Directed Video RVM560 User Manual

LCD Video Monitor

MODEL RVM560, RVM680, RVM700

OWNER’S GUIDE

INSTALLATION GUIDE

Table of Contents

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

When Cleaning the Vehicle ...........................................................................................................5

While Driving.............................................................................................................................5

When Parked..............................................................................................................................5

Proper Use ...............................................................................................................................6

Repairs ....................................................................................................................................6

Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

FCC Notice ................................................................................................................................6

Your Warranty ...........................................................................................................................6

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Features....................................................................................................................................6

Accessories................................................................................................................................6

Basic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Monitor Description ...................................................................................................................7

Maintenance ............................................................................................................................7

On-Screen Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Making Changes to System Settings .............................................................................................8

Setup Menu Descriptions and Operation ........................................................................................9

System Settings Menu ................................................................................................................10

Hardware Options Menu ..............................................................................................................11

Assign Source Names Menu .........................................................................................................12

Assign Trigger Names Menu .........................................................................................................12

Source Names ...........................................................................................................................13

Trigger Names ...........................................................................................................................13

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Monitor Specifications ................................................................................................................14

Installing the Monitor ................................................................................................................14

Removing the Monitor ................................................................................................................14

For a period of THREE YEARS from the date of purchase,

Directed Electronics, Inc. ("DIRECTED") promises to the

original purchaser to repair or replace, free of cost, with a

comparable reconditioned model any VIDEO MONITOR

(hereafter the "UNIT"), which proves to be defective in

workmanship or material defect under normal and reason-

able use during the first 3 years after the purchase and

installation of the unit provided the following conditions

are met: the unit was purchased and installed by an author-

ized DIRECTED dealer; the unit remains in the vehicle in

which the unit was originally installed; and the unit is

returned to DIRECTED. The unit in question must be

returned to DIRECTED postage paid and must be accompa-

nied by a clear, legible copy of the bill of sale bearing the

following information:

■

Date of Purchase

■

Your Full name and address

■

Authorized dealer's company name and address

■

Type of unit installed

■

Year, make and model of the automobile

■

Automobile license number

■

Vehicle Identification number

■

Installation receipts

All components and accessories other that the unit, includ-

ing without limitation the remote control, cables and

installation accessories carry a 60-day warranty from the

date of purchase of the same.

This warranty is automatically void if the unit is bought

from anyone other than an authorized dealer, the unit's

date code or serial number is defaced, missing or altered;

the unit has been modified or used in a manner contrary to

its intended purpose; or the unit has been damaged by

accident, unreasonable use, neglect, improper service,

installation or other causes not arising out of defects in

workmanship, materials or construction. This warranty is

nontransferable and does not cover batteries. This warran-

ty does not co

ver labor costs for the removal, diagnosis,

troubleshooting or reinstallation of the unit. For service on

an out-of-warranty product a flat fate fee by model is

charged. Contact your authorized dealer to obtain the serv-

ice charge for your unit.

TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WAR-

RANTIES, INCLUDING BUT NOT LIMITED TO EXPRESS WAR-

RANTY, IMPLIED WARRANTY, WARRANTY OF MER-

CHANTABILITY, FITNESS FOR PARTICULAR PURPOSE AND

WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL

PROPERTY, ARE EXPRESSLY EXCLUDED; AND DIRECTED

NEITHER ASSUMES NOR AUTHORIZES ANY PERSON OR

ENTITY TO ASSUME FOR IT ANY DUTY, OBLIGATION OR

LIABILITY IN CONNECTION WITH ITS PRODUCTS. DIRECT-

ED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR

ANY AND ALL ACTS OF THIRD PARTIES INCLUDING DEAL-

ERS OR INSTALLERS. IN THE EVENT OF A CLAIM OR A DIS-

PUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE

PROPER VENUE SHALL BE SAN DIEGO COUNTY IN THE

STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND

APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN

THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY

CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED

TO THE AUTHORIZED DIRECTED DEALER'S PURCHASE

PRICE OF THE UNIT. DIRECTED SHALL NOT BE RESPONSI-

BLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT

NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES, INCI-

DENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME,

LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECO-

NOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING

THE ABOVE, THE MANUFACTURER DOES OFFER A LIMITED

WARRANTY TO REPLACE OR REPAIR THE CONTROL MOD-

ULE AS DESCRIBED ABOVE. Some states do not allow lim-

itations on how long an implied warranty will last or the

exclusion or limitation of incidental or consequential dam-

ages. This warranty gives you specific legal rights and you

may also have other rights that vary from State to State.

DIRECTED does not and has not authorized any person or

entity to create for it any other obligation, promise, duty

or obligation in connection with this UNIT.

Limited Three-Year Warranty

Important Safeguards

■

Only operate the monitor as described in this guide. Attempts to use or modify this monitor contrary to the descriptions in this guide may cause damage and void the warranty.

■

Extremes in temperature can cause abnormal display operation. This monitor has an optimal operating temperature range between 35-115 degrees Fahrenheit. If the vehicle interior is outside this range, do NOT operate the monitor until the temperature is within its operating range.

■

Exposure to moisture or dust can cause harmful damage to the internal electronics. Do not mount near cup holders or in areas where spills may occur.

■

This monitor is designed for use in vehicles with standard (-) 12 volt ground electrical systems.

■

Do not operate for an extended period of time without the engine running or the vehicle’s battery voltage may drop to damaging levels.

Safety Instructions

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS EQUIPMENT TO

RAIN OR MOISTURE. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK AND ANNOYING INTERFERENCE, USE ONLY THE INCLUDED HARDWARE.

THIS MONITOR IS ONLY DESIGNED FOR REAR SEAT PASSENGER VIEWING AND IS NOT INTENDED FOR VIEWING BY THE DRIVER WHILE THE VEHICLE IS IN MOTION. SUCH USE MAY DISTRACT THE DRIVER OR INTERFERE WITH THE SAFE OPERATION OF THE VEHICLE, AND MAY ALSO VIOLATE STATE LAW.

DIRECTED ELECTRONICS, INC. DISCLAIMS ANY LIABILITY FOR ANY BODILY INJURY, INCLUDING FATALITIES, OR PROPERTY DAMAGE THAT MAY RESULT FROM ANY IMPROPER OR UNINTENDED USES OF THIS PRODUCT.

WHEN CLEANING THE VEHICLE

Do not spray this unit with water or cleaning

solutions. Moisture and the chemicals found in

cleaning fluids could damage the consoles finish

and interior electronics.

WHILE DRIVING

This unit is intended for use in the rear seat area

only. It should not be installed in a location that

would allow the driver to view it while driving.

WHEN PARKED

The screen is easily removable. Always remove or

close the screen when parking for an extended

period of time to avoid potential theft or

extended exposure to direct sunlight.
