D Link CHG601WA1 Users Manual

DCH-G601W/DCH-G601WA1 D-Link Corporation

DCH-G601W/DCH-G601WA1

User’s Manual

Version 1.0

March 23th, 2018

Page 1

DCH-G601W D-Link Corporation

Table of Contents

1. PRODUCT DESCRIPTION .................................................................................. 3

2. APPEARANCE ..................................................................................................... 3

3. APPLICATIONS ................................................................................................... 4

4. INSTALLATIONS ................................................................................................ 5

5. SYSTEM REQUIREMENT…...………………………………………………..13

Page 2

DCH-G601W/DCH-G601WA1 D-Link Corporation

1. PRODUCT DESCRIPTION

The DCH-G601W/DCH-G601WA1 Wi-Fi Bluetooth Hub is a high-performance
and secure Connected Home Bluetooth gateway used the latest Bluetooth
technology combined with Afero security chip, the Bluetooth Hub allows your
devices to communicate with one another. The Hub built in with most secured
Afero encryption chipset. You can pair with Afero’s Bluetooth equipped smart
home devices to the hub to manage, operate, and enjoy the convenience of smart
home. The hub has backup battery which keep you smart home devices online
all the time.

2. APPEARANCE

DCH-G601W Hub

Page 3

DCH-G601W/DCH-G601WA1 D-Link Corporation

Front

 LED: Status indicator

Rear

 Micro USB: Power jack, Vdc 5V/2A, Cable length: 1.5 meters
 Micro SD card: microSD slot, support SD/SDHC/SDXC, up to 128G
 Reset button: [1]Reset[2] Reset to factory default (>=press 10 seconds)
 WPS button: TBD
 Tripod: for external stand. (TBD)

3. APPLICATIONS

Page 4

DCH-G601W/DCH-G601WA1 D-Link Corporation

4. INSTALLATIONS

Step 1 Plug the included Power Adapter into the back of the hub.

Red LED: user ca binding, go to step 2.

Step 2. Download afero App to your smart phone and register an account to login.

or scan the QR code for your iOS or Android phone.

iOS Android

Step 3 New users: Tap New users, sign up here to install your Hub.

Existing users: Sign in to your afero account and tap Add a Device on the next

screen.

Step 4 Adding the Hub to your account

Note: The QR code on the bottom of the device is unique to the device itself.
Please be sure to scan each device individually during set up.

Page 5
