Consumer Drones And Goggles
Compatibility Information
(for DJI Goggles 3)
2024.04v1.0
Compatible Devices and Firmware Version Requirements 2
Firmware Update 2
Linking 3
Function Compatibility Information 4
• This Compatibility Information does not apply to DJI AvataTM 2. For information on the
use of DJI Avata 2 with the goggles, visit https://www.dji.com/avata-2/downloads and
read the documentation.
Compatible Devices and Firmware Version Requirements
The following consumer drones can be used with DJI goggles and remote control devices,
providing a first-person view and convenient flight control experience.
Aircraft Compatible Goggles Compatible Remote Control Devices
• DJI RC Motion 3
(v01.00.0100 and above)
• DJI Air 3
(v01.00.1200 and above)
• DJI Mini 4 Pro
(v01.00.0400 and above)
• When using the above aircrafts with the goggles, only one remote control device is
supported for flight control.
• DJI Goggles 3
(v01.00.0100 and above)
• DJI RC 2
(v02.02.0000 and above)
• DJI RC-N2
when used with DJI Air 3:
(v01.00.0700 and above)
when used with DJI Mini 4 Pro:
(v01.01.0300 and above)
Firmware Update
Update the firmware of the aircraft, goggles, and remote control device to the latest version
before using for the first time. Otherwise, the devices cannot be linked.
1. Updating the Aircraft and the Original Remote Controller
Link the aircraft with its original remote controller and run DJI Fly. Follow the on-screen
instructions to update the firmware. Note that you cannot update the firmware if the
remote controller is not linked to the aircraft. An internet connection is required.
2. Updating the Goggles and the Motion Controller (If Available)
• Make sure the aircraft is powered off while updating the goggles and motion
controller (if available) to avoid interference.
Power on the goggles and motion controller (if available), connect the USB-C port of the
goggles to a mobile device, run DJI Fly, and select
the corresponding goggles. Select
to update the firmware. Make sure the mobile device is connected to the internet during the
update.
• Alternatively, the DJI Assistant 2 (Consumer Drone Series) software can be used on a
computer to update the firmware of the devices separately.
• If using a non-touchscreen remote controller with the goggles and aircraft, make
sure to update the DJI Fly app on your mobile device to the latest version.
Firmware Update
>
Profile
Device Management
and follow the on-screen instructions
. Locate
2
Linking
Preparation before linking:
1. Power on the aircraft, goggles, and remote control device (motion controller or remote
controller). Power on the aircraft, the goggles, and the remote control device before
linking. Make sure the devices are within 0.5 m of each other during linking. Make sure the
devices are updated to the latest firmware version and have enough battery level.
• The aircraft can be controlled with only one remote control device during flight.
If the aircraft has been linked with multiple remote control devices, turn off other
remote control devices before linking.
2. Open the goggles menu. Select
at the top of the menu is correct. Otherwise, select
the menu and then select the correct aircraft.
and make sure that the aircraft model displayed
Status
from the upper right corner of
Switch
Linking via the DJI Fly App (recommended)
Keep the goggles connected to the mobile device after activation. Tap
DJI Fly from the mobile device and follow the on-screen instructions to connect the aircraft.
Connection Guide
Linking via Button
• If using the combination of aircraft, goggles, and motion controller, follow the
instructions below to link the aircraft with the goggles, and link the goggles with the
motion controller.
• If using the combination of aircraft, goggles, and remote controller, note that as the
aircraft has already been linked with the remote controller, you only need to link the
aircraft with the goggles.
on
3
Link the aircraft with the goggles Link the goggles with the motion controller
5s 5s
a) Press and hold the power button on the
aircraft until the battery level LEDs start to
blink in sequence.
b) Press and hold the power button on
the goggles until the goggles start to
beep continuously and the battery
level LEDs start to blink in sequence.
c) Once linking is completed, the battery
level LEDs of the aircraft display the
battery level, the goggles stop beeping,
and image transmission can be displayed
normally.
5s
a) Press and hold the power button on
the goggles until the goggles start to
beep continuously and the battery level
LEDs start to blink in sequence.
b) Press and hold the power button on
the motion controller until it starts to
beep continuously and the battery level
LEDs start to blink in sequence.
c) Once linking is completed, the goggles
and the motion controller stop beeping
and the battery level LEDs display the
battery level.
5s
Function Compatibility Information
When using the aircraft with goggles, refer to the following table for function compatibility
information.
• When using QuickTransfer, make sure that the goggles are not connected to the mobile
device.
• To ensure flight safety, use the following combinations correctly, and make sure that when
using one of the combinations, the devices of the other combination are powered off.
Combination 1: Aircraft + goggles + motion controller.
Combination 2: Aircraft + goggles + remote controller.
• Make sure to set the Aircraft Signal Lost Action in the goggles menu before takeoff. The
aircraft will automatically perform the set Aircraft Signal Lost Action (Return to Home,
Descend, or Hover) in the following scenarios. Make sure to pay attention to the on-screen
prompts in the goggles.
Combination 1: Aircraft + goggles + motion controller. The goggles or the motion
controller is disconnected from the aircraft.
Combination 2: Aircraft + goggles + remote controller. The remote controller is
disconnected from the aircraft.
4
Aircraft Function Compatibility Information
1. Camera switching, settings for gimbal parameter, manual focus,
and intelligent flight modes such as SmartShots, Waypoint Flight,
MasterShots, or QuickShots are not supported.
2. Only the following shooting modes are supported:
• Single shot (12MP resolution)
• Video: Normal (4K/60fps, 1080p/60fps)
3. When using the remote controller as the control device:
DJI Air 3
• Only the goggles display image transmission. DJI Fly does not
display image transmission.
• The remote controller can control the recording function of the
aircraft, but cannot control the recording function of the goggles.
Enabling recording from the shortcut menu of the goggles will
enable the aircraft and the goggles to record simultaneously.
4. When using the motion controller as the control device, head tracking
is supported.
1. The Portrait mode, settings for gimbal parameter, manual focus,
and intelligent flight modes such as SmartShots, Waypoint Flight,
MasterShots, or QuickShots are not supported.
2. Only the following shooting modes are supported:
• Single shot (12MP resolution)
• Video: Normal (4K/60fps, 1080p/60fps)
3. When using the remote controller as the control device:
DJI Mini 4 Pro
• Only the goggles display image transmission. DJI Fly does not
display image transmission.
• The remote controller can control the recording function of the
aircraft, but cannot control the recording function of the goggles.
Enabling recording from the shortcut menu of the goggles will
enable the aircraft and the goggles to record simultaneously.
4. When using the motion controller as the control device, head tracking
is supported.
For more information on how to use the compatible devices, refer to the user manual of the corresponding
product.
DJI is a trademark of DJI.
Copyright © 2024 DJI All Rights Reserved.
