DJI DJI AIR 2S FM User guide

User Manual

v1.0

2021.04

Searching for Keywords

Search for keywords such as “battery” and “install” to find a topic. If you are using Adobe Acrobat Reader to read this document, press Ctrl+F on Windows or Command+F on Mac to begin a search.

Navigating to a Topic

View a complete list of topics in the table of contents. Click on a topic to navigate to that section.

Printing this Document

This document supports high resolution printing.

Using this Manual

Legend

Warning Important Hints and Tips Reference

Read Before the First Flight

Read the following documents before using the DJI

1. Disclaimer and Safety Guidelines

2. Quick Start Guide

3. User Manual

It is recommend to watch all tutorial videos on the ocial DJI website and read the disclaimer and safety guidelines before using for the rst time. Prepare for your rst ight by reviewing the quick start guide

and refer to this user manual for more information.

Video Tutorials

Go to the address below or scan the QR code to watch the DJI Air 2S tutorial videos, which demonstrate how to use the DJI Air 2S safely:

http://www.dji.com/air-2s/video

Download the DJI Fly App

Make sure to use DJI Fly during ight. Scan the QR code on the right to download the

latest version.

The Android version of DJI Fly is compatible with Android v6.0 and later. The iOS version of DJI Fly is compatible with iOS v11.0 and later.

Air 2S:

* For increased safety, ﬂight is restricted to a height of 98.4 ft (30 m) and range of 164 ft (50 m) when not

connected or logged into the app during ﬂight. This applies to DJI Fly and all apps compatible with DJI

aircraft.

Download DJI Assistant 2 (Consumer Drones Series)

Download DJI Assistant 2 (Consumer Drones Series) at

The operating temperature of this product is 0° to 40° C. It does not meet the standard operating

temperature for military grade application (-55° to 125° C), which is required to endure greater

environmental variability. Operate the product appropriately and only for applications that it meets the

operating temperature range requirements of that grade.

http://www.dji.com/air-2s/downloads

Contents

Using this Manual

Legend

Read Before the First Flight

Video Tutorials

Download the DJI Fly App

Download DJI Assistant 2 (Consumer Drones Series)

Product Prole

Introduction

Preparing the Aircraft

Preparing the Remote Controller

Aircraft Diagram

Remote Controller Diagram

Activating DJI Air 2S

Aircraft

Flight Modes

Aircraft Status Indicators

Return to Home

Vision Systems and Infrared Sensing System

Intelligent Flight Mode

Advanced Pilot Assistance Systems 4.0

Flight Recorder

Propellers

Intelligent Flight Battery

Gimbal and Camera

Remote Controller

Remote Controller Prole

Using the Remote Controller

Linking the Remote Controller

DJI Fly App

Home

Camera View

Flight

Flight Environment Requirements

Flight Limits and GEO Zones

Pre-Flight Checklist

Auto Takeoff/Landing

Starting/Stopping the Motors

Flight Test

Appendix

Specications

Firmware Update

After-Sales Information 55

Product Prole

This section introduces lists the components of the aircraft and remote controller.

DJI Air 2S

and

Product Prole

Introduction

DJI Air 2S features a fully stabilized 3-axis gimbal and 1-inch CMOS sensor camera that can shoot

5.4K 30fps, 4K 60fps, and 1080p 120fps video as well as 20MP photos. Capture complex shots easily with DJI signature technologies such as Obstacle Sensing and Advanced Pilot Assistance System 4.0

and enjoy Intelligent Flight modes such as MasterShots, Hyperlapse, QuickShots, and FocusTrack

which includes ActiveTrack 4.0, Spotlight 2.0, and Point of Interest 3.0. DJI Air 2S features both an

Infrared Sensing System and Forward, Backward, Upward, and Downward Vision Systems, allowing for

hovering and ying indoors as well as outdoors and for automatic Return to Home. The aircraft has a maximum ight speed of 42 mph (68.4 kph) and a maximum ight time of 31 minutes.

DJI Air 2S boasts four built-in antennas and DJI’s long-range transmission O3 (OCUSYNCTM 3.0)

technology, oering a maximum transmission range of 12 km and video quality of up to 1080p from the

aircraft to the DJI Fly app on a mobile device.

The remote controller works at both 2.4 and 5.8 GHz, and is capable of selecting the best transmission channel automatically without latency. The aircraft and camera can easily be controlled using the onboard buttons. The maximum runtime of the remote controller is six hours.

Maximum ight time was tested in an environment with no wind while ying at a consistent 12 mph

(19.4 kph) and the maximum ight speed was tested at sea level altitude with no wind. These

values are for reference only.

The remote controller reaches its maximum transmission distance (FCC) in a wide-open area with no electromagnetic interference at an altitude of about 400 ft (120 m). The maximum transmission distance refers to the maximum distance that the aircraft can still send and receive

transmissions. It does not refer to the maximum distance the aircraft can y in a single ight.

The maximum runtime was tested in a laboratory environment and without charging the mobile device. This value is for reference only.

5.8 GHz is not supported in some regions. Observe the local laws and regulations.

Preparing the Aircraft

All aircraft arms are folded before the aircraft is packaged. Follow the steps below to unfold the aircraft.

1. Remove the gimbal protector from the camera.

2. Unfold the front arms, and then unfold the rear arms.

Attach the gimbal protector when not in use.

3. Attach the propellers with marks to the motors with marks. Press the propeller down onto the

motors and turn until it is secure. Attach the other propellers to the unmarked motors. Unfold all the propeller blades.

DJI Air 2S User Manual

4. All Intelligent Flight Batteries are in hibernation mode before delivery to ensure safety. Use the provided charger to charge and activate the Intelligent Flight Batteries for the first time. It takes approximately 1 hour and 35 minutes to fully charge an Intelligent Flight Battery.

Unfold the front arms before unfolding the rear arms.

Make sure the gimbal protector is removed and all arms are unfolded before powering on the aircraft. Otherwise, it may affect the aircraft self-diagnostics.

Preparing the Remote Controller

1. Remove the control sticks from their storage slots on the remote controller and screw them into place.

2. Pull out the mobile device holder. Choose an appropriate remote controller cable based on the type

of mobile device. A Lightning connector cable, Micro USB cable, and USB-C cable are included in the packaging. Connect the end of the cable with the phone icon to your mobile device. Make sure the mobile device is secured.

DJI Air 2S User Manual

If a USB connection prompt appears when using an Android mobile device, select the option to

charge only. Otherwise, it may Otherwise, it may fail to connect.

Aircraft Diagram

1. Forward Vision System

2. Propellers

3. Motors

4. Landing Gears (Built-in antennas)

5. Gimbal and Camera

6. Downward Vision System

7. Auxiliary Bottom Light

8. Infrared Sensing System

9. USB-C Port

10. Battery Buckles

11. Front LEDs

12. Aircraft Status Indicators

13. Backward Vision System

14. Intelligent Flight Battery

15. Battery Level LEDs

16. Power Button

17. microSD Card Slot

18. Upward Vision System

Remote Controller Diagram

DJI Air 2S User Manual

1. Power Button

Press once to check the current battery level. Press once, then again, and hold to power the remote controller on or o.

2. Flight Mode Switch

Switch between Sport mode, Normal mode, and Cine mode.

3. Flight Pause/Return to Home (RTH) Button

Press once to make the aircraft brake and

hover in place (only when GNSS or Vision

Systems are available). Press and hold the

button to initiate RTH. The aircraft returns to

the last recorded Home Point. Press again to

cancel RTH.

4. Battery Level LEDs

Displays the current battery level of the remote controller.

5. Control Sticks

Use the control sticks to control the aircraft

movements. Set the ight control mode in DJI

Fly. The control sticks are removable and easy to store.

6. Customizable Button

Press once to turn the Auxiliary Bottom Light on or o. Press twice to recenter the gimbal or

tilt the gimbal downward (default settings). The button can be set in DJI Fly.

7. Photo/Video Toggle

Press once to switch between photo and video

mode.

8. Remote Controller Cable

Connect to a mobile device for video linking via the remote controller cable. Select the cable according to the mobile device.

9. Mobile Device Holder

Used to securely mount the mobile device to the remote controller.

10. Antennas

Relay aircraft control and video wireless signals.

11. USB-C Port

For charging and connecting the remote controller to the computer.

12. Control Sticks Storage Slot

For storing the control sticks.

13. Gimbal Dial

Controls the tilt of the camera. Press and hold

the customizable button to use the gimbal dial to adjust the zoom in video mode.

14. Shutter/Record Button

Press once to take photos or start or stop

recording.

15. Mobile Device Slot

Used to secure the mobile device.

Activating DJI Air 2S

DJI Air 2S requires activation before using for the rst time. After powering on the aircraft and remote

controller, follow the on-screen instructions to activate DJI Air 2S using DJI Fly. An internet connection is

required for activation.

Aircraft

DJI Air 2S contains a ight controller,

video downlink system, vision systems, infrared sensing system, propulsion system, and an Intelligent Flight Battery.

Aircraft

DJI Air 2S contains a ight controller, video downlink system, vision systems, infrared sensing system,

propulsion system, and an Intelligent Flight Battery.

Flight Modes

DJI Air 2S has three flight modes, plus a fourth flight mode that the aircraft switches to in certain scenarios. Flight modes can be switched via the Flight Mode switch on the remote controller.

Normal Mode: The aircraft utilizes GNSS and the Forward, Backward, Upward and Downward Vision Systems and Infrared Sensing System to locate itself and stabilize. When the GNSS signal is strong, the aircraft uses GNSS to locate itself and stabilize. When the GNSS is weak but the lighting and other

environment conditions are sucient, the aircraft uses the vision systems to locate itself and stabilize.

When the Forward, Backward, Upward and Downward Vision Systems are enabled and lighting and

other environment conditions are sucient, the maximum ight altitude angle is 35° and the maximum ight speed is 15 m/s.

Sport Mode: In Sport Mode, the aircraft uses GNSS for positioning and the aircraft responses are optimized for agility and speed making it more responsive to control stick movements. The maximum

ight speed is 19 m/s. Obstacle sensing is disabled in Sport mode.

Cine Mode: Cine mode is based on Normal mode and the ight speed is limited, making the aircraft

more stable during shooting.

The aircraft automatically changes to Attitude (ATTI) mode when the Vision Systems are unavailable or disabled and when the GNSS signal is weak or the compass experiences interference. In ATTI mode,

the aircraft may be more easily aected by its surroundings. Environmental factors such as wind can result in horizontal shifting, which may present hazards, especially when ying in conned spaces.

The Forward, Backward and Upward Vision Systems are disabled in Sport mode, which means the aircraft cannot sense obstacles on its route automatically.

The maximum speed and braking distance of the aircraft signicantly increase in Sport mode. A minimum braking distance of 30 m is required in windless conditions.

A minimum braking distance of 10 m is required in windless conditions while the aircraft is ascending

and descending.

The responsiveness of the aircraft signicantly increases in Sport mode, which means a small control

stick movement on the remote controller translates into the aircraft moving a large distance. Make

sure to maintain adequate maneuvering space during ight.

DJI Air 2S User Manual

Aircraft Status Indicators

DJI Air 2S has front LEDs and aircraft status indicators.

Front LED

Aircraft Status Indicator

When the aircraft is powered on but the motors are not running, the front LEDs glow solid red to display

the orientation of the aircraft. When the aircraft is powered on but the motors are not running, the

aircraft status indicators display the status of the ight control system. Refer to the table below for more

information about the aircraft status indicators.

After the motor starts, the front LEDs blink green and the aircraft status indicators blink red and green

alternately.

Aircraft Status Indicator States

Color Action Aircraft Status

Normal States

×4

×2

Warning States

——

Alternating red, green, and yellow

Blinks

Yellow Blinks four times Warming up

Green Blinks slowly GNSS enabled

Green Periodically blinks twice Vision Systems enabled

Yellow Blinks slowly NO GNSS or Vision Systems

Yellow Blinks quickly Remote controller signal lost

Red Blinks slowly Low battery

Red Blinks quickly Critically low battery

Red Blinks IMU error

Red Solid Critical error

Alternating red and yellow

Blinks quickly Compass calibration required

Turning on and performing selfdiagnostic tests

DJI Air 2S User Manual

Return to Home

Return to Home (RTH) returns the aircraft to the last recorded Home Point when the positioning system

is functioning normally. There are three types of RTH: Smart RTH, Low Battery RTH, and Failsafe RTH.

The aircraft automatically flies back to the Home Point and lands when Smart RTH is initiated, the aircraft enters Low Battery RTH, or the video link signal is lost during ight.

Description

Home

Point

GNSS

The default Home Point is the first location where the aircraft received a

strong to moderately strong GNSS signal where the icon is white. The Home

Point can be updated before takeo as long as the aircraft receives a strong to moderately strong GNSS. If the GNSS signal is weak then the Home Point

cannot be updated.

Smart RTH

If the GNSS signal is sucient, Smart RTH can be used to bring the aircraft back to the Home Point.

Smart RTH is initiated either by tapping in DJI Fly or by pressing and holding the RTH button on the remote controller until it beeps. Exit Smart RTH by tapping in DJI Fly or by pressing the RTH button on the remote controller.

Smart RTH includes Straight Line RTH and Power Saving RTH.

Straight Line RTH Procedure:

1. The Home Point is recorded.

2. Smart RTH is triggered.

3. a. If the aircraft is farther than 50 m from the Home Point when the RTH procedure begins, the aircraft

adjusts its orientation and ascends to the preset RTH altitude and ies to the Home Point. If the current altitude is higher than the RTH altitude, the aircraft ies to the Home Point at the current

altitude.

b. If the aircraft is at a distance of 5 to 50 m from the Home Point when the RTH procedure begins,

the aircraft adjusts its orientation and ies to the Home Point at the current altitude.

c. If the aircraft is less than 5 m from the Home Point when the RTH procedure begins, it lands

immediately.

4. After reaching the Home Point, the aircraft lands and the motors stop.

If the RTH is triggered through DJI Fly and the aircraft is farther than 5 m from the Home Point, a

prompt will appear in the app for users to select a landing option.

Power Saving RTH Procedure:

During Straight Line RTH, if the distance is farther than 480 m and the altitude is more than 90 m above the RTH altitude as well as more than 290 m above the takeo altitude, a prompt appears in DJI Fly asking the user if they wish to enter Power Saving RTH. After entering Power Saving RTH, the aircraft adjusts to an angle of 14° and ies to the Home Point. The aircraft lands when it is above the Home Point and the motors stop.

The aircraft exits from power saving RTH and enter Straight Line RTH in the following scenarios:

DJI Air 2S User Manual

Formatting here needs adjusting. One line for each point.

1. If the pitch stick is pulled down.

2. If the remote controller signal is lost.

3. If the Vision Systems become unavailable.

Area of where Power Saving RTH is triggered

Aircraft triggers Power Saving RTH

Descent of aircraft in

Power Saving RTH

Low Battery RTH

Low Battery RTH is triggered when the Intelligent Flight Battery is depleted to the point that the safe

return of the aircraft may be aected. Return home or land the aircraft immediately when prompted.

DJI Fly displays a warning when the battery level is low. The aircraft will automatically return to the Home

Point if no action is taken after a 10 second countdown.

The user can cancel RTH by pressing the RTH button or Flight Pause button on the remote controller. If

RTH is cancelled following a low battery level warning, the Intelligent Flight Battery may not have enough power for the aircraft to land safely, which may lead to the aircraft crashing or being lost.

The aircraft will land automatically if the current battery level can only support the aircraft long enough to descend from its current altitude. Auto landing cannot be canceled but the remote controller can be used to alter the direction of the aircraft during the landing process.

Failsafe RTH

If the Home Point was successfully recorded and the compass is functioning normally, Failsafe RTH

automatically activates after the remote controller signal is lost for more than 6 seconds. The aircraft will

y backwards for 50 m on its original ight route, and then enter Straight Line RTH. If the aircraft is less than 50 m from the Home Point when the video signal is lost, it ies to the Home Point at the current

altitude.

After ying for 50 m:

1. If the aircraft is less than 50 m from the Home Point, it ies back to the Home Point at the current

altitude.

2. If the aircraft is farther than 50 m from the Home Point and the current altitude is higher than the preset RTH altitude, it ies back to the Home Point at the current altitude.

3. If the aircraft is farther than 50 m from the Home Point and the current altitude is lower than the preset RTH altitude, it ascends to the preset RTH altitude and then ies back to the Home Point.

Obstacle Avoidance During RTH

When aircraft is ascending:

1. The aircraft brakes when an obstacle is sensed from in front and ies backward until a safe distance

DJI Air 2S User Manual

is reached before continuing to ascend.

2. The aircraft brakes when an obstacle is sensed from behind and ies forward until a safe distance is

reached before continuing to ascend.

3. The aircraft brakes when an obstacle is sensed from above and ies forward until a safe distance is

reached before continuing to ascend.

4. No operation will occur when an obstacle is sensed below the aircraft.

When aircraft is ying forward:

1. The aircraft brakes when an obstacle is sensed from in front and les backward to a safe distance. It ascends until no obstacle is sensed and continues to ascend another 5 m and then continues to y

forward.

2. No operation will occur when an obstacle is sensed from behind.

3. No operation will occur when an obstacle is sensed from above.

4. The aircraft brakes when an obstacle is sensed from below and ascends until no obstacle is sensed

before ying forward.

During RTH, obstacles on either side of the aircraft cannot be detected or avoided.

When ascending in RTH, the aircraft will stop ascending if the throttle stick is pulled all the way down. The aircraft will exit from RTH if the throttle stick is held down for more than 10 seconds or the stick is recentered.

When ying forward in RTH, the aircraft will brake and hover in place if the pitch stick is pulled

all the way down. The aircraft will exit from RTH if the pitch stick is held down for more than 10 seconds.

The aircraft may not be able to return to the Home Point normally if the GNSS signal is weak or unavailable. The aircraft may enter ATTI mode if the GNSS signal becomes weak or unavailable after entering Failsafe RTH. The aircraft will hover in place for a while before landing.

It is important to set a suitable RTH altitude before each ight. Launch DJI Fly and set the RTH

altitude. The default RTH altitude is 100 m.

The aircraft cannot avoid obstacles during Failsafe RTH if the Forward, Backward, and Upward Vision Systems are unavailable.

During RTH, the speed and altitude of the aircraft can be controlled using the remote controller or DJI Fly if the remote controller signal is normal. The orientation of the aircraft and the direction

of ight, however, cannot be controlled. The aircraft cannot avoid obstacles if the pitch stick is used to accelerate and the ight speed exceeds 15 m/s.

If the aircraft ies into a GEO zone during RTH it will either descend until it exits the GEO zone

and continue to the Home Point or it will hover in place.

The aircraft may not be able to return to a Home Point when the wind speed is too high. Fly with caution.

Landing Protection

Landing Protection will activate during Smart RTH.

1. During Landing Protection, the aircraft will automatically detect and carefully land on suitable ground.

2. If the ground is determined unsuitable for landing, DJI Air 2S will hover and wait for pilot conrmation.

3. If Landing Protection is not operational, DJI Fly will display a landing prompt when the aircraft descends below 0.5 m. Pull down on the throttle stick or use the auto landing slider to land.

Landing Protection activates during Low Battery RTH and Failsafe RTH. The aircraft performs as follows:

DJI Air 2S User Manual

During Low Battery RTH and Failsafe RTH, the aircraft hovers at 0.5 m above the ground and waits for

the pilot to conrm it is suitable to land. Pull down on the throttle for one second or use the auto landing slider in the app to land. Landing Protection activates and the aircraft performs the steps listed above.

Precision Landing

The aircraft automatically scans and attempts to match the terrain features below during RTH. When the

current terrain matches the Home Point terrain, the aircraft will land. A prompt will appear in DJI Fly if the

terrain match fails.

Landing Protection is activated during Precision Landing.

The Precision Landing performance is subject to the following conditions:

a. The Home Point must be recorded upon takeo and must not be changed during ight. Otherwise,

the aircraft will have no record of the Home Point terrain features.

b. During takeo, the aircraft must ascend at least 7 m before ying horizontally.

c. The Home Point terrain features must remain largely unchanged.

d. The terrain features of the Home Point must be suciently distinctive. Terrain such as snow-covered

areas are not suitable.

e. The lighting conditions must not be too light or too dark.

The following actions are available during Precision Landing:

a. Press the throttle stick down to accelerate landing.

b. Move the control sticks in any direction to stop Precision Landing. The aircraft will descend vertically

after the control sticks are released.

Vision Systems and Infrared Sensing System

DJI Air 2S is equipped with both an Infrared Sensing System and Forward, Backward, Upward, and

Downward Vision Systems.

The Forward, Backward, Upward, and Downward Vision Systems consist of two cameras each and the Infrared Sensing System consists of two 3D infrared modules.

The Downward Vision System and Infrared Sensing System helps the aircraft maintain its current position, hover in place more precisely, and to fly indoors or in other environments where GNSS is unavailable.

In addition, the Auxiliary Bottom Light located on the underside of the aircraft improves visibility for the Downward Vision System in weak light conditions.

Forward Vision System

Downward Vision System

Infrared Sensing System

Downward Vision System

Auxiliary Bottom Light

Backward Vision System

Upward Vision System

DJI Air 2S User Manual

Detection Range

Forward Vision System

Detection Range: 0.38-23.8 m; FOV: 72° (horizontal), 58° (vertical)

Backward Vision System

Detection Range :0.37-23.4 m; FOV: 57° (horizontal), 44° (vertical)

Upward Vision System

Detection Range: 0.34-28.6 m; FOV: 63° (horizontal), 78° (vertical)

Downward Vision System

The Downward Vision System works best when the aircraft is at an altitude of 0.5 to 30 m, and its operating range is 0.5 to 60 m.

0.38-23.8 m

72°

57°

0.37-23.4 m

0.34-28.6 m 63°

63°

44°

78°

58°

0.5-30 m

Calibrating Vision System Cameras

Auto Calibration

The Vision System cameras installed on the aircraft are factory calibrated. If any abnormality is detected with a vision system camera, the aircraft will automatically perform calibration and a prompt will appear

in DJI Fly. No further operation is required.

Advanced Calibration

If the abnormality persists after auto calibration, a prompt appears in the app that advanced calibration

is required. The advanced calibration must be used with DJI Assistant 2 (Consumer Drones Series).

Follow the steps below to calibrate the Forward Vision System camera and repeat the steps to calibrate other Vision System cameras.

Point the aircraft toward the screen.

Align the boxes.

Pan and tilt the aircraft.

DJI Air 2S User Manual

Using the Vision Systems

When GNSS is unavailable, the Downward Vision System is enabled if the surface has a clear texture

and sucient light. The Downward Vision System works best when the aircraft is at an altitude of 0.5 to

30 m.

The Forward, Backward, and Upward Vision Systems will activate automatically when the aircraft is powered on if the aircraft is in Normal or Cine mode and Obstacle Avoidance is set to Bypass or Break in DJI Fly. Using the Forward, Backward, and Upward Vision Systems, the aircraft can actively brake when detecting obstacles. The Forward, Backward, and Upward Vision Systems work best with

adequate lighting and clearly marked or textured obstacles.

Vision Systems have limited ability to sense and avoid obstacles, and the performance may be affected by the surrounding environment. Make sure to maintain visual line of sight with the aircraft and pay attention to prompts in DJI Fly.

The max hover altitude of the aircraft is 60 m if there is no GNSS available. The Downward Vision

Systems work best when the aircraft is at an altitude from 0.5 to 30 m. Extra caution is required if

the altitude of the aircraft is above 30 m as the Vision Systems may be affected.

The Auxiliary Bottom Light can be set in DJI Fly. If set to Auto, it is automatically enabled when

the environment light is too weak. Note that the Vision System cameras performance may be

affected when the Auxiliary Bottom Light is enabled. Fly with caution if the GNSS signal is weak.

The Vision Systems may not function properly when the aircraft is ying over water or snow-covered

areas.

The Vision Systems cannot work properly over surfaces that do not have clear pattern variations. The Vision Systems cannot work properly in any of the following situations. Operate the aircraft cautiously.

a. Flying over monochrome surfaces (e.g., pure black, pure white, pure green).

b. Flying over highly reective surfaces.

c. Flying over water or transparent surfaces.

d. Flying over moving surfaces or objects.

e. Flying in an area where the lighting changes frequently or drastically.

f. Flying over extremely dark (< 10 lux) or bright (> 40,000 lux) surfaces.

g. Flying over surfaces that strongly reect or absorb infrared waves (e.g., mirrors).

h. Flying over surfaces without clear patterns or texture.

i. Flying over surfaces with repeating identical patterns or textures (e.g., tiles with the same design).

j. Flying over obstacles with small surface areas (e.g., tree branches).

Keep the sensors clean at all times. DO NOT tamper with the sensors. DO NOT use the aircraft in dusty or humid environments.

DJI Air 2S User Manual

Calibrate the camera if the aircraft is involved in a collision or if prompted to do so in DJI Fly.

DO NOT y when it is raining, foggy, or if there is no clear sight.

Check the following before each takeoff:

a. Make sure there are no stickers or any other obstructions over the Infrared Sensing and Vision

Systems.

b. If there is any dirt, dust, or water on the Infrared Sensing and Vision Systems, clean it with a soft

cloth. Do not use any cleanser that contains alcohol.

c. Contact DJI Support if there is any damage to the glass of the Infrared Sensing and Vision

Systems.

DO NOT obstruct the Infrared Sensing System.

Intelligent Flight Mode

FocusTrack

FocusTrack includes Spotlight 2.0, ActiveTrack 4.0, and Point of Interest 3.0.

Spotlight 2.0: Control the aircraft manually while the camera remains locked on the subject with this convenient mode. Move the roll stick to circle the subject, move the pitch stick to alter the distance from the subject, move the throttle stick to change the altitude, and move the pan stick to adjust the frame.

ActiveTrack 4.0: ActiveTrack 4.0 has two modes. Move the roll stick to circle the subject, move the pitch stick to alter the distance from the subject, move the throttle stick to change the altitude, and move the pan stick to adjust the frame.

1. Trace: The aircraft tracks the subject at a constant distance. In Normal and Cine mode, the

maximum ight speed is 12 m/s. The aircraft can sense obstacles in this mode when there are pitch

stick movements, but cannot sense obstacles when there are roll and throttle stick movements. In

Sport mode, the maximum ight speed is 19 m/s and the aircraft cannot sense obstacles.

2. Parallel: The aircraft tracks the subject at a constant angle and distance from the side. In Normal and Cine mode, the maximum ight speed is 12 m/s. In Sport mode, the maximum ight speed is 19 m/s. The aircraft cannot sense obstacles in Parallel.

Point of Interest 3.0 (POI 3.0): The aircraft tracks the subject in a circle based on the radius and ight

speed that is set. The mode supports both static and moving subjects such as vehicles, boats, and people. Note that the altitude of the aircraft will not change if the altitude of a subject changes and subjects that move too fast may be lost.

Using FocusTrack

1. Take o and hover at least 1 m above the ground.

1 m

DJI Air 2S User Manual

RCRC

1:30:301:30:30

STORAGESTORAGE

FHD 120FHD 120

SIZESIZE

+1.0+1.0

EVEV

0m/s3m/s

50m50m

0m/s3m/s

30m30m

POISpotlightActiveTrack

In Flight

2. Drag a box around the subject in the camera view to enable FocusTrack.

23 26

3. FocusTrack begins. The default mode is Spotlight. Tap the icon to switch between Spotlight , ActiveTrack , and POI . Once subjects can be recognized, ActiveTrack will begin when a wave

gesture is detected. Users can wave with a single hand and their elbow above their shoulder.

4. Tap the shutter/record button to take photos or start recording. View the footage in Playback.

Exiting FocusTrack

Tap Stop in DJI Fly or press the Flight Pause button once on the remote controller to exit FocusTrack.

DO NOT use FocusTrack in areas with people, animals, small or ﬁne objects (e.g., tree branches or power lines), or transparent objects (e.g., water or glass).

Pay attention to objects around the aircraft and use the remote controller to avoid collisions with

the aircraft.

Operate the aircraft manually. Press the Flight Pause button or tap stop in DJI Fly in an emergency.

Be extra vigilant when using FocusTrack in any of the following situations:

a. The tracked subject is not moving on a level plane.

b. The tracked subject changes shape drastically while moving.

c. The tracked subject is out of sight for an extended period.

d. The tracked subject is moving on a snowy surface.

e. The tracked subject has a similar color or pattern to its surrounding environment.

f. The lighting is extremely low (<300 lux) or high (>10,000 lux).

Make sure to follow local privacy laws and regulations when using FocusTrack.

It is recommended to only track vehicles, boats, and people (but not children). Fly with caution when tracking other subjects.

Do not track a remote control model car or boat.

The tracking subject may inadvertently swap to another subject if they pass nearby to each other.

When using a gesture to activate ActiveTrack, the aircraft only tracks the people who perform the

rst detected gesture. The distance between the people and aircraft should be 5 to 10 m and the tilt

angle of the aircraft should not exceed 60°.

FcousTrack is disabled when recording at a high resolution such as 2.7K 48/50/60 fps, 1080p

48/50/60/120 fps, 4K 48/50/60 fps, and 5.4K 24/25/30 fps.

DJI Air 2S User Manual

RCRC

1:30:301:30:30

STORAGESTORAGE

FHD 120FHD 120

SIZESIZE

+1.0+1.0

EVEV

0m/s3m/s

50m50m

0m/s3m/s

30m30m

Start

Video


QuickShot

MasterShot

MasterShots

MasterShots keeps the subject in the center of the frame while executing different maneuvers in

sequence to generate a short cinematic video.

Using MasterShots

1. Take o and hover at least 2 m above the ground.

2 m

2. In DJI Fly, tap the shooting mode icon to select MasterShots and follow the prompts. Make sure that you understand how to use the shooting mode and that there are no obstacles in the surrounding area.

3. Select your target subject in the camera view by tapping the circle on the subject or dragging a box

around the subject. Tap Start to begin recording. The aircraft ies back to its original position once shooting is nished.

In Flight

23 26

4. Tap to access the video.

Exiting MasterShots

Press the Flight Pause button once or tap in DJI Fly to exit MasterShots. The aircraft will hover in place.

Use MasterShots at locations that are clear of buildings and other obstacles. Make sure that there

are no humans, animals, or other obstacles on the ight path. The aircraft will brake and hover in

place if there is an obstacle detected. Note that obstacles cannot be detected on either side of the aircraft.

Pay attention to objects around the aircraft and use the remote controller to avoid collisions with the

aircraft.

DJI Air 2S User Manual

DO NOT use MasterShots in any of the following situations:

a. When the subject is blocked for an extended period or outside the line of sight.

b. When the subject is similar in color or pattern with the surroundings.

c. When the subject is in the air.

d. When the subject moves fast.

e. The lighting is extremely low (<300 lux) or high (>10,000 lux).

DO NOT use MasterShots in places that are close to buildings or where the GNSS signal is weak.

Otherwise, the ight path will be unstable.

Make sure to follow local privacy laws and regulations when using MasterShots.

QuickShots

QuickShots shooting modes include Dronie, Rocket, Circle, Helix, Boomerang, and Asteroid. DJI Air 2S records according to the selected shooting mode and automatically generates a short video. The video can be viewed, edited, or shared to social media from playback.

Dronie: The aircraft ies backward and ascends, with the camera locked on the subject.

Rocket: The aircraft ascends with the camera pointing downward.

Circle: The aircraft circles around the subject.

Helix: The aircraft ascends and spirals around the subject.

Boomerang: The aircraft ies around the subject in an oval path, ascending as it ies away from

its starting point and descending as it flies back. The starting point of the aircraft forms one end of the long axis of the oval while the other end of the long axis is at the opposite side of the

subject from the starting point. Make sure there is sucient space when using Boomerang. Allow

a radius of at least 30 m around the aircraft and allow at least 10 m above the aircraft.

Asteroid: The aircraft ies backward and upward, takes several photos, and then ies back to

the starting point. The video generated starts with a panorama of the highest position and then

shows the descent. Make sure there is sucient space when using Asteroid. Allow at least 40 m

behind and 50 m above the aircraft.

Using QuickShots

1. Take o and hover at least 2 m above the ground.

2 m

DJI Air 2S User Manual

RCRC

1:30:301:30:30

STORAGESTORAGE

FHD 120FHD 120

SIZESIZE

+1.0+1.0

EVEV

0m/s3m/s

50m50m

0m/s3m/s

30m30m

Start

Video


QuickShot

MasterShot

2. In DJI Fly, tap the shooting mode icon to select QuickShots and follow the prompts. Make sure that you understand how to use the shooting mode and that there are no obstacles in the surrounding area.

3. Select your target subject in the camera view by tapping the circle on the subject or dragging a box around the subject. Choose a shooting mode and tap Start to begin recording. QuickShots can also be triggered with a wave gesture. Users can wave with a single hand and their elbow above their

shoulder. The aircraft ies back to its original position once shooting is nished.

In Flight

23 26

4. Tap to access the video.

Exiting QuickShots

Press the Flight Pause button once or tap in DJI Fly to exit QuickShots. The aircraft will hover in place.

Use QuickShots at locations that are clear of buildings and other obstacles. Make sure that there are

no humans, animals, or other obstacles on the ight path. The aircraft will brake and hover in place if

there is an obstacle detected. Note that obstacles cannot be detected on either side of the aircraft.

Pay attention to objects around the aircraft and use the remote controller to avoid collisions with the

aircraft.

DO NOT use QuickShots in any of the following situations:

a. When the subject is blocked for an extended period or outside the line of sight.

b. When the subject is more than 50 m away from the aircraft.

c. When the subject is similar in color or pattern with the surroundings.

d. When the subject is in the air.

e. When the subject moves fast.

f. The lighting is extremely low (<300 lux) or high (>10,000 lux).

DO NOT use QuickShots in places that are close to buildings or where the GNSS signal is weak.

Otherwise, the ight path will be unstable.

Make sure to follow local privacy laws and regulations when using QuickShots.

When using a gesture to activate QuickShots, the aircraft will only track the people who perform

the first detected gesture. The distance between the people and aircraft should be 5 to 10 m and tilt angle of the aircraft should not exceed 60°.

DJI Air 2S User Manual

RCRC

1:30:301:30:30

STORAGESTORAGE

FHD 120FHD 120

SIZESIZE

+1.0+1.0

EVEV

0m/s3m/s

50m50m

0m/s3m/s

30m30m

Hyperlapse

Hyperlapse shooting modes include Free, Circle, Course Lock, and Waypoint.

In Flight

23 26

Free

Circle

MasterShot

QuickShot

Hyperlapse

Pano

A message should be simple

Course Lock

Waypoint

Free

The aircraft automatically takes photos and generates a timelapse video. Free mode can be used while

the aircraft is on the ground. After takeo, control the movement and gimbal angle of the aircraft using

the remote controller. Follow the steps below to use Free:

1. Set the interval time, video duration, and max speed. The screen displays the number of photos that will be taken and how long the shooting time will be.

2. Tap the shutter/record button to begin.

Cruise Control: Set the function of the Customizable button to Cruise Control and press the Customizable button and control stick at the same time to enter Cruise Control. The aircraft will continue

to y at the same speed.

Circle

The aircraft automatically takes photos while ying around the selected subject to generate a timelapse

video. Follow the steps below to use Circle:

1. Set the interval time, video duration, and max speed. Circle can be selected to travel in either a clockwise or counter-clockwise direction. The screen displays the number of photos that will be taken and how long the shooting time will be.

2. Select a subject on the screen.

3. Tap the shutter/record button to begin.

4. Move the pan stick and gimbal dial to adjust the frame, move the tilt stick to alter the distance from the subject, move the roll stick to control the circled speed, and move the throttle stick to control the

vertical ight speed.

Course Lock

Course Lock can be used in two ways. In the rst way, the orientation of the aircraft is xed, but a subject cannot be selected. In the second way, the orientation of the aircraft is xed and the aircraft ies

around a selected object. Follow the steps below to use Course Lock:

1. Set the interval time, video duration, and max speed. The screen displays the number of photos that will be taken and how long the shooting time will be.

2. Set a ight direction.

3. If applicable, select a subject. Use the gimbal dial and pan stick to adjust the frame.

DJI Air 2S User Manual

4. Tap the shutter/record button to begin. Move the tilt stick and roll stick to control the horizontal ight speed and move the aircraft parallel. Move the throttle stick to control the vertical ight speed.

Waypoints

The aircraft automatically takes photos on a flight path of two to five waypoints and generates a

timelapse video. The aircraft can y in order from waypoint 1 to 5 or 5 to 1. Follow the steps below to

use Waypoints.

1. Set the desired waypoints and the lens direction.

2. Set the interval time, video duration, and max speed. The screen displays the number of photos that will be taken and how long the shooting time will be.

3. Tap the shutter button to begin.

The aircraft will generate a timelapse video automatically, which is viewable in playback. In the camera

settings, users can select to save the footage in JPEG or RAW format and to store the footage in the

built-in storage or the microSD card.

For optimal performance, it is recommended to use Hyperlapse at an altitude higher than 50 m and

to set a dierence of at least two seconds between the interval time and shutter.

It is recommended to select a static subject (e.g., high-rise buildings, mountainous terrain) at a safe distance from the aircraft (farther than 15 m). Do not select a subject that is too near the aircraft.

The aircraft brakes and hovers in place if an obstacle is detected during Hyperlapse. Note that obstacles cannot be detected on either side of the aircraft.

The aircraft only generates a video if it has taken at least 25 photos, which is the amount required to

generate a one second video. The video is generated when a user command is received from the remote controller or if the mode is exited unexpectedly such as when Low Battery RTH is triggered.

Advanced Pilot Assistance Systems 4.0

The Advanced Pilot Assistance Systems 4.0 (APAS 4.0) feature is available in Normal mode. When APAS is enabled, the aircraft continues to respond to user commands and plans its path according to both control stick inputs and the ight environment. APAS makes it easier to avoid obstacles, obtain smoother footage, and gives a better ying experience.

Keep moving the pitch stick forward or backward. The aircraft will avoid the obstacles by ying above,

below, or to the left or right of the obstacle.

When APAS is enabled, the aircraft can be brought to a stop by pressing the Flight Pause button on

the remote controller or tapping Stop on the screen in DJI Fly. The aircraft hovers for three seconds and awaits further pilot commands.

To enable APAS, open DJI Fly, enter System Settings, then Safety, and enable APAS.

DJI Air 2S User Manual

APAS is disabled when using Intelligent Flight modes and recording at high resolution such as 2.7K

48/50/60 fps, 1080p 120 fps, 4K 48/50/60 fps, and 5.4K 24/25/30 fps.

APAS is only available when ying forward, backward, upward, and downward. APAS is disabled if the aircraft ies left or right.

Make sure you use APAS when the Forward and Backward Vision Systems are available. Be sure

there are no people, animals, objects with small surface areas (e.g., tree branches), or transparent

objects (e.g., glass or water) along the desired ight path.

Make sure you use APAS when the Downward Vision System is available or the GNSS signal is strong. APAS may not function properly when the aircraft is ying over water or snow-covered areas.

Be extra cautious when ying in extremely dark (<300 lux) or bright (>10,000 lux) environments.

Pay attention to DJI Fly and make sure the aircraft is working normally in APAS mode.

APAS may not function properly when the aircraft is ying near ight limits or in a GEO zone.

Flight Recorder

Flight data including ight telemetry, aircraft status information, and other parameters are automatically

saved to the internal data recorder of the aircraft. The data can be accessed using DJI Assistant 2 (Consumer Drones Series).

Propellers

There are two types of DJI Air 2S Low-Noise Quick Release Propellers, which are designed to spin in dierent directions. Marks are used to indicate which propellers should be attached to which motors.

Make sure to match the propeller and motor following the instructions.

Propellers Marked Unmarked

Illustration

Position Attach on motors with marks Attach on motors without marks

Description Turn the propellers in the indicated direction to mount and tighten.

Attaching the Propellers

Attach the propellers with marks to the motors with marks and the unmarked propellers to the motors

without marks. Press each propeller down onto the motor and turn until it is secure.

DJI Air 2S User Manual

Detaching the Propellers

Press the propellers down onto the motors and rotate them in the unlock direction.

Propeller blades are sharp. Handle with care.

Only use ocial DJI propellers. DO NOT mix propeller types.

Purchase the propellers separately if necessary.

Make sure that the propellers are installed securely before each ight.

Make sure all propellers are in good condition before each ight. DO NOT use aged, chipped, or

broken propellers.

Stay away from the rotating propellers and motors to avoid injuries.

Do not squeeze or bend the propellers during transportation or storage.

Make sure the motors are mounted securely and rotating smoothly. Land the aircraft immediately if a motor is stuck and unable to rotate freely.

DO NOT attempt to modify the structure of the motors.

DO NOT touch or let your hands or body come in contact with the motors after ight as they may be

hot.

DO NOT block any of the ventilation holes on the motors or the body of the aircraft.

Make sure the ESCs sound normal when powered on.

Intelligent Flight Battery

The DJI Air 2S Intelligent Flight Battery is a 11.55 V, 3500 mAh battery with smart charging and discharging functionality.

Battery Features

1. Battery Level Display: The LED indicators display the current battery level.

2. Auto-Discharging Function: To prevent swelling, the battery automatically discharges to 96% of the battery level when it is idle for one day, and automatically discharges to 60% of the battery level when it is idle for ve days. It is normal to feel moderate heat being emitted from the battery during

the discharging process.

3. Balanced Charging: During charging, the voltages of the battery cells are automatically balanced.

4. Overcharge Protection: The battery stops charging automatically once fully charged.

5. Temperature Detection: In order to protect itself, the battery only charges when the temperature is between 41° and 104° F (5° and 40° C).

6. Overcurrent Protection: The battery stops charging if an excess current is detected.

7. Over-Discharge Protection: Discharging stops automatically to prevent excess discharge when the

battery is not in use. Over-discharge protection is not enabled when the battery is in use.

DJI Air 2S User Manual

8. Short Circuit Protection: The power supply is automatically cut if a short circuit is detected.

9. Battery Cell Damage Protection: DJI Fly displays a warning prompt when a damaged battery cell is

detected.

10. Hibernation Mode: The battery switches o after 20 minutes of inactivity to save power. If the battery

level is less than 5%, the battery enters Hibernation mode to prevent over-discharge after being idle

for six hours. In Hibernation mode, the battery level indicators do not illuminate. Charge the battery to wake it from hibernation.

11. Communication: Information about the voltage, capacity, and current of the battery is transmitted to

the aircraft.

Refer to the DJI Air 2S Disclaimer and Safety Guidelines and the battery sticker before use. Users take full responsibility for all operations and usage.

Using the Battery

Checking Battery Level

Press the power button once to check the battery level.

Battery Level LEDs

LED4

LED2

Power Button

LED1LED3

Battery Level LEDs

: LED is on : LED is ashing : LED is o

LED1 LED2 LED3 LED4

Battery Level

Battery Level ≥ 88%

75% ≤ Battery Level < 88%

63% ≤ Battery Level < 75%

50% ≤ Battery Level < 63%

38% ≤ Battery Level < 50%

25% ≤ Battery Level < 38%

13% ≤ Battery Level < 25%

0% ≤ Battery Level < 13%

Powering On/O

Press the power button once, then press again, and hold for two seconds to power the battery on or o. The battery level LEDs display the battery level when the aircraft is powered on.

Low Temperature Notice

1. Battery capacity is signicantly reduced when ying in low-temperature environments of 32° to 41° F (0°

to 5° C). It is recommended to hover the aircraft in place for a while to heat the battery. Make sure to

DJI Air 2S User Manual

fully charge the battery before takeo.

2. Batteries cannot be used in extremely low-temperature environments of lower than 14° F (-10° C).

3. When in low-temperature environments, end the ight as soon as DJI Fly displays the low battery

level warning.

4. To ensure the optimal performance of the battery, keep the battery temperature above 68° F (20° C).

5. The reduced battery capacity in low-temperature environments reduces the wind speed resistance performance of the aircraft. Fly with caution.

6. Fly with extra caution at high sea levels.

Charging the Battery

Fully charge the Intelligent Flight Battery before every ight using the provided DJI charger.

1. Connect the AC power adapter to an AC power supply (100-240 V, 50/60 Hz).

2. Attach the Intelligent Flight Battery to the AC power adapter using the battery charging cable with

the battery powered o.

3. The battery level LEDs display the current battery level during charging.

4. The Intelligent Flight Battery is fully charged when all the battery level LEDs are off. Detach the

charger when the battery is fully charged.

DO NOT charge an Intelligent Flight Battery immediately after ight as the temperature may be too

high. Wait until it cools down to room temperature before charging again.

The charger stops charging the battery if the battery cell temperature is not within the operating

range of 41° to 104° F (5° to 40° C). The ideal charging temperature is 71.6° to 82.4° F (22° to 28° C).

The Battery Charging Hub (not included) can charge up to three batteries. Visit the ocial DJI Online

Store for more information.

Fully charge the battery at least once every three months to maintain battery health.

DJI does not take any responsibility for damage caused by third-party chargers.

It is recommended to discharge the Intelligent Flight Batteries to 30% or lower before transportation. This can be done by ying the aircraft outdoors until there is less than 30% charge left.

The table below shows the battery level during charging.

LED1 LED2 LED3 LED4

Battery Level

0% < Battery Level ≤ 50%

50% < Battery Level ≤ 75%

75% < Battery Level < 100%

Fully Charged

DJI Air 2S User Manual

Battery Protection Mechanisms

The battery LED indicator can display battery protection indications triggered by abnormal charging

conditions.

Battery Protection Mechanisms

LED1 LED2 LED3 LED4 Blinking Pattern

Status

LED2 blinks twice per second Overcurrent detected

LED2 blinks three times per

second

Short circuit detected

LED3 blinks twice per second Overcharge detected

LED3 blinks three times per

second

Over-voltage charger detected

LED4 blinks twice per second Charging temperature is too low

LED4 blinks three times per

second

Charging temperature is too high

If the battery protection mechanisms activate, in order to resume charging it is necessary to unplug the battery from the charger and plug it in agai. If the charging temperature is abnormal, wait for the charging temperature to return to normal, and the battery will automatically resume charging without

requiring to unplug and plug in the charger again.

Inserting the Intelligent Flight Battery

Insert the Intelligent Flight Battery into the battery compartment of the aircraft. Make sure it is mounted securely and that the battery buckles click into place.

Click

Removing the Intelligent Flight Battery

Press the battery buckles on the sides of the Intelligent Flight Battery to remove it from the

compartment.

DO NOT detach the battery when the aircraft is powering on.

Make sure that the battery is mounted rmly.

DJI Air 2S User Manual

-80° 80°

Gimbal and Camera

Gimbal Prole

The 3-axis gimbal of DJI Air 2S provides stabilization for the camera, allowing you to capture clear and

stable images and video. The control tilt range is -90° to +24°. The default control tilt range is -90˚ to 0˚, and the tilt range can be extended to -90˚ to +24˚ by enabling “Allow Upward Gimbal Rotation” in DJI Fly.

24°

0°

-90°

Use the gimbal dial on the remote controller to control the tilt of the camera. Alternatively, enter the

camera view in DJI Fly. Press the screen until an adjustment bar appears and drag up and down to

control the tilt of the camera.

Gimbal Operation Modes

Two gimbal operation modes are available. Switch between the dierent operation modes in DJI Fly.

Follow Mode: The angle between the gimbal’s orientation and aircraft front remains constant at all times.

FPV Mode: The gimbal synchronizes with the movement of the aircraft to provide a rst-person ying

experience.

Do not tap or knock the gimbal when the aircraft is powered on. To protect the gimbal during

takeoff, take off from open and at ground.

Precision elements in the gimbal may be damaged in a collision or impact, which may cause the gimbal to function abnormally.

Avoid getting dust or sand on the gimbal, especially in the gimbal motors.

A gimbal motor may enter protection mode in the following situations:

a. The aircraft is on uneven ground or the gimbal is obstructed.

b. The gimbal experiences excessive external force, such as during a collision.

DO NOT apply external force to the gimbal after the gimbal is powered on. DO NOT add any extra payload to the gimbal as this may cause the gimbal to function abnormally or even lead to permanent motor damage.

Make sure to remove the gimbal protector before powering on the aircraft. Also, make sure to mount the gimbal protector when the aircraft is not in use.

Flying in heavy fog or clouds may make the gimbal wet, leading to temporary failure. The gimbal recovers full functionality once it is dry.

DJI Air 2S User Manual

Camera Prole

DJI Air 2S uses a 1-inch CMOS sensor camera, which can shoot 5.4K 30 fps, 4K 60fps, and 1080p

120 fps video and 20MP photos. It also supports shooting modes such as SmartPhoto, Slow Motion, MasterShots, QuickShots, Hyperlapse, and Panorama. The aperture of the camera is f2.8 and can shoot at 0.6 m to innity.

Make sure the temperature and humidity is suitable for the camera during usage and storage.

Use a lens cleanser to clean the lens to avoid damage.

DO NOT block any ventilation holes on the camera as the heat generated may damage the device and hurt the user.

Storing Photos and Videos

DJI Air 2S supports the use of a microSD card to store photos and videos. A UHS-I Speed Grade 3

rating microSD card is required due to the fast read and write speeds necessary for high-resolution

video data. Refer to the Specifications section for more information about recommended microSD cards.

Do not remove the microSD card from the aircraft while it is powered on. Otherwise, the microSD card may be damaged.

To ensure the stability of the camera system, single video recordings are limited to 30 minutes.

Check camera settings before use to ensure they are conﬁgured as desired.

Before shooting important photos or videos, shoot a few images to test the camera is operating correctly.

Photos or videos cannot be transmitted or copied from the camera if the aircraft is powered off.

Make sure to power off the aircraft correctly. Otherwise, your camera parameters will not be saved and any recorded videos may be damaged. DJI is not responsible for any failure of an image or video to be recorded or having been recorded in a way that is not machine-readable.

Remote Controller

This section describes the features of the remote controller and includes instructions for controlling the aircraft and the camera.

Remote Controller

Remote Controller Profile

Built into the remote controller is DJI’s long-range transmission technology OcuSync 2.0, offering a maximum transmission range of 12 km and displaying video from the aircraft to DJI Fly on a mobile device at up to 1080p. The aircraft and camera are easy to control using the onboard buttons and the detachable control sticks make the remote controller easier to store.

In a wide-open area with no electromagnetic interference, the aircraft uses O3 and the remote controller uses OcuSync 2.0 to smoothly transmit video links at up to 1080p, no matter the change in flight attitude. The remote controller works at both 2.4 GHz and 5.8 GHz, automatically selecting the best transmission channel. Transmission system reduces the latency to 120-130 ms by improving the camera performance through its video decoding algorithm and the wireless link.

The built-in battery has a capacity of 5200 mAh and a maximum run time of 6 hours. The remote controller charges the mobile device with a charging ability of 500 mA@5V. The remote controller automatically charges Android devices. For iOS devices, first make sure that charging is enabled in DJI Fly. Charging for iOS devices is disabled by default and needs to be enabled each time the remote controller is powered on.

Compliance Version: The remote controller is compliant with local regulations.

Control Stick Mode: The control stick mode determines the function of each control stick movement.

Three pre-programmed modes (Mode 1, Mode 2, and Mode 3) are available and custom modes can

be congured in DJI Fly. The default mode is Mode 2.

Using the Remote Controller

Powering On/O

Press the power button once to check the current battery level. Press once, then again, and hold to power the remote controller on or o. If the battery level is too low, recharge before use.

Charging the Battery

Use a USB-C cable to connect an AC power charger to the USB-C port of the remote controller. It takes approximately four hours to fully charge the remote controller.

Power Outlet

Controlling the Gimbal and Camera

1. Shutter/Record Button: Press once take a photo or to start or stop recording.

2. Photo/Video Toggle: Press once to switch between photo and video mode.

3. Gimbal Dial: Use to control the tilt of the gimbal.

4. Press and hold the customizable button in order to be able to use the gimbal dial to adjust the zoom

in video mode.

DJI Air 2S User Manual

Gimbal Dial

Customizable Button

Shutter/Record Button

Photo/Video

Toggle

Controlling the Aircraft

The control sticks control the aircraft’s orientation (pan), forward/backward movement (pitch), altitude (throttle), and left/right movement (roll). The control stick mode determines the function of each control stick movement. Three preprogrammed modes (Mode 1, Mode 2, and Mode 3) are available and

custom modes can be congured in DJI Fly. The default mode is Mode 2.

Mode 1

Left Stick

Mode 2

Forward

Backward

Right Stick

Turn RightTurn Left

Right StickLeft Stick

Down

RightLeft

Forward

Mode 3

Down

Turn RightTurn Left

Left Stick Right Stick

Forward

Backward

RightLeft

Backward

RightLeft

Down

Turn RightTurn Left

DJI Air 2S User Manual

Remote

Controller

(Mode 2)

Aircraft

( Indicates Nose Direction)

Remarks

Moving the left stick up or down changes the

aircraft’s altitude. Push the stick up to ascend and

down to descend. The more the stick is pushed away from the center position, the faster the

aircraft will change altitude. Push the stick gently

to prevent sudden and unexpected changes in altitude.

Moving the left stick to the left or right controls

the orientation of the aircraft. Push the stick left to

rotate the aircraft counter-clockwise and right to rotate the aircraft clockwise. The more the stick is pushed away from the center position, the faster the aircraft will rotate.

Moving the right stick up and down changes the

aircraft’s pitch. Push the stick up to y forward and down to y backward. The more the stick is

pushed away from the center position, the faster the aircraft will move.

Moving the right stick to the left or right changes

the aircraft’s roll. Push the stick left to y left and right to y right. The more the stick is pushed

away from the center position, the faster the aircraft will move.

Flight Mode Switch

Toggle the switch to select the ight mode.

Position Flight Mode

Sport Sport Mode

Normal Normal Mode

Cine Cine Mode

Flight Pause/RTH Button

Press once to make the aircraft brake and hover in place. If the aircraft is performing MasterShots,

QuickShots, Smart RTH, or auto landing, press once to exit the procedure and then brake.

Press and hold the RTH button until the remote controller beeps to start RTH. Press this button again to

cancel RTH and regain control of the aircraft. Refer to the Return to Home section for more information about RTH.

DJI Air 2S User Manual

Customizable Button

Go to System Settings in DJI Fly and select Control to customize the function of the button. Functions

include recentering the gimbal, switching the auxiliary LED, and toggling the map and live view.

Remote Controller Alert

The remote controller sounds an alert during RTH or when the battery level is low (6% to 15%). The low

battery alert level can be cancelled by pressing the power button. The critical battery level alert (less

than 5%), however, cannot be cancelled.

Optimal Transmission Zone

The signal between the aircraft and the remote controller is most reliable when the antennas are positioned in relation to the aircraft as depicted below.

Weak

Strong

DJI Fly

App

Optimal Transmission Zone

Linking the Remote Controller

The aircraft and remote controller must be linked before using. Follow these steps to link a new remote controller:

1. Power on the remote controller and the aircraft.

2. Launch DJI Fly.

3. In camera view, tap and select Control and Pair to Aircraft (Link).

4. Press and hold the power button of the aircraft for more than four seconds. The aircraft beeps once

indicating it is ready to link. The aircraft beeps twice indicating linking is successful. The battery level

LEDs of the remote controller will glow solid.

DJI Air 2S User Manual

Make sure the remote controller is within 0.5 m of the aircraft during linking.

The remote controller will automatically unlink from an aircraft if a new remote controller is linked to the same aircraft.

Fully charge the remote controller before each ight. The remote controller sounds an alert when the

battery level is low.

If the remote controller is powered on and not in use for ve minutes, an alert will sound. After 6 minutes, the aircraft automatically powers o. Move the control sticks or press any button to cancel

the alert.

Adjust the mobile device holder to ensure the mobile device is secure.

Fully charge the battery at least once every three months to maintain battery health.

DJI Fly App

This section introduces the main functions of the DJI Fly app.

DJI Fly App

Academy

GO FLY

Skypixel

Album

Home

Launch DJI Fly and enter the home screen.

Altitude Zone (120m)

Fly Spots

View or share nearby subtable ight and shooting locations, learn more about GEO zones, and preview aerial photos of dierent locations taken by other users.

Academy

Tap the icon in the top right corner to enter Academy. Product tutorials, ight tips, ight safety, and

manual documents can be viewed here.

Album

Allows you to view photos and videos from DJI Fly and mobile device. Create contains Templates and

Pro. Templates provides auto edit feature for imported footage. Pro allows you to edit the footage

manually.

SkyPixel

Enter SkyPixel to view videos and photos shared by users.

Prole

View the account information, ight records, DJI forum, online store, Find My Drone feature, and other

settings.

Camera View

RCRC

1:30:301:30:30

STORAGE

4K 60

FHD 120FHD 120

SIZESIZE

+1.0+1.0

EVEV

0m/s

50m

0m/s

30m

3m/sD3m/s

50m

30m

1 2 43 65 7

1. Flight Mode

: Displays the current ight mode.

2. System Status Bar

: Indicates aircraft ight status and displays various warning messages.

In Flight

3. Battery Information

: Displays the current battery level and remaining ight time. Tap to view more information about

24'26"

the battery.

4. Video Downlink Signal Strength

: Displays the video downlink strength between the aircraft and remote controller.

5. Forward and Backward Vision Systems Status

: The top of the icon indicates the status of the Forward Vision System and the bottom of the icon indicates the status of the Backward Vision System. The icon is white when the vision system is working normally and red when the vision system is unavailable.

6. GNSS Status

: Displays the current GNSS signal strength. Tap to check the GNSS signal status. The Home Point can

be updated when the icon is white, which indicates the GNSS signal is strong.

7. System Settings

: Tap to view information about safety, control, and transmission.

Safety

Flight Assistance: The icon appears in the camera view after setting Obstacle Avoidance to Bypass or Break.

The aircraft cannot sense obstacles if Obstacle Avoidance is disabled. The aircraft cannot y left or right if

Sideways Flight is disabled.

Flight Protection: Tap to set the max altitude, max distance, Auto RTH altitude, and to update the Home Point.

Sensors: Tap to view the IMU and compass status and start to calibrate if necessary. Users can also check

the auxiliary bottom light and unlock GEO zone settings.

Battery: Tap to view the battery information such as battery cell status, serial number, times charged, and production date.

Auxiliary LED: Tap to set the auxiliary LED to auto, on, or o.

Unlock GEO Zone: Tap to view the information about unlocking GEO zones.

In Flight

DJI Air 2S User Manual

23 26

14 1315

DJI Air 2S User Manual

The Find My Drone feature helps to nd the location of the aircraft on the ground.

Advanced Safety Settings include the behavior settings of the aircraft when the remote controller signal is

lost, when the propellers can be stopped during ight, and the AirSense switch.

The behavior of the aircraft when the remote controller signal is lost can be set to Return to Home, Descend, and Hover.

“Emergency Only” indicates that the motors can only be stopped mid-ight in an emergency situation such

as if there is a collision, a motor has stalled, the aircraft is rolling in the air, or the aircraft is out of control

and is ascending or descending very quickly. “Anytime” indicates that the motors can be stopped mid-ight anytime once user performs a combination stick command (CSC). Stopping the motors in mid-ight will

cause the aircraft to crash.

An alert will appear in DJI Fly when a manned aircraft is detected if AirSense is enabled. AirSense cannot be used while in ActiveTrack or recording at 4K 30p. Read the disclaimer in the DJI Fly prompt before using AirSense.

Control

Aircraft Settings: Units Settings.

Gimbal Settings: Tap to set the gimbal mode, advanced settings, allow gimbal rotation, and perform gimbal

calibration.

Remote Controller Settings: Tap to set the function of the customizable button, to calibrate the remote controller, to enable phone charging for the iOS device connected, and to switch stick modes. Make sure to understand the operations of a stick mode before changing stick mode.

Beginner Flight Tutorial: View the ight tutorial.

Connect to Aircraft: Tap to start linking when the aircraft is not linked to the remote controller.

Camera

Camera Parameter Settings: Displays dierent settings according to the shooting mode.

Shooting Modes Settings

Photo Photo Format, Size, and Anti-Flicker

Video Video Format, Coding Format, Anti-Flicker, and Video Subtitles

MasterShots Video Format, Coding Format, Shooting Priority, Anti-Flicker, and Video Subtitles

QuickShots Video Format, Coding Format, Color, Anti-Flicker, and Video Subtitles

Hyperlapse Video Format, Photo Type, Anti-Flicker, and Shot Frame

Pano Photo Type and Anti-Flicker

General Settings: Tap to view and set histogram, overexposure warning, gridlines, peaking level, white balance, auto sync HD photos, and cache when recording.

Storage Location: Footage can be stored in the aircraft or on a microSD card. Internal storage and microSD cards can be formatted. The max video cache capacity settings and camera reset settings can also be adjusted.

Transmission

Denition, frequency, and channel mode settings.

About

View device information, rmware information, app version, battery version, and more.

8. Shooting Modes

Photo: Single, SmartPhoto, AEB, Burst, and Timed Shot. SmartPhoto integrates scene recognition,

Hyperlight, and HDR into one mode for optimal results. Hyperlight optimizes photos taken at night or in

low-light situations while scene recognition optimizes dierent camera parameters for scenes that feature

DJI Air 2S User Manual

sunsets, blue skies, grass, snow, and green trees. HDR uses an adaptive dynamic expansion algorithm that determines optimal parameters to select the best image from multiple layers.

Video: Normal (5.4K 24/25/30fps, 4K 24/25/30/48/50/60fps, 2.7K 24/25/30/48/50/60fps, 1080p

24/25/30/48/50/60/120fps), Slow Motion (1080p 120 fps).

MasterShots: Select a subject. The aircraft will record while executing dierent maneuvers in sequence and

keeping the subject in the center of the frame. A short cinematic video will be generated afterward.

QuickShots: Choose from Dronie, Circle, Helix, Rocket, Boomerang, and Asteroid.

Hyperlapse: Choose from Free, Circle, Course Lock, and Waypoints.

Pano: Choose from Sphere, 180°, Wide Angle, and Vertical. The aircraft automatically takes several photos

according to the selected type of Pano and generates a panoramic shot.

9. Zoom/Focus Button

: Zoom can be used in video mode. The icon shows the zoom ratio. Press or hold the icon to adjust the

zoom ratio.

AF/ MF

: Press or hold the focus icon to switch the focus mode.

10. Shutter/Record Button

: Tap to take a photo or to start or stop recording a video.

11. Playback

: Tap to enter playback and preview photos and videos as soon as they are captured.

12. Camera Modes Switch

: Choose between Auto and Pro mode when in photo mode. Different parameters can be set in

dierent modes.

13. microSD Card Information

: Displays the remaining number of photos or video recording time of the current microSD card.

Tap to view the available capacity of the microSD card.

14. Flight Telemetry

D 50m H 30m 3m/s 3m/s

: Displays the distance between the aircraft and the Home Point, height from

the Home Point, aircraft horizontal speed, and aircraft vertical speed.

15. Attitude Indicator

Displays information such as the orientation and tilt angle of the aircraft, position of the remote controller,

and position of the Home Point.

Aircraft orientation

Remote controller position

Home Point

Collapse

Aircraft tilt angle

Switch to minimap

16. Auto Takeo/Landing/RTH

: Tap the icon. When the prompt appears, press and hold the button to initiate auto takeo or

landing.

: Tap to initiate Smart RTH and have the aircraft return to the last recorded Home Point.

17. APAS Status

: Displays the current APAS status.

18. Back

: Tap to return to the home screen.

Switch to Attitude Indicator

DJI Air 2S User Manual

Drag a box around a subject in the camera view to enable FocusTrack. Press and hold on the screen to bring

up the gimbal adjustment bar to adjust the gimbal angle.

Tap on the screen to enable focus or spot metering. Focus or spot metering will display dierently depending

on the focus mode, exposure mode, and spot metering mode. After using spot metering, press and hold on the screen to lock the exposure. To unlock the exposure, press and hold on the screen again

Make sure to fully charge your mobile device before launching DJI Fly.

Mobile cellular data is required when using DJI Fly. Contact your wireless carrier for data

charges.

If you are using a mobile phone as your display device, DO NOT accept phone calls or use

texting features during ight.

Read all safety tips, warning messages, and disclaimers carefully. Familiarize yourself with the related regulations in your area. You are solely responsible for being aware of all relevant

regulations and ying in a way that is compliant.

a. Read and understand the warning messages before using the auto-take o and auto-landing.

b. Read and understand the warning messages and disclaimer before setting the altitude beyond the

default limit.

c. Read and understand the warning messages and disclaimer before switching between ight

modes.

d. Read and understand the warning messages and disclaimer prompts near or in GEO zones.

e. Read and understand the warning messages before using the Intelligent Flight modes.

Land the aircraft immediately in a safe location if prompted to do so in the app.

Review all warning messages on the checklist displayed in the app before each ight.

Use the in-app tutorial to practice your ight skills if you have never operated the aircraft or if you do not have sufﬁcient experience to operate the aircraft with conﬁdence.

Cache the map data of the area where you intend to y the aircraft by connecting to the internet before each ight.

The app is designed to assist your operation. Use your sound discretion and DO NOT rely on

the app to control your aircraft. Your use of the app is subject to DJI Fly Terms of Use and DJI

Flight

This section describes safe ight practices and ight restrictions.

Flight

Once pre-ight preparation is complete, it is recommended to hone your ight skills and practice ying safely. Make sure that all ights are carried out in an open area. Refer to the Remote Controller and DJI

Fly sections for information about using the remote controller and the app to control the aircraft.

Flight Environment Requirements

1. Do not use the aircraft in severe weather conditions including wind speeds exceeding 10.7 m/s,

snow, rain, and fog.

2. Only y in open areas. Fly in open areas. Tall structures and large metal structures may aect the

accuracy of the onboard compass and GNSS system. It is recommended to keep the aircraft at least 5 m away from structures.

3. Avoid obstacles, crowds, high voltage power lines, trees, and bodies of water. It is recommended to keep the aircraft at least 3 m above water.

4. Minimize interference by avoiding areas with high levels of electromagnetism such as locations near power lines, base stations, electrical substations, and broadcasting towers.

5. Aircraft and battery performance is subject to environmental factors such as air density and

temperature. Be careful when ying 10,464 ft (5,000 m) or more above sea level, since battery and

aircraft performance may be reduced.

6. Aircraft cannot use GNSS within the polar regions. Use the Downward Vision System when ying in

such locations.

7. If taking o from a moving surface, such as a moving boat or vehicle, y with caution.

Flight Limits and GEO Zones

Unmanned aerial vehicle (UAV) operators should abide by the regulations from self-regulatory organizations such as the International Civil Aviation Organization, the Federal Aviation Administration, and local aviation authorities. For safety reasons, flight limits are enabled by default to help users

operate this aircraft safely and legally. Users can set ight limits on height and distance.

Altitude limits, distance limits, and GEO zones function concurrently to manage ight safety when GNSS

is available. Only altitude can be limited when GNSS is unavailable.

Flight Altitude and Distance Limits

The ight altitude and distance limits can be changed in DJI Fly. Based on these settings, the aircraft will y in a restricted cylinder, as shown below:

Max Flight Altitude

Height of aircraft

when takeo

Max Radius

Home Point

DJI Air 2S User Manual

When GNSS is available

Flight Limits DJI Fly App

Max Altitude Aircraft's altitude cannot exceed the specied value Warning: Height limit reached

Max Radius Flight distance must be within the max radius Warning: Distance limit reached

Only Downward Vision System is available

Flight Limits DJI Fly App

Height is restricted to 30 m when the GNSS signal is weak.

Max Altitude

Max Radius

Height is restricted to 5 m when the GNSS signal is weak

and light conditions is not sucient.

The restrictions on the radius are disabled and warning prompts cannot be received in the app.

The altitude limit when the GNSS is weak will not be restricted if there was a strong GPS signal when the aircraft was powered on.

If the aircraft reaches a limit, you can still control the aircraft, but you cannot y it any further. If the aircraft ies out of the max radius, it will automatically y back within range when the GNSS

signal is strong.

For safety reasons, do not y close to airports, highways, railway stations, railway lines, city

centers, or other sensitive areas. Fly the aircraft only within your line of sight.

Warning: Height limit reached.

GEO Zones

All GEO zones are listed on the DJI ocial website at http://www.dji.com/ysafe. GEO zones are divided

into different categories and include locations such as airports, flying fields where manned aircraft operate at low altitudes, borders between countries, and sensitive locations such as power plants.

There will be prompts in the DJI Fly app to y in GEO zones.

Pre-Flight Checklist

1. Make sure the remote controller, mobile device, and Intelligent Flight Battery are fully charged.

2. Make sure the Intelligent Flight Battery and the propellers are mounted securely.

3. Make sure the aircraft arms are unfolded.

4. Make sure the gimbal and camera are functioning normally.

5. Make sure that there is nothing obstructing the motors and that they are functioning normally.

6. Make sure that DJI Fly is successfully connected to the aircraft.

7. Make sure that the camera lens and Vision System sensors are clean.

8. Use only genuine DJI parts or parts certified by DJI. Unauthorized parts or parts from non-DJI

certied manufacturers may cause system malfunctions and compromise safety.

DJI Air 2S User Manual

Auto Takeoff/Landing

Auto Takeo

Use auto takeo when the aircraft status indicator blinks green.

1. Launch DJI Fly and enter the camera view.

2. Complete all steps in the pre-ight checklist.

3. Tap . If conditions are safe for takeo, press and hold the button to conrm.

4. The aircraft will take o and hover 1.2 m above the ground.

Auto Landing

Use auto landing:

1. Tap . If conditions are safe to land, press and hold the button to conrm.

2. Auto landing can be cancelled by tapping .

3. If the Vision System is working normally, Landing Protection will be enabled.

4. Motors stops after landing.

Starting/Stopping the Motors

Starting the Motors

A Combination Stick Command (CSC) is used to start the motors. Push both sticks to the bottom

inner or outer corners to start the motors. Once the motors have started spinning, release both sticks simultaneously.

Stopping the Motors

There are two methods to stop the motors.

1. Method 1: When the aircraft has landed, push and hold the left stick down. The motors will stop after

three seconds.

2. Method 2: When the aircraft has landed, push the left stick down and perform the same CSC that

was used to start the motors. The motors will stop immediately. Release both sticks once the motors have stopped.

Method 1 Method 2

DJI Air 2S User Manual

Stopping the Motors Mid-Flight

Stopping motors mid-ight will cause the aircraft to crash. The motors should only be stopped midight in an emergency situation such as if a collision has occurred or if the aircraft is out of control and is ascending or descending very quickly, rolling in the air, or if a motor has stalled. To stop the motors mid-ight use the same CSC that was used to start the motors. The default setting can be changed in

DJI Fly.

Flight Test

Takeo/Landing Procedures

1. Place the aircraft in an open, at area with the aircraft status indicator facing towards you.

2. Turn on the aircraft and the remote controller.

3. Launch DJI Fly and enter the camera view.

4. Wait until the aircraft status indicators blink green indicating that the Home Point has been recorded and it is now safe to y.

5. Gently push the throttle stick to take o or use auto-takeo.

6. Pull the throttle stick or use auto-landing to land the aircraft.

7. After landing, push the throttle stick down and hold. The motors stop after three seconds.

8. Turn o the aircraft and remote controller.

Video Suggestions and Tips

1. The pre-ight checklist is designed to help you y safely and to ensure that you can shoot video during ight. Go through the full pre-ight checklist before each ight.

2. Select the desired gimbal operation mode in DJI Fly.

3. Use Normal or Cine mode to record video.

4. DO NOT y in bad weather conditions such as when it is raining or windy.

5. Choose the camera settings that best suit your needs.

6. Perform ight tests to establish ight routes and to preview scenes.

Make sure to place the aircraft on a at and steady surface before takeo. DO NOT takeo from your

palm or while holding the aircraft with your hand.

It is important to understand the basic ight guidelines for the safety of both you

and those around you.

DO NOT forget to read the disclaimer and safety guidelines.

Appendix

Specifications

Aircraft

Takeo Weight

Dimensions (L×W×H) Folded: 180×97×77 mm

Diagonal Distance

Max Ascent Speed 6 m/s (S Mode)

Max Descent Speed 6 m/s (S Mode)

Max Speed (near sea level, no wind)

Max Service Ceiling Above Sea Level

Max Flight Time

Max Hover Time (without wind)

Max Flight Distance

Max Wind Speed Resistance

Max Tilt Angle 35° (S Mode)

Max Angular Velocity 250°/s (S Mode)

Operating Temperature 32° to 104° F (0° to 40° C)

GNSS GPS+GLONASS

Operating Frequency 2.400-2.4835 GHz, 5.725-5.850 GHz

Transmitter Power (EIRP) 2.400-2.4835 GHz:

Hovering Accuracy Range Vertical: ±0.1 m (with Vision Positioning), ±0.5 m (with GNSS

Internal Storage 8 GB

Gimbal

Mechanical Range Tilt: -135° to +45°

Controllable Range Tilt: -90° to 0° (default setting), -90° to +24° (extended setting)

Stabilization 3-axis (tilt, roll, pan)

Max Control Speed (tilt) 100°/s

Angular Vibration Range ±0.01°

595 g

Unfolded: 183×253×77 mm

302 mm

6 m/s (N Mode)

19 m/s (S Mode)

15 m/s (N Mode) 5 m/s (C Mode)

5,000 m

31 mins (measured while ying at 19.4 kph in windless conditions)

30 mins

18.5 km

10.7 m/s (Scale 5)

Front: 30°, Back: 20°, Left: 35°, Right: 35° (N Mode)

90°/s (N Mode)

60°/s (C Mode)

30 dBm (FCC), < 20 dBm (CE/SRRC/MIC)

5.725-5.850 GHz:

30 dBm (FCC), < 14 dBm (CE), < 29 dBm (SRRC)

Positioning)

Horizontal: ±0.1 m (with Vision Positioning), ±1.5 m (with GNSS Positioning)

Roll: -45° to +45° Pan: -100° to +100°

DJI Air 2S User Manual

Sensing System

Forward Precision Measurement Range: 0.38-23.8 m

Backward Precision Measurement Range: 0.37-23.4 m

Upward Precision Measurement Range: 0.34-28.6 m

Downward Infrared Sensor Measurement Range: 0.1-8 m

Operating Environment Non-reflective, discernible surfaces with diffuse reflectivity of >20%;

Camera

Sensor 1-inch CMOS

Lens FOV: 88°

ISO Video:

Electronic Shutter Speed 1/8000-8 s

Max Image Size 20MP (5472×3648, 3:2; 5472×3078, 16:9)

Still Photography Modes Single: 20MP

Video Resolution 5.4K: 5472×3078 24/25/30fps

Max Video Bitrate 150 Mbps

Supported File System FAT32

Photo Format JPEG/DNG (RAW)

Video Format MP4/MOV (H.264/MPEG-4 AVC, H.265/HEVC)

Eective Sensing Speed: ≤15 m/s FOV: 72° (horizontal), 58° (vertical)

Eective Sensing Speed: ≤12 m/s FOV: 57° (horizontal), 44° (vertical)

Eective Sensing Speed: ≤12 m/s FOV: 63° (horizontal), 78° (vertical)

Hovering Range: 0.5-30 m Vision Sensor Hovering Range: 0.5-60 m

Adequate lighting of lux >15

Eective Pixels: 20MP

35 mm Format Equivalent: 22 mm

Aperture: f/2.8

Shooting Range: 0.6 m to ∞

100-3200 (Auto), 100-6400 (Manual) Video-10bit: 100-800 (Auto), 100-1600 (Manual)

Photo:

100-3200 (Auto), 100-12800 (Manual)

Burst: 20MP Automatic Exposure Bracketing (AEB): 20MP, 3/5 Frames at 0.7EV

Step

Timed: 20MP 2/3/5/7/10/15/20/30/60 seconds SmartPhoto: 20MP HDR Panorama:

Vertical (3×1): approx. 3328×8000 pixels (W×H) Wide (3×3): approx. 8000×6144 pixels (W×H)

180° Panorama (3×7): approx. 8192×3500 pixels (W×H) Sphere (3×8+1): approx. 8192×4096 pixels (W×H)

4K Ultra HD: 3840×2160 24/25/30/48/50/60fps

2.7K: 2688×1512 24/25/30/48/50/60fps FHD: 1920×1080 24/25/30/48/50/60/120fps

exFAT (recommend)

DJI Air 2S User Manual

Digital Zoom 4K 24/25/30fps – 4x

Remote Controller

Operating Frequency 2.400-2.4835 GHz, 5.725-5.850 GHz

Remote Controller Transmission System

Max Transmission Distance (unobstructed, free of interference)

Operating Temperature 32° to 104° F (0° to 40° C)

Transmitter Power (EIRP) 2.400-2.4835 GHz:

Battery Capacity 5200 mAh

Operating Current/Voltage 1200 mA@3.6 V (with Android device)

Max Supported Mobile Device Size (H×W×T)

Supported USB Port Types Lightning, Micro USB (Type-B), USB-C

Video Transmission System

Video Transmission System O3

Live View Quality 1080p@30fps

Max Transmission Distance (unobstructed, free of interference)

Video Coding Format H.265/H.264

Max Bitrate 16 Mbps

Latency (depending on environmental conditions and mobile device)

Charger

Input 100-240V, 50/60 Hz, 1.3 A

Output Battery: 13.2 V 2.82 A

Rated Power 38 W

Intelligent Flight Battery

Battery Capacity 3500 mAh

Voltage 11.55 V

Max Charging Voltage 13.2 V

Battery Type LiPo 3S

Energy 40.42 Wh

Weight 198 g

2.7K 24/25/30fps – 6x

1080p 24/25/30fps – 8x

2.7K 48/50/60fps – 4x

1080p 48/50/60fps – 6x Note: Digital zoom is not available when recording in D-log, HLG, or slow motion at 120fps.

OcuSync 2.0

12 km (FCC)

8 km (CE/SRRC/MIC)

26 dBm (FCC), < 20 dBm (CE/SRRC/MIC)

5.725-5.850 GHz:

26 dBm (FCC/SRRC), < 14 dBm (CE)

700 mA@3.6 V (with iOS device)

180×86×10 mm

12 km (FCC)

8 km (CE/SRRC/MIC)

120-130 ms

USB: 5V/2A

DJI Air 2S User Manual

Charging Temperature 41° to 104° F (5° to 40° C)

Max Charging Power 38 W

App

App DJI Fly

Required Operating System iOS v11.0 or later; Android v6.0 or later

SD Cards

Supported SD Cards UHS-I Speed Grade 3 rating microSD card

Recommended microSD Cards SanDisk Extreme PRO 64GB V30 A2 microSDXC

SanDisk High Endurance 64GB V30 microSDXC SanDisk Extreme 64GB V30 A2 microSDXC SanDisk Extreme 128GB V30 A2 microSDXC SanDisk Extreme 256GB V30 A2 microSDXC Lexar Lexar 667x 64GB V30 A2 microSDXC Lexar High-Endurance 64GB V30 microSDXC Samsung EVO 64GB microSDXC Samsung EVO Plus 64GB microSDXC Samsung EVO Plus 256GB microSDXC Kingston 128GB V30 microSDXC Netac 256GB A1 microSDXC

Firmware Update

Use DJI Fly or DJI Assistant 2 (Consumer Drones Series) to update the aircraft rmware.

Using DJI Fly

When you connect the aircraft or remote controller to DJI Fly, you will be notified if a new firmware update is available. To start updating, connect your mobile device to the internet and follow the on-

screen instructions. Note that you cannot update the rmware if the remote controller is not linked to the aircraft. Internet is required.

Using DJI Assistant 2 (Consumer Drones Series)

Update the aircraft and remote controller rmware separately using DJI Assistant 2 (Consumer Drones Series). Follow the instructions below to update the aircraft rmware through DJI Assistant 2 (Consumer

Drones Series):

1. Launch DJI Assistant 2 (Consumer Drones Series) and log in with your DJI account.

2. Power on the aircraft and connect the aircraft to a computer via the USB-C port.

3. Select DJI Air 2S and click on Firmware Updates on the left panel.

4. Select the rmware version that you wish to update to.

DJI Air 2S User Manual

5. Wait for the rmware to download. The rmware update will start automatically.

6. The aircraft will reboot automatically after the rmware update is complete.

Follow the instructions below to update the remote controller ﬁrmware through DJI Assistant 2

(Consumer Drones Series):

1. Launch DJI Assistant 2 (Consumer Drones Series) and log in with your DJI account.

2. Power on the remote controller and connect to a computer via the USB-C port using a Micro USB

cable.

3. Select DJI Air 2S Remote Controller and click on Firmware Updates on the left panel.

4. Select the rmware version that you wish to update to.

5. Wait for the rmware to download. The rmware update will start automatically.

6. Wait for the rmware update to be completed.

Make sure follow all the steps to update rmware. Otherwise, the update may fail.

The firmware update will take approximately 10 minutes. It is normal that the gimbal goes limp,

aircraft status indicators blink, and the aircraft reboots. Wait patiently until the update is complete.

Make sure the computer has access to the internet.

Before performing an update, make sure the Intelligent Flight Battery is at least 40% charged and the

remote controller is at least 30% charged.

Do not disconnect the aircraft from the computer during an update.

After-Sales Information

Visit https://www.dji.com/support to learn more about after-sales service policies, repair services, and support.

DJI Support

http://www.dji.com/support

This content is subject to change.

Download the latest version from http://www.dji.com/air-2s

If you have any questions about this document, please contact

DJI by sending a message to DocSupport@dji.com.

DJI is a trademark of DJI.

DJI DJI AIR 2S FM User guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Using this Manual

Legend

Read Before the First Flight

Video Tutorials

Download the DJI Fly App

Download DJI Assistant 2 (Consumer Drones Series)

Introduction

Preparing the Aircraft

Preparing the Remote Controller

Aircraft Diagram

Remote Controller Diagram

Activating DJI Air 2S

Aircraft

Flight Modes

Aircraft Status Indicators

Return to Home

Vision Systems and Infrared Sensing System

Intelligent Flight Mode

Advanced Pilot Assistance Systems 4.0

Flight Recorder

Propellers

Intelligent Flight Battery

Gimbal and Camera

Remote Controller

Remote Controller Profile

Using the Remote Controller

Linking the Remote Controller

DJI Fly App

Home

Camera View

Flight

Flight Environment Requirements

Flight Limits and GEO Zones

Pre-Flight Checklist

Auto Takeoff/Landing

Starting/Stopping the Motors

Flight Test

Appendix

Specifications

Firmware Update

After-Sales Information
