Dimplex Opti-Suite2Go2 Instruction Manual

08/52509/0 Issue 1

The product complies with the European Safety Standards EN60335-2-30 and the European Standard Electromagnetic Compatibility (EMC)
EN55014, EN60555-2 and EN60555-3. These cover the essential requirements of EEC Directives 2006/95/EC and 2006/108/EC

UK

Opti-Suite2Go²

1

3

2

IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE

Important Safety Advice

When using electrical appliances, basic
precautions should always be followed to reduce

the risk of re, electrical shock and injury to

persons, including the following:
If the appliance is damaged, check with the
supplier before installation and operation.
Do not use outdoors.
Do not use in the immediate surroundings of a
bath, shower or swimming pool.
Do not locate the appliance immediately below

a xed socket outlet or connection box.

The appliance carries the Warning
symbol DO NOT COVER, indicating
that it must not be covered.

This appliance can be used by children
aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities

or lack of experience and knowledge if they

have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
shall not play with the appliance. Cleaning and
user maintenance shall not be made by Children
without supervision.

Children of less than 3 years should be kept
away unless continuously supervised. Children
aged from 3 years and less than 8 years shall
only switch on/off the appliance provided that
it has been placed or installed in its intended
normal operating position and they have been
given supervision or instruction concerning use
of the appliance in a safe way and understanding
the hazards involved. Children aged from 3
years and less than 8 years shall not plug in,
regulate and clean the appliance or perform
user maintenance.

Do not use this appliance in series with a
thermal control, a program controller, a timer
or any other device that switches on the heat

automatically, since a re risk exists when the

appliance is accidentally covered or displaced.
Ensure that furniture, curtains or other
combustible material are positioned no closer
than 1 metre from the appliance.
In the event of a fault unplug the appliance.
Unplug the appliance when not required for
long periods.
Although this appliance complies with safety
standards, we do not recommend its use on deep
pile carpets or on long hair type of rugs.
The appliance must be positioned so that the
plug is accessible.
If the supply cord is damaged it must be
replaced by the manufacturer or service agent

or a similarly qualied person in order to avoid

a hazard.
Keep the supply cord away from the front of
the appliance.
Warning: In order to avoid overheating, do not
cover the appliance. Do not place material or
garments on the appliance, or obstruct the air
circulation around the appliance, for instance
by curtains or furniture, as this could cause

overheating and a re risk.

Opti-Suite2Go²
Model: OPS2G2

UK

Warning: In order to avoid a hazard due to
inadvertent resetting of the thermal cut-out,
this appliance must not be supplied through an

external switching device, such as a timer, or

connected to a circuit that is regularly switched
on and off by the utility.
CAUTION - Some parts of this product can become
very hot and cause burns. Particular attention has
to be given where children and vulnerable people
are present.

The heater carries the Warning symbol, indicating
that it must not be covered. The replace must be

securely xed to the wall using the xing strap,

wall plug and screw supplied, see diagram 3 for
recommended position.

This instruction can be found at

WWW.DIMPLEX.CO.UK

General

Unpack the heater carefully and retain the packaging for possible

future use, in the event of moving or returning the re to your

supplier.

The re incorporates a ame effect, which can be used with or

without heating, so that the comforting effect may be enjoyed at

any time of the year. Using the ame effect on its own only requires

little electricity.

Before connecting the heater check that the supply voltage is the
same as that stated on the heater.

Please note: Used in an environment where background noise is
very low, it may be possible to hear a sound which is related to

the operation of the ame effect. This is normal and should not

be a cause for concern.

Electrical connection

WARNING – THIS APPLIANCE MUST BE EARTHED

This heater must be used on an AC ~ supply only and the voltage
marked on the heater must correspond to the supply voltage.

Before switching on, please read the safety warnings and operating
instructions.

Fixing - see Fig. 1&3.

The appliance should be securely xed by the nylon xing strap

provided. Step 1. screw the strap to the Opti-Suite2Go² as

illustrated in Fig.1. Next Drill holes using a 6mm drill bit into the

block wall, insert the plug into the wall and place the end of the
nylon strap over the plug and screw tightly to the wall. (Special
fastners are required for stud walls)

Manual Controls - see Fig. 2

Three switches provide a choice of heat setting. Each switch is
activated when the bottom half of the switch is pushed in.

Switch 1 Controls the electricity supply to the heater.

Note: This switch must be in the ON position for the
heater to operate with or without heat.

Switch 2 Provides 1kw heat output.

Switch 3 Provides 2kw output when used in conjunction with

switch 2

Continued

IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE

UK

Dimplex

Millbrook House
GrangeDrive
HedgeEnd
Southampton
Hampshire.SO30 2DF

TEL: [phone]
FAX: [phone]
WEBSITE: www.dimplex.co.uk
Republic of Ireland Tel. [phone]

[c] GDC Group Ltd,

All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing of Dimplex.

A division of GDC Group Ltd,

Opti-Suite2Go²
Model: OPS2G2

Thermal Safety Cut-out

A thermal safety cut-out is incorporated in the heater to prevent
damage due to overheating. This can happen if the heat outlet
was restricted in any way. The heater will switch on once the
obstruction has been removed and the heater has cooled. If the
cut-out continues to operate intermittently, the heater should be
switched off and a service agent contacted.

Maintenance

WARNING: ALWAYS DISCONNECT FROM THE POWER SUPPLY
BEFORE ATTEMPTING ANY MAINTENANCE.

Light Emitting Diode

This re is tted with LED (Light Emitting Diode) bulbs in place

of conventional bulbs . These generate the same light levels as
conventional bulbs, but use a fraction of the energy consumed.
These LED bulbs are maintenance – free and will not require
replacing during the life of the product.

Cleaning

WARNING – ALWAYS DISCONNECT FROM THE POWER SUPPLY
BEFORE CLEANING THE HEATER.

For general cleaning use a soft clean duster – never use abrasive
cleaners. The glass viewing screen should be cleaned carefully
with a soft cloth. DO NOT use proprietary glass cleaners.

To remove any accumulation of dust or fluff the soft brush
attachment of a vacuum cleaner should occasionally be used to
clean the outlet grille of the fan heater.

Three switches provide a choice of heat setting. Each switch is
activated when the bottom half of the switch is pushed in.

Recycling

For electrical products sold within the European
Community. At the end of the electrical products
useful life it should not be disposed of with household

waste. Please recycle where facilities exist. Check

with your Local Authority or retailer for recycling
advice in your country.

Model Number

The Model & Serial number of your product is displayed on the
rating plate at the rear of your product, you should have this
information to hand when contacting customer service.

After Sales Service

Your product is guaranteed for one year from the date of purchase.

Within this period, we undertake to repair or exchange this product
free of charge (excluding lamps & subject to availability) provided

it has been installed and operated in accordance with these
instructions.

Your rights under this guarantee are additional to your statutory
rights, which in turn are not affected by this guarantee.

Should you require after sales information or assistance with
this product, please contact 0844 879 3588 (UK) or 01 842 4833
(R.O.I.)

Please retain your receipt as proof of purchase.
