Product Prole
Introduction
When used with the DJI FPV Goggles V2, the DJI Motion Controller provides an immersive and intuitive ying
experience that allows users to easily control the aircraft using hand movements. Built into the DJI Motion
Controller is DJI's O3 transmission technology, oering a maximum transmission range of 6 mi (10 km). The
motion controller works at both 2.4 and 5.8 GHz and is capable of selecting the best transmission channel
automatically. The maximum runtime of the motion controller is approximately 5 hours.
The motion controller reaches its maximum transmission distance (FCC) in a wide-open area with no
electromagnetic interference when the aircraft is at an altitude of approximately 400 ft (120 m). The
maximum transmission distance refers to the maximum distance that the aircraft can still send and
receive transmissions. It does not refer to the maximum distance the aircraft can y in a single ight.
5.8 GHz is not supported in certain regions. Observe local laws and regulations.
Diagram
1
2
4
3
10
7
1. Battery Level LEDs
Indicates the battery level of the motion controller.
2. Lock Button
Press twice to start the motors of the aircraft.
Press and hold to make the aircraft automatically take o, ascend to approximately 1 m, and hover.
Press and hold again to make the aircraft automatically land and the motors stop.
Press once to cancel Low Battery RTH when the countdown appears in the goggles.
3. Mode Button
Press once to switch between Normal and Sport mode.
© 2021 DJI All Rights Reserved.
5
5
6
9
8
DJI Motion Controller
4. Brake Button
Press once to make the aircraft brake and hover in place (only when GPS or Downward Vision System is
available). Press again to unlock the attitude and record the current position as zero attitude.
Press and hold to initiate RTH. Press again to cancel RTH.
5. Gimbal Tilt Slider
Push up and down to adjust the tilt of the gimbal (only available before takeo).
6. Shutter/Record Button
Press once to take photos or start or stop recording. Press and hold to switch between photo and video
mode.
7. Accelerator
Press to fly the aircraft in the direction of the circle in the goggles. Apply more pressure to accelerate.
Release to stop and hover.
8. Lanyard Hole
9. USB-C Port
For charging or connecting the motion controller to a computer to update rmware.
10. Power Button
Press once to check the current battery level. Press once then again and hold to power the motion
controller on or o.
User Manual
© 2021 DJI All Rights Reserved.
6
Operation
Powering On/O
Press the power button once to check the current battery level. Recharge before using if the battery level is too low.
Press once then press again and hold to power the motion controller on or o.
The battery level LEDs display the power level of the battery during
charging and discharging. The statuses of the LEDs are dened below:
LED is on.
LED is ashing.
LED is o.
LED1 LED2 LED3 LED4 Battery Level
Battery Level > 80%
75% < Battery Level ≤ 80%
63% < Battery Level ≤ 75%
50% < Battery Level ≤ 63%
38% < Battery Level ≤ 50%
15% < Battery Level ≤ 38%
8% < Battery Level ≤ 15%
0% < Battery Level ≤ 8%
Charging
Use a USB-C cable to connect a charger to the USB-C port of
the motion controller. It takes approximately 2.5 hours to fully
charge the motion controller.
5V, 1A
The table below shows the battery level during charging.
LED1 LED2 LED3 LED4 Battery Level
0% < Battery Level ≤ 50%
50% < Battery Level ≤ 75%
75% < Battery Level < 100%
Fully charged
© 2021 DJI All Rights Reserved.
7
DJI Motion Controller
User Manual
Linking
Follow the steps below to link the motion controller and the aircraft.
The aircraft must be linked with the goggles before the motion controller.
2s 2s
Make sure that all devices are powered on before linking.
1. Press and hold the power button of the aircraft until the battery level LEDs start to blink in sequence.
2. Press and hold the power button of the motion controller until it beeps continually and the battery level
indicators blink in sequence.
3. The motion controller stops beeping when linking is successful and both the battery level indicators turn
solid and display the battery level.
Activation
The DJI Motion Controller must be activated before using for the rst time. Make sure all devices are linked after
powering on the aircraft, goggles, and motion controller. Connect the USB-C port of the goggles to the mobile
device, run DJI Fly, and follow the prompts to activate. An internet connection is required for activation.
DJI Fly
App
Controlling the Aircraft
The motion controller has two modes: Normal mode and Sport mode. Normal mode is selected by default.
Zero attitude: the initial position of the motion controller that is used as a reference point when
any movements are made with the motion controller.
Before using for the rst time, practice ying with the motion controller using DJI Virtual Flight.
© 2021 DJI All Rights Reserved.
8
DJI Motion Controller
User Manual
Motion Controller
Aircraft & Goggles Screen
Indicates nose direction)
(
Remarks
Rotate the motion controller to control the orientation
of the aircraft.
The orientation of the aircraft changes with the rotation
of the motion controller accordingly and is always
consistent with the orientation of the motion controller.
The circle in the goggles will move left and right and
the video transmission will change accordingly.
The orientation of the aircraft can also be controlled by
tilting the motion controller left and right.
Tilt left to rotate the aircraft counterclockwise and tilt
right to rotate clockwise. The aircraft hovers in place if
the motion controller is at zero attitude.
The tilt angle corresponds to the angular velocity of
the rotation of the aircraft. The greater the tilt angle of
the motion controller, the faster the aircraft will rotate.
The circle in the goggles will move left and right and
the video transmission will change accordingly.
Tilt the motion controller up and down to control the
tilt of the gimbal.
The tilt of the gimbal changes with the tilt of the motion
controller accordingly and is always consistent with
the orientation of the motion controller.
The circle in the goggles will move up and down and
the video transmission will change accordingly.
© 2021 DJI All Rights Reserved.
9
To control the ascent or descent of the aircraft, rst tilt
the motion controller 90° up or down. Once complete,
press the accelerator to make the aircraft ascend or
descend.
Press the accelerator to y in the direction of the circle
in the goggles.
Apply more pressure to accelerate. Release to stop
and hover.
DJI Motion Controller
User Manual
Lock Button
Mode Button
Brake Button
Lock Button
Press twice to start the motors of the aircraft.
Press and hold to make the aircraft automatically take o, ascend to approximately 1 m, and hover.
Press and hold while hovering to make the aircraft automatically land and the motors to stop.
Press once to cancel Low Battery RTH when the countdown appears in the goggles.
Critical Low Battery RTH cannot be canceled.
Brake Button
Press once to make the aircraft brake and hover in place. The goggles will show . Press again to unlock the
attitude and record the current position as zero attitude. To record the zero attitude, the motion controller must
be held upright and the white dot must be inside the box of the motion controller movement display. The box
turns to when the white dot is inside.
If the aircraft is performing RTH or auto landing, press once to exit RTH.
Press and hold the brake button until the motion controller beeps to indicate that RTH has started. Press the
button again to cancel RTH and regain control of the aircraft.
If the aircraft brakes and hovers, the zero attitude may need to be reset before the ight can resume.
Mode Button
Press once to switch between Normal and Sport mode. The current mode is displayed in the goggles.
Motion Controller Alert
The motion controller sounds an alert during RTH. The alert cannot be cancelled.
The motion controller sounds an alert when the battery level is 6% to 15%. A low battery level alert can be
cancelled by pressing the power button. A critical battery level alert will sound when the battery level is less
than 5% and cannot be cancelled.
© 2021 DJI All Rights Reserved.
10
DJI Motion Controller
User Manual
Controlling the Camera
1. Shutter/Record Button: press once to take a photo or to start or stop recording. Press and hold to switch
between photo and video mode.
2. Gimbal Tilt Slider: push up and down to adjust the tilt of the gimbal (only available before takeo).
Gimbal Tilt Slider
Shutter/Record Button
Optimal Transmission Zone
The signal between the aircraft and the motion controller is most reliable when the motion controller is
positioned in relation to the aircraft as shown below.
Optimal Transmission Zone
In order to avoid interference, DO NOT use other wireless devices on the same frequency as the
motion controller.
© 2021 DJI All Rights Reserved.
11
Goggles Screen
15min
10min
1.8km/h
1024.4m
D
500m
H
20.5km/h
20
75%
12'59''
The motion controller should be used with the DJI FPV Goggles V2, which give users a rst-person view from
the aerial camera with real-time video and audio transmission.
1
2
13
Press Brake button to cancel RTH
Low battery RTH
15
45678911 1012
1. Flight Direction Indicator
When the motion controller is stationary, it indicates the midpoint of the screen. When the motion controller
is moved, it indicates the change of the aircraft orientation or gimbal pitch.
2. microSD Card Information
Displays whether or not a microSD card is inserted in the aircraft or goggles as well as the remaining
capacity. A ashing icon will appear when recording.
3. Prompts
Displays information such as when switching modes and when the battery level is low.
4. Goggles Battery Level
Displays the battery level of the goggles. The goggles will beep when the battery level is too low. The
voltage will also be displayed if a third-party battery is being used.
5. GPS Status
Displays the current strength of the GPS signal.
6. Remote Control and Video Downlink Signal Strength
Displays the remote control signal strength between the aircraft and motion controller and the video
downlink signal strength between the aircraft and the goggles.
7. Forward Vision System Status
Displays the status of the Forward Vision System. The icon is white when the Forward Vision System is
working normally. Red indicates that the Forward Vision System is not enabled or working abnormally and
the aircraft cannot automatically slow down when encountering obstacles.
8. Remaining Flight Time
Displays the remaining ight time of the aircraft after starting the motors.
3
© 2021 DJI All Rights Reserved.
12
DJI Motion Controller
9. Aircraft Battery Level
Displays the current battery level of the Intelligent Flight Battery on the aircraft.
10. Motion Controller Movement Display
Displays the attitude information of the motion controller such as when it tilts left and right, up and down,
and whether the attitude is xed when the aircraft brakes and hovers.
11. Flight Telemetry
D 1024.4 m, H 500 m, 9 m/s, 6 m/s: displays the distance between the aircraft and the Home Point, height
from the Home Point, aircraft horizontal speed, and aircraft vertical speed.
12. Flight Modes
Displays the current ight mode.
13. Home Point
Indicates the location of the Home Point.
It is recommended to watch the tutorial video in the goggles before using for the rst time. Go to
Settings, Control, Motion Controller, Flight Control, and then First Flight Tutorial.
Using the goggles does not satisfy the requirement of visual line of sight (VLOS). Some countries or
regions require a visual observer to assist during ight. Make sure to comply with local regulations
when using the goggles.
User Manual
© 2021 DJI All Rights Reserved.
13
Appendix
Specications
Model FC7BMC
Weight 167 g
Operating Frequency 2.400-2.4835 GHz; 5.725-5.850 GHz
Max Transmission Distance
(unobstructed, free of interference)
Transmitter Power (EIRP)
Operating Temperature Range -10° to 40° C (14° to 104° F)
Max Runtime 5 hours
Motion Controller Calibration
The compass, IMU, and accelerator of the motion controller can be calibrated. Immediately calibrate any of the
modules when prompted to do so.
On the goggles, go to Settings, Control, Motion Controller, and then Motion Controller Calibration. Select the
module and follow the prompts to complete calibration.
DO NOT calibrate the compass in locations where magnetic interference may occur such as close
to magnetite deposits or large metallic structures such as parking structures, steel-reinforced
basements, bridges, cars, or scaolding.
DO NOT carry objects that contain ferromagnetic materials such as mobile phones near the aircraft
during calibration.
10 km (FCC); 6 km (CE/SRRC/MIC)
2.4 GHz: ≤28.5 dBm (FCC), ≤20 dBm (CE/SRRC/MIC)
5.8 GHz: ≤31.5 dBm (FCC), ≤19 dBm (SRRC), ≤14 dBm (CE)
Firmware Update
Use DJI Fly or DJI Assistant 2 (DJI FPV series) to update the motion controller rmware.
Using DJI Fly
Power on the aircraft, goggles, and motion controller. Make sure all the devices are linked. Connect the USB-C port
of the goggles to the mobile device, run DJI Fly, and follow the prompt to update. An internet connection is required.
Using DJI Assistant 2 (DJI FPV Series)
Use DJI Assistant 2 (DJI FPV series) to update the motion controller separately.
1. Power on the device and connect it to a computer with a USB-C cable.
2. Launch DJI Assistant 2 (DJI FPV series) and log in with a DJI account.
3. Select the device and click Firmware Update on the left.
4. Select the rmware version required.
5. DJI Assistant 2 (DJI FPV series) will download and update the rmware automatically.
6. The device will restart automatically after the rmware update is complete.
© 2021 DJI All Rights Reserved.
14
DJI Motion Controller
Before performing an update, make sure the motion controller has a battery level of at least 30%.
Do not unplug the USB-C cable during an update.
The firmware update will take approximately 5 minutes. Make sure the mobile device or the
computer is connected to the internet.
User Manual
After-Sales Information
Visit https://www.dji.com/support to learn more about after-sales service policies, repair services, and support.
© 2021 DJI All Rights Reserved.
15
DJI Support
http://www.dji.com/support
This content is subject to change.
Download the latest version from
https://www.dji.com/dji-fpv
If you have any questions about this document, please contact
DJI by sending a message to DocSupport@dji.com.
Copyright
2021 DJI All Rights Reserved.
©
Loading...
