CLOVA
AUS/NZ
08/51487/0 Issue 0
1
424
1130 Recommended
184
300 M in.
600 Recommended
625
780
1
2
3
I
II
2
1
2
3
4
5
Clova
Model: CLV20B/CLV20W
IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
AUS/NZ
Important Safety Advice
When using electrical appliances, basic precautions
should be followed to reduce the risk of fire, electric
shock, and injury to persons, including the following:
If the appliance is damaged, check immediately with the
supplier before installation and operation.
Do not use this heater in the immediate surroundings of
a bath, shower or swimming pool.
Do not use outdoors.
This heater must not be located immediately above or
below a fixed socket outlet or connection box.
Do not cover or obstruct in any way the heat outlet grille
located underneath the heater. Overheating will result if
the heater is accidentally covered.
In the event of a fault unplug the heater.
Unplug the heater when not required for long periods.
The supply cord must be placed on the right hand side of
the heater away from the heat outlet underneath the
heater.
Although this heater complies with safety standards, we
do not recommend its use on deep pile carpets or on
long hair type of rugs.
This appliance is not intended for use by children or other
persons without assistance or supervision if their
physical, sensory or mental capabilities prevent them
from using it safely. Children should be supervised to
ensure that they do not play with the appliance.
The appliance must be positioned so that the plug is
accessible.
If the supply cord is damaged it must be replaced by the
manufacturer or service agent or similarly qualified
person in order to avoid a hazard.
Caution: In order to avoid a hazard due to inadvertent
resetting of the thermal cut-out, this appliance must not
be supplied through an external switching device, such
as a timer, or connected to a circuit that is regularly
switched on and off by the utility.
This heater is not equipped with a device to control the
room. Do not use this heater in small rooms when they
are occupied by persons not capable of leaving the room
on their own, unless constant supervision is provided.
The appliance must not to be located beneath a socket
outlet.
General
Unpack the heater carefully and retain the packaging for
possible future use, in the event of moving or returning the fire
to your supplier.
The fire incorporates a flame effect, which can be used with or
without heating, so that the comforting effect may be enjoyed at
any time of the year. Using the flame effect on its own only
requires little electricity.
Before connecting the heater check that the supply voltage is
the same as that stated on the heater.
Please note: Used in an environment where background noise
is very low, it may be possible to hear a sound which is related
to the operation of the flame effect. This is normal and should
not be a cause for concern.
Electrical
WARNING – THIS APPLIANCE MUST BE EARTHED
This heater must be used on an AC ~ supply only and the
voltage marked on the heater must correspond to the supply
voltage.
Do not switch the appliance on until properly installed. Please
read all the safety warnings and operating instructions.
Wall fixing - see Fig. 1
The appliance should be securely fixed to the wall using the
wall plugs and screws supplied for block walls.
Note – for studded walls special fasteners are required, see
diagram for recommended position of fixing screws.
Controls - see Fig. 2
Three switches provide a choice of heat settings. A switch is in
the ON position when the side with the markings on (i.e. I, I, or
II) is pushed in.
Switch 1 (I) Controls the electricity supply to the heater and
flame effect.
Note: This switch must be in the ON (I) position for heater to
operate with or without heat.
Switch 2 (I) Provides 1kW heat output.
Switch 3 (II) Provides 2kW output with switch 2.
Thermal Safety Cut-out
A thermal safety cut-out is incorporated in the heater to prevent
damage due to overheating. This can happen if the heat outlet
was restricted in any way. The heater will switch on once the
obstruction has been removed and the heater has cooled. If
the cut-out continues to operate intermittently, the heater should
be switched off and a service agent contacted.
Maintenance
WARNING: ALWAYS DISCONNECT FROM THE POWER SUPPLY
BEFORE ATTEMPTING ANY MAINTENANCE.
Lamp Replacement - see Fig. 3, Fig. 4 and Fig. 5
Turn off the appliance. Remove the loose coal or pebbles.
Remove the 2 screws holding the fuel bed in place, remove the
fuel bed.
Remove the rotisserie by carefully sliding the rubber connecter
off (Fig. 4).
Remove the defective lamp by unscrewing it as shown in Fig.5.
Replace with a 60W E14 SES Clear Candle lamp.
Take care not to over-tighten the lamp.
Refit the fret and fuel effect.
Cleaning
WARNING – ALWAYS DISCONNECT FROM THE POWER
SUPPLY BEFORE CLEANING THE HEATER.
For general cleaning use a soft clean duster – never use
abrasive cleaners. The glass viewing screen should be
cleaned carefully with a soft cloth. DO NOT use proprietary
glass cleaners.
To remove any accumulation of dust or fluff the soft brush
attachment of a vacuum cleaner should occasionally be used
to clean the outlet grille of the fan heater.
Clova
Model: CLV20B/CLV20W
IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
Recycling
At the end of the electrical products useful life it should
not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local
Authority or retailer for recycling advice in your country.
After Sales Service
Please see the separate Warranty leaflet for details of your
Warrantee & after sales service including contact details.
Should you require after sales service, please get in touch with
the supplier through whom you purchased the appliance, or
the contact number on your Warranty leaflet.
Please retain your receipt as proof of purchase.
AUS/NZ
Specification subject to change without prior notice
Glen Dimplex Australasia Ltd.
38 Harris Road,
East Tamaki, Auckland, New Zealand
Ph: +64 9 274 8265
Fax: +64 9 274 8472
Glen Dimplex Australia Pty Ltd
2/205 Abbotts Road
Dandenong South VIC 3175
Ph: 1300 556 816
N16269
