Revision Log
VersionDateRevisions
v1.22023.12Added Vision Assist, Auto mode for ActiveTrack, Vison Positioning
and Obstacle Sensing switch, etc.
v1.42024.06Added support for Enhanced Transmission in some countries and
regions.
DJI Mini 4 Pro
User Manual
Using this Manual
Legend
ImportantHints and TipsReference
Read Before the First Flight
DJITM provides users with tutorial videos and the following documents.
1. Safety Guidelines
2. Quick Start Guide
3. User Manual
It is recommended to watch all tutorial videos and read the safety guidelines before using for
the rst time. Prepare for your rst ight by reviewing the quick start guide and refer to this
user manual for more information.
Video Tutorials
Go to the address below or scan the QR code to watch the tutorial videos, which demonstrate
how to use the product safely:
https://s.dji.com/guide66
Download the DJI Fly App
Make sure to use DJI Fly during ight. Scan the QR code above to download the latest version.
• The remote controller with screen has the DJI Fly app already installed. Users are
required to download DJI Fly to their mobile device when using the remote controller
without screen.
• To check the Android and iOS operating system versions supported by DJI Fly, visit
https://www.dji.com/downloads/djiapp/dji-y.
* For increased safety, ight is restricted to a height of 98.4 ft (30 m) and a range of 164 ft (50 m) when not
connected or logged into the app during flight. This applies to DJI Fly and all apps compatible with DJI
• The operating temperature of this product is -10° to 40° C. It does not meet the
standard operating temperature for military-grade application (-55° to 125° C), which is
required to endure greater environmental variability. Operate the product appropriately
and only for applications that meet the operating temperature range requirements of
that grade.
Introduction 9
Feature Highlights 9
Using for the First Time 10
Preparing the Aircraft 10
Preparing the Remote Controller 12
Activating the Aircraft 13
Binding the Aircraft and Remote Controller 13
Firmware Update 13
Using DJI Fly 112
Using DJI Assistant 2 (Consumer Drones Series) 112
Enhanced Transmission 113
Installing the nano-SIM Card 114
Installing the DJI Cellular Dongle 2 to the Aircraft 114
Using Enhanced Transmission 116
Security Strategy 117
Remote Controller Usage Notes 117
4G Network Requirements 117
Post-Flight Checklist 118
Maintenance Instructions 118
Troubleshooting Procedures 119
Risk and Warnings 119
Disposal 120
C0 and C1 Certification 120
FAR Remote ID Compliance Information 126
Aftersales Information 127
This chapter introduces the major
features of the product.
DJI Mini 4 Pro
User Manual
Product Prole
Introduction
DJI Mini 4 Pro features both an omnidirectional vision system and a 3D infrared sensing system,
it is capable of hovering and ying indoors and outdoors, and can automatically Return to Home
while sensing obstacles in all directions. The aircraft also boasts a foldable and compact design,
weighing less than 249 g. The aircraft has a maximum ight time of 34 minutes when used with
the Intelligent Flight Battery, and 45 minutes with the Intelligent Flight Battery Plus.
The aircraft is compatible with both the DJI RC 2 and DJI RC-N2 remote controllers. Refer to the
Remote Controller chapter for more information.
Feature Highlights
Gimbal and Camera:
4 Pro is able to shoot 4K 60fps HDR and 4K 100fps video and 48MP photos. It also supports
switching between Landscape mode and Portrait mode with one tap in DJI Fly. The newly added
10-bit D-Log M color mode brings a more convenient experience for post-production color
correction, while HLG provides better dynamic range and color display performance.
Video Transmission:
a maximum transmission range of 20 km and video quality at up to 1080p 60fps from the
aircraft to the DJI Fly app. The remote controller works at 2.4, 5.8, and 5.1 GHz and is capable of
selecting the best transmission channel automatically.
Intelligent Flight Modes:
quickly sense and bypass obstacles in all directions while the user is operating the aircraft for
a safer ight and smoother footage. Intelligent Flight Modes such as FocusTrack, MasterShots,
QuickShots, Hyperlapse, Waypoint Flight and Cruise Control enable users to capture cinematic
videos eortlessly.
• The maximum ight speed was tested at sea level altitude without wind. The maximum
ight time was tested in an environment without wind while ying at a consistent ight
speed of 13.4 mph (21.6 kph).
• The remote control devices reach their maximum transmission distance (FCC) in a wide
open area with no electromagnetic interference at an altitude of about 120 m (400 ft).
The maximum transmission distance refers to the maximum distance that the aircraft
can still send and receive transmissions. It does not refer to the maximum distance the
aircraft can y in a single ight.
• 5.8 GHz is not supported in some regions, where it will automatically be disabled.
Always observe local laws and regulations.
• 5.1 GHz can be used only in countries and regions where it is permitted by local laws
and regulations.
• The Intelligent Flight Battery Plus needs to be purchased separately and it is sold only in
some countries and regions. Visit the ocial DJI online store for more information.
With a fully stabilized 3-axis gimbal and a 1/1.3″ sensor camera, DJI Mini
With DJI’s long-range transmission O4 technology, the aircraft can oer
With the Advanced Pilot Assistance System (APAS), the aircraft can
• The maximum takeoff weight will be more than 249 g if the aircraft is used with the
User Manual
Intelligent Flight Battery Plus. Make sure to observe local laws and regulations about the
takeo weight.
Using for the First Time
Click the link below or scan the QR code to watch
the tutorial video.
https://s.dji.com/guide66
Preparing the Aircraft
All aircraft arms are folded before the aircraft is packaged. Follow the steps below to unfold the
aircraft.
1. All Intelligent Flight Batteries are in hibernation mode before shipment to ensure safety.
Charge to activate the batteries for the rst time. Connect the USB charger to the USB-C port
on the aircraft to charge. The battery is activated when it begins charging.
1. Remove the control sticks from the storage slots and mount them on the remote controller.
2
2. Unfold the antennas.
3. The remote controller needs to be activated before rst use and an internet connection is
required for activation. Press, and then press and hold the power button to power on the
remote controller. Follow the on-screen prompts to activate the remote controller.
1
DJI RC-N2
1. Remove the control sticks from the storage slots and mount them on the remote controller.
2. Pull out the mobile device holder. Choose the appropriate remote controller cable based
on the port type of your mobile device (a Lightning connector cable and a USB-C cable are
included in the packaging). Place your mobile device in the holder, then connect the end of
the cable without the remote controller logo to your mobile device. Make sure your mobile
device is securely in place.
• If a USB connection prompt appears when an Android mobile device is used, select the
option to charge only. Other options may cause the connection to fail.
User Manual
Activating the Aircraft
The aircraft requires activation before first use. Press, and then press and hold the power
button to power on the aircraft and remote controller respectively, and then follow the onscreen prompts to activate the aircraft using DJI Fly. An internet connection is required for
activation.
Binding the Aircraft and Remote Controller
After activation, the aircraft is bound to the remote controller automatically. If automatic
binding fails, follow the on-screen prompts on DJI Fly to bind the aircraft and remote controller
for optimal warranty services.
Firmware Update
A prompt will appear in DJI Fly when new rmware is available. Update the rmware whenever
prompted to ensure optimal user experience.
aircraft movements. Set the control stick
mode in DJI Fly. The control sticks are
removable and easy to store.
2. Antennas
Transmit aircraft control and video
wireless signals.
3. Status LED
Indicates the status of the remote
controller.
4. Battery Level LEDs
Displays the current battery level of the
remote controller.
5. Flight Pause/Return to Home (RTH)
Button
Press once to make the aircraft brake and
hover in place (only when GNSS or Vision
Systems are available). Press and hold to
initiate RTH. Press again to cancel RTH.
6. Flight Mode Switch
For switching between three ight modes:
Cine, Normal, and Sport mode.
7. Power Button
Press once to check the current battery
level. Press, and then press and hold to
power the remote controller on or off.
When the remote controller is powered
on, press once to turn the touchscreen
on or o.
11
12
15
13
14
8. Touchscreen
Touch the screen to operate the remote
controller. Note that the touchscreen is
not waterproof. Operate with caution.
9. USB-C Port
For charging and connecting the remote
controller to your computer.
10. microSD Card Slot
For inserting a microSD card.
11. Gimbal Dial
Controls the tilt of the camera.
12. Record Button
Press once to start or stop recording.
13. Camera Control Dial
For zoom control. Set the function in DJI
Fly by entering Camera View > Settings >
Control > Button Customization.
14. Focus/Shutter Button
Press halfway down on the button to
autofocus and press all the way down
to take a photo. Press once to switch to
photo mode when in record mode.
Systems are available). Press and hold to
initiate RTH. Press again to cancel RTH.
4. Battery Level LEDs
Displays the current battery level of the
remote controller.
5. Control Sticks
Use the control sticks to control the
aircraft movements. Set the control stick
mode in DJI Fly. The control sticks are
removable and easy to store.
DJI Mini 4 Pro
User Manual
6. Customizable Buttons
Press once to recenter the gimbal or
point the gimbal downward. Press
twice to switch between Landscape and
Portrait mode. Set the function in DJI Fly
by entering Camera View > Settings >
Control > Button Customization.
7. Photo/Video Toggle
Press once to switch between photo and
video mode.
8. Remote Controller Cable
Connect to a mobile device for video
linking via the remote controller cable.
Select the cable according to the port
type on your mobile device.
9. Mobile Device Holder
For mounting the mobile device securely
on the remote controller.
10. Antennas
Transmit aircraft control and video
wireless signals.
11. USB-C Port
For charging and connecting the remote
controller to your computer.
12. Control Sticks Storage Slot
For storing the control sticks.
13. Gimbal Dial
Controls the tilt of the camera. Press and
hold the customizable button to use the
gimbal dial for zoom control.
This chapter describes safe flight
practices, ight restrictions, basic ight
operations, and the intelligent flight
modes.
DJI Mini 4 Pro
User Manual
Flight and Safety
After completing the pre-flight preparation, it is recommended to train your flying skills and
practice ying safely. Pick a suitable area to y in according to the following ight requirements
and restrictions. Strictly abide by local laws and regulations when flying. Read the Safety
Guidelines before ight to ensure the safe use of the product.
Flight Environment Requirements
1. DO NOT operate the aircraft in severe weather conditions including wind speeds exceeding
10.7 m/s, snow, rain, and fog.
2. Only fly in open areas. Tall buildings and large metal structures may affect the accuracy
of the onboard compass and GNSS system. Therefore, DO NOT take off from a balcony
or anywhere within 10 m of buildings. Keep a distance of at least 10 m from buildings
during ight. After takeo, make sure you are notied with the voice prompt Home Point
is updated before continuing ight. If the aircraft has taken o near buildings, the accuracy
of the Home Point cannot be guaranteed. In this case, pay close attention to the current
position of the aircraft during auto RTH. When the aircraft is close to the Home Point,
it is recommended to cancel auto RTH and manually control the aircraft to land at an
appropriate location.
3. The performance of the aircraft and its battery is limited when ying at high altitudes. Fly
with caution. The maximum takeo altitude of the aircraft is 4,000 m (13,123 ft) when ying
with the Intelligent Flight Battery. If the Intelligent Flight Battery Plus is used, the maximum
takeo altitude drops to 3,000 m (9,843 ft). If a propeller guard is installed on the aircraft
with the Intelligent Flight Battery, the maximum takeo altitude becomes 1,500 m (4,921 ft).
DO NOT use the propeller guard together with the Intelligent Flight Battery Plus.
4. The braking distance of the aircraft is aected by the ight altitude. The higher the altitude,
the greater the braking distance. When ying at an altitude above 3,000 m (9,843 ft), the
user should reserve at least 20 m of vertical braking distance and 25 m of horizontal braking
distance to ensure ight safety.
5. Avoid obstacles, crowds, trees, and bodies of water (recommended height is at least 3 m
above water).
6. Minimize interference by avoiding areas with high levels of electromagnetism, such as
locations near power lines, base stations, electrical substations, and broadcasting towers.
7. GNSS cannot be used on the aircraft in polar regions. Use the vision system instead.
8. DO NOT take o from moving objects such as cars, ships, and airplanes.
9. DO NOT take o from solid-colored surfaces or surfaces with strong reection such as a car
roof.
10. DO NOT use the aircraft, remote controller, battery, battery charger, and the battery
charging hub near accidents, fire, explosions, floods, tsunamis, avalanches, landslides,
earthquakes, dust, sandstorms, salt spray, or fungus.
11. Operate the aircraft, remote controller, battery, battery charger, and the battery charging
hub in a dry environment.
12. DO NOT operate the aircraft in an environment at risk of a re or explosion.
To avoid serious injury and property damage, observe the following rules:
1. Make sure you are NOT under the inuence of anesthesia, alcohol, or drugs or suering
from dizziness, fatigue, nausea, or other conditions that could impair the ability to operate
the aircraft safely.
2. When landing, power o the aircraft rst, then switch o the remote controller.
3. DO NOT drop, launch, fire, or otherwise project any dangerous payloads on or at any
buildings, persons, or animals, which could cause personal injury or property damage.
4. DO NOT use an aircraft that has been crashed or accidentally damaged or an aircraft that is
not in good condition.
5. Make sure to train sufficiently and have contingency plans for emergencies or when an
incident occurs.
6. Make sure to have a ight plan. DO NOT y the aircraft recklessly.
7. Respect the privacy of others when using the camera. Make sure to comply with local
privacy laws, regulations, and moral standards.
8. DO NOT use this product for any reason other than general personal use.
9. DO NOT use it for illegal or inappropriate purposes such as spying, military operations, or
unauthorized investigations.
10. DO NOT use this product to defame, abuse, harass, stalk, threaten, or otherwise violate
legal rights such as the right to privacy and publicity of others.
11. DO NOT trespass onto the private property of others.
Flight Restrictions
GEO (Geospatial Environment Online) System
DJI’s Geospatial Environment Online (GEO) System is a global information system that provides
real-time information on ight safety and restriction updates and prevents UAVs from ying in
restricted airspace. Under exceptional circumstances, restricted areas can be unlocked to allow
ights in. Prior to that, the user must submit an unlocking request based on the current restriction
level in the intended flight area. The GEO system may not fully comply with local laws and
regulations. Users shall be responsible for their own ight safety and must consult with the local
authorities on the relevant legal and regulatory requirements before requesting to unlock a ight
in a restricted area. For more information about the GEO system, visit https://y-safe.dji.com.
Flight Limits
For safety reasons, ight limits are enabled by default to help users operate this aircraft safely.
Users can set ight limits on height and distance. Altitude limits, distance limits, and GEO zones
function concurrently to manage flight safety when GNSS is available. Only altitude can be
limited when GNSS is unavailable.
Max altitude restricts an aircraft’s ight altitude, while max distance restricts an aircraft’s ight
radius around the Home Point. These limits can be changed in the DJI Fly app for improved
ight safety.
Max Altitude
Home Point
Max Distance
Height of aircraft
when taking off
Home Point not manually updated during flight
Strong GNSS Signal
Flight RestrictionsPrompt in DJI Fly App
Max Altitude
Max Distance
Altitude of the aircraft cannot exceed the value
set in DJI Fly.
The straight-line distance from the aircraft to
the Home Point cannot exceed the max ight
distance set in DJI Fly.
Max ight altitude
reached.
Max ight distance
reached.
Weak GNSS Signal
Flight RestrictionsPrompt in DJI Fly App
• Altitude is restricted to 30 m from the takeoff
point if lighting is sucient.
• Altitude is restricted to 2 m above the ground
Max Altitude
if lighting is not sufficient and the 3D infrared
sensing system is operating.
Max ight altitude
reached.
• Altitude is restricted to 30 m from the takeoff
point if lighting is not sufficient and the 3D
infrared sensing system is not operating.
Max Distance No limits
• Each time the aircraft is powered on, the altitude limit of 2 m or 30 m will be automatically
removed as long as the GNSS signal ever becomes strong (GNSS signal strength ≥ 2) once,
and the limit will not take eect even if the GNSS signal becomes weak afterwards.
• If the aircraft flies out of the set flight range due to inertia, you can still control the
aircraft but cannot y it any further.
• For safety reasons, DO NOT y the aircraft close to airports, highways, railway stations,
railway lines, city centers, or other sensitive areas. Only y the aircraft within a visual
line of sight.
DJI’s GEO system designates safe flight locations, provides risk levels and safety notices for
individual flights and offers information on restricted airspace. All restricted flight areas are
referred to as GEO Zones, which are further divided into Restricted Zones, Authorization Zones,
Warning Zones, Enhanced Warning Zones, and Altitude Zones. Users can view such information
in real-time in DJI Fly. GEO Zones are specic ight areas, including but not limited to airports,
large event venues, locations where public emergencies have occurred (such as forest res),
nuclear power plants, prisons, government properties, and military facilities. By default, the
GEO system limits takeos and ights in zones that may cause safety or security concerns. A
GEO Zone map that contains comprehensive information on GEO Zones around the globe is
available on the ocial DJI website: https://y-safe.dji.com/nfz/nfz-query.
Unlocking GEO Zones
To satisfy the needs of dierent users, DJI provides two unlocking modes: Self-Unlocking and
Custom Unlocking. Users may request on the DJI Fly Safe website.
Self-Unlocking
the user must submit an unlocking request via the DJI Fly Safe website at https://fly-safe.dji.
com. Once the unlocking request is approved, the user may synchronize the unlocking license
through the DJI Fly app. To unlock the zone, alternatively, the user may launch or y the aircraft
directly into the approved Authorization Zone and follow the prompts in DJI Fly to unlock the
zone.
Custom Unlocking
custom ight areas and provides ight permission documents specic to the needs of dierent
users. This unlocking option is available in all countries and regions and can be requested via
the DJI Fly Safe website at https://y-safe.dji.com.
is intended for unlocking Authorization Zones. To complete Self-Unlocking,
is tailored for users with special requirements. It designates user-dened
• To ensure ight safety, the aircraft will not be able to y out of the unlocked zone after
entering it. If the Home Point is outside the unlocked zone, the aircraft will not be able
to return home.
Pre-Flight Checklist
1. Make sure the propeller holder and the gimbal protector is removed.
2. Make sure the Intelligent Flight Battery and the propellers are mounted securely.
3. Make sure the remote controller, mobile device, and Intelligent Flight Battery are fully
charged.
4. Make sure the aircraft arms are unfolded.
5. Make sure the gimbal and camera are functioning normally.
6. Make sure that there is nothing obstructing the motors and that they are functioning
normally.
7. Make sure that DJI Fly is successfully connected to the aircraft.
8. Make sure all camera lenses and sensors are clean.
9. Only use genuine DJI parts or DJI authorized parts. Unauthorized parts may cause system
malfunctions and compromise ight safety.
10. Make sure the Obstacle Avoidance Action is set in DJI Fly, and the max flight altitude,
max flight distance and RTH altitude are all set properly according to the local laws and
regulations.
User Manual
Basic Flight
Auto Takeo/Landing
Auto Takeo
Use the Auto Takeo function:
1. Launch DJI Fly and enter the camera view.
2. Complete all steps in the pre-ight checklist.
3. Tap
4. The aircraft will take o and hover approximately 1.2 m (3.9 ft) above the ground.
Auto Landing
Use the Auto Landing function:
1. Tap
2. Auto landing can be canceled by tapping
3. If the Downward Vision System is working normally, Landing Protection will be enabled.
4. Motors will stop automatically after landing.
. If conditions are safe for takeo, press and hold the button to conrm.
. If conditions are safe to land, press and hold the button to conrm.
.
• Choose the proper place for landing.
Starting/Stopping the Motors
Starting the Motors
Perform the Combination Stick Command (CSC) as shown below to start the motors. Once the
motors have started spinning, release both sticks simultaneously.
When the aircraft has landed, push the throttle stick down and hold until the motors
stop.
When the aircraft has landed, perform the same CSC used to start the motors until
the motors stop.
OR
Method 1Method 2
Stopping the Motors Mid-Flight
Stopping the motors mid-ight will cause the aircraft to crash. The default setting for Emergency
Propeller Stop in the DJI Fly app is Emergency Only, which means that the motors can only
be stopped mid-flight when the aircraft detects that it is in an emergency situation such as
the aircraft is involved in a collision, a motor has stalled, the aircraft is rolling in the air, or the
aircraft is out of control and is ascending or descending very quickly. To stop the motors midight, perform the same CSC that was used to start the motors. Note that the user needs to
hold the control sticks for two seconds while performing the CSC to stop the motors. Emergency
Propeller Stop can be changed to Anytime in the app by users. Use this option with caution.
The control sticks of the remote controller can be used to control the aircraft movements. The
control sticks can be operated in Mode 1, Mode 2, or Mode 3, as shown below. The default
control mode of the remote controller is Mode 2. Refer to Remote Controller section for more
1. Place the aircraft in an open, at area with the rear of the aircraft facing towards the user.
2. Power on the remote controller and the aircraft.
3. Launch DJI Fly and enter the camera view.
4. Tap Settings > Safety, and then set the Obstacle Avoidance Action to Bypass or Brake. Make
sure to set an appropriate Max Altitude and RTH Altitude.
5. Wait for the aircraft self-diagnostics to complete. If DJI Fly does not show any irregular
warning, you can start the motors.
6. Push the throttle stick up slowly to take o.
7. To land, hover over a level surface and push the throttle stick down to descend.
8. After landing, push the throttle down and hold until the motors stop.
9. Power o the aircraft before the remote controller.
Video Suggestions and Tips
1. The pre-ight checklist is designed to help the user y safely and shoot videos during ight.
Go through the full pre-ight checklist before each ight.
2. Select the desired gimbal operation mode in DJI Fly.
3. It is recommended to take photos or record videos when ying in Normal or Cine mode.
4. DO NOT y in bad weather such as on rainy or windy days.
5. Choose the camera settings that best suit your needs.
6. Perform ight tests to establish ight routes and preview scenes.
7. Push the control sticks gently to ensure smooth and stable movement of the aircraft.
• Make sure to place the aircraft on a flat and steady surface before takeoff. DO NOT
launch the aircraft from your palm or while holding it with your hand.
FocusTrack includes Spotlight, Point of Interest, and ActiveTrack.
• Refer to the Controlling the Aircraft section in the Remote Controller chapter for more
information about the roll, pitch, throttle, and yaw sticks.
• The aircraft does not automatically take photos or record videos while using FocusTrack.
Users need to manually control the aircraft to take photos or record videos.
SpotlightPoint of Interest (POI)ActiveTrack
Description
Supported
Subjects
Control
The aircraft does not
y automatically, but
the camera remains
locked on the subject
while the user
manually controls the
ight.
• Stationary subjects
• Moving subjects (only vehicles, boats, and people)
Using the control sticks
to move the aircraft:
• Move the roll stick to
circle the subject
• Move the pitch stick
to alter the distance
from the subject
• Move the throttle
stick to change the
altitude
• Move the yaw stick to
adjust the frame
The aircraft tracks the
subject in a circle based
on the set radius and ight
speed.
The max ight speed
is 12 m/s and the ight
speed may be adjusted
dynamically according the
actual radius.
Using the control sticks to
move the aircraft:
• Move the roll stick to
change the circling speed
of the aircraft around
the subject
• Move the pitch stick to
alter the distance from
the subject
• Move the throttle stick to
change the altitude
• Move the yaw stick to
adjust the frame
The aircraft keeps a certain
distance and altitude from
the tracked subject, and
there are three modes: Auto,
Manual and Parallel.
The max ight speed is 12 m/s.
• Moving subjects (only
vehicles, boats, and people)
Using the control sticks to
move the aircraft:
• Move the roll stick to
circle the subject
• Move the pitch stick to
alter the distance from
the subject
The aircraft continuously plan and adjust the ight path based on its environment
and execute automatic movements.
There are eight types of tracking
directions: Front, Back, Left,
Right, Front Diagonal Left, Front
Diagonal Right, Back Diagonal Left,
and Back Diagonal Right. After
setting the tracking direction, the
aircraft will follow the subject
from the tracking direction
relative to the direction of the
subject movements.
User Manual
When the vision
systems are working
normally, the aircraft
will hover if an
obstacle is detected,
regardless of whether
the obstacle avoidance
action is set to Bypass
or Brake in DJI Fly.
Note: obstacle
avoidance is disabled
in Sport mode.
In Auto mode, the aircraft can only track people and will not respond to any
control stick movements.
The aircraft will bypass obstacles regardless of the ight
modes or obstacle avoidance action settings in DJI Fly
when the vision systems are working normally.
The aircraft tracks the subject
while maintaining the same
geographical orientation in
relation to the subject.
(Take East Follow as an example)
DJI Mini 4 Pro
User Manual
• In Trace mode, the direction setting is only effective when the subject is moving in a
stable direction. If the moving direction of the subject is not stable, the aircraft will track
the subject from a certain distance and altitude. Once the tracking starts, the direction of
tracking can be adjusted through the trace wheel.
In ActiveTrack, the supported follow ranges of the aircraft and subject are as follows:
SubjectPeopleVehicles/Boats
Horizontal Distance
Altitude
4-20 m (Optimal: 4-15 m)6-100 m (Optimal: 20-50 m)
0.5-20 m (Optimal: 2-15 m)6-100 m (Optimal: 10-50 m)
• When tracking a person, the parameter of the maximum horizontal distance or altitude
between the aircraft and the subject can be set to 15 m. In actual ight, the aircraft can
break the limit and y to 20 m by moving the control sticks.
• The aircraft will fly to the supported distance and altitude range if the distance and
altitude is out of range when ActiveTrack begins. Fly the aircraft at the optimal distance
and altitude for the best tracking performance.
Using FocusTrack
1. Launch the aircraft and take o.
2. Drag-select the subject in the camera view, or enable Subject Scanning under Control
settings in DJI Fly and tap the recognized subject to enable FocusTrack.
• FocusTrack must be used within the supported zoom ratio as follows. Otherwise,
subject recognition will be aected.
[1]
a. Spotlight/Point of Interest: supports up to 4x
zoom for moving subjects (only
vehicles, boats, and people) and stationary subjects.
[1]
b. ActiveTrack: supports up to 4x
people)
.
[1] The actual zoom ratio depends on the shooting mode. 12MP Photo: 1-2x, 4K: 1-3x, FHD: 1-4x.
zoom for moving subjects (only vehicles, boats, and
a. The aircraft enters Spotlight by default and does not y automatically. The user needs
to manually control the ight of the aircraft by using the control sticks. Tap the shutter/
record button on the camera view in DJI Fly or press the shutter/record button on the
remote controller to start shooting.
b. Tap on the bottom of the screen to switch to Point of Interest. After setting the flight
direction and speed, tap GO and the aircraft will automatically start circling around the
subject at the current altitude. The user can also move the control sticks to manually
control the ight while the aircraft is automatically ying. Tap the shutter/record button
on the camera view in DJI Fly or press the shutter/record button on the remote controller
to start shooting.
c. Tap on the bottom of the screen to switch to ActiveTrack. Select a sub-mode and tap
GO, the aircraft will start tracking the subject automatically. The user can also move
the control sticks to manually control the ight while the aircraft is automatically ying.
Tap the shutter/record button on the camera view in DJI Fly or press the shutter/record
button on the remote controller to start shooting.
In Manual mode, there will be a trace wheel in the camera view. The dots on the trace wheel
indicate different tracking directions. The tracking direction can be changed by tapping
the dots or dragging the tracking direction icon
to any other dot on the trace wheel. The
aircraft will fly to the selected tracking direction based on the green flight route shown
on the trace wheel. The aircraft's current position, end position/tracking direction, and
ight route can be viewed on the trace wheel. The tracking direction can be adjusted while
tracking to t your needs.
• If the tracking subject is a person, the trace wheel in the bottom left corner of the
camera view displays the inner and outer circles. If the tracking subject is a vehicle, the
trace wheel displays only one circle.
Set the parameters by entering Settings > Control > FocusTrack Settings.
Inner/Outer Radius
[1]
Set the horizontal distance between the aircraft and the subject
when tracking in the inner/outer circle.
[1]
Inner/Outer Height
Set the vertical distance between the aircraft and the subject when
tracking in the inner/outer circle.
Camera MotionSelect Normal or Fast.
Normal: Aircraft bypasses obstacles with more subtle attitude
changes and maintains smooth ight.
Fast: Aircraft bypasses obstacles with greater attitude changes and
maneuvers more dynamically.
[1]
Near-Ground Flight
If enabled, the aircraft’s height can be set to below 2 m when
tracking. This will increase the risk of colliding with near-ground
obstacles. Fly with caution.
Reset FocusTrack Settings FocusTrack settings for all subjects will be reset to default.
[1] This setting only appears when the tracking subject is a person. During tracking, the user can control the
tracking distance and height of the aircraft by using the pitch and throttle sticks. After moving the control
sticks, the parameters of the inner/outer circle where the end position/tracking direction
also be adjusted accordingly when tracking. Note that the parameters for the inner and outer circles in
the FocusTrack Settings will not be changed.
is located will
Exiting FocusTrack
In Point of Interest or ActiveTrack, press the Flight Pause button once on the remote controller
or tap Stop on the screen to return to Spotlight.
In Spotlight, press the Flight Pause button once on the remote controller to exit FocusTrack.
After exiting FocusTrack, tap
• The aircraft cannot avoid moving subjects such as people, animals, or vehicles. When
using FocusTrack, pay attention to the surrounding environment to ensure ight safety.
• DO NOT use FocusTrack in areas with small or ne objects (e.g., tree branches or power
lines), transparent objects (e.g., water or glass), or monochrome surfaces (e.g., white
walls).
• Always be prepared to press the Flight Pause button on the remote controller or tap
Stop in DJI Fly in order to operate the aircraft manually in case any emergency situation
occurs.
• Be extra vigilant when using FocusTrack in any of the following situations:
a. The tracked subject is not moving on a level plane.
b. The tracked subject changes shape drastically while moving.
c. The tracked subject is out of sight for an extended period.
d. The tracked subject is moving on a snowy surface.
e. The tracked subject has a similar color or pattern to its surrounding environment.
f. The lighting is extremely dark (<300 lux) or bright (>10,000 lux).
• Make sure to follow local privacy laws and regulations when using FocusTrack.
• It is recommended to only track vehicles, boats, and people (but not children). Fly with
caution when tracking other subjects.
• For the supported moving subjects, vehicles refer to cars and small to medium-sized
boats. DO NOT track a remotely controlled model car or boat.
• The tracking subject may be inadvertently swapped to another subject if they pass
nearby each other.
• In Photo mode, FocusTrack is only available when using Single.
• FocusTrack is unavailable in the Night video mode.
• ActiveTrack is unavailable when lighting is insufficient and the vision systems are
unavailable. Spotlight and POI for static subjects can still be used, but obstacle sensing
is not available.
• FocusTrack is unavailable when the aircraft is on the ground.
• FocusTrack may not function properly when the aircraft is ying near ight limits or in a
GEO Zone.
• If the subject is obstructed and it is lost by the aircraft, the aircraft will keep ying at
the current speed and orientation for 8 seconds to try and re-identify the subject. If the
aircraft fails to re-identify the subject in 10 seconds, it will exit ActiveTrack automatically.
MasterShots keeps the subject at the center of the frame while executing dierent maneuvers
in sequence to generate a short cinematic video.
Using MasterShots
1. Launch the aircraft and make it hover at least 2 m (6.6 ft) above ground.
2m
2. In DJI Fly, tap the shooting mode icon to select MasterShots and read the instructions.
Make sure you understand how to use the shooting mode and there are no obstacles in the
surrounding area.
3. Drag-select the subject in the camera view, and set the ight range. Enter the map view to
check the estimated flight range and flight paths, and ensure there is no obstacle in the
flight range, such as high buildings. Tap Start, the aircraft will start flying and recording
automatically. The aircraft will y back to its original position once recording is nished.
4. Tap to access, edit, or share the video to social media.
Press the Flight Pause button once or tap in DJI Fly to exit MasterShots. The aircraft will brake
and hover.
• Use MasterShots at locations that are clear of buildings and other obstacles. Make sure
there are no humans, animals, or other obstacles in the ight path. When the lighting is
sucient and the environment is suitable for vision systems, the aircraft will brake and
hover in place if there is an obstacle detected.
• Always pay attention to objects around the aircraft and use the remote controller to
avoid collisions or the aircraft getting obstructed.
• DO NOT use MasterShots in any of the following situations:
a. When the subject is blocked for an extended period or outside the line of sight.
b. When the subject is similar in color or pattern with the surroundings.
c. When the subject is in the air.
d. When the subject is moving fast.
e. The lighting is extremely dark (<300 lux) or bright (>10,000 lux).
• DO NOT use MasterShots in places close to buildings or where the GNSS signal is weak.
Otherwise, the ight path may become unstable.
• Make sure to follow local privacy laws and regulations when using MasterShots.
QuickShots
Click the link below or scan the QR code to watch
the tutorial video.
https://s.dji.com/intelligent-flight
QuickShots shooting modes include Dronie, Rocket, Circle, Helix, Boomerang, and Asteroid. The
aircraft records according to the selected shooting mode and automatically generates a short
video. The video can be viewed, edited, or shared to social media from playback.
The aircraft ies backward and ascends with the camera locked on the subject.
Dronie:
The aircraft ascends with the camera pointing downward.
Rocket:
The aircraft circles around the subject.
Circle:
The aircraft ascends and spirals around the subject.
Helix:
Boomerang:
away from its starting point and descending as it flies back. The starting point of the
aircraft forms one end of the long axis of the oval, while the other end is at the opposite
side of the subject from the starting point.
The aircraft flies around the subject in an oval path, ascending as it flies
back to the starting point. The video generated starts with a panorama of the highest
position and then shows the view from the aircraft as it descends.
• Make sure there is sucient space when using Boomerang. Allow a radius of at least 30
• Make sure there is sufficient space when using Asteroid. Allow at least 40 m (131 ft)
The aircraft flies backward and upward, takes several photos, and then flies
m (99 ft) around the aircraft and a space of at least 10 m (33 ft) above the aircraft.
behind and 50 m (164 ft) above the aircraft.
Using QuickShots
1. Launch the aircraft and make it hover at least 2 m (6.6 ft) above ground.
2m
2. In DJI Fly, tap the shooting mode icon to select QuickShots and follow the prompts. Make
sure you understand how to use the shooting mode and there are no obstacles in the
surrounding area.
3. Choose a sub-mode, drag-select the subject in the camera view. Tap Start, the aircraft will
start ying and recording automatically. The aircraft will y back to its original position once
recording is nished.
4. Tap to access, edit, or share the video to social media.
Exiting QuickShots
Press the Flight Pause button once or tap in DJI Fly to exit QuickShots. The aircraft will brake
and hover. Tap the screen again and the aircraft will continue shooting.
Note: if you accidentally move a control stick, the aircraft will exit QuickShots and hover in place.
• Use QuickShots at locations that are clear of buildings and other obstacles. Make sure
there are no people, animals, or other obstacles in the ight path. The aircraft will brake
and hover in place if there is an obstacle detected.
• Always pay attention to objects around the aircraft and use the remote controller to avoid
collisions or the aircraft getting obstructed.
• DO NOT use QuickShots in any of the following situations:
a. When the subject is blocked for an extended period or outside the line of sight.
b. When the subject is more than 50 m away from the aircraft.
c. When the subject is similar in color or pattern with the surroundings.
d. When the subject is in the air.
e. When the subject is moving fast.
f. The lighting is extremely dark (<300 lux) or bright (>10,000 lux).
• DO NOT use QuickShots in places close to buildings or where the GNSS signal is weak.
Otherwise, the ight path will become unstable.
• Make sure to follow local privacy laws and regulations when using QuickShots.
Hyperlapse
Click the link below or scan the QR code to watch
the tutorial video.
https://s.dji.com/intelligent-flight
Hyperlapse shooting modes include Free, Circle, Course Lock, and Waypoint.
• After selecting the Hyperlapse shooting mode, go to Settings > Camera > Hyperlapse in
DJI Fly to select the photo type of the original hyperlapse photos to be saved, or select
O to not save any original hyperlapse photos. It is recommended to store the footage
in the microSD card of the aircraft.
• For optimal performance, it is recommended to use Hyperlapse at an altitude higher
than 50 m and set a dierence of at least two seconds between the interval time and
shutter speed.
• It is recommended to select a static subject (e.g., high-rise buildings, mountainous
terrain) located at a safe distance from the aircraft (further than 15 m). DO NOT select a
subject that is too close to the aircraft or people or a moving car, etc.
• When the lighting is sucient and the environment is suitable for vision systems, the
• The aircraft will only generate a video after at least 25 photos have been taken, which
User Manual
aircraft will brake and hover in place if an obstacle is detected during Hyperlapse. If the
lighting becomes insucient or the environment is unsuitable for the vision systems to
operate during Hyperlapse, the aircraft will continue shooting without obstacle sensing.
Fly with caution.
is the amount required to generate a one-second video. The video will be generated by
default regardless of whether Hyperlapse concludes normally or the aircraft exits from
the mode unexpectedly (such as when Low Battery RTH is triggered).
Free
The aircraft automatically takes photos and generates a timelapse video.
Free mode can be used while the aircraft is on the ground.
After takeo, the aircraft’s movements and gimbal tilt can be controlled. Drag-select a subject
on the screen, the aircraft will move around the subject when moving the control sticks
manually.
Follow the steps below to use Free:
1. Set the interval time, video length, and max speed. The screen displays the number of
photos that will be taken and the shooting duration.
2. Tap the shutter/record button to begin.
Circle
The aircraft automatically takes photos while flying around the selected subject to generate
a timelapse video. During ight, move the roll stick to adjust the circling speed of the aircraft
around the subject, the throttle stick to adjust the altitude, and the pitch stick to adjust the
distance from the subject.
1. Set the interval time, video length, speed, and circle direction. The screen displays the
number of photos that will be taken and the shooting duration.
2. Drag-select a subject on the screen. Use the yaw stick and gimbal dial to adjust the frame.
3. Tap the shutter/record button to begin.
Course Lock
Course Lock allows the user to lock the ight direction. While doing so, the user may select a
subject for the camera to point toward while taking hyperlapse photos.
During ight, move the roll stick to adjust the ight path horizontally, the throttle stick to adjust
the altitude, and the pitch stick to adjust the ight speed.
If there is only ight direction locked and no subject is selected, then the aircraft orientation and
gimbal tilt can be adjusted.
Follow the steps below to use Course Lock:
1. Adjust the aircraft to the desired orientation, and then tap
as the ight direction.
2. Set the interval time, video length, and speed. The screen displays the number of photos
that will be taken and the shooting duration.
3. If applicable, drag-select a subject. After selecting the subject, the aircraft will automatically
adjust the orientation or gimbal angle to center the subject in the camera view. At this time,
the frame cannot be adjusted manually.
4. Tap the shutter/record button to begin.
to lock the current orientation
Waypoints
The aircraft automatically takes photos on a ight path of multiple waypoints and generates a
timelapse video. The aircraft can y in sequence from the rst waypoint to the nal waypoint or
in reverse order. The aircraft will not respond to the remote controller stick movements during
ight.
Follow the steps below to use Waypoints:
1. Set the desired waypoints. Fly the aircraft to the desired locations and adjust the aircraft
orientation and the gimbal tilt.
2. Set the shooting order, interval time, and video length. The screen displays the number of
photos that will be taken and the shooting duration.
3. Tap the shutter/record button to begin.
The aircraft will generate a timelapse video automatically, which is viewable in playback.
Waypoint Flight enables the aircraft to capture images during a ight according to the waypoint
flight route generated by the preset waypoints. Points of Interest (POI) can be linked to the
waypoints. The heading will point toward the POI during ight. A waypoint ight route can be
saved and repeated.
Using Waypoint Flight
1. Enable Waypoint Flight
Tap on the left of the camera view in DJI Fly to enable Waypoint Flight.
• When pinning a waypoint, it is recommended to y to the location for a more accurate
and smoother imaging result.
• The aircraft horizontal GNSS position, altitude from the takeo point, heading, gimbal
tilt, and camera zoom ratio at this waypoint will be recorded if the waypoint is pinned
during ight via the remote controller or the operation panel.
• Connect the remote controller to the internet and download the map before using
the map to pin a waypoint. When the waypoint is pinned via the map, only the aircraft
horizontal GNSS position can be recorded, and the default altitude of the waypoint is
set to 50 m from the takeo point.
• The flight route will curve between waypoints, so the aircraft altitude between
waypoints may become lower than the altitudes of the waypoints during the flight.
Make sure to avoid any obstacles below when setting a waypoint.
b. Settings
Tap the waypoint number for settings, the waypoint parameters are described as follows:
Camera ActionThe camera action at the waypoint. Choose between None, Take Photo, and
Start or Stop Recording.
AltitudeThe altitude at the waypoint from the takeo point. Make sure to take o at
the same takeo altitude of the original ight to obtain higher accuracy of
altitude when a Waypoint Flight is repeated.
SpeedThe ight speed from the current waypoint to the next waypoint.
• Global Speed: the aircraft will y at the set global speed from the current
waypoint to the next waypoint.
• Custom: the aircraft will smoothly accelerate or decelerate from the
current waypoint to the next waypoint, and reach the custom speed during
the process.
HeadingThe aircraft heading at the waypoint.
• Follow Course: the heading of the aircraft is the same as the horizontal
tangent to the ight route.
[1]
: tap the POI number to point the aircraft heading toward the specic
• POI
POI.
• Manual: the aircraft heading between the previous waypoint and the
current waypoint can be adjusted by the user during a Waypoint Flight.
• Custom: drag the bar to adjust the heading. The heading can be previewed
in the map view.
Gimbal TiltThe gimbal tilt at the waypoint.
[1]
: tap the POI number to point the camera toward the specic POI.
• POI
• Manual: the gimbal tilt between the previous waypoint and the current
waypoint can be adjusted by the user during a Waypoint Flight.
• Custom: drag the bar to adjust the tilt of the gimbal.
ZoomThe camera zoom at the waypoint.
[2]
• Digital Zoom (1-4x)
: drag the bar to adjust the zoom ratio.
• Manual: the zoom ratio between the previous waypoint and the current
waypoint can be adjusted by the user during a Waypoint Flight.
[3]
: the zoom ratio from the previous waypoint to the next waypoint
• Auto
will be adjusted smoothly by the aircraft.
Hovering TimeThe duration of the aircraft hovering at the current waypoint.
[1] Before selecting POI for heading or gimbal tilt, make sure there are POIs in the ight route. If a POI is
linked to a waypoint, the heading and gimbal tilt of the waypoint will be reset to toward the POI.
[2] The actual zoom ratio depends on the shooting mode. 12MP Photo: 1-2x, 4K: 1-3x, FHD: 1-4x.
[3] The zoom of the Start Point and the End Point cannot be set to Auto.
The currently selected parameter setting (all the settings except camera action) can be
applied to all waypoints after selecting Apply to All. Tap to delete the currently selected
waypoint.
Tap POI on the operation panel to switch to POI settings. Use the same method to pin a POI
as used with a waypoint.
Tap the POI number to set the altitude of the POI and link the POI to waypoints.
AltitudeAfter setting the altitude of the POI, which is the actual altitude of the subject,
the gimbal will adjust the pitch angle to ensure that the camera points toward
the POI.
Link Waypoint Multiple waypoints can be linked to the same POI, and the camera will point
toward the POI during the Waypoint Flight.
5. Perform a Waypoint Flight
• Check the Obstacle Avoidance settings in Settings > Safety page of DJI Fly before
performing a Waypoint Flight. When set to Bypass or Brake, the aircraft will brake and
hover in place if an obstacle is detected during the Waypoint Flight. The aircraft cannot
sense obstacles if the Obstacle Avoidance Action is disabled. Fly with caution.
• Observe the environment and ensure there are no obstacles on the route before
performing a Waypoint Flight.
• Make sure to maintain visual line of sight (VLOS) of the aircraft. Always be prepared to
press the ight pause button in case any emergency situation occurs.
• When the remote controller signal is lost during flight, the aircraft will perform the
action set in On Signal Lost.
• When the Waypoint Flight is nished, the aircraft will perform the action set in End of
Flight.
a. Tap Next or
on the operation panel to enter the ight route parameters setting page
and check again. Users can change the Start Point if necessary. Tap GO to upload the
waypoint ight task. Tap to cancel the uploading process and return to the ight route
parameters setting page.
b. The waypoint ight task will be performed after uploading. The ight duration, waypoints,
and distance will be displayed on the camera view. The pitch stick can be used to change
the ight speed during a Waypoint Flight.
c. Tap
to pause the Waypoint Flight after the task begins. Tap to continue the
Waypoint Flight. Tap
to stop Waypoint Flight and return to the ight route parameters
setting page.
6. Library
When planning a Waypoint Flight, the task will be generated automatically and saved every
on the left to enter Library and save the task manually.
DJI Mini 4 Pro
User Manual
• In the ight route library, you can check the saved tasks, and tap to open or edit a task.
• Tap
to edit the name of the task.
• Slide left to delete a task.
• Tap the icon on the top right corner to change the order the tasks are displayed.
: tasks will be sorted based on the date they were saved.
: tasks will be sorted based on the distance between the current position of the remote
controller and the start waypoints, from closest to farthest.
7. Exit Waypoint Flight
to exit Waypoint Flight. Tap Save and Exit to save the task to Library and exit.
Tap
Cruise Control
Click the link below or scan the QR code to watch
the tutorial video.
https://s.dji.com/intelligent-flight
The cruise control function enables the aircraft to lock the current control stick input of the
remote controller when conditions permit, and to automatically y at the speed corresponding
to the current control stick input. Without the need to continually move the control sticks, longdistance ights become more eortless, and image shaking which often happens during manual
operating can be avoided. More camera movements such as spiraling up can be achieved by
increasing the control stick input.
Go to DJI Fly, select Settings > Control > Button Customization, and then set the customizable
button of the remote controller to Cruise Control.
2. Enter Cruise Control
• Press the cruise control button while pushing the control stick(s), then the aircraft will
y at the current speed according to the control stick input. The control stick(s) can be
released and will automatically return to the center.
• Before the control stick(s) returns to the center, press the cruise control button again to
reset the ight speed based on the current control stick input.
• Push the control stick(s) after returning to the center, the aircraft will y at the updated
speed based on the previous speed. In this case, press the cruise control button again,
and the aircraft will automatically y at the updated speed.
3. Exit Cruise Control
Press the cruise control button without a control stick input, press the ight pause button on
the remote controller, or tap
and hover.
• Cruise control is available when the user is manually operating the aircraft in
Normal, Cine, and Sport mode. Cruise control is also available when using APAS,
Free Hyperlapse, and Spotlight.
• Cruise control cannot be started without a control stick input.
• The aircraft cannot enter or will exit cruise control in the following situations:
a. When near the Max Altitude or Max Distance.
b. When the aircraft disconnects from the remote controller or DJI Fly.
c. When the aircraft senses an obstacle and thus brakes and hovers in place.
d. During RTH or auto landing.
e. When switching ight modes.
• The obstacle sensing in cruise control follows the current flight mode. Fly with
caution.
on the screen to exit cruise control. The aircraft will brake
The aircraft contains a ight controller,
video downlink system, vision systems,
infrared sensing system, propulsion
system, and an Intelligent Flight
Battery.
DJI Mini 4 Pro
User Manual
Aircraft
The aircraft contains a ight controller, video downlink system, vision systems, infrared sensing
system, propulsion system, and an Intelligent Flight Battery.
Flight Mode
The aircraft supports the following flight modes, which can be switched via the Flight Mode
switch on the remote controller.
Normal Mode
The aircraft utilizes GNSS, the omnidirectional vision system, the downward vision system,
and the 3D infrared sensing system to locate itself and stabilize. When the GNSS signal is
strong, the aircraft uses GNSS to locate itself and stabilize. When the GNSS is weak, but the
lighting and other environmental conditions are sucient, the aircraft uses the vision systems
for positioning. When the vision systems are enabled, and lighting and other environmental
conditions are sucient, the maximum pitch angle is 30° and the maximum horizontal speed is
12 m/s.
Sport Mode
In Sport Mode, the aircraft uses GNSS and the downward vision system for positioning, and the
aircraft responses are optimized for agility and speed, making it more responsive to control
stick movements. The maximum horizontal speed is 16 m/s. Note that obstacle sensing is
disabled in Sport Mode.
Cine Mode
Cine mode is based on Normal mode with a limited ight speed, making the aircraft more stable
during shooting.
The aircraft automatically changes to Attitude (ATTI) mode when the vision systems are
unavailable or disabled and the GNSS signal is weak or the compass experiences interference. In
ATTI mode, the aircraft may be more easily aected by its surroundings. Environmental factors
such as wind can result in horizontal drift of the aircraft, which may present hazards especially
when ying in conned spaces. The aircraft will not be able to hover or brake automatically,
therefore the pilot should land the aircraft as soon as possible to avoid accidents.
• The ight modes are only eective for manual ight and cruise control.
• The vision systems are disabled in Sport mode, which means the aircraft cannot sense
obstacles on its route automatically. The user must stay alert to the surrounding
environment and control the aircraft to avoid obstacles.
• The maximum speed and braking distance of the aircraft signicantly increase in Sport
mode. A minimum braking distance of 30 m is required in windless conditions.
• A minimum braking distance of 10 m is required in windless conditions while the
aircraft is ascending and descending in Sport mode or Normal mode.
• The responsiveness of the aircraft signicantly increases in Sport mode, which means a
small control stick movement on the remote controller translates into the aircraft moving
a large distance. Make sure to maintain adequate maneuvering space during ight.
• The ight speed and attitude are both restricted when the aircraft is ying left or right
to ensure shooting stability. The restriction reaches its maximum when the tilt of the
gimbal is -90°. If there are strong winds, the restriction will be disabled to improve the
wind resistance of the aircraft. As a result, the gimbal may vibrate while shooting.
• Users may experience a minor tremor in videos recorded in Sport mode.
Aircraft Status Indicators
The aircraft has two aircraft status indicators.
User Manual
Aircraft Status Indicator
When the aircraft is powered on, but the motors are not running,
Aircraft Status Indicator
the aircraft status
indicators will display the current status of the ight control system. Refer to the table below for
more information about the aircraft status indicators.
Aircraft Status Indicators Descriptions
Normal States
Blinks red, yellow, and green
alternately
Powering on and performing self-diagnostic
tests
×4 Blinks yellow four timesWarming up
Blinks green slowlyGNSS enabled
×2 Blinks green twice repeatedlyVision systems enabled
Blinks yellow slowly
GNSS and vision systems disabled (ATTI
mode enabled)
Warning States
Blinks yellow quicklyRemote controller signal lost
Blinks red slowlyTakeo is disabled, e.g. low battery
[1]
Blinks red quicklyCritically low battery
— Solid redCritical error
Blinks red and yellow alternately Compass calibration required
[1] If the aircraft cannot takeo while the status indicators are blinking red slowly, view the warning prompt
which indicate the aircraft is a UAV. While in Chinese Mainland, the status indicator on the left
side of the aircraft blinks red and the status indicator on the right side blinks green.
• Lighting requirements vary depending on the region. Observe local laws and
regulations.
the aircraft status indicators will blink green for conspicuity purpose,
Return to Home
Click the link below or scan the QR code to watch
the tutorial video.
https://s.dji.com/RTH
The Returnto Home (RTH) functionbrings the aircraft backto the last recordedHome Point.
The RTH can be triggered in three ways: the user actively triggers RTH, the aircraft has low
battery, or the control signal between the remote controller and the aircraft is lost. If the aircraft
records the Home Point successfully and the positioning system is functioning normally, when
the RTH function is triggered, the aircraft will automatically y back and land at the Home Point.
GNSS
The first location where the aircraft receives a strong to moderately strong
GNSS signal (indicated by a white icon) will be recorded as the default
Home Point. The Home Point can be updated before takeoff as long as the
Home
Point
During RTH, the aircraft will automatically adjust the gimbal tilt to point the camera toward the
RTH route by default. If the video transmission signal is normal, the AR Home Point, AR RTH
route, and AR aircraft shadow will be displayed in the camera view by default. This improves the
ight experience by helping users view the RTH route and Home Point and avoid obstacles on
the route. The display can be changed in System Settings > Safety > AR Settings.
aircraft receives another strong to moderately strong GNSS signal. If the
10
signal is weak, the Home Point will not be updated. After the Home Point is
recorded, DJI Fly will issue a voice prompt.
If it is necessary to update the Home Point during a flight (such as where
the position of the user has changed), the Home Point can be manually
updated in Settings > Safety page in DJI Fly.
Descriptions
• The AR RTH route is only used for reference, and may deviate from the actual flight
route in dierent scenarios. Always pay attention to the liveview on the screen during
RTH. Fly with caution.
• During RTH, use the gimbal dial to adjust the camera orientation or press the
customizable buttons on the remote controller to recenter the camera will stop the
aircraft from automatically adjusting the gimbal tilt, which may prevent the AR RTH
route from being viewed.
• When reaching the Home Point, the aircraft will automatically adjust the gimbal tilt
vertically down.
User Manual
Advanced RTH
When Advanced RTH is triggered, the aircraft will automatically plan the best RTH path, which
will be displayed in DJI Fly and will adjust according to the environment.
If the control signal between the remote controller and the aircraft is good, exit RTH by tapping
in DJI Fly or by pressing the RTH button on the remote controller. After exiting RTH, users will
regain control of the aircraft.
Trigger Method
•
The user actively triggers RTH
Advanced RTH can be initiated either by tapping in DJI Fly or by pressing and holding the
RTH button on the remote controller until it beeps.
•
Aircraft low battery
When the Intelligent Flight Battery level is too low and there is not enough power to return
home, land the aircraft as soon as possible.
To avoid unnecessary danger caused by insufficient power, the aircraft automatically
calculates if the battery power is sufficient to return to the Home Point according to the
current position, environment, and flight speed. A warning prompt will appear in DJI Fly
when the battery level is low and only enough to complete an RTH ight. The aircraft will
automatically y to the Home Point if no action is taken after a countdown.
The user can cancel RTH by pressing the RTH button on the remote controller. If RTH is
canceled following the warning, the Intelligent Battery may not have enough power for the
aircraft to land safely, which may lead to the aircraft crashing or being lost.
The aircraft will land automatically if the current battery level can only support the aircraft
long enough to descend from its current altitude. Auto landing cannot be canceled, but the
remote controller can be used to control the horizontal movement and the descent speed
of the aircraft during landing. If there is sucient power, the throttle stick can be used to
make the aircraft ascend at a speed of 1 m/s.The aircraft will initiate force landing when the
available battery power is depleted, and the throttle stick cannot be pushed to change the
descent speed.
During auto landing, move the aircraft horizontally to nd an appropriate place to land as
soon as possible. The aircraft will fall if the user keeps pushing the throttle stick upward until
the power is depleted.
•
Loss of remote controller signal
The action of the aircraft when the remote controller signal is lost can be set to RTH, land, or
hover in Setting >Safety > Advanced Safety Settings in DJI Fly. If the action is set to RTH, the
Home Point was successfully recorded and the compass is functioning normally, Failsafe RTH
automatically activates after the remote controller signal is lost for more than six seconds.
When the lighting is sufficient and the environment is suitable for the vision systems to
work normally, DJI Fly will display the RTH path that was generated by the aircraft before the
remote controller signal was lost. The aircraft will start RTH using Advanced RTH according
to the RTH settings. The aircraft will remain in RTH even if the remote controller signal is
restored. DJI Fly will update the RTH path accordingly.
When the lighting is not sucient or the environment is not suitable for the vision systems
to work normally, the aircraft will enter Original Route RTH. The aircraft will enter or remain
in Preset RTH if the remote controller signal is restored during RTH. The Original Route RTH
procedure is as follows:
1. The aircraft brakes and hovers in place.
2. When RTH begins:
• If the RTH distance (the horizontal distance between the aircraft and the Home Point)
is farther than 50 m, the aircraft adjusts its orientation and ies backward for 50 m on
its original ight route before entering Preset RTH.
• If the RTH distance is farther than 5 m but less than 50 m, it adjusts its orientation and
ies to the Home Point in a straight line at the current altitude.
• The aircraft lands immediately if the RTH distance is less than 5 m.
3. The aircraft begins to land when it reaches above the Home Point.
• If RTH is triggered through DJI Fly and the RTH distance is farther than 5 m, DJI Fly will
display the two following options: RTH and Landing. Users can select either RTH or
directly land the aircraft.
• The aircraft may not be able to return to the Home Point normally if the positioning
system is functioning abnormally. During Failsafe RTH, the aircraft may enter ATTI mode
and land automatically if the positioning system is functioning abnormally.
• It is important to set a suitable RTH altitude before each ight. Launch DJI Fly and set
the RTH altitude. The default RTH altitude is 100 m.
• The aircraft cannot sense obstacles during Failsafe RTH if the vision systems are
unavailable.
• GEO zones may aect the RTH. Avoid ying near GEO zones.
• The aircraft may not be able to return to a Home Point when the wind speed is too high.
Fly with caution.
• Pay extra attention to small or fine objects (such as tree branches or power lines)
or transparent objects (such as water or glass) during RTH. Exit RTH and control the
aircraft manually in an emergency.
• RTH cannot be activated during auto landing.
User Manual
RTH Procedure
1. The Home Point is recorded.
2. Advanced RTH is triggered.
3. The aircraft brakes and hovers in place. When RTH begins:
• The aircraft lands immediately if the RTH distance is less than 5 m.
• If the RTH distance is farther than 5 m, the aircraft will adjust its orientation to the Home
Point and plan the best path according to the RTH settings, lighting, and environmental
conditions.
4. The aircraft will fly automatically according to the RTH settings, environment, and
transmission signal during RTH.
5. The aircraft lands and the motors stop after reaching the Home Point.
RTH Settings
RTH settings are available for Advanced RTH. Go to the camera view in DJI Fly, tap Settings >
Safety, and then RTH.
1. Optimal:
• If the lighting is sufficient and the environment is suitable for the vision systems, the
aircraft will automatically plan the optimal RTH path and adjust the altitude according to
environmental factors, such as obstacles and transmission signals, regardless of the RTH
Altitude setting. The optimal RTH path means the aircraft will travel the shortest distance
possible to reduce the amount of battery power used and to increase ight time.
• If the lighting is insucient or the environment is not suitable for the vision systems, the
aircraft will execute Preset RTH based on the RTH Altitude setting.
When the aircraft is approaching the Home Point, if the current altitude is higher than the RTH
altitude, the aircraft will intelligently decide whether to descend while ying forward according
to the surrounding environment, lighting, the set RTH altitude, and the current altitude. When
the aircraft reaches above the Home Point, the current altitude of the aircraft will not be lower
than the set RTH altitude. Note that when the lighting is insucient or the environment is not
suitable for the vision systems, the aircraft cannot avoid obstacles. Make sure to set a safe
RTH altitude and pay attention to the surrounding environment to ensure ight safety.
The RTH plans for dierent environments, RTH trigger methods, and RTH settings are as follows:
RTH altitude
Current altitude ≥
RTH altitude
Suitable for Vision
Lighting and
Environment Conditions
The user actively triggers
RTH
Aircraft low battery
Loss of remote controller
signal
The aircraft can bypass
obstacles and GEO zones
The aircraft will execute RTH
based on the RTH setting:
• Optimal
• Preset
Suitable for Vision
Systems
The aircraft will plan the RTH
path, fly to an open area
while bypassing obstacles,
<
ascend to the RTH Altitude,
and return to home using
the best path.
The aircraft will return to
home using the best path at
the current altitude.
Systems
Unsuitable for Vision
Systems
The aircraft will ascend
to the RTH altitude, and
fly to the Home Point
in a straight line at the
RTH altitude.
The aircraft will fly
to the Home Point in
a straight line at the
current altitude.
Unsuitable for Vision
Systems
The aircraft cannot bypass
obstacles but can bypass GEO
zones
Preset
Original route RTH,
Preset RTH will be executed
when the signal is restored
• During Advanced RTH, the aircraft will adjust the flight speed automatically to suit
environmental factors such as wind speed and obstacles.
• The aircraft cannot avoid small or ne objects such as tree branches or power lines. Fly
the aircraft to an open area before using RTH.
• Set Advanced RTH as Preset if there are power lines or towers that the aircraft cannot
bypass on the RTH path and make sure the RTH Altitude is set higher than all obstacles.
• The aircraft will brake and return to home according to the latest settings if the RTH
settings are changed during RTH.
• If the max altitude is adjusted below the current altitude during RTH, the aircraft will
descend to the max altitude rst and then continue returning to home.
• The RTH Altitude cannot be changed during RTH.
• If there is a large difference between the current altitude and the RTH altitude, the
amount of battery power used cannot be calculated accurately due to wind speed
dierence at dierent altitudes. Pay extra attention to the battery power prompts and
warning prompts in DJI Fly.
• During Advanced RTH, the aircraft will enter Preset RTH if the lighting condition or
environment becomes unsuitable for the vision systems. In this case, the aircraft cannot
bypass the obstacles. An appropriate RTH altitude must be set before entering RTH.
• When the remote controller signal is normal during Advanced RTH, the pitch stick can
be used to control the ight speed, but the orientation and altitude cannot be controlled
and the aircraft cannot be controlled to y to the left or right. Constantly pushing the
pitch stick to accelerate will increase the battery power consumption speed. The aircraft
cannot bypass obstacles if the flight speed exceeds the effective sensing speed. The
aircraft will brake and hover in place and exit RTH if the pitch stick is pushed all the way
down. The aircraft can be controlled after the pitch stick is released.
• If the aircraft reaches the altitude limit of the aircraft current location or of the Home
Point while it is ascending during Preset RTH, the aircraft stops ascending and returns
to the Home Point at the current altitude. Pay attention to ight safety during RTH.
• If the Home Point is within the Altitude Zone but the aircraft is not, when the aircraft
reaches the Altitude Zone it will descend below the altitude limit, which may be lower
than the set RTH altitude. Fly with caution.
• The aircraft will bypass any GEO zones encountered when it is ying forward during
Advanced RTH. Fly with caution.
• The aircraft will exit RTH if the surrounding environment is too complex to complete
RTH, even if the vision systems are working properly.
• If the O4 video transmission is obstructed and disconnects, the aircraft can only rely
on the 4G connectivity of Enhanced Transmission. Considering there may be large
obstacles on the RTH route, to ensure safety during RTH, the RTH route will take the
previous flight path as reference. When using Enhanced Transmission, pay more
attention to the battery status and the RTH route in the map.
Landing Protection is enabled once the aircraft begins to land.
1. During Landing Protection, the aircraft will automatically detect and carefully land on
suitable ground.
2. If the ground is determined unsuitable for landing, the aircraft will hover and wait for pilot
conrmation.
3. If Landing Protection is not operational, DJI Fly will display a landing prompt when the
aircraft descends to 0.5 m from the ground. Tap conrm or push the throttle stick all the
way down and hold for one second, and the aircraft will land.
Precision Landing
The aircraft automatically scans and attempts to match the terrain features below during RTH.
The aircraft will land when the current terrain matches the Home Point. A prompt will appear in
DJI Fly if the terrain match fails.
• Landing Protection is activated during Precision Landing.
• The performance of Precision Landing is subject to the following conditions:
a. The Home Point must be recorded upon takeo and must not be changed during
ight. Otherwise, the aircraft will have no record of the terrain features of the Home
Point.
b. During takeo, the aircraft must ascend at least 7 m before moving horizontally.
c. The Home Point terrain features must remain largely unchanged.
d. The terrain features of the Home Point must be suciently distinctive. Terrain such
as a snow-covered eld is not suitable.
e. The lighting conditions must not be too bright or too dark.
• The following actions are available during Precision Landing:
a. Press the throttle stick down to accelerate landing.
b. Movement of any other control stick apart from the throttle stick will be regarded
as giving up Precision Landing. The aircraft will descend vertically after the control
sticks are released. Landing Protection is still eective in this case.
DJI Mini 4 Pro is equipped with both an omnidirectional vision system (forward, backward,
lateral, upward), downward vision system, and 3D infrared sensing system, which allows for
positioning and omnidirectional obstacle sensing.
The omnidirectional vision system consists of four cameras which are located at the front of
the aircraft. The downward vision system consists of two cameras, located at the bottom of the
aircraft. The vision systems sense obstacles by image ranging.
The 3D infrared sensing system on the bottom consists of a 3D infrared emitter and a receiver.
The 3D infrared sensing system helps the aircraft to assess the distance to obstacles, the
distance to the ground, and calculate the aircraft position together with the downward vision
system. The 3D infrared sensing system meets the human eye safety requirement for Class 1
laser products.
The auxiliary light located at the bottom of the aircraft can assist the downward vision system.
It will automatically turn on by default in low-light environments when the flight altitude is
under 5 m. Users can also turn it on or o manually in the DJI Fly app. Each time the aircraft is
restarted, the auxiliary light will revert back to the default setting Auto.
Omnidirectional Vision System
Omnidirectional
Vision System
Auxiliary Light
Downward Vision System
3D Infrared Sensing System
Detection Range
Forward Vision System
Backward Vision System
Lateral Vision System
Upward Vision System
Downward Vision System
3D Infrared Sensing System
[1] The omnidirectional vision system can sense obstacles in horizontal directions and above.
Precision Measurement Range: 0.5-18 m;
FOV: 90° (horizontal), 72° (vertical)
Precision Measurement Range: 0.5-15 m;
FOV: 90° (horizontal), 72° (vertical)
Precision Measurement Range: 0.5-12 m;
FOV: 90° (horizontal), 72° (vertical)
[1]
Precision Measurement Range: 0.5-15 m;
FOV: 72° (front and back), 90° (left and right)
Precision Measurement Range: 0.3-12 m;
FOV: 106° (front and back), 90° (left and right)
Hovering Range: 0.5-30 m
Precision Measurement Range: 0.1-8 m (> 10% reflectivity);
FOV: 60° (front and back),60° (left and right)
The positioning function of the downward vision system is applicable when GNSS signals are
unavailable or weak. It is automatically enabled in Normal or Cine mode.
The omnidirectional vision system will activate automatically when the aircraft is in Normal
or Cine mode and Obstacle Avoidance is set to Bypass or Brake in DJI Fly. The omnidirectional
vision system works best with adequate lighting and clearly marked or textured obstacles. Due
to inertia, users must make sure to brake the aircraft within a reasonable distance.
Vision Positioning and Obstacle Sensing can be disabled in System Settings > Safety > Advanced
Safety Settings in DJI Fly.
• Pay attention to the ight environment. The vision system and the 3D infrared sensing
system only work in certain scenarios and cannot replace human control and judgment.
During a ight, always pay attention to the surrounding environment and the warnings
in DJI Fly, and be responsible for and maintain control of the aircraft at all times.
• The downward vision system works best when the aircraft is at an altitude from 0.5 to
30 m if there is no GNSS available. Extra caution is required if the altitude of the aircraft
is above 30 m as the vision positioning performance may be aected.
• In low-light environments, the vision systems may not achieve optimal positioning
performance even if the auxiliary light is turned on. Fly with caution if the GNSS signal is
weak in such environments.
• The downward vision system may not work properly when the aircraft is flying near
water. Therefore, the aircraft may not be able to actively avoid water below it when
landing. It is recommended to maintain flight control at all times, make reasonable
judgments based on the surrounding environment, and avoid over-relying on the
downward vision system.
• The vision systems cannot accurately identify large structures with frames and cables,
such as tower cranes, high-voltage transmission towers, high-voltage transmission lines,
cable-stayed bridges, and suspension bridges.
• The vision systems cannot work properly near surfaces without clear pattern variations
or where the light is too weak or too strong. The vision systems cannot work properly in
the following situations:
a. Flying near monochrome surfaces (e.g., pure black, white, red, or green).
b. Flying near highly reective surfaces.
c. Flying near water or transparent surfaces.
d. Flying near moving surfaces or objects.
e. Flying in an area with frequent and drastic lighting changes.
f. Flying near extremely dark (< 10 lux) or bright (> 40,000 lux) surfaces.
g. Flying near surfaces that strongly reect or absorb infrared waves (e.g., mirrors).
h. Flying near surfaces without clear patterns or textures.
i. Flying near surfaces with repeating identical patterns or textures (e.g., tiles with the
same design).
j. Flying near obstacles with small surface areas (e.g., tree branches, and power lines).
• Keep the sensors clean at all times. DO NOT scratch or tamper with the sensors. DO
NOT use the aircraft in dusty or humid environments.
• Vision system cameras may need to be calibrated after being stored for an extended
period. A prompt will appear in DJI Fly and calibration will be performed automatically.
• DO NOT y when it is rainy, smoggy, or the visibility is lower than 100 m.
• Check the following each time before takeo:
a. Make sure there are no stickers or any other obstructions over the glass of the
infrared sensing system and vision systems.
b. Use soft cloth if there is any dirt, dust, or water on the glass of the vision systems
and infrared sensing system. DO NOT use any cleaning product that contains
alcohol.
c. Contact DJI Support if there is any damage to the lenses of the infrared sensing and
vision systems.
• DO NOT obstruct the infrared sensing system and vision systems.
• The aircraft can y at any time of the day or night. However, the vision systems become
unavailable when ying the aircraft at night. Fly with caution.
The Advanced Pilot Assistance Systems (APAS) feature is available in Normal mode and Cine
mode. When APAS is enabled, the aircraft will continue to respond to user commands and plan
its path according to both control stick inputs and the ight environment. APAS makes it easier
to avoid obstacles, obtain smoother footage, and give a better ying experience.
Keep moving the control sticks in any direction. The aircraft will bypass obstacles by flying
above, below, or to the left or right of the obstacle. The aircraft can also respond to the control
stick inputs while bypassing obstacles.
When APAS is enabled, the aircraft can be stopped by pressing the Flight Pause button on the
remote controller. The aircraft brakes and hovers for three seconds and awaits further pilot
commands.
To enable APAS, open DJI Fly, enter Settings > Safety, and enable APAS by selecting Bypass.
Select Normal or Nifty mode when using Bypass. In Nifty mode, the aircraft can fly faster,
smoother, and closer to obstacles obtaining better footage while bypassing obstacles. However,
the risk of crashing into obstacles will increase. Fly with caution.
Nifty mode cannot work normally in the following situations:
1. When aircraft orientation changes rapidly ying near obstacles.
2. When ying through narrow obstacles such as canopies or bushes at high speed.
3. When ying near obstacles that are too small to detect.
4. When ying with the propeller guard.
Landing Protection
Landing Protection will activate if Obstacle Avoidance is set to Bypass or Brake and the user
pushes the throttle stick down to land the aircraft. Landing Protection is enabled once the
aircraft begins to land.
1. During Landing Protection, the aircraft will automatically detect if an area is suitable for
landing, and then land the aircraft.
2. If the ground is determined to be unsuitable for landing, the aircraft will hover when the
aircraft descends to 0.8 m above ground. Push down on the throttle stick for at least ve
seconds, and the aircraft will land without obstacle sensing.
• Make sure to use APAS when the vision systems are available. Make sure there are no
people, animals, objects with small surface areas (e.g., tree branches), or transparent
objects (e.g., glass or water) along the desired ight path.
• Make sure to use APAS when the downward vision systems are available or the GNSS
signal is strong. APAS may not function properly when the aircraft is ying over water or
snow-covered areas.
• Be extra cautious when flying in extremely dark (<300 lux) or bright (>10,000 lux)
environments.
• Pay attention to DJI Fly and make sure APAS is working normally.
• APAS may not function properly when the aircraft is ying near ight limits or in a GEO zone.
The vision assist view, powered by the horizontal vision system, changes the horizontal speed
direction (forward, backward, left, and right) to help users navigate and observe obstacles
during ight. Swipe left on the attitude indicator, right on the mini map, or tap the icon in the
lower right corner of the attitude indicator to switch to the vision assist view.
• When using vision assist, the quality of the video transmission may be lower due to
transmission bandwidth limits, cell phone performance, or the video transmission
resolution of the screen on the remote controller.
• It is normal for propellers to appear in the vision assist view.
• Vision assist should be used for reference only. Glass walls and small objects such as
tree branches, electric wires, and kite strings cannot be displayed accurately.
• Vision assist is not available when the aircraft has not taken off or when the video
transmission signal is weak.
Vision Assist View
Direction
Horizontal Speed of
the Aircraft
Collapse
Horizontal Speed of the
Aircraft
The direction of the line indicates the current horizontal
direction of the aircraft, and the length of the line indicates the
Max
Locked
Switch to the Mini
Map
horizontal speed of the aircraft.
Vision Assist View
Direction
Switch to the Mini Map
Collapse
Max
Locked
Indicates the direction of the vision assist view. Tap and hold to
lock the direction.
Tap to switch from the vision assist view to the mini map.
Tap to minimize the vision assist view.
Tap to maximize the vision assist view.
Indicates that the direction of the vision assist view is locked.
Tap to cancel the lock.
• When the direction is not locked in a specific direction, the vision assist view
automatically switches to the current ight direction. Tap any other directional arrow to
switch the direction of the vision assist view for three seconds before returning to the
view of the current horizontal ight direction.
• When the direction is locked in a specic direction, tap any other directional arrow to
switch the direction of the vision assist view for three seconds before returning to the
current horizontal ight direction.
When an obstacle in the current view direction is detected, the vision assist view shows a
collision warning. The color of the warning is determined by the distance between the obstacle
and the aircraft.
Collision Warning ColorDistance between the Aircraft and the Obstacle
Yellow2.2-5 m
Red≤2.2 m
• The FOV of the vision assist in all directions is approximately 80°. It is normal not to see
obstacles in the eld of view during a collision warning.
• The collision warning is not controlled by the Display Radar Map switch and remains
visible even when the radar map is switched o.
• A collision warning appears only when the vision assist view is displayed in the small window.
Flight Recorder
Flight data including flight telemetry, aircraft status information, and other parameters are
automatically saved to the internal data recorder of the aircraft. The data can be accessed using
DJI Assistant 2 (Consumer Drones Series).
Propellers
There are two types of propellers, which are designed to spin in dierent directions. Marks are
used to indicate which propellers should be attached to which motors. Make sure to match the
propellers and motors by following the instructions.
Attach the marked propellers to the motors of the marked arm, and the unmarked propellers to
the motors of the unmarked arm. Use the screwdriver from the aircraft package to mount the
propellers. Make sure the propellers are secure.
MarkedUnmarked
• Make sure to only use the screwdriver from the aircraft package for mounting
propellers. Using other screwdrivers may damage the screws.
• Make sure to keep the screws vertical while tightening them. The screws should not be
at a tilted angle to the mounting surface. After installation is complete, check whether
the screws are ush and rotate the propellers to check for any abnormal resistance.
Detaching the propellers
Use the screwdriver from the aircraft package to loosen the screws and detach the propellers
from the motors.
• Propeller blades are sharp. Handle with care.
• The screwdriver is only for mounting the propellers. DO NOT use the screwdriver to
disassemble the aircraft.
• If a propeller is broken, remove the two propellers and screws on the corresponding
motor and discard them. Use two propellers from the same package. DO NOT mix with
propellers from other packages.
• Only use ocial DJI propellers. DO NOT mix propeller types.
• Propellers are consumable components. Purchase additional propellers if necessary.
• Make sure that the propellers and motors are installed securely before each flight.
Check to make sure the screws on the propellers are tightened after every 30 hours of
ying time (approx. 60 ights).
• Make sure that all propellers are in good condition before each flight. DO NOT use
aged, chipped, or broken propellers.
• To avoid injury, stay away from rotating propellers or motors.
• To avoid damaging the propellers, place the aircraft correctly during transportation or
storage. DO NOT squeeze or bend the propellers. If propellers are damaged, the ight
performance may be aected.
• Make sure the motors are mounted securely and rotating smoothly. Land the aircraft
immediately if a motor is stuck and unable to rotate freely.
• DO NOT attempt to modify the structure of the motors.
• DO NOT touch or let hands or body parts come in contact with the motors after ight,
• DO NOT block any of the ventilation holes on the motors or the body of the aircraft.
• Make sure the ESCs sound normal when powered on.
User Manual
as they may be hot.
Intelligent Flight Battery
DJI Mini 4 Pro Intelligent Flight Battery (BWX140-2590-7.32) is a 7.32V, 2590mAh battery. DJI Mini
3 Pro Intelligent Flight Battery Plus (BWX162-3850-7.38) is a 7.38V, 3850mAh battery. The two
batteries have the same structure and dimensions but have a dierent weight and capacity.
Both batteries are equipped with smart charging and discharging functionality.
Battery Features
1. Balanced Charging: during charging, the voltages of the battery cells are automatically
balanced.
2. Auto-Discharging Function: to prevent swelling, the battery automatically discharges to 96%
battery level when it is idle for three days, and automatically discharges to 60% battery level
when it is idle for nine days. Note that it is normal for the battery to emit heat during the
discharging process.
3. Overcharge Protection: the battery stops charging automatically once fully charged.
4. Temperature Detection: to prevent damage, the battery only charges when the temperature
is between 5° and 40° C (41° and 104° F). Charging stops automatically if the temperature of
the battery cells exceed 55° C (131° F) during charging.
5. Overcurrent Protection: the battery stops charging if an excess current is detected.
6. Over-Discharge Protection: discharging stops automatically to prevent excess discharge
when the battery is not in use. Over-discharge protection is not enabled when the battery is
in use.
7. Short Circuit Protection: the power supply is automatically cut if a short circuit is detected.
8. Battery Cell Damage Protection: the app will display a warning prompt when a damaged
battery cell is detected.
9. Hibernation Mode: if the battery is less than 10% when the aircraft is idle, the battery
enters Hibernation mode to prevent over-discharge. Charge the battery to wake it from
hibernation.
10. Communication: information about the voltage, capacity, and current of the battery is
transmitted to the aircraft.
11. Maintenance Instructions: the battery automatically checks the voltage dierences between
battery cells and decides whether maintenance is required. If maintenance is required,
insert the battery into the aircraft and power it on, the aircraft will not be able to take o,
and a prompt for maintenance will appear in DJI Fly. If the maintenance prompt appears
in DJI Fly, follow the prompt to fully charge the battery and allow the battery to rest for 48
hours. If the battery still does not work after two times of maintenance, contact DJI Support.
• Refer to the Safety Guidelines and the stickers on the battery before use. Users shall
take full responsibility for all operations and usage.
Using the Battery
Checking the Battery Level
Press the power button once to check the current battery level.
LED1
LED2
LED3
LED4
Battery Level LEDs
Power Button
The battery level LEDs display the power level of the battery during charging and
discharging. The statuses of the LEDs are dened below:
LED is on LED is ashing LED is o
LED1LED2LED3LED4
Battery Level
88%-100%
76%-87%
63%-75%
51%-62%
38%-50%
26%-37%
13%-25%
0%-12%
Powering On/O
Press the power button once and then press and hold for two seconds to power the aircraft
on or o. The battery level LEDs display the battery level when the aircraft is powered on. The
battery level LEDs turn o when the aircraft is powered o.
If LEDs 3 and 4 blink simultaneously, this indicates the battery is malfunctioning. Remove the
battery from the aircraft, insert the battery again and make sure that it is securely mounted.
1. Battery capacity is signicantly reduced when ying at low temperatures from -10° to 5° C (14°
to 41° F). Make sure to fully charge the battery before takeo. It is recommended to power
on the aircraft for a while to warm up the battery. Take o after DJI Fly prompts that the
battery is fully warmed up.
2. Batteries cannot be used in extremely low-temperature environments of lower than -10° C
(14° F).
3. To ensure optimal performance, keep the battery temperature above 20° C (68° F).
4. The reduced battery capacity in low-temperature environments reduces the wind speed
resistance performance of the aircraft. Fly with caution.
5. Take extra caution when ying at a high elevation with a low temperature.
Charging the Battery
Fully charge the battery before each use. It is recommended to use the charging devices
provided by DJI, such as the DJI Mini 3 Pro Two-Way Charging Hub, DJI 30W USB-C Charger,
or other USB Power Delivery chargers. The DJI Mini 3 Pro Two-Way Charging Hub and the DJI
30W USB-C Charger are both optional accessories. Visit the official DJI online store for more
information.
• When you charge the battery mounted to the aircraft or inserted into the DJI Mini 3 Pro TwoWay Charging Hub, the maximum charging power supported is 30 W.
Using a Charger
1. Ensure the battery has been correctly installed in the aircraft.
2. Connect a charger to an AC power supply (100-240 V, 50/60 Hz; use a power adapter if
necessary).
3. Connect the charger to the charging port on the aircraft using a USB-C cable.
4. The battery level LEDs display the current battery level during charging.
5. The Intelligent Flight Battery is fully charged when all the battery level LEDs emit a solid
light. Detach the charger when the battery is fully charged.
PD 30 W
• The battery cannot be charged if the aircraft is powered on.
• The maximum charge voltage for the aircraft charging port is 12 V.
• DO NOT charge an Intelligent Flight Battery immediately after ight as it may be too hot.
Wait for the battery to cool down to the operating temperature before charging again.
• The charger stops charging the battery if the battery cell temperature is not within the
operating range of 5° to 40° C (41° to 104° F). The ideal charging temperature is from
22° to 28° C (71.6° to 82.4° F).
• Fully charge the battery at least once every three months to maintain battery health.
• When using the DJI 30W USB-C Charger, the charging time for Mini 4 Pro Intelligent
Flight Battery is approximately 1 hour and 10 minutes, while for Mini 3 Pro Intelligent
Flight Battery Plus it is approximately 1 hour and 41 minutes.
• For safety purposes, keep the batteries at a low power level in transit. Before
transportation, it is recommended to discharge the batteries to 30% or lower.
The table below shows the battery level during charging.
LED1LED2LED3LED4
Battery Level
0%-50%
51%-75%
76%-99%
100%
• The blinking frequency of the battery level LEDs diers depending on the USB charger
used. If the charging speed is fast, the battery level LEDs will blink quickly.
• If the battery is not correctly inserted into the aircraft, LEDs 3 and 4 will blink
simultaneously. Insert the battery again and make sure it is securely mounted.
• Four LEDs blinking simultaneously indicates the battery is damaged.
User Manual
Using the Charging Hub
When used with a USB charger, the DJI Mini 3 Pro Two-Way Charging Hub can charge up to
three Intelligent Flight Batteries or Intelligent Flight Batteries Plus in sequence from high to low
power level. When used with the DJI 30W USB-C Charger, the charging hub can fully charge one
Intelligent Flight Battery in approximately 58 minutes, and one Intelligent Flight Battery Plus in
approximately 1 hour and 18 minutes.
When the charging hub is connected to an AC power outlet using a USB charger, users can
connect both the Intelligent Flight Batteries and an external device (such as a remote controller
or smartphone) to the hub to be charged. The batteries will be charged before the external
device by default. When the charging hub is not connected to an AC power outlet, insert the
Intelligent Flight Batteries into the hub and connect an external device to the USB port to
charge the device, using the charging hub as a power bank. Refer to the DJI Mini 3 Pro Two-Way
Charging Hub User Guide for more details.
1. Insert the batteries into the charging hub until there is a click.
2. Connect the charging hub to a power outlet (100-240 V, 50/60 Hz) using a USB-C cable and a
DJI 30W USB-C charger or other USB Power Delivery chargers.
3. The battery with the highest power level will be charged rst. The rest will be charged in
sequence according to their power levels. The corresponding status LEDs will display the
charging status (see table below). After the battery is fully charged, the corresponding LEDs
will change to solid green.
Status LED Indicator Descriptions
Charging Status
Blinking PatternDescriptions
Status LEDs in an array blink
quickly successively
Status LEDs in an array blink
slowly successively
The battery in the corresponding battery port is being
charged using a USB PD charger.
The battery in the corresponding battery port is being
charged using a normal charger.
Status LEDs in an array are solid The battery in the corresponding battery port is fully
charged.
All status LEDs blink in sequence No battery is inserted.
Battery Level
Each battery port of the charging hub has its corresponding status LED array, from LED1 to
LED4 (left to right). Check battery levels by pressing the function button once. The battery level
LED statuses are the same as those on the aircraft. For details, refer to aircraft battery level
LEDs statuses and descriptions.
Abnormal Status
The LED status for battery abnormality is the same as that on the aircraft. Refer to the Battery
Protection Mechanisms section for details.
• It is recommended to use a DJI 30W USB-C Charger or other USB Power Delivery
chargers to power the charging hub.
• The environmental temperature aects the charging speed. Charging is faster in a wellventilated environment at 25° C (77° F).
• The charging hub is only compatible with BWX140-2590-7.32, BWX162-2453-7.38
Intelligent Flight Battery and BWX162-3850-7.38 Intelligent Flight Battery Plus. DO NOT
use the charging hub with other battery models.
• Place the charging hub on a at and stable surface when in use. Make sure the device is
properly insulated to prevent re hazards.
• DO NOT touch the metal terminals on the battery ports.
• Clean the metal terminals with a clean, dry cloth if there is any noticeable build
Battery Protection Mechanisms
The battery level LEDs can display battery protection notifications triggered by abnormal
charging conditions.
Battery Protection Mechanisms
LED1 LED2 LED3 LED4 Blinking PatternStatus
LED2 blinks twice per second Overcurrent detected
LED2 blinks three times per
second
LED3 blinks twice per second Overcharge detected
LED3 blinks three times per
second
LED4 blinks twice per second Charging temperature is too low
LED4 blinks three times per
second
If any of the battery protection mechanisms are activated, unplug the charger, and plug it in
again to resume charging. If the charging temperature is abnormal, wait for it to return to
normal. The battery will automatically resume charging without the need to unplug and plug
the charger again.
Insert the Intelligent Flight Battery into the battery compartment of the aircraft. Make sure the
battery is fully inserted with a clicking sound, which indicates the battery buckles are securely
fastened.
Press the textured part of the battery buckles on the sides of the battery to remove it from the
compartment.
• DO NOT insert or remove the battery while the aircraft is powered on.
• Ensure the battery is inserted with a clicking sound. DO NOT launch the aircraft
when the battery is not securely mounted, as this may cause poor contact between
the battery and the aircraft and present hazards. Make sure the battery is mounted
securely.
Gimbal and Camera
Gimbal Prole
The 3-axis gimbal stabilizes the camera, allowing you to capture clear and steady images and
video at a high ight speed. The gimbal has a control tilt range of -90˚ to +60˚, and two control
roll angles of -90˚ (portrait) and 0˚ (landscape).
Use the gimbal dial on the remote controller to control the tilt of the gimbal. Alternatively, do so
through the camera view in DJI Fly. Press and hold the screen until the gimbal adjustment bar
appears. Drag the bar up and down to control the gimbal’s tilt.
Tap the Landscape/Portrait Mode Switch in DJI Fly to switch between the two gimbal roll angles.
The roll axis will rotate to -90° when Portrait Mode is enabled, and back to 0° in Landscape
Mode.
Gimbal Operation Modes
Two gimbal operation modes are available. Switch between the dierent operation modes in
Settings > Control in DJI Fly.
Follow Mode:
adjust the gimbal tilt. This mode is suitable for shooting stills.
FPV Mode:
the aircraft to provide a rst-person ying experience.
the angle of the gimbal remains stable relative to the horizontal plane. Users can
when the aircraft is ying forward, the gimbal synchronizes with the movement of
• Make sure there are no stickers or objects on the gimbal before taking o. DO NOT tap
or knock the gimbal after the aircraft is powered on. Launch the aircraft from open and
at ground to protect the gimbal.
• After installing the wide-angle lens, unfold the arms before powering on the aircraft.
Make sure the gimbal is level and pointing forward before takeo, so that the aircraft
can correctly detect the installation status of the wide-angle lens. The gimbal will be
level when the aircraft is powered on, if the gimbal rotates, recenter the gimbal using
the remote controller or DJI Fly as follows:
a. Tap Recenter Gimbal on the Settings > Control page of DJI Fly.
b. Press the Fn button on DJI RC-N2 remote controller or the Customizable C1 Button
on DJI RC 2 remote controller. The default function is recentering the gimbal or
pointing the gimbal downward, which can be customized.
• Pano and Asteroid functions will not be available after the wide-angle lens is installed.
• Precision elements in the gimbal may be damaged by a collision or impact, which may
cause the gimbal to function abnormally.
• Avoid getting dust or sand on the gimbal, especially in the gimbal motors.
• A gimbal motor may enter protection mode if the gimbal is obstructed by other objects
• DO NOT apply external force to the gimbal after the aircraft is powered on.
• DO NOT add any extra payload other than an official accessory to the gimbal, as
• Remove the gimbal protector before powering on the aircraft. Attach the gimbal
• Flying in heavy fog or clouds may make the gimbal wet, leading to temporary failure.
User Manual
when the aircraft is put on uneven ground or on grass, or if the gimbal experiences an
excessive external force, such as during a collision.
this may cause the gimbal to function abnormally or even lead to permanent motor
damage.
protector when the aircraft is not in use.
The gimbal will recover full functionality once it is dry.
Camera Prole
DJI Mini 4 Pro uses a 1/1.3-in CMOS sensor with 48MP eective pixels. The equivalent focal length is
approximately 24 mm. The aperture of the camera is F1.7 and shoots from 1 m to innity.
The DJI Mini 4 Pro camera can take 48MP stills and supports shooting modes such as Single, Burst,
AEB, Timed Shot, and Panorama. It also supports H.264/H.265 video recording, digital zoom, and
slow motion recording. 4K 60fps HDR and 4K 100fps videos are also supported.
• DO NOT expose the camera lens in an environment with laser beams, such as a laser
show, or point the camera at intense light sources for an extended period, such as the
sun on a clear day, in order to avoid damaging the sensor.
• Make sure the temperature and humidity are suitable for the camera during use and
storage.
• Use a lens cleanser to clean the lens to avoid damage or poor image quality.
• DO NOT block any ventilation holes on the camera as the heat generated may damage
the device and injure the user.
• The cameras may not focus correctly in the following situations:
a. Shooting dark objects far away.
b. Shooting objects with repeating identical patterns and textures or objects without
clear patterns or textures.
c. Shooting shiny or reective objects (such as street lighting and glass).
d. Shooting ashing objects.
e. Shooting fast-moving objects.
f. When the aircraft/gimbal is moving fast.
g. Shooting objects with varying distances in the focus range.
• DJI Mini 4 Pro uses SmartPhoto mode by default in Single Shot, which integrates
features such as scene recognition or HDR for optimal results. SmartPhoto needs to
take multiple shots continuously for image synthesis. When the aircraft is moving or
using the 48MP resolution, SmartPhoto will not be supported, and the image quality will
dier.
DJI Mini 4 Pro supports the use of a microSD card to store your photos and videos. A UHS-I
Speed Grade 3 rating or above microSD card is required due to the fast read and write speeds
necessary for high-resolution video data. Refer to the Specications for more information about
recommended microSD cards.
Photos and videos can also be saved in the internal storage of the aircraft when no microSD
card is available. Use of a microSD card is recommended for large data storage.
Exporting Photos and Videos
• Use QuickTransfer to export the footage to a mobile device.
• Connect the aircraft to a computer using a data cable, export the footage in the internal
storage of the aircraft or in the microSD card mounted on the aircraft. The aircraft does not
need to be powered on during the exporting process.
• Remove the microSD card from the aircraft and insert it into a card reader, and export the
footage in the microSD card through the card reader.
• DO NOT remove the microSD card from the aircraft when taking photos or videos.
Otherwise, the microSD card may be damaged.
• Check camera settings before use to ensure they are congured correctly.
• Before shooting important photos or videos, shoot a few images to test whether the
camera is operating correctly.
• Make sure to power o the aircraft correctly. Otherwise, the camera parameters will
not be saved, and any recorded videos may be aected. DJI is not responsible for any
loss caused by an image or video recorded in a way that is not machine-readable.
QuickTransfer
The aircraft can connect directly to mobile devices via Wi-Fi, enabling users to download photos and
videos from the aircraft to the mobile device through DJI Fly without using the remote controller. Users
can enjoy faster and more convenient downloads with a transmission rate of up to 30 MB/s.
Usage
Method 1: mobile device is not connected to the remote controller
1. Power on the aircraft and wait until the self-diagnostic tests of the aircraft are complete.
2. Make sure Bluetooth and Wi-Fi are enabled on the mobile device. Launch DJI Fly and a
prompt will appear to connect to the aircraft.
3. Tap Connect. Once successfully connected, the files on the aircraft can be accessed and
downloaded at high speed. When connecting the mobile device to the aircraft for the rst
time, press and hold the power button of the aircraft for two seconds to conrm.
Method 2: mobile device is connected to the remote controller
1. Make sure that the aircraft is connected to the mobile device via the remote controller and
the motors are o.
2. Enable Bluetooth and Wi-Fi on the mobile device.
3. Launch DJI Fly, enter playback, and tap
aircraft to download at high speed.
• DJI RC 2 does not support QuickTransfer.
• The maximum download rate can only be achieved in countries and regions where the 5.8
GHz frequency is permitted by laws and regulations, when using devices that support 5.8
GHz frequency band and Wi-Fi connection, and in an environment without interference or
obstruction. If 5.8 GHz is not allowed by local regulations (such as in Japan), or the mobile
device of the user does not support the 5.8 GHz frequency band, or the environment
has severe interference, then QuickTransfer will use the 2.4 GHz frequency band and its
maximum download rate will reduce to 6 MB/s.
• Make sure that Bluetooth, Wi-Fi, and location services are enabled on the mobile device
before using QuickTransfer.
• When using QuickTransfer, it is not necessary to enter the Wi-Fi password on the
settings page of the mobile device in order to connect. Launch DJI Fly and a prompt will
appear to connect the aircraft.
• Use QuickTransfer in an unobstructed environment with no interference and stay
away from sources of interference such as wireless routers, Bluetooth speakers, or
headphones.
in the upper right corner to access the les on the
This chapter describes the features
of the remote controller and includes
instructions for controlling the aircraft
and the camera.
DJI Mini 4 Pro
User Manual
Remote Controller
DJI RC 2
The DJI RC 2 remote controller features O4 video transmission when used with DJI Mini 4 Pro,
and works at 2.4 GHz, 5.8 GHz and 5.1 GHz frequency bands. It is capable of selecting the best
transmission channel automatically and can transmit 1080p 60fps HD live view from the aircraft
to the remote controller at a distance of up to 20 km (12.4 mi) (compliant with FCC standards,
and measured in a wide open area without interference). Equipped with a 5.5-in touchscreen
(1920×1080 pixel resolution) and a wide range of controls and customizable buttons, DJI RC 2
enables users to easily control the aircraft and remotely change the aircraft settings. DJI RC 2
comes with many other functions such as built-in GNSS (GPS+Galileo+BeiDou), Bluetooth, and
Wi-Fi connection.
The remote controller has detachable control sticks, built-in speakers, a 32GB internal storage,
and supports the use of a microSD card for additional storage needs.
The 6200mAh 22.32Wh battery provides the remote controller with a maximum operating time
of three hours.
• The 5.1 GHz band can be used only in countries and regions where it is permitted by
local laws and regulations.
Operation
Powering On/O
Press the power button once to check the current battery level.
Press once, then press and hold for two seconds to power the remote controller on or o.
Connect the charger to the USB-C port on the remote controller. It takes approximately 1 hour
and 30 minutes to fully charge the remote controller (with a 9V/3A USB charger).
Controlling the Gimbal and Camera
1. Focus/Shutter Button: press halfway down to auto-focus and press all the way down to take
a photo.
2. Record Button: press once to start or stop recording.
3. Camera Control Dial: use to adjust the zoom by default. The dial function can be set to
adjust the focal length, EV, shutter speed, and ISO.
Use the left stick to take o when the motors
are spinning at an idle speed. Push the stick
gently to prevent sudden and unexpected
changes in altitude.
Yaw Stick:
controls the orientation of the aircraft.
• Push the stick left to rotate the aircraft
counterclockwise and right to rotate the
aircraft clockwise.
• The aircraft hovers in place if the stick is in
the center.
• The more the stick is pushed away from the
center, the faster the aircraft rotates.
Pitch Stick:
down to change the pitch of the aircraft.
• Push the stick up to y forward and down to
y backward.
• The aircraft hovers in place if the stick is in
the center.
• The more the stick is pushed away from the
center, the faster the aircraft moves.
Roll Stick:
right changes the roll of the aircraft.
• Push the stick left to y left and right to y
right.
• The aircraft hovers in place if the stick is in
the center.
Toggle the switch to select the desired ight mode.
CNS
PositionFlight Mode
SSport Mode
NNormal Mode
CCine Mode
Flight Pause/RTH Button
Press once to make the aircraft brake and hover in place.
Press and hold the button until the remote controller beeps and starts RTH. The aircraft will
return to the last recorded Home Point. Press the button again to cancel RTH and regain control
of the aircraft.
Customizable Button
Go to Settings > Control in DJI Fly to set the functions of the customizable C1 and C2 buttons.
Blinking redThe battery level of the aircraft is low.
—
Solid greenConnected with the aircraft.
Blinking blueThe remote controller is linking to an aircraft.
—
Solid yellowFirmware update failed.
—
Solid blueFirmware update successful.
Blinking yellowThe battery level of the remote controller is low.
Blinking cyanControl sticks not centered.
Battery Level LEDs
Blinking PatternBattery Level
76%-100%
51%-75%
26%-50%
0%-25%
Remote Controller Alert
The remote controller beeps to indicate an error or warning. Pay attention when prompts
appear on the touchscreen or in DJI Fly. Slide down from the top of the screen and select Mute
to disable all alerts, or slide the volume bar to 0 to disable some alerts.
The remote controller sounds an alert during RTH. The alert cannot be canceled. The remote
controller sounds an alert when the battery level of the remote controller is low (6% to 10%
battery level). A low battery level alert can be canceled by pressing the power button. The critical
low battery level alert, which is triggered when the battery level is less than 5% and cannot be
The signal between the aircraft and the remote controller is most reliable when the antennas
are positioned in relation to the aircraft as illustrated below.
The optimal transmission range is where the antennas face toward the aircraft and the angle
between the antennas and the back of the remote controller is 180° or 270°.
• DO NOT use other wireless devices operating at the same frequency as the remote
controller. Otherwise, the remote controller will experience interference.
• A prompt will be displayed in DJI Fly if the transmission signal is weak during flight.
Adjust the antennas to make sure that the aircraft is in the optimal transmission range.
Linking the Remote Controller
The remote controller is already linked to the aircraft when purchased together as a combo.
Otherwise, follow the steps below to link the remote controller and the aircraft after activation.
1. Power on the aircraft and the remote controller.
2. Launch DJI Fly.
3. In camera view, tap
status LED of the remote controller blinks blue and the remote controller beeps.
4. Press and hold the power button of the aircraft for more than four seconds. The aircraft
beeps once, and its battery level LEDs blink in sequence to indicate it is ready to link. The
remote controller will beep twice, and its status LED will turn solid green to indicate linking is
successful.
and select Control and then Re-pair to Aircraft. During linking, the
• Make sure the remote controller is within 0.5 m of the aircraft during linking.
• The remote controller will automatically unlink from an aircraft if a new remote
controller is linked to the same aircraft.
• Turn o Bluetooth and Wi-Fi for optimal video transmission.
• Fully charge the remote controller before each ight. The remote controller sounds an
• If the remote controller is powered on and not in use for five minutes, an alert will
sound. After six minutes, the remote controller automatically powers off. Move the
control sticks or press any button to cancel the alert.
• Fully charge the battery at least once every three months to maintain the battery’s
health.
• DO NOT operate the aircraft when the light condition is too bright or too dark using the
remote controller to monitor ight. User is responsible for the correct adjustment of
display brightness and shall take care of direct sunshine onto the screen during ight
operation.
Operating the Touchscreen
Home
User Manual
Screen Gestures
Slide from the left or right to
the center of the screen to
return to the previous screen.
Slide up from the bottom of
the screen to return to DJI Fly.
Slide down from the top of the
screen to open the status bar
when in DJI Fly.
The status bar displays the
time, Wi-Fi signal, battery level
of the remote controller, etc.
Slide down twice from the top
of the screen to open Quick
Settings when in DJI Fly.
Quick Settings
1
1. Notications
Tap to check system notications.
2. System Settings
Tap to access system settings and configure settings such as Bluetooth, volume, and
network. Users can also view the Guide to learn more about the controls and status LEDs.
3. Shortcuts
: tap to enable or disable Wi-Fi. Hold to enter settings and then connect to or add a Wi-Fi
network.
: tap to enable or disable Bluetooth. Hold to enter settings and connect with nearby
Bluetooth devices.
: tap to enable Airplane mode. Wi-Fi and Bluetooth will be disabled.
: tap to turn o system notications and disable all alerts.
The compass may need to be calibrated after the remote controller is used in areas with
electromagnetic interference. A warning prompt will appear if the compass of the remote
controller requires calibration. Tap the warning prompt to start calibrating. In other cases,
follow the steps below to calibrate the remote controller.
1. Power on the remote controller, and enter Quick Settings.
2. Select System Settings
3. Follow the on-screen instructions to calibrate the compass.
4. A prompt will be displayed when the calibration is successful.
The DJI RC-N2 remote controller features O4 video transmission when used with DJI Mini 4 Pro,
the remote controller works at 2.4 GHz, 5.8 GHz and 5.1 GHz frequency bands. The remote
controller is also capable of selecting the best transmission channel automatically and can
transmit 1080p 60fps HD live view from the aircraft to DJI Fly on a mobile device (depending on
mobile device performance) at a maximum transmission range of 20 km (12.4 mi) (compliant
with FCC standards, and measured in a wide open area without interference). Users can control
the aircraft and change the settings easily within this range. The retractable mobile device
holder can be used to place mobile devices stably, and the control sticks are removable and
easy to store.
The built-in battery has a capacity of 5200 mAh and power of 18.72 Wh that supports a
maximum run time of six hours (when not charging the mobile device).
• The 5.1 GHz band can be used only in countries and regions where it is permitted by
local laws and regulations.
Operation
Powering On/O
Press the power button once to check the current battery level.
Press once, then press and hold for two seconds to power the remote controller on or o.
Charging the Battery
Connect the charger to the USB-C port on the remote controller.
Controlling the Gimbal and Camera
1. Shutter/Record Button: Press once to take a photo or to start or stop recording.
2. Photo/Video Toggle: Press once to switch between photo and video mode.
The default control mode of the remote controller is Mode 2. In this manual, Mode 2 is used as
an example to illustrate how to use the control sticks.
User Manual
• Stick Neutral/Center Point: control sticks are in the center.
• Moving the control stick: the control stick is pushed away from the center position.
Remote Controller
(Mode 2)
AircraftRemarks
Throttle Stick:
changes the altitude of the aircraft.
• Push the stick up to ascend and push down to
descend.
• The aircraft hovers in place if the stick is in the
center.
• The more the stick is pushed away from the
center, the faster the aircraft changes elevation.
Use the left stick to take o when the motors are
spinning at an idle speed. Push the stick gently to
prevent sudden and unexpected changes in altitude.
Yaw Stick:
controls the orientation of the aircraft.
• Push the stick left to rotate the aircraft
counterclockwise and right to rotate the aircraft
clockwise.
• The aircraft hovers in place if the stick is in the
center.
• The more the stick is pushed away from the
center, the faster the aircraft rotates.
Pitch Stick:
change the pitch of the aircraft.
• Push the stick up to y forward and down to y
backward.
• The aircraft hovers in place if the stick is in the
center.
• The more the stick is pushed away from the
center, the faster the aircraft moves
Roll Stick:
changes the roll of the aircraft.
• Push the stick left to y left and right to y right.
• The aircraft hovers in place if the stick is in the
Toggle the switch to select the desired ight mode.
PositionFlight Mode
SSport Mode
NNormal Mode
CCine Mode
CNS
Flight Pause/RTH Button
Press once to make the aircraft brake and hover in place.
Press and hold the button until the remote controller beeps and starts RTH. The aircraft will
return to the last recorded Home Point. Press this button again to cancel RTH and regain control
of the aircraft.
Customizable Button
Go to Settings in DJI Fly and select Control to set the functions of the customizable button.
The remote controller sounds an alert during RTH. The alert cannot be canceled. The remote
controller sounds an alert when the battery level of the remote controller is low (6% to 10%). A
low battery level alert can be cancelled by pressing the power button. The critical low battery
level alert, which is triggered when the battery level is less than 5%, cannot be canceled.
Optimal Transmission Zone
The signal between the aircraft and the remote controller is most reliable when the antennas
are positioned in relation to the aircraft as illustrated below.
Optimal Transmission Zone
Weak Signal
• DO NOT use other wireless devices operating at the same frequency as the remote
controller. Otherwise, the remote controller will experience interference.
• A prompt will be displayed in DJI Fly if the transmission signal is weak during ight.
Adjust the remote controller orientation to make sure that the aircraft is in the
optimal transmission range.
The remote controller is already linked to the aircraft when purchased together as a combo.
Otherwise, follow the steps below to link the remote controller and the aircraft after activation.
1. Power on the aircraft and the remote controller.
2. Connect a mobile device to the remote controller, and Launch DJI Fly.
3. In camera view, tap
beeps during linking.
4. Press and hold the power button of the aircraft for more than four seconds. The aircraft
beeps once, and its battery level LEDs blink in sequence to indicate it is ready to link. After
the linking is successful, the battery level LEDs of the remote controller will appear on and
solid.
• Make sure the remote controller is within 0.5 m of the aircraft during linking.
• The remote controller will automatically unlink from an aircraft if a new remote
controller is linked to the same aircraft.
• Turn o Bluetooth and Wi-Fi of the remote controller for optimal video transmission.
• Fully charge the remote controller before each ight. The remote controller sounds
an alert when the battery level is low.
• If the remote controller is powered on and not in use for ve minutes, an alert will
sound. After six minutes, the remote controller automatically powers o. Move the
control sticks or press any button to cancel the alert.
• Adjust the mobile device holder to make sure your mobile device is secure.
• Fully charge the battery at least once every three months to maintain the battery’s
health.
• DO NOT operate the aircraft when the light condition is too bright or too dark using
mobile phone to monitor flight. User is responsible for the correct adjustment of
display brightness and shall take care of direct sunshine onto the screen during
ight operation.
• Make sure to use a mobile device together with the DJI RC-N2 remote controller to
control the aircraft. If the mobile device turns o for any reason, land the aircraft as
soon as possible for safety.
and select Control and then Re-pair to Aircraft. The remote controller
displays aircraft ight status and various warning messages. Tap to view more
information when a warning prompt appears.
3. Battery Information
80
24'17"
: displays the current battery level and remaining ight time. Tap to view more
information about the battery.
4. Video Downlink Signal Strength
: displays the video downlink signal strength between the aircraft and the remote
controller.
5. Vision System Status
: the left side of the icon indicates the status of the horizontal vision system and the
right side of the icon indicates the status of the upward and downward vision systems. The
icon is white when the vision system is working normally and turns red when the vision
system is unavailable.
6. GNSS Status
: displays the current GNSS signal strength. Tap to check the GNSS signal status. The
Home Point can be updated when the icon is white, which indicates the GNSS signal is
strong.
7. Settings
: tap to view or set parameters for safety, control, camera, and transmission. Refer to
the Settings section for more information.
8. Shooting Modes
Photo: Single, AEB, Burst Shooting, and Timed Shot.
Video: Normal, Night, and Slow Motion.
MasterShots: drag-select a subject. The aircraft will record while executing
dierent maneuvers in sequence and keep the subject in the center of the frame.
A short cinematic video will be generated afterward.
QuickShots: Dronie, Rocket, Circle, Helix, Boomerang, and Asteroid.
Hyperlapse: Free, Circle, Course Lock, and Waypoints.
Pano: Sphere, 180°, Wide Angle, and Vertical. The aircraft will automatically
take several photos and synthesize a panoramic photo based on the selected
panoramic photo type.
• The Night video mode provides better noise reduction and cleaner footage,
supports up to 12800 ISO.
• The Night video mode currently supports 4K 24/25/30fps and 1080p 24/25/30fps.
• FocusTrack is not supported in Night video mode.
: tap to switch between Landscape and Portrait modes. The camera will rotate 90
degrees when switching to Portrait mode, for shooting portrait videos and photos. Portrait
mode is not supported when using Pano or the Asteroid shooting mode in QuickShots.
10. Zoom
1x
: displays the zoom ratio. Tap to adjust the zoom ratio. Tap and hold the icon to expand
the zoom bar and slide on the bar to adjust the zoom ratio. Use two fingers on the screen
to zoom in or out.
• Digital zoom is only supported when taking 12MP photo, or recording in Normal or
Night video mode.
• When zooming in or out, the larger the zoom ratio, the slower the aircraft will rotate
to achieve a smooth view.
11. Shutter/Record Button
: tap to take a photo or to start or stop recording a video.
12. Focus Button
AF/ MF
: tap to switch between AF and MF. Press and hold the icon to bring up the focus bar
to adjust the focus.
13. Playback
: tap to enter playback and preview photos and videos as soon as they are captured.
14. Camera Mode Switch
: tap to switch between Auto and Pro mode. Dierent parameters can be set in dierent
modes.
15. Shooting Parameters
RES&FP
: displays the current shooting parameters. Tap to access parameter settings.
4K 60
16. Storage Information
torag
: displays the remaining number of photos or video recording time of the current
storage. Tap to view the available capacity of the aircraft internal storage or the microSD
card. Tap to view more information about the storage.
17. Flight Telemetry
Displays the horizontal distance (D) between the aircraft and the Home Point, height (H)
from the Home Point, aircraft horizontal speed, and aircraft vertical speed.
18. Map/Altitude Indicator/Vision Assist
: tap to expand to the mini map, and tap the center of the mini map to switch from the
camera view to the map view. The mini map can be switched to the attitude indicator.
• Mini Map: displays the map in the bottom left corner of the screen so that the user can
simultaneously check the camera view, the real-time position and orientation of the
aircraft and the remote controller, the Home Point location, and ight paths, etc.
Locked to NorthNorth is locked on the map with North pointing upward in
the map view. Tap to switch from Lock to North to the remote
controller orientation where the map rotates when the remote
controller changes the orientation.
Smart Scaletap the +/- icon to slightly zoom in or out.
Switch to Attitude
Indicator
tap to switch from the mini map to the attitude indicator.
Collapsetap to minimize the map.
• Attitude Indicator: displays the attitude indicator in the bottom left corner of the screen
so that the user can simultaneously check the camera view, the relative location and
orientation of the aircraft and the remote controller, the Home Point location, and the
aircraft horizontal attitude information, etc. The attitude indicator supports displaying the
aircraft or the remote controller as the center.
switch to the remote
controller as the center
Remote controller
Switch to the aircraft/
remote controller as
Aircraft Orientation
Home Point
Aircraft Horizontal
Attitude
switch to mini map
Collapse
Aircraft as the CenterRemote Controller as the Center
switch to the aircraft as
the center
Tap to switch to aircraft/remote controller as the center of the
attitude indicator.
the center
Aircraft OrientationIndicates the aircraft orientation. When the aircraft is
displayed as the center of the attitude indicator and the user
is changing the aircraft orientation, all the other elements on
the attitude indicator will rotate around the aircraft icon. The
arrow direction of the aircraft icon stays unchanged.
Aircraft Horizontal
Attitude
Indicates the aircraft horizontal attitude information (including
pitch and roll). The deep cyan area is horizontal and in the
center of the attitude indicator when the aircraft hovers in
place. If not, it indicates that the wind is changing the aircraft
attitude. Fly with caution. The deep cyan area changes in real
time based on the aircraft horizontal attitude.
Tap to switch from the altitude indicator to the vision assist
view.
CollapseTap to minimize the attitude indicator.
Home PointThe location of the Home Point. To manually control the
aircraft to return home, adjust the aircraft orientation to point
towards the Home Point rst.
Remote ControllerThe dot indicates the remote controller location, while the
arrow on the dot indicates the remote controller orientation.
Adjust the remote controller orientation during the flight
to make sure the arrow points towards the aircraft icon for
optimal signal transmission.
• Vision Assist: the vision assist view, powered by the horizontal vision system, changes
the horizontal speed direction (forward, backward, left, and right) to help users navigate
and observe obstacles during ight.
Vision Assist View
Direction
Horizontal Speed of
the Aircraft
Collapse
Horizontal Speed of the
Aircraft
The direction of the line indicates the current horizontal
direction of the aircraft, and the length of the line indicates
Max
Locked
Switch to the Mini
Map
the horizontal speed of the aircraft.
Vision Assist View
Direction
Switch to the Mini Map
Collapse
Max
Locked
Indicates the direction of the vision assist view. Tap and hold
to lock the direction.
Tap to switch from the vision assist view to the mini map.
Tap to minimize the vision assist view.
Tap to maximize the vision assist view.
Indicates that the direction of the vision assist view is locked.
Tap to cancel the lock.
19. Auto Takeo/Landing/RTH
/ : tap the icon. When the prompt appears, press and hold the button to initiate auto
takeo or landing.
: tap to initiate RTH and have the aircraft return to the last recorded Home Point.
Press and hold on the screen to bring up the gimbal adjustment bar and adjust the gimbal
angle.
Focus/Spot Metering
Tap on the screen to enable focus or spot metering. Focus or spot metering will display
dierently depending on the shooting mode, focus mode, exposure mode, and spot metering
mode.
After using spot metering:
• Drag
• Press and hold the box on the screen to lock the exposure. To unlock the exposure, tap and
next to the box up and down to adjust the EV (exposure value).
hold on the screen again or tap on another area of the screen.
Bypassing Options Select Normal or Nifty mode when using Bypass.
Display Radar Map When enabled, the real-time obstacle detection radar map will be displayed.
• Return to Home (RTH): set Advanced RTH, Auto RTH Altitude, and to update the Home Point.
• AR Settings: enable display of AR Home Point, AR RTH Route, and AR Aircraft Shadow.
• Flight Protection: set the max altitude and the max distance for ights.
• Sensors: tap to view the IMU and compass statuses and start calibration if necessary.
• Battery: tap to view battery information such as battery cell status, serial number, and
number of times charged.
• Auxiliary LED: tap to set the auxiliary LED to auto, on, or o. DO NOT turn on the Auxiliary
LED before takeo.
• Unlock GEO Zone: tap to view information about unlocking GEO Zones.
• Find My Drone: this feature helps to nd the location of the aircraft, either by enabling the
aircraft to ash or beep or by using the map.
• Advanced Safety Settings
Signal LostThe behavior of the aircraft when the remote controller signal is lost can
Emergency
Propeller Stop
Vision
Positioning and
Obstacle Sensing
Omnidirectional vision system is enabled after setting Obstacle
Avoidance Action to Bypass or Brake. The aircraft cannot sense
obstacles if Obstacle Avoidance is disabled.
be set to RTH, Descend, or Hover.
Emergency Only indicates that the motors can only be stopped by
performing a combination stick command (CSC) for at least 2 seconds midight in an emergency situation, such as if there is a collision, a motor has
stalled, the aircraft is rolling in the air, or the aircraft is out of control and is
ascending or descending very quickly. Anytime indicates that the motors can
be stopped mid-ight anytime once user performs a CSC.
Stopping the motors mid-ight will cause the aircraft to crash.
When Vision Positioning and Obstacle Sensing are disabled, the aircraft
relies only on GNSS to hover, omnidirectional obstacle sensing is
unavailable, and the aircraft will not automatically decelerate during
descent close to the ground. Extra caution is required when Vision
Positioning and Obstacle Sensing are disabled. Vision Positioning and
Obstacle Sensing can be temporarily disabled in clouds and fog or
when an obstacle is detected when landing. Keep Vision Positioning and
Obstacle Sensing enabled in regular ight scenarios. Vision Positioning
and Obstacle Sensing are enabled by default after restarting the aircraft.
Vision Positioning and Obstacle Sensing are only available when
ying manually and are unavailable in modes such as RTH, auto landing,
and Intelligent Flight Mode.
Subject ScanningWhen enabled, the aircraft automatically scans and displays subjects
in the camera view (only available for single-shot and normal video
modes).
FocusTrack Settings set tracking distance and height of the Inner/Outer circle for dierent
kinds of tracking subject, select Camera Motion when the aircraft is
bypassing obstacles, enable or disable Near-Ground Flight, and reset
FocusTrack Settings.
Gain and Expo
Tuning
• When releasing the joystick, an increased brake sensitivity reduces the braking
distance of the aircraft, while a decreased brake sensitivity increases the braking
distance. Fly with caution.
• Gimbal Settings: tap to set the gimbal mode, perform gimbal calibration, and recenter the
gimbal or move it downward.
• Remote Controller Settings: tap to set the function of the customizable button, calibrate the
remote controller, switch control stick modes. Make sure to understand the operations of a
stick mode before changing the control stick mode.
• Flight Tutorial: view the ight tutorial.
• Re-pair to Aircraft (Link): tap to start linking when the aircraft is not linked to the remote
controller.
Supports the gain and expo settings to be ne-tuned for the aircraft
and the gimbal in dierent ight modes, including the max horizontal
speed, max ascent speed, max descent speed, max angular velocity,
yaw smoothness, brake sensitivity, expo, and the gimbal max tilt
control speed and tilt smoothness.
Camera
• Camera Parameter Settings: displays dierent settings according to the shooting mode.
Shooting ModesSettings
Photo ModeFormat, Aspect Ratio, Resolution
Record ModeColor, Coding Format, Video Subtitles
MasterShotsColor, Coding Format, Video Subtitles
QuickShotsColor, Coding Format, Video Subtitles
HyperlapsePhoto Type, Shot Frame
PanoPhoto Type
[1] Video subtitles are not supported in Asteroid.
