Version 1.00| 12/20/2018
User Manual
AC1300 Mesh-Enabled Smart Wi-Fi Router
DIR-1360
Preface
D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any
person or organization of such revisions or changes.
Manual Revisions
Revision Date Description
1.00 December 20, 2018 Initial A1 release
Trademarks
D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries.
All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies.
Apple®, Apple logo®, Safari®, iPhone®, iPad®, iPod touch® and Macintosh® are trademarks of Apple Inc., registered in the U.S. and other countries.
App Store
TM
is a service mark of Apple Inc.
Chrome™ browser, Google Play™ and Android™ are trademarks of Google Inc.
Internet Explorer®, Windows® and the Windows logo are trademarks of the Microsoft group of companies.
Copyright © 2018 by D-Link Corporation, Inc.
All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written permission from D-Link Corporation, Inc.
Power Usage
This device is an Energy Related Product (ErP) with High Network Availability (HiNA), and automatically switches to a power-saving Network
Standby mode within 1 minute of no packets being transmitted. It can also be turned o through a power switch to save energy when it is not
needed.
Network Standby: 4.87 watts
Switched O: 0.06 watts
iD-Link DIR-1360 User Manual
Table of Contents
Table of Contents
Product Overview .............................................................. 1
Package Contents .........................................................................1
System Requirements ................................................................. 2
Introduction ................................................................................... 3
Features ............................................................................................4
Hardware Overview ..................................................................... 5
LED Indicators ........................................................................ 5
Back Panel ...............................................................................6
Installation ......................................................................... 7
Before you Begin ...........................................................................7
Wireless Installation Considerations ......................................8
Hardware Setup ............................................................................9
Completing Setup ......................................................................12
Setup Wizard ........................................................................13
D-Link Wi-Fi App .................................................................17
Conguration ................................................................... 19
Home ..............................................................................................20
Internet ...................................................................................20
DIR-1360.................................................................................21
Connected Clients ..............................................................22
Settings ..........................................................................................23
Wizard .....................................................................................23
Wireless ..................................................................................54
Guest Zone .......................................................................57
Network ..................................................................................58
Features ..........................................................................................60
QoS Engine............................................................................60
Firewall ...................................................................................61
IPv4/IPv6 Rules ...............................................................63
Port Forwarding ..................................................................64
Virtual Server ................................................................... 65
Website Filter ........................................................................66
Static Routes .........................................................................67
IPv6 .....................................................................................68
Dynamic DNS .......................................................................69
IPv6 Host ...........................................................................70
Management ........................................................................71
Time & Schedule .................................................................71
Time ....................................................................................71
Schedule ...........................................................................72
System Log ............................................................................73
System Admin ......................................................................75
System ...............................................................................76
Upgrade .................................................................................77
Statistics .................................................................................78
Internet ...................................................................................23
IPv6 .....................................................................................33
VLAN ...................................................................................53
Connect a Wireless Client to your Router ......................79
WPS Button ...................................................................................79
Windows® 10 ................................................................................80
iiD-Link DIR-1360 User Manual
Table of Contents
Windows® 8 ...................................................................................82
WPA/WPA2 ............................................................................82
Windows® 7 ...................................................................................84
WPA/WPA2 ............................................................................84
WPS ..........................................................................................87
Windows Vista® ............................................................................91
WPA/WPA2 ............................................................................92
Troubleshooting .............................................................. 94
Wireless Basics .................................................................98
What is Wireless? .........................................................................99
Tips ................................................................................................ 101
Wireless Modes .........................................................................102
Networking Basics .........................................................103
Check your IP address ............................................................ 103
Wireless Security ......................................................... 104
What is WPA? ................................................................ 104
Technical Specications ................................................ 105
Regulatory Information ................................................106
iiiD-Link DIR-1360 User Manual
Section 1 - Product Overview
Product Overview
Package Contents
DIR-1360
Ethernet Cable
Power Adapter
If any of the above items are missing or damaged, please contact your local reseller.
Note: Using a power supply with a dierent voltage rating than the one included with the DIR-1360 will cause damage and void the warranty
for this product.
Quick Installation Document
1D-Link DIR-1360 User Manual
Section 1 - Product Overview
Network Requirements
System Requirements
• An Ethernet-based cable or DSL modem
• IEEE 802.11ac/n/g/b/a wireless clients
• 10/100/1000 Ethernet
Computer with the following:
• Windows®, Macintosh, or Linux-based operating system
• An installed Ethernet adapter
Web-based Conguration
Utility Requirements
Wi-Fi App Requirements
Browser Requirements:
• Internet Explorer 10 or higher
• Firefox 28 or higher
• Safari 6 or higher
• Chrome 28 or higher
Windows
• iPhone®/iPad® Android™ smartphone or tablet. (Please refer
to the mobile app's store page to check whether your device is
compatible)
®
Users: Make sure you have Javascript enabled.
2D-Link DIR-1360 User Manual
Section 1 - Product Overview
Introduction
The D-Link DIR-1360 AC1300 Mesh-Enabled Smart Wi-Fi Router shares your Internet connection over a blazing-fast Gigabit
Wireless AC connection of up to 1300 Mbps (Up to 867 Mbps on the 5 GHz Wireless AC band and up to 400 Mbps on the 2.4
1
GHz Wireless N band)
devices. Equipped with a Gigabit WAN/Internet port and four Gigabit LAN ports to provide wired speeds of up to 10 times
faster than standard 10/100 ports, the DIR-1360 lets you experience networking at its best – no matter if you're using wireless
or wired Ethernet.
Featuring four antennas and a 2x2 + 2x2 Multiple In Multiple Out (MIMO) hardware and software conguration, the DIR-1360
oers better data rates, fewer dead-spots, more coverage, and better reliability. Operating exclusively in the 5 GHz band, the
DIR-1360's 802.11ac wireless connections bypasses the crowded 2.4 GHz band, giving you faster speeds while still maintaining
backward compatibility with older 802.11n/g/b devices through the 2.4 GHz band. A stronger Wi-Fi signal means you can
install more wireless surveillance cameras, baby monitors, sensors, and alarms in the places where you need them. Add these
features together, and the DIR-1360 lets you expand your Smart Home by bringing Wi-Fi to places your old signal can’t reach.
by using advanced AC beamforming technology to signicantly outperform 802.11n and other 802.11ac
The DIR-1360's Smart Connect technology makes connecting to wireless networks easy automating multiple networks.
Since the introduction of 5 GHz multi-band wireless technology, choosing between 5 GHz or 2.4 GHz networks to optimize
range and speed involved guesswork. Smart Connect eliminates the guesswork by unifying both bands into a single network
name. Behind the scenes, when a connection is initiated, the DIR-1360's advanced algorithms determine the best band for
your device and automatically distributes each device to its optimal band – providing a faster, more reliable, and hassle-free
experience for all users.
1
Maximum wireless signal rate derived from IEEE Standard 802.11a, 802.11b, 802.11g, 802.11n and 802.11ac specications. Actual data throughput will vary. Network conditions
and environmental factors, including volume of network trac, building materials and construction, and network overhead, lower actual data throughput rate.
3D-Link DIR-1360 User Manual
Section 1 - Product Overview
• Superior Wireless Networking - The DIR-1360 provides Gigabit wireless speeds of up to a combined 1300
Mbps (867 Mbps 802.11ac 5 GHz, plus 400 Mbps 802.11n 2.4 GHz)1. These speeds rival wired connections and
allow users enjoy online activities such as HD video communication, online gaming, and Voice over IP telephony
lag-free from anywhere in your home while still oering full 802.11n/g/b backward compatibility.
• Extreme Wired LAN and WAN Networking - With four 10/100/1000 Gigabit Ethernet LAN ports, and a
10/100/1000 Gigabit Ethernet WAN port, the DIR-1360 has an enormous amount of bandwidth to take full
advantage of the fastest broadband speeds available.
• IPv6 Support - The DIR-1360 fully supports IPv6 and includes support for a variety of IPv6 connection types
including: SLAAC/DHCPv6, 6to4, 6rd, Static IPv6, IPv6 PPPoE, IPv6 in IPv4 tunneling, and local connectivity.
• Smart Connect - Creates a single wireless SSID for your devices. Behind the scenes, the DIR-1360 automatically
determines whether to connect a device to the 2.4 or 5 GHz network, thereby providing the best speed and
range for each device and optimally distributing devices to each network.
Features
• Advanced Firewall Features - The web-based user interface displays a number of advanced network
management features. Easily apply content ltering based on MAC address, URL, and/or domain name.
Schedule these lters to be active on certain days or for a duration of hours or minutes.
• Encrypted Multiple/Concurrent Sessions - The DIR-1360 supports VPN passthroughs. It supports multiple
and concurrent IPSec and PPTP sessions, so users behind the DIR-1360 can access corporate networks through
encrypted channels.
• User-friendly Setup Wizard - Using its easy-to-use web-based user interface or D-Link Wi-Fi App, the DIR-1360
lets you quickly congure and secure your router to your specic settings in minutes.
1
Maximum wireless signal rate derived from IEEE Standard 802.11a, 802.11g, 802.11n and 802.11ac specications. Actual data throughput will vary. Network conditions and
environmental factors, including volume of network trac, building materials and construction, and network overhead, lower actual data throughput rate. Environmental
conditions will adversely aect wireless signal range.
4D-Link DIR-1360 User Manual
Section 1 - Product Overview
Hardware Overview
LED Indicators
1 Power LED
2 Internet LED
3 Wireless (2.4 GHz LED) A solid blue light indicates that the 2.4 GHz wireless band is enabled.
4 Wireless (5 GHz LED) A solid blue light indicates that the 5 GHz wireless band is enabled.
5 USB 3.0 Port Connect a USB storage device to share les over the network.
A solid blue light indicates a proper connection to the power supply. The light will be solid orange
during boot up.
A solid blue light indicates a connection on the Internet port. If the LED is orange, the router cannot
connect to the Internet.
2
345
1
5D-Link DIR-1360 User Manual
Section 1 - Product Overview
Hardware Overview
Back Panel
1
1 Reset Button
2 Gigabit LAN Ports (1- 4) Connect Ethernet devices such as computers, switches, storage (NAS) devices, and game consoles.
3 Gigabit WAN Port Using an Ethernet cable, connect your broadband modem to this port.
4 WPS Button Press to start the WPS process and automatically create an encrypted connection to a WPS client.
5 Power Connector Connect the supplied power adapter here.
6 Power Button Press the power button to power the device on or o.
Insert a paperclip in the hole to press the recessed button, hold for 10 seconds, and release to reset the
router to default settings
2
3
4 5 6
6D-Link DIR-1360 User Manual
Section 3 - Installation
Installation
This section will walk you through the installation of the DIR-1360.
Before you Begin
• Placement of the router is very important. Do not place the router in an enclosed area such as a closet, cabinet,
attic, or garage. This is to allow proper ventilation and prevent overheating.
• Congure the router with the computer that was last connected directly to your Internet connection. Verify that it
is connected to the Internet before connecting additional devices.
• If your Internet Service provider (ISP) provided you with a modem/router combo, you will need to set it to “bridge”
mode so the router can work properly. Please contact your ISP or refer to the user manual for your modem/router
device.
• If connecting to a DSL modem, make sure to have your DSL service information provided by your Internet Service
Provider handy. This information is likely to include your DSL account's Username and Password. Your ISP may also
supply you with additional WAN conguration settings which might be necessary to establish a connection.
• If you are connecting a considerable amount of networking equipment, it may be a good idea to take the time to
label each cable or take a picture of your existing setup before making any changes.
• If you have DSL and are connecting via PPPoE, make sure you disable or uninstall any PPPoE software such as
WinPoET, BroadJump, or EnterNet 300 from your computer or you will not be able to connect to the Internet.
7D-Link DIR-1360 User Manual
Section 3 - Installation
Wireless Installation Considerations
The D-Link wireless router lets you access your network using a wireless connection from virtually anywhere within the
operating range of your wireless network. Keep in mind that the number, thickness and location of walls, ceilings, or other
objects that the wireless signals must pass through may limit the range. Typical ranges vary depending on the types of
materials and background RF (radio frequency) noise in your home or business. The key to maximizing wireless range is to
follow these basic guidelines:
• Keep the number of walls and ceilings between the D-Link router and other network devices to a minimum each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position your devices so that
the number of walls or ceilings is minimized.
• Be aware of the direct line between network devices. A wall that is 1.5 feet thick (0.5 meters), at a 45-degree
angle appears to be almost 3 feet (1 meter) thick. At a 2-degree angle it looks over 42 feet (14 meters) thick!
Position devices so that the signal will travel straight through a wall or ceiling (instead of at an angle) for better
reception.
• Building materials make a dierence. A solid metal door or aluminum studs may have a negative eect on
range. Try to position access points, wireless routers, and computers so that the signal passes through drywall or
open doorways. Materials and objects such as glass, steel, metal, walls with insulation, water (sh tanks), mirrors,
le cabinets, brick, and concrete will degrade your wireless signal.
• Keep your product away (at least 3-6 feet or 1-2 meters) from electrical devices or appliances that generate RF
noise.
• If you are using 2.4 GHz cordless phones or X-10 (wireless products such as ceiling fans, lights, and home
security systems), your wireless connection may degrade dramatically or drop completely. Make sure your 2.4
GHz phone base is as far away from your wireless devices as possible. The base transmits a signal even if the
phone is not in use.
8D-Link DIR-1360 User Manual
Section 3 - Installation
Hardware Setup
1. The DIR-1360 is designed to give you the fastest, most stable network connection possible. In order to maximize
performance, fully extend the antennas into a 105-degree angle (middle notch) to provide optimal wireless coverage.
Keep the router in an open area for better wireless coverage.
105˚
2. Position your DIR-1360 near your Internet-connected modem. Place it in an open area for better wireless coverage.
Modem
DIR-1360
3. Turn o and unplug the power and Ethernet cable to your cable or DSL broadband modem. This is required. In some
cases, you may need to turn it o for up to ve minutes.
DIR-1360
Modem
9D-Link DIR-1360 User Manual
Section 3 - Installation
4. Use the included Ethernet cable to connect your modem to the yellow port labeled INTERNET on the router.
DIR-1360
Modem
5. Turn on or plug your modem back in and wait approximately one minute before proceeding onward.
DIR-1360
Modem
6. Connect the supplied power adapter to the router and a power outlet, press the power button, and wait approximately
one minute until the LED indicator on the front of the device changes from orange to solid blue.
DIR-1360
Modem
10D-Link DIR-1360 User Manual
Section 3 - Installation
7. If you are conguring the DIR-1360 wirelessly from a PC, connect to a Wi-Fi network printed on the included Wi-Fi
Conguration Card. You can also nd the Wi-Fi network names and passwords printed on the label attached to the
bottom your router.
Modem
DIR-1360
Quick Install Card
If you are conguring the DIR-1360 from a PC with a wired Ethernet connection, plug one end of an Ethernet cable
into the port labeled 1 on the back of the router, and the other end into the Ethernet port on your computer.
Modem
DIR-1360
8. If you are connecting to a broadband service that uses a dynamic connection (not PPPoE), you may be online already.
Try opening a web browser and connecting to a website. If the website does not load, proceed to Setup Wizard on
page 13.
11D-Link DIR-1360 User Manual
Section 3 - Installation
Completing Setup
There are dierent ways you can congure your router to connect to the Internet and connect to your clients:
• D-Link Setup Wizard - This wizard will launch when you log into the router for the rst time.
Refer to Setup Wizard on page 13.
• D-Link Wi-Fi App - Use your Android™ device, iPhone™ or IPad™ to congure your router. Refer to D-Link Wi-Fi App on
page 17.
• Manual Setup - Log in to the router and manually congure your router.
Refer to Conguration on page 19.
12D-Link DIR-1360 User Manual
Section 3 - Installation
Setup Wizard
If this is your rst time installing the router, open your web browser and enter
http://dlinkrouter.local./ in the address bar. Alternatively, enter the IP address
of the router (default: http://192.168.0.1).
The wizard is designed to guide you through a step-by-step process to congure
your new D-Link router and connect to the Internet.
Click Next to continue.
Please wait while your router detects your Internet connection type. If the router
detects your Internet connection, you may need to enter your ISP information
such as username and password.
If the router does not detect a valid Internet connection, a list of connection
types to choose from will be displayed.
Select your Internet connection type (this information can be obtained from
your Internet Service Provider) and click Next to continue.
13D-Link DIR-1360 User Manual
Section 3 - Installation
Setup Wizard (continued)
If the router detected or you selected PPPoE, enter your PPPoE username and
password and click Next to continue.
Note: Make sure to remove your PPPoE software from your computer. The software
is no longer needed and will not work through a router.
If the router detected or you selected Static, enter the IP and DNS settings
supplied by your ISP. Click Next to continue.
14D-Link DIR-1360 User Manual
Section 3 - Installation
Setup Wizard (continued)
Create a Wi-Fi password (between 8-63 characters). Your wireless clients will
need to have this passphrase or key entered to be able to connect to your
wireless network.
Click Next to continue.
Note: The DIR-1360's Smart Connect feature presents a single wireless network.
When connecting clients to an extension network, they will be automatically added
to the best band, either 2.4 GHz or 5 GHz. To disable the Smart Connect feature and
individually congure 2.4 GHz and 5 GHz networks, refer to Wireless on page 54.
To help protect your router, please enter a new password. You will be prompted
for this password every time you want to use the router’s web conguration
utility. Click Next to continue.
15D-Link DIR-1360 User Manual
Section 3 - Installation
Setup Wizard (continued)
You will be presented with a summary of your settings. Click Next to nalize
the settings or Back to make changes.
At the end of the wizard, you will be presented with a nal summary of your
settings. Click Finish to close the wizard.
Congratulations, your device has been successfully congured!
16D-Link DIR-1360 User Manual
Section 3 - Installation
D-Link Wi-Fi App
The D-Link Wi-Fi App allows you to install and congure your DIR-1360 AC1300 Mesh-Enabled Smart Wi-Fi Router from your
mobile device.
Note: The screenshots may be dierent depending on your mobile device’s OS version. The following steps show the Android
interface of the D-Link Wi-Fi app. If you are using an iOS device, the appearance may be dierent from that of the screenshots, but the
process is the same.
Step 1
Search for the free D-Link Wi-Fi App on the Apple App Store or Google Play
and install. You can also scan the QR code on the right, which will take you to
the respective D-Link Wi-Fi app store page directly.
Step 2
Launch the D-Link Wi-Fi App from the Home screen of your device.
Step 3
Click on the Install Your Device Button at the bottom of the screen. (Or click on
the Menu button on the top left of the app and do the same.)
D-Link Wi-Fi
17D-Link DIR-1360 User Manual
Section 3 - Installation
D-Link Wi-Fi App (continued)
Step 4
Select from list of options the device you want to install. If you do not see your
device listed choose "Others" then tap NEXT.
Step 5
You will now be guided through a step-by-step process for setting up your
device. Simply follow the on-screen instructions to complete the installation
and DIR-1360 conguration process.
18D-Link DIR-1360 User Manual
Section 4 - Conguration
Conguration
To access the conguration utility, open a web-browser such as Internet
Explorer and enter http://dlinkrouter.local./ or you may also connect by
typing the IP address of the router (by default this is http://192.168.0.1) in the
address bar.
Enter your password. If you previously followed the setup wizard, please use
the admin password you entered during the wizard. Otherwise, leave the
password blank. Click Log In to proceed.
Note: If you cannot remember your password and cannot log in, press and hold
the recessed reset button for longer than 10 seconds to restore the router to its
default settings.
The router’s home page will open displaying its current connection status.
The bar at the top of the page has quick access to Settings and Management
functions. You may quickly jump back Home at any time.
Note: The system will automatically log out after a period of inactivity.
19D-Link DIR-1360 User Manual
Section 4 - Conguration
Home
The Home page displays the current status of the router in the form of an
interactive diagram. You can click each icon to display information about each
part of the network at the bottom of the screen. The menu bar at the top of
the page will allow you to quickly navigate to other pages.
The Home page displays whether or not the router is currently connected to
the Internet. If it is disconnected, click Click to repair to bring up the setup
wizard, refer to Setup Wizard on page 13 for more information.
Internet
To bring up more details about your Internet connection, click on the
Internet icon. Click IPv4 or IPv6 to see details of the IPv4 connection and IPv6
connection respectively.
Click Release IP Address to disconnect from the Internet. If you do this and
wish to reconnect, click Renew.
To recongure the Internet settings, refer to Internet on page 23.
20D-Link DIR-1360 User Manual
Section 4 - Conguration
DIR-1360
Click on the DIR-1360 icon to view details about the router and its wireless
settings.
Here you can see the router’s current Wi-Fi network name and password, as
well as the router's MAC address, IPv4 address, and IPv6 address.
To recongure the network settings, either click Go to settings in the center,
or click Settings (at the top of the page) and then Network on the menu that
appears. Refer to Network on page 58 for more information.
To recongure the wireless settings, either click Go to settings, on the lower
right, or click Settings (at the top of the page) and then Wireless on the menu
that appears. Refer to Wireless on page 54 for more information.
21D-Link DIR-1360 User Manual
Section 4 - Conguration
Connected Clients
Click on the Connected Clients icon to view details about the router and its
wireless settings.
On this page you can see all the clients currently connected to the router, and
their IP addresses.
To edit each client’s settings, click the pencil icon on the client you want to
edit.
Name: Enter a custom name for this client.
Vendor: Displays the vendor of the device.
MAC Address: Displays the MAC address of the device.
IP Address: Displays the current IP address of this client.
Reserve IP: Enable to reserve this IP address for this client.
IP Address
(Reserved):
Parental Control: Allow or Block access to the router.
Specify an IP address for the DIR-1360's DHCP server to assign.
Click Save when you are done.
22D-Link DIR-1360 User Manual
Section 4 - Conguration
Settings
Wizard
In the Settings menu on the bar on the top of the page, click Wizard to open the setup wizard. This is the same wizard that
appears when you start the router for the rst time. Refer to Setup Wizard on page 13 for details.
Internet
In the Settings menu on the bar on the top of the page, click Internet to see the Internet conguration options.
My Internet
Connection Is:
For Dynamic IP (DHCP) refer to page 24.
For Static IP refer to page 25.
For PPPoE refer to page 26.
For PPTP refer to page 28.
For L2TP refer to page 30.
For DS-Lite refer to page 32.
To congure an IPv6 connection, click the IPv6 link. Refer to page 33.
Choose your Internet connection type from the drop-down menu. You
will be presented with the appropriate options for your connection
type. Click Advanced Settings... to expand the list and see all of the
options.
23D-Link DIR-1360 User Manual
Section 4 - Conguration
Dynamic IP (DHCP)
Select Dynamic IP (DHCP) to obtain IP address information automatically
from your Internet Service Provider (ISP). Select this option if your ISP does not
specify an IP address to use.
Advanced Settings
Host Name: The host name is optional but may be required by some ISPs. Leave
it blank if you are not sure.
Primary DNS
Server:
Secondary DNS
Server:
MTU: Maximum Transmission Unit - you may need to change the MTU for
MAC Address
Clone:
Enter the primary DNS server IP address assigned by your ISP. This
address is usually obtained automatically from your ISP.
Enter the secondary DNS server IP address assigned by your ISP. This
address is usually obtained automatically from your ISP.
optimal performance with your ISP (Default is AUTO).
The default MAC address is set to the Internet port’s physical interface
MAC address on the router. You can use the drop-down menu to
replace the Internet port’s MAC address with the MAC address of a
connected client.
Click Save when you are done.
24D-Link DIR-1360 User Manual
Section 4 - Conguration
Static IP
Select Static IP if your IP information is provided by your Internet Service
Provider (ISP).
IP Address: Enter the IP address provided by your ISP.
Subnet Mask: Enter the subnet mask provided by your ISP.
Default Gateway: Enter the default gateway address provided by your ISP.
Primary DNS
Server:
Advanced Settings
Secondary DNS
Server:
MTU: Maximum Transmission Unit - you may need to change the MTU for
MAC Address
Clone:
Enter the primary DNS server IP address assigned by your ISP.
Enter the secondary DNS server IP address assigned by your ISP.
optimal performance with your ISP. The recommended setting is Auto.
The default MAC address is set to the Internet port’s physical interface
MAC address on the router. You can use the drop-down menu to
replace the Internet port’s MAC address with the MAC address of a
connected client.
Click Save when you are done.
25D-Link DIR-1360 User Manual
Section 4 - Conguration
PPPoE
Select PPPoE if your ISP provides and requires you to enter a PPPoE username
and password in order to connect to the Internet.
Username: Enter the username provided by your ISP.
Password: Enter the password provided by your ISP.
Reconnect Mode: Select either Always on, On Demand, or Manual.
Maximum Idle
Time:
Enter a maximum idle time during which the Internet connection is
maintained during inactivity. To disable this feature, select Always
on as the reconnect mode.
Advanced Settings
Address Mode: Select Static IP if your ISP assigned you the IP address, subnet mask,
gateway, and DNS server addresses. In most cases, select Dynamic IP.
Dynamic IP
Service Name: Enter the ISP service name (optional).
Primary DNS
Server:
Secondary DNS
Server:
MTU: Maximum Transmission Unit - you may need to change the MTU for
Enter the primary DNS server IP address assigned by your ISP.
Enter the secondary DNS server IP address assigned by your ISP.
optimal performance with your ISP. The recommended setting is Auto.
26D-Link DIR-1360 User Manual
Section 4 - Conguration
PPPoE (continued)
MAC Address
Clone:
The default MAC address is set to the Internet port’s physical interface
MAC address on the router. You can use the drop-down menu to
replace the Internet port’s MAC address with the MAC address of a
connected client.
Static IP
IP Address: Enter the IP address provided by your ISP.
Service Name: Enter the ISP service name (optional).
Primary DNS
Server:
Secondary DNS
Server:
MTU: Maximum Transmission Unit - you may need to change the MTU for
MAC Address
Clone:
Enter the primary DNS server IP address assigned by your ISP.
Enter the secondary DNS server IP address assigned by your ISP.
optimal performance with your ISP. The recommended setting is Auto.
The default MAC address is set to the Internet port’s physical interface
MAC address on the router. You can use the drop-down menu to
replace the Internet port’s MAC address with the MAC address of a
connected client.
Click Save when you are done.
27D-Link DIR-1360 User Manual
Section 4 - Conguration
PPTP
Choose PPTP (Point-to-Point-Tunneling Protocol) if your Internet Service
Provider (ISP) uses a PPTP connection. Your ISP will provide you with a
username and password.
PPTP Server IP
Address:
Username: Enter the username provided by your ISP.
Password: Enter the password provided by your ISP.
Reconnect Mode: Select either Always on, On demand, or Manual.
Maximum Idle
Time:
Enter the PPTP server IP address provided by your ISP.
Enter a maximum idle time during which the Internet connection is
maintained during inactivity. To disable this feature, select Always
on as the reconnect mode.
Advanced Settings
Address Mode: Select Static IP if your ISP assigned you the IP address, subnet mask,
gateway, and DNS server addresses. In most cases, select Dynamic IP.
Dynamic IP
Primary DNS
Server:
Enter the primary DNS server IP address assigned by your ISP.
Secondary DNS
Server:
MTU: Maximum Transmission Unit - you may need to change the MTU for
Enter the secondary DNS server IP address assigned by your ISP.
optimal performance with your ISP. The recommended setting is Auto.
28D-Link DIR-1360 User Manual
Section 4 - Conguration
Static IP
PPTP IP Address: Enter the IP address provided by your ISP.
PPTP (continued)
PPTP Subnet
Mask:
PPTP Gateway IP
Address:
Primary DNS
Server:
Secondary DNS
Server:
MTU: Maximum Transmission Unit - you may need to change the MTU for
Enter the subnet mask provided by your ISP.
Enter the gateway IP address provided by your ISP.
Enter the primary DNS server IP address assigned by your ISP.
Enter the secondary DNS server IP address assigned by your ISP.
optimal performance with your ISP. The recommended setting is Auto.
Click Save when you are done.
29D-Link DIR-1360 User Manual
Section 4 - Conguration
L2TP
Choose L2TP (Layer 2 Tunneling Protocol) if your Internet Service Provider
(ISP) uses a L2TP connection. Your ISP will provide you with a username and
password.
L2TP Server: Enter the L2TP server IP address provided by your ISP.
Username: Enter the username provided by your ISP.
Password: Enter the password provided by your ISP.
Reconnect Mode: Select either Always on, On demand, or Manual.
Maximum Idle
Time:
Enter a maximum idle time during which the Internet connection is
maintained during inactivity. To disable this feature, select Always
on as the reconnect mode.
Advanced Settings
Address Mode: Select Static IP if your ISP assigned you the IP address, subnet mask,
gateway, and DNS server addresses. In most cases, select Dynamic IP.
Dynamic IP
Primary DNS
Server:
Secondary DNS
Server:
MTU: Maximum Transmission Unit - you may need to change the MTU for
Enter the primary DNS server IP address assigned by your ISP.
Enter the secondary DNS server IP address assigned by your ISP.
optimal performance with your ISP. The recommended setting is Auto.
30D-Link DIR-1360 User Manual
Section 4 - Conguration
Static IP
L2TP IP Address: Enter the IP address provided by your ISP.
L2TP (continued)
L2TP Subnet
Mask:
L2TP Gateway IP
Address:
Primary DNS
Server:
Secondary DNS
Server:
MTU: Maximum Transmission Unit - you may need to change the MTU for
Enter the subnet mask provided by your ISP.
Enter the gateway IP address provided by your ISP.
Enter the primary DNS server IP address assigned by your ISP.
Enter the secondary DNS server IP address assigned by your ISP.
optimal performance with your ISP. The recommended setting is Auto.
Click Save when you are done.
31D-Link DIR-1360 User Manual
Section 4 - Conguration
DS-Lite
DS-Lite is an IPV4/IPv6 hybrid connection type. After selecting DS-Lite, the
following parameters will be available for conguration:
Advanced Settings
DS-Lite
Conguration:
Select DS-Lite DHCPv6 Option to let the router allocate the AFTR
IPv6 address automatically. Select Manual Conguration to enter
the AFTR IPv6 address manually.
DS-Lite DHCPv6
B4 IPv6 Address: Enter the B4 IPv4 address value used here.
WAN IPv6
Address:
IPv6 WAN Default
Gateway:
Once connected, the WAN IPv6 address will be displayed here.
Once connected, the IPv6 WAN default gateway address will be
displayed here.
Manual
AFTR IPv6
Address:
B4 IPv6 Address: Enter the B4 IPv4 address value used here.
Enter the AFTR IPv6 address used here.
WAN IPv6
Address:
IPv6 WAN Default
Gateway:
Once connected, the WAN IPv6 address will be displayed here.
Once connected, the IPv6 WAN default gateway address will be
displayed here.
Click Save when you are done.
32D-Link DIR-1360 User Manual
Section 4 - Conguration
IPv6
To congure an IPv6 connection, click the IPv6 link. To return to the IPv4
settings, click IPv4.
My Internet
Connection Is:
Choose your IPv6 connection type from the drop-down menu. You
will be presented with the appropriate options for your connection
type. Click Advanced Settings... to expand the list and see all of the
options.
For Auto Detection refer to page 34.
For Static IPv6 refer to page 36.
For Auto Conguration (SLAAC/DHCPv6) refer to page 38.
For PPPoE refer to page 41.
For IPv6 in IPv4 Tunnel refer to page 45.
For 6 to 4 refer to page 48.
For 6rd refer to page 50.
For Local Connectivity Only refer to page 52.
33D-Link DIR-1360 User Manual
Section 4 - Conguration
Auto Detection
Select Auto Detection to automatically detect the IPv6 connection method
used by your Internet Service Provider (ISP). If Auto Detection fails, you can
manually select another IPv6 connection type.
IPv6 DNS Settings
DNS Type: Select either Obtain DNS server address automatically or Use the
following DNS address.
If Use the following DNS address is selected:
Primary DNS
Server:
Secondary DNS
Server:
If you selected Use the following DNS address above, enter the
primary DNS server address.
If you selected Use the following DNS address above, enter the
secondary DNS server address.
LAN IPv6 Address Settings
Enable DHCP-PD: Enable or disable DHCP Prex Delegation.
LAN IPv6 LinkLocal Address:
If Enable DHCP-PD is disabled, these additional parameters are available for conguration:
LAN IPv6 Address: Enter a valid LAN IPv6 address.
LAN IPv6 LinkLocal Address:
Displays the router’s LAN link-local address.
Displays the router’s LAN link-local address.
34D-Link DIR-1360 User Manual
Section 4 - Conguration
Auto Detection (continued)
Advanced Settings - Address Autoconguration Settings
Enable Automatic
IPv6 Address
Assignment:
Enable Automatic
DHCP-PD in LAN:
Autoconguration
Type:
If you selected SLAAC+RDNSS or SLAAC+Stateless DHCP as the Autoconguration Type:
Router
Advertisement
Lifetime:
If you selected Stateful DHCPv6 as the Autoconguration Type:
IPv6 Address
Range (Start):
Enable or disable the Automatic IPv6 Address Assignment feature.
Enable or disable DHCP-PD for other IPv6 routers connected to the
LAN interface.
Note: This feature requires a smaller subnet prex than /64 (i.e. allowing
for a larger address allocation), such as /63. Contact your ISP for more
information.
Select SLAAC+RDNSS, SLAAC+Stateless DHCP, or Stateful DHCPv6.
Enter the router advertisement lifetime (in minutes).
Enter the starting IPv6 address for the DHCP server’s IPv6 assignment.
IPv6 Address
Range (End):
Enter the ending IPv6 address for the DHCP server’s IPv6 assignment.
Click Save when you are done.
35D-Link DIR-1360 User Manual
Section 4 - Conguration
Static IPv6
Select Static IP if your IPv6 information is provided by your Internet Service
Provider (ISP).
IPv6 DNS Settings
If Use the following DNS address is selected for DNS Type:
Primary DNS
Server:
Secondary DNS
Server:
Enter the primary DNS server address.
Enter the secondary DNS server address.
LAN IPv6 Address Settings
If Enable DHCP-PD is disabled these additional parameters are available for conguration:
LAN IPv6 Address: Enter the LAN (local) IPv6 address for the router.
LAN IPv6 LinkLocal Address:
Displays the router’s LAN link-local address.
Advanced Settings - Address Autoconguration Settings
Enable Automatic
IPv6 Address
Assignment:
Autoconguration
Type:
Enable or disable the Automatic IPv6 Address Assignment feature.
Select SLAAC+RDNSS, SLAAC+Stateless DHCP, or Stateful DHCPv6.
Router
Advertisement
Lifetime:
Enter the router advertisement lifetime (in minutes).
36D-Link DIR-1360 User Manual
Section 4 - Conguration
Static IPv6 (continued)
If you selected Stateful DHCPv6 as the Autoconguration Type:
IPv6 Address
Range (Start):
IPv6 Address
Range (End):
Enter the starting IPv6 address for the DHCP server’s IPv6 assignment.
Enter the ending IPv6 address for the DHCP server’s IPv6 assignment.
Click Save when you are done.
37D-Link DIR-1360 User Manual
Section 4 - Conguration
Auto Conguration (SLAAC/DHCPv6)
Select Auto Conguration if your ISP assigns your IPv6 address when your
router requests one from the ISP’s server. Some ISPs require you to adjust
settings on your side before your router can connect to the IPv6 Internet.
IPv6 DNS Settings
DNS Type: Select either Obtain DNS server address automatically or Use the
following DNS address.
If Use the following DNS address is selected:
Primary DNS
Server:
Secondary DNS
Server:
Enter the primary DNS server address.
Enter the secondary DNS server address.
LAN IPv6 Address Settings
Enable DHCP-PD: Enable or disable prex delegation services.
LAN IPv6 LinkLocal Address:
If Enable DHCP-PD is disabled, these additional parameters are available for conguration:
LAN IPv6 Address: Enter a valid LAN IPv6 address.
LAN IPv6 LinkLocal Address:
Displays the router’s LAN link-local address.
Displays the router’s LAN link-local address.
38D-Link DIR-1360 User Manual
Section 4 - Conguration
Auto Conguration (SLAAC/DHCPv6) (continued)
Advanced Settings - Address Autoconguration Settings
Enable Automatic
IPv6 Address
Assignment:
If DHCP-PD is enabled in LAN IPv6 Address Settings:
Enable Automatic
DHCP-PD in LAN:
Autoconguration
Type:
If you selected SLAAC+RDNSS or SLAAC+Stateless DHCP as the Autoconguration Type:
Router
Advertisement
Lifetime:
If you selected Stateful DHCPv6 as the Autoconguration Type:
Enable or disable the Automatic IPv6 Address Assignment feature.
Enable or disable DHCP-PD for other IPv6 routers connected to the
LAN interface.
Note: This feature requires a smaller subnet prex than /64 (i.e. allowing
for a larger address allocation), such as /63. Contact your ISP for more
information.
Select SLAAC+RDNSS, SLAAC+Stateless DHCP, or Stateful DHCPv6.
Enter the router advertisement lifetime (in minutes).
IPv6 Address
Range (Start):
IPv6 Address
Range (End):
Enter the starting IPv6 address for the DHCP server’s IPv6 assignment.
Enter the ending IPv6 address for the DHCP server’s IPv6 assignment.
39D-Link DIR-1360 User Manual
Section 4 - Conguration
Auto Conguration (SLAAC/DHCPv6) (continued)
If DHCP-PD is disabled in LAN IPv6 Address Settings and SLAAC+Stateless DHCP or
SLAAC+RDNSS is chosen as the Autoconguration Type:
Router
Advertisement
Lifetime:
If DHCP-PD is disabled in LAN IPv6 Address Settings and Stateful DHCPv6 is chosen as the
Autoconguration Type:
IPv6 Address
Range (Start):
IPv6 Address
Range (End):
IPv6 Address
Lifetime:
Enter the router advertisement lifetime (in minutes).
Enter the starting IPv6 address for the DHCP server’s IPv6 assignment.
Enter the ending IPv6 address for the DHCP server’s IPv6 assignment.
Enter the IPv6 address lifetime (in minutes).
Click Save when you are done.
40D-Link DIR-1360 User Manual
Section 4 - Conguration
PPPoE
Select PPPoE if your ISP provides and requires you to enter a PPPoE username
and password in order to connect to the Internet.
PPPoE Session: Choose Share with IPv4 to re-use your IPv4 PPPoE username and
password, or Create a new session.
Address Mode: Select Static IP if your ISP assigned you an IP address. In most cases,
select Dynamic IP.
MTU: Maximum Transmission Unit - you may need to change the MTU for
optimal performance with your ISP.
If you selected Static IP as the Address Mode and Share with IPv4 as the PPPoE Session:
IP Address: Enter the IP address provided by your ISP.
MTU: Maximum Transmission Unit - you may need to change the MTU for
optimal performance with your ISP.
If you selected Create a new session as the PPPoE Session:
Username: Enter the username provided by your ISP.
Password: Enter the password provided by your ISP.
Address Mode: Select either Dynamic IP or Static IP.
Service Name: Enter the ISP service name (optional).
Reconnect Mode: Select either Always On or Manual.
MTU: Maximum Transmission Unit - you may need to change the MTU for
optimal performance with your ISP.
41D-Link DIR-1360 User Manual
Section 4 - Conguration
PPPoE (continued)
If you selected Static IP as the Address Mode and Create a new session as the PPPoE Session:
IP Address: Enter the IP address provided by your ISP
Service Name: Enter the ISP service name (optional).
Reconnect Mode: Select either Always-on or Manual.
MTU: Maximum Transmission Unit - you may need to change the MTU for
optimal performance with your ISP.
IPv6 DNS Settings
DNS Type: Select either Obtain DNS server address automatically or Use the
following DNS address.
If Use the following DNS address is selected:
Primary DNS
Server:
Secondary DNS
Server:
Enter the primary DNS server address.
Enter the secondary DNS server address.
LAN IPv6 Address Settings
Enable DHCP-PD: Enable or disable prefix delegation services. This option is only
available if you selected Dynamic IP for address mode.
LAN IPv6 LinkLocal Address:
Displays the router’s LAN link-local address.
42D-Link DIR-1360 User Manual
Section 4 - Conguration
PPPoE (continued)
If Enable DHCP-PD is disabled these additional parameters are available for conguration:
LAN IPv6 Address: If DHCP-PD disabled or static address mode is selected, enter the LAN
(local) IPv6 address for the router.
LAN IPv6 LinkLocal Address:
Displays the router’s LAN link-local address.
Advanced Settings - Address Autoconguration Settings
Enable Automatic
IPv6 Address
Assignment:
If DHCP-PD is enabled in LAN IPv6 Address Settings:
Enable Automatic
DHCP-PD in LAN:
Autoconguration
Type:
If you selected SLAAC+RDNSS or SLAAC+Stateless DHCP as the Autoconguration Type:
Enable or disable the Automatic IPv6 Address Assignment feature.
Enable or disable DHCP-PD for other IPv6 routers connected to the
LAN interface.
Note: This feature requires a smaller subnet prex than /64 (i.e. allowing
for a larger address allocation), such as /63. Contact your ISP for more
information.
Select SLAAC+RDNSS, SLAAC+Stateless DHCP, or Stateful DHCPv6.
Router
Advertisement
Lifetime:
Enter the router advertisement lifetime (in minutes).
43D-Link DIR-1360 User Manual
Section 4 - Conguration
PPPoE (continued)
If you selected Stateful DHCPv6 as the Autoconguration Type:
IPv6 Address
Range (Start):
IPv6 Address
Range (End):
If DHCP-PD is disabled in LAN IPv6 Address Settings:
IPv6 Address
Range (Start):
IPv6 Address
Range (End):
IPv6 Address
Lifetime:
Enter the starting IPv6 address for the DHCP server’s IPv6 assignment.
Enter the ending IPv6 address for the DHCP server’s IPv6 assignment.
Enter the starting IPv6 address for the DHCP server’s IPv6 assignment.
Enter the ending IPv6 address for the DHCP server’s IPv6 assignment.
Enter the IPv6 address lifetime (in minutes).
Click Save when you are done.
44D-Link DIR-1360 User Manual
Section 4 - Conguration
IPv6 in IPv4 Tunnel
The user can congure the IPv6 connection to run in IPv4 Tunnel mode. IPv6
over IPv4 tunnelling encapsulates IPv6 packets in IPv4 packets so that IPv6
packets can be sent over an IPv4 infrastructure.
Remote IPv4
Address:
Remote IPv6
Address:
Local IPv4
Address:
Local IPv6
Address:
Subnet Prex
Length:
Enter the IPv4 remote address you will use.
Enter the IPv6 remote address you will use.
Displays the current local IPv4 address.
Enter the IPv6 local address you will use.
Enter the subnet prex length supplied by your ISP.
IPv6 DNS Settings
DNS Type: Select either Obtain DNS server address automatically or Use the
following DNS address.
If Use the following DNS address is selected:
Primary DNS
Server:
Secondary DNS
Server:
Enter the primary DNS server address.
Enter the secondary DNS server address.
45D-Link DIR-1360 User Manual
Section 4 - Conguration
IPv6 in IPv4 Tunnel (continued)
LAN IPv6 Address Settings
Enable DHCP-PD: Enable or disable prefix delegation services. This option is only
available if you selected Dynamic IP for address mode.
LAN IPv6 LinkLocal Address:
If Enable DHCP-PD is disabled, these additional parameters are available for
conguration:
LAN IPv6 Address: If DHCP-PD disabled or static address mode is selected, enter the LAN
LAN IPv6 LinkLocal Address:
Displays the router’s LAN link-local address.
(local) IPv6 address for the router.
Displays the router’s LAN link-local address.
Advanced Settings - Address Autoconguration Settings
Enable Automatic
IPv6 Address
Assignment:
If DHCP-PD is enabled in LAN IPv6 Address Settings:
Enable Automatic
DHCP-PD in LAN:
Enable or disable the Automatic IPv6 Address Assignment feature.
Enable or disable DHCP-PD for other IPv6 routers connected to the
LAN interface.
Autoconguration
Type:
Note: This feature requires a smaller subnet prex than /64 (i.e. allowing
for a larger address allocation), such as /63. Contact your ISP for more
information.
Select SLAAC+RDNSS, SLAAC+Stateless DHCP, or Stateful DHCPv6.
46D-Link DIR-1360 User Manual
Section 4 - Conguration
IPv6 in IPv4 Tunnel (continued)
If you selected SLAAC+RDNSS or SLAAC+Stateless DHCP as the Autoconguration Type:
Router
Advertisement
Lifetime:
If you selected Stateful DHCPv6 as the Autoconguration Type:
IPv6 Address
Range (Start):
IPv6 Address
Range (End):
If DHCP-PD is disabled in LAN IPv6 Address Settings and SLAAC+Stateless DHCP or
SLAAC+RDNSS is chosen as the Autoconguration Type:
Router
Advertisement
Lifetime:
If DHCP-PD is disabled in LAN IPv6 Address Settings and Stateful DHCPv6 is chosen as the
Autoconguration Type:
Enter the router advertisement lifetime (in minutes).
Enter the starting IPv6 address for the DHCP server’s IPv6 assignment.
Enter the ending IPv6 address for the DHCP server’s IPv6 assignment.
Enter the router advertisement lifetime (in minutes).
IPv6 Address
Range (Start):
IPv6 Address
Range (End):
IPv6 Address
Lifetime:
Enter the starting IPv6 address for the DHCP server’s IPv6 assignment.
Enter the ending IPv6 address for the DHCP server’s IPv6 assignment.
Enter the IPv6 address lifetime (in minutes).
Click Save when you are done.
47D-Link DIR-1360 User Manual
Section 4 - Conguration
6to4
In this section the user can congure the IPv6 6 to 4 connection settings. 6to4
is an IPv6 address assignment and automatic tunneling technology that is
used to provide unicast IPv6 connectivity between IPv6 sites and hosts across
the IPv4 Internet.
6to4 Address: Displays the 6 to 4 address.
6to4 Relay: Enter the 6 to 4 relay supplied by your ISP.
Primary DNS
Server:
Secondary DNS
Server:
Enter the primary DNS server address.
Enter the secondary DNS server address.
LAN IPv6 Address Settings
LAN IPv6 Address: Enter the LAN (local) IPv6 address for the router.
LAN IPv6 LinkLocal Address:
Displays the router’s LAN link-local address.
48D-Link DIR-1360 User Manual
Section 4 - Conguration
6to4 (continued)
Advanced Settings - Address Autoconguration Settings
Enable Automatic
IPv6 Address
Assignment:
Autoconguration
Type:
If you selected SLAAC+RDNSS or SLAAC+Stateless DHCP as the Autoconguration Type:
Router
Advertisement
Lifetime:
If you selected Stateful DHCPv6 as the Autoconguration Type:
IPv6 Address
Range (Start):
IPv6 Address
Range (End):
IPv6 Address
Lifetime:
Enable or disable the Automatic IPv6 Address Assignment feature.
Select SLAAC+RDNSS, SLAAC+Stateless DHCP, or Stateful DHCPv6.
Enter the router advertisement lifetime (in minutes).
Enter the starting IPv6 address for the DHCP server’s IPv6 assignment.
Enter the ending IPv6 address for the DHCP server’s IPv6 assignment.
Enter the IPv6 address lifetime (in minutes).
Click Save when you are done.
49D-Link DIR-1360 User Manual
Section 4 - Conguration
6rd
In this section the user can congure the IPv6 6rd connection settings.
Assign IPv6 Prex: Currently unsupported.
Primary DNS
Server:
Secondary DNS
Server:
Enter the primary DNS server address.
Enter the secondary DNS server address.
6rd Manual Conguration
Enable Hub and
Spoke Mode:
6rd Conguration: Choose the 6rd DHCPv4 Option to automatically discover and
If you selected Manual conguration
6rd IPv6 Prex: Enter the 6rd IPv6 prex and mask length supplied by your ISP.
WAN IPv4 Address Displays the router’s IPv4 address.
6rd Border Relay
IPv4 Address:
Enable this option if you want to minimize the number of routes to
the destination by using a hub and spoke method of networking.
populate the data values, or Manual Conguration to enter the
settings yourself.
Enter the 6rd border relay IPv4 address settings supplied by your ISP.
LAN IPv6 Address Settings
LAN IPv6 Address: Displays the router’s LAN IPv6 Address link-local address.
LAN IPv6 LinkLocal Address:
Displays the router’s LAN link-local address.
50D-Link DIR-1360 User Manual
Section 4 - Conguration
6rd (continued)
Advanced Settings - Address Autoconguration Settings
Enable Automatic
IPv6 Address
Assignment:
Autoconguration
Type:
If you selected SLAAC+RDNSS or SLAAC+Stateless DHCP as the Autoconguration Type:
Router
Advertisement
Lifetime:
If you selected Stateful DHCPv6 as the Autoconguration Type:
IPv6 Address
Range (Start):
IPv6 Address
Range (End):
IPv6 Address
Lifetime:
Enable or disable the Automatic IPv6 Address Assignment feature.
Select SLAAC+RDNSS, SLAAC+Stateless DHCP, or Stateful DHCPv6.
Enter the router advertisement lifetime (in minutes).
Enter the starting IPv6 address for the DHCP server’s IPv6 assignment.
Enter the ending IPv6 address for the DHCP server’s IPv6 assignment.
Enter the IPv6 address lifetime (in minutes).
Click Save when you are done.
51D-Link DIR-1360 User Manual
Section 4 - Conguration
Local Connectivity Only
Local Connectivity Only allows you to set up an IPv6 connection that will not
connect to the Internet.
Advanced Settings
IPv6 ULA Settings
Enable ULA: Click here to enable Unique Local IPv6 Unicast Addresses settings.
Use Default ULA
Prex:
If you selected Enable ULA and disabled Default ULA Prex:
ULA Prex: Enter your own ULA prex.
Enable this option to use the default ULA prex.
Current IPv6 ULA Settings
Current ULA
Prex:
LAN IPv6 ULA: Displays the LAN's IPv6 ULA.
Displays the current ULA prex.
Click Save when you are done.
52D-Link DIR-1360 User Manual
Section 4 - Conguration
VLAN
VLAN allows for services such as Triple-Play to be used, and divides a network
into segments that can only be accessed by other devices in the same VLAN.
In the Settings menu on the bar on the top of the page, click Internet, then
click the VLAN link.
Triple-Play
Status: Click to enable or disable the Triple-Play VLAN feature.
If Status is enabled:
Internet VLAN ID Enter the VLAN ID for your Internet connection, as provided by your
ISP.
IPTV VLAN ID Enter the VLAN ID for your IPTV service, as provided by your ISP.
VOIP VLAN ID: Enter the VLAN ID for your VoIP network, as provided by your ISP.
Interface Trac Type Setting
LAN 1-4, Wireless,
Guest Zone:
From the drop-down menu, you can select the type of connection
(Internet, IPTV, or Voice over IP) coming from the WAN connection to
each interface on the DIR-1360.
Click Save when you are done.
53D-Link DIR-1360 User Manual
Section 4 - Conguration
Wireless
From this page you can congure your wireless network settings.
Smart Connect
Smart Connect: Enable or disable the Smart Connect Feature. When enabled, only
a few conguration options are available to simplify conguration.
Wi-Fi Name (SSID): Create a name for your wireless network using up to 32 characters.
Password: Create a password to use for wireless security. Wireless clients will
need to enter this password to successfully connect to the network.
Advanced Settings
Security Mode: Choose None or WPA/WPA2-Personal (recommended).
Transmission
Power:
Schedule: Use the drop-down menu to select the time schedule that the rule
Select the desired wireless transmission power.
will be enabled for. The schedule may be set to Always Enable, or
you can create your own schedules in the Schedules section. Refer
to Schedule on page 72 for more information.
Wi-Fi Protected Setup
The easiest way to connect your wireless devices to the router is with Wi-Fi Protected Setup
(WPS). Using WPS-PIN is disabled by default due to security vulnerabilities.
WPS-PBC Status: Enable or disable WPS-PBC (Push Button Conguration) fuctionality.
WPS-PIN Status: Enable or disable WPS-PIN fuctionality.
Refer to the next page if you wish to disable Smart Connect or click
Save when you are done.
54D-Link DIR-1360 User Manual
Section 4 - Conguration
Wireless - Smart Connect Disabled
If Smart Connect is disabled the following options are available:
2.4GHz / 5GHz
Status: Enable or disable the 2.4 GHz / 5 GHz wireless network.
Wi-Fi Name (SSID): Create a name for your wireless network using up to 32 characters.
Password: Create a password to use for wireless security.
Advanced Settings
Security Mode: Choose None or WPA/WPA2-Personal (recommended).
802.11 Mode
(2.4 GHz):
802.11 Mode
(5 GHz):
Wi-Fi Channel: Select the desired channel. The default is Auto (recommended).
Transmission
Power:
Channel Width
(2.4 GHz):
Channel Width
(5 GHz):
Select the desired wireless networking standards to use.
The available options for the 2.4 GHz wireless network are Mixed
802.11b/g/n, Mixed 802.11g/n, 802.11n only.
Select the desired wireless networking standards to use.
The available options for the 5 GHz wireless network are Mixed
802.11a/n/ac, Mixed 802.11n/ac, 802.11ac only, Mixed 802.11a/n,
Mixed 802.11n only, or 802.11a only.
Select the desired wireless transmission power.
Select Auto 20/40 if you are using both 802.11n and non-802.11n
devices, or select 20 MHz if you are not using any 802.11n devices.
Select Auto 20/40/80 if you are using 802.11ac, 802.11n, and 802.11a
devices, select Auto 20/40 if you are using 802.11n and 802.11a
devices, or select 20 MHz if you are only using 802.11a devices.
55D-Link DIR-1360 User Manual
Section 4 - Conguration
HT20/40
Coexistence:
(2.4 GHz):
Visibility Status: The default setting is Visible. Select Invisible if you do not want to
Schedule: Use the drop-down menu to select the time schedule that the rule
Enable or disable HT20/40 Coexistence.
broadcast the SSID of your wireless network.
will be enabled for. The schedule may be set to Always Enable, or
you can create your own schedules in the Schedules section. Refer
to Schedule on page 72 for more information.
Wi-Fi Protected Setup
The easiest way to connect your wireless devices to the router is with Wi-Fi Protected Setup
(WPS). Using WPS-PIN disabled by default due to security vulnerabilities.
WPS-PBC Status: Enable or disable WPS-PBC (Push Button Conguration) functionality.
WPS-PIN Status: Enable or disable WPS-PIN functionality.
Click Save when you are done.
56D-Link DIR-1360 User Manual
Section 4 - Conguration
Guest Zone
The Guest Zone feature will allow you to create temporary zones that can be
used by guests to access the Internet. These zones will be separate from your
main wireless network. You may congure dierent zones for the 2.4 GHz and
5 GHz wireless bands.
Note: If Smart Connect is enabled, Guest Zone is unavailable.
In the Settings menu on the bar on the top of the page, click Wireless, then
click the Guest Zone link.
2.4 GHz / 5 GHz
Status: Enable or disable the 2.4 GHz / 5 GHz wireless network.
Wi-Fi Name (SSID): Create a name for your wireless network using up to 32 characters.
Password: Create a password to use for wireless security.
Home Network Access
Internet Access
Only:
Enabling this option will confine connectivity to the Internet,
preventing guests from accessing other local network devices.
Click Save when you are done.
57D-Link DIR-1360 User Manual
Section 4 - Conguration
Network
This section will allow you to change the local network settings of the router
and to congure the DHCP settings. In the Settings menu on the bar on the
top of the page, click Network. Click Advanced Settings... to expand the list
and see all of the options.
Network Settings
LAN IP Address: Enter the IP address of the router. The default IP address is 192.168.0.1.
If you change the IP address, once you click Save, you will need
to enter the new IP address in your browser to get back into the
conguration utility.
Subnet Mask: Enter the subnet mask of the router. The default subnet mask is
255.255.255.0.
Management
Link:
Local Domain
Name:
Enable DNS Relay: Disable to transfer the DNS server information from your ISP to your
The default address to access the router’s conguration is
http://dlinkrouter.local/ Here, you can replace dlinkrouter with a
name of your choice.
Enter the domain name (optional).
computers. If enabled, your computers will use the router for a DNS
server.
58D-Link DIR-1360 User Manual
Section 4 - Conguration
DHCP Server
Status: Enable or disable the DHCP server.
Network (continued)
DHCP IP Address
Range:
DHCP Lease Time: Enter the length of time for the IP address lease in minutes.
Always Broadcast: Enable this feature to broadcast your network's DHCP server to LAN/
Enter the starting and ending IP addresses for the DHCP server’s IP
assignment.
Note: If you statically (manually) assign IP addresses to your computers
or devices, make sure the IP addresses are outside of this range or you
may have an IP conict.
WLAN clients.
Advanced Settings
WAN Port Speed: You may set the port speed of the Internet port to 10 Mbps, 100
Mbps, 1000 Mbps, or Auto (recommended).
UPnP: Enable or disable Universal Plug and Play (UPnP). UPnP provides
compatibility with networking equipment, software, and peripherals.
IPv4 Multicast
Stream:
Enable to allow IPv4 multicast trac to pass through the router from
the Internet.
IPv6 Multicast
Stream:
Enable to allow IPv6 multicast trac to pass through the router from
the Internet.
Click Save when you are done.
59D-Link DIR-1360 User Manual
Section 4 - Conguration
Features
QoS Engine
This Quality of Service (QoS) Engine will allow you to prioritize particular
clients over others, so that those clients receive higher bandwidth. For
example, if one client is streaming a movie and another is downloading a nonurgent le, you might wish to assign the former device a higher priority than
the latter so that the movie streaming is not disrupted by the trac of the
other devices on the network.
In the Features menu on the bar on the top of the page, click QoS Engine.
Under Connected Clients, you will see device cards representing each
connected client. If some are o-screen, you can use the < and > buttons to
scroll through the cards.
A maximum of one device can be assigned Highest priority.
A maximum of two devices can be assigned High priority.
A maximum of eight devices can be assigned Medium priority.
If no devices are explicitly assigned a priority, they will all be treated with
equal priority. If some devices are not assigned a priority and others are, the
unassigned devices will be treated with the lowest priority.
To assign a priority level to a device, drag the device card from the All Devices
list over an empty slot and release the mouse button. The card will remain in
the slot. If you want to remove a priority assignment from a device and return
it to the All Devices list, click the cross icon in the top right of the device card.
Click Save when you are done.
60D-Link DIR-1360 User Manual
Section 4 - Conguration
Firewall
The router’s rewall protects your network from malicious attacks over
the Internet. In the Features menu on the bar on the top of the page, click
Firewall. Click Advanced Settings... to expand the list and see all of the
options.
Enable DMZ: Enable or disable Demilitarized Zone (DMZ). This completely exposes
the client to threats over the Internet, and is not recommended in
ordinary situations.
DMZ IP Address: If you enabled DMZ, enter the IP address of the client you wish to
expose, or use the drop-down menu to quickly select it.
Enable SPI IPv4: Enabling Stateful Packet Inspection (SPI) helps to prevent cyber
attacks by validating that the trac passing through the session
conforms to the protocol.
Enable Anti-Spoof
Checking:
IPv6 Simple
Security:
IPv6 Ingress
Filtering:
Enable this feature to help protect your network from certain kinds
of “spoong” attacks.
Enable or disable IPv6 simple security.
Enable or disable IPv6 ingress ltering.
61D-Link DIR-1360 User Manual
Section 4 - Conguration
Firewall Settings (continued)
Advanced Settings - Application Level Gateway (ALG) Conguration
PPTP: Allows multiple machines on the LAN to connect to their corporate
network using the PPTP protocol.
IPSec (VPN): Allows multiple VPN clients to connect to their corporate network
using IPSec. Some VPN clients support traversal of IPSec through
NAT. This Application Level Gateway (ALG) may interfere with the
operation of such VPN clients. If you are having trouble connecting
with your corporate network, try turning this ALG o. Please check
with the system administrator of your corporate network whether
your VPN client supports NAT traversal.
RTSP: Allows applications that uses Real Time Streaming Protocol (RTSP) to
receive streaming media from the Internet.
SIP: Allows devices and applications using VoIP (Voice over IP) to
communicate across NAT. Some VoIP applications and devices have
the ability to discover NAT devices and work around them. This ALG
may interfere with the operation of such devices. If you are having
trouble making VoIP calls, try turning this ALG o.
Click Save when you are done.
62D-Link DIR-1360 User Manual
Section 4 - Conguration
IPv4/IPv6 Rules
The IPv4/IPv6 Rules section is an advanced option that lets you congure what
kind of trac is allowed to pass through the network. To congure the IPv4
rules, from the Firewall Settings page click IPv4 Rules. To congure IPv6 rules,
from the Firewall Settings page click IPv6 Rules. To return to the main Firewall
Settings page, click Advanced.
To begin, use the drop-down menu to select whether you want to ALLOW or
DENY the rules you create. You can also choose to turn ltering OFF.
If you wish to remove a rule, click on its trash can icon in the Delete column. If
you wish to edit a rule, click on its pencil icon in the Edit column. If you wish to
create a new rule, click the Add Rule button. Click Save when you are done. If
you edit or create a rule, the following options will appear:
Name: Enter a name for the rule.
Source IP Address
Range:
Destination IP
Address Range:
Protocol & Port
Range:
Schedule: Use the drop-down menu to select the time schedule that the rule
Enter the source IP address range that the rule will apply to, and using
the drop-down menu, specify whether it is a WAN or LAN IP address.
Enter the destination IP address range that the rule will apply to, and
using the drop-down menu, specify whether it is a WAN or LAN IP
address.
Select the protocol of the trac to allow or deny (Any, TCP, or UDP)
and then enter the range of ports that the rule will apply to.
will be enabled for. The schedule may be set to Always Enable, or
you can create your own schedules in the Schedules section. Refer
to Refer to Schedule on page 72 for more information.
Click Save when you are done.
63D-Link DIR-1360 User Manual
Section 4 - Conguration
Port Forwarding
Port forwarding allows you to specify a port or range of ports to open
for specic devices on the network. This might be necessary for certain
applications to connect through the router. In the Features menu on the bar
on the top of the page, click Port Forwarding.
If you wish to remove a rule, click on its trash can icon in the Delete column. If
you wish to edit a rule, click on its pencil icon in the Edit column. If you wish to
create a new rule, click the Add Rule button. Click Save when you are done. If
you edit or create a rule, the following options will appear:
Name: Enter a name for the rule.
Local IP: Enter the IP address of the computer on your local network that you
want to allow the incoming service to. Alternatively, select the device
from the drop-down menu.
TCP Port: Enter the TCP ports that you want to open. You can enter a single
port or a range of ports. Separate ports with a comma (for example:
24,1009,3000-4000).
UDP Port: Enter the UDP ports that you want to open. You can enter a single
port or a range of ports. Separate ports with a comma (for example:
24,1009,3000-4000).
Schedule: Use the drop-down menu to select the time schedule that the rule
will be enabled for. The schedule may be set to Always Enable, or
you can create your own schedules in the Schedules section. Refer
to Schedule on page 72 for more information.
Click Save when you are done.
64D-Link DIR-1360 User Manual
Section 4 - Conguration
Virtual Server
The virtual server allows you to specify a single public port on your router for
redirection to an internal LAN IP address and Private LAN port. To congure
the virtual server, from the Port Forwarding page click Virtual Server. To
return to the main Port Forwarding page, click Port Forwarding.
If you wish to remove a rule, click on its trash can icon in the Delete column. If
you wish to edit a rule, click on its pencil icon in the Edit column. If you wish to
create a new rule, click the Add Rules button. Click Save when you are done. If
you edit or create a rule, the following options will appear:
Name: Enter a name for the rule. Alternatively, select the protocol/Application
from the drop-down menu.
Local IP: Enter the IP address of the computer on your local network that you
want to allow the incoming service to. Alternatively, select the device
from the drop-down menu.
Protocol: Select the protocol of the trac to allow or deny (TCP, UDP, Both,
or Other).
Protocol Number: If you entered Other above, enter the protocol number.
External Port: Enter the public port you want to open.
Internal Port: Enter the private port you want to open.
Schedule: Use the drop-down menu to select the time schedule that the rule
will be enabled for. The schedule may be set to Always Enable, or
you can create your own schedules in the Schedules section. Refer
to Schedule on page 72 for more information.
Click Save when you are done.
65D-Link DIR-1360 User Manual
Section 4 - Conguration
Website Filter
The website lter settings allow you to block access to certain web sites. You
can either create a list of sites to block, or create a list of sites to allow (with all
other sites being blocked).
In the Features menu on the bar on the top of the page, click Website Filter.
If you want to create a list of sites to block, select DENY client access to ONLY
these sites from the drop-down menu. All other sites will be accessible. If you
want to specify a list of sites to allow, select ALLOW clients access to ONLY
these sites from the drop-down menu. All other sites will be blocked.
You may specify a maximum of twenty-four web sites. To add a new site to
the list, click Add Rule. Next, under Website URL/Domain enter the URL or
domain. If you wish to remove a rule, click on the corresponding trash can
icon in the Delete column. If you wish to edit a rule, simply replace the URL or
domain.
Click Save when you are done.
66D-Link DIR-1360 User Manual
Section 4 - Conguration
Static Routes
The Static Routes section allows you to dene custom routes to control how
data trac is moved around your network.
In the Features menu on the bar on the top of the page, click Static Route.
To congure IPv6 rules, click IPv6 and refer to IPv6 on page 68. To return to
the main IPv4 static routes page, click IPv4.
If you wish to remove a rule, click on the corresponding trash can icon in the
Delete column. If you wish to edit a rule, click on its pencil icon in the Edit
column. If you wish to create a new rule, click the Add Route button. Click
Save when you are done. If you edit or create a rule, the following options will
appear:
Name: Enter a name for the rule.
Destination
Network:
Mask: Enter the subnet mask of the route.
Gateway: Enter your next hop gateway to be taken if this route is used.
Metric: Enter a route metric value ranging from 0 to 15. This value indicates
Interface: Select the interface that the IP packet must use to transit out of the
Enter the IP address of packets that will take this route.
the cost of using this route.
router when this route is used.
Click Save when you are done.
67D-Link DIR-1360 User Manual
Section 4 - Conguration
IPv6
To congure IPv6 rules, on the Static Routes page click IPv6. To return to the
main IPv4 static routes page, click IPv4.
If you wish to remove a rule, click on its trash can icon in the Delete column. If
you wish to edit a rule, click on its pencil icon in the Edit column. If you wish to
create a new rule, click the Add Rules button. Click Save when you are done. If
you edit or create a rule, the following options will appear:
Name: Enter a name for the rule.
DestNetwork: This is the IP address of the router used to reach the specified
destination.
PrexLen: Enter the IPv6 address prex length of the packets that will take this
route.
Gateway: Enter your next hop gateway to be taken if this route is used.
Metric: Enter a route metric value ranging from 0 to 15. This value indicates
the cost of using this route.
Interface: Select the interface that the IP packet must use to transit out of the
router when this route is used.
Click Save when you are done.
68D-Link DIR-1360 User Manual
Section 4 - Conguration
Dynamic DNS
Most Internet Service Providers (ISPs) assign dynamic (changing) IP addresses.
Using a dynamic DNS service provider, people can enter your domain name in
their web browser to connect to your server no matter what your IP address is.
In the Features menu on the bar on the top of the page, click Dynamic DNS.
Enable Dynamic
DNS:
Status: Displays the current dynamic DNS connection status.
Server Address: Enter the address of your dynamic DNS server, or select one from the
Host Name: Enter the host name that you registered with your dynamic DNS
User Name: Enter your dynamic DNS username.
Password: Enter your dynamic DNS password.
Time Out: Enter a time out time (in hours).
Enable or disable dynamic DNS. Enabling this feature will reveal
further conguration options.
drop-down menu.
service provider.
Click Save when you are done.
At the bottom of the page are the IPv6 host settings. To congure an IPv6
dynamic DNS host, refer to IPv6 Host on page 70.
69D-Link DIR-1360 User Manual
Section 4 - Conguration
IPv6 Host
The IPv6 host settings are found at the bottom of the Dynamic DNS page.
If you wish to remove a rule, click on its trash can icon in the Delete column. If
you wish to edit a rule, click on its pencil icon in the Edit column. If you wish to
create a new rule, click the Add Record button. Click Save when you are done.
If you edit or create a rule, the following options will appear:
Host Name: Enter the host name that you registered with your dynamic DNS
service provider.
IPv6 Address: Enter the IPv6 address of the dynamic DNS server. Alternatively, select
the server device in the drop-down menu.
Click Save when you are done.
70D-Link DIR-1360 User Manual
Section 4 - Conguration
Management
Time & Schedule
Time
The Time page allows you to congure, update, and maintain the correct
time on the internal system clock. From here you can set the time zone, the
Network Time Protocol (NTP) server, and enable or disable daylight saving
time.
In the Management menu on the bar on the top of the page, click Time &
Schedule.
Time Conguration
Time Zone: Select your time zone from the drop-down menu.
Time: Displays the current date and time of the router.
Enable Daylight
Saving:
Automatic Time Conguration
Update Time
Using an NTP
Server:
To congure and manage your schedules, click Schedule and refer to
Schedule on page 72.
Enable or disable daylight saving time.
Enable or disable to allow an NTP server on the Internet to synchronize
the time and date with your router. If you enable this option, select
an NTP server from the drop-down menu. To congure the router's
time and date manually, disable this option and use the drop-down
menus that appear to input the time and date.
Click Save when you are done.
71D-Link DIR-1360 User Manual
Section 4 - Conguration
Schedule
Some router functions can be controlled through a pre-congured schedule.
To create, edit, or delete schedules, from the Time page click Schedule. To
return to the Time page, click Time.
If you wish to remove a rule, click on its trash can icon in the Delete column. If
you wish to edit a rule, click on its pencil icon in the Edit column. If you wish to
create a new rule, click the Add Rule button. Click Save when you are done. If
you edit or create a rule, the following screen will appear:
First, enter the name of your schedule in the Name eld.
Each box represents one hour, with the time at the top of each column. To add
a time period to the schedule, simply click on the starting hour and drag to the
ending hour. You can add multiple days to the schedule.
To remove a time period from the schedule, click on the X icon.
Click Save when you are done.
72D-Link DIR-1360 User Manual
Section 4 - Conguration
System Log
The router keeps a running log of events. This log can be sent to a Syslog
server, or sent to your email address. In the Management menu on the bar on
the top of the page, click System Log.
Log Settings
System Log Click the Check System Log button to download a text le containing
the system log.
SysLog Settings
Enable Logging to
Syslog Server:
If Logging to the Syslog Server is Enabled:
Syslog Server IP
Address:
Check this box to send the router logs to a SysLog Server.
Enter the IP address for the Syslog server. If the Syslog server is
connected to the extender, select it from the drop-down menu to
automatically populate the eld.
Email Settings
Enable E-mail
Notication:
If E-mail notication is Enabled:
From E-mail
Address:
To E-mail Address: Enter the email address your SysLog messages will be sent to.
SMTP Server
Address:
Enable this option if you want the logs to be automatically sent to
an email address.
Enter the email address your SysLog messages will be sent from.
Enter your SMTP server address.
73D-Link DIR-1360 User Manual
Section 4 - Conguration
SMTP Server Port: Enter your SMTP server port.
System Log (continued)
Enable
Authentication:
Account Name: Enter your SMTP account name.
Password: Enter your SMTP account's password
Check this box if your SMTP server requires authentication.
E-mail Log When Full or On Schedule
Send When Log
Send on Schedule: If enabled, this option will set the router to send according to a set
Schedule: If you enable Send On Schedule, use the drop-down menu to select
If enabled, this option will set the router to send the log when it is full.
Full:
schedule.
a schedule to apply. The schedule may be set to Always Enable, or
you can create your own schedules in the Schedules section. Refer
to Schedule on page 72 for more information.
Click Save when you are done.
74D-Link DIR-1360 User Manual
Section 4 - Conguration
System Admin
This page will allow you to change the administrator (Admin) password and
enable remote management. In the Management menu on the bar on the top
of the page, click System Admin. To load, save, reset settings, or reboot the
router, click System and refer to Schedule on page 72.
Admin Password
Password: Enter a new password for the administrator account. You will need to
enter this password whenever you congure the router using a web
browser.
Enable Graphical
Authentication
(CAPTCHA):
Enables a challenge-response test to require users to type letters or
numbers from a distorted image displayed on the screen to prevent
online hackers and unauthorized users from gaining access to your
router’s network settings.
Advanced Settings - Administration
Enable HTTPS
Server:
Enable Remote
Management:
Remote Admin
Port:
Check to enable HTTPS to connect to the router securely. Instead of using
http://dlinkrouter.local./, you must use https://dlinkrouter.local./ in
order to connect to the router.
Remote management allows the DIR-1360 to be congured from the
Internet by a web browser. A password is still required to access the web
management interface.
The port number used to access the DIR-1360 is used in the URL. Example:
http://x.x.x.x:8080 where x.x.x.x is the WAN IP address of the DIR-1360
and 8080 is the port used for the web management interface.
Note: If you enabled Use HTTPS and wish to access the router remotely and
securely, you must enter https:// at the beginning of the address.
Click Save when you are done.
75D-Link DIR-1360 User Manual
Section 4 - Conguration
System
This page allows you to save the router’s current conguration, load a
previously saved conguration, reset the router to its factory default settings,
or reboot the router.
From the Admin page, click System. To return to the Admin page, click Admin.
System
Save Settings To
Local Hard Drive:
Load Settings
From Local Hard
Drive:
Restore To Factory
Default Settings:
This option will save the current router conguration settings to a le
on your computer.
This option will load a previously saved router conguration le. This will
overwrite the router’s current conguration.
This option will restore all conguration settings back to the settings that
were in eect at the time the router was shipped from the factory. Any
settings that have not been saved will be lost, including any rules that
you have created. If you want to save the current router conguration
settings, use the Save Settings To Local Hard Drive button above.
Auto Reboot Conguration
Reboot The
Device:
Auto Reboot: You may set the DIR-1360 to automatically reboot at a set time. The
Click to reboot the router immediately.
options are Never, Daily, Weekly. You may set the hour using a 24
hour format, the minute, and the day you wish to have the DIR-1360
automatically reboot.
Click Save when you are done.
76D-Link DIR-1360 User Manual
Section 4 - Conguration
Upgrade
This page will allow you to upgrade the router’s rmware, either automatically
or manually. To manually upgrade the rmware, you must rst download the
relevant le from http://support.dlink.com.
In the Management menu on the bar on the top of the page, click Upgrade.
Firmware Information
Current Firmware
Version/Date :
Check for New
Firmware:
Upgrade Manually
Upgrade
Firmware:
The current rmware's version and date will be displayed.
Click this button to prompt the router to automatically check for a new
rmware version. If a newer version is found, it will prompt you to install it.
If you wish to upgrade manually, rst download the rmware le you wish
to upgrade to. Next, click the Upgrade Firmware button and browse to
the le to install the new rmware. You can also browse to a language
pack le to install a new language pack.
77D-Link DIR-1360 User Manual
Section 4 - Conguration
Statistics
On the Statistics page you can view the amount of packets that pass through
the router on the WAN, LAN, and wireless segments.
In the Management menu on the bar on the top of the page, click Statistics.
You can view the Internet, LAN, Wi-Fi 2.4 GHz, or Wi-Fi 5 GHz by clicking on
the respective tabs at the top. The graph will update in real time. To clear the
information on the graph, click Clear.
The trac counter will reset if the device is rebooted.
78D-Link DIR-1360 User Manual
Section 6- Connecting a Wireless Client
Connect a Wireless Client to your Router
WPS Button
The easiest and most secure way to connect your wireless devices to the router is with WPS (Wi-Fi Protected Setup). Most
wireless devices such as wireless adapters, media players, Blu-ray DVD players, wireless printers and cameras will have a WPS
button (or a software utility with WPS) that you can press to connect to the DIR-1360 router. Please refer to your user manual
for the wireless device you want to connect to make sure you understand how to enable WPS. Once you know, follow the steps
below:
Step 1 - Press the WPS button on the DIR-1360 for about 1 second. The LED on the front will start to blink.
WPS Button
Step 2 - Within 2 minutes, press the WPS button on your wireless device (or launch the software utility and start the WPS
process).
Step 3 - Allow up to 1 minute for your connection to be congured. Once the Internet light stops blinking, you will be
connected and your wireless connection will be encrypted with WPA2.
79D-Link DIR-1360 User Manual
Section 6- Connecting a Wireless Client
Windows® 10
When connecting to the DIR-1360 wirelessly for the rst time, you will need to input the wireless network name (SSID) and
Wi-Fi password (security key) of the device you are connecting to. If your product has a Wi-Fi conguration card, you can
nd the default network name and Wi-Fi password here. Otherwise refer to the product label for the default Wi-Fi network
SSID and password, or enter the Wi-Fi credentials set during the product conguration.
To join an existing network, locate the wireless network icon in the taskbar,
next to the time display and click on it.
Wireless Icon
Clicking on this icon will display a list of wireless networks which are within
range of your computer. Select the desired network by clicking on the SSID.
80D-Link DIR-1360 User Manual
Section 6- Connecting a Wireless Client
To connect to the SSID, click Connect.
To automatically connect with the router when your device next detects the
SSID, click the Connect Automatically check box.
You will then be prompted to enter the Wi-Fi password (network security key)
for the wireless network. Enter the password into the box and click Next to
connect to the network. Your computer will now automatically connect to this
wireless network when it is detected.
You can also use Wi-Fi Protected Setup (WPS) to connect to the router.
Press the WPS button on your D-Link device and you will be automatically
connected.
81D-Link DIR-1360 User Manual
Section 6- Connecting a Wireless Client
Windows® 8
WPA/WPA2
It is recommended that you enable wireless security (WPA/WPA2) on your wireless router or access point before conguring
your wireless adapter. If you are joining an existing network, you will need to know the security key (Wi-Fi password) being
used.
To join an existing network, locate the wireless network icon in the taskbar
next to the time display.
Wireless Icon
Clicking on this icon will display a list of wireless networks that are within
connecting proximity of your computer. Select the desired network by clicking
on the network name.
82D-Link DIR-1360 User Manual
Section 6- Connecting a Wireless Client
You will then be prompted to enter the network security key (Wi-Fi password)
for the wireless network. Enter the password into the box and click Next.
If you wish to use Wi-Fi Protected Setup (WPS) to connect to the router, you
can also press the WPS button on your router during this step to enable the
WPS function.
When you have established a successful connection to a wireless network, the
word Connected will appear next to the name of the network to which you
are connected to.
83D-Link DIR-1360 User Manual
Section 6- Connecting a Wireless Client
Windows® 7
WPA/WPA2
It is recommended that you enable wireless security (WPA/WPA2) on your wireless router or access point before conguring
your wireless adapter. If you are joining an existing network, you will need to know the security key or passphrase being used.
Click on the wireless icon in your system tray (lower-right corner).
Wireless Icon
The utility will display any available wireless networks in your area.
84D-Link DIR-1360 User Manual
Section 6- Connecting a Wireless Client
Highlight the wireless connection with Wi-Fi name (SSID) you would like to
connect to and click the Connect button.
If you get a good signal but cannot access the Internet, check your TCP/IP
settings for your wireless adapter. Refer to the Networking Basics section in
this manual for more information.
The following window appears while your computer tries to connect to the
router.
85D-Link DIR-1360 User Manual
Section 6- Connecting a Wireless Client
Enter the same security key or passphrase (Wi-Fi password) that is on your
router and click Connect. You can also connect by pushing the WPS button on
the router.
It may take 20-30 seconds to connect to the wireless network. If the
connection fails, please verify that the security settings are correct. The key or
passphrase must be exactly the same as the one on the wireless router.
86D-Link DIR-1360 User Manual
Section 6- Connecting a Wireless Client
WPS
The WPS feature of the DIR-1360 can be congured using Windows® 7. Carry out the following steps to use Windows® 7 to
congure the WPS feature:
Click the Start button and select Computer from the Start menu.
Click Network on the left side.
87D-Link DIR-1360 User Manual
Section 6- Connecting a Wireless Client
Double-click the DIR-1360.
Input the WPS PIN number (on the router label) in the Setup > Wireless Setup
menu in the Router’s Web UI) and click Next.
DIR-1360
88D-Link DIR-1360 User Manual
Section 6- Connecting a Wireless Client
Type a name to identify the network.
To congure advanced settings, click the
Click Next to continue.
icon.
89D-Link DIR-1360 User Manual
Section 6- Connecting a Wireless Client
The following window appears while the DIR-1360 is being congured.
Wait for the conguration to complete.
The following window informs you that WPS on the DIR-1360 has been set up
successfully.
Make a note of the security key as you may need to provide this security key if
adding an older wireless device to the network in the future.
Click Close to complete WPS setup.
90D-Link DIR-1360 User Manual
Section 6- Connecting a Wireless Client
Windows Vista®
Windows Vista® users may use the built-in wireless utility. If you are using another company’s wireless utility, please refer to the
user manual of your wireless adapter for help connecting to a wireless network. Most wireless utilities will have a “site survey”
option similar to the Windows Vista® utility as seen below.
If you receive the Wireless Networks Detected bubble, click on the center of
the bubble to access the utility.
or
Right-click on the wireless computer icon in your system tray (lower-right
corner next to the time). Select Connect to a network.
The utility will display any available wireless networks in your area. Click on a
network (displayed using the SSID) and click the Connect button.
If you get a good signal but cannot access the Internet, check you TCP/IP
settings for your wireless adapter. Refer to the Networking Basics section in
this manual for more information.
91D-Link DIR-1360 User Manual
Section 6- Connecting a Wireless Client
WPA/WPA2
It is recommended that you enable wireless security (WPA/WPA2) on your wireless router or access point before conguring
your wireless adapter. If you are joining an existing network, you will need to know the security key or passphrase being used.
Open the Windows Vista® Wireless Utility by right-clicking on the wireless
computer icon in your system tray (lower right corner of screen). Select
Connect to a network.
Highlight the Wi-Fi name (SSID) you would like to connect to and click
Connect.
92D-Link DIR-1360 User Manual
Section 6- Connecting a Wireless Client
Enter the same security key or passphrase (Wi-Fi password) that is on your
router and click Connect.
It may take 20-30 seconds to connect to the wireless network. If the
connection fails, please verify that the security settings are correct. The key or
passphrase must be exactly the same as the one on the wireless router.
93D-Link DIR-1360 User Manual
Section 7 - Troubleshooting
Troubleshooting
This chapter provides solutions to problems that can occur during the installation and operation of the DIR-1360. Read the
following descriptions if you are having problems. The examples below are illustrated in Windows® XP. If you have a dierent
operating system, the screenshots on your computer will look similar to these examples.
1. Why can’t I access the web-based conguration utility?
When entering the IP address of the D-Link router (192.168.0.1 for example), you are not connecting to a website, nor do you
have to be connected to the Internet. The device has the utility built-in to a ROM chip in the device itself. Your computer must
be on the same IP subnet to connect to the web-based utility.
• Make sure you have an updated Java-enabled web browser. We recommend the following:
- Microsoft Internet Explorer® 10 or higher
- Mozilla Firefox 28 or higher
- Google™ Chrome 28 or higher
- Apple Safari 6 or higher
• Verify physical connectivity by checking for solid link lights on the device. If you do not get a solid link light, try using a
dierent cable, or connect to a dierent port on the device if possible. If the computer is turned o, the link light may not be
on.
• Disable any Internet security software running on the computer. Software rewalls such as ZoneAlarm, BlackICE, Sygate,
®
Norton Personal Firewall, and Windows
included with your rewall software for more information on disabling or conguring it.
XP rewall may block access to the conguration pages. Check the help les
94D-Link DIR-1360 User Manual
Section 7 - Troubleshooting
• Congure your Internet settings:
• Go to Start > Settings > Control Panel. Double-click the Internet Options Icon. From the Security tab, click
the button to restore the settings to their defaults.
• Click the Connection tab and set the dial-up option to Never Dial a Connection. Click the LAN Settings button.
Make sure nothing is checked. Click OK.
• Go to the Advanced tab and click the button to restore these settings to their defaults. Click OK three times.
• Close your web browser (if open) and open it.
• Access the web management. Open your web browser and enter the IP address of your D-Link router in the address bar. This
should open the login page for your web management.
• If you still cannot access the conguration, unplug the power to the router for 10 seconds and plug back in. Wait about 30
seconds and try accessing the conguration. If you have multiple computers, try connecting using a dierent computer.
2. What can I do if I forgot my password?
If you forgot your password, you must reset your router. This process will change all your settings back to the factory defaults.
To reset the router, locate the reset button (hole) on the rear panel of the unit. With the router powered on, use a paperclip
to hold the button down for 10 seconds. Release the button and the router will go through its reboot process. Wait about 30
seconds to access the router. The default IP address is 192.168.0.1. When logging in, leave the password box empty.
95D-Link DIR-1360 User Manual
Section 7 - Troubleshooting
3. Why can’t I connect to certain sites or send and receive emails when connecting through my router?
If you are having a problem sending or receiving email, or connecting to secure sites such as eBay, banking sites, and Hotmail,
we suggest lowering the MTU in increments of ten (Ex. 1492, 1482, 1472, etc).
To nd the proper MTU Size, you’ll have to do a special ping of the destination you’re trying to go to. A destination could be
another computer, or a URL.
• Click on Start and then click Run.
• Windows® 95, 98, and Me users type in command (Windows® NT, 2000, XP, Vista®, and 7 users type in cmd) and
press Enter (or click OK).
• Once the window opens, you’ll need to do a special ping. Use the following syntax:
ping [url] [-f] [-l] [MTU value]
Example: ping yahoo.com -f -l 1472
96D-Link DIR-1360 User Manual
Loading...
