D-Link COVR-3902 User Manual
Version 1.01 | 2016/06/03
HIGH PERFORMANCE MORE COVERAGE
Covr your Whole Home in High-Power Wi-Fi
AC3900 WHOLE HOME WI-FI SYSTEM
User Manual
ONE SEAMLESS
NETWORK
COVR-3902
USER MANUAL
Preface
D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any
person or organization of such revisions or changes.
Manual Revisions
Revision Date Description
1.00 July 27, 2017 Initial release.
Trademarks
D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries.
All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies.
Apple®, Apple logo®, Safari®, iPhone®, iPad®, iPod touch® and Macintosh® are trademarks of Apple Inc., registered in the U.S. and other countries.
App Store
Chrome™ browser, Google Play™ and Android™ are trademarks of Google Inc.
SM
is a service mark of Apple Inc.
Internet Explorer®, Windows® and the Windows logo are trademarks of the Microsoft group of companies.
Copyright © 2017 by D-Link Corporation, Inc.
All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written permission from D-Link Corporation, Inc.
Power Usage
This device is an Energy Related Product (ErP) with High Network Availability (HiNA), and automatically switches to a power-saving Network
Standby mode within 1 minute of no packets being transmitted. It can also be turned o through a power switch to save energy when it is not
needed.
COVR-2600R COVR-1300E
Network Standby: 6.41 watts Network Standby: 3.92 watts
Switched O: 0.06 watts Switched O: 0.05 watts
iD-Link COVR-3902 User Manual
Table of Contents
Table of Contents
Product Overview ..............................................................1
Package Contents .........................................................................1
System Requirements ................................................................. 2
Introduction ................................................................................... 3
Features ............................................................................................3
Hardware Overview .....................................................................5
COVR-2600R LED Indicators ..............................................5
COVR-1300E LED Indicators .............................................. 6
COVR-2600R Back Panel ..................................................... 7
COVR-2600R Front Panel .................................................... 8
COVR-1300E Back Panel ..................................................... 9
COVR-1300E Side Panel ....................................................10
Installation ....................................................................... 11
Before you Begin .........................................................................12
Wireless Installation Considerations ....................................13
Hardware Setup ..........................................................................14
Completing Setup ......................................................................16
D-Link Wi-Fi App .................................................................17
Web Interface Setup Wizard ...........................................24
Settings ..........................................................................................38
Wizard .....................................................................................38
Internet ...................................................................................38
IPv6 .....................................................................................48
Wireless ..................................................................................68
Guest Zone .......................................................................70
Network ..................................................................................71
USB Sharing ..........................................................................73
Features ..........................................................................................74
QoS Engine............................................................................74
Firewall ...................................................................................75
IPv4/IPv6 Rules ...............................................................77
Port Forwarding ..................................................................78
Virtual Server ................................................................... 79
Website Filter ........................................................................80
Static Routes .........................................................................81
IPv6 .....................................................................................82
Dynamic DNS .......................................................................83
IPv6 Host ...........................................................................84
Quick VPN ..............................................................................85
Conguration - COVR-2600R ..........................................31
Home ..............................................................................................32
Internet ...................................................................................32
COVR-2600R ..........................................................................33
Connected Clients ..............................................................34
Extenders ...............................................................................36
USB Device ............................................................................37
Management ................................................................................87
Time & Schedule .................................................................87
Time ....................................................................................87
Schedule ...........................................................................88
System Log ............................................................................89
System Admin ......................................................................91
System ...............................................................................92
iiD-Link COVR-3902 User Manual
Table of Contents
Upgrade .................................................................................93
Statistics .................................................................................94
Conguration - COVR-1300E ..........................................95
System ...............................................................................96
Upgrade ............................................................................97
Statistics ............................................................................98
Quick VPN .........................................................................99
Important Information .......................................................... 100
Quick VPN Server Setup Instructions ............................... 101
iOS Devices ................................................................................ 102
Mac OS X ..................................................................................... 106
Windows 7 ..................................................................................109
Windows 8.1/8 .......................................................................... 113
Windows 10 ............................................................................... 119
Android ....................................................................................... 122
Connect a Wireless Client to your Router ....................126
WPS Button ................................................................................126
Wireless Basics ...............................................................127
What is Wireless? ...................................................................... 128
Tips ................................................................................................130
Technical Specications ................................................131
Regulatory Statements - COVR-2600R ......................... 134
Regulatory Statements - COVR-1300E .........................154
iiiD-Link COVR-3902 User Manual
Section 1 - Product Overview
Product Overview
Package Contents
Ethernet Cable x 1COVR-2600R AC2600 Wi-Fi Router
Detachable Antenna x 4COVR-1300E AC1300 Wi-Fi Range Extender
Quick Installation GuidePower Adapter x 2
Wi-Fi Conguration Note
Wi-Fi Conguration Card
If any of the above items are missing or damaged, please contact your local reseller.
Note: Using a power supply with a dierent voltage rating than the one included with the COVR-3902 will cause damage and void the
warranty for this product.
1D-Link COVR-3902 User Manual
Section 1 - Product Overview
Network Requirements
Web-based Conguration
Utility Requirements
System Requirements
• An Ethernet-based cable or DSL modem
• IEEE 802.11ac/n/g/b/a wireless clients
• 10/100/1000 Ethernet
Computer with the following:
• Windows®, Macintosh, or Linux-based operating system
• An installed Ethernet adapter
Browser Requirements:
• Internet Explorer 10 or higher
• Firefox 28 or higher
• Safari 6 or higher
• Chrome 28 or higher
D-Link Wi-Fi Requirements
Windows
installed. Visit www.java.com to download the latest version.
• iPhone®/iPad®/iPod touch®, Android™, or Windows smartphone
or tablet. (Please refer to the mobile app's store page to check
whether your device is compatible)
®
Users: Make sure you have the latest version of Java
2D-Link COVR-3902 User Manual
Section 1 - Product Overview
Introduction
The COVR-3902 Covr Wi-Fi System is a revolutionary wireless networking solution comprised of the COVR-2600R AC2600 Wi-Fi Router
and COVR-1300E AC1300 Wi-Fi Range Extender. The Covr Wi-Fi System uses a high-power Wi-Fi router at its core to oer a “PowrZone” of
1
blazing fast 2533 Mbps
as you move through your home for up to 6,000 sq. ft of seamless whole home coverage. With the COVR-3902, D-Link has got you Covr’d.
Wi-Fi, while the Covr Seamless Extender takes care of the outer edge. Automatically connect to the strongest signal
Features
• High-Power Wi-FI - The COVR-3902 features a high-power AC2600 router oering blazing-fast wireless speeds
of up to a combined 2533 Mbps (1732 Mbps 802.11ac 5 GHz, plus 800 Mbps 802.11n 2.4 GHz)1 combined with
the AC1300 seamless extender to bring high-performance Wi-Fi to the hard-to-reach places in your home.
COVR-3902 provides you with the speed you need to fully enjoy data-intensive activities such as 4K video
steaming and online gaming.
• Smart Roaming - The Covr Wi-Fi System creates a single, seamless wireless network throughout your entire
home using a single wireless network name (SSID). This means that once you connect, your connection
is maintained seamlessly as you and your wireless device roam throughout your home, allowing you to
experience an uninterrupted connection without buering, drop-outs or dead spots.
• 4 x 4 MU-MIMO Technology - Multi-User MIMO (MU-MIMO) sends and receives data to and from multiple
devices simultaneously to increase speed and eciency. Your laptop, tablet, media player and game console
can all be sending and receiving data at the same time, with no need to wait in turn, allowing you to get more
out of your home Wi-Fi network than ever before.
1
Maximum wireless signal rate derived from IEEE Standard 802.11a, 802.11g, 802.11n and 802.11ac specications. Actual data throughput will vary. Network conditions and
environmental factors, including volume of network trac, building materials and construction, and network overhead, lower actual data throughput rate. Environmental
conditions will adversely aect wireless signal range.
3D-Link COVR-3902 User Manual
Section 1 - Product Overview
• Smart Steering - Behind the scenes, the COVR-3902 automatically determines whether to connect a device to
the 2.4 or 5 GHz band, thereby providing the best speed and range for each device and optimally distributing
devices to each network.
• Expandable Network - Covr’s Wi-Fi System is pre-paired and works straight out of the box, so you just need to
plug them in and get started. Covr is also a scalable solution; extra extenders can be added to increase the reach
of your network. Scale up your Wi-Fi by adding another extender to get true whole-home coverage.
• Easy Setup - Through its intuitive web-based user interface or the free D-Link Wi-Fi app, you can quickly set up
the COVR-3902 and congure your network to your specic settings in a matter of minutes.
Features (continued)
4D-Link COVR-3902 User Manual
Section 1 - Product Overview
Hardware Overview
COVR-2600R LED Indicators
3 5421
1
2
3
4
5
Wireless (2.4 GHz LED) A solid green light indicates that the 2.4 GHz wireless band is enabled.
Power LED
Internet LED
Wireless (5 GHz LED) A solid green light indicates that the 5 GHz wireless band is enabled.
USB LED A solid green light indicates a USB storage device is connected to the USB 3.0 port on the front of the router.
A solid green light indicates a proper connection to the power supply. The light will be solid orange during
boot up.
A solid green light indicates a connection on the Internet port. If the LED is orange, the router cannot connect
to the Internet.
5D-Link COVR-3902 User Manual
Section 1 - Product Overview
COVR-1300E LED Indicators
3 5421
1
2
3
4
5
2.4 GHz Downlink LED A solid green light indicates that the 2.4 GHz wireless downlink connection is established.
Power LED
2.4 GHz Uplink LED A solid green light indicates that the 2.4 GHz wireless uplink connection is established.
5 GHz Uplink LED A solid green light indicates that the 5 GHz wireless uplink connection is established.
5 GHz Downlink LED A solid green light indicates that the 5 GHz wireless downlink connection is established.
A solid green light indicates a proper connection to the power supply. The light will be solid orange during
boot up.
6D-Link COVR-3902 User Manual
Section 1 - Product Overview
COVR-2600R Back Panel
4 5 6 731 2
1 Power Connector Connector for the supplied power adapter.
2 Power Button Press the power button to power the device on or o.
3 INTERNET Port Using an Ethernet cable, connect your broadband modem to this port.
4 Gigabit LAN Ports (1- 4) Connect Ethernet devices such as computers, switches, storage (NAS) devices, and game consoles.
5 WPS Button Press to start the WPS process and automatically create an encrypted connection to a WPS client.
6 Reset Button Insert a paper clip into the hole, wait for 10 seconds, and release to reset the router to default settings.
7 Wi-Fi Button Press this button turn o or turn on the wireless networks.
7D-Link COVR-3902 User Manual
Section 1 - Product Overview
COVR-2600R Front Panel
1 USB 3.0 Port Connect a USB storage device to share les over the network.
1
8D-Link COVR-3902 User Manual
Section 1 - Product Overview
COVR-1300E Back Panel
2 3 4 51
1 Reset Button Insert a paper clip into the hole, wait for 10 seconds, and release to reset the router to default settings.
2 Wi-Fi Button Press this button turn o or turn on the wireless networks.
3 Gigabit LAN Ports Connect Ethernet devices such as computers, switches, storage (NAS) devices, and game consoles.
4 Power Button Press the power button to power the device on or o.
5 Power Input Connector for the supplied power adapter.
9D-Link COVR-3902 User Manual
Section 1 - Product Overview
COVR-1300E Side Panel
1
1 WPS Button Press to start the WPS process and automatically create an encrypted connection to a wireless client.
10D-Link COVR-3902 User Manual
Section 2 - Installation
Installation
This section will walk you through the installation of the COVR-3902. During the setup procedure, your Internet connection will
be temporarily unavailable, until the setup process is completed.
Note: If you will be setting up the COVR-3902 AC3900 Whole Home Wi-Fi System on your mobile device using the free D-Link
Wi-Fi app, you must download this app before beginning the installation process.
To get the D-Link Wi-Fi app, browse the App Store for Apple devices or the Google Play store and search for D-Link Wi-Fi. You
can also scan the QR code below, which will take you to the respective D-Link Wi-Fi app store page directly.
D-Link Wi-Fi
11D-Link COVR-3902 User Manual
Section 2 - Installation
Before you Begin
• Placement of the router is very important. Do not place the router in an enclosed area such as a closet, cabinet,
attic, or garage.
• Congure the router with the computer that was last connected directly to your Internet connection. Verify that it
is connected to the Internet before connecting additional devices.
• If your ISP provided you with a modem/router combo, you will need to set it to “bridge” mode so the router can
work properly. Please contact your ISP or refer to the user manual for your modem/router device.
• You can only use the Ethernet port on your modem. If you were using the USB connection before using the router,
then you must turn o your modem, disconnect the USB cable and connect an Ethernet cable to the Internet
port on the router, and then turn the modem back on. In some cases, you may need to call your Internet Service
Provider (ISP) to change connection types (USB to Ethernet).
• If connecting to a DSL modem, make sure to have your DSL service information provided by your Internet Service
Provider handy. This information is likely to include your DSL account's Username and Password. Your ISP may also
supply you with additional WAN conguration settings which might be necessary to establish a connection.
• If you are connecting a considerable amount of networking equipment, it may be a good idea to take the time to
label each cable or take a picture of your existing setup before making any changes.
• If you have DSL and are connecting via PPPoE, make sure you disable or uninstall any PPPoE software such as
WinPoET, BroadJump, or EnterNet 300 from your computer or you will not be able to connect to the Internet.
12D-Link COVR-3902 User Manual
Section 2 - Installation
Wireless Installation Considerations
The D-Link wireless router lets you access your network using a wireless connection from virtually anywhere within the
operating range of your wireless network. Keep in mind that the number, thickness and location of walls, ceilings, or other
objects that the wireless signals must pass through may limit the range. Typical ranges vary depending on the types of
materials and background RF (radio frequency) noise in your home or business. The key to maximizing wireless range is to
follow these basic guidelines:
1. Keep the number of walls and ceilings between the D-Link router and other network devices to a minimum -
each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position your devices so that
the number of walls or ceilings is minimized.
2. Be aware of the direct line between network devices. A wall that is 1.5 feet thick (0.5 meters), at a 45-degree
angle appears to be almost 3 feet (1 meter) thick. At a 2-degree angle it looks over 42 feet (14 meters) thick!
Position devices so that the signal will travel straight through a wall or ceiling (instead of at an angle) for better
reception.
3. Building materials make a dierence. A solid metal door or aluminum studs may have a negative eect on
range. Try to position access points, wireless routers, and computers so that the signal passes through drywall or
open doorways. Materials and objects such as glass, steel, metal, walls with insulation, water (sh tanks), mirrors,
le cabinets, brick, and concrete will degrade your wireless signal.
4. Keep your product away (at least 3-6 feet or 1-2 meters) from electrical devices or appliances that generate RF
noise.
5. If you are using 2.4 GHz cordless phones or X-10 (wireless products such as ceiling fans, lights, and home
security systems), your wireless connection may degrade dramatically or drop completely. Make sure your 2.4
GHz phone base is as far away from your wireless devices as possible. The base transmits a signal even if the
phone is not in use.
13D-Link COVR-3902 User Manual
Section 2 - Installation
115°
3
SWSW
V...
5A
SW
F
3
SWSW
V...
5A
SW
F
Hardware Setup
1. Attach the four included antennas to the sides and back of the router. The COVR-3902 system is designed to give you
the fastest, most stable network connection possible. In order to maximize performance, fully extend the side antennas
into a 45-degree angle and the rear antennas into a 90-degree angle to provide optimal wireless coverage. Keep the
router in an open area for better wireless coverage.
45
2. Position your COVR-2600R router near your Internet-connected modem. Place it in an open area for better wireless
coverage.
COVR-2600R
POWER1
3
1
E
i
Modem
3. Connect the supplied power adapter to the router and a power outlet, press the power button, and wait approximately
one minute until the Power and 2.4 GHz/5 GHz LED indicators on the front of the device are lit solid green.
COVR-2600R
3
1
E
POWER1
i
Modem
14D-Link COVR-3902 User Manual
Section 2 - Installation
4321INTERNETRESE
TWP
SW
i
2
V...
5A
+
+
SW
F
4321INTERNETRESE
TWP
SW
i
2
V...
5A
+
+
SW
4. If you are conguring the COVR-2600R wirelessly from a PC, connect to the Wi-Fi network printed on the included
Wi-Fi Conguration Card. You can also nd the Wi-Fi network name and password printed on the label attached to the
bottom of your router.
COVR-2600R
Modem
Wi-Fi Conguration Note
3
POWER1
i
If you are conguring the COVR-2600R from a PC with a wired Ethernet connection, plug one end of an Ethernet
cable into the LAN port labeled 1 on the back of the router, and the other end into the Ethernet port on your computer.
COVR-2600R
POWER1
3
i
Modem
Note: This unit is to be used with the included 12 V/3 A power supply.
The COVR-3902 is now ready to be congured using either the web-based user interface, or the free D-Link Wi-Fi
mobile app. Proceed to Completing Setup on page 16 for more information on how to complete the setup
process.
15D-Link COVR-3902 User Manual
Section 2 - Installation
Completing Setup
There are several dierent ways you can congure your router to connect to the Internet and connect to your clients:
• D-Link Wi-Fi App - Use your Android device, iPhone, iPad, or iPod touch to congure your router.
Refer to D-Link Wi-Fi App on page 17.
• D-Link Setup Wizard - This wizard will launch when you log into the router's web-based user interface for the rst time.
Refer to Web Interface Setup Wizard on page 24.
• Manual Setup - Log in to the router and manually congure your router.
Refer to Conguration on page 31.
16D-Link COVR-3902 User Manual
Section 2 - Installation
D-Link Wi-Fi App
The D-Link Wi-Fi app allows you to install and congure your COVR-3902
AC3900 Whole Home Wi-Fi System from your mobile device.
Note: The screenshots may be dierent depending on your mobile device’s OS
version. The following steps show the iOS interface of the D-Link Wi-Fi app. If
you are using an Android device, the appearance may be dierent from that of
the screenshots, but the process is the same.
D-Link Wi-Fi
17D-Link COVR-3902 User Manual
Section 2 - Installation
D-Link Wi-Fi App (continued)
Step 1
Open the D-Link Wi-Fi app and tap Add Device.
Step 2
You will be instructed to connect your mobile device to your Covr Wi-Fi
network. The default network name (SSID) and password can be found on the
included Wi-Fi Conguration Card and on the sticker on the base of the router,
and will look something like dlink-XXXX. Once connected, return to the D-Link
Wi-Fi app and tap NEXT.
18D-Link COVR-3902 User Manual
Section 2 - Installation
D-Link Wi-Fi (continued)
Step 3
Plug in the COVR-1300E Extender next to the Covr Router and wait
approximately 120 seconds for the Extender to boot up. If the Extender is
powered on, tap Next.
Step 4
When your Covr Extender was successfully detected, a message will appear to
conrm. Tap Next to continue.
19D-Link COVR-3902 User Manual
Section 2 - Installation
D-Link Wi-Fi (continued)
Step 5
The D-Link Wi-Fi app will search for your Covr Whole Home Wi-Fi System. Once
found, it will display the product details on the screen. Tap Next to continue.
Step 6
Connect the Ethernet cable from your broadband modem to the yellow
INTERNET port on the back of the Covr router and follow the on-screen
instructions to set up your Internet connection. Tap Next.
20D-Link COVR-3902 User Manual
Section 2 - Installation
D-Link Wi-Fi (continued)
Step 7
Create a Network Name (SSID) and password for your Covr Whole Home
Network and tap Next.
Step 8
Specify an administrator password for your Covr System (note that this should
not be the same as your Wi-Fi network password congured in the previous
step) and tap Next.
21D-Link COVR-3902 User Manual
Section 2 - Installation
D-Link Wi-Fi (continued)
Step 9
A summary of your network’s conguration will be displayed. Tap SAVE to
complete the setup process.
Step 10
Unplug the Covr Extender and place it anywhere in your home where the
Wi-Fi signal is weak. For optimal performance, make sure all ve LEDs on the
Extender are solid green. If they are not, place the Extender closer to the router
until they do.
22D-Link COVR-3902 User Manual
Section 2 - Installation
D-Link Wi-Fi (continued)
Step 11
Your Covr Wi-Fi System is now congured and ready to use. You can now
connect to the Covr Wi-Fi network listed in the overview. Tap Finish to close
the wizard and complete the setup.
23D-Link COVR-3902 User Manual
Section 2 - Installation
Web Interface Setup Wizard
If this is your rst time installing the router, open your web browser and enter
http://covr.local./ in the address bar. Alternatively, enter the IP address of the
router (default: http://192.168.0.1).
The wizard is designed to guide you through a step-by-step process to congure
your new D-Link router and connect to the Internet.
You can change the language of the setup wizard by selecting a language from
the drop-down menu in the lower left.
Click Next to continue.
Step 1
Plug in the Covr Extender next to the Covr Router and wait approximately 120
seconds for the Extender to boot up. When the Extender is powered on, click
Next to continue.
24D-Link COVR-3902 User Manual
Section 2 - Installation
Setup Wizard (continued)
Step 2
If the Covr Extender could not be detected, click Retry to manually pair the
Extender to the Router using WPS (see Step 3 below), or click Skip Covr Setup
to skip adding the Extender and continue conguring the router settings.
Step 3
If the system failed to detect the Covr Extender in the previous step and you
clicked Retry, you can use WPS to manually pair the devices. Press the WPS
button on the left side panel of the Extender within the time limit displayed
on the screen. If done correctly, all four wireless LEDs on the Extender will start
to ash. If successful, the wizard will automatically continue to the next step.
If pairing through WPS also fails to detect the Extender, try resetting the
Extender by holding down the reset button on the back of the device for
roughly 10 seconds using an unfolded paper clip. Once reset, run the Setup
Wizard again.
25D-Link COVR-3902 User Manual
Section 2 - Installation
Setup Wizard (continued)
Step 4
A message will appear to conrm the Covr Extender was successfully detected
and synced to the Covr Router. Click Next to continue.
Step 5
Using an Ethernet cable, connect the yellow port on the back of the Covr Router
labeled INTERNET to your modem. Click Next to continue.
The Covr Router will now detect your Internet connection. If your Internet
connection was successfully auto-detected, continue to the Step 9. If your
connection was not automatically detected, refer to the following steps.
26D-Link COVR-3902 User Manual
Loading...
