clients and access point automatically. User can press a software or hardware button to activate WPS function, and WPS-compatible wireless clients and access point will establish connection by themselves. There are two types of WPS: PBC (Push-Button Configuration) and PIN code.

D Link WA127A1 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
