Page 1

OWNER’S GUIDE

INSTALLATION GUIDE

Drawer-Type DVD Player

MODEL DV1700

Page 2

Table of Contents

Limited One-Year Warranty. . . . . . . 3

Safety Instructions . . . . . . . . . . . . 4

Region Management Information ................4

Important Safeguards . . . . . . . . . . 4

When Driving...........................................4

When Car Washing....................................4

When Parked............................................4

Use the Proper Power Supply......................4

Protect the Disc Mechanism.......................5

Repairs ...................................................5

Placement ...............................................5

When Not in Use ......................................5

Avoid Water and Magnets ..........................5

Stacking..................................................5

Condensation...........................................5

Important Information. . . . . . . . . . 6

FCC Notice...............................................6

Your Warranty..........................................6

Features . . . . . . . . . . . . . . . . . . . . 6

Features..................................................6

Accessories..............................................6

Disc Notes . . . . . . . . . . . . . . . . . . 7

Disc Formats Supported by this Player.........7

Disc Formats Not Supported by this Player ...7

Handling and Cleaning..............................7

Front Panel Operation . . . . . . . . . . 8

Front Panel Features .................................8

Front Panel Controls..................................8

Display Panel Operation . . . . . . . . . 9

Display Panel Features...............................9

Remote Operation . . . . . . . . . . . . . 10

Prior to Use.............................................10

Remote Control Functions . . . . . . . 11

Basic Operation . . . . . . . . . . . . . . 12

Turning the Player On/Off .........................12

Play Disc ................................................12

Stop Disc ...............................................12

Remove Disc ...........................................12

Volume Control .......................................12

Pause/Resume Play .................................12

Skip Tracks/Chapters.................................12

Fast Forward/Fast Rewind..........................12

Repeat Play .............................................12

Timed Repeat Play....................................13

Audio Mode.............................................13

Mute Audio..............................................13

Zoom Play ...............................................13

On-Screen Display.....................................13

Advanced Operation. . . . . . . . . . . . 14

DVD Operation .........................................14

CD/VCD Operation.....................................15

MP3 Operation .........................................15

Setup Menu. . . . . . . . . . . . . . . . . . 16

Setup Menu Navigation .............................16

General Setup Page...................................17

Dolby Digital Setup...................................17

Password Setup Page.................................17

Preferences Page ......................................18

Screen Format..........................................19

Installation. . . . . . . . . . . . . . . . . . 20

Connecting to a Stereo TV .........................20

Remote Control ........................................20

Mounting the Unit....................................20

Wiring Connections...................................21

Troubleshooting. . . . . . . . . . . . . . . 22

Specifications . . . . . . . . . . . . . . . . 23

Page 3

Limited One-Year Warranty

For a period of ONE YEAR from the date of purchase, Directed Electronics, Inc. ("DIRECTED") promises to the original purchaser to repair or replace, free of cost, with a comparable reconditioned model any DVD PLAY- ER (hereafter the "UNIT”), which proves to be defective in workmanship or material defect under normal use, provided the following conditions are met: the unit was purchased and installed by an authorized DIRECTED dealer; the unit remains in the vehicle in which the unit was originally installed; and the unit is returned to DIRECTED. The unit in question must be returned to DIRECTED postage paid and must be accompanied by a clear, legible copy of the bill of sale bearing the following information:

■

Date of Purchase

■

Your Full name and address

■

Authorized dealer's company name and address

■

Type of unit installed

■

Year, make, model, and color of the automobile

■

Automobile license number

■

Vehicle Identification number

■

Installation receipts

All components other than the unit, including and

without limitation the remote control, cables and

installation accessories, carry a 60-day warranty from

the date of purchase of the same.

This warranty is automatically void if the unit's date

code or serial number is defaced, missing or altered;

the unit has been modified or used in a manner con-

trary to its intended purpose; or the unit has been

damaged by accident, unreasonable use, neglect,

improper service, installation or other causes not aris-

ing out of defects in materials or construction. This

warranty is nontransferable and does not apply to any

until that has been modified or used in a manner con-

trary to its intended purpose and does not cover bat-

teries. This warranty does not co

ver labor costs for

the removal, diagnosis, troubleshooting or reinstalla-

tion of the unit. For service on an out-of-warranty

product a flat fate fee by model is charged. Contact

your authorized dealer to obtain the service charge for

your unit.

TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL

WARRANTIES, INCLUDING BUT NOT LIMITED TO

EXPRESS WARRANTY, IMPLIED WARRANTY, WARRAN-

TY OF MERCHANTABILITY, FITNESS FOR PARTICULAR

PURPOSE AND WARRANTY OF NON-INFRINGEMENT OF

INTELLECTUAL PROPERTY, ARE EXPRESSLY EXCLUDED;

AND DIRECTED NEITHER ASSUMES NOR AUTHORIZES

ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY,

OBLIGATION OR LIABILITY IN CONNECTION WITH ITS

PRODUCTS. DIRECTED DISCLAIMS AND HAS

ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS

OF THIRD PARTIES INCLUDING DEALERS OR

INSTALLERS. IN THE EVENT OF A CLAIM OR A DIS-

PUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE

PROPER VENUE SHALL BE SAN DIEGO COUNTY IN THE

STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND

APPLICABLE FEDERAL LAWS SHALL APPLY AND GOV-

ERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER

ANY CLAIM AGAINST DIRECTED SHALL BE STRICTLY

LIMITED TO THE AUTHORIZED DIRECTED DEALER'S

PURCHASE PRICE OF THE UNIT. DIRECTED SHALL NOT

BE RESPONSIBLE FOR ANY DAMAGES WHATSOEVER,

INCLUDING BUT NOT LIMITED TO, ANY CONSEQUEN-

TIAL DAMAGES, INCIDENTAL DAMAGES, DAMAGES

FOR THE LOSS OF TIME, LOSS OF EARNINGS, COM-

MERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY

AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE

MANUFACTURER DOES OFFER A LIMITED WARRANTY

TO REPLACE OR REPAIR THE CONTROL MODULE AS

DESCRIBED ABOVE. Some states do not allow limita-

tions on how long an implied warranty will last or the

exclusion or limitation of incidental or consequential

damages. This warranty gives you specific legal rights

and you may also have other rights that vary from State

to State. DIRECTED does not and has not authorized

any person or entity to create for it any other obliga-

tion, promise, duty or obligation in connection with

these UNITS.

Page 4

Safety Instructions

CAUTION: MOBILE DVD PLAYER IS A CLASS I LASER PRODUCT. HOWEVER THIS MOBILE DVD PLAYER USES A VIS-

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR

This product incorporates copyright protection

technology that is protected by method claims

of certain U.S. patents and other intellectual

property rights owned by Macrovision

Corporation and other rights owners. Use of this

authorized by Macrovision Corporation, and is

intended for home and other limited viewing

uses only unless otherwise authorized by

Macrovision Corporation. Reverse engineering or

disassembly is prohibited.

IBLE/INVISIBLE LASER BEAM THAT COULD CAUSE HAZARDOUS RADIATION IF EXPOSED DIRECTLY. BE SURE TO OPERATE THE MOBILE DVD PLAYER AS INSTRUCTED. USE OF CONTROLS, ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.

MOISTURE. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK AND ANNOYING INTERFERENCE, USE ONLY THE RECOMMENDED ACCESSORIES.

REGION MANAGEMENT INFORMATION

This Mobile DVD Player is designed and manu-

factured to respond to the Region Management

Information that is recorded on a DVD disc. If

the Region number described on the DVD disc

does not correspond to the Region number of

this Mobile DVD Player, the disc will not play.

Important Safeguards

WHEN DRIVING

Keep the volume level low enough to be aware

of road and traffic conditions.

WHEN CAR WASHING

Do not expose the product to water or excessive

moisture. This could cause electrical shorts, fire,

or other damage.

WHEN PARKED

Parking in direct sunlight can produce very high

temperatures inside your vehicle. Give the interior

a chance to cool down before starting playback.

USE THE PROPER POWER SUPPLY

This product is designed to operate with a (+)

12 volt DC, negative ground battery system.

Page 5

PROTECT THE DISC MECHANISM

STACKING

Avoid inserting any foreign objects into the disc

tray of this player. Failure to observe this may

cause malfunction due to the precise mechanism

of this unit.

REPAIRS

Do not attempt to disassemble or adjust this

precision product. Please consult your author-

ized Directed dealer for service assistance.

PLACEMENT

Avoid placing the player in areas of:

■

Direct sunlight or heater vents.

■

Excessive dust.

■

Vibration, impact, or high foot traffic.

■

Surface tilt - the internal parts may be seriously damaged.

WHEN NOT IN USE

When not in use, set the player to standby mode.

When left unused for a long period of time, the

player should be turned off.

Place the player in a horizontal position, and do

not place anything heavy on it. Do not place the

player on amplifiers or other equipment which

may become hot.

CONDENSATION

Moisture may form on the lens in the following

conditions:

■

Immediately after a heater has been turned on.

■

In a steamy or very humid vehicle.

NOTE: If moisture forms inside this player, it may not

operate properly. In this case, turn the power on and wait about one hour for the moisture to evaporate.

AVOID WATER AND MAGNETS

Keep the player away from cup holders. If liquids

are spilled into the player, serious damage could

occur.

Keep magnetic objects, such as speakers, at a

distance from the player.

Page 6

Important Information

FCC NOTICE

This device complies with Part 15 of FCC rules.

Operation is subject to the following two condi-

tions: (1) This device may not cause harmful

interference, and (2) this device must accept

any interference received, including interfer-

ence that may cause undesired operation.

Changes or modifications not expressly

approved by the party responsible for compli-

ance could void the user's authority to operate

this device.

Features

FEATURES

■

Compatible with DVD, Super-VCD, VCD, CD and MP3 discs.

■

Compatible with PAL DVD (Video CD) and NTSC DVD (Video CD).

■

L/R stereo analog audio outputs (RCA) for connection to existing head unit aux inputs or audio amplifiers.

■

Audio/digital to analog converter.

■

Accepts double-layered discs.

■

10 bit video D/A converter reproduces images faithfully.

YOUR WARRANTY

Your warranty registration must be completely

filled out and returned within 10 days of pur-

chase. Your product warranty will not be vali-

dated if your warranty registration is not

returned. Make sure you receive the warranty

registration from your dealer. It is also neces-

sary to keep your proof of purchase, which

reflects that the product was installed by an au-

thorized dealer.

ACCESSORIES

■

Remote Control

■

Two AAA batteries

■

Owner’s Guide

■

External remote sensor

■

Mounting fittings

■

DC 12V power source cord

■

Audio cord

■

Video cord

■

Filter

NOTE: This manual makes reference to optional Directed

Video accessories not included with this product.

Page 7

DIGITAL VIDEO

VIDEO

Disc Notes

DISC FORMATS SUPPORTED BY THIS PLAYER

DVD 12 cm disc/8 cm disc (Single-sided disc only)

Video CD 12 cm disc/8 cm disc

Super-VCD 12 cm disc

CD/MP3 12 cm disc/8 cm disc

DISC FORMATS NOT SUPPORTED BY THIS PLAYER

■

DVD-ROM

■

DVD-R/ DVD-RAM

■

CD-RAM

■

CDV

■

CD-G

■

Photo CD

HANDLING AND CLEANING

■

Dirt, dust, scratches, and warping discs will cause misoperation.

■

Do not place stickers or make scratches on discs.

■

Do not warp discs.

■

A disc should always be kept in its case when not in use to prevent damage.

■

Do not place discs in the following places:

1. Direct sunlight.

2. Dirty, dusty, and damp areas.

3. Near car heaters.

4. On the seats or dashboard.

DISC CLEANING

Use a dry soft cloth to wipe the surface. If the

disc is quite dirty, use a soft cloth slightly mois-

tened with isopropyl (rubbing) alcohol. Never

use solvents such as benzine, thinner, or con-

ventional record cleaners as they may mar the

surface of the disc.

NOTE: A disc may become somewhat scratched (although

not enough to make it unusable) depending on how it is handled and conditions in the usage environment. These scratches are not an indication of any problem with the player.

Page 8

Front Panel Operation

FRONT PANEL FEATURES

1 On/Standby Button Turns the unit on and off.

2 Video Input Plug in alternate video input here.

3 Audio Input Plug in alternate audio input here.

4 Display Panel Displays playback information.

5 Disc Tray Place the disk here.

6 Play/Stop/Pause/Menu Button Plays, stops or pauses playback, and menu selection.

7 Open/Close Button Opens and closes the disc tray.

2 7

FRONT PANEL CONTROLS

■

Power ON/OFF - Press ON/STANDBY button (1) to turn the unit on/off.

■

Loading a Disc - Press OPEN/CLOSE button (7) and set the disc (label side up) onto the disc tray (4). Push the disc tray gently and it will close; the unit will begin playback.

■

Ejecting a Disc - Press OPEN/CLOSE button (7) and the disc tray will slide out. Then remove the disc and close the disc tray.

■

Stop Playback - Press STOP button (6), and

541

playback will cease.

■

Resume Playback - Press PLAY button (6), and playback will resume.

■

Audio/Video Inputs - The AUDIO (3) and VIDEO (2) inputs allow alternate audio

and video sources to play through the DVD player.

■

Menu - Press MENU button (6) to display the root menu. Press continuously to advance through the selections. Once the desired selection is highlighted, press PLAY button (6) to select.

Page 9

Display Panel Operation

DISPLAY PANEL FEATURES

1 DVD Indicator

2 Title Indicator

3 Chapter/Track Indicator

4 Repeat Play Indicator

5 Second Indicator

6 Minute Indicator

7 Hour Indicator

8 Title/Chapter/Track Indicator

9 Pause Indicator

10 Play Indicator

11 PBC Indicator

1011

68 7

Page 10

Remote Operation

REMOTE CONTROL BATTERY

■

Battery Installation

■

Press on the panel at the rear of the remote control and slide the battery cover open.

■

Insert the batteries while observing the correct (+) and (-) polarities.

■

Slide the battery cover into place on the back of the remote control.

■

Service life of batteries - The batteries normally last for about six months, although this depends on how often the remote control is used.

■

If the remote control until fails to work, even when if is operated near the player, replace the batteries.

■

Use size AAA batteries.

■

Do not drop, step on, or otherwise impact the remote control unit.

■

Do not mix old and new batteries.

■

If the remote control is not going to be used for a long time, remove the batteries.

REMOTE CONTROL OPERATION RANGE

This unit is supplied with an external remote sen-

sor which allows you to access all features by

remote control when the DVD unit is mounted in

a location where the DVD is out of the line of

sight.

The remote control should not be used from

more than about 23 feet (7m) from the remote

control sensor and within about 60 degrees of

the front of the payer. The operating distance

may vary according to the brightness of the

vehicle interior.

PRIOR TO USE

■

The player output signal must be adjusted to match the monitor system type. Press the SYSTEM (22) button to change the sys- tem output signal type as shown.

■

During playback, the TV volume may be at a lower level than other source units. If this is the case, adjust the volume to the desired level.

■

Select the appropriate screen type from the setup menu according to your monitor.

■

Connect the DVD player according to the instructions in the Installation section of this guide.

■

If the DVD player is connected to the monitor through a VCR, the picture may not be played back normally. It is strongly recommended not connecting the DVD player through a VCR.

■

The on-screen menu language of your player has been factory preset to English. If you would like to change the menu language, please refer to the Setup Menu sec- tion of this guide.

■

Check the following before using the DVD player:

■

The monitor and audio equipment are properly connected to the player.

■

The power for the monitor and audio equipment is turned on.

■

The input setting for the monitor and audio equipment is properly selected.

Page 11

Remote Control Functions

BUTTON FUNCTION

1 OPEN/CLOSE

2 DVD & MV/TV SELECT

3 SUBTITLE

4 LANGUAGE

5 REPEAT

6 A-B REPEAT

7 VOLUME

8 FR/FF SEARCH

9 PBC/SLOW

10 SETUP

11 DIRECTION BUTTONS

12 PLAY/ENTER

13 TITLE

14 ZOOM

15 MENU

16 PAUSE/STEP

17 STOP

18 PREVIOUS/NEXT

19 AUDIO MODE

20 RETURN

21 OSD

22 SYSTEM

23 TV/AV

24 MUTE

25 POWER

1 2

3 4

5 6

12 13

24 23

22 21

20 19

17 16

Page 12

Basic Operation

Operations in this section are common for all

discs types (DVD, CD, Video CD, and Super-VCD).

TURNING THE PLAYER ON/OFF

Press POWER (25) on the remote control to turn the player on, off, or to standby mode.

PLAY DISC

1. Press POWER (25) to turn on the player.

2. Press OPEN/CLOSE (1) to open the disc

tray.

3. Holding the disc by its edge, place it on the disc tray with the label side up.

4. Press PLAY (12), OPEN/CLOSE (1), or push the disc tray in to close; the disc will begin playing automatically.

5. If the disc doesn't begin playback automatically, press PLAY (12).

STOP DISC

Press STOP (17) once to stop play. Press PLAY

(12) to resume playback.

REMOVE DISC

Press OPEN/CLOSE (1) to open the disc tray for

removal of the disc.

PAUSE/RESUME PLAY

Press PAUSE (16) to pause play. Press PLAY (12)

to resume play.

SKIP TRACKS/CHAPTERS

Moving forward or back a chapter/track at a

time can be done by using the PREVIOUS/NEXT

(18) buttons.

1. Press NEXT to advance to the next chap-

ter/track on the disc.

2. Press PREV to return to the previous

chapter/track on the disc.

FAST FORWARD/FAST REWIND

Fast forward play or fast rewind play through

chapters/tracks can be done using the FR/FF

SEARCH (8) buttons during playback.

1. Press the right FR/FF button repeatedly to

fast forward play at 2x, 4x, 6x, and 8x normal speed.

2. Press the left FR/FF button repeatedly to

fast rewind play at 2x, 4x, 6x, and 8x normal speed.

3. Press PLAY (12) to resume playback at

normal speed.

VOLUME CONTROL

The audio output volume can be controlled

using the volume buttons. Press either VOLUME

(7) button (+ or -), and a volume bar graphic

will appear in the OSD indicating the volume

level. Press repeatedly or hold the volume but-

ton to raise or lower the volume.

NOTE: Each time the button is pressed the rate of play

will appear in the OSD.

REPEAT PLAY

Chapters and tracks can be repeated during

playback. Press REPEAT (5) during playback to

toggle through the following repeat functions.

Page 13

■

REPEAT CHAPTER - Repeats the DVD chapter or the audio CD track.

■

REPEAT TITLE - Repeats the DVD title or the Audio CD title.

■

REPEAT OFF - Repeat function discontinued

TIMED REPEAT PLAY

Sections of chapters/tracks can be chosen and

repeated with the A-B (6) button.

1. Press A-B (6) during playback, and A will be displayed on the monitor. This will set the starting point of timed repeat.

2. Press A-B (6) again, and B will be displayed on the monitor. This will set the ending point of timed repeat. The player will then repeat the disc information between points A and B.

3. Press A-B (6) again to turn timed repeat off.

NOTE: Some disc recording software may not allow the

timed repeat operation on certain discs.

AUDIO MODE

■

LEFT - Audio output will be left channel only.

■

RIGHT - Audio output will be right channel only.

■

STEREO - Audio output will be in stereophonic mode.

MUTE AUDIO

Audio can be muted at any time during play-

back.

1. Press MUTE (24) to mute the audio portion

of the disc during playback.

2. Press again to resume audio playback.

ZOOM PLAY

Press ZOOM (14) during playback to enlarge the

picture to twice its size. Press ZOOM (14) again

to enlarge the picture to four times its size.

Then use the DIRECTION BUTTONS (11) to move

the picture. To return the picture to normal size,

press ZOOM (14) repeatedly until ZOOM OFF

appears in the OSD.

Audio playback on CD/VCD can be changed from

mono to stereo using the AUDIO MODE (19) button.

Press AUDIO MODE (19) repeatedly to toggle

through all available selections. They will

appear in the OSD.

ON-SCREEN DISPLAY

Press OSD (21) at anytime to display informa-

tion about the current disc in the player. Press

again to clear the OSD from the screen.

Page 14

Advanced Operation

DVD OPERATION

TITLE MENU

The title menu has selections for disc playback

setup that usually include audio, language, sub-

titles, playback and special features. The avail-

able selections are determined by the recorded

material on the disc.

1. Press TITLE (13) on the remote and the title menu will be displayed.

2. Press the DIRECTION BUTTONS (11) to highlight a title.

3. Press PLAY (12) to begin title playback

ROOT MENU

The root menu has selections for program play-

back including chapters and special features.

1. Press MENU (15) anytime to display the root menu.

2. Use the DIRECTION BUTTONS (11) to highlight a menu item.

3. Press PLAY (12) to begin playback.

SLOW MOTION PLAYBACK

A disc may be viewed in slow motion using the

SLOW (9) button.

1. Press SLOW (9); playback will continue at the rate of speed indicated on the display.

2. Press SLOW (9) repeatedly to toggle through the available slow motion playback speeds.

3. Press PLAY (12) to return to normal playback speed.

NOTE: The rate of slow motion playback will be dis-

played in the On-Screen Display (OSD).

FRAME ADVANCE

The picture can be advanced one frame at a time

with the PAUSE/STEP (16) button.

1. During playback press PAUSE/STEP (16) to

pause playback.

2. Press PAUSE/STEP (16) repeatedly at this

time to advance the image one frame at a time.

3. Press PLAY (12) to return to normal

playback.

SUBTITLES OPERATION

During playback, subtitles can be turned on and

off, and the subtitle language can be changed

on discs with multiple subtitle language capa-

bilities.

1. Press SUBTITLE (3) during playback; the

subtitles indicator will be displayed.

2. Press SUBTITLE (3) repeatedly to toggle

through all language selections available on the disc.

3. Press OSD (21) to clear the screen.

NOTE: If the subtitles are not displayed immediately,

follow steps one and two until it is displayed

If a disc that supports closed caption is being played, the subtitles may overlap the closed caption on the monitor. Turn the subtitles off to avoid this.

Page 15

LANGUAGE CONTROL

Many discs have several languages available dur-

ing disc playback. They can be changed at any

time by pressing LANGUAGE (4). Each time the

button is pressed, the language will change and

the information about the current language will

appear in the OSD.

VIEWING ANGLE

Many DVDs have scenes that are recorded from

multiple angles. These scenes can be viewed from

other angles by using the TV/AV (23) button.

1. Press TV/AV (23), the angle the scene is viewed from will change and the angle mark will appear in the on-screen display.

2. Press TV/AV (23) repeatedly to change to different viewing angles.

3. Press OSD (21) to clear the screen.

CD/VCD OPERATION

BASIC CD/VCD OPERATION

Stop Disc, OSD, Mute, Fast Forward/Fast Rewind,

Pause/Resume Play, Volume, Skip Tracks, Audio

Mode, and Repeat Play operate as described in

the Basic Operation section of this guide.

Load an Audio CD; the disc information will be

displayed on-screen.

DISC PLAYBACK

Press PLAY (12) to begin playback; the screen

will show the track information.

ON-SCREEN DISPLAY (OSD)

Information about the current disc being played

can be displayed on screen.

1. Press OSD (21) to turn the OSD on and off.

MP3 OPERATION

BASIC MP3 OPERATION

Stop Disc, OSD, Mute, Pause/Resume Play,

Volume, Skip Tracks, Audio Mode, and Repeat

Play operate as described in the Basic Operation

section of this guide.

Load a disc with MP3 files into the player. The

disc information will appear on screen.

Page 16

If the menu appears on more than one page the

<< >> icons will be displayed. Use the PREVI-

OUS/NEXT (18) buttons to move to the addi-

tional menu pages.

Use the PREVIOUS/NEXT (18) buttons to high-

light an ALBUM or ROOT then press PLAY (12). If

an ALBUM is selected, the album sub-menu will

be displayed. If ROOT is selected, the track titles

will be displayed since there are no albums titled.

Setup Menu

Use the PREVIOUS/NEXT (18) buttons to select

the desired track and press PLAY (12) to begin

playback. During playback information will be

displayed on screen. Press RETURN (20) at any

time to return to the home menu.

NOTE: If the track menu appears on more than one

page, << >> still appears next to the menu. Use the PREVIOUS/NEXT (18) buttons to move to the additional menu pages.

The setup menu contains settings for disc play-

back and should be used to adjust the DVD play-

er according to the disc being played, personal

preferences, and the type of equipment the DVD

player is connected to.

SETUP MENU NAVIGATION

1. Press SETUP (10) to enter or exit the Setup Menu Main Page.

2. Use the DIRECTION BUTTONS (11) to highlight a selection from the Setup Menu Main Page.

3. Press the PLAY (12) button to enter the selections menu page.

4. Use the DIRECTION BUTTONS (11) to

highlight a selection in this menu page. As each selection is highlighted, a submenu of possible settings will be displayed to the right. Use the right DIRECTION BUT- TON (11) to enter the sub-menu.

5. Use the DIRECTION BUTTONS (11) to

highlight a setting in the submenu, and then press the PLAY (12) button to con- firm the setting.

6. Use the left DIRECTION BUTTON (11) to

exit the submenu and return to the previous menu.

7. To exit the Setup Menu at any time press

the SETUP (10) button.

Page 17

GENERAL SETUP PAGE

When the General Setup page has been entered

the on-screen display will appear as shown.

TV DISPLAY

The TV Display submenu sets the screen shape

output to match the type of monitor connected.

For information about monitor types refer to the

Screen Format section of this guide.

TV TYPE

The TV Type submenu sets the video output to

the type of monitor connected. For information

about monitor types refer to the Screen Format

section of this guide.

ANGLE MARK

The Angle Mark submenu will turn the angle

mark indicator in the OSD on and off during disc

playback.

CAPTIONS

The Captions submenu will turn the captions on

and off during disc playback.

SCREEN SAVER

The Screen Saver submenu will turn the screen

saver on and off.

DOLBY DIGITAL SETUP

The Dolby Digital Setup page is for setup of

Dolby Digital signal Processing.

NOTE: This unit only supports two-channel stereo opera-

tions, therefore all settings in this menu should remain in their default setting.

PASSWORD SETUP PAGE

The Password Setup Page menu allows adult con-

trol so unauthorized individuals can not change

any of the settings in the Preferences Page. The

Preferences Menu Page cannot be entered unless

the password mode has been turned off.

PASSWORD MODE ON/OFF

Enter the Password Setup Page. Then select the

desired Password mode, and press PLAY (12) to

confirm the selection.

Page 18

Enter the Password by pressing NEXT (18) five

times. Press PLAY (12) to enter the password;

the Password Setup Page will appear. Then press

the left DIRECTION BUTTON (11) to highlight

the password mode. The password mode is now

set.

PREFERENCES PAGE

Enter the Preferences Page.

NOTE: Password mode must be turned OFF and the disc

must be in stop mode to enter the Preferences Page.

AUDIO

The Audio submenu is used to select the audio

language. This feature is usually adjusted in the

disc title menu.

SUBTITLES

The Subtitles submenu is used to turn subtitles

on and off, and to select the subtitle language.

This feature is usually adjusted in the disc title

menu.

DISC MENU

The Disc Menu submenu is used to set the on-

screen disc menu language. This feature is usu-

ally adjusted in the disc title menu.

COUNTRY/REGION

The Country/Region submenu is used to set the

player for the country or region, and should

match the region rating of the disc being

played.

PARENTAL

The Parental submenu is used to set the rating

level for discs that are allowed to be played.

DEFAULTS

The Defaults submenu will set all player setting

to factory default.

Page 19

SCREEN FORMAT

TV SYSTEM

NTSC is the default setting and is the standard

system for video monitors in North America.

TV SHAPE

DVDs and VCDs have several screen formats that

are usually indicated on the package. First

determine the screen format for the disc you are

playing and adjust the player accordingly.

PAL, PAL 60, and PAL M are settings for moni-

tors outside the North American continent.

Consult your authorized dealer for the proper

setting.

Auto will automatically adjust the player output

to match the monitor type.

If the picture has no color, abnormal color or the

video doesn't play properly, check the monitor

and player settings to make sure they are the

same.

The graphic below gives a depiction of how dif-

ferent disc formats will look on a monitor.

Page 20

Installation

CONNECTING TO A STEREO TV

BASIC CONNECTION

■

Do not block ventilation holes of the DVD player and arrange it so air can circulate freely.

■

Read these instructions thoroughly before connecting audio and video cables.

■

Ensure that you observe the color coding when connecting audio and video cables.

REMOTE CONTROL

To install the external remote sensor, simply plug

it into the REMOTE IN socket located at the rear

of the DVD and route the sensor cable to the

front of the vehicle, mount the sensor in a con-

venient location so that the remote control is in

the line of sight of the external remote sensor.

■

Before installing the unit, connect the wiring temporarily and test the system for proper operation.

■

Use only the parts included with the unit to ensure proper installation. The use of unauthorized parts can cause malfunctions. Consult with your nearest dealer if installation requires the drilling of holes or other modifications of the vehicle.

■

Install the unit where it does not get in the driver's way and cannot injure the passenger if there is a sudden or emergency stop. For optimum performance, this unit should NOT be mounted at an angle of more than 5 degrees from horizontal.

■

Avoid installing the unit where it would be subject to high temperature, such as direct sunlight, hot air from the heater, or where it would be subject to dust, dirt, or excessive vibration.

NOTE: Do not mount the unit where it will be stepped on

or where items will be placed on top of or spilled into the unit.

MOUNTING THE UNIT

This unit can be mounted either under a cabinet

or under a seat by using the brackets supplied in

the kit. Attach the mounting brackets as shown

in the drawing below according to the final

mounting position of the player.

If mounting the player under a seat, attach the

brackets using the bottom holes. This will allow

the player sufficient ventilation for proper oper-

ation and avoid moisture collection that may

cause moisture collection.

Always mount the player to a solid location to

avoid possible vibration and shock.

Page 21

WIRING CONNECTIONS

1. POWER CONNECTOR - The RED power wire must be connected to a wire that has (+) 12 volts when the key is in the accessory position. The BLACK ground wire must be connected to a metal chassis point, preferably scraped sheet metal. The YELLOW wire must be connected to a constant 12 volt source.

2. EXTERNAL REMOTE CONTROL CONNECTOR Insert the 1/8" pin plug for the External Remote Sensor eye into this socket.

3. VIDEO OUT - Connect the YELLOW Composite Video RCA cable to this jack.

4. AUDIO OUT - Connect the system L/R stereo Audio RCA cables to these jacks.

2 3

Page 22

Troubleshooting

PROBLEM SOLUTION

NO SOUND 1. Check all audio cable connectors in the system for loose or

improper connections.

2. Test system components for proper power and operation.

3. Make sure that none of the components is in MUTE mode.

NO PICTURE 1. Check all video cable connectors in the system for loose or

improper connections.

2. Test system components for proper power and operation.

3. Make sure the monitor is turned on and set to the proper channel or input zone.

NO REMOTE FUNCTION 1. Remove any objects that may be blocking the IR eye.

2. Make sure the remote IR eye is fully plugged into the con nector on the rear panel.

3. Test and replace any depleted remote control batteries.

PARTIAL OR NO DISPLAY 1. Inspect the disc for damage or dirt.

2. Check the monitor power and video cables for loose con nections.

3. Check the system setting to make sure all components are set for the same system type.

DISC TRAY WON'T OPEN 1. Wait 10 seconds before pressing the eject button again.

2. If the tray won't open with the eject button on the front panel use the eject button on the remote control.

Page 23

Specifications

Laser: Wavelength 650nm

Video System: NTSC/PAL/AUTO

Frequency Response: 30Hz ~ 20KHz + 2dB

Signal/Noise Ratio: >85dB

Audio Distortion/Noise: <-70dB (1KHz)

Channel Separation >85dB (1KHz)

Dynamic Range >80dB (1KHz)

Output - Audio Out (Analog) Output Level: 2

Load Impedance: 10K

Output - Video Out Output Level: 1

Load Impedance: 10K

Power Supply DC12V, 1.5A

Environment Temperature 5~35 C

Power Consumption <20W

Dimensions 170 x 215 x 73mm

Weight Approximately 1.4Kgs

NOTE: Specifications and design are subject to modification, without notice, due to improvements in technology.

+0-1V

Page 24

The company behind this system is Directed Electronics, Inc.

Since its inception, DEI®has had one purpose, to provide consumers with the finest vehicle security, car stereo products, rear seat entertainment, and accessories available. The recipient of more than 20 patents in the field of advanced electronic technology, DEI is ISO 9001 registered.

Quality Directed Electronics products are sold and serviced throughout North America and around the world.

Call (800) 274-0200 for more information about our products and services.

Directed®is committed to delivering world-class quality products

and services that excite and delight our customers.

Directed Electronics, Inc.

Vista, CA 92083

www.directed.com

N83102 1-03

Directed Video DV1700 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
