DJI CP.AC.000021 User manual

2.4G Bluetooth Datalink & iPad
The Air
end
The
Ground end
Flight control
system
PC Ground
Station
iPad Ground
Station
CAN-Bus
USB
Bluetooth
Bluetooth
Signals from
Ground Station
Signals from Flight
control system
BTU module
CAN-Bus
Flight control systems that support the 2.4G Bluetooth Datalink
ACE ONE(Firmware V4.02 or above), WKM(Firmware V5.24 or above), NAZA-M, NAZA-M V2(Firmware V4.00 or above), A2(Firmware V2.0 or above)
Important: To make your Phantom 2 compatible with the 2.4G Bluetooth Datalink, please update the firmware of Phantom 2 and BTU module to the latest version.
BTU
Module
USB
cable
CAN-Bus
cable
DC power
cable
Ground Station Installer CD for
PC
The Ground end of
2.4G Bluetooth Datalink
The Ground end of
2.4G Bluetooth Datalink
The Air end of

2.4G Bluetooth Datalink

Ground Station User Guide V1.10
Thank you for purchasing DJI products. Please strictly follow this user guide to mount and connect the 2.4G Bluetooth Datalink, install the Assistant Software on your computer, as well as the App on your mobile device.
NoteThe map of Mainland China download from Mainland China IP addresses has differences with the actual geographic environments. If users download the map of Mainland China from foreign IP addresses, which will be
more accurate.
2.4G Bluetooth Datalink
The 2.4G Bluetooth Datalink consists of the Air end and the Ground end, which provides reliable and stable remote wireless transmissions for Ground Station based applications. The signal flow is as shown below.

1.1 In the box

Importantthe firmware of BTU should be upgraded to version 1.0.1.2 or above to use with the 2.4G Bluetooth Datalink.

1.2 User supplied

To use the 2.4G Bluetooth Datalink and Ground Station, please prepare the Flight control system, the aircraft, batteries, PC or iPad etc.
©2013-2014 DJI Innovations. All Rights Reserved. - 1 -

1.3 Connections and use

Antenna
The tail of the Antenna should be pointed downward and unobstructed to ensure the communication distance.
· PC Ground Station
· 2.4G Bluetooth Datalink
Assistant Software
· As si st an t Soft ware o f Flight control system
USB port
Connect to a PC via a USB cable to use the PC Ground Station or configure the 2.4G Bluetooth Datalink in the Assistant Software.
CAN-Bus port
Connect the BTU module when using the iPAD Ground Station
DC power port
Connect DC power, you can choose one of the USB power supply or DC power supply to provide power for the Ground end.
The Ground end
Distance between the
two ends should be
more than 1.5m
Co mm un ic at io n& power supply port
Ex tra pow er supply port
· 3S-6S Battery
· 9.9V~25.2V
DC power
-
+
· iPad Ground Station
· Assistant of Flight control system
+
-
90
o
To Flight control system
To any CAN-Bus port on ACE ONE, WKM , NAZA-MNAZA-M V2
Or to the CAN2 port(or the CAN-Bus port on the devices connected to the CAN2 port) on A2
The Air end
Antenna
The tail of the Antenna should be pointed upwards and unobstructed to ensure the communication distance.
Notes (1) You can configure the Flight control system using the Assistant software on a PC or iOS mobile Device
wirelessly over the link of the 2.4G Bluetooth Datalink, however you cannot upgrade the firmware of the Flight control system using this communication route.
(2) When connecting a BTU module or a LED Bluetooth unit to the Flight control system to configure in
the Assistant on mobile devices, as well as connecting a BTU module to the Ground end to use the iPad Ground station, the two Bluetooth communication links will not interfere with each other.
(3) If the Air end is changed to connect to a new Main controller, you should power cycle the Ground end. (4) Make sure the LED indicator of BTU module is green after power on, for specific usage details please
refer to the BTU Manual.
(5) For usage of the PC Ground Station please refer to the latest Ground Station User Manual.
Important : (1) If there are obstacles between the ground and air ends then the radio signal of the 2.4G Bluetooth
Datalink will be weak; please make sure the antennas are always visibly unobstructed during the flight. Human body, trees, buildings or hills will disconnect the link between the Air end and the Ground end.
(2) Make sure the antenna of the Air end is pointing down, and the antenna of the Ground end is pointing
upwards; its better to put the Ground end at a high place to get further transmission distance.
(3) When using the ACE ONE Flight control system with the 2.4G Bluetooth Datalink, the Ground Station
will connect to the Main controller 15s after power on.
(1) Please assemble the antenna of the Ground end first. (2) For connections and use please refer to the diagram below.
©2013-2014 DJI Innovations. All Rights Reserved. - 2 -

1.4 LED Indicator descriptions

LED
TX/RX
LINK
The Air
end
LINK
TX/RX
Green blinks
Sending
Solid Green
The Air end links with the
Ground end successfully
Red blinks
Receiving
Solid Red
The Air end delinks with the
Ground end
Yellow blinks
Searching the
Main controller
The
Ground
end
TX/RX
LINK
Green blinks
Sending
Solid Green
The Air end links with the
Ground end successfully
Red blinks
Receiving
Solid Red
The Air end delinks with the
Ground end
Yellow blinks
Power voltage of
the Ground end
is less than 9.9V
Notes :
(1) LED Indicators on both ends will blink when powering on, then the TX/RX indicator of the Air end will
blink when searching the Main controller.
(2) The LED Indicators of LINK on both ends should be solid green to indicate that the two ends have linked
successfully.
(3) It’s recommended to check the power voltage of the Ground end regularly when using batteries for
power supply, in order to avoid over-discharging.
· 2.4G Bluetooth Datalink Assistant software
To upgrade the Air end
and the Ground end
To upgrade the Ground
end and BTU module
· 2.4G Bluetooth Datalink Assistant software
Important : POWER CYCLE the Flight control system and 2.4G Bluetooth Datalink after upgrade.
The LED Indicators of the 2.4G Bluetooth Datalink will work after power on, the descriptions are shown below.

1.5 Upgrade

Use the 2.4G Bluetooth Datalink Assistant software to upgrade the 2.4G Bluetooth Datalink and BTU module. Please refer to the diagram below to connect when upgrading.
©2013-2014 DJI Innovations. All Rights Reserved. - 3 -
