Owner’s Manual
Model
DFB4047
DF2305
DF2307SS
6901740259
DFB4047-NL
7206960100R09
IMPORTANT SAFETY INFORMATION: Always read this manual rst
before attempting to install or use this replace. For your safety, always
comply with all warnings and safety instructions contained in this manual
to prevent personal injury or property damage.
To view the full line of Dimplex products, please visit
www.dimplex.com
Page 2
2 www.dimplex.com
Table of Contents
Always use a qualied technician
or service agency to repair
this replace.
!
NOTE: Procedures and
techniques that are considered
important enough to emphasize.
CAUTION: Procedures and
techniques which, if not carefully
followed, will result in damage to
the equipment.
WARNING: Procedures
and techniques which, if not
carefully followed, will expose
the user to the risk of re,
serious injury, or death.
Welcome & Congratulations ................3
IMPORTANT INSTRUCTIONS ...............4
Fireplace Installation ......................7
Operation ..............................10
Maintenance ...........................12
Warranty ...............................15
Replacement Parts .......................17
Page 3
3
Welcome & Congratulations
Thank you and congratulations for choosing to purchase an electric
replace from Dimplex, the world leader in electric replaces.
Please carefully read and save these instructions.
CAUTION: Read all instructions and warnings carefully before
starting installation. Failure to follow these instructions may result in a
possible electric shock, re hazard and will void the warranty.
Please record your model and serial numbers below for future
reference: model and serial numbers can be found on the Model and
Serial Number Label of your replace.
NO NEED TO RETURN TO THE STORE
Questions with operation or assembly? Require Parts Information?
Product Under Manufacturer’s Warranty?
Contact us at: www.dimplex.com/customer_support
For Troubleshooting and Technical Support
OR Toll-Free 1-888-DIMPLEX (1-888-346-7539)
Monday to Friday 8:00 a.m. to 4:30 p.m. EST
Please have your model number and product serial
number ready. (See above)
Serial Number
Model Number
Model/CAT Number
Catalog Number
Page 4
4 www.dimplex.com
IMPORTANT INSTRUCTIONS
When using electrical appliances,
basic precautions should always
be followed to reduce the risk of
fire, electric shock, and injury to
persons, including the following:
① Read all instructions before
using the replace.
② The heater is hot when in use.
To avoid burns, do not let bare
skin touch hot surfaces. The trim
around the heater outlet becomes
hot during heater operation.
Keep combustible materials, such
as furniture, pillows, bedding,
papers, clothes, and curtains at
least 3 ft (0.9 m) from the front of
the unit and keep them away from
the sides and rear.
③ Extreme caution is necessary when any heater is used by
or near children or invalids and
whenever the unit is left operating
and unattended.
④ Always unplug the fireplace
when not in use.
⑤ Do not operate any heater
after it malfunctions. Disconnect
power at the service panel and
have the heater inspected by a
reputable electrician before reusing.
⑥ Do not operate any unit with
a damaged cord or plug, or if the
heater has malfunctioned, or if
the electric replace has been
dropped or damaged in any man-
ner, contact Dimplex Technical
Service at 1-888-346-7539.
⑦ Do not use outdoors.
⑧ The fireplace is not intended
for use in bathrooms, laundry areas and similar indoor locations.
Never locate heater where it may
fall into a bathtub or other water
container.
⑨ Do not run the cord under
carpeting (for units supplied with
a cord). Do not cover cord with
throw rugs, runners, or the like.
Arrange cord away from trafc area and where it will not be
tripped over.
⑩ To disconnect the unit, turn
the controls off, and then remove
the plug from the outlet.
⑪ Do not insert or allow foreign
objects to enter any ventilation
or exhaust opening as this may
cause an electric shock or re, or
damage to the heater.
⑫ To prevent a possible re, do
not block air intake or exhaust in
Page 5
5
SAVE THESE INSTRUCTIONS
IMPORTANT INSTRUCTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
NO USER-SERVICABLE PARTS INSIDE
any manner.
⑬ All electrical heaters have
hot and arcing or sparking parts
inside. Do not use in areas where
gasoline, paint, or ammable liquids are used or stored.
⑭ Do not modify the replace.
Use it only as described in this
manual. Any other use not recommended by the manufacturer
may cause re, electric shock or
injury to persons.
⑮ This unit may have a polarized plug (one blade is wider than
the other). The plug will t in a
polarized outlet only one way. If
the plug does not t fully in the
outlet, reverse the plug. If it still
does not t, contact a qualied
electrician to install the proper
outlet.
⑯ Always plug heaters directly
into a wall outlet/receptacle.
Never use with an extension cord
or relocatable power tap (outlet/
power strip).
⑰ Do not burn wood or other
materials in the replace.
⑱ Do not strike the glass front.
⑲ Always use a certied electri-
cian should new circuits or outlets
be required.
⑳ Always use properly ground-
ed, fused and polarized outlets.
㉑ Disconnect all power supply
before performing any cleaning,
maintenance or relocation of the
unit.
㉒ When transporting or storing
the unit and cord, keep in a dry
place, free from excessive vibra-
tion and store so as to avoid dam-
age.
WARNING: To avoid
overheating, do not cover the
heater.
Page 6
6 www.dimplex.com
CAUTION: This equipment has been
tested and found to comply with the limits
for Class B digital device, pursuant to
part 15 of the FCC Rules. These limits
are designed to provide reasonable
protection against harmful interference in
a residential installation. This equipment
generates, uses and can radiate radio
frequency energy and, if not installed and
used in accordance with the instructions,
may cause harmful interference to radio
or television reception, which can be
determined by turning the equipment off
and on, the user is encouraged to try to
correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and the receiver.
• Connect the equipment into an outlet
on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
Operation is subject to the following
two conditions: (1) this device may not
cause interference and (2) this device
must accept any interference, including
interference that may cause undesired
operation of the device.
IMPORTANT INSTRUCTIONS
WARNING: Remote control
contains small batteries.
Keep away from children. If
swallowed, seek medical attention
immediately.
WARNING: Do not install
battery backwards, charge, put
in re or mix with used or other
battery types - may explode or
leak causing injury.
!
NOTE: Changes or
modications not expressly
approved by the party responsible
for compliance could void
user's authority to operate the
equipment.
Page 7
7
Fireplace Installation
This section provides easy step
by step instructions for selecting a
location and preparing the site to
install the replace into:
• Existingreplace
• New wall construction
• Dimplex mantel surround
kit or custom made mantel
surround
WARNING: Ensure the power
cord is not installed so that it is
pinched or against a sharp edge
and ensure that the power cord is
stored or secured to avoid tripping
or snagging to reduce the risk
of re, electric shock or injury to
persons.
WARNING: Construction
and electrical outlet wiring must
comply with local building codes
and other applicable regulations
to reduce the risk of re, electric
shock and injury to persons.
WARNING: Do not attempt
to wire your own new outlets or
circuits. To reduce the risk of re,
electric shock or injury to persons,
always use a licensed electrician.
WARNING: To reduce the risk
of re, do not store or use gasoline or other ammable vapors or
liquids in the vicinity of the heater.
!
NOTE: A 15amp, 120-volt cir-
cuit is required. A dedicated circuit is preferred but not essential
in all cases. A dedicated circuit
will be required if, after installation, the circuit breaker trips or
the fuse blows on a regular basis
when the heater is operating. Additional appliances on the same
circuit may exceed the current
rating of the circuit breaker.
CAUTION: High temperature,
risk of re, keep electrical cords,
drapery, furnishings, and other
combustibles at least 3 ft (0.9 m)
from the front of the heater.
!
NOTE: The replace insert is
to be installed in an opening with
minimum dimensions: 24 in. (610
mm) wide by 23 in. (585 mm) high
and 11 ½ in. (292 mm) deep.
CAUTION: Clearance for air
circulation beneath the replace
insert is provided by four (4) rubber feet (Figure 1). Do not install
the replace insert directly on
carpet or similar surfaces which
may restrict air circulation. If installing the replace in a carpeted
area, place a one-piece, solid, at
surface under the replace insert.
Ensure that all 4 of the insert’s
feet rest securely on this surface.
Page 8
8 www.dimplex.com
Existing Fireplace Installation
1. Seal all drafts and vents with
non-brous insulation materials to prevent chimney debris
from falling into the replace
insert. Do not install into an
existing replace that is prone
to leaks or dampness.
2. Cap the top of the chimney
ue to prevent rain from
entering.
3. Plan your electrical power
supply.
4. The power cord can run along
the front of the hearth to an
outlet near the replace.
WARNING: To prevent per-
sonal injury you should hire a
professional to cap the chimney ue or cut a hole in the
existing replace for wiring.
If you return your existing
replace to its original use
(example wood burning), it
should be inspected by the
local building department prior
to use to reduce the risk of re
and personal injury.
New Wall Construction
1. Mark the desired location on
the oor and store the replace in a safe, dry and dust
free location.
Fireplace Installation
23
3
8
"
(594 mm)
11
1
8
"
(283 mm)
22
1
2
"
(572 mm)
Figure 1
Page 9
9
2. Use studs to frame an opening of 24 in. (610 mm) wide X
23 ¼ in. (591 mm) high X 11
½ in. (292 mm) deep (Figure 2).
3. Plan your electrical power
supply.
Mantel Installation
1. Install the replace into the
mantel (refer to mantel as-
sembly instructions).
!
IMPORTANT: If not using a
Dimplex mantel, the replace
must be installed in an enclosure
with the following minimum internal/opening dimensions - Figure
2.
Option #1 - The power cord can
be lead from behind the replace trim and along the wall
to an outlet near the replace.
Option #2 - A new outlet can be
installed inside the new frame
construction.
Option #3 - The power cord can
be lead from behind the mantel and along the wall to an
outlet near the replace.
1. Make sure the units 3-Posi-
tion Switch is switched Off
(refer to operating instruction
section).
2. Plug the unit into a 15 Amp,
120 Volt outlet.
Fireplace Installation
23 ¼"
(591 mm)
11 ½"
(292 mm)
Figure 2
24"
(610 mm)
Wiring
Page 10
10 www.dimplex.com
Operation
WARNING: This electric
rebox must be properly installed
before it is used.
Manual Controls
A - 3-Position Switch
The power switch has two On positions marked with “ I ” and “ II ”.
The “ I ” position is for manual op-
eration. In this position the built-in
remote control is bypassed.
The “ II ” position is for operating
the unit with the provided remote
control. When in “ II ” position the
unit is operated with the ON and
OFF buttons of the remote control.
When the switch is in the center
(“O”) position the unit is off.
B - Heat Switch
The Heat On/Off Switch supplies
Figure 3
power to the heater fan and the
heater element. When the switch
is in the On position the heater
operates if the thermostat calls for
heat.
!
NOTE: The heater on your
replace may emit a slight,
harmless odor when rst used.
This odor is a normal condition
caused by the initial heating of
internal heater parts and will
not occur again.
C - Heater Thermostat Control
To adjust the temperature to your
individual requirements, turn the
thermostat control clockwise all
the way to turn on the heater.
When the room reaches the
desired temperature, turn the
thermostat knob counter clockwise until you hear a click. Leave
A
B
C
Page 11
11
Remote Control (Figure 4)
The replace is supplied with an
integrated On/Off remote control,
that is factory syncronized with
the rebox.
To operate, push the ON button
to turn replace on, push the OFF
button to turn the replace off.
The amount of heat produced will
be dependant on positioning of
manual heat controls.
!
NOTE: Ensure that the re-
place’s On/Off switch is set to
the remote control setting (“ II ”
position).
!
NOTE: Before attempting any
operation with the remote, pull
the plastic insulator strip out
from between the remote casing and battery cover
Initialization/Reprogramming
Follow these steps for remote
control initialization if required:
1. Set the 3-Position switch to
OFF ("O"). (Figure 3A)
2. Wait a minimum of ve (5)
seconds and set the 3-Position Switch to the Remote
position ("II").
3. Within 10 seconds of re-ac-
quiring power, press the ON
button located on the remote
control.
Operation
in this position to maintain the
room temperature at this setting.
For additional heat, turn clockwise
until you hear the click again and
the heater will turn on.
Resetting the Temperature
Cutoff Switch
The heater is protected with a
safety device to prevent overheating. Should the heater overheat,
an automatic cut out will turn the
heater off and it will not come
back on without being reset. It
can be reset by switching the
3-Position to Off and waiting 5
minutes before switching the unit
back on.
CAUTION: If the unit con-
tinuously cuts out, unplug the
unit and call customer service at
1-800-DIMPLEX.
Figure 4
Off
Button
On
Button
Battery
cover
Plastic
strip
Page 12
12 www.dimplex.com
Operation
!
NOTE: You will have only 10
seconds to perform this last
step. Failure to do so will
result in these steps needing
to be followed again.
This will synchronize the remote
control and receiver.
Battery Replacement
① Slide battery cover open on
the remote control (Figure 3).
② Correctly install one 12 Volt
(A23) battery in the battery
holder.
③ Close the battery cover.
Battery must be recycled
or disposed of properly.
Check with your Local
Authority or Retailer for recycling
advice in your area.
Maintenance
WARNING: Disconnect power
before attempting any main-
tenance or cleaning to reduce
the risk of re, electric shock or
damage to persons.
!
NOTE: The replace should
not be operated with an accumu-
lation of dust or dirt on or in the
unit, as this can cause a build up
of heat and eventual damage. For
this reason the heater must be
inspected regularly, depending
upon conditions and at least at
yearly intervals.
Figure 5
Glass clip
and outer screw
Page 13
13
Maintenance
Light Bulb Replacement
Light bulbs need to be replaced
when you notice a dark section
of the ame. There are two (2)
bulbs under the log set which
generate the ames and embers.
Light Bulb Requirements
Quantity of two clear chandelier
or candelabra bulbs with an E-12
(small) socket base, 60 Watt rating. Example: GE 60BC or Philips
60CTC. Do not exceed 60 Watts
per bulb.
Replacement:
CAUTION: Allow at least 10
minutes for light bulbs and heater
to cool off before touching bulbs
to avoid accidental burning of
skin.
1. Remove the front glass by
removing the 2 outer screws
holding the glass clips (Figure
5).
2. Remove the log grate by
removing the 2 mounting
screws (Figure 6).
3. Remove the log set by lifting
Figure 6
Figure 7
Log set
Light
assembly
Light bulbs
Log grate
Front
glass
Glass
clips
Page 14
14 www.dimplex.com
Maintenance
straight up (Figure 7).
4. Slide the light assembly
slightly out of the insert ap-
proximately 1 in..
5. Examine the bulb(s) to determine which bulb(s) require
replacement.
6. Unscrew the bulbs counter
clockwise.
7. Insert new bulbs.
8. Slide the light assembly back
into the insert.
9. Replace the log set into the
insert.
10. Reinstall the log grate.
11. Reinstall the front glass.
Glass Cleaning
The glass is cleaned in the factory
during the assembly operation.
During shipment, installation,
handling, etc., the clear door may
collect dust particles, these can
be removed by dusting lightly with
a clean dry cloth.
To remove ngerprints or other
marks, the clear door can be
cleaned with a damp cloth. The
clear door should be completely
dried with a lint free cloth to
prevent water spots. To prevent
scratching, do not use abrasive
cleaners or spray liquids on the
clear door surface.
Fireplace Surface Cleaning
Use warm water only to clean
painted surfaces. Do not use
abrasive cleaners on glass surface or spray liquids directly onto
any surface.
Unit Storage
Store the unit when not in use in
a dry, dust free location with the
power cord properly secured.
Servicing
Except for light bulb replacement
and cleaning described above, an
authorized service representative
should perform any other servicing.
Page 15
15
Products to which this limited warranty
applies
This limited warranty applies to the follow-
ing models of your newly purchased Dimplex electric replace DFB4047, DF2305,
DF2307SS, 6901740259, DFB4047-NL
and to newly purchased Dimplex replace
surrounds (mantels) and trims. This
limited warranty applies only to purchases
made in any province of Canada except
for Yukon Territory, Nunavut, or Northwest
Territories or in any of the 50 States of the
USA (and the District of Columbia) except
for Hawaii and Alaska. This limited warranty applies to the original purchaser of
the product only and is not transferable.
Products excluded from this limited warranty
Light bulbs are not covered by this limited
warranty and are the sole responsibil-
ity of the owner/purchaser. Products
purchased in Yukon Territory, Nunavut,
Northwest Territories, Hawaii, or Alaska
are not covered by this limited warranty.
Products purchased in these States,
provinces, or territories are sold AS IS
without warranty or condition of any kind
(including, without limitation, any implied
warranties or conditions of merchantability or tness for a particular purpose)
and the entire risk of as to the quality and
performance of the products is with the
purchaser, and in the event of a defect
the purchaser assumes the entire cost of
all necessary servicing or repair.
What this limited warranty covers and for
how long
Products covered by this limited warranty
have been tested and inspected prior to
shipment and, subject to the provisions
of this warranty, Dimplex warrants such
products to be free from defects in mate-
rial and workmanship for a period of 12
months from the date of the rst purchase
of such product.
The limited 12 month warranty period also
applies to any implied warranties that may
exist under applicable law. Some jurisdictions do not allow limitations on how long
an implied warranty lasts, so the above
limitation may not apply to the purchaser.
What this limited warranty does not cover
This limited warranty does not apply to
products that have been repaired (except
by Dimplex or its authorized service
representatives) or otherwise altered. This
limited warranty does further not apply
to defects resulting from misuse, abuse,
accident, neglect, incorrect installation,
improper maintenance or handling, or
operation with an incorrect power source.
What you must do to get service under
this limited warranty
Defects must be brought to the attention of
Dimplex Technical Service by contacting
Dimplex at 1-888-DIMPLEX (1-888-346-
7539), or 1367 Industrial Road, Cambridge Ontario, Canada N1R 7G8. Please
have proof of purchase, catalogue/model
and serial numbers available when calling.
Limited warranty service requires a proof
of purchase of the product.
What Dimplex will do in the event of a
defect
In the event a product or part covered by
this limited warranty is proven to be defec-
tive in material or workmanship during the
12 month limited warranty period you have
the following rights:
• Dimplex will in its sole discretion
replace such defective part(s) without
Warranty
Page 16
16 www.dimplex.com
charge, or if part replacement proves
not to be commercially practicable or
cannot be timely made, Dimplex may,
in lieu of replacing part(s) choose to
replace the unit.
• This limited warranty does not entitle
the purchaser to on-site or in-home
services. On-site or in-home services
may be performed at the purchaser’s
specic request and expense at
Dimplex’s then-current rates for such
services.
• The purchaser is responsible for
removal and transportation of such
product or part (and any repaired or
replacement product or part) to and
from the authorized dealer’s or service
agent’s place of business.
• Dimplex will not be responsible for,
and the limited warranty services shall
not include, any expense incurred for
installation or removal of the product
or part (or any replacement product
or part) or any labour or transporta-
tion costs. Such costs shall be the
purchaser’s responsibility.
What Dimplex and its dealers and service
agents are also not responsible for:
IN NO EVENT WILL DIMPLEX, OR ITS
DIRECTORS, OFFICERS, OR AGENTS,
BE LIABLE TO THE PURCHASER OR
ANY THIRD PARTY, WHETHER IN CONTRACT, IN TORT, OR ON ANY OTHER
BASIS, FOR ANY INDIRECT, SPECIAL,
PUNITIVE, EXEMPLARY, CONSEQUENTIAL, OR INCIDENTAL LOSS, COST,
OR DAMAGE ARISING OUT OF OR
IN CONNECTION WITH THE SALE,
MAINTENANCE, USE, OR INABILITY TO
USE THE PRODUCT, EVEN IF DIMPLEX
OR ITS DIRECTORS, OFFICERS, OR
AGENTS HAVE BEEN ADVISED OF
THE POSSIBILITY OF SUCH LOSSES,
COSTS OR DAMAGES, OR IF SUCH
LOSSES, COSTS, OR DAMAGES ARE
FORESEEABLE. IN NO EVENT WILL
DIMPLEX, OR ITS OFFICERS, DIRECTORS, OR AGENTS BE LIABLE FOR
ANY DIRECT LOSSES, COSTS, OR
DAMAGES THAT EXCEED THE PURCHASE PRICE OF THE PRODUCT.
SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION
OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION
OR EXCLUSION MAY NOT APPLY TO
THE PURCHASER.
How State and Provincial law apply
This limited warranty gives you specic
legal rights, and you may also have other
rights which vary from jurisdiction to
jurisdiction. The provisions of the United
Nations Convention on Contracts for
the Sale of Goods shall not apply to this
limited warranty or the sale of products
covered by this limited warranty.
Warranty
Page 17
17
Log Set ......................................... 0438200700RP
Flicker Motor ..................................... 2000220100RP
Flicker Rod ...................................... 5900340100RP
Heater Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2200490800RP
3 Position On/Off/On Switch ......................... 2800071100RP
Heater On/Off Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2800070200RP
Control Knob ..................................... 8800000300RP
Cutout .......................................... 2300270100RP
Thermostat ...................................... 2300150100RP
Cord Set ........................................ 4100090101RP
Front Glass ...................................... 5900380100RP
Partially Reective Glass ............................ 5900350100RP
Lampholder Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4200121000RP
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3000370500RP
Remote Control Receiver ........................... 3000380200RP
© 2013 Dimplex North America Limited
Dimplex North America Limited
1367 Industrial Road
Cambridge ON
Canada N1R 7G8
Replacement Parts
Loading...
